AEG-Electrolux ERA39395X8 User Manual

MMaannuuaall ddee iinnssttrruucccciioonneess
UUsseerr MMaannuuaall
ERA 39395 X8
Frigorifico
Fridge
electrolux
3
Gracias por elegir un producto Electrolux de primera clase, el cual esperamos le proporcione una gran satisfacción en el futuro. Electrolux ambiciona ofrecerle una amplia variedad de productos de calidad que haga su vida más cómoda. Usted encontrará algunos ejemplos en la portada de este manual. Por favor, tómese unos minutos para estudiar este manual de modo que pueda aprovecharse de los beneficios de su nueva máquina. Nosotros prometemos proporcionarle una experiencia superior como usuario y mucha tranquilidad. ¡Buena suerte!
4
electrolux
En este manual se utilizan los símbolos siguientes
Información importante para su seguridad personal y para evitar daños al electrodoméstico
Información general y consejos
Información medioambiental
El símbolo en el producto o en su embalaje indica que este producto no se puede tratar como desperdicios normales del hogar. Este producto se debe entregar al punto de recolección de equipos eléctricos y electrónicos para reciclaje. Al asegurarse de que este producto se deseche correctamente, usted ayudará a evitar posibles consecuencias negativas para el ambiente y la salud pública, lo cual podría ocurrir si este producto no se manipula de forma adecuada. Para obtener información más detallada sobre el reciclaje de este producto, póngase en contacto con la administración de su ciudad, con su servicio de desechos del hogar o con la tienda donde compró el producto.
electrolux
5
INDICE
Advertencias yy cconsejos iimportants 66 Uso 9 Limpieza de las partes internas 9 El panel de control 9 Display 10 Funcionamiento 10 Desconexión 10 Regulación de la temperatura 11 Menú de Funciones 11 Uso del compartimento frigorífico 12 Función Holiday 12 Refrigeración de alimentos y bebidas 13 Rejillas movibles 13 Compartimiento para botellas 13 Ubicación estantes de la contrapuerta 14 Compartimiento Cool-Fresh 14 Circulatión de aire 14
Consejos 15 Consejos para refrigeración 15 Manutención 15 Limpieza periódica 15 Temporadas largas de inactividad 16 Lámpara de iluminación 16 Desescarche 16 Datos ttécnicos 17 Como aactuar ssi eel aaparato nno funciona 17 Instalación 18 Colocación 18 Conexión eléctrica 18 Retenes-Repisas 19 Distanciadores posteriores 19 Reversibilidad de la puerta 20 Garantía/Servicio ppostventa 22 Garantía EEuropea 24 www.electrolux.com 25
6
electrolux
ADVERTENCIAS Y CONSEJOS IMPORTANTS
Es mmuy iimportante cconservar eeste libro dde iinstrucciones jjunto aal aaparato por ssi ffuera nnecesario cconsultarlo. SSi eel aparato sse vvendiese oo ttransfiriese aa otra ppersona, aacuérdese dde eentregarlo junto ccon éél ppara qque eel nnuevo propietario cconozca eel ffuncionamiento de lla mmáquina yy ssus aadvertencias.
En ccaso dde qque eeste aaparato, ddotado de ccierre mmagnético, ssustituya uuno con ccierre aautomático, aaconsejamos que lla ccerradura dde eeste úúltimo qquede inservible, aantes dde ddeshacerse dde éél. Así sse eevitará qque llos nniños, jjugando, puedan qquedarse eencerrados ddentro, con ggrave ppeligro dde ssus vvidas.
Estas aadvertencias hhan ssido redactadas ppara ssu sseguridad yy ppara la sseguridad dde llos ddemás. LLe rogamos, ppor llo ttanto, lleerlas atentamente aantes dde iinstalar yy uutilizar el aaparato.
Seguridad
• Este aparato no está pensado para ser utilizado por personas (incluidos los niños) con capacidades físicas, sensoriales o mentales reducidas, o que no tengan experiencia y conocimiento, a menos que una persona responsable de su seguridad les supervise o les ofrezca instrucción en el uso del aparato. Los niños deben ser supervisados para asegurarse de que no jueguen con el aparato.
• Es peligroso modificar o intentar modificar las características de este aparato.
• Quitar siempre el enchufe de la toma de corriente antes de efectuar cualquier operación de limpieza o manutención (como la substitución de la bombilla en aquellos aparatos que la tienen).
• No consumir nunca los cubitos de hielo recién sacados del congelador ya que podrían provocar quemaduras.
• Estos aparatos son pesados. Tener cuidado en los desplazamientos.
• EEste aaparato nno ccontiene een eel circuito rrefrigerante yy een eel aislamiento, ggases rrefrigerantes nocivos ppare eel oozono. EEl aaparato no ddebe sser eeliminado jjunto ccon los ddeshechos uurbanos yy chatarras. SSe ddebe eevitar eel ddaño del ccircinto rrefrigerante, ssobre ttodo en lla pparse pposterior ccerca ddel intercambiador. LLas iinformaciones sobre llos ccentros dde rrecepción sson suministradas ppor llas aautoridades municipales
• PPrestar lla mmáxima aatención ddurante las ooperaciones dde ddesplazamiento pare nno ddañar llas pparses ddel circuito rrefrigerante aa ffin dde eevitar las pposibles ssalidas dde lliquido.
• EEl aaparato nno ddebe sser ccolocado cerca dde ttermosifones oo ccocinas aa gas.
• EEvitar lla eexposición pprolongada ddel aparato aa llos rrayos ssolares
• LLa pparse pposterior ddel aaparato ddebe
electrolux
7
recibir uuna ccirculación dde aaire suficiente yy sse ddebe eevitar ccualquier daño aal ccircuito rrefrigerante.
• SSolamente ppare llos ccongeladores (excluidos llos eempotrados): ssu mejor uubicación ees eel ssótano.
• NNo iintroducir aaparatos eeléctricos en eel iinterior ddel eequipo ((por ejemplo: ffabricadora dde hhelados).
Asistencia
• Cualquier modificación que eventualmente fuese necesaria a la instalación eléctrica doméstica para poder instalar el aparato tiene que ser realizada sólo por personal competente.
• Para eventuales intervenciones dirigirse a un Centro de Asistencia Técnica autorizado y exigir las piezas de repuesto originales.
• En caso de necesitar reparaciones no intentar hacerlas personalmente. Las reparaciones efectuadas por personas no competentes pueden provocar daños. Ponerse en contacto con el Centro de Asistencia más cercano y emplear sólo repuestos originales.
Uso
• Los frigoríficos y/o congeladores domésticos están destinados sólo a la conservación y/o congelación de alimentos.
• Las mejores prestaciones se obtienen con temperaturas ambiente comprendidas entre
+18°C y +43°C (Clase T); +18°C y +38°C (Clase ST); +16°C y +32°C (Clase N); +10°C y +32°C (Clase SN); la clase de pertenencia está indicada en la placa matrícula situada en la cámara al lado del cajón verduras.
Atención:
en caso de temperaturas ambiente diferentes de las indicadas para la clase climática a la cual pertenece este producto, es preciso observar las indicaciones siguientes: cuando la temperatura ambiente desciende por debajo del valor mínimo puede suceder que la temperatura de conservación en el vano congelador no esté garantizada; por lo tanto, se aconseja que se consuman a lo más pronto los alimentos presentes en su interior.
• Los productos que hayan sido descongelados no se tienen que volver a congelar.
• Seguir atentamente las indicaciones del fabricante para la conservación y/o congelación de los alimentos.
