ABIT AN52, AN52S User Manual

“

AN52S
AN52

Hardware Setup

Motherboard
AMD Socket AM2

User’s Manual

 NVIDIA NF520 Single Chip

 2000MT/s HT

 Dual Channel DDR2 800

 Gigabit LAN

BIOS Setup

Driver & Utility Multilingual QIG Appendix

 SATA 3Gb/s RAID

 USB 2.0

 7.1-Channel HD Audio

 abit SoftMenu™ Technology

About this Manual:

This user’s manual contains all the information you may
need for setting up this motherboard. To read the user’s
manual of PDF format (readable by Adobe Reader), place
the “Driver & Utility CD” into the CD-ROM drive in your
system. The auto-run screen will appear, click the

Manual” tab to enter its submenu. If not, browse the
root directory of the CD-ROM via the File Manager, and
double click the “AUTORUN” file.

 abit Silent OTES™ Technology

(AN52S)

 External CMOS Clearing

Switch (AN52S)

 Vista HW Ready

j

g

g

g

g

g

AN52S/AN52

User’s Manual
English + Multilingual QIG

P/N: 4310-0000-87
Rev. 2.00, May 2007

Copyright and Warranty Notice

The information in this document is sub
commitment on part of the vendor, who assumes no liability or responsibility for any errors that
may appear in this manual.

No warranty or representation, either expressed or implied, is made with respect to the quality,
accuracy or fitness for any particular part of this document. In no event shall the manufacturer be
liable for direct, indirect, special, incidental or consequential dama
error in this manual or product.

Product names appearing in this manual are for identification purpose only and trademarks and
product names or brand names appearin
owners.

This document contains materials protected under International Copyri
No part of this manual may be reproduced, transmitted or transcribed without the expressed
written permission of the manufacturer and authors of this manual.

If you do not properly set the motherboard settin
fail, we cannot guarantee any responsibility.

ect to change without notice and does not represent a

es arising from any defect or

in this document are the property of their respective

ht Laws. All rights reserved.

s, causing the motherboard to malfunction or

The Following Information is Only for EU-member States:

Directive 2002/96/EC on Waste Electrical and Electronic Equipment
(WEEE): The use of the symbol indicates that this product may not be

treated as household waste. By Ensuring this product is disposed of correctly,
you will help prevent potential ne
and human health, which could otherwise be cause by inappropriate waste
handling of this product. For more detailed information about recycling of this
product, please contact your local city office, your household waste disposal
service or the shop where you purchased the product.

ative consequences for the environment

ii AN52S/AN52

Contents

1. Hardware Setup ............................................................... 1-1

1.1 Specifications............................................................................... 1-1

1.2 Motherboard Layout ..................................................................... 1-2

1.2.1 AN52S ................................................................................1-2

1.2.2 AN52 .................................................................................. 1-3

1.3 Choosing a Computer Chassis ....................................................... 1-4

1.4 Installing Motherboard .................................................................1-4

1.5 Checking Jumper Settings............................................................. 1-5

1.5.1 CMOS Memory Clearing Header and Backup Battery .............. 1-5

1.6 Connecting Chassis Components ................................................... 1-7

1.6.1 ATX Power Connectors......................................................... 1-7

1.6.2 Front Panel Switches & Indicators Headers ........................... 1-8

1.6.3 FAN Power Connectors ........................................................ 1-9

1.7 Installing Hardware.................................................................... 1-10

1.7.1 CPU Socket AM2................................................................ 1-10

1.7.2 DDR2 Memory Slots........................................................... 1-12

1.8 Connecting Peripheral Devices .................................................... 1-13

1.8.1 Floppy and IDE Disk Drive Connectors ................................ 1-13

1.8.2 Serial ATA Connectors ....................................................... 1-14

1.8.3 Additional USB 2.0 Port Headers......................................... 1-14

1.8.4 Internal Audio Connectors.................................................. 1-15

1.8.5 Front Panel Audio Connection Header ................................. 1-15

1.8.6 PCI and PCI Express X16, X1 Slots ..................................... 1-17

1.9 Onboard Indicators .................................................................... 1-18

1.9.1 Power Source Indicators .................................................... 1-18

1.10 Connecting Rear Panel I/O Devices ........................................... 1-19

Hardware Setup

BIOS Setup

Driver & Utility Multilingual QIG Appendix

2. BIOS Setup....................................................................... 2-1

2.1 SoftMenu Setup ...........................................................................2-2

2.2 Standard CMOS Features.............................................................. 2-4

2.3 Advanced BIOS Features .............................................................. 2-7

2.4 Advanced Chipset Features........................................................... 2-9

2.5 Integrated Peripherals................................................................ 2-10

2.6 Power Management Setup .......................................................... 2-14

2.7 PnP/PCI Configurations .............................................................. 2-16

2.8 PC Health Status ........................................................................ 2-17

2.9 Load Fail-Safe Defaults............................................................... 2-19

2.10 Load Optimized Defaults........................................................... 2-19

2.11 Set Password ........................................................................... 2-19

2.12 Save & Exit Setup..................................................................... 2-19

2.13 Exit Without Saving .................................................................. 2-19

AN52S/AN52 iii

3. Driver & Utility ................................................................. 3-1

3.1 CD-ROM AUTORUN ...................................................................... 3-1

3.2 nVidia nForce Chipset Driver ......................................................... 3-2

3.3 Realtek HD Audio Driver ............................................................... 3-2

3.4 Cool’n’Quiet Driver ....................................................................... 3-4

3.5 USB 2.0 Driver .............................................................................3-4

3.6 abitEQ (The Hardware Doctor Utility) ............................................3-5

3.7 FlashMenu (BIOS Update Utility) ...................................................3-6

3.8 SATA RAID Driver (for Windows Vista) .......................................... 3-7

3.9 SATA RAID Driver (for Windows XP, 2003, or 2000)....................... 3-7

4. Multilingual Quick Installation Guide .............................. 4-1

4.1 Français//Guide d'Installation Rapide............................................. 4-1

4.2 Deutsch//Kurze Installationsanleitung............................................ 4-2

4.3 Italiano//Guida all’installazione rapida ........................................... 4-3

4.4 Español//Guía rápida de instalación............................................... 4-4

4.5 Português//Guia de instalação rápida ............................................ 4-5

4.6 Русский//Краткое руководство по установке .............................. 4-6

4.7 Eesti//Kiirpaigaldusjuhend ............................................................ 4-7

4.8 Latviski//Ātrās instalēšanas instrukcija........................................... 4-8

4.9 Lietuvių//Trumpas instaliavimo vadovas ........................................ 4-9

4.10 Polski//Instrukcja szybkiej instalacji........................................... 4-10

4.11 Magyar//Gyorstelepítési útmutató.............................................. 4-11

4.12 Türkçe//Hızlı Kurulum Kılavuzu.................................................. 4-12

4.13 اللغة العربية//دليل التركيب السريع....................... 4-13

4.14 فارسی// راﻩنمای نصب سریع............................................... 4-14

4.15 日本語//クイックインストールガイド ...................................... 4-15

4.16 한국어//빠른 설치 가이드 ....................................................... 4-16

4.17 Bahasa Malaysia//Panduan Pemasangan Ringkas ....................... 4-17

4.18 ไทย//คู่มือการติดตั้งอย่างย่อ ........................................................ 4-18

4.19 繁體中文................................................................................. 4-19

4.19.1 規格............................................................................... 4-19

4.19.2 快速安裝略說.................................................................. 4-20

4.20 简体中文................................................................................. 4-21

4.20.1 规格............................................................................... 4-21

4.20.2 快速安装略说.................................................................. 4-22

5. Appendix .......................................................................... 5-1

5.1 Troubleshooting (How to Get Technical Support?).......................... 5-1

5.1.1 Q & A .................................................................................5-1

5.1.2 Technical Support Form....................................................... 5-4

iv AN52S/AN52

5.1.3 Contact Information............................................................. 5-5

1. Hardware Setup

1.1 Specifications

Hardware Setup

CPU

• Supports Socket AM2 940 Processor
with 2000MT/s system bus using Hyper
Transport™ Technology

• Supports AMD CPU Cool ‘n’ Quiet
Technology

Chipset

• NVIDIA NF520 Single Chip

Memory

• 4x 240-pin DIMM slots support
maximum memory capacity up to 8GB

• Supports Dual Channel DDR2 800
Un-buffered ECC/Non-ECC memory

LAN

• Onboard Gigabit LAN

Audio

• Onboard 7.1-Channel HD Audio CODEC

• Supports auto Jack Sensing and Jack

Retasking functions

Serial ATA

• 4x SATA 3Gb/s supports SATA RAID 0,
1, 0+1, 5

Expansion Slots

• 1x PCI-E X16 slot

• 2x PCI-E X1 slots

• 3x PCI slots

※ Specifications and information contained herein are subject to change without

notice.

Internal I/O Connectors

• 1x Floppy port

• 1x Ultra ATA 133 IDE connector

• 4x SATA 3Gb/s connectors

• 3x USB 2.0 headers

• 1x FP-Audio header

• 1x CD-In connector

Rear Panel I/O

• 1x PS/2 Keyboard connector

• 1x PS/2 Mouse connector

• 1x COM port

• 1x External CMOS Clearing Switch

AN52S only)

• 1x 7.1-Channel Audio connector

• 4x USB 2.0 connectors

• 1x RJ-45 LAN connector

(For AN52S only)

abit Engineered

• abit Softmenu™ Technology

• abit Silent OTES

AN52S only)

• External CMOS Clearing Switch

AN52S only)

™

Technology

RoHS

• 100% Lead-free process and RoHS
compliant

Miscellaneous

• ATX form factor (305mm x 245mm)

• Vista HW Ready

(For

(For

(For

AN52S/AN52 1-1

1.2 Motherboard Layout

1.2.1 AN52S

1-2 AN52S/AN52

1.2.2 AN52

Hardware Setup

※ The motherboard and its component layouts illustrated in the following chapter

of this manual were mainly based on model “AN52S”, unless specifically stated.

