AEG SB323N13 User Manual

user manual

notice d'utilisation

benutzerinformation

istruzioni per l’uso

Fridge-Freezer

Réfrigérateur-congélateur

Integrierbare Kühl-/Gefrierkombination

Frigorifero-Congelatore

SB323N13

2 electrolux

Electrolux. Thinking of you.

Share more of our thinking at www.electrolux.com

Contents

Safety information 2
Control panel 4
First use 7
Daily use 7
Helpful hints and tips 9

Subject to change without notice

Care and cleaning 10
What to do if… 11
Technical data 13
Installation 13
Environmental concerns 17

Safety information

In the interest of your safety and to ensure
the correct use, before installing and first us­ing the appliance, read this user manual
carefully, including its hints and warnings. To
avoid unnecessary mistakes and accidents,
it is important to ensure that all people using
the appliance are thoroughly familiar with its
operation and safety features. Save these in­structions and make sure that they remain
with the appliance if it is moved or sold, so
that everyone using it through its life will be
properly informed on appliance use and safe­ty.
For the safety of life and property keep the
precautions of these user's instructions as
the manufacturer is not responsible for dam­ages caused by omission.

Children and vulnerable people safety

• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or in­struction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure
that they do not play with the appliance.

• Keep all packaging well away from chil­dren. There is risk of suffocation.

• If you are discarding the appliance pull the
plug out of the socket, cut the connection
cable (as close to the appliance as you
can) and remove the door to prevent play­ing children to suffer electric shock or to
close themselves into it.

• If this appliance featuring magnetic door
seals is to replace an older appliance hav-

ing a spring lock (latch) on the door or lid,
be sure to make that spring lock unusable
before you discard the old appliance. This
will prevent it from becoming a death trap
for a child.

General safety

Caution! Keep ventilation openings

clear of obstruction.

• The appliance is intended for keeping
foodstuff and/or beverages in a normal
household as explained in this instruction
booklet.

• Do not use a mechanical device or any ar­tificial means to speed up the thawing
process.

• Do not use other electrical appliances
(such as ice cream makers) inside of re­frigerating appliances, unless they are ap­proved for this purpose by the manufac­turer.

• Do not damage the refrigerant circuit.

• The refrigerant isobutane (R600a) is con­tained within the refrigerant circuit of the
appliance, a natural gas with a high level of
environmental compatibility, which is nev­ertheless flammable.
During transportation and installation of
the appliance, be certain that none of the
components of the refrigerant circuit be­come damaged.
If the refrigerant circuit should become
damaged:
– avoid open flames and sources of igni-

tion

– thoroughly ventilate the room in which

the appliance is situated

electrolux 3

• It is dangerous to alter the specifications or
modify this product in any way. Any dam­age to the cord may cause a short-circuit,
fire and/or electric shock.

Warning! Any electrical component
(power cord, plug, compressor) must be
replaced by a certified service agent or
qualified service personnel.

1. Power cord must not be lengthened.

2. Make sure that the power plug is not

squashed or damaged by the back of
the appliance. A squashed or dam­aged power plug may overheat and
cause a fire.

3. Make sure that you can come to the

mains plug of the appliance.

4. Do not pull the mains cable.

5. If the power plug socket is loose, do

not insert the power plug. There is a
risk of electric shock or fire.

6. You must not operate the appliance

without the lamp cover

1)

of interior

lighting.

• This appliance is heavy. Care should be
taken when moving it.

• Do not remove nor touch items from the
freezer compartment if your hands are
damp/wet, as this could cause skin abra­sions or frost/freezer burns.

• Avoid prolonged exposure of the appli­ance to direct sunlight.

Daily Use

• Do not put hot pot on the plastic parts in
the appliance.

• Do not store flammable gas and liquid in
the appliance, because they may explode.

• Do not place food products directly
against the air outlet on the rear wall.

2)

• Frozen food must not be re-frozen once it
has been thawed out.

• Store pre-packed frozen food in accord­ance with the frozen food manufacturer's
instructions.

• Appliance's manufacturers storage rec­ommendations should be strictly adhered
to. Refer to relevant instructions.

• Do not place carbonated or fizzy drinks in
the freezer compartment as it creates

1) If the lamp cover is foreseen

2) If the appliance is Frost Free

3) If a water connection is foreseen

pressure on the container, which may
cause it to explode, resulting in damage to
the appliance.

• Ice lollies can cause frost burns if con­sumed straight from the appliance.

Care and cleaning

• Before maintenance, switch off the appli­ance and disconnect the mains plug from
the mains socket.

• Do not clean the appliance with metal ob­jects.

• Do not use sharp objects to remove frost
from the appliance. Use a plastic scraper.

• Regularly examine the drain in the refriger­ator for defrosted water. If necessary,
clean the drain. If the drain is blocked, wa­ter will collect in the bottom of the appli­ance.

Installation
Important! For electrical connection

carefully follow the instructions given in
specific paragraphs.

• Unpack the appliance and check if there
are damages on it. Do not connect the ap­pliance if it is damaged. Report possible
damages immediately to the place you
bought it. In that case retain packing.

• It is advisable to wait at least four hours
before connecting the appliance to allow
the oil to flow back in the compressor.

• Adequate air circulation should be around
the appliance, lacking this leads to over­heating. To achieve sufficient ventilation
follow the instructions relevant to installa­tion.

• Wherever possible the back of the product
should be against a wall to avoid touching
or catching warm parts (compressor, con­denser) to prevent possible burn.

• The appliance must not be located close
to radiators or cookers.

• Make sure that the mains plug is accessi­ble after the installation of the appliance.

•

Connect to potable water supply only.

3)

4 electrolux

Service

• Any electrical work required to do the serv­icing of the appliance should be carried out
by a qualified electrician or competent per­son.

