Page 1
PERFEKT GLIDE 24-1
24” Built-in Telescopic Range Hood
Page 2
Specifications are subject to change without notice
V1.4
RANGE HOOD FEATURES
• 24” (60cm) stainless steel built-in glide-out range hood
• LED lighting (3,200 Lumens)
• 2 speed adjustment
• 2 x dishwasher safe honey comb filters
• Electronic switch controls
• Quiet (7 sones/56dB) 300 CFM motor
PERFEKT GLIDE 24-1
24” Built-in Telescopic Range Hood
• 115 Volt, 60Hz, 15AMP
• AEG Range Hoods are supplied with a
Canadian cord and plug
• Electrical cord located 3
1/8
” (79mm)
from the top right corner of the unit at
the rear
ELECTRICAL REQUIREMENTS
• 6” Duct Adapter Included
DUCT SIZE
Page 3
Specifications are subject to change without notice
V1.4
Specifications
PERFEKT GLIDE 24-1
FRONT PANEL - DUCTED
D: 11” x W: 23
9/16
”
D: 280mm x W: 598mm
RANGE HOOD DIMENSIONS
Page 4
Specifications are subject to change without notice
V1.4
Specifications
PERFEKT GLIDE 24-1
CABINET BOX DESIGN
FRONT VIEW SIDE VIEW
6
9/16
”
166mm
23
5/8
”
600mm
Shelf Supports
Range hood
8
1/4
”
210mm
External Gable
External Gable
Page 5
Specifications are subject to change without notice
V1.4
Specifications
PERFEKT GLIDE 24-1
• 1. Pull the glide forward
• 2. Remove the 4 screws holding the glide to the panel
• 3. Install the matching front panel using the 4 screws
*Custom panel provided by customer*
NOTE: Removing the front stainless steel trim
6
9/16
”
166mm
FRONT PANEL INSTALLATION
Page 6
Specifications are subject to change without notice
V1.4
Specifications
PERFEKT GLIDE 24-1
• Ensure that the cabinet door panel is
lengthened to accommodate the
smaller sized Range Hood Front
Panel
NOTE: Cabinet Door Panel Height
Page 7
Specifications are subject to change without notice
V1.4
Specifications
PERFEKT GLIDE 24-1
• Drill (1/8”) at the points located
• Secure the damper to the motor
housing using the screws supplied
with the range hood
SECURING THE DAMPER
201.5mm
7
15/16
”
100mm
3
15/16
”
120mm
4
3/4
”
191.5mm
7
9/16
”
168.5mm
6
5/8
”
DAMPER INSTALLATION
139.7mm
5
1/2
”
Page 8
Specifications are subject to change without notice
V1.4
Specifications
PERFEKT GLIDE 24-1
• W: 220mm x D:175mm
W: 8
11/16
” x 6
7/8
”
• Shelf depth MUST BE a minimum of 11” deep
DAMPER CUT-OUT
220mm
8
11/16
”
175mm
6
7/8
”
141mm
5
9/16
”
100mm
3
15/16
”
• Shelf with less than 1” of shelf extension MUST HAVE a support
brace in place
DAMPER INSTALLATION (SHELF CUT-OUT)
Page 9
Specifications are subject to change without notice
V1.4
Specifications
PERFEKT GLIDE 24-1
• W: 220mm x D:175mm
W: 8
11/16
” x 6
7/8
”
• Shelf depth MUST BE a minimum of 11” deep
DAMPER CUT-OUT
220mm
8
11/16
”
175mm
6
7/8
”
141mm
5
9/16
”
100mm
3
15/16
”
• Shelf with 1” or more extension does not require a support brace.
DAMPER INSTALLATION (SHELF CUT-OUT)
Page 10
Specifications are subject to change without notice
V1.4
Specifications
PERFEKT GLIDE 24-1
RECOMMENDED CABINET MINIMUM CLEARANCE
(GAS COOKING SURFACE)
Page 11
Specifications are subject to change without notice
V1.4
Specifications
PERFEKT GLIDE 24-1
RECOMMENDED CABINET MINIMUM CLEARANCE
(ELECTRIC / INDUCTION COOKING SURFACE)
24” (610mm)