AN52S/AN52 1-3

1.3 Choosing a Computer Chassis

• Choose a chassis big enough to install this motherboard.

• As some features for this motherboard are implemented by cabling connectors on the

motherboard to indicators and switches or buttons on the chassis, make sure your chassis
supports all the features required.

• If there is a possibility of adopting some more hard drives, make sure your chassis has
sufficient power and space for them.

• Most chassis have alternatives for I/O shield located at the rear panel. Make sure the I/O
shield of the chassis matches the I/O port configuration of this motherboard. You can find
an I/O shield specifically designed for this motherboard in its package.

1.4 Installing Motherboard

Most computer chassis have a base with many
mounting holes to allow the motherboard to be
securely attached, and at the same time, prevent
the system from short circuits. There are two
ways to attach the motherboard to the chassis
base: (1) with studs, or (2) with spacers.

Basically, the best way to attach the board is
with studs. Only if you are unable to do this
should you attach the board with spacers. Line up the holes on the board with the mounting
holes on the chassis. If the holes line up and there are screw holes, you can attach the board
with studs. If the holes line up and there are only slots, you can only attach with spacers. Take
the tip of the spacers and insert them into the slots. After doing this to all the slots, you can
slide the board into position aligned with slots. After the board has been positioned, check to
make sure everything is OK before putting the chassis back on.

※ Always power off the computer and unplug the AC power cord before adding or

removing any peripheral or component. Failing to so may cause severe damage
to your motherboard and/or peripherals. Plug in the AC power cord only after
you have carefully checked everything.

To install this motherboard:

1. Locate all the screw holes on the
motherboard and the chassis base.

2. Place all the studs or spacers needed on
the chassis base and have them tightened.

3. Face the motherboard’s I/O ports toward
the chassis’s rear panel.

4. Line up all the motherboard’s screw holes
with those studs or spacers on the chassis.

5. Install the motherboard with screws and
have them tightened.

※ To prevent shorting the PCB circuit,

please REMOVE the metal studs or
spacers if they are already fastened
on the chassis base and are without
mounting-holes on the motherboard
to align with.

Face the chassis’s rear panel.

1-4 AN52S/AN52

1.5 Checking Jumper Settings

• For a 2-pin jumper, plug the
jumper cap on both pins will
make it CLOSE (SHORT).
Remove the jumper cap, or
plug it on either pin
(reserved for future use) will
leave it at OPEN position.

• For 3-pin jumper, pin 1~2 or pin 2~3 can be
shorted by plugging the jumper cap in.

SHORT OPEN

1.5.1 CMOS Memory Clearing Header and Backup Battery

The time to clear the CMOS memory occurs when (a)
the CMOS data becomes corrupted, (b) you forgot the
supervisor or user password preset in the BIOS menu,
(c) you are unable to boot-up the system because the
CPU ratio/clock was incorrectly set in the BIOS menu,
or (d) whenever there is modification on the CPU or
memory modules.

This header uses a jumper cap to clear the CMOS
memory and have it reconfigured to the default values
stored in BIOS.

• Pins 1 and 2 shorted
(Default): Normal

operation.

• Pins 2 and 3 shorted:
Clear CMOS memory.

To clear the CMOS memory and load in the default values:

1. Power off the system.

2. Set pin 2 and pin 3 shorted by the jumper cap. Wait for a few seconds. Set the jumper
cap back to its default settings --- pin 1 and pin 2 shorted.

3. Power on the system.

4. For incorrect CPU ratio/clock settings in the BIOS, press <Del> key to enter the BIOS
setup menu right after powering on system.

5. Set the CPU operating speed back to its default or an appropriate value.

6. Save and exit the BIOS setup menu.

※ Another easy way to clear the CMOS memory can be done by switching the

“EZ-CCMOS1”, see the section of “Connecting Rear Panel I/O Devices” in this
manual for detail.

※ Please do shut down the system power before clearing CMOS memory.

(For AN52S only)

Pin 1~2 SHORT Pin 2~3 SHORT

OPEN

Hardware Setup

AN52S/AN52 1-5

CMOS Backup Battery:

An onboard battery saves the CMOS memory to keep the BIOS information stays on even after
disconnected your system with power source. Nevertheless, this backup battery exhausts after
some five years. Once the error message like “CMOS BATTERY HAS FAILED” or “CMOS
checksum error” displays on monitor, this backup battery is no longer functional and has to
be renewed.

To renew the backup battery:

1. Power off the system and disconnect with AC power source.

2. Remove the exhausted battery.

3. Insert a new CR2032 or equivalent battery. Pay attention to its polarity. The “+” side is its
positive polarity.

4. Connect AC power source and power on the system.

5. Enter the BIOS setup menu. Reconfigure the setup parameters if necessary.

CAUTION:

※ Danger of explosion may arise if the battery is incorrectly renewed.

※ Renew only with the same or equivalent type recommended by the battery

manufacturer.

※ Dispose of used batteries according to the battery manufacturer’s instructions.

1-6 AN52S/AN52

1.6 Connecting Chassis Components

1.6.1 ATX Power Connectors

For a fully configured system, we recommend that
you use a power supply of ATX12V 2.0 (or newer)
specification compliant and of providing minimum
400W power output capability.

※ The following motherboard photos are

served for DEMO only, and may not be
the same type or model as the one

[ATXPWR1]: 24-pin power connector

You may connect either a 20-pin (ATX12V

1.3) or 24-pin (ATX12V 2.0) power source.

However, it is recommended to connect the
24-pin ATX12V power source to meet the
240VA protection limits.

described in this user’s manual.

Plugged from a 24-pin
ATX12V power.

Hardware Setup

Plugged from a 20-pin
ATX12V power.

[ATX12V1]: 8-pin power connector

This connector supplies +12V power to CPU.

You may connect either a 4-pin ATX12V or
an 8-pin EPS12V power source. However, it
is recommended to connect the 8-pin
EPS12V power source to meet the 240VA
protection limits.

AN52S/AN52 1-7

Plugged from a 4-pin
ATX12V power.

Plugged from an 8-pin
EPS12V power.

1.6.2 Front Panel Switches & Indicators Headers

This header is used for connecting switches and LED indicators on the chassis front panel.

Watch the power LED pin position and orientation. The mark “+” align to the pin in the figure
below stands for positive polarity for the LED connection. Please pay attention when connecting
these headers. A wrong orientation will only result in the LED not lighting, but a wrong
connection of the switches could cause system malfunction.

• HLED (Pin 1, 3):

Connects to the HDD LED cable of chassis front panel.

• RST (Pin 5, 7):

Connects to the Reset Switch cable of chassis front panel.

• SPKR (Pin 13, 15, 17, 19):

Connects to the System Speaker cable of chassis.

• SLED (Pin 2, 4):

Connects to the Suspend LED cable (if there is one) of chassis front panel.

• PWR (Pin 6, 8):

Connects to the Power Switch cable of chassis front panel.

• PLED (Pin 16, 18, 20):

Connects to the Power LED cable of chassis front panel.

1-8 AN52S/AN52

1.6.3 FAN Power Connectors

These connectors each provide power to the cooling fans installed in your system.

• CPUFAN1: CPU Fan Power Connector

• SYSFAN1: System Fan Power Connector

• AUXFAN1~2: Auxiliary Fan Power Connectors

※ These fan connectors are not jumpers. DO NOT place jumper caps on these

connectors.

Hardware Setup

AN52S/AN52 1-9

1.7 Installing Hardware

※ DO NOT scratch the motherboard when installing hardware. An accidentally

scratch of a tiny surface-mount component may seriously damage the
motherboard.

1.7.1 CPU Socket AM2

※ DO NOT touch or bend the delicate pins on the CPU whenever you are holding it.

The installation procedures vary with different types of CPU fan-and-heatsink assembly. The
one shown here is served for DEMO only. For detailed information on how to install the one
you bought, refer to its installation guidelines.

1. Pull out the socket lever away from the

socket and fully lift it up over 90-degree
angle.

Locate and align the triangle mark with
both the CPU and the socket body.
Vertically place the CPU with its pin-side
down into the socket.

Be careful to insert the CPU into the
socket. The CPU only fits in one
orientation with the socket. DO NOT
force the CPU into the socket.

2. After placing the CPU into position, push

the socket lever down into its locked
position to secure the CPU. The lever
clicks when it’s locked into position.

3. The heatsink for CPU may have thermal

interface material attached to its
bottom. If not, applying a few squeeze
of thermal paste to the CPU die will help
to increase the contact.

1-10 AN52S/AN52

4. Place the heatsink and fan assembly

onto the retention frame. Match the
heatsink clip with the socket
mounting-lug. Hook the spring clip to
the mounting-lug.

5. On the other side, push the retention

clip straight down to lock into the plastic
lug on the retention frame.

6. Connect the CPU cooling fan power

cable to the CPUFAN1 connector on this
motherboard.

※ The “CPUFAN1” connector can be

connected either with a 3-Pin or
4-Pin CPU cooling fan. For a 3-Pin
connection, there will be no speed
control available in the BIOS setup
menu; the CPU fan will run at full
speed.

Also, please watch out for the
orientation when inserting 3-Pin
plug into this 4-Pin fan connector.

※ The motherboard in this illustration is served for DEMO only, may not be the

same type or model as the one described in this user’s manual.