• This product must be serviced by an au­thorized Service Centre, and only genuine
spare parts must be used.

Environment Protection

This appliance does not contain gasses
which could damage the ozone layer, in

either its refrigerant circuit or insulation
materials. The appliance shall not be dis­carded together with the urban refuse
and rubbish. The insulation foam con­tains flammable gases: the appliance
shall be disposed according to the ap­plicable regulations to obtain from your
local authorities. Avoid damaging the
cooling unit, especially at the rear near
the heat exchanger. The materials used
on this appliance marked by the symbol

are recyclable.

Control panel

B

A - Appliance button ON/OFF D - Function button
B - Temperature regulation button E - Confirmation button
C - Temperature and function indicator

Display

DEAC

If on the indicated compartment is on. Child Lock function indicator.
If on the indicated temperature is that

of the relative compartment.

If it flashes the operations corresponds

to the relative compartment.
Excessive temperature alarm. Drinks Chill function indicator.
If on the indicated temperature is the

ambient temperature.
Positive or negative temperature indi-

cator.
Temperature indicator.

Timer function indicator.

Shopping function indicator.

Action Freeze function indicator.

Eco mode function indicator.

electrolux 5

First switch on

After plugging the plug into the power outlet,
if the display is not illuminated, press key (A),
appliance on.
As soon as the appliance is turned on, it is in
alarm condition, the temperature flashes and
you will hear a buzzer.
Press key (E) and the buzzer will go off (also
see the section on "excessive temperature
alarm" ) the icon still flashes and on the

indicator

will appear the warmest tem­perature reached.
For a correct storage of the food select the
Eco mode function that guarantee the fol­lowing temperatures are set:
+5°C in the fridge

-18°C in the freezer

• Wait until the inside compartment temper-

ature reach -18°C, before introducing the
goods in the freezer compartment.

• To select a different temperature see

"Temperature regulation".

Switching off

The appliance is shut off by pressing key (A)
for more than 1 second.
During this, a countdown of the temperature
from -3 -2 -1 will be shown.

Functions Menu

By activating the key (D) the functions menu
is operating. Each function could be con­firmed by pressing button (E). If there is no
confirmation after some seconds the display
will go out from the menu and return in nor­mal condition.

The following functions are indicated:

Select/Switch off/Switch on fridge com-

partment

Select/Switch off/Switch on freezer com-

partment

Ambient Temperature
Child Lock function
Shopping function
Eco Mode function

Action Freeze function

Drinks Chill function

Temperature regulation

The temperature may be regulated by press­ing the key (D) to select the compartment and

than the key (B) to set the desired tempera­ture.
By pressing the key (B) the current tempera­ture setting flashes on the indicator. To con­firm the choice of the temperature press the
key (E).
You will hear the buzzer for few seconds and
the indicator displays the newly selected
temperature for a few seconds, then shows
again the inside compartment temperature.
The newly selected-temperature must be
reached after 24 hours.
After a long period out of use it is not neces­sary to set again the temperature because it
remains stored.

Important! During the stability period by the
first starting the temperature displayed can
not correspond to the setting temperature.
During this time it is possible that the
temperature displayed is different than the
setting temperature.

Holiday Function "H"

The holiday function sets the temperature at
+ 15°C.
This function allows you to keep the refriger­ator shut and empty during a long holiday
period ( e. g. the summer holidays) without
the formation of a bad smell.
To turn on the holiday function operate as per
modift the selected temperature. The tem­perature indicator can modify the displayed
temperature up to + 8 °C, 1 °at a tim. + 2 °C
will be followed by the letter "H ". Press key
E to confirm.
Now the refrigerator is in the "holiday "func­tion in the energy- saving mode.

Important! The fridge compartment must
be empty with holiday function on.

Ambient Temperature Function

The ambient temperature function is activa­ted by pressing key (D) (several times if nec­essary) until the corresponding icon appears

. In this condition the displayed temper­ature is the ambient temperature.
You must confirm the choice by pressing key
(E) within few seconds. You will hear the buz­zer and the icon remains lighted.
It is possible to de-activate the function at
any time by pressing key (D) until the corre­sponding icon will flash and then key (E)

6 electrolux

Child Lock Function

The Child Lock function is activated by
pressing key (D) (several times if necessary)

until the corresponding icon appears

.
You must confirm the choice by pressing key
(E) within few seconds. You will hear the buz­zer and the icon remains lighted. In this con­dition any possible operation through the
keys does not cause any change as long as
this function is activated.
It is possible to de-activate the function at
any time by pressing key (D) until the corre­sponding icon will flash and then key (E).

Shopping Function

If you need to insert a large amount of warm
food, for example after doing the grocery
shopping, we suggest activating the Shop­ping function to chill the products more rap­idly and to avoid warming the other food
which is already in the refrigerator.
The Shopping function is activated by press­ing key (D) (several times if necessary) until

the corresponding icon appears

. You
must confirm the choise by pressing key (E)
within few seconds. You will hear the buzzer
and the icon remains lighted.
The Shopping function shuts off automati­cally after approximately 6 hours. It is possi­ble to de-activate the function at any time by
pressing key (D) until the corresponding icon
will flash and then key (E).

Eco Mode Function

The Eco Mode function is activated by press­ing key (D) (several times if necessary) until

the corresponding icon appears
You must confirm the choice by pressing key
(E) within few seconds. You will hear the buz­zer and the icon remains lighted.
In this condition the chosen temperatures are
automatically set (+ 5°C and - 18°C), in the
best conditions for storing food.
It is possible to de-activate the function at
any time by changing the selected tempera­ture in one of the compartment.

Action Freeze Function

The freezer compartment is suitable for long
term storage of commercially frozen and
deep-frozen food, and for freezing fresh
food.
The maximum quantity of foods to freeze in
24 hours is shown on the rating plate.

