AEG CD2160-1D User Manual
COMPETENCE D2160-1
Built-in Electric Fanned
Double Oven
Operating Instructions
IMPORTANT SAFETY INFORMATION
These warnings are provided in the interests of your safety. Ensure that you understand them all before installing
or using the appliance. Your safety is of paramount importance. If you are unsure about any of the information in
this book contact the Customer Care Department. Telephone 0870 5 350350
INSTALLATION
The appliance must be installed according to
the instructions supplied.
The appliance must be installed in an
adequately ventilated room.
NOTE: It is imperative that the appliance is left
in the base to protect both the appliance and
the floor.
This appliance is heavy and care must be
taken when moving it. Do not try to move the
appliance by pulling the door handles.
Warning: Do Not attempt to lift this appliance
by the handles.
All packaging, both inside and outside the
appliance must be removed before the
appliance is used.
It is dangerous to alter the specifications or
modify the appliance in any way.
After installation please dispose of the
packaging with due regard for safety and the
environment. Your local authority can arrange
this.
CHILD SAFETY
Do not allow young children to play with any
part of the packaging.
This appliance is designed to be operated by
adults. Young children must not be allowed to
tamper with the controls or play near or with
the appliance.
CAUTION: Accessible parts may be hot
when the grill is in use. Young children
should be kept away
.
DURING USE
The appliance is not intended for use by young
children or infirm persons without supervision.
This appliance has been designed for domestic
use to cook edible foodstuffs only, and must
not be used for any other purpose.
Take great care when heating fats and oils as
they will ignite if they become too hot.
Never place plastic or any other material which
may melt in or on the oven.
Do not stand too close to the oven or grill while
in use as warm air will exhaust from the grill
cavity and the vents on the front frame of the
appliance.
Always use oven gloves to remove and place
food in the oven.
Ensure that all vents are left unobstructed to
ensure ventilation of the oven cavity.
Never line any part of the appliance with foil.
During use the appliance becomes Hot. Care
should be taken to avoid touching heating
elements inside the oven.
Stand clear when opening the drop down oven
doors. Support the doors using the handles
until fully open.
Never leave the appliance unattended when
the oven door is open.
Do not place sealed cans or aerosols inside
the oven. They may explode if they are heated.
Ensure that all control knobs are in the OFF
position when not in use.
Do not stand on the appliance or on the open
oven doors.
Do not hang towels, dishcloths or clothes from
the appliance or its handles. They are a safety
hazard.
CLEANING AND MAINTENANCE
The appliance is heavy and care must be taken
when moving it.
For hygiene and safety reasons this
appliance should be kept clean at all times.
A build-up of fats or other foodstuffs could
result in a fire especially in the grill pan.
Do not leave cookware containing foodstuffs,
e.g. fat or oil in the appliance in case it is
inadvertently switched on.
Always allow the cooling fan to cool the
appliance down before switching off at the wall
prior to carrying out any cleaning / maintenance
work.
Only clean this appliance in accordance with
the instructions given in this book.
SERVICE
Repairs should not be carried out by
inexperienced persons as this may cause injury
or serious malfunction. This appliance should
be serviced by an authorised Service Engineer
and only genuine approved spare parts should
be used. Details of servicing and repair
arrangements are supplied on page 29 of this
book.
AT THE END OF THE COOKERS LIFE
When the time comes to dispose of your
appliance please contact your local Council
Authority. They can arrange to dispose of the
appliance in a safe and controlled manner. The
number will be in the telephone book.
Please read this
instruction book carefully
before use and retain
for future reference.