※ A higher fan speed will be helpful for better airflow and heat-dissipation.

Nevertheless, stay alert to not touch any heatsink since a high temperature
generated by the working system is still possible.

Hardware Setup

AN52S/AN52 1-11

1.7.2 DDR2 Memory Slots

To reach the performance of Dual Channel DDR2, the following rules must be obeyed:

• For a 2-DIMM dual-channel installation:
Populate DIMM modules of the same type and size on slots [DIMM1]+[DIMM2], or slots
[DIMM3]+[DIMM4].

• For a 4-DIMM dual-channel installation:
Populate 2 DIMM modules of the same type and size on slots [DIMM1]+[DIMM2], and
another 2 DIMM modules of the same type and size on slots [DIMM3]+[DIMM4].

※ [DIMM1] and [DIMM2] slots are made of the same color.

[DIMM3] and [DIMM4] are made of another same color.

Usually there is no hardware or BIOS setup requires after adding or removing memory modules,
but you will have to clear the CMOS memory first if any memory module related problem
occurs.

To install system memory:

1. Power off the computer and unplug the
AC power cord before installing or
removing memory modules.

2. Locate the DIMM slot on the board.

3. Hold two edges of the DIMM module
carefully, keep away from touching its
connectors.

4. Align the notch key on the module with the rib on the slot.

5. Firmly press the module into the slots until the ejector tabs at both sides of the slot
automatically snap into the mounting notch. Do not force the DIMM module in with extra
force as the DIMM module only fits in one direction.

6. To remove the DIMM modules, push the two ejector tabs on the slot outward
simultaneously, and then pull out the DIMM module.

※ Static electricity can damage the electronic components of the computer or

optional boards. Before starting these procedures, ensure that you are
discharged of static electricity by touching a grounded metal object briefly.

1-12 AN52S/AN52

g

1.8 Connecting Peripheral Devices

1.8.1 Floppy and IDE Disk Drive Connectors

The FDC1 connector connects up to two floppy drives with a 34-wire, 2-connector floppy cable.
Connect the single end at the longer length of ribbon cable to the FDC1 on the board, the two
connectors on the other end to the floppy disk drives connector. Generally you need only one
floppy disk drive in your system.

※ The red line on the ribbon cable must be aligned with pin-1 on both the FDC1

port and the floppy connector.

Each of the IDE port connects up to two IDE drives
at Ultra ATA/100 mode by one 40-pin, 80-conductor,
and 3-connector Ultra ATA/66 ribbon cables.

Connect the sin
length of ribbon cable to the IDE port of this board,
the other two ends (gray and black connector) at the
shorter length of the ribbon cable to the connectors
of your hard drives.

※ Make sure to configure the “Master” and “Slave” relation before connecting

two drives by one single ribbon cable. The red line on the ribbon cable must be
aligned with pin-1 on both the IDE port and the hard-drive connector.

le end (blue connector) at the longer

Hardware Setup

AN52S/AN52 1-13

1.8.2 Serial ATA Connectors

Each SATA connector serves as one single channel to connect one SATA device by SATA cable.

To connect SATA device:

1. Attach either end of the signal cable
to the SATA connector on
motherboard. Attach the other end to
the SATA device.

2. Attach the SATA power cable to the
SATA device and connect the other
end from the power supply.

※ The motherboard in this photo is served for DEMO only, and may not be the

same type or model as the one described in this user’s manual.

1.8.3 Additional USB 2.0 Port Headers

Each header supports 2x additional USB 2.0 ports by connecting bracket or cable to the rear I/O
panel or the front-mounted USB ports of your chassis.

Pin Pin Assignment Pin Pin Assignment

1 VCC 2 VCC
3 Data0 - 4 Data1 ­5 Data0 + 6 Data1 +
7 Ground 8 Ground

10 NC

※ Make sure the connecting cable bears the same pin assignment.

1-14 AN52S/AN52

1.8.4 Internal Audio Connectors

This connector connects to the audio output of internal CD-ROM drive or add-on card.

1.8.5 Front Panel Audio Connection Header

This header provides the front panel connection for HD (High Definition)
Audio, yet for AC’97 Audio CODEC connection, you must carefully check the
pin assignment before connecting from the front panel module. An incorrect
connection may cause malfunction or even damage the motherboard.

※ Please do not connect the “Ground” cable or “USB VCC” cable

from the front panel module to the Pin 4 “AVCC” of this
header.

Hardware Setup

Pin Assignment

Pin

(HD AUDIO)

1 MIC2 L 1 MIC In

2 AGND 2 GND

3 MIC2 R 3 MIC Power

4 AVCC 4NC

5 FRO-R 5 Line Out (R)

6 MIC2_JD 6 NC

7F_IO_SEN 7 NC

9 FRO-L 9 Line Out (L)

10 LINE2_JD 10 NC

AN52S/AN52 1-15

Pin Assignment

Pin

(AC’97 AUDIO)

Driver Configuration for AC’97 audio connection:

The audio driver is originally configured to support HD Audio. For AC’97 audio connection, you
may:

1. Right-click the “Realtek HD
Audio Manager” icon
system tray.

2. Click “Audio I/O” tab, and then
click “Connector Settings”.

in

3. Click “Disabled front panel
jack detection”, and then click
“OK” to confirm.

1-16 AN52S/AN52

1.8.6 PCI and PCI Express X16, X1 Slots

Install PCI Express X16 graphics card into slot “PCIEXP1”.

Install PCI Express X1 cards into slots “PCIE1” and/or “PCIE2”.

Install PCI cards into slots “PCI1”, “PCI2”, and/or “PCI3”.

Hardware Setup

AN52S/AN52 1-17

1.9 Onboard Indicators

1.9.1 Power Source Indicators

• 5VSB: This LED lights up when the power supply is connected with power source.

• VCC: This LED lights up when the system power is on.

1-18 AN52S/AN52

1.10 Connecting Rear Panel I/O Devices

The rear I/O part of this motherboard provides the following I/O ports:

AN52S

AN52

Hardware Setup

• Mouse: Connects to PS/2 mouse.

• Keyboard: Connects to PS/2 keyboard.

• COM1: Connects to external modem, mouse or other devices that support this

communication protocol.

• EZ-CCMOS1: This switch enables clearing the CMOS memory without uncovering the
system chassis.

(For AN52S only)

(For AN52S only)

To clear the CMOS memory by EZ-CCMOS1 switch:
Step 1: Power off the system.
Step 2: Turn left this switch to the

“Clear CMOS” position.
Step 3: Turn right this switch to its

default “Normal” position. The default
CMOS memory is now reloaded.

※ Make sure to set this switch to its

“Normal” position before turning on
the AC power. Otherwise, the DC
power won’t be able to turn on.

※ Also make sure to shut down the system power before clearing CMOS memory.

Note that by turning left this switch to the “Clear CMOS” position under system
power-on condition will force shutting down the system, and by turning right
this switch to the “Normal” position will then force turning on the system.

AN52S/AN52 1-19

• AUDIO1:
Cen./Sub. (Center / Subwoofer): Connects to the center and subwoofer channel.
R.L./R.R. (Rear Left / Rear Right): Connects to the rear left and rear right channel.
S.L./S.R. (Surround Left / Surround Right): Connects to the surround left and

surround right channel.

Line-In: Connects to the line out from external audio sources.
Line-Out: Connects to the front left and front right channel.
Mic-In: Connects to the plug from external microphone.

• LAN1: Connects to Local Area Network.

• USB1/USB2: Connects to USB devices such as scanner, digital speakers, monitor, mouse,

keyboard, hub, digital camera, joystick etc.

1-20 AN52S/AN52

2. BIOS Setup

This motherboard provides a programmable EEPROM so that you can update the BIOS utility.
The BIOS (Basic Input/Output System) is a program that deals with the basic level of
communication between processor and peripherals. Use the BIOS Setup program only when
installing motherboard, reconfiguring system, or prompted to “Run Setup”. This chapter
explains the Setup Utility of BIOS utility.

After powering up the system, the BIOS message appears on the screen, the memory count
begins, and then the following message appears on the screen:

PRESS DEL TO ENTER SETUP

If this message disappears before you respond, restart the system by pressing <Ctrl> + <Alt>
+ <Del> keys, or by pressing the Reset button on the computer chassis. Only when these two
methods fail should you restart the system by powering it off and then back on.

After pressing <Del> key, the main menu screen appears.

► SoftMenu Setup ► PC Health Status

► Standard CMOS Features Load Fail-Safe Defaults

► Advanced BIOS Features Load Optimized Defaults

► Advanced Chipset Features Set Password

► Integrated Peripherals Save & Exit Setup

► Power Management Setup Exit Without Saving

► PnP/PCI Configurations

Esc: Quit
F10: Save & Exit Setup

Phoenix – AwardBIOS CMOS Setup Utility

: Select Item



(NF-MCP65-6A61LA1AC-00)

Change CPU’s Clock & Voltage

BIOS Setup

※ In order to increase system stability and performance, our engineering staff is

constantly improving the BIOS menu. The BIOS setup screens and descriptions
illustrated in this manual are for your reference only, and may not completely
match with what you see on your screen.

AN52S/AN52 2-1

2.1 SoftMenu Setup

This option configures the CPU’s clock and voltage.

AMD Athlon(tm) 64 X2 Dual Core Processor 4800+ Item Help
Frequency : 2400MHz

CPU Operating Speed Default

- CPU External Clock(MHz) 200MHz

x

- PCIe Clock 100MHz

x
x - Multiplier Factor

Voltages Control Default

- CPU Core Voltage 1.150 V

x

- DDR2 Voltage 1.85 V

x

- Hyper Transport Voltage 1.20 V

x

- NB Voltage 1.20 V

x

- DDR2 Reference Voltage 0.0%

x

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help



F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

Brand Name

This item displays the CPU model name installed on this motherboard.