To freeze the amount of food indicated on the
rating plate, place the food directly in touch
with the cooling surface (remove the drawer
or basket). In case the food is frozen inside
the drawers or baskets, the maximum quan­tity is slightly reduced.
To freeze fresh foods, you will need to acti­vate the Action Freeze function. Press key (D)
(several times if necessary) until

indicator
appears.
You must confirm the choice by pressing key
(E) within few seconds. You will hear the buz­zer and on the display will appear some ani­mation with lines.
After a pre-cooling period of 24 hours, place
the foods in the freezer.

Place the food to be frozen in the

com­partment, as this is the coldest point.
The freezing process takes 24 hours. During
this period do not put other foods in the
freezer.
This function stops automatically after 52
hours.
It is possible to deactivate the function at any

time by pressing key (D) until

indicator will

flash and then press key (E).

Drinks Chill Function

The Drinks Chill function is to be used as a
safety warning when placing bottles in the
freezer compartment. It is activated by
pressing key (D) (several times if necessary)

until the corresponding icon appears

.
You must confirm the choice by pressing key
(E) within few seconds. You will hear the buz­zer and the icon remains lighted.
In this condition it operates a timer with a de­fault value of 30 min. and it could change
from 1 to 90 min., by pressing key (B) you
select the minutes needed.
At the end of the selected time there are the
following indications:

•

on the indicator

•

the icon

•

the icon

flashing

the symbol flashing

flashing

• sounding of an acoustic alarm until key (E)

is pressed
At this point bear in mind to remove the
drinks contained in the freezer compartment.
It is possible to deactivate the function at any
time by pressing key (D) until the correspond­ing icon will flash and then key (E).

electrolux 7

Excessive temperature alarm

An increase in the temperature in a compart­ment (for example due to an power failure) is
indicated by:

• flashing temperature

•

freezer compartment

•

flashing of the icon

• sounding of buzzer
When normal conditions are restored:

• the acoustic signal shuts off

flashing

First use

Cleaning the interior

Before using the appliance for the first time,
wash the interior and all internal accessories
with lukewarm water and some neutral soap
so as to remove the typical smell of a brand­new product, then dry thoroughly.

Daily use

Important! this appliance is sold in France.
In accordance with regulations valid in this
country it must be provided with a special
device (see figure) placed in the lower com­partment of the fridge to indicate the coldest
zone of it.

• the temperature value continues to flash
When you press key (E) to de-activate the
alarm, the highest temperature reached in
the compartment appears on indicator
for some seconds.
Then it returns on the normal operation
showing the temperature of the selected
compartment.
During the alarm phase, the buzzer can be
switched off by pressing key (E).

Important! Do not use detergents or abra­sive powders, as these will damage the fin­ish.

Thawing

Deep-frozen or frozen food, prior to being
used, can be thawed in the refrigerator com­partment or at room temperature, depending
on the time available for this operation.
Small pieces may even be cooked still frozen,
directly from the freezer: in this case, cooking
will take longer.

Movable shelves

The walls of the refrigerator are equipped
with a series of runners so that the shelves
can be positioned as desired.

Storage of frozen food

When first starting-up or after a period out of
use, before putting the products in the com­partment let the appliance run at least 2
hours on the higher settings.

Important! In the event of accidental
defrosting, for example due to a power
failure, if the power has been off for longer
than the value shown in the technical
characteristics chart under "rising time", the
defrosted food must be consumed quickly or
cooked immediately and then re-frozen (after
cooling).

8 electrolux

Bottle rack

Place the bottles (with the opening facing
front) in the pre-positioned shelf.

Important! If the shelf is positioned
horizontally, place only closed bottles.

This bottle holder shelf can be tilted in order
to store previously opened bottles. To obtain
this result, pull the shelf up so it can rotate
upwards and be placed on the next higher
level.

Air cooling

The Dynamic Air Cooling (DAC) fan let food
cool quickly and a more uniform temperature
in the compartment.

1. You can switch on the fan by pressing the

switch (1).

Positioning the door shelves

To permit storage of food packages of vari­ous sizes, the door shelves can be placed at
different heights.
To make these adjustments proceed as fol­lows:
gradually pull the shelf in the direction of the
arrows until it comes free, then reposition as
required.

1

This device allows for rapid cooling of foods
and a more uniform temperature in the com­partment.

Important! Switch on the fan when the
ambient temperature exceeds 25°C.

electrolux 9

Vegetable Drawer

The drawer is suitable for storing fruit and
vegetables.
There is a separator inside the drawer that
can be placed in different positions to allow
for the subdivision best suited to personal
needs.
There is a grille (if foreseen) on the bottom of
the drawer to separate the fruit and vegeta­bles from any humidity that may form on the
bottom surface.
All parts inside the drawer can be removed
for cleaning purposes

Removal of freezing baskets from the
freezer

The freezing baskets have a limit stop to pre­vent their accidental removal or falling out. At
the time of its removal from the freezer, pull
the basket towards yourself and, upon
reaching the end point, remove the basket by
tilting its front upwards.

At the time of putting it back, slightly lift the
front of the basket to insert it into the freezer.
Once you are over the end points, push the
baskets back in their position.

2

1

Helpful hints and tips

Normal Operating Sounds

• You may hear a faint gurgling and a bub­bling sound when the refrigerant is pum­ped through the coils or tubing. This is cor­rect.

• When the compressor is on, the refrigerant
is being pumped around and you will hear
a whirring sound and a pulsating noise
from the compressor. This is correct.

• The thermic dilatation might cause a sud­den cracking noise. It is natural, not dan­gerous physical phenomenon. This is cor­rect.

Hints for energy saving

• Do not open the door frequently or leave it
open longer than absolutely necessary.