2
CONTENTS
FOR THE USER
Important Safety Information ................ 2
Description Of The Oven .................... 4
Getting To Know Your Oven ................... 5
The Cooling Fan For The Controls ............. 5
Control Panel Indicator Neons ................. 5
Grill And Oven Furniture ....................... 6
Telscopic Runners ............................ 6
Before Using The Oven For The First Time ..... 7
When First Switching On ...................... 7
Rating Plate ................................... 7
Preparing To Use Your Oven .................. 7
Condensation And Steam ..................... 7
Cookware .................................... 7
Electronic Timer ............................. 8
The Dual Grill ............................... 12
Using The Grill ............................... 12
Things To Note .............................. 12
Using The Telescopic Runners ............... 12
The Grill Pan And Handle ..................... 13
Hints And Tips ............................... 13
Grilling Chart ................................. 14
The Second Oven ........................... 15
Using The Second Oven ..................... 15
Things To Note .............................. 15
To Fit The Second Oven Shelf ................ 15
Hints And Tips ............................... 16
The Main Fan Oven ......................... 17
Preheating ................................... 17
Cooking Temperatures ....................... 17
Batch Baking ................................. 17
Using The Fan Oven ......................... 17
Things To Note .............................. 17
To Fit The Main Oven Shelves ................ 17
Using The Telescopic Runners ............... 18
Hints And Tips ............................... 18
Care And Cleaning .......................... 24
Cleaning Materials ........................... 24
Cleaning The Outside Of The Oven ........... 24
Cleaning The Gold Handles ................... 24
Removing And Replacing Wirework
Side Runners ................................ 24
Cleaning Inside The Ovens ................... 25
Cleaning The Door Glass ..................... 25
To Remove The Inner Glass .................. 25
To Clean The Inner Glass Door Panels ........ 25
To Replace The Inner Glass Panel ............ 26
Cleaning The Grill And Oven Furniture ........ 26
Replacing An Oven Light Bulb ................ 26
Something Not Working .................... 27
Service and Spare Parts .................... 29
Guarantee Conditions ...................... 30
FOR THE INSTALLER
Technical Details ........................... 31
Warnings ..................................... 32
Choice Of Electrical Connection ............ 32
Things To Note .............................. 33
Preparing Cabinet For Fitting Of Oven ........ 33
Recommended Cabinet Dimensions .......... 34
How To Finish Unpacking .................... 35
Tools Required ............................... 35
Making The Electrical Connections ......... 35
Preparing Cable .............................. 35
To Remove Cover Of Mains Terminal ......... 36
Connecting To The Mains Terminal ........... 37
Connecting To A Hob Or Cooker Point ........ 37
Checking Electrical Connections .............. 37
Fitting Into The Cabinet ..................... 38
Oven Cooking Chart ........................ 19
Roasting Chart .............................. 20
Defrosting .................................. 21
Using Defrost Feature ........................ 21
Things To Note .............................. 21
Hints And Tips ............................... 21
Helpful Hints When Buying And Preparing
Food ..................................... 23
3
DESCRIPTION OF THE OVEN
Build-in electric fanned double oven.
Electronic Timer
Control Panel
Top Oven/Grill
Main Oven
Please note: D2160-1G control knobs will differ in type and shape from that shown in the diagram.
Please note that the handle type on your product may differ in type and shape from that shown in the diagram.
Your build-in oven comprises of a conventional second oven and dual grill in the top compartment.
The main fanned oven is the larger of the two ovens. It can be automatically controlled by the electronic timer.
To help you the following symbols
will be found in the text.
Safety Instructions
1, 2, 3,
Step by Step Instructions
Hints and Tips
4
GETTING TO KNOW YOUR OVEN
The Control Panel
Please note: D2160-1G control knobs and graphics will differ in type and shape from that shown in the diagram.
A - Main Oven Temperature Control
B - Main Oven Indicator Neon
C - Electronic Timer
D - Dual Grill Control
E - Grill Indicator Neon
F - Second Oven Indicator Neon
G - Second Oven Temperature Control
The Cooling Fan for the Controls
The cooling fan comes on immediately when the grill is switched on and after a short time when either of the
ovens are in use. It may run on after the controls are switched off until the appliance has cooled. During the
initial period the cooling fan may turn ON and OFF, this is quite normal.
