A&D MPA-1200 User Manual

PA-10/MPA-20/MPA-200/MPA-1200

Single Channel Electronic Pipette

INSTRUCTION MANUAL

1WMPD4002874B

WARNING DEFINITIONS

The warnings described in this manual have the following meanings:

DANGER

WARNING

CAUTION

NOTE Information or cautions to use the device correctly.

An imminently hazardous situation which, if not avoided, will result in death or serious injury.

A potentially hazardous situation which, if not avoided, could result in death or serious injury.

A potentially hazardous situation which, if not avoided, may result in minor or moderate injury or damage to the instrument.

© 2014 A&D Company Ltd. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, or translated into any language in any form by any means without the written permission of A&D Company Ltd.

The contents of this manual and the specifications of the instrument covered by this manual are subject to change for improvement without notice.

CONTENTS

1. FOR SAFE USE..........................................................................................................3

1-1 Precautions on using the pipette...............................................................................................3

1-2 Precautions on handling the battery....................................................................................... ...3

2. INTRODUCTION.........................................................................................................4

3. FEA TURE....................................................................................................................4

4. COMPLIANCE............................................................................................................5

5. MP A FUNCTION......................................................................................................... 7

6. P ACKING CONTENTS AND NAME OF ITEMS..................................................... 8

7. PREP ARATION BEFORE USE ..............................................................................10

7-1 Installing the battery..................................................................................................................10

7-2 Recharging the battery .............................................................................................................11

7-3 Exchange selectable power plug.............................................................................................12

7-4 Before operating the pipette.....................................................................................................12

7-5 Parts names ..............................................................................................................................14

8. NAME AND FUNCTIONS OF DISPLAY AND KEYS...........................................15

8-1 Display and functions................................................................................................................15

8-2 Key switches and functions......................................................................................................16

9. FUNCTION AND HOW TO USE.............................................................................17

9-1 Standard mode (AUTO)............................................................................................................17

9-2 Multiple dispensing mode (MD)............................................................................................. ..19

9-3 Mixing mode（MIX）...............................................................................................................21

9-4 System setting mode（SYS）.................................................................................................23

9-5 Program setting mode ..............................................................................................................25

9-6 Reverse operation (Dispensing liquid that tends to remain in the tip) ..................................25

9-7 Blowout function........................................................................................................................27

9-8 Total discharge function ............................................................................................................28

9-9

“Dispensing correction function” for multiple dispensing......................................................28

10. PIPETTING FOR ACCURATE DISPENSING .......................................................28

11. CALIBRA TING THE PIPETTE USING AN ELECTRONIC BALANCE..............29

11-1 Volume calibration function (μL calibration function)............................................................29

11-2 Resetting the volume calibration............................................................................................30

1 1-3 Dispensing in a unit of weight

(in mg unit)

...........................................................................31

11-4 Weight calibration function (mg calibration function)............................................................32

12. ADJUSTING HEIGHT OF THE TIP EJECTOR.....................................................34

13. STORAGE AND MAINTENANCE..........................................................................34

13-1 Autoclave .................................................................................................................................35

14. TROUBLE SHOOTING............................................................................................36

15. WHEN REQUESTNG REP AIRE.............................................................................37

16. SPECIFICA TION.......................................................................................................38

17. LIST OF ITEMS SOLD SEP ARATEL Y（DISPOSABLE ITEMS）.....................39

17-1 Stands and hanger..................................................................................................................39

17-2 Tips and accessories ..............................................................................................................40

17-3 Disposable items (User replaceable)....................................................................................42

17-4 Others ......................................................................................................................................43

1. FOR SAFE USE

1-1 Precautions on using the pipette

DANGER

- This instrument is not an explosion proof instrument. Do not use the pipette in an environment where there is a risk of explosion, or use it for explosive chemicals that may cause explosion.

- When using potentially harmful solutions, such as infectious bacteria or viruses,

radioactive substances that have a risk of exposure, or poisons, exercise extreme caution and follow all safety measures.

CAUTION

- When using a corrosive solution such as an organic solvent, confirm the chemical-proofness of the tip or pipette. When confirming material of the pipette, refer to “7-5 Parts names”.

- Do not attempt to disassemble or repair the pipette by yourself. Refer to “14. TROUBLE SHOOTING” when it appears that the pipette has a mechanical error.

1-2 Precautions on handling the battery

The MPA series use the high-density lithium-ion battery. To prevent injuries or accidents due to a leaking battery, heat generation, fire or burst, and to ensure safe use, be sure to keep the manual on hand.

DANGER

- Do not dispose of the battery in fire, do not heat it, do not disassemble or modify it.