• If the ambient temperature is high and the
Temperature Regulator is set to low tem­perature and the appliance is fully loaded,
the compressor may run continuously,
causing frost or ice on the evaporator. If
this happens, set the Temperature Regu­lator toward warmer settings to allow au­tomatic defrosting and so a saving in elec­tricity consumption.

10 electrolux

Hints for fresh food refrigeration

To obtain the best performance:

• do not store warm food or evaporating liq­uids in the refrigerator

• do cover or wrap the food, particularly if it
has a strong flavour

• p osit ion f ood s o tha t air can circulate freely
around it

Hints for refrigeration

Useful hints:
Meat (all types) : wrap in polythene bags and
place on the glass shelf above the vegetable
drawer.
For safety, store in this way only one or two
days at the most.
Cooked foods, cold dishes, etc..: these
should be covered and may be placed on any
shelf.
Fruit and vegetables: these should be thor­oughly cleaned and placed in the special
drawer(s) provided.
Butter and cheese: these should be placed
in special airtight containers or wrapped in
aluminium foil or polythene bags to exclude
as much air as possible.
Milk bottles: these should have a cap and
should be stored in the bottle rack on the
door.
Bananas, potatoes, onions and garlic, if not
packed, must not be kept in the refrigerator.

Hints for freezing

To help you make the most of the freezing
process, here are some important hints:

• the maximum quantity of food which can
be frozen in 24 hrs. is shown on the rating
plate;

• the freezing process takes 24 hours. No
further food to be frozen should be added
during this period;

• only freeze top quality, fresh and thorough­ly cleaned, foodstuffs;

• prepare food in small portions to enable it
to be rapidly and completely frozen and to
make it possible subsequently to thaw only
the quantity required;

• wrap up the food in aluminium foil or pol­ythene and make sure that the packages
are airtight;

• do not allow fresh, unfrozen food to touch
food which is already frozen, thus avoiding
a rise in temperature of the latter;

• lean foods store better and longer than
fatty ones; salt reduces the storage life of
food;

• water ices, if consumed immediately after
removal from the freezer compartment,
can possibly cause the skin to be freeze
burnt;

• it is advisable to show the freezing in date
on each individual pack to enable you to
keep tab of the storage time.

Hints for storage of frozen food

To obtain the best performance from this ap­pliance, you should:

• make sure that the commercially frozen
foodstuffs were adequately stored by the
retailer;

• be sure that frozen foodstuffs are transfer­red from the foodstore to the freezer in the
shortest possible time;

• not open the door frequently or leave it
open longer than absolutely necessary.

• Once defrosted, food deteriorates rapidly
and cannot be refrozen.

• Do not exceed the storage period indica­ted by the food manufacturer.

Care and cleaning

Caution! Unplug the appliance before
carrying out any maintenance operation.

This appliance contains hydrocarbons in
its cooling unit; maintenance and re­charging must therefore only be carried
out by authorized technicians.

Periodic cleaning

The equipment has to be cleaned regularly:

• clean the inside and accessories with luke­warm water and some neutral soap.

• regularly check the door seals and wipe
clean to ensure they are clean and free
from debris.

• rinse and dry thoroughly.

electrolux 11

Important! Do no t p ul l, m ov e o r d ama ge an y
pipes and/or cables inside the cabinet.
Never use detergents, abrasive powders,
highly perfumed cleaning products or wax
polishes to clean the interior as this will dam­age the surface and leave a strong odour.

Clean the condenser (black grill) and the
compressor at the back of the appliance with
a brush or a vacuum cleaner. This operation
will improve the performance of the appli­ance and save electricity consumption.

Important! Take care of not to damage the
cooling system.

Many proprietary kitchen surface cleaners
contain chemicals that can attack/damage
the plastics used in this appliance. For this
reason it is recommended that the outer cas­ing of this appliance is only cleaned with
warm water with a little washing-up liquid
added.
After cleaning, reconnect the equipment to
the mains supply.

Defrosting of the refrigerator

Frost is automatically eliminated from the
evaporator of the refrigerator compartment
every time the motor compressor stops, dur­ing normal use. The defrost water drains out
through a trough into a special container at
the back of the appliance, over the motor
compressor, where it evaporates.
It is important to periodically clean the defrost
water drain hole in the middle of the refriger-

ator compartment channel to prevent the
water overflowing and dripping onto the food
inside. Use the special cleaner provided,
which you will find already inserted into the
drain hole.

Defrosting of the freezer

The freezer compartment of this model, on
the other hand, is a "no frost" type. This
means that there is no buildup of frost when
it is in operation, neither on the internal walls
nor on the foods.
The absence of frost is due to the continuous
circulation of cold air inside the compart­ment, driven by an automatically controlled
fan.

What to do if…

Caution! Before troubleshooting,
disconnect the power supply.
Only a qualified electrician or competent
person must do the troubleshooting that
is not in this manual.

Problem Possible cause Solution

The appliance is noisy. The appliance is not supported

The compressor operates
continually.

The door is not closed correctly. Refer to "Closing the door".
The door has been opened too

properly.

The Temperature regulator may
be set incorrectly.

frequently.

Important! There are some sounds during
normal use (compressor, refrigerant
circulation).

Check if the appliance stands sta­ble (all the four feet should be on
the floor).

Set a warmer temperature.

Do not keep the door open longer
than necessary.

12 electrolux

Problem Possible cause Solution

The product temperature is too

The room temperature is too

The Action Freeze function is

Water flows on the rear
plate of the refrigerator.

Water flows into the re­frigerator.

Products prevent that water flows

Water flows on the
ground.

There is too much frost
and ice.

The door is not closed correctly. Refer to "Closing the door".
The Temperature regulator may

The temperature in the
appliance is too high.

The product temperature is too

Many products are stored at the

The temperature in the re­frigeration is too high.

The temperature in the
freezer is too high.

The appliance does not
operate.

The mains plug is not connected

The appliance has no power.

