Belshaw Adamatic
BARP-2 Series Retarder-Proofer,
2-Door, Roll-in
Construction
Stainless steel exterior with 300 Series s/s interior and ▪
aluminized steel top
Foamed insulation in walls ceilings and doors ▪
Modular wall+ceiling panels with cam lock construction ▪
Rapid responding air-wash heat and humidity system ▪
Heavy duty welded s/s hinges ▪
Depth up to 120”, capacity up to 14 racks ▪
208/240 VAC, either 1 or 3-phase eld convertible ▪
Refrigeration components compatible with R404A refrigerant ▪
Includes condenser standard ▪
Operation
Dual purpose, provides both proong and retarding ▪
70°-120° F proong range ▪
34°-45° F retarding range ▪
50 - 99% humidity range ▪
Non-submerged calrod type heaters ▪
Evaporators sized for high humidity levels, prevents drying ▪
Refrigeration system sized for rapid pull down ▪
Interior bumpers protect interior walls from damage ▪
Lighted interior ▪
Controls
Digital set Temperature, Humidity, Time ▪
PID type controls for rapid accurate response without overshoot ▪
Operates in individual modes or automatic mode ▪
All digital controls mounted in the door at eye-level ▪
Large LED display, real-time clock ▪
Options
Stainless steel oor ▪
Refrigeration condenser (requires separate connection) ▪
Prison package ▪
Model/Rack Capacity*
Model / Depth Side Load
28.4”Wx18.0”D
End Load
26.0”Wx20.4”D
Double
28.4”Wx36.0”D
BARP-2-30 2 Racks 3 Racks None
BARP-2-40 4 Racks 3 Racks 2 Racks
BARP-2-50 5 Racks 5 Racks 2 Racks
BARP-2-60 6 Racks 6 Racks 3 Racks
BARP-2-70 7 Racks 7 Racks 3 Racks
BARP-2-80 9 Racks 8 Racks 4 Racks
BARP-2-90 10 Racks 10 Racks 5 Racks
BARP-2-100 11 Racks 10 Racks 5 Racks
BARP-2-110 12 Racks 13 Racks 5 Racks
BARP-2-120 14 Racks 13 Racks 7 Racks
*Racks may be snug at maximum capacity. For details of rack arrangement, see
the Rack Capacity Guide at http://www.belshaw-adamatic.com/specs/belshaw-
adamatic-rack-capacity-guide.pdf
BARP-2-40 Retarder Proofer
Short Bid Specication
Rack Proofer Model BARP-2-xxx [insert 30 thru 120] shall
be a 5 to 13.2 kW electrically heated, double door roll-in rack
unit with: quick responding air-wash heat / humidity system;
modular cam lock panel construction with foamed insulation; all
stainless steel interior, with protective cart bumpers; heavy-duty
doors with magnetic seal/mechanical closure system and full
width protective bar handle; simple computerized controls,
door mounted at eye-level, with accurate digital temperature,
humidity and time readouts; plus all the features listed and
options checked.
Standard Product Warranty
One-Year Parts and Labor, USA and Canada.
(USA includes 50 states + DC unless specied)
Certications
BELSHAW ADAMATIC BAKERY GROUP 206-322-5474 ▪ 800-578-2547 ▪ info@belshaw-adamatic.com
814 44th St NW, Suite 103, Auburn, WA 98001 USA • www.belshaw-adamatic.com
©2009 Belshaw Adamatic Bakery Group Specications are subject to change without notice.
BARP-2 Series Retarder-Proofer, 2-Door
C
with ceiling-mounted Condenser
Add 16.9”
91.4
68.75
Opening Width
Specifications
Model
Retarder
BTU’s *
BARP-2-30 5500
3.7
for Drain
Water and �
Electrical �
13.5 from �
74.1
Opening Height
37.00
88.00
4.0
Drain
D
Overall�
edge
A
Depth
Height Width Depth Approx Weight (lbs)
Int Ext Int Ext “A” “B” “C” “D” Actual Ship
68” 26” 39.5” 31.1” 1100 1200
78.80
68.5
Inside Width
Freight Class=70
BARP-2-40 5500 78” 36” 49.5” 41.1” 1157 1282
BARP-2-50 7000 88” 46” 59.5” 51.1” 1329 1454
BARP-2-60 9000 98” 56” 69.5” 61.1” 1411 1536
BARP-2-70 9000 108” 66” 79.5” 71.1” 1493 1618
BARP-2-80 11,000 118” 76” 89.5” 81.1” 1665 1790
74.1” 91.4” 68.1” 78.8”
BARP-2-90 11,000 128” 86” 99.5” 91.1” 1924 2049
BARP-2-100 15,000 138” 96” 109.5” 101.1” 2006 2131
BARP-2-110 15,000 148” 106” 119.5” 111.1” 2178 2303
BARP-2-120 18,000 158” 116” 129.5” 121.1” 2260 2385
Electrical Requirements
* BTU Rating @35°
Model Voltage Total kW 1-Phase 3-Phase Condenser
BARP-2-(30-80) 208 VAC 5 kW 24.0 A 13.8 A
240 VAC 6.6 kW 27.5 A 15.8 A
BARP-2-(90-120) 208 VAC 10.2 kW 48.0 A 27.6 A
240 VAC 13.2 kW 55 A 31.6 A
Volts: 208/240/60/1
Amps: 6A-18A. Condenser model depends
on target minimum temperature chosen.
Condenser specs: http://www.belshaw-adamatic.
com/specs/belshaw-adamatic-retarder-proofer-
BARP-condenserspecs.pdf
Water Supply and Drainage Requirements
Model Water Supply Drainage
BARP-2-(30-80) 1/2” NPT .07 GPM @ 60 PSI
BARP-2-(90-120) 1/2” NPT .14 GPM @ 60 PSI
1/2”PVC; 110°F
<1 GPM Max, Vented
B
Inside Depth
Installation Requirements
Requires on-site installation ▪
Refrigeration condenser requires separate connection ▪
KD shipment. When disassembled, can t through 36” ▪
opening
Consult factory for shipment fully assembled ▪
208/240 VAC, either 1 or 3-phase, eld convertible ▪
1/2” NPT cold water conection ▪
1/2” PVC vented drain connection ▪
Refrigeration system must be installed by a licenced refrig- ▪
eration technician
This appliance is designed to operate at normal room ▪
temperatures; if installed next to an oven or other heat
source allow a minimum clearance of 4” to prevent heat
transfer.
Clearance from combustibles is 0.0” sides and back ▪
2” clearance on both sides, required for doors to open 90° ▪
For install on non-porous surfaces only ▪
Your local water conditions may damage your appliance. ▪
Failure to properly treat water may result in damage and
may void your warranty. Ensure that your water supply
meets these minimum water quality specications:
Alkalinity: 22 ppm Aluminum: 17 ppm Calcium: 3.3 ppm Free chlorine residual: 0.6 ppm Magnesium: 0.65 ppm PH range: 8.5 s.u. Sodium: 8.5 ppm Total Hardness: 11.9 ppm -
Consult your local water treatment company for proper water ▪
ltration system.
