PLE0085I
HomePlug 1.0 Turbo Ethernet Adapter – Inlet type
- 1 Power Line Port
- 1 Ethernet Port
Description
The PLE0085I provides convenient powerline access to
office/family users by sharing a simple AC power line
network. HomePlug 1.0 Turbo (85Mbps), compatible with
1.0 (14Mbps), enables you to connect one PC Ethernet por
to another PC’s at other end of power line, and not limite
by the wall or layer that block RF wireless communication.
Features
1 Power Line Port
1 Ethernet Port
Full Compatibility tested
Specification
Main Chipset Intellon INT5500 + RTL8201
Standard support HomePlug 1.0 (14Mbps) & 1.0 Turbo (85Mbps)
Interface One port via power cord, One Ethernet port
LED Power: Yellow-Green
Link/Act: Yellow-Green (Powerline)
Ethernet: Yellow-Green
Power AC 100~240V/ 50~60Hz/ 0.5A (120cm AC cord)
Dimension (W x D x L) 103mm x 71.4mm x 27.8 mm.
LED Power: Yellow-Green
On: Power On
Off: Power Off
Status-
Link/Act: Yellow-Green (Powerline)
Link: On
Act: Blink
Ethernet: Yellow-Green
Link: On
Act: Blink
Operating Operating Temperature: 0~40ºC (32~104ºF)
Relative Humidity: 10%~90% non-condensing
Storage Temperature: -25~75ºC (-13~167ºF)
Relevant Humidity: 0%~95% non-condensing
Altitude: Sea level to 40,000 feet
CERTIFICATIONS FCC Part 15, Part B, Class B , CE Class B, BSMI
ICE Class B (option)
UL/cUL (option)
CB/VDE (option)