The lamp does not work. The lamp is defective. Refer to "Replacing the lamp".

high.

high.

switched on.
During the automatic defrosting

process, frost defrosts on the rear
plate.

The water outlet is clogged. Clean the water outlet.

into the water collector.
The melting water outlet does not

flow in the evaporative tray above
the compressor.

Products are not wrapped prop­erly.

be set incorrectly.
The door is not closed correctly. Refer to "Closing the door".

high.

same time.
There is no cold air circulation in

the appliance.
Products are too near to each

other.
The appliance is switched off. Switch on the appliance.

to the mains socket correctly.

There is no voltage in the mains
socket.

Let the product temperature de­crease to room temperature before
storage.

Decrease the room temperature.

Refer to "Action Freeze function".

This is correct.

Make sure that products do not
touch the rear plate.

Attach the melting water outlet to
the evaporative tray.

Wrap the products better.

Set a higher temperature.

Let the product temperature de­crease to room temperature before
storage.

Store less products at the same
time.

Make sure that there is cold air cir­culation in the appliance.

Store products so that there is cold
air circulation.

Connect the mains plug to the
mains socket correctly.

Connect a different electrical appli­ance to the mains socket. Contact
a qualified electrician.

As much as the advice does not lead to result, call the nearest brand-mark service.

Replacing the lamp

If you want to replace the bulb, do these
steps:

1. Break the circuit of the appliance.

2. Unscrew the lamp cover securing screw.

3. Unhook the moving part by pressing it as

shown in the figure.

4. Replace the bulb with one of the same

power (the maximum power is shown on
the light bulb cover)

5. Fix the lamp cover in place.

electrolux 13

6. Screw the lamp cover securing screw.

7. Reconnect the appliance.

8. Open the door and check if the light
comes on.

Closing the door

1. Clean the door gaskets.

2. If necessary, adjust the door. Refer to "In­stallation".

3. If necessary, replace the defective door
gaskets. Contact the Service Force Cen­ter.

1

2

3

Technical data

Dimension
Height 1850 mm
Width 595 mm
Depth 632 mm
Rising Time 18 h

The technical information are situated in the
rating plate on the internal left side of the ap­pliance and in the energy label.

Installation

Read the "Safety Information" carefully
for your safety and correct operation of
the appliance before installing the
appliance.

Positioning

Install this appliance at a location where the
ambient temperature corresponds to the cli­mate class indicated on the rating plate of the
appliance:

Climate

class

SN +10°C to + 32°C
N +16°C to + 32°C
ST +16°C to + 38°C
T +16°C to + 43°C

Ambient temperature

Location

The appliance should be installed well away
from sources of heat such as radiators, boil­ers, direct sunlight etc. Ensure that air can
circulate freely around the back of the cabi­net. To ensure best performance, if the ap­pliance is positioned below an overhanging
wall unit, the minimum distance between the
top of the cabinet and the wall unit must be
at least 100 mm . Ideally, however, the ap­pliance should not be positioned below over­hanging wall units. Accurate levelling is en­sured by one or more adjustable feet at the
base of the cabinet.

14 electrolux

Warning! It must be possible to

disconnect the appliance from the mains
power supply; the plug must therefore
be easily accessible after installation.

2

mm

min

100

A

mm

20

B

Electrical connection

Before plugging in, ensure that the voltage
and frequency shown on the rating plate cor­respond to your domestic power supply.
The appliance must be earthed. The power
supply cable plug is provided with a contact
for this purpose. If the domestic power sup­ply socket is not earthed, connect the appli­ance to a separate earth in compliance with
current regulations, consulting a qualified
electrician.
The manufacturer declines all responsibility if
the above safety precautions are not ob­served.
This appliance complies with the E.E.C. Di­rectives.

Rear spacers
In the bag with the documentation, there

are two spacers which must be fitted as
shown in the figure.

Slacken the screws and insert the spacer
under the screw head, then tighten again the
screws.

1

3

Levelling

When placing the appliance ensure that it
stands level. This can be achieved by two
adjustable feet at the bottom in front.

Removing the shelf holders

Your appliance is equipped with shelf retain­ers that make it possible to secure the
shelves during transportation.
To remove them proceed as follows:

1. Move the shelf holders in the direction of
the arrow (A).

2. Raise the shelf from the rear and push it
forward until it is freed (B).

3. Remove the retainers (C).

electrolux 15

2. Remove the little plastic cover from the

door plastic trim and refit on the opposite
side (t3).

3. Remove the panel (t4). If it is necessary

use a screwdriver very carefully. Un­screw the screw on the other side. Re­move the upper door mount (t5). Place
them in an empty plastic bag.

t4

Door reversibility

Warning! Before carrying out any

operations, remove the plug from the
power socket.

Important! To carry out the following
operations, we suggest that this be made
with another person that will keep a firm hold
on the doors of the appliance during the
operations.

To change the opening direction of the door,
do these steps:

1. Open the door with the appliance in the
upright position. Unscrew the screws (t1)
and remove the upper door plastic trim
(t2). Close the door.

t1

t1

t1

t2

t3

d7

t5

4. Remove the upper door.

5. Unscrew the screw and remove the door
stopper (d1). Attach it reversed on the
other side.

d1

6. Unscrew the middle hinge (m2). Remove
the plastic spacer (m1).

7. Remove the lower door.

16 electrolux

m1

m5

m3

8. Remove the spacer (m6) and move to
the other side of the hinge pivot (m5).

9. Remove using a tool the cover (b1). Un­screw the lower hinge pivot (b2) and the
spacer (b3) and place them on the op­posite side.

10. Re-insert the cover (b1) on the opposite
side.

m2

m6

m4

14. Re-insert the lower door on the pivot pin
(b2).

15. Re-screw the middle hinge (m1) on the
opposite side . Do not forget the plastic
spacer (m2) inserted under the middle
hinge.