Frequency

This item displays the processor speed of the CPU installed on this motherboard.

Phoenix – AwardBIOS CMOS Setup Utility

SoftMenu Setup

x12

CPU Operating Speed

This item displays the CPU operating speed according to the type and speed of your CPU. You
can also select the [User Define] option to enter the manual option.

User Define:

※ The wrong settings of the multiplier and external clock in certain

circumstances may cause CPU damage. Setting the working frequency higher
than the PCI chipset or processor specs, may cause abnormal memory module
functioning, system hangs, hard disk drive data lose, abnormal functioning of
the VGA card, or abnormal functioning with other add-on cards. Using
non-specification settings for your CPU is not the intention of this explanation.
These should be used for engineering testing, not for normal applications.

※ There will be no guaranty for the settings beyond specification. Any damage of

any component on this motherboard or peripherals resulting therein is not our
responsibility.

- CPU External Clock(MHz)

This item selects the external clock frequency. Due to the specification limit of the CPU you
installed, the speed you set over its standard bus speed is supported, but not guaranteed.

- Multiplier Factor

This item displays the multiplier factor for the CPU you installed.

2-2 AN52S/AN52

- PCIe Clock

This item selects the clock frequency for PCI Express slot.

Voltages Control

This option allows you to switch between the default and user-defined voltages. Leave this
setting at default unless the current voltage setting cannot be detected or is not correct. The
option “User Define” enables you to select the following voltages manually.

- CPU Core Voltage

- DDR2 Voltage

- Hyper Transport Voltage

- NB Voltage

- DDR2 Reference Voltage

BIOS Setup

AN52S/AN52 2-3

2.2 Standard CMOS Features

Phoenix – AwardBIOS CMOS Setup Utility

Date (mm:dd:yy) Tue, May 15 2007 Item Help
Time (hh:mm:ss) 12 : 34 : 56

► IDE Channel 1 Master None
► IDE Channel 1 Slave None
► SATA Channel 1 None
► SATA Channel 2 None
► SATA Channel 3 None
► SATA Channel 4 None

Drive A 1.44M, 3.5 in.
Floppy 3 Mode Support Disabled
Halt On All, But Keyboard

Base Memory 640K
Extended Memory 1047552K
Total Memory 1047552K

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help



F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

Date (mm:dd:yy)

This item sets the date you specify (usually the current date) in the format of [Month], [Date],
and [Year].

Time (hh:mm:ss)

This item sets the time you specify (usually the current time) in the format of [Hour], [Minute],
and [Second].

Standard CMOS Features

 IDE Channel 1 Master/Slave, SATA Channel 1~4

Click <Enter> key to enter its submenu:

Phoenix – AwardBIOS CMOS Setup Utility

IDE HDD Auto-Detection Press Enter Item Help

IDE Channel 1 Master Auto
Access Mode Auto

Capacity 0 MB

Cylinder 0
Head 0
Precomp 0
Landing Zone 0
Sector 0

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help



F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

2-4 AN52S/AN52

IDE Channel 1 Master

IDE HDD Auto-Detection

This item allows you to detect the parameters of IDE drives by pressing <Enter> key. The
parameters will be shown on the screen automatically.

IDE Channel 1 Master/Slave, SATA Channel 1~4

When set to [Auto], the BIOS will automatically check what kind of IDE or SATA hard drive you
are using. If you want to define your own drive yourself, set it to [Manual] and make sure you
fully understand the meaning of the parameters. Please refer to the instruction manual provided
by the device’s manufacturer to get the setting right.

Access Mode

This item selects the mode to access your IDE or SATA devices. Leave this item at its default
[Auto] setting to detect the access mode of your HDD automatically.

Capacity

This item displays the approximate capacity of the disk drive. Usually the size is slightly greater
than the size of a formatted disk given by a disk-checking program.

Cylinder

This item configures the numbers of cylinders.

Head

This item configures the numbers of read/write heads.

Precomp

This item displays the number of cylinders at which to change the write timing.

Landing Zone

This item displays the number of cylinders specified as the landing zone for the read/write
heads.

Sector

This item configures the numbers of sectors per track.

 Back to Standard CMOS Features Setup Menu

Drive A

This item sets the type of floppy drive installed.

BIOS Setup

Floppy 3 Mode Support

This item allows you to use “3 Mode Floppy Drive” in Japanese computer systems by selecting
drive A, B, or both. Leave this item at its default [Disabled] setting if you are not using this
Japanese standard floppy drive.

Halt On

This item determines whether the system stops if an error is detected during system boot-up.

[All Errors]: The system-boot will stop whenever the BIOS detect a non-fatal error.

[No Errors]: The system-boot will not stop for any error detected.

AN52S/AN52 2-5

[All, But Keyboard]: The system-boot will stop for all errors except a keyboard error.

[All, But Diskette]: The system-boot will stop for all errors except a diskette error.

[All, But Disk/Key]: The system-boot will stop for all errors except a diskette or keyboard

error.

Base Memory

This item displays the amount of base memory installed in the system. The value of the base
memory is typically 640K for systems with 640K or more memory size installed on the
motherboard.

Extended Memory

This item displays the amount of extended memory detected during system boot-up.

Total Memory

This item displays the total memory available in the system.

2-6 AN52S/AN52

2.3 Advanced BIOS Features

Phoenix – AwardBIOS CMOS Setup Utility

Quick Power On Self Test Enabled Item Help
► CPU Feature Press Enter

►

Hard Disk Boot Priority Press Enter
First Boot Device Floppy
Second Boot Device Hard Disk
Third Boot Device CDROM
Boot Other Device Enabled
Boot Up Floppy Seek Disabled
Boot Up NumLock Status On
Security Option Setup
MPS Version Ctrl For OS 1.4
Delay IDE Initial (Secs) 0
Full Screen LOGO Show Enabled

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help



F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

Quick Power On Self Test

When set to [Enabled], this item speeds up the Power On Self Test (POST) after powering on
the system. The BIOS shorten or skip some check during the POST.

 CPU Feature

Click <Enter> key to enter its submenu:

Phoenix – AwardBIOS CMOS Setup Utility

Virtualization Enabled Item Help

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help



F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

Advanced BIOS Features

CPU Feature

BIOS Setup

Virtualization Technology

This option enables or disables the additional hardware capabilities provided by Virtualization
Technology.

AN52S/AN52 2-7

 Back to Advanced BIOS Features Setup Menu

Hard Disk Boot Priority

This item selects the hard disks booting priority. By pressing <Enter> key, you can enter its
submenu where the hard disks detected can be selected for the booting sequence to boot up
system.

This item functions only when there is the option of [Hard Disk] in any one of the
First/Second/Third Boot Device items.

First Boot Device / Second Boot Device / Third Boot Device / Boot Other Device

Select the drive to boot first, second and third in the [First Boot Device], [Second Boot Device],
and [Third Boot Device] items respectively. The BIOS will boot the operating system according
to the sequence of the drive selected. Set [Boot Other Device] to [Enabled] if you wish to boot
from another device other than these three items.

Boot Up Floppy Seek

When set to [Enabled], the BIOS will check whether the floppy disk drive is installed or not.

Boot Up NumLock Status

This item determines the default state of the numeric keypad at system booting up.

[On]: The numeric keypad functions as number keys.

[Off]: The numeric keypad functions as arrow keys.

Security Option

This item determines when the system will prompt for password - every time the system boots
or only when enters the BIOS setup.

[Setup]: The password is required only when accessing the BIOS Setup.

[System]: The password is required each time the computer boots up.

※ Don’t forget your password. If you forget the password, you will have to open

the computer case and clear all information in the CMOS before you can start
up the system. But by doing this, you will have to reset all previously set
options.

MPS Version Ctrl For OS

This item specifies which version of MPS (Multi-Processor Specification) this motherboard will
use. Leave this item at its default setting.

Delay For HDD (Secs)

This item allows the BIOS to support some old or special IDE devices by prolonging this delay
time. A larger value will give more delay time to the device for which to initialize and to prepare
for activation.

Full Screen LOGO Show

This item determines to show the full screen logo when booting.

2-8 AN52S/AN52

2.4 Advanced Chipset Features

Phoenix – AwardBIOS CMOS Setup Utility

K8<->NB HT Speed Auto Item Help
K8<->NB HT Width Auto

► DRAM Configuration Press Enter

SSE/SSE2 Instructions Enabled

↓↑→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

K8<->NB HT Speed

This item selects the LDT Bus Frequency between CPU and NF520 Chipset.

K8<->NB HT Width

This item selects the LDT Bus Width between CPU and NF520 Chipset.

DRAM Configuration

Click <Enter> key to enter its submenu.

You may manually set the DRAM timing parameters through its sub-items, or leave them at
their default settings according to the SPD (Serial Presence Detect) data stored in the DRAM.

Advanced Chipset Features

BIOS Setup

SSE/SSE2 Instructions

This item allows you to Enable or Disable the SSE/SSE2 (Streaming SIMD Extensions)
instruction set.