- Do not splash water on the battery, or do not keep the battery in a location at high temperature or high humidity.

- Do not allow battery contacts to contact metal. When keeping or carrying the battery, be sure not to allow the battery to contact metal.

WARNING

- Recharge the battery with pipette installed. The pipette can be used even when the battery is being recharged.

- When recharging is unsuccessful even after charging for the specified time (Five hours up to fully recharge), stop recharging the battery.

- Use only the battery supplied with the pipette. Do not use other batteries.

CAUTION

- Do not use a leaking battery.

- Because the battery body may become hot when using the pipette continuously for a long time, take care not to get burned when handling it.

- Should you get battery fluid from a leaking battery in your eye, immediately flush with copious amounts of water and seek immediate medical attention. Should the liquid contact the clothes or skin, rinse immediately with copious amounts of water.

2. INTRODUCTION

Thank you for purchasing the MPA series electronic pipette. To ensure safe use of the product, be sure to read the manual thoroughly.

3. FEATURE

The MPA series is a high precision and performance electronic pipette that achieves operability without putting a burden on the hand. This pipette is developed for the purpose to prevent RSI (Repetitive Strain Injury) which may occur when repeatedly using a manual pipette, and does not require any special skill so anyone can easily and accurately dispense the specified volume.

□ Pipette is operated by merely pressing a key, the degree*1 of fatigue is 1/100 or

less of when using pipette manually. (*1 Calculated by operating force and movement)

□ It has an ergonomic design, fitting the hand for easy adjustments and operation. □ Using a lithium-ion battery enables usage for long periods of time.*2

（*2 Approximately 1,800 dispensing operations are possible on a full charge）

□ Impact-absorbing pads adopted to fully protect against falling. (Patent has been

applied for)

4. COMPLIANCE

Compliance with FCC Rules

Please note that this device generates, uses and can radiate radio frequency energy. This device has been tested and has been found to comply with the limits of a Class A computing device pursuant to Subpart J of Part 15 of FCC rules. These rules are designed to provide reasonable protection against interference when this device is operated in a commercial environment. If this unit is operated in a residential area, it may cause some interference and under these circumstances the user would be required to take, at his own expense, whatever measures are necessary to eliminate the interference. (FCC = Federal Communications Commission in the U.S.A.)

Compliance With EMC Directives of CE mark

This device features radio interference suppression, safety regulation and restriction of Hazardous Substances in compliance with the following Council Directives

Council directive 2004/108/EC EN61326 EMC directive Council directive 2006/95/EC EN61010-1 Low voltage directive

Council directive 2011/65/EU EN50581 Restriction of the use of certain

Hazardous Substances The CE mark is an official mandatory European marking. Please note that any electronic product must comply with local laws and regulations when sold or used anywhere outside Europe.

5. MPA FUNCTION

□ The pipette has three modes where advantages of electromotion are utilized.

(Refer to “9. FUNCTION AND HOW TO USE”)

- Standard mode (AUTO) This is for basic pipette operation. In this mode, the pipette aspirates once and

then dispenses once.

- Multiple dispensing mode (MD) This is for dispensing liquid on a microplate, etc. In this mode, the pipette aspirates

once and dispenses several times.

- Mixing mode (MIX) This is a useful operation when uniformly mixing different types of liquids. In this

mode, the pipette repeats a cycle of aspirating and dispensing.

□ User setting allows storage within the pipette of up to nine programs containing

operating mode and dispensed volume. By reading them out when necessary, operation for setting again can be omitted. Settings from the prior use are stored in memory even with the power turned off.

□ The pipette is equipped with the reverse operation suitable for dispensing a liquid

that has a tendency to remain in the tip. (Refer to “9-6 Reverse operation (Dispensing liquid that tends to remain in the tip)”)

□ The pipette also has “Dispensing correction function” (Patent applied for) with

multiple dispensing to cancel errors due to backlash. It enables the dispensing of liquids precisely without difference due to operators. (Refer to “9-9 “Dispensing correction function” for multiple dispensing”)

□ Various kinds of tips can be used. (The height of the tip ejector can be adjusted)

(Refer to “12. ADJUSTING HEIGHT OF THE TIP EJECTOR”)

□ Calibration (adjustment) of dispensed volumes is easy. (User CAL function). Even

differences in dispensed amounts due to tip differences can be corrected. (Refer to

“11-1 Volume calibration function (μL calibration function)”) (Patent applied for)

□ Dispensing by weight is also available. Refer to “11-3 Dispensing in a unit of

weight (in mg unit)”) (Patent applied for)

6. PACKING CONTENTS AND NAME OF ITEMS

Confirm that the following contents are all included.