16. Re-insert the upper door on the middle
hinge (m5).
Make sure that the edges of the doors
run parallel to the side edge of the appli­ance.

17. Position and fix the upper hinge (you can
find them in the instruction for use bag)
on the opposite side (t6).

t6

t7

b1

b2

b3

11. Remove the stoppers (d1) and move to
the other side of the doors.

12. Remove the left-hand cover pin of the
middle hinge (m3,m4) and move to the
other side.

13. Fit the pin of the middle hinge (m5) into
the left-hand hole of the lower door.

18. Insert the panel (t7) (that can be found in
the instruction for use bag).

19. Open the upper door, attach the top
cover (t2) using screws (t1). Insert the
magnet (d7). Close the door.

20. Reposition, level the appliance, wait for
at least four hours and then connect it to
the power socket.

Do a final check to make sure that:

• All screws are tightened.

• The magnetic seal adheres to the cabinet.

• The door opens and closes correctly.

If the ambient temperature is cold (i.e. in Win­ter), the gasket may not fit perfectly to the
cabinet. In that case, wait for the natural fit­ting of the gasket.
In case you do not want to carry out the
above mentioned operations, contact the
nearest After Sales Service Force. The After
Sales Service specialist will carry out the re­versibility of the doors at your cost.

Environmental concerns

The symbol on the product or on its
packaging indicates that this product may
not be treated as household waste. Instead
it should be taken to the appropriate
collection point for the recycling of electrical
and electronic equipment. By ensuring this
product is disposed of correctly, you will help
prevent potential negative consequences for

electrolux 17

the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product. For more
detailed information about recycling of this
product, please contact your local council,
your household waste disposal service or the
shop where you purchased the product.

18 electrolux

Electrolux. Thinking of you.

Partagez notre imagination sur www.electrolux.com

Sommaire

Consignes de sécurité 18
Bandeau de commande 20
Première utilisation 24
Utilisation quotidienne 24
Conseils utiles 27
Entretien et nettoyage 28

Sous réserve de modifications

En cas d'anomalie de fonctionnement

Caractéristiques techniques 31
Pose 31
En matière de sauvegarde de
l'environnement 35

Consignes de sécurité

Pour votre sécurité et garantir une utilisation
correcte de l'appareil, lisez attentivement
cette notice, y compris les conseils et aver­tissements, avant d'installer et d'utiliser l'ap­pareil pour la première fois. Pour éviter toute
erreur ou accident, veillez à ce que toute per­sonne qui utilise l'appareil connaisse bien
son fonctionnement et ses fonctions de sé­curité. Conservez cette notice avec l'appa­reil. Si l'appareil doit être vendu ou cédé à
une autre personne, veillez à remettre cette
notice au nouveau propriétaire, afin qu'il
puisse se familiariser avec son fonctionne­ment et sa sécurité.
Pour la sécurité des personnes et des biens,
conservez et respectez les consignes de sé­curité figurant dans cette notice. Le fabricant
décline toute responsabilité en cas de dom­mages dus au non-respect de ces instruc­tions.

Sécurité des enfants et des personnes
vulnérables

• Cet appareil n'est pas destiné à être utilisé
par des enfants ou des personnes dont les
capacités physiques, sensorielles ou men­tales, ou le manque d'expérience et de
connaissance les empêchent d'utiliser
l'appareil sans risque lorsqu'ils sont sans
surveillance ou en l'absence d'instruction
d'une personne responsable qui puisse
leur assurer une utilisation de l'appareil
sans danger.
Empêchez les enfants de jouer avec l'ap­pareil.

• Ne laissez pas les emballages à la portée
des enfants. Risque d'asphyxie !

• Si l'appareil doit être mis au rebut, sortez
la fiche de la prise électrique, coupez le
cordon d'alimentation au ras de l'appareil
et démontez la porte pour éviter les risques
d'électrocution et que des enfants ne res­tent enfermés à l'intérieur.

• Si cet appareil muni de fermetures magné­tiques est destiné à remplacer un appareil
équipé d'une fermeture à ressort sur la
porte ou le couvercle, veuillez faire en sorte
que la fermeture à ressort devienne inutili­sable avant d'éliminer le vieil appareil. Ceci
afin d'éviter aux enfants de s'enfermer
dans l'appareil et de mettre ainsi leur vie en
danger.

Sécurité générale

Attention Veillez à ce que les orifices de

ventilation ne soient pas obstrués.

• Cet appareil est destiné uniquement à la
conservation d'aliments et/ou de boissons
dans le cadre d'un usage domestique nor­mal, tel que celui décrit dans la présente
notice.

• N'utilisez pas de dispositifs mécaniques
ou autres moyens artificiels pour accélérer
le dégivrage de l'appareil.

• N'utilisez pas d'autres appareils électri­ques (par exemple, sorbetières) à l'inté­rieur d'appareils réfrigérants sauf s'ils sont
homologués pour cet usage par leur fabri­cant.

• N'endommagez pas le circuit de refroidis­sement.

29

electrolux 19

• Le circuit de refroidissement de l'appareil
contient de l'isobutane (R600a), un gaz
naturel offrant un haut niveau de compati­bilité avec l'environnement mais qui est
néanmoins inflammable.
Pendant le transport et l'installation de
l'appareil, assurez-vous qu'aucune pièce
du circuit de refroidissement n'est endom­magée.
Si tel est le cas :
– évitez les flammes vives et les sources

d'ignition

– aérez soigneusement la pièce où se

trouve l'appareil

• Il est dangereux de modifier les caracté­ristiques de l'appareil ou l'appareil. Un cor­don d'alimentation endommagé peut être
la cause de courts-circuits, d'incendies et/
ou de décharges électriques.