• En todos los aparatos de refrigeración y congelación existen superficies que se cubren con escarcha. Según el modelo, la escarcha puede ser eliminada automáticamente (desescarche automático) o manualmente. No intentar nunca quitar la escarcha con un objeto puntiagudo ya que se podría dañar irremediablemente el evaporador. Utilizar para ello sólo el rascador de plástico que se suministra con el aparato. Por el
8
electrolux
mismo motivo no despegar nunca las cubetas del hielo con un cuchillo o cualquier otro objeto puntiagudo.
• No colocar en el compartimiento de la baja temperatura (congelador o conservador) bebidas gaseosas que podrían explotar.
Instalación
• El aparato se calienta considerablemente en la proximidad del condensador y del compresor, por lo tanto hay que verificar que el aire pueda circular libremente alrededor del mismo. Una ventilación insuficiente puede causar un mal funcionamiento y daños al aparato. Seguir cuidadosamente las instrucciones que se dan para la instalación.
• Una vez instalado el aparato verificar que no esté apoyado sobre el cable de alimentación.
Importante:
en caso de que el cable de alimentación se dañe, deberá ser sustituido con un cable especial. Ambos cables pueden ser solicitados al fabricante o al Servicio de asistencia.
• Si el aparato es transportado en forma horizontal es posible que el aceite contenido en el compresor pase al circuito refrigerante. Esperar por lo menos dos horas antes de poner en marcha el aparato para dar tiempo a que el aceite regrese al compresor.
Protección del
ambiente
Este aaparato nno ccontiene een eel ccircuito refrige-rrante yy een eel aaislamiento, ggases refrigerantes nnocivos ppara eel oozono. EEl aparato nno ddebe sser eeliminado jjunto con llos ddeshechos uurbanos yy chatarras. SSe ddebe eevitar eel ddano ddel circinto rrefrigerante, ssobre ttodo een lla parte pposterior ccerca ddel intercambiador. LLas iinformaciones sobre llos ccentros dde rrecepciõn sson suministradas ppor llas aautoridades municipales; LLos mmateriales uusados een este aaparato mmarcados ccon eel ssimbolo
son rreciclables.
electrolux
9
USO
Limpieza de las partes internas
Antes del empleo limpiar todas las partes internas con agua tibia y jabón neutro, a fin de eliminar el característico olor de nuevo y secarlas luego cuidadosamente.
No eemplear ddetergentes oo polvos aabrasivos qque ppodrían ddañar llas superficies.
El panel de control
A - Tecla de encendido / apagado del
aparato
B - Tecla de regulación de la
temperatura
C - Display de visualización de las
temperaturas y funciones
D - Tecla de activación de las
funciones
E - Tecla de confirmación
A
B
C
D
E
10
electrolux
Display
Si está encendido, indica que la temperatura mostrada en el display es la temperatura ambiente.
Indicador de temperatura positiva Indicador de la temperatura
Si está encendido, indica que está activa la función Child Lock
Si está encendido, indica que está activa la función Shopping
Si está encendido, indica que está activa la función Eco Mode
Importante Si la puerta permanece abierta durante mas de 7 minutos la luz interior será desconectada automáticamente la luz se reactivará al volver a cerrar y abrir la puerta.
Desconexión
La desconexión se realiza pulsando la tecla (A) durante más de 1 segundo. Después de esto, se indicará una cuenta atrás de la temperatura de -3 -2 -1.
Funcionamiento
Después de pulse la toma de corriente, si el display no se ilumina de conexión la tecla (A), encendido del aparato. Para la correcta conservación de los alimentos, es recomendable definir la función Eco Mode y las siguientes temperaturas: +5°C en el frigorífico
• Para modificar la temperatura, consulte la sección "Regulación de la temperatura".
electrolux
11
Regulación de la Temperatura
Apretando el botón (B), en el indicador parpadea la temperatura programada. Confirme la temperatura elegida pulsando el botón E (se oye un sonido) o esperando unos segundos (no se oye el sonido). El indicador indica de nuevo la temperatura actual dentro del compartimiento. La temperatura programada es alcanzada dentro de 24 h. Después de periodos largos sin usar el aparato no será necesario regular de nuevo la temperatura, ya que esta permanece almacenada en memoria.
¡Atención! Durante el periodo de estabilización, después de la primera puesta en marcha, la temperatura mostrada puede no corresponderse con la temperatura programada. Durante este periodo es posible que la temperatura mostrada sea differente a la temperatura programada.
Menú de Funciones
Pulsando la tecla D se activa el menú de funciones. La activación de cada función puede confirmarse pulsando la tecla. Si después de unos segundo no se confirma ninguna función el display saldrá del menú de funciones y regresará su estado normal.
En el display se indican las siguientes funciones:
Función Temperatura Ambiente Función Child Lock Función Shopping Función Eco Mode
Función Temperatura Ambiente
La función Temperatura ambiente se activa pulsando la tecla D (si es necesario, varias veces) hasta que
aparezca el icono correspondiente . En esta situación, se muestra la temperatura ambiente. Debe confirmar la selección pulsando en pocos segundos el botón E . Se oirá una señal acústica y el icono permanecerá activado. Se puede desactivar la función en cualquier momento pulsando la tecla D hasta que el icono correspondiente comience a parpadear y seguidamente pulsar el botón E.
Función Child Lock
La función Child Lock se activa pulsando la tecla D (si es necesario, varias veces) hasta que aparezca el
icono correspondiente . Debe confirmar la selección pulsando en pocos segundos el botón E . Se oirá una señal acústica y el icono permanecerá activado. En este estado, ninguna acción sobre los botones implicará variación alguna mientras la función esté activa.
12
electrolux
Se puede desactivar la función en cualquier momento pulsando la tecla D hasta que el icono correspondiente comience a parpadear y seguidamente pulsar el botón E.
Función Shopping
Si hay que introducir una gran cantidad de alimentos calientes, por ejemplo después de haber hecho la compra, se aconseja activar la función Shopping para enfriarlos más rápidamente y para evitar que suba la temperatura de los alimentos que ya están en el frigorífico.
La función Shopping se activa pulsando la tecla D (si es necesario varias veces) hasta que aparezca el
icono correspondiente . Debe confirmar la selección pulsando en pocos segundos el botón E . Se oirá una señal acústica y el icono permanecerá activado. La función Shopping se apaga automáticamente después de unas 6 horas. Se puede desactivar la función en cualquier momento pulsando la tecla D hasta que el icono correspondiente comience a parpadear y seguidamente pulsar el botón E.
Función Eco Mode
La función Eco Mode se activa pulsando la tecla D (si es necesario, varias veces) hasta que aparezca el
icono correspondiente (o fijando la temperatura en + 5°C). Debe confirmar la selección pulsando en pocos segundos el botón E . Se
oirá una señal acústica y el icono permanecerá activado. En este estado, las temperaturas se fijan de modo automático (+ 5°C), para obtener las mejores condiciones de conservación de los alimentos. Se puede desactivar la función en cualquier momento modificando la temperatura seleccionada en el compartimiento.
Uso del compartimento frigorífico
Es posible programar la temperatura de este compartimento entre +2°C y +8°C. Durante el funcionamiento normal se indica la temperatura dentro del compartimiento frigorífico.
¡Atención! Es normal que exista una diferencia entre la temperatura mostrada y la programada. En particular cuando:
• recientemente se ha modificado la temperatura programada.
• la puerta ha quedado abierta por mucho tiempo.
• se han introducido en el frigorífico alimentos calientes.