AN52S/AN52 2-9

2.5 Integrated Peripherals

Phoenix – AwardBIOS CMOS Setup Utility

► OnChip IDE/SATA Device Press Enter Item Help
Init Display First PCIe
OnChip USB V1.1+V2.0

- USB Keyboard Support OS

- USB Mouse Support OS
OnChip Audio Controller Enabled
Onboard FDD Controller Enabled
Onboard Serial Port Auto
Onboard LAN Controller Enabled

- Onboard LAN Boot ROM Disabled

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help



F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

 OnChip IDE/SATA Device

Click <Enter> key to enter its submenu:

Phoenix – AwardBIOS CMOS Setup Utility

► IDE/SATA Function Setup Press Enter Item Help

► RAID Configuration Press Enter

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help



F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

Integrated Peripherals

OnChip IDE/SATA Device

2-10 AN52S/AN52

 IDE/SATA Function Setup

Click <Enter> key to enter its submenu:

Phoenix – AwardBIOS CMOS Setup Utility

IDE 1 Controller Enabled Item Help

IDE DMA Transfer Access Enabled

OnChip SATA Controller Enabled

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help



F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

IDE 1 Controller

This item allows you to enable or disable the IDE1 controller.

IDE DMA Transfer Access

This item selects the DMA mode for devices connected through IDE channels.

IDE/SATA Function Setup

BIOS Setup

OnChip SATA Controller

This item enables or disables the onchip SATA controller.

AN52S/AN52 2-11

 RAID Configuration

Click <Enter> key to enter its submenu:

Phoenix – AwardBIOS CMOS Setup Utility

OnChip SATA Mode IDE Item Help

x - SATA1 RAID Disabled
x - SATA2 RAID Disabled
x - SATA3 RAID Disabled
x - SATA4 RAID Disabled

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help



F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

OnChip SATA Mode

This item determines the mode for OnChip SATA.

[IDE]: The on-chip SATA served as IDE mode.

[RAID]: The on-chip SATA served as RAID mode.

- SATA1 RAID ~ SATA4 RAID

This item allows you to enable or disable the RAID function for each of the SATA 1 ~ SATA4
port individually.

RAID Configuration

 Back to Integrated Peripherals Setup Menu

Init Display First

This item allows you to choose the primary display card.

OnChip USB

This option enables or disables the USB controller.

- USB Keyboard Support

Select [BIOS] for the legacy operating system (such as DOS) that does not support USB
keyboard.

- USB Mouse Support

Select [BIOS] for the legacy operating system (such as DOS) that does not support USB
mouse.

OnChip Audio Controller

This option enables or disables the audio controller.

2-12 AN52S/AN52

Onboard FDD Controller

This option enables or disables the floppy disk controller.

Onboard Serial Port

This item determines which I/O addresses the onboard Serial Port controller will access.

Onboard LAN Controller

This option enables or disables the LAN controller.

- Onboard LAN Boot ROM

This item allows you to use the boot ROM (instead of a disk drive) to boot-up the system and
access the local area network directly.

(For AN52S only)

BIOS Setup

AN52S/AN52 2-13

2.6 Power Management Setup

Phoenix – AwardBIOS CMOS Setup Utility

ACPI Suspend Type S3(Suspend-To-RAM) Item Help

- USB Resume from S3 Disabled
Power Button Function Instant-Off
Wake Up by WAKE# of PCIe Disabled
Wake Up by PME# of PCI Disabled
Wake Up by Ring Disabled
Wake Up by Alarm Disabled
X - Day of Month Alarm 0
X - Time(hh:mm:ss) Alarm 0 : 0 : 0
Cool’n’Quiet Technology Auto
Power On Function Button Only
Restore On AC Power Loss Power Off
HPET Support Enabled

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help



F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

ACPI Suspend Type

This item selects the type of Suspend mode.

- USB Resume from S3

When set to [Enabled], this item allows you to use a USB device to wake up a system that is in
the S3 (STR - Suspend To RAM) state. This item can be configured only if the item “ACPI
Suspend Type” is set to [S3(STR)].

Power Management Setup

Power Button Function

This item selects the method of powering off your system:

[Delay 4 Sec.]: Pushing the power button for more than 4 seconds will power off the system.
This will prevent the system from powering off in case you accidentally hit or pushed the power
button.

[Instant-Off]: Pressing and then releasing the power button at once will immediately power
off the system.

Wake Up by WAKE# of PCIe

When set to [Enabled], access through the add-on PCI Express card can remotely wake up the
system that was in Soft-Off condition. The PCI Express card must support the wake up function.

Wake Up by PME# of PCI

When set to [Enabled], access through the add-on PCI card can remotely wake up the system
that was in Soft-Off condition. The PCI card must support the wake up function.

Wake Up by Ring

When set to [Enabled], any event affecting from Modem Ring will awaken a system that has
powered down.

Wake Up by Alarm

When set to [Enabled], you can set the date and time you would like the Soft-Off PC to

2-14 AN52S/AN52

power-on in the “Date (of Month) Alarm” and “Time (hh:mm:ss) Alarm” items. However,
if the system is being accessed by incoming calls or the network (Resume On Ring/LAN) prior to
the date and time set in these items, the system will give priority to the incoming calls or
network instead.

- Day of Month Alarm

[0]: This option power-on the system everyday according to the time set in the “Time

(hh:mm:ss) Alarm” item.

[1-31]: This option selects a date you would like the system to power-on. The system will
power-on on the date set, and the time set in the “Time (hh:mm:ss) Alarm” item.

- Time (hh:mm:ss) Alarm

This item sets the time you would like the system to power-on.

Cool ’n’ Quiet Technology

This option enables or disables the AMD K8 cool and quiet function.

Restore On AC Power Loss

This item selects the system action after an AC power failure.

[Power Off]: When power returns after an AC power failure, the system’s power remains off.
You must press the Power button to power-on the system.

[Power On]: When power returns after an AC power failure, the system’s power will be
powered on automatically.

[Last State]: When power returns after an AC power failure, the system will return to the
state where you left off before power failure occurred. If the system’s power is off when AC
power failure occurs, it will remain off when power returns. If the system’s power is on when
AC power failure occurs, the system will power-on when power returns.

BIOS Setup

HPET Support

This item selects to support the “High Precision Event Timer” (HPET), a new timer hardware for
use by the system software when generating interrupts for thread schedulers, kernels, and
multimedia timer servers.

AN52S/AN52 2-15

2.7 PnP/PCI Configurations

Phoenix – AwardBIOS CMOS Setup Utility

Resources Controlled By Auto(ESCD) Item Help
x IRQ Resources Press Enter

PCI/VGA Pallete Snoop Disbaled

** PCI Express relative items **
Maximum Payload Size 4096

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help



F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

Resources Controlled By

This item configures all of the boot and Plug-and-Play compatible devices.

[Auto(ESCD)]: The system will automatically detect the settings.

[Manual]: Choose the specific IRQ resources in the “IRQ Resources” menu.

- IRQ Resources

Click <Enter> key to enter its submenu:

This item sets each system interrupt to either [PCI Device] or [Reserved].

PnP/PCI Configurations

PCI/VGA Palette Snoop

This item determines whether the MPEG ISA/VESA VGA cards can work with PCI/VGA or not.

[Enabled]: MPEG ISA/VESA VGA cards work with PCI/VGA.

[Disabled]: MPEG ISA/VESA VGA cards do not work with PCI/VGA.

Maximum Payload Size

This item sets the maximum TLP payload size for the PCI Express devices.

2-16 AN52S/AN52

2.8 PC Health Status

CPU Shutdown Temperature 90°C/194°F
CPU Warning Temperature 80°C/176°F
FAN Fail Alarm Selectable Disabled
Shutdown When FAN Fail Disabled
CPU FanEQ Control Enabled

- CPU FanEQ Target Temp. 50°C/122°F

- CPU FanEQ Temp. Tolerance 5°C/ 41°F

- CPU FanEQ Start Control 80%

- CPU FanEQ Stop Control 50%
SYS FanEQ Control Enabled

- SYS FanEQ Reference Temp. System

- SYS FanEQ Target Temp. 35°C/ 95°F

- SYS FanEQ Temp. Tolerance 5°C/ 41°F

- SYS FanEQ Start Control 70%

- SYS FanEQ Stop Control 50%
CPU Temperature 42°C/107°F
System Temperature 30°C/100°F
PWM Temperature 42°C/107°F
CPU FAN Speed 3245 RPM
SYS FAN Speed 0 RPM
AUX1 FAN Speed O RPM
AUX2 FAN Speed O RPM
CPU Core Voltage 1.29 V
DDR2 Voltage 1.87 V
Hyper Transport Voltage 1.20 V
NB Voltage 1.20 V
ATX +12V 12.00 V
ATX +3.3V 3.30 V

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help



F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

Phoenix – AwardBIOS CMOS Setup Utility

PC Health Status

Item Help

CPU Shutdown Temperature

You can set the processor shutdown temperature here. If the processor temperature exceeds
the settings value, system will force to shutdown to protect the processor not overheat.

BIOS Setup

CPU Warning Temperature

This item lets you select the temperature at which you want the system to send out a warning
message to the PC speakers of when the temperature goes beyond either limit. You can select
the temperatures you want.

FAN Fail Alarm Selectable

This item selects the fan that will be monitored for malfunction.

Shutdown When FAN Fail

When set to [Enabled], the system will be shut down if the fan selected for monitoring is not
running.

CPU FANEQ Control

This item allows you to control the CPU fan speed. When set to [Enabled], the following items
become selectable.

- CPU FanEQ Target Temp.

This item sets the temperature mark for the “CPU FanEQ” function to take effect.

AN52S/AN52 2-17

- CPU FanEQ Temp. Tolerance

This item sets the temperature tolerance range for the item “CPU FanEQ Target Temp.”.

- CPU FanEQ Start Control

This item sets the speed ratio for the 4-pin CPU fan assembly connected at “CPUFAN1” fan
power connector to start running.