Avertissement Les composants élec­triques (cordon d'alimentation, prise,
compresseur) doivent être remplacés
par un technicien d'entretien agréé ou
par un électricien spécialisé.

1. Le cordon d'alimentation ne doit pas

être rallongé.

2. Assurez-vous que la prise n'est pas

écrasée ou endommagée par l'arrière
de l'appareil. Une prise de courant en­dommagée peut s'échauffer et provo­quer un incendie.

3. Assurez-vous de pouvoir accéder à la

prise secteur de l'appareil.

4. Ne tirez pas sur le cordon d'alimenta-

tion.

5. Si la fiche du cordon d'alimentation est

desserrée, ne la branchez pas dans la
prise murale. Risque d'électrocution
ou d'incendie.

6. N'utilisez pas l'appareil si le diffuseur

de l'ampoule d'éclairage n'est pas pré-

4)

sent

pour l'éclairage intérieur.

• Cet appareil est lourd. Faites attention lors
de son déplacement.

• Ne touchez pas les produits congelés sor­tant du congélateur avec les mains humi­des car ceci peut provoquer des abrasions
ou des brûlures cutanées.

• Évitez les expositions prolongées de l'ap­pareil aux rayons solaires.

4) Si le diffuseur est prévu

5) Si l'appareil est sans givre

Utilisation quotidienne

• Ne posez pas d'éléments chauds sur les
parties en plastique de l'appareil.

• Ne stockez pas de gaz ou de liquides in­flammables dans l'appareil (risque d'ex­plosion).

• Ne placez pas d'aliments directement
contre la sortie d'air sur la paroi arrière de

l'appareil.

5)

• Un produit décongelé ne doit jamais être
recongelé.

• Conservez les aliments emballés confor­mément aux instructions de leur fabricant.

• Respectez scrupuleusement les conseils
de conservation donnés par le fabricant de
l'appareil. Consultez les instructions res­pectives.

• Ne mettez pas de bouteilles ni de boîtes
de boissons gazeuses dans le comparti­ment congélateur, car la pression se for­mant à l'intérieur du contenant pourrait le
faire éclater et endommager ainsi l'appa­reil.

• Ne consommez pas certains produits tels
que les bâtonnets glacés dès leur sortie de
l'appareil, car ils peuvent provoquer des
brûlures.

Entretien et nettoyage

• Avant toute opération d'entretien, mettez
l'appareil hors tension et débranchez-le de
la prise de courant.

• N'utilisez pas d'objets métalliques pour
nettoyer l'appareil.

• N'utilisez pas d'objet tranchant pour grat­ter la couche de givre. Utilisez une spatule
en plastique.

• Contrôlez régulièrement l'orifice d'évacua­tion de l'eau de dégivrage dans le com­partiment réfrigérateur. Nettoyez-le, le cas
échéant. Si l'orifice est bouché, l'eau
s'écoulera en bas de l'appareil.

Installation
Important Pour le branchement électrique,

respectez scrupuleusement les consignes
données dans cette notice.

20 electrolux

• Déballez l'appareil et vérifiez qu'il n'est pas
endommagé. Ne branchez pas l'appareil
s'il est endommagé. Signalez immédiate­ment les dommages constatés à votre
vendeur. Dans un tel cas, conservez l'em­ballage.

• Nettoyez fréquemment l'intérieur du réfri­gérateur en utilisant un produit d'entretien
doux sans effet oxydant sur les parties mé­talliques, puis rincer avec de l'eau addi­tionnée de jus de citron, de vinaigre blanc
ou avec tout produit désinfectant adapté
au réfrigérateur.

• Veillez à ce que l'air circule librement au­tour de l'appareil pour éviter qu'il ne sur­chauffe. Pour assurer une ventilation suffi­sante, respectez les instructions d'instal­lation.

• Dans la mesure du possible, placez l'ap­pareil dos au mur pour éviter tout contact
avec des pièces chaudes (compresseur,
condenseur) et tout risque de brûlure.

• L'appareil ne doit pas être placé à proxi­mité de radiateurs ou de cuisinières.

• Assurez-vous que la prise principale est
accessible une fois l'appareil installé.

• Branchez à l'alimentation en eau potable
uniquement.

6)

Bandeau de commande

Maintenance

• Les branchements électriques nécessai­res à l'entretien de l'appareil doivent être
réalisés par un électricien spécialisé ou
une personne compétente.

• Cet appareil ne doit être entretenu et ré­paré que par un service après-vente
agréé, exclusivement à l'aide de pièces
certifiées Constructeur.

Protection de l'environnement

Le circuit de refroidissement et les ma­tériaux isolants de cet appareil ne con­tiennent pas de gaz frigorigène suscep­tible de nuire à la couche d'ozone. L'ap­pareil ne doit pas être mis au rebut avec
les ordures ménagères et les déchets
urbains. La mousse isolante contient
des gaz inflammables : l'appareil doit
être mis au rebut conformément aux rè­glements applicables (informez-vous
auprès des services locaux compé­tents). Veillez à ne pas détériorer les cir­cuits frigorifiques, notamment au dos, à
proximité de l'évaporateur. Les maté­riaux utilisés dans cet appareil identifiés

par le symbole

sont recyclables.

B

A - Touche Marche/Arrêt D - Touche Fonctions
B - Touche de réglage de la température E - Touche de confirmation
C - Affichage de la température et de la fonc-

tion

6) Si un branchement sur le réseau d'eau est prévu

DEAC

Afficheur

electrolux 21

Symbole allumé : le compartiment indi-

Fonction Sécurité enfants

qué est mis en fonctionnement.
Symbole allumé : la température affi-

Fonction Minuteur
chée correspond à celle du comparti­ment correspondant.

Le voyant clignote : les opérations en

cours se réfèrent au compartiment cor-

Fonction Shopping (refroidissement ra-

pide)
respondant.