Función Holiday “H”
Al activar la función Holiday se regula la temperatura del frigorífico a +15 ºC. Esta función le permite mantener frigorífico vacío y con la puerta cerrada durante periodos largos como las vacaciones, evitándose la formación de malos olores.
electrolux
13
La función Holiday H puede regularse pulsando la tecla B. Al pulsar la tecla B, en el indicador parpadea el ajuste de temperatura actual. Vuelva a pulsar la tecla B. Cuando aparezca en pantalla la letra H, confirme la temperatura elegida apretando el botón E (oirá un sonido) o esperando unos segundos (no oirá el sonido). Ahora el refrigerador se encuentra en función Holiday del modo de ahorro de energía y el indicador muestra la letra H. Se puede desactivar la función en cualquier momento modificando la temperatura seleccionada en el compartimiento.
¡Atención! El frigorífico de estar totalmente vacío de alimentos cuando se active la función Holiday.
Refrigeracíon de alimentos y bebidas
Para utilizar de la mejor manera el compartimiento refrigerante, es necesario:
• no introducir comidas calientes o
líquidos en en evaporacíon;
• tapar o envolver los alimentos,
especialmente si son aromáticos;
• no colocar sobre las rejillas
papeles, cartones o plásticos que obstaculicen la circulacíon del aire.
Rejillas movibles
En las paredes del compartimento existen unas guías que consienten poner las rejillas a distintas alturas.
Compartimiento para botellas
Almacene las botellas con el cuello hacia adelante. Atención: Coloque echadas sólo las botellas sin abrir. Para guardar botellas ya abiertas puede usted alzar el compartimiento hasta dejarlo inclinado. Para ello tire del compartimiento hacia adelante hasta que sea posible virarlo hacia arriba e introduzca entonces la superficie delantera en el nivel inmediato superior.
D338
14
electrolux
Ubicación estantes de la contrapuerta
Para poder colocar confecciones de varios tamaños es posible colocar los estantes de la contrapuerta a varias alturas. La operación se efectúa de la siguiente manera: Empujar gradualmente el estante en el sentido indicado por las flechas hasta llegar a desengancharlo, luego volverlo a montar en la posición deseada.
Compartimiento Cool-Fresh
Los modelos dotados en la zona frigorífica con este compartimiento especial,están indicados para una mejor conservación de los alimentos frescos,altamente perecederos,como por ejemplo: mariscos, pescados, carnes, etc. Está situado en la parte inferior, directamente encima de la zona destinada a la conservación de verduras.
Circulación de aire
El compartimiento frigorífico está provisto de un ventilador especial que se activa actuando sobre el interruptor; el piloto verde encendido indica que el ventilador está en marcha.
Se aconseja el uso del ventilador cuando la temperatura ambiente exceda de los 25°C.
Este dispositivo consiente la refrigeración rápida de los alimentos y la máxima uniformidad de temperatura en el compartimiento.
SWITCH
electrolux
15
CONSEJOS
Consejos para refrigeración
Para un correcto uso aconsejamos: Carne:
debe ser envuelta en saquitos de plástico y colocada en el espacio situado sobre los cajones verdura.
En eesta pposicíon lla ccarne ppuede sser conservada aal mmáximo ppor 11 aa 22 ddias.
Alimentos ccocinados ,, pplatos ffríos, eetc. tienen que conservarse bien cubiertos y se pueden colocar en cualquier bandeja del frigorífico.
Fruta yy vverdura:
una vez lavada, ha de
colocarse en el cajón (cajones) inferior. Mantequilla yy qqueso:
deben colocarse en los reci-pientes adecuados o envueltos en hojas de aluminio o politileno, a fin de evitar el contacto con el aire.
Leche eembotellada:
bien tapada, en la
contropuerta. Bananas, ppapas, ccebollas yy aajo, ssi nno
están cconfeccionados, nno sse ddeben colocar een ffrigorífico.
MANUTENCIÓN
Desenchufar ssiempre eel aparato aantes dde pproceder aa cualquier ooperación dde llimpieza.
Atención Este aaparato ccontiene
hidrocarburos een eel ccircuito refrigerante; ppor llo ttanto eel mantenimiento yy lla rrecarga deben sser eefectuados exclusivamente ppor ppersonal autorizado ppor lla eempresa.
Limpieza periódica
Muchos ddetergentes eespecíficos ppara las ssuperficies dde ccocina ccontienen agentes qquímicos qque ppuede atacar/perjudicar llas ppartes een pplástico presentes een eeste aaparato. SSe aconseja ppues llimpiar eel rrevestimiento de eeste aaparato ssólo ccon aagua caliente qque ccontenga uuna ppequeña cantidad dde ddetergente llíquido ppara vajillas. Limpiar el interior con agua templada y bicarbonato y las partes exteriores esmaltadas con cera a la silicona; limpiar el condensador y el motocompresor con un cepillo o un aspirador. Esta operación mejorará el funcionamiento con el consiguiente ahorro de energia.
16
electrolux
Temporadas largas de inactividad
Durante los períodos en los cuales el aparato no esté funcionando observar las siguientes precauciones:
• desenchufarlo;
• sacar todos los alimentos;
• limpiar cuidadosamente el interior y
todos los accesorios.
• Dejar las puertas entornadas para
facilitar la circulación del aire, a fin de evitar la formación de olores desagradables.
Lámpara de iluminación
Para la sustitución eventual de la lámpara oprimir el enganche posterior y al mismo tiempo sacar la tapa en dirección de las flechas.
Atención
Sustituir la lámpara por otra de igual potencia (la potencia máxima está indicada en el difusor de luz).
Desescarche
La escarcha del evaporador del compartimento refrigerante se elimina automáticamente a cada interrupcion del motocompresor. El agua de la escarcha derretida, mediante un canal adecuado, se recoge en un pequeño depósito colocado en la parte posterior sobre el motocompresor del aparato, de donde evapora.
Se rrecomienda llimpiar pperiódicamente el aagujero dde ddesagüe ddel aagua dde desescarche, ssituado een lla pparte central ddel ccanal een eel ccompartimiento refrigerante, uutilizando eel ««limpiador» adecuado qque sse eencuentra een eel agujero, ppara eevitar qque eel aagua dde desescarche ccaiga ssobre llos alimentos.
Atención
Se rrecomienda nno uutilizar uutensilios metálicos ppara qquitar lla eescarcha aa ffin de eevitar ggraves ddaños aal aaparato.
No uusar ddispositivo mmecánico aalguno uu otro mmedio aartificial ppara aacelerar eel processo dde ddesescarche eexcepto llos recomendados.
D037
D037
electrolux
17
COMO ACTUAR SI EL APARATO NO FUNCIONA
Si el aparato presentase anomalías será oportuno controlar:
• Que esté bien enchufado y que el interruptor de la instalación eléctrica esté conectado.
• Que no haya un corte de energía eléctrica.
• Además si el aparato hace demasiado ruido verificar que los costados no estén en contacto con muebles que pueden causar ruidos o vibraciones y que la unidad refrigerante no vibre.
• Si se ven restos de agua en el fondo del refrigerador comprobar que el orificio de desagüe de la escarcha derretida no esté obturado (ver cápitulo Desescarche).
Después de hacer las verificaciones anteriores, si la anomalía persiste, llame al Centro de Asistencia Técnica más cercano.
Es iimportante een eel mmomento dde llamar pproporcionar lla rreferencia ddel modelo yy eel nnúmero dde mmatrícula ddel aparato iindicados een eel ccertificado dde garantía oo een lla ttarjeta mmatrícula.
DATOS TÉCNICOS
378
0,403
147
1800
600
645
Capacidad neta del frigorífico en litros
Consumo energético en kWh/año
Consumo energético en kWh/día
Dimensiones en mm
Altura
Ancho
Profundidad
Los datos técnicos se indican en la placa-matrícula situada sobre el lado izquierdo interno del aparato.