- CPU FanEQ Stop Control

This item sets the lowest speed ratio for the 4-pin CPU fan assembly connected at “CPUFAN1”
fan power connector to run at when the CPU temperature detected is lower than the value of
item “CPU FanEQ Target Temp.” plus the value of item “CPU FanEQ Temp. Tolerance”.

In the situation when the CPU temperature detected is higher than the value of item “CPU
FanEQ Target Temp.” plus the value of item “CPU FanEQ Temp. Tolerance”, the speed ratio for
the 4-pin CPU fan assembly connected at “CPUFAN1” fan power connector will first run at the
speed ratio set by the item “CPU FanEQ Start Control”, and then up to 100%.

※ The 3-pin fan assembly connected at this 4-pin “CPUFAN1” fan power

connector will have no speed control function.

SYS FanEQ Control

This item allows you to control the SYSFAN speed. When set to [Enabled], the following items
become selectable.

- SYS FanEQ Reference Temp.

This item sets the reference point for taking temperature. The options are “System” and “CPU”.

※ In the situation when connecting a 3-pin CPU fan assembly, and you still want

the speed control function to take effect, you must:

1. Plug the 3-pin CPU fan assembly to “SYSFAN1” fan power connector.

2. Set the “SYS FanEQ Reference Temp.” item from the default “System” to
“CPU”.

- SYS FanEQ Target Temp.

This item sets the temperature mark for the “SYS FanEQ” function to take effect.

- SYS FanEQ Temp. Tolerance

This item sets the temperature tolerance range for the item “SYS FanEQ Target Temp.”.

- SYS FanEQ Start Control

This item sets the speed ratio for the 3-pin fan assembly connected at “SYSFAN1” fan power
connector to start running.

- SYS FanEQ Stop Control

This item sets the lowest speed ratio for the 3-pin fan assembly connected at “SYSFAN1” fan
power connector to run at when the temperature of “SYS FanEQ Reference Temp.” detected is
lower than the value of item “SYS FanEQ Target Temp.” plus the value of item “SYS FanEQ
Temp. Tolerance”.

In the situation when the temperature of “SYS FanEQ Reference Temp.” detected is higher than
the value of item “SYS FanEQ Target Temp.” plus the value of item “SYS FanEQ Temp.
Tolerance”, the speed ratio for the 3-pin fan assembly connected at “SYSFAN1” fan power
connector will first run at the speed ratio set by the item “SYS FanEQ Start Control”, and then
up to 100%.

2-18 AN52S/AN52

All Voltages, Fans Speed and Thermal Monitoring

These unchangeable items list the current status of the CPU and environment temperatures, fan
speeds, and system power voltage.

2.9 Load Fail-Safe Defaults

This option loads the BIOS default values for the most stable, minimal-performance system
operations.

2.10 Load Optimized Defaults

This option loads the BIOS default values that are factory settings for optimal-performance
system operations.

2.11 Set Password

This option protects the BIOS configuration or restricts access to the computer itself.

2.12 Save & Exit Setup

This option saves your selections and exits the BIOS setup menu.

2.13 Exit Without Saving

This option exits the BIOS setup menu without saving any changes.

BIOS Setup

AN52S/AN52 2-19

2-20 AN52S/AN52

3. Driver & Utility

The “Driver-&-Utility CD” that came packed with this motherboard contains drivers, utilities and
software applications required for its basic and advanced features.

3.1 CD-ROM AUTORUN

To run the CD-ROM automatically:

1. Place the “Driver-&-Utility CD” into the

CD-ROM drive in your system. The
following installation auto-run screen
appears. If not, browse the root
directory of the CD-ROM via the File
Manager, and double click the
“AUTORUN” file.

2. Click the item needed for installation.

• [Drivers]: Click to enter the driver
installation menu.

• [Manual]: Click to enter the user’s
manual menu.

• [Utility]: Click to enter the utilities
installation menu.

• [abit Utility]: Click to enter the installation menu of utilities exclusively developed by
abit.

Driver & Utility

• [

• [

3. The Windows will automatically search
for current and updated software by
looking up your computer.

When this “Found New Hardware
Wizard” window appears. Click
[Cancel] to start the following
procedures.

AN52S/AN52 3-1

Browse CD]: Click to browse the contents of this “Driver-&-Utility CD”.

Close]: Click to exit this installation menu.

3.2 nVidia nForce Chipset Driver

To install this program:

1. Click on the [Drivers] tab in the
installation menu screen.

2. Click the [nVidia nForce Chipset
Driver] item. The installation screen
appears.

3. Follow the prompts on the screen to
complete installation.

※ Please install this nVidia nForce

Chipset Driver first after having
installed the Windows operating
system.

3.3 Realtek HD Audio Driver

To install this program:

1. Click on the [Drivers] tab in the
installation menu screen.

2. Click the [Realtek HD Audio Driver]
item. The installation screen appears.

3. Follow the prompts on the screen to
complete installation.

4. After restarting the system, right-click
the Sound Manager icon located at the
desktop shortcut. Click item “Sound
Manager”. The Realtek HD Audio
Manager appears.

3-2 AN52S/AN52

5. Click the [Audio I/O] tab.

6. Click the pull down menu to select the
channel configuration.

7. Click [OK] button to apply the Audio
I/O settings and exit.

Driver & Utility

AN52S/AN52 3-3

3.4 Cool’n’Quiet Driver

To install this program:

1. Click on the [Drivers] tab in the
installation menu screen.

2. Click the [Cool’n’Quiet Driver] item.
The installation screen appears.

3. Follow the prompts on the screen to
complete installation.

4. Restart the system for the driver to
take effect.

5. After the system restarted, open the
“Power Options” from the control panel
and choose the power scheme “Minimal
Power Management” to enable Cool ‘n’
Quiet.

※ For Windows 2000 or ME system,

an AMD Cool ‘n’ Quiet tab will
appear under “Power Options”
when the Cool ‘n’ Quiet software
for Windows 2000 and ME is
installed. This must be set to
“Automatic Mode” for Cool ‘n’
Quiet to be enabled.

3.5 USB 2.0 Driver

※ There is no need to install this driver for Windows 2000 with Service Pack 4,

Windows XP with Service Pack 1, or their later version.

3-4 AN52S/AN52

3.6 abitEQ (The Hardware Doctor Utility)

The abitEQ is a self-diagnostic system that protects PC Hardware by monitoring critical items of
Power Supply Voltage, CPU & System Fans Speed, and CPU & System Temperature.

To install this utility:

1. Click on the [abit Utility] tab in the
installation menu screen.

2. Click the [abitEQ] item. The following
screen appears.

3. Follow the prompts on the screen to
complete installation.

Driver & Utility

4. Execute the abitEQ by entering the
Windows Menu [Start]  [All
Programs]  [abit]  [abitEQ].

5. The abitEQ shows you the status of
Voltage, Fan Speed, and Temperature
readings as well.

AN52S/AN52 3-5

3.7 FlashMenu (BIOS Update Utility)

The FlashMenu is a utility to flash the BIOS in a more easily and quickly way.

To install this utility:

1. Click on the [abit Utility] tab in the
installation menu screen.

2. Click the [FlashMenu] item. The
following screen appears.

3. Follow the prompts on the screen to
complete installation.

4. Execute the FlashMenu by entering the
Windows Menu [Start]  [All

Programs]  [abit]  [FlashMenu]
 [FlashMenu].

5. This FlashMenu screen appears. You
can easily update the BIOS from
clicking [Update From File], [One

Click LiveUpdate], or [LiveUpdate
Step by Step] button.

3-6 AN52S/AN52

3.8 SATA RAID Driver (for Windows Vista)

The Raid Driver needed when installing Windows Vista operating system is located at the
following path of your CD-ROM drive after placing the “Driver-&-Utility CD” into it:

For Vista 32bit  CD-ROM Drive:\Drivers\SATARAID\MCP65\Vista32
For Vista 64bit  CD-ROM Drive:\Drivers\SATARAID\MCP65\Vista64

3.9 SATA RAID Driver (for Windows XP, 2003, or 2000)

The “Driver Disk Maker” program bundled in the Driver-&-Utility CD is a utility to build the driver
program needed for SATA controller into a floppy disk under DOS environment. This procedure
is necessary only for installing Windows operating system to the hard disk connected to
“SATA1~SATA4” connector.

To create a driver disk Under DOS Environment:

1. Before starting, connect a 3.5” floppy disk drive to the “FDC1” connector, and connect a
CD-ROM drive to your motherboard. Prepare a 3.5” floppy disk.

2. After completing all the start-up preparation for hardware setup, power on the system.

3. Enter the BIOS Setup Menu by hitting <Del> key
Enter and select the BIOS menu “Advanced BIOS Features”. Configure the option

“First Boot Device” to “CD-ROM”

2

drive. Save this selection and exit BIOS setup menu

by accessing the BIOS menu “Save & Exit Setup”.

4. Restart the system. The system will now boot from CD, and enter the ABIT Boot Manager,
the following options appear

3

:

(0) Boot From First HDD
(1) Make Driver Disk
(2) Boot From First Floppy Drive
(3) Skip CD-ROM Boot (Try Next Boot Device)

Type <1> and hit <Enter> key. The following options appear:

(1) Make Driver Disk
(2) Exit

Type <1> and hit <Enter> key to start making.

5. The driver options appear:

(1) NVRaid Floppy Disk for WinXP_2K_2003 (32bit)
(2) NVRaid Floppy Disk for WinXP_2003 (64bit)

Type the number of the actions you want and hit <Enter> key.

6. Insert floppy disk to the floppy drive

7. Copying files to floppy now starts. After completed copying, hit the <n> key if you do not
want to make another Driver Disk, and stop at the A:\> prompt.