Alarme de température Fonction Refroidissement des bois-

sons
Symbole allumé : la température affi-

Fonction Congélation rapide
chée correspond à la température am­biante.

Indicateur de température positif ou né-

Fonction Mode Eco
gatif.

Affichage de la température

Première mise en service de l'appareil

Si, après avoir branché l'appareil, l'afficheur
n'est pas allumé, appuyez sur la touche (A)
pour mettre l'appareil sous tension.
Dès que l'appareil est mis en service, il se
trouve en condition d'alarme : l'afficheur de
température clignote et un signal sonore re­tentit.
Appuyez sur la touche (E) : le signal sonore
se désactive (reportez-vous également au
paragraphe "Alarme de température" ), le

symbole

clignote et l'affichage indi­que la température la plus élevée qui a été
atteinte.
Pour une conservation correcte des ali­ments, sélectionnez la fonction Mode Eco,
qui permet de garantir les réglages de tem­pérature suivants :
+5 °C dans le compartiment réfrigérateur

-18°C dans le compartiment congélateur

• Avant d'introduire des aliments dans le
congélateur, attendez que la température
du compartiment soit de -18°C.

• Si vous souhaitez sélectionner une tempé­rature différente, reportez-vous au para­graphe "Réglage de la température".

Mise à l'arrêt

Pour mettre l'appareil à l'arrêt, appuyez sur
la touche (A) pendant plus de 1 seconde.
L'afficheur effectue un décompte de 3 à 1.

Menu Fonctions

Pour activer le menu Fonctions, appuyez sur
la touche (D). Pour confirmer la fonction sé­lectionnée, appuyez sur la touche (E). Si vous
omettez de confirmer votre sélection, l'écran
quitte le menu Fonctions au bout de quel­ques secondes et retourne au mode de fonc­tionnement normal.

Les fonctions affichées sont les suivan­tes :

22 electrolux

Sélectionner/Mettre à l'arrêt/Mettre en

service le compartiment réfrigérateur

Sélectionner/Mettre à l'arrêt/Mettre en

service le compartiment congélateur

Température ambiante
Fonction Sécurité enfants
Fonction Shopping
Fonction Mode Eco

Fonction Congélation Rapide

Fonction Refroidissement des boissons

Réglage de la température

Pour régler la température, appuyez sur la
touche (D) pour sélectionner le comparti­ment, puis sur la touche (B) pour régler la
température souhaitée.
En appuyant sur la touche (B), la température
réglée clignote sur l'afficheur. Pour confirmer
la température sélectionnée, appuyez sur la
touche (E).
Un signal sonore retentit pendant quelques
secondes ; l'afficheur indique la nouvelle
température sélectionnée pendant quelques
secondes, puis indique à nouveau la tempé­rature actuelle du compartiment.
La nouvelle température sélectionnée sera
atteinte après 24 heures.
Si l'appareil n'est pas utilisé pendant une lon­gue période, il n'est pas nécessaire de régler
de nouveau la température car elle reste mé­morisée.

Important Pendant la période de
stabilisation de la première mise en service,
la température affichée peut ne pas
correspondre à la température réglée.
Pendant cette période, il se peut que la
température affichée et la température
programmée soient différentes.

Fonction Vacances "H"

La fonction Vacances règle la température à
+15 °C dans le compartiment réfrigérateur.
Cette fonction vous permet de garder le
compartiment réfrigérateur vide et fermé
pendant une longue période (par exemple,
les vacances d'été), sans formation de mau­vaises odeurs.
Pour activer la fonction Vacances, procédez
comme pour modifier la température sélec­tionnée. L'afficheur de température peut mo­difier la température indiquée jusqu'à + 8 °C,
par paliers de 1°C. + 2 °C est suivi de la lettre

"H ". Appuyez sur la touche E pour confirmer
votre sélection.
Le réfrigérateur est à présent en fonction
"Vacances" et en mode économie d'énergie.

Important Le compartiment réfrigérateur
doit être vide quand la fonction Vacances est
activée. Vous ne devez pas conserver de
marchandises dans ce compartiment !

Fonction Température ambiante

Pour activer la fonction Température am­biante, appuyez sur la touche (D) (plusieurs
fois, si nécessaire), jusqu'à ce que le symbole

correspondant apparaisse

Dans ce cas,
la température affichée correspond à la tem­pérature ambiante.
Vous devez valider votre sélection en appuy­ant sur la touche (E) dans les secondes qui
suivent. Un signal sonore retentit et le sym­bole reste allumé.
Il est possible de désactiver la fonction à tout
moment en appuyant sur la touche (D) jus­qu'à ce que le symbole correspondant cli­gnote, puis sur la touche (E)

Fonction Sécurité enfants

Pour activer la fonction Sécurité enfants, ap­puyez sur la touche (D) (plusieurs fois, si né­cessaire), jusqu'à ce que le symbole corres-

pondant apparaisse
Vous devez valider votre sélection en appuy­ant sur la touche (E) dans les secondes qui
suivent. Un signal sonore retentit et le sym­bole reste allumé. Dans ce cas, aucune mo­dification n'est possible en appuyant sur
l'une des touches tant que la fonction est
activée.
Il est possible de désactiver la fonction à tout
moment en appuyant sur la touche (D) jus­qu'à ce que le symbole correspondant cli­gnote, puis sur la touche (E).

Fonction Shopping

Si vous avez besoin de stocker une grande
quantité d'aliments dans votre réfrigérateur,
par exemple après avoir fait vos courses,
nous vous suggérons d'activer la fonction
Shopping : elle permet de refroidir rapide­ment les aliments tout en évitant le réchauf­fement des denrées déjà stockées dans le
compartiment.
Pour activer la fonction Shopping, appuyez
sur la touche (D) (plusieurs fois, si nécessai­re), jusqu'à ce que le symbole correspondant