18
electrolux
Conexión eléctrica
Antes de enchufar el aparato, asegurarse de que la tensión y la frecuencia indicadas en la tarjeta matrícula, correspondan a las de la instalación doméstica. Se admite una oscilación de 6% sobre la tensión nominal. Para el funcionamiento a tensiones distintas, habrá que utilizar un autotransformador de potencia adecuada. Asegurarse de que la toma de corriente y el enchufe sean compatibles entre sí sin tener que interponer reducciones ladrones o adaptadores varios. Si fuera necesario, cambiar la toma de la instalación de la casa con una adapta. Es iindispensable cconectar eel aaparato aa una ttoma dde ttierra eeficaz. Para ello el enchufe del cable de alimentación está dotado de un adecuado contacto. Si la toma de corriente de la instalación doméstica no estuviera conectada a tierra, conectar el aparato a una instalación de tierra, conforme a las leyes en vigor, consultando para ello con un técnico especializado. El ffabricante ddeclina ttoda responsabilidad een eel ccaso qque eesta norma nno ssea rrespetada.
Este aparato es conforme a las siguientes Directivas
Comunitarias:
87/308 CCEE
del 2/6/87 relativa a la
supresión de interferencias radio.
73/23 CCEE
19/02/73 (Baja tensión)
y modificaciones sucesivas;
89/336 CCEE
03/05/89 (Compatibilidad electromagnética) y modificaciones sucesivas.
INSTALACIÓN Colocación
Situar el aparato lejos de fuentes de calor, como: radiadores, estufas, exposición directa a los rayos del sol, etc. Asegurarse de que en les partes posterior, superior e inferior no haya ningún obstáculo que impida la circulacidn del aire. Para que el aparato rinda mejor, la distancia mínima entre la parte superior y el eventual mueble pénsil de encima, debería ser por lo menos de 100 mm . La solución preferible, de todos modos, seria la ilustrada en la (sin mueble). Dos patas graduables, situadas en la base del mueble, consienten rivelarlo a la perfección. Asegurarse de que la toma de corriente y el enchute sean compatibles entre sí sin tener que interponer reducciones ladrones o adaptadores varios. Si fuera necesario, cambiar la toma de la instalación de la casa con una adepta.
Importante
Se debe
poder desenchufar el aparato; por lo tanto una vez efectuada la instalación es necesario que el enchufe no quede escondido.
100 mm10 mm
10 mm
NP007
electrolux
19
Retenes-Repisas
Su aparato dispone de retenes-repisas que permiten bloquear las repisas durante el transporte.
Para quitarlos actuar como sigue: mover los retenes-repisas en la
dirección de la flecha, subir el vidrio por la parte trasera y empujarlo hacia adelante hasta que queda libre, seguidamente quitar los retenes.
Distanciadores posteriores
En el aparato hay dos distanciadores que deberàn ser montados como se muestra en la figura.
Aflojar los tornillos, introducir el distanciador debajo de la cabeza del tronillo y volver a atornillar.
A
B
C
20
electrolux
• Quitar la puerta
• Retirar usando una herramienta la cubierta (e) y desatornilla el eje de la bisagra inferior (f) y atornillalo en el lado contrario.
• Reinsertar la cubierta (e) en el lado contrario.
• Reinsertar la puerta.
• Poner atención para que el canto frontal de la puerta tiene que estar en paralelo con el panel superior.
• Fijar el tope puerta en el lado opuesto.
• Posicionar y ajustar la bisagra superior (que se encuentra en el interior de la bolsa del libro de instrucciones) en el lado contrario.
Reversibilidad de la puerta
Antes de llevar a cabo alguna operación, quitar el enchufe de alimentación. Para cambiar el sentido de apertura de la puerta, proceder de la siguiente forma. Para llevar a cabo las siguientes operaciones, sugerimos que estas se realicen acompañado de otra persona con el fin de ayudar a sujetar la puerta del aparato durante los procesos.
• Abrir la puerta con el frigorífico en posición vertical. Desatornillar los tornillos de la cornisa puerta superior de plástico.
• Extraer el tapón y montarlo en el lado opuesto (d).
• Tumbar el aparato sobre la parte posterior.
• Retirar el tornillo de la bisagra (a)
• Retire los tornillos de la bisagra superior y extráigala (b).
• Retire el tope puerta extrayendo su tornillo (c).
a
b
c
electrolux
21
• Fije la nueva tapa bisagra ( que se encuentra en el interior de la bolsa del libro de instrucciones).
• Levantar el aparato situándolo en su posición vertical.
• Abrir la puerta y colocar la cornisa puerta superior con tornillos.
• Fijar la manilla de la puerta en el lado opuesto. Insertar los tapones de plástico en los agujeros que quedan. Los tapones los puedes encontrar en la bolsa de las instrucciones.
Colocar de nuevo, nivelar el aparato, esperar por lo menos dos horas antes de y conectar la alimentación.
De todas formas si no pudiera realizar las operaciones mencionadas, contacte con tu Servicio Técnico mas cercano. El Servicio postventa especializado llevará acabo la reversibilidad de la puerta por su cuenta.
Advertencia
Después dde hhaber ccambiado eel ssentido de aapertura dde llas ppuertas ccompruebe que ttodos llos ttornillos eestén debidamente aapretados yy qque lla guarnición mmagnética sse aajusta correctamente aal mmueble. SSi lla temperatura aambiente ees bbaja ((p.ej. invierno), lla gguarnición mmagnética quizás nno aajuste pperfectamente. EEn eel caso mmencionado, eespere aa qque lla guarnición sse aajuste ssola oo aacelere eeste proceso ccalentando lla zzona aafectada con uun ssecador nnormal dde ppelo.
22
electrolux
GARANTÍA/SERVICIO POSTVENTA
Condiciones dde GGarantía: EELECTROLUX HHOME PPRODUCTS EESPAÑA, SS.A. garantiza al usuario del aparato cuyos datos de identificación figuran en el presente documento, durante el plazo de dos (2) años desde la fecha de su entrega, la reparación totalmente gratuita de las averías que experimente el aparato, incluyendo la presente garantía tanto el coste de las piezas de recambio como el de la mano de obra y, en su caso, el del desplazamiento del personal técnico del Servicio Oficial de la Marca al domicilio del usuario. En el supuesto de que el producto, por su tamaño y movilidad, fuera susceptible de ser trasportado por el usuario al Taller Oficial de la Marca, éste quedará liberado de la obligación de trasladar su personal técnico al domicilio del usuario. Para hacer uso del derecho de garantía aquí reconocido, será requisito necesario que el aparato se destine al uso privado. También será necesario presentar al personal técnico de la marca, antes de su intervención, la factura o tique de compra del aparato o el albarán de entrega correspondiente si éste fuera posterior, en unión del presente documento.
Exclusiones:
La presente garantía no cubre la instalación, nivelación, instrucciones de uso del aparato ni sustitución de lámparas. No quedan cubiertas por esta garantía y por tanto la misma quedará sin efecto en los casos de averías producidas como consecuencia de:
• Fuerza mayor (fenómenos atmosféricos, geológicos, etc.)
• Uso inadecuado o no acorde con las instrucciones del fabricante.
• Falta de mantenimiento y limpieza: filtros con objetos tales como botones,
monedas, etc; condensadores con polvo, pelusa u otros elementos que impidan la libre circulación del aire; cubetas de detergente con residuos, etc.
• Uso de productos de limpieza abrasivos que causen daños en chapa, pintura
y plásticos.
• La rotura accidental de componentes de plástico y vidrio.
• La instalación y/o conexión incorrectas o no reglamentarias (voltaje, presión de
gas o agua, conexión eléctrica o hidráulica no adecuadas).
• Los daños estéticos no denunciados en el momento de la entrega.