Control Panel Indicator Neons
These lights indicate whether the grill or ovens are switched ON. In the case of the ovens, the neons also
indicate when the set temperature has been reached. The indicator neon will go out when the oven has
reached the set temperature. It will turn on and off during cooking to show that the oven temperature is being
maintained.
If the neons do not operate as the instructions indicate the controls have been incorrectly set. Return all
controls to zero and reset following the instructions for the required setting.
5
GRILL AND OVEN FURNITURE
The following items of grill and oven furniture have
been supplied with the appliance. If you require
replacements of any of the items listed below,
please contact your local Service Force Centre
quoting the relevant part number.
1 grill pan
(311409401)
1 grill pan handle
(311468100)
Note
If you require an additional handle for your grill pan,
this can be ordered from your local Service Force
Centre by quoting part number 311479800\6
Telescopic Runners
Your appliance may be fitted with telescopic
runners in the grill and main oven.
To fit the shelf into the telescopic runner,
1. Ensure the telescopic runners are pushed back
into the oven cavity before fitting the shelf.
2. Holding the front edge of the shelf with both
hands, place the rear shelf forms over the
telescopic runners.
3. Slide the shelf into position, lifting slightly at the
front so that the shelf locates into the retaining
hooks.
To remove, raise the front edge and withdraw the
shelf.
FORM
RETAINING
HOOK
1 grill pan grid
(311419801)
1 meat tin
(311409401)
1 cranked shelf
(for grilling and
second oven
cooking only)
2 straight shelves
(for main oven
cooking)
6
BEFORE USING THE OVEN FOR THE FIRST TIME
When First Switching on
The oven has a 24 hour clock. When the oven is
first switched on at the wall the electronic display
will automatically show 12.00, the 'Time' ( )
neon will also flash.
To set the time of day and use the timer refer to
instructions on page 8.
Rating plate
This is situated on the lower front frame of the
oven and can be seen upon opening the main
cavity door. Alternatively the rating plate may also
be found on the back or top of some models
(where applicable).
The oven must be protected by a suitably rated
fuse or circuit breaker. The rating of the oven is
given on the rating plate.
The rating plate must not be removed from the
oven front frame as this may invalidate the
guarantee.
Preparing to use your oven
Clean the ovens with a soft cloth and hot soapy
water and wash the grill and oven furniture before
use.
The grill and ovens should be heated without food
to burn off any residue from the elements. To do
this, run the ovens at 220°C for 10 - 15 minutes.
The procedure should be repeated with the grill for
approximately 5 - 10 minutes.
During this period an odour may be emitted, it is
therefore advisable to open a window for
ventilation.
Condensation and Steam
When food is heated it produces steam in the
same way as a boiling kettle does. The ovens are
vented to allow some of this steam to escape.
However, always stand back from the appliance
when opening the oven doors to allow any build up
of steam or heat to be released. If the steam
comes into contact with a cool surface on the
outside of the appliance, e.g. a trim, it will
condense and produce water droplets. This is quite
normal and is not caused by a fault on the
appliance.
To prevent discolouration occurring, regularly wipe
away condensation and any soilage from the
appliance surfaces.
Cookware
Baking trays, oven dishes etc., should not be
placed directly against the grid covering the fan at
the back of the oven.
Do not use baking trays larger than 30cm x 35cm
(12" x 14") as they will restrict the circulation of
heat and may affect performance.Do not place
bakeware directly on the second oven base when
the oven is on as damage to the oven enamel and
bakeware will occur.
7
ELECTRONIC TIMER
KEY
A COOK TIME
B END TIME
C COUNTDOWN
DTIME
E DECREASE CONTROL
F SELECTOR CONTROL
G INCREASE CONTROL
NOTE:
The time of day must be set before the main
oven will operate manually.
1. HOW TO SET THE TIME OF DAY
The oven has a 24 hour clock.