○ Electronic pipette MPA-10 / 20 / 200 / 1200 (Any one among them) ○ Accessories

(1) Battery (1 pc) (2) The AC adapter (Combined use for charging) (Switching with AC100V to 240V)

Selectable power plug (A / BF / C / S type)

* AC adapter has the A type AC adapter plug attached.

Use AC adapter plug for AC adapter to match local outlet.

Note Please confirm that the AC adapter type is correct for your local

voltage and receptacle type.

(3) Power cable (USB cable: Mini B plug - A plug) (4) Instruction manual (This document) (5) Quick operation guide (6) Performance certification (Pipette Accuracy Test Result) (7) Pipette tip (3 pcs)

(For 10/20μL (1 pc), for 200μL (1 pc), for 1200μL (1 pc))

(8) Name sticker (The pipette has a location in the battery compartment for

affixing the name sticker.

The pipette has a protective film on the display. Remove it if necessary.

Pipette

(1) Battery

(7) Pipette tip

(Sample, each 1 pc)

For 10/20μL (For MPA-10/20)

For 200μL (For MPA-200)

For 1200μL (For MPA-1200)

(2) AC adapter *

type

BF type

C type

Selectable power plug

(8) Name sticker

(3) Power cable

S type

(4) Instruction manual (5) Quick operation guide (6) Performance certification

Should the pipette arrive damaged or an accessory be missing, contact the nearest A&D dealer.

Note The accessories included with this product may be changed without notice.

7. PREPARATION BEFORE USE

7-1 Installing the battery

1. Remove the battery cover (2) by sliding it upward while pressing and holding the battery cover release button (1).

2. Connect the terminal of the battery’s cable, as shown in the figure below, to the connector for the battery in the bottom of the battery compartment. When connecting the terminal, be sure it is connected in the proper direction.

3. Install the battery so that the battery cable is in the cable guide.

4. Attach the battery cover on the pipette by sliding it downward from the upside.

Battery cover release button

(2)

Battery cover

(1)

Red

Expanded

Black

Battery connector

1. Open the battery cover. 2. Connect the battery connector.

Cable

3. Install the battery. 4. Attach the battery cover.

Note

When connecting the battery to the pipette, all illuminations on the

display illuminate and the pipette built-in piston automatically goes to the

Cable guide

initial default position. If a key is pressed, the pipette goes into the operating mode.

7-2 Recharging the battery

When purchasing the instrument, the battery does not have a full charge. For initial use, first charge the battery fully. Recharge the battery with the battery installed in the pipette. Pipette use is available during recharging.

Recharging

1. Remove the power connector cover from the pipette.

2. Connect the power cable connected to the AC adapter to the power connector on the pipette.

3. Connect the AC adapter plug to the outlet. The battery mark will be displayed on LCD of the pipette, and it will blink during recharging. If connecting the power cable to the outlet before setting the battery in the pipette, please note that the recharging will not start. When the recharging is complete, the battery mark changes from blinking to a steady illumination, then the recharging completes automatically. (About five hours)

NOTE: After recharging the battery completely, remove the power cable from the pipette. Firmly attach the power connector cover by pushing it onto the pipette.

Power connector cover

(1)

(2)

Power connector

Power cable （Mini USB B type）

(3)

7-3 Exchange selectable power plug

The A-Type power supply plug is originally attached to the AC adapter. Please change the power supply plug to the one that suits your location.

Exchange method

1. As shown, remove the power supply plug from the AC adapter.

2. As shown, put on the power supply plug that you want to use.

AC adapter

1. Remove the power supply plug.

A-Type

BF-Type

2. Put on an appropriate power supply plug.

C-Type S-Type

7-4 Before operating the pipette

Holding the pipette

- Hold the pipette so that the finger hook is between a forefinger and middle finger.

- To aspirate or dispense a liquid, operate the Operation key or the Up key below the display. Operate the Operation key using the forefinger, as shown in the figure below.

- Operate the eject button by using the thumb to remove the tip.

Finger hook

Operation key

Eject button

Operating mode and standby mode

- The pipette goes into standby mode to reduce the battery wasting to minimize battery use if the pipette is idle for 10 minutes.

- When off, the pipette can be returned to the operation mode by pressing any key, and information such as setting volume will be displayed on the display (Refer to example of the display), enabling dispensing. At this time, the pipette automatically positions the built-in piston to the initial default position.

- While in the operating mode, holding down the Operation key for approx. five

seconds will turn the pipette off.

Example of display

Operation

Turning the power off manually

(The display is example.)

Operation key

Press and hold the Operation key on the pipette for at least five seconds until OFF is displayed on the display .

Buzzer sounds (Three times), and the pipette turns the power off (OFF).