La garantía no tendrá efecto en caso de manipulación de la placa de características del aparato o de los datos que figuren en la factura, tique de compra o albarán de entrega de aquél o de los consignados en este documento. Tampoco producirá efecto si se produjesen intervenciones de personal técnico no autorizado o no perteneciente al Servicio Oficial de la marca. Se informa al usuario que, además de la garantía reconocida en este documento, tiene la protección que le concede la Ley 23/2003, de 10 de julio, respecto de la
electrolux
23
exigencia de que el bien adquirido sea conforme con el contrato de compraventa, pudiendo reclamar al vendedor, en caso de disconformidad, por las faltas que se pongan de manifiesto en el plazo de dos (2) años desde la entrega. En ese supuesto, tendrá derecho a solicitar la reparación gratuita del bien o a la sustitución de éste, salvo que una de esas opciones resulte imposible o desproporcionada.
EELLEECCTTRROOLLUUXX HHOOMMEE PPRROODDUUCCTTSS EESSPPAAÑÑAA,, SS..AA..-SSoocciieeddaadd UUnniippeerrssoonnaall Albacete, n 3C - 28027 MADRID - CIF A08145872
CCeennttrraall SSeerrvviicciioo TTééccnniiccoo Ctra. M-300 km, 29,900 Apdo. 119 28802 Alcalá de Henares (Madrid)
RReecceeppcciióónn ddee LLllaammaaddaass Averías 902 116 388 Atención Usuarios: e-mail: usuarios.postventa@electrolux.es
PPaarraa EEssppaaññaa:: Puede comprar recambios y accesorios on-line entre en http://www.service.electrolux.com y seleccione Tienda Virtual
24
electrolux
GARANTÍA EUROPEA
Este aparato está garantizado por Electrolux en cada uno de los países indicados en la parte posterior de este manual durante el periodo especificado en la garantía del aparato o el periodo que prevea la ley. Si usted se traslada de uno de estos países a otro de los países abajo indicados, la garantía del aparato se desplazará con usted siempre que se cumplan los siguientes requisitos:
• La garantía entra en vigor el día en que usted compre el aparato, que se
demostrará mediante un justificante de compra válido emitido por el vendedor del aparato.
• La garantía del aparato tendrá el mismo periodo de validez y cubrirá las
mismas piezas y mano de obra que las garantías emitidas en su nuevo país de residencia para ese modelo o gama de aparatos en concreto.
• La garantía del aparato es personal del comprador original e intransferible.
• El aparato deberá ser instalado y utilizado según las instrucciones de Electrolux
y es únicamente de uso doméstico, lo que significa que no podrá ser utilizado con fines comerciales.
• El aparato deberá ser instalado observando todas las normativas relevantes
que estén en vigor en su nuevo país de residencia.
Las disposiciones de esta Garantía Europea no afectan a los derechos que le correspondan por ley.
electrolux
25
Suomi
www.electrolux.fi
Sverige
+46 (0)771 76 76 76
Electrolux Service, S:t Göransgatan 143, S-105 45 Stockholm
Türkiye
+90 21 22 93 10 25
Tarlaba caddesi no : 35 Taksim stanbul
+7 095 937 7837
Albania
+35 5 4 261 450
Rr. Pjeter Bogdani Nr. 7 Tirane
Belgique/België/Belgien
+32 2 363 04 44
Bergensesteenweg 719, 1502 Lembeek
Danmark
+45 70 11 74 00
Sjællandsgade 2, 7000 Fredericia
eská republika
+420 2 61 12 61 12
Bud jovická 3, Praha 4, 140 21
Deutschland
+49 180 32 26 622
Muggenhofer Str. 135, 90429 Nürnberg
Eesti
+37 2 66 50 030
Mustamäe tee 24, 10621 Tallinn
España
+34 902 11 63 88
Carretera M-300,Km.29,900 Alcalá de Henares Madrid
France
Great Britain
+44 8705 929 929
Addington Way, Luton, Bedfordshire LU4 9QQ
Hellas
+30 23 10 56 19 70
4, Limnou Str., 54627 Thessaloniki
Hrvatska
+385 1 63 23 338
Slavonska avenija 3, 10000 Zagreb
Ireland
+353 1 40 90 753
Long Mile Road Dublin 12
Italia
+39 (0) 434 558500
C.so Lino Zanussi, 26 - 33080 Porcia (PN)
Latvija
+37 17 84 59 34
Kr. Barona iela 130/2, LV-1012, Riga
Lietuva
+370 5 2780609
Verki 29, LT-09108 Vilnius
Luxembourg
+35 2 42 43 13 01
Rue de Bitbourg, 7, L-1273 Hamm
Magyarország
+36 1 252 1773
H-1142 Budapest XIV, Erzsébet királyné útja 87
Nederland
+31 17 24 68 300
Vennootsweg 1, 2404 CG - Alphen aan den Rijn
Norge
+47 81 5 30 222
Risløkkvn. 2 , 0508 Oslo
Österreich
+43 18 66 400
Herziggasse 9, 1230 Wien
Polska
+48 22 43 47 300
ul. Kolejowa 5/7, Warsaw
Portugal
+35 12 14 40 39 39
Quinta da Fonte-Edificio Gonçalves Zarco-Q 35-2774-518 Paço de Arcos
Romania
+40 21 451 20 30
Str. Garii Progresului 2, S4, 040671 RO
Schweiz-Suisse-Svizzera
+41 62 88 99 111
Industriestrasse 10, CH-5506 Mägenwil
Slovenija
+38 61 24 25 731
Electrolux Ljubljana d.o.o., Gerbi eva 98, 1000 Ljubljana
Slovensko
+421 2 43 33 43 22
Electrolux Slovakia s.r.o., Electrolux Domáce spotrebi e SK, Seberíniho 1, 821 03 Bratislava
www.electrolux.com
ě
á
ŏ
ŝ
www.electrolux.fr
È
129090 Москва, Олимпийский проспект, 16, БЦ "Олимпик"
ģ
ě
Россия
26
electrolux
Welcome to the world of Electrolux
You’ve chosen a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. Electrolux ambition is to offer a wide variety of quality products that would make your life even more comfortable. You can look at some examples on the cover in this manual. But now it’s time to study this manual and start using and enjoying the benefits from your new machine. We promise that it’ll make your life a little easier. Good luck!
electrolux
27
The following symbols are used in this manual:
Important information concerning your personal safety and information on how to avoid damaging the appliance.
General information and tips
Environmental information
The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.
28
electrolux
CONTENTS
Safety IInformation 29 Use 332 Cleaning the interior 32 Control panel 32 Display 33 First switch on 33 Switching off 33 Temperature regulation 33 Functions Menu 34 Use of the fridge compartment 35 Holiday Function 35 Fresh food refrigeration 35 Movable shelves 36 Bottle rack 36 Positioning the door shelves 36 Cold Store compartment 37 Air recycling 37
Hints 37 Hints for refrigeration 37 Maintenance 337 Periodic cleaning 38 Periods of non-operation 38 Interior light 38 Defrosting 38 Technical iinformation 39 Customer sservice aand sspare pparts 339 Installation 40 Location 40 Electrical connection 40 Shelf holders 41 Rear spacers 41 Door reversibility 42 European GGuarantee 44 www.electrolux.com 45
electrolux
29
SAFETY INFORMATION
It iis mmost iimportant tthat tthis instruction bbook sshould bbe rretained with tthe aappliance ffor ffuture rreference. Should tthe aappliance bbe ssold oor transferred tto aanother oowner, oor should yyou mmove hhouse aand lleave tthe appliance, aalways eensure tthat tthe book iis ssupplied wwith tthe aappliance iin order tthat tthe nnew oowner ccan bbe acquainted wwith tthe ffunctioning oof tthe appliance aand tthe rrelevant wwarnings.