When the electricity supply is first switched ON, the
display will show 12.00 and the 'Time' ( )
indicator neon will flash as Fig. 1.
To set the correct time press the increase control
button (+) and if necessary, the decrease control
button (-) until the correct time on the 24 hour clock
is reached, e.g. 10.00am as Fig. 2. The 'Time'
indicator ( ) neon will flash for 5 seconds and
then go out.
A
B
Fig. 1
E
C
D
F G
Note: The increase and decrease control
buttons operate slowly at first, and then more
rapidly. They should be pressed separately.
2. HOW TO SET THE COUNTDOWN
The 'Countdown' gives an audible reminder at the
end of any period of cooking. This cooking period
may be up to 2 hrs 30 mins. It is not part of the
automatic control.
To set, press the Selector Control button ( )
until the 'Countdown' indicator is illuminated ( )
the display reads 0 . 00 as Fig.3.
To set the correct time duration depress the
increase control (+) until the display indicates the
interval to be timed, e.g. 1hr 45 mins as Fig. 4. If
necessary depress the decrease control (-) to
achieve the correct time interval.
NOTE: This must be completed within 5
seconds of first pressing the Selector Control
button.
During the operation of the Countdown, the
remaining time period will be shown in the display.
Fig. 2
Fig. 3
Fig. 4
8
The 'Countdown' will sound intermittently for up to
2 minutes at the end of the timed period. The
sound can be stopped by pressing any button.
TO CANCEL THE COUNTDOWN
If you change your mind and want to cancel the
'Countdown', press the Selector Control button until
the 'Countdown' indicator ( ) flashes and then
the decrease control ( - ) until 0 . 00 shows in the
display as Fig. 5. The Countdown indicator ( )
will continue to flash for a few seconds and then
return to the time of day.
3. SETTING THE OVEN TIMER
CONTROL
The main oven only can be automatically timed.
When using the timer control for the very first time,
it is advisable to let it operate while you are at
home. The displays can be checked to show that it
is operating correctly and you will feel confident to
leave a meal to cook automatically in the future.
A) TO SET THE TIMER TO SWITCH ON
AND OFF AUTOMATICALLY
i) Ensure the electricity supply is switched ON
and that the correct time of day is displayed,
e.g. 9.a.m. as Fig. 6.
ii) Place food in oven.
iii) To set the length of cooking time, press the
Selector Control button ( ) until the 'Cook
Time' indicator is illuminated ( ) . Press
the increase control ( + ) until the required
length of cooking time is displayed, e.g. 2
hrs 15 mins as Fig. 7. If necessary depress
the decrease control ( - ) until the correct
time interval is achieved.
The maximum cooking time is 10 hours.
iv) Release the buttons. The 'Cook Time'
indicator ( ) will be illuminated.
Remember, this must be completed within 5
seconds of first pressing the Selector Control
button.
Fig. 5
Fig. 6
Fig. 7
9
v) To set the 'End Time'. Press the Selector
Control button until the 'End Time' ( )
flashes. Press the increase control ( + )
until the required stop time is displayed, e.g.
12.15 p.m. as Fig. 8. If necessary
depress the decrease control ( - ) until the
correct time interval is achieved.
vi) Release the buttons. The time of day will
be displayed after 5 seconds. The Cook
Time ( ) and End Time ( ) indicators
will be illuminated.
The 'End Time' must not be more than 23
hours 59 minutes from the time of day. For
example, if the time of day is 09.00 a.m.,
the latest 'End Time' would be 08.59 a.m.
the next day.
vii) Set the main oven control to the required
temperature. The oven indicator neon
should be OFF.
Note: When the automatic timed period starts,
the oven indicator neon will turn ON and OFF
periodically during cooking, showing that the
temperature is being maintained.