8. Take out the Driver-&-Utility CD from the CD-ROM drive now. Restart your system5.

1

You may refer to the chapter “BIOS Setup Menu” in user’s manual on how to do so.

2

The name may vary as per BIOS version. Place the “Driver-&-Utility CD” into the CD-ROM drive now.

3

You will have to type your command within 20 seconds, or the system will boot from HD.

4

You will be asked to do the format procedure if the floppy disk is not blank. Hit <n> key for not formatting

another floppy.

5

Now you have this driver disk ready for installing Windows Operating System. Insert this floppy disk to

floppy drive and press <F6> key when the screen instruction prompts you to install a third-party SCSI or
RAID driver.

AN52S/AN52 3-7

4

. Press any key to continue.

1

.

Driver & Utility

3-8 AN52S/AN52

4. Multilingual Quick Installation Guide

4.1 Français//Guide d'Installation Rapide

Ce “Guide d’Installation rapide ” contient seulement l
information de base dont vous pouvez avoir besoin lors de
l’installation de votre carte mère abit. Pour des opérations plus
avancées, vous devez vous reporter à la version complète.

Précautions d’installation du matériel

• Toujours il vous faut arrêter l’alimentation électrique et

déconnecter le câble électrique de la prise Courant Alternatif
avant d’installer la carte ou de changer des paramètres de
configuration.

• Mettez vous à la terre proprement en portant une bande de

poignet de sécurité contre les décharges électrostatiques et ce
avant d’enlever la carte de son emballage anti-statique

• Tenez la carte sur les bords. Evitez d’y toucher les composants

qui se trouvent dessus.

• Evitez de toucher les contacts des barrettes et les puces des

circuits intégrés(IC).

• Placez la carte sur une surface antistatique mise à la terre ou sur

l’emballage antistatique dans lequel se trouvait la carte.

Installation de la carte dans le boîtier

Le boîtier de l’ordinateur pour cette carte mère devrait:

• Accommoder le facteur de forme de cette carte mère.

• Supporter tout le câblage des connecteurs sur la carte mère aux

indicateurs et interrupteurs sur le boîtier.

• Etre capable de fournir suffisamment de puissance et d’espace

pour tous les lecteurs que vous voulez installer.

• Son modèle E/S dans le panneau arrière doit s’apparier avec les

ports E/S et les slots d’extension sur la carte mère.

Pour installer la carte mère dans le boîtier, vous devez:

• Face le côté des ports E/S vers la partie arrière du boîtier.

• Localisez les trous des vis à la fois sur la carte mère et sur la

base du boîtier.

• Placez tous les boulons ou entretoises nécessaires à la base du

boîtier et serrez les.

• Alignez tous les trous des vis de la carte mère avec ces boulons

ou entretoises sur le boîtier.

• Serrez toutes les vis.

Afin de prévenir tout court-circuit du circuit PCB, veillez s’il
vous plaît ENLEVER les goujons métalliques ou les entretoises
s’ils sont déjà installés sur la base du boîtier et n’ont pas de
trous de montage sur cette carte mère avec qui s’aligner.

Le cavalier d’effacement de la CMOS

Ce cavalier est utilisé pour effacer la mémoire CMOS afin de
paramétrer les contenus du BIOS. Vous pouvez avoir besoin
d’effacer la mémoire CMOS si les paramètres du BIOS sont
incorrects et empêchent votre carte mère de bien fonctionner.

Pour effacer la mémoire CMOS, déconnectez tous les câbles
d’alimentation de la carte mère, installez la fiche du cavalier sur le
réglage “Effacer CMOS” pendant quelques secondes, et puis
installez la fiche à son réglage “Normal”. Après reconnectez
l’alimentation électrique et redémarrez, le contenu BIOS sera
paramétré à nouveau à sa configuration d’usine.

Connections des Composants du Boîtier

L’alimentation électrique ATX: [ATXPWR1], [ATX12V1]
Connecteurs des VENTILATEURS: [CPUFAN1], [SYSFAN1],

[AUXFAN1], [NBFAN1]
Connecteurs sur le Panneau Avant: [FPIO1]

• [HLED]: Connecte au câble en nappe de la DEL du lecteur du

disque dur (HDD).

• [RST]: Connecte au câble en nappe de l’interrupteur de

réinitialisation.

AN52S/AN52 4-1

• [SPKR]: Connecte au câble du Haut-parleur du système.

• [SLED]: Connecte au câble de la DEL de veille.

• [PWR]: Connecte au câble de l’interrupteur de l’alimentation

électrique.

• [PLED]: Connecte au câble de la DEL d’alimentation.

Socle des Ports USB Supplémentaires: [FP-USB1], [FP-USB2]
Socle de Pins des Ports Supplémentaires IEEE1394: [FP-1394-1],

[FP-1394-2]
Socle de Connections Audio sur le Panneau Avant:

[FP-AUDIO1]
Connecteur Audio Interne: [CD1], [AUX1]

Montage de l’assemblage Unité Centrale de Traitement (CPU) &
Dissipateur thermique

Parce que l’on peut choisir beaucoup de types de CPU et de
dissipateurs d’énergie, chacun à des façons différentes de montage,
veuillez suivre exactement les instructions de montage que vous
pouvez trouver dans l’ensemble que vous venez d’acheter. Le CPU
est une unité électronique délicate qui produit des montants énormes
de chaleur en fonctionnement. Veuillez donc faire très attention
durant l’assemblage.

Après avoir fini d’assembler le dissipateur d’énergie sur le
processeur, Connectez l’alimentation du ventilateur de
refroidissement du CPU au connecteur [CPUFAN1] sur la carte
mère.

Installation des Barrettes de Mémoire

• Poussez vers le bas les pattes d’éjection de chaque côté du

connecteur d’extension.

• Alignez la barrette mémoire sur le connecteur d’extension. Ce

dernier a un ergot qui doit s’aligner avec l’encoche de la barrette
mémoire de façon qu’elle puisse s’enclipser dans un seul sens.

• Installez la barrette mémoire dans le connecteur d’extension en

appuyant dessus avec fermeté. Les pattes d’éjection du
connecteur levées vers le haut automatiquement verrouillent les
extrémités de la barrette mémoire.

• Pour enlever la barrette mémoire, poussez simultanément vers le

bas les pattes d’éjection de chaque extrémité du connecteur et
puis retirez la barrette mémoire.

Connection des Unités de Stockage

Connections du lecteur de disquettes: [FDC1]
Connections des disques durs IDE: [IDE1], [IDE2]
Connections des lecteurs de disques durs de série ATA:

[SATA1] ~ [SATA4]

Connections du Panneau Arrière

• Mouse: Connecte à la souris PS/2.

• Keyboard: Connecte au clavier PS/2.

• LPT1: Connecte à l’imprimante ou autres dispositifs qui

supportent le protocole de communication parallèle.

• COM1: Connecte au modem externe, à la souris ou autres

dispositifs qui supportent le protocole de communication série.

• OPT-IN1: Ce connecteur fournit une connexion S/PDIF en entrée

à travers une fibre optique aux appareils multimédia numériques.

• OPT-OUT1: Ce connecteur fournit une connexion S/PDIF en

sortie à travers une fibre optique aux appareils multimédia
numériques.

• AUDIO1: Connecte la 7.1 canaux audio.

• IEEE1394: Connecte aux unités du protocole IEEE1394.

• LAN1: Connecte au réseau local d’ordinateurs.

• USB1/USB2: Connecte aux unités du protocole USB.

Multilingual QIG

4.2 Deutsch//Kurze Installationsanleitung

Diese “Kurze Installationsanleitung” enthält nur die
grundlegenden Hardwareinformationen, die Sie zur
Installation Ihres abit-Motherboards benötigen. Details
finden Sie im ausführlichen Handbuch.

Vorsichtsmaßnahmen beim Einrichten der Hardware

• Vor Installation des Motherboards und Ändern von

Einstellungen müssen Sie immer die Stromversorgung
ausschalten und den Stecker von der Steckdose abziehen.

• Erden Sie sich ordnungsgemäß, indem Sie ein statisches

Handgelenksband tragen, bevor Sie das Motherboard aus
seinem antistatischen Beutel herausnehmen.

• Halten Sie das Motherboard an seinen Rändern fest.

Kommen Sie nicht mit den darauf befindlichen Komponenten
in Kontakt.

• Berühren Sie keine Modulkontakte und IC-Chips.

• Legen Sie das Motherboard auf eine geerdete, antistatische

Oberfläche oder auf den antistatischen Beutel, in dem sich
das Motherboard befand.

Installieren des Motherboards im Gehäuse

Das Computergehäuse für dieses Motherboard sollte folgenden
Voraussetzungen entsprechen:

• Es eignet sich für den Formfaktor dieses Motherboards.

• Anzeigen und Schalter am Gehäuse werden von allen

Kabelanschlüssen auf dem Motherboard unterstützt.

• Es liefert genügend Strom und besitzt ausreichend Platz für

alle zu installierenden Laufwerke.

• Seine rückseitigen Anschlussblende stimmt mit der

rückseitigen Anschlussblende und den
Erweiterungssteckplätzen auf dem Motherboard überein.

So wird das Motherboard im Gehäuse installiert:

• Legen Sie die Seite mit den E/A-Anschlüssen an die

Rückseite des Gehäuses.

• Finden Sie die Schraubenlöcher auf dem Motherboard und

auf dem Gehäuseboden.

• Legen Sie alle erforderlichen Stehbolzen oder Distanzstücke

auf den Gehäuseboden und befestigen Sie diese.

• Richten Sie alle Schraubenlöcher auf dem Motherboard mit

den Stehbolzen oder Distanzstücken auf dem
Gehäuseboden aus.

• Schrauben Sie das Motherboard fest.