If tthis aappliance ffeaturing mmagnetic door sseals iis tto rreplace aan oolder appliance hhaving aa sspring llock ((latch) on tthe ddoor oor llid, bbe ssure tto mmake that sspring llock uunusable bbefore yyou discard tthe oold aappliance. TThis wwill prevent iit ffrom bbecoming aa ddeath-ttrap for aa cchild.
These wwarnings aare pprovided iin tthe interest oof ssafety. YYou mmust rread tthem carefully bbefore iinstalling oor uusing tthe appliance.
General Safety
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
• It is dangerous to alter the specifications or modify this product in any way.
• Before any cleaning or maintenance work is carried out, be sure to switch off and unplug the appliance.
• This appliance is heavy. Care should be taken when moving it
• Ice lollies can cause frost burns if consumed straight from the appliance.
Take uutmost ccare wwhen hhandling
your aappliance sso aas nnot tto ccause any ddamages tto tthe ccooling uunit with cconsequent ppossible ffluid leakages.
• The aappliance mmust nnot bbe llocated close tto rradiators oor ggas ccookers.
• Avoid pprolonged eexposure oof tthe appliance tto ddirect ssunlight.
• There mmust bbe aadequate vventilation round tthe bback oof tthe aappliance and aany ddamage tto tthe rrefrigerant circuit mmust bbe aavoided.
• For ffreezers oonly ((except bbuilt-iin models): aan iideal llocation iis tthe cellar oor bbasement.
• Do nnot uuse oother eelectrical appliances ((such aas iice ccream makers) iinside oof rrefrigerating appliances.
Service/Repair
• Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person
• This product should be serviced by an authorized Service Centre, and only genuine spare parts should be used.
30
electrolux
• Under no circumstances should you attempt to repair the appliance yourself. Repairs carried out by inexperienced persons may cause injury or more serious malfunctioning. Refer to your local Service Centre, and always insist on genuine spare parts.
• This appliance contains hydrocarbons in its cooling unit; maintenance and recharging must therefore only be carried out by authorized technicians.
Use
• The domestic refrigerators and freezers are designed to be used specifically for the storage of edible foodstuffs only.
• Best performance is obtained with ambient temperature between +18°C and +43°C (class T); +18°C and +38°C (class ST); +16°C and +32°C (class N); +10°C and +32°C (class SN). The class of your appliance is shown on its rating plate.
Warning:
when the ambient temperature is not included within the range indicated for the class of this appliance, the following instructions must be observed: when the ambient temperature drops below the minimum level, the storage temperature in the freezer compartment cannot be guaranteed; therefore it is advisable to use the food stored as soon as possible.
• Frozen food must not be re-frozen once it has been thawed out.
• Manufacturers’ storage recommendations should be strictly adhered to. Refer to relevant instructions.
• The inner lining of the appliance consists of channels through which the refrigerant passes. If these should be punctured this would damage the appliance beyond repair and cause food loss. DO NOT USE SHARP INSTRUMENTS to scrape off frost or ice. Frost may be removed by using the scraper provided. Under no circumstances should solid ice be forced off the liner. Solid ice should be allowed to thaw when defrosting the appliance.
• Do not place carbonated or fizzy drinks in the freezer as it creates pressure on the container, which may cause it to explode, resulting in damage to the appliance.Do not use a mechanical device or any artificial means to speed up the thawing process other than those recommended by the manufacturer. Never use metal objects for cleaning your appliance as it may get damaged.
Installation
• During normal operation, the condenser and compressor at the back of the appliance heat up considerably. For safety reasons, minimum ventilation must be as shown in the instructions.
electrolux
31
Attention: kkeep vventilation oopenings clear oof oobstruction.
• Care must be taken to ensure that the appliance does not stand on the electrical supply cable.
Important:
if the supply cord is damaged, it must be replaced by a special cord or assembly availa-ble from the manufacturer or its service agent.
• If the appliance is transported horizontally, it is possible that the oil contained in the compressor flows in the refrigerant circuit. It is advisable to wait at least two hours before connecting the appliance to allow the oil to flow back in the compressor.
• There are working parts in this product which heat up. Always ensure that there is adequate ventilation as a failure to do this will result in component failure and possible food loss. See installation instructions.
• Parts which heat up should not be exposed. Wherever possible the back of the product should be against a wall.
Environment Protection
This aappliance ddoes nnot ccontain gasses wwhich ccould ddamage tthe oozone layer, iin eeither iits rrefrigerant ccircuit oor insulation mmaterials. TThe aappliance shall nnot bbe ddiscarded ttogether wwith the uurban rrefuse aand rrubbish. AAvoid damaging tthe ccooling uunit, eespecially at tthe rrear nnear tthe hheat eexchanger. Information oon yyour llocal ddisposal ssites may bbe oobtained ffrom mmunicipal authorities. TThe mmaterials uused oon tthis appliance mmarked bby tthe ssymbol are rrecyclable.
32
electrolux
USE
Cleaning the interior
Before using the appliance for the first time, wash the interior and all internal accessories with luke-warm water and some neutral soap so as to remove the typical smell of a brand-new product, then dry thoroughly.
Do nnot uuse ddetergents oor abrasive ppowders, aas tthese wwill damage tthe ffinish.
Control panel
A - Appliance button ON/OFF B - Temperature regulation button C - Temperature and function indicator
D - Function button E - Confirmation button
A
B
C
D
E
electrolux
33
Display
If on the temperature indicated is the ambient temperature
Positive Temperature indicator Temperature indicator
If on the Child Lock function is on If on the Shopping function is on If on the Eco Mode function is on
First switch on
After plugging the plug into the power outlet, if the display is not illuminated, press key (A), appliance on. For a correct storage of the food select the Eco Mode function that guarantee the following temperature is set:
+5°C in the fridge
• To select a different temperature see "Temperature regulation".
Important If the door remains ajar for some minutes, the internal lighting will turn off electronically; after this, the lighting function will be reset by closing and opening the door itself.
Switching off
The appliance is shut off by pressing key (A) for more than 1 second. During this, a countdown of the temperature from -3 -2 -1 will be shown.
Temperature regulation
The temperature may be regulated by pressing the key B. By pressing the key B the current temperature setting flashes on the indicator and by pressing the key B again it is possible to change it. You confirm the choice of the temperature either by pressing the key E, (you will hear the buzzer) or by waiting for some seconds (you will not hear the buzzer). Then the indicator shows again the inside compartment temperature. The newly selected-temperature must be reached after 24 hours. After a long period out of use it is not necessary to set again the temperature because it remains stored.
34
electrolux
Attention!
During the stability period by the first starting the temperature displayed can not correspond to the setting temperature. During this time it is possible that the temperature displayed is different than the setting temperature.
Functions Menu
By activating the key D the functions menu is operating. Each function could be confirmed by pressing button E. If there is no confirmation after some seconds the display will go out from the menu and return in normal condition. The following functions are indicated:
Ambient Temperature Child Lock function Shopping function Eco Mode function
Ambient Temperature Function
The ambient temperature function is activated by pressing key D (several times if necessary) until the
corresponding icon appears . In this condition the displayed temperature is the ambient temperature. You must confirm the choice by pressing key E within few seconds. You will hear the buzzer and the icon remains lighted. It is possible to de-activate the function at any time by pressing key D until the corresponding icon will flash and then key E.
Child Lock Function
The Child Lock function is activated by pressing key D (several times if necessary) until the corresponding icon
appears . You must confirm the choice by pressing key E within few seconds. You will hear the buzzer and the icon remains lighted. In this condition any possible operation through the keys does not cause any change as long as this function is activated. It is possible to de-activate the function at any time by pressing key D until the corresponding icon will flash and then key E.