Fig. 8
B) TO SET THE TIMER TO SWITCH OFF
ONLY
i) Ensure the electricity supply is switched ON
and that the correct time of day is displayed,
e.g. 10.00am as Fig. 9.
ii) Place food in oven.
iii) To set the length of cooking time, press the
Selector Control button until the 'Cook Time'
( ) indicator is illuminated. Press the
increase control (+) until the required length
of cooking time is displayed, e.g. 2 hrs 15
mins as Fig. 10. Depress the decrease
control (-) if necessary.
iv) Release the buttons. The 'Cook Time'
indicator ( ) will illuminate and the time
of day will be displayed after 5 seconds.
v) Set the oven temperature. The oven
indicator neon should be ON.
vi) To check the End Time during the cooking
period, simply press the Selector Control
button once and the remaining time will be
displayed, as Fig. 11.
Fig. 9
Fig. 10
Fig. 11
10
4. TO CANCEL AN AUTOMATIC
PROGRAMME
i) To cancel an automatic programme press
the Selector Control button until the Cook
Time indicator ( ) flashes. Press the
decrease control ( - ) until the display reads
0.00 as Fig.12.
ii) Release the buttons. The 'Cook Time'
indicator ( ) will flash and after 5
seconds return to the time of day
iii) Turn off oven control.
5. TO RETURN THE APPLIANCE TO
MANUAL
At the end of a timed cooking period, the
indicator neon will flash and an alarm will sound
for up to 2 minutes.
i) To stop the sound press any of the three
buttons, as Fig. 13.
Fig. 12
ii) The display will return to the time of day.
iii) Turn off the oven controls.
6. THINGS TO NOTE
l
In the event of an interruption of the electricity
supply, the timer will reset itself to zero, and all
programming will be cancelled.
7. AUTOMATIC COOKING
It is advisable to leave food in the oven for as
short a time as possible before automatic
cooking. Always ensure commercially prepared
food is well within its use by date and that
home prepared food is fresh and of good
quality.
When cooking is complete, do not leave food
to stand in the oven, but remove and cool it
quickly if the food is not to be consumed
immediately.
Fig. 13
Always ensure food in the oven has been
covered before cooking if it is not possible to
remove food immediately after cooking.
11
USING THE
THE DUAL GRILL
CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS
IN USE. CHILDREN SHOULD BE KEPT AWAY.
The grill is a dual circuit grill which means that the full area of the grill can be used or for economy purposes,
the centre section only can be used when cooking smaller quantities of food.
USING THE GRILL
Please note: D2160-1G control knobs and graphics will differ in type and shape from that shown in the diagram.
1. To operate the grill turn the grill control
clockwise for full grill or anticlockwise for centre
section only.
2. The highest number represents the hottest
setting and the lowest the coolest setting.
3. Ensure the second oven control is in the OFF
position '0'.
THE GRILL DOOR MUST BE LEFT
OPEN DURING GRILLING. IF
CLOSED THE ELEMENTS WILL
SWITCH OFF AND THE OVEN
LIGHT WILL TURN ON AND OFF
AS A WARNING.
USING THE TELESCOPIC RUNNERS
(where fitted)
1. Ensure the telescopic runners are pushed back
into the oven cavity before fitting the shelf.
2. Holding the front edge of the shelf with both
hands, place the rear shelf forms over the
telescopic runners.
3. Slide the shelf into position, lifting slightly at the
front so that the shelf locates into the retaining
hooks.
To remove, raise the front edge and withdraw
the shelf.
THINGS TO NOTE
l
The cooling fan for the controls will operate in
conjunction with the grill. For more information
on the operation of the cooling fan see page 5.
l
The grill indicator neon will glow until the
desired power level has been reached. It will
turn ON and OFF periodically during cooking
showing that the temperature is being
maintained.
l
The outer grill element may appear to glow
slightly brighter than the inner element. This is
quite normal.
l
The cranked shelf MUST only be used in the
grill compartment.
l
Some smoke from fat splashes may be evident
as the grill cleans itself.
RETAINING
HOOK
12
Loading...