Shopping Function
If you need to insert a large amount of warm food, for example after doing the grocery shopping, we suggest activating the Shopping function to chill the products more rapidly and to avoid warming the other food which is already in the refrigerator. The Shopping function is activated by pressing key D (several times if necessary) until the corresponding icon
appears . You must confirm the choise by pressing key E within few seconds. You will hear the buzzer and the icon remains lighted. The Shopping function shuts off automatically after approximately 6 hours. It is possible to de-activate the function at any time by pressing key D until the corresponding icon will flash and then key E.
electrolux
35
Holiday Function “H”
The Holiday function sets the temperature at + 15°C. This function allows you to keep the refrigerator shut and empty during a long holiday period ( e. g. the summer holidays) without the formation of a bad smell. The Holiday Function H may be regulated by pressing the key B. By pressing the key B the current temperature setting flashes on the indicator. Press the key B again. When on the display appears the letter H confirm the choice of the temperature or by pressing the key E, (you will hear the buzzer) or by waiting for some seconds (you will not hear the buzzer).
Now the refrigerator is in the Holiday function in the energy- saving mode and the indicator shows the letter H. It is possible to de-activate the function at any time by changing the selected temperature in the compartment.
Attention! The fridge compartment must be empty with Holiday function on.
Fresh food refrigeration
To obtain the best performance:
• do not store warm food or
evaporating liquids in the refrigerator;
• do cover or wrap the food,
particularly if it has a strong flavour.
• Position food so that air can
circulate freely round it.
Eco Mode Function
The Eco Mode function is activated by pressing key D (several times if necessary) until the corresponding icon
appears (or setting the temperature at +5°C). You must confirm the choice by pressing key E within few seconds. You will hear the buzzer and the icon remains lighted. In this condition the chosen temperatures are automatically set (+ 5°C), in the best conditions for storing food. It is possible to de-activate the function at any time by changing the selected temperature in the compartment.
Use of the fridge compartment
The temperature of this compartment may be regulated between +2°C and +8°C. During normal functioning the indicator shows the temperature inside the fridge.
Attention! Difference between the temperature displayed and temperature setting is normal. Especially when:
• a new setting has recently been
selected
• the door has been left open for a
long time
• warm food has been placed in the
compartment.
36
electrolux
Movable shelves
The walls of the refrigerator are equipped with a series of runners so that the shelves can be positioned as desired.
Bottle rack
Place bottles in the rack with the bottleneck to the front. Important: Only store unopened bottles horizontally. The bottle rack can be tilted for storing opened bottles. To do this pull the bottle rack forward until it can be tilted upwards, then slide the front support into the next level up.
Positioning the door shelves
To permit storage of food packages of various sizes, the door shelves can be placed at different heights. To make these adjustments proceed as follows: Gradually pull the shelf in the direction of the arrows until it comes free, then reposition as required.
D338
electrolux
37
Cold Store compartment
The models equippied with this feature in the fridge part, it is indicated for a best conservation of fresh foods as fish, meat, seafood, etc.
It is placed in the lower part, directly above of the vegatable conservation drawer.
Air recycling
The refrigerator compartment is equipped with a device which can be turned on with the switch ( see fig.). The green light, when on, means that the fan is working. It is suggested that the device be used when the ambient temperature exceeds 25°C . This device allows for rapid cooling of foods and a more uniform temperature in the compartment.
HINTS
Hints for refrigeration
Useful hints: Meat ((all ttypes):
wrap in polythene bags and place on the glass shelf above the vegetable drawer.
For ssafety, sstore iin tthis wway oonly oone or ttwo ddays aat tthe mmost.
Cooked ffoods, ccold ddishes, eetc..: these should be covered and may be placed on any shelf.
Fruit aand vvegetables:
these should be thoroughly cleaned and placed in the special drawer(s) provided.
Butter aand ccheese:
these should be placed in special airtight containers or wrapped in aluminium foil or polythene bags to exclude as much air as possible.
Milk bbottles:
these should have a cap and should be stored in the bottle rack on the door.
Bananas, ppotatoes, oonions aand ggarlic, if nnot ppacked, mmust nnot bbe kkept iin tthe refrigerator.
MAINTENANCE
Unplug tthe aappliance bbefore carrying oout aany mmaintenance operation.
Warning This aappliance ccontains
hydrocarbons iin iits ccooling uunit; maintenance aand rrecharging mmust therefore oonly bbe ccarried oout bby authorized ttechnicians.
SWITCH
38
electrolux
Periodic cleaning
Many pproprietary kkitchen ssurface cleaners ccontain cchemicals tthat ccan attack/damage tthe pplastics uused iin this aappliance. FFor tthis rreason iit iis recommended tthat tthe oouter ccasing oof this aappliance iis oonly ccleaned wwith warm wwater wwith aa llittle wwashing-uup liquid aadded.
Clean the inside with warm water and bicarbonate of soda. Rinse and dry thoroughly. Clean the condenser (black grill) and the compressor at the back of the appliance with a brush or a vacuum cleaner. This operation will improve the performance of the appliance and save electricity consumption.
Periods of non-operation
When the appliance is not in use for long periods, take the following precautions:
• remove the plug from the wall socket;
• remove all food;
• defrost and clean the interior and all accessories;
• leave the door ajar to allow air to circulate to prevent unpleasant smells.
Interior light
If it becomes necessary to replace the lamp, press on the rear hook and at the same time slide the cover in the direction indicated by the arrow.
Attention Replace the lamp with one of the same power (the maximum power is shown on the light diffuser).
Defrosting
Frost is automatically eliminated from the evaporator of the refrigerator compartment every time the motor compressor stops, during normal use. The defrost water drains out through a trough into a special container at the back of the appliance, over the motor compressor, where it evaporates.
It iis iimportant tto pperiodically cclean tthe defrost wwater ddrain hhole iin tthe mmiddle of tthe rrefrigerator ccompartment channel tto pprevent tthe wwater overflowing aand ddripping oonto tthe ffood inside. UUse tthe sspecial ccleaner provided, wwhich yyou wwill ffind aalready inserted iinto tthe ddrain hhole.
D037
electrolux
39
CUSTOMER SERVICE AND SPARE PARTS
If the appliance is not functioning properly, check that:
• the plug is firmly in the wall socket and the mains power switch is on;
• there is an electricity supply (find out by plugging in another appliance);
• If there are water drops on the bottom of the cabinet, check that the defrost water drain opening is not obstructed (see “Defrosting” section).
• If your appliance is still not working properly after making the above checks, contact the nearest service centre.
To oobtain ffast sservice, iit iis eessential that wwhen yyou aapply ffor iit yyou sspecify the mmodel aand sserial nnumber oof yyour appliance wwhich ccan bbe ffound oon tthe guarantee ccertificate oor oon tthe rrating plate llocated iinside tthe aappliance, oon the bbottom lleft-hhand sside.
TECHNICAL INFORMATION
378
0,403
147
1800
600
645
Net Fridge Capacity lt.
Energy Consumption kWh/year
Dimensions mm
High
Energy Consumption kWh/24h
Width
Depth
The technical infomation are situated in the rating plate on the internal left side of the appliance.
40
electrolux
INSTALLATION Location
The appliance should be installed well away from sources of heat such as radiators, boilers, direct sunlight etc. Ensure that air can circulate freely around the back of the cabinet. To ensure best performance, if the appliance is positioned below an overhanging wall unit, the minimum distance between the top of the cabinet and the wall unit must be at least 100 mm . Ideally, however, the appliance should not be positioned below overhanging wall units. Accurate levelling is ensured by one or more adjustable feet at the base of the cabinet.
Attention
It must be possible to disconnect the appliance from the mains power supply; the plug must therefore be easily accessible after installation.
Electrical connection
Before plugging in, ensure that the voltage and frequency shown on the serial number plate correspond to your domestic power supply. Voltage can vary by ±6% of the rated voltage. For operation with different voltages, a suitably sized auto-transformer must be used. The aappliance mmust bbe eearthed. The power supply cable plug is provided with a contact for this purpose. If the domestic power supply socket is not earthed, connect the appliance to a separate earth in compliance with current regulations, consulting a specialist technician. The MManufacturer ddeclines aall responsibility iif tthe aabove ssafety precautions aare nnot oobserved.
This appliance complies with the following E.E.C. Directives:
87/308 EEEC
of 2/6/87 relative to
radio interference suppression.
73/23 EEEC
of 19.2.73 (Low Voltage Directive) and subsequent modifications;
89/336 EEEC
of 3.5.89 (Electromagnetic Compatibility Directive) and subsequent modifications.
100 mm10 mm
10 mm
NP00
electrolux
41
Rear spacers
In the appliance, there are two spacers which must be fitted as shown in the figure . Slacken the screws and insert the spacer under the screw head, then re­tighten the screws.
Shelf holders
Your appliance is equipped with shelf retainers that make it possible to secure the shelves during transportation.
To remove them proceed as follows: Move the shelf holders in the direction
of the arrow, raise the shelf from the rear and push it forward until it is freed and remove the retainers.
A
B
C
42
electrolux
Door reversibility
Before carrying out any operations, remove the plug from the power socket.
To change the opening direction of the door, proceed as follows:
• To carry out the following operations, we suggest that this be made with another person that will keep a firm hold on the doors of the appliance during the operations.
• Open the door with the appliance in the upright position. Unscrew the screws and remove the upper door plastic trim.
• Remove the little plastic cover from the door plastic trim and refit on the opposite side (d).
• Lay down the appliance back side down.
• Remove the screw of the hinge cover plug (a).
• Unscrew the upper hinge and remove it (b).
• Unscrew the screw and remove the door stopper (c).
• Remove the door.
• Remove using a tool the cover (e) unscrew the lower hinge pivot (f) and place it on the opposite side.
• Reinsert the cover (e) on the opposite side.
• Reinsert the door .
• Pay attention that the front board of the doors are parallel to the front board of the top.
• Fix the door stopper on the opposite side.
• Position and fix the upper hinge (that can be found in the instruction for use bag) on the opposite side .
• Fix the screw of the new cover hinge (that can be found in the instruction for use bag).
b
c
a
electrolux
43
• Lift up the appliance to vertical position.
• Open the door and reposition the upper door plastic trim with screws.
• Fix the handle on the opposite side, insert the plastic plugs into the holes left open that can be found in the instruction for use bag.
Reposition, level the appliance, wait for at least two hours and then connect it to the power socket.
In case you do not want to carry out the above mentioned operations, contact the nearest After Sales Service Force.. The After Sales Service specialist will carry out the reversibility of the doors at your cost.
Warning
After hhaving rreversed tthe oopening direction oof tthe ddoors ccheck tthat aall tthe screws aare pproperly ttightened aand tthat the mmagnetic sseal aadheres tto tthe cabinet.
If tthe aambient ttemperature iis ccold ((i.e. in WWinter), tthe ggasket mmay nnot ffit perfectly tto tthe ccabinet. IIn tthat ccase, wait ffor tthe nnatural ffitting oof tthe ggasket or aaccelerate tthis pprocess bby hheating up tthe ppart iinvolved wwith aa nnormal hairdrier. LLay ddown tthe aappliance bback side ddown
.
44
electrolux
EUROPEAN GUARANTEE
This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appliance guarantee or otherwise by law. If you move from one of these countries to another of the countries listed, the appliance guarantee will move with you subject to the following qualifications:
• The appliance guarantee starts from the date you first purchased the appliance which will be evidenced by production of a valid purchase document issued by the seller of the appliance.
• The appliance guarantee is for the same period and to the same extent for labour and parts as exists in your new country of residence for this particular model or range of appliances.
• The appliance guarantee is personal to the original purchaser of the appliance and cannot be transferred to another user.
• The appliance is installed and used in accordance with instructions issued by Electrolux and is only used within the home, i.e. is not used for commercial purposes.
• The appliance is installed in accordance with all relevant regulations in force within your new country of residence.
The provisions of this European Guarantee do not affect any of the rights granted to you by law.
electrolux
45
Suomi
www.electrolux.fi
Sverige
+46 (0)771 76 76 76
Electrolux Service, S:t Göransgatan 143, S-105 45 Stockholm
Türkiye
+90 21 22 93 10 25
Tarlaba caddesi no : 35 Taksim stanbul
+7 095 937 7837
Albania
+35 5 4 261 450
Rr. Pjeter Bogdani Nr. 7 Tirane
Belgique/België/Belgien
+32 2 363 04 44
Bergensesteenweg 719, 1502 Lembeek
Danmark
+45 70 11 74 00
Sjællandsgade 2, 7000 Fredericia
eská republika
+420 2 61 12 61 12
Bud jovická 3, Praha 4, 140 21
Deutschland
+49 180 32 26 622
Muggenhofer Str. 135, 90429 Nürnberg
Eesti
+37 2 66 50 030
Mustamäe tee 24, 10621 Tallinn
España
+34 902 11 63 88
Carretera M-300,Km.29,900 Alcalá de Henares Madrid
France
Great Britain
+44 8705 929 929
Addington Way, Luton, Bedfordshire LU4 9QQ
Hellas
+30 23 10 56 19 70
4, Limnou Str., 54627 Thessaloniki
Hrvatska
+385 1 63 23 338
Slavonska avenija 3, 10000 Zagreb
Ireland
+353 1 40 90 753
Long Mile Road Dublin 12
Italia
+39 (0) 434 558500
C.so Lino Zanussi, 26 - 33080 Porcia (PN)
Latvija
+37 17 84 59 34
Kr. Barona iela 130/2, LV-1012, Riga
Lietuva
+370 5 2780609
Verki 29, LT-09108 Vilnius
Luxembourg
+35 2 42 43 13 01
Rue de Bitbourg, 7, L-1273 Hamm
Magyarország
+36 1 252 1773
H-1142 Budapest XIV, Erzsébet királyné útja 87
Nederland
+31 17 24 68 300
Vennootsweg 1, 2404 CG - Alphen aan den Rijn
Norge
+47 81 5 30 222
Risløkkvn. 2 , 0508 Oslo
Österreich
+43 18 66 400
Herziggasse 9, 1230 Wien
Polska
+48 22 43 47 300
ul. Kolejowa 5/7, Warsaw
Portugal
+35 12 14 40 39 39
Quinta da Fonte-Edificio Gonçalves Zarco-Q 35-2774-518 Paço de Arcos
Romania
+40 21 451 20 30
Str. Garii Progresului 2, S4, 040671 RO
Schweiz-Suisse-Svizzera
+41 62 88 99 111
Industriestrasse 10, CH-5506 Mägenwil
Slovenija
+38 61 24 25 731
Electrolux Ljubljana d.o.o., Gerbi eva 98, 1000 Ljubljana
Slovensko
+421 2 43 33 43 22
Electrolux Slovakia s.r.o., Electrolux Domáce spotrebi e SK, Seberíniho 1, 821 03 Bratislava
www.electrolux.com
ě
á
ŏ
ŝ
www.electrolux.fr
È
129090 Москва, Олимпийский проспект, 16, БЦ "Олимпик"
ģ
ě
Россия
2223 463-02-00 26092007
wwwwww..eelleeccttrroolluuxx..ccoomm
www.electrolux.es
Loading...