Damit kein Kurzschluss auf der Leiterplatine erzeugt werden
kann, ENTFERNEN Sie bereits auf dem Gehäuseboden
befindliche Stehbolzen oder Distanzstücke aus Metall, wenn
sich diese nicht mit den Befestigungslöchern dieses
Motherboards ausrichten lassen.

Jumper zum Löschen des CMOS-Inhalts

Dieser Jumper löscht den Inhalt des CMOS-Speichers, um die
BIOS-Daten zurückzusetzen. Sie müssen den Inhalt des
CMOS-Speichers löschen, wenn die BIOS-Einstellungen falsch
sind und sie zu einem Fehlbetrieb des Motherboards führen.

Um den Inhalt des CMOS-Speichers zu löschen, stecken Sie
alle Netzkabel vom Motherboard ab, setzen Sie die
Jumperkappe einige wenige Sekunden auf die Einstellung
“CMOS löschen” und setzen Sie sie dann wieder zurück auf die
Einstellung “Normal”. Nach dem Wiederanschluss aller
Netzkabel und einem Neustart des Computers setzt sich der
BIOS-Inhalt auf seine Standardkonfiguration zurück.

Anschließen der Gehäusekomponenten

ATX-Stromversorgung: [ATXPWR1], [ATX12V1]
Lüfteranschlüsse (FAN): [CPUFAN1], [SYSFAN1],

[AUXFAN1], [NBFAN1]

4-2 AN52S/AN52

Anschlüsse auf der Vorderseite: [FPIO1]

• [HLED]: Kabelanschluss für Festplattenzugriffsanzeige.

• [RST]: Kabelanschluss für Rücksetzschalter.

• [SPKR]: Kabelanschluss für Kabelanschluss für

Systemlautsprecher.

• [SLED]: Kabelanschluss für Suspend-LED.

• [PWR]: Kabelanschluss für Netzschalter.

• [PLED]: Kabelanschluss für Betriebsanzeige (LED).

Zusatz-Header für USB-Anschluss: [FP-USB1], [FP-USB2]
Zusätzlicher IEEE1394-Anschluss-Header: [FP-1394-1],

[FP-1394-2]
Audioanschluss-Header auf der Vorderseite: [FP-AUDIO1]
Interne Audioanschlüsse: [CD1], [AUX1]

Installieren der CPU mit Kühlkörper

Da es unterschiedliche CPUs (Prozessoren) mit Kühlkörpern
zur Auswahl gibt, die jeweils unterschiedlich installiert werden
müssen, beachten Sie bitte genau die Installationsanweisungen
auf der von Ihnen gekauften Verpackung. Die CPU ist ein
empfindliches, elektronisches Gerät, das während des Betriebs
sehr viel Hitze erzeugt. Seien Sie bitte vorsichtig bei der
Installation.
Wenn der Kühlkörper am Prozessor angebracht ist, verbinden
Sie das CPU-Lüfterkabel mit dem [CPUFAN1]-Anschluss auf
dem Motherboard.

Installieren von Speichermodulen

• Drücken Sie die Verriegelungen auf beiden Seiten des

Steckplatzes herunter.

• Richten Sie das Speichermodul mit dem Steckplatz aus. Der

Steckplatz ist gekerbt und das Speichermodul hat einen
Ausschnitt, so dass es nur in eine Richtung passt.

• Drücken Sie das Speichermodul fest in den Steckplatz

hinein. Die Verriegelungen des Steckplatzes bewegen sich
automatisch nach oben und rasten in den Rändern des
Sp[eichermoduls ein.

• Um das Speichermodul zu entfernen, drücken Sie die

Verriegelungen auf beiden Seiten des Steckplatzes
gleichzeitig nach unten und ziehen Sie dann das
Speichermodul heraus.

Anschließen von Speichergeräten

Anschließen von Diskettenlaufwerken: [FDC1]
Anschließen von IDE-Festplatten: [IDE1], [IDE2]
Anschließen von SATA-Festplatten: [SATA1] ~ [SATA4]

Anschlüsse auf der Rückseite

• Mouse: Anschluss für eine PS/2-Maus.

• keyboard: Anschluss für eine PS/2-Tastatur.

• LPT1: Anschluss für einen Drucker oder andere Geräte, die

das parallele Kommunikationsprotokoll unterstützen.

• COM1: Anschluss für ein externes Modem, eine Maus oder

andere Geräte, die das serielle Kommunikationsprotokoll
unterstützen.

• OPT-IN1: Dieser Anschluss ist ein optischer S/P

DIF-Eingang für digitale Multimediageräte.

• OPT-OUT1: Dieser Anschluss ist ein optischer S/P

DIF-Ausgang für digitale Multimediageräte.

• AUDIO1: Anschluss für 7.1 Kanal HD Audio

• IEEE1394: Anschluss für Geräte mit IEEE1394-Protokoll.

• LAN1: Anschluss für ein ortsgebundenes Netzwerk.

• USB1/USB2: Anschluss für USB-Geräte wie Scanner,

digitale Lautsprecher, Monitor, Maus, Tastatur, Hub,
Digitalkamera, Joystick, etc.

4.3 Italiano//Guida all’installazione rapida

Questa “Guida all’installazione rapida” contiene solamente
le informazioni di base sull’hardware necessarie
all’installazione della scheda madre abit. Fare riferimento
alla versione completa della guida per eseguire le
operazioni avanzate.

Precauzioni sull’installazione dell’hardware

• Spegnere sempre l’unità e scollegare il cavo d’alimentazione

dalla presa CA prima di installare la scheda o modificare
qualsiasi impostazione.

• Indossare una fascetta antistatica prima di rimuovere la scheda

dalla busta antistatica.

• Tenere la scheda per i lati. Evitare di toccare qualsiasi

componente presente sulla scheda.

• Evitare di toccare i contatti dei moduli ed i chip IC.

• Appoggiare la scheda su una superficie antistatica con massa a

terra, oppure nella busta in cui la scheda è confezionata.

Installazione della scheda nella struttura

La struttura del computer deve:

• Accomodare le dimensioni di questa scheda madre

• Supportare tutti i connettori di cablaggio sulla scheda madre ai

relativi indicatori ed interruttori sulla struttura.

• Essere in grado si fornire spazio ed alimentazione sufficienti per

tutte le unità che si intendono installare.

• Il modello I/O del pannello posteriore deve combaciare con le

porte I/O e gli alloggiamenti d’espansione sulla scheda madre.

Per installare la scheda madre nella struttura si deve:

• Disporre il lato con le porte I/O verso la parte posteriore della

struttura.

• Ubicare i fori delle viti sulla scheda e sulla base della struttura.

• Collocare e stringere tutte le guarnizioni o spaziatori necessari

sulla base della struttura.

• Allineare tutti i fori delle viti sulla scheda con quelli delle

guarnizioni o spaziatori sulla struttura.

• Stringere tutte le viti.

Per evitare di mandare in corto il circuito il PCB, si prega di
RIMUOVERE le guarnizioni o gli spaziatori metallici che sono
già stati installati sulla base della struttura, e che sono
sprovvisti di fori di montaggio in grado di allinearsi con la
scheda madre.

Azzeramento del jumper CMOS

Questo jumper è utilizzato per azzerare la memoria CMOS in modo
da ripristinare i contenuti del BIOS. Potrebbe essere necessario
azzerare la memoria CMOS se le impostazioni del BIOS sono
scorrette ed impediscono alla scheda madre di funzionare.

Per azzerare la memoria CMOS, scollegare tutti i cavi
d’alimentazione della scheda madre, collocare per alcuni secondi il
cappuccio del jumper all’impostazione “Clear CMOS” (Azzeramento
CMOS) e poi rimetterlo nella sua impostazione normale “Normal”.
Dopo avere ricollegato tutti i cavi d’alimentazione ed avere riavviato il
sistema, i contenuti del BIOS saranno ripristinati alla loro
configurazione predefinita.

Collegamento dei componenti della struttura

Alimentazione ATX: [ATXPWR1], [ATX12V1]
Connettori ventolina: [CPUFAN1], [SYSFAN1], [AUXFAN1],

[NBFAN1]
Connettori del pannello frontale: [FPIO1]

• [HLED]: collega al cavo LED disco rigido.

• [RST]: collega al cavo Interruttore ripristino.

• [SPKR]: collega al cavo delle casse di sistema.

• [SLED]: collega al cavo LED sospensione.

• [PWR]: collega al cavo Interruttore alimentazione.

• [PLED]: collega al cavo LED alimentazione.

Collettore porta USB aggiuntiva: [FP-USB1], [FP-USB2]
Collettore porta IEEE1394 aggiuntiva: [FP-1394-1], [FP-1394-2]
Collettore di collegamento audio del pannello frontale:

[FP-AUDIO1]
Connettori audio interni: [CD1], [AUX1]

Installazione della CPU e del dispersore di calore

Dato che ci sono vari tipi di CPU (Central Processing Unit) e relativi
dispersori di calore tra cui scegliere, ciascuno con metodi diversi
d’installazione, seguire esattamente le istruzioni d’installazione
allegate alla confezione della CPU acquistata. La CPU è un
dispositivo elettronico delicato che produce una grande quantità di
calore quando è in funzionamento. Procedere con estrema
attenzione.

Al completamento dell’installazione del dispersore di calore sul
processore, collegare l’alimentazione della ventolina di
raffreddamento della CPU al connettore [CPUFAN1] sulla scheda
madre.

Installazione dei moduli di memoria

• Spingere verso il basso i fermagli ad entrambe le estremità

dell’alloggiamento.

• Allineare il modulo di memoria con l’alloggiamento.

L’alloggiamento è dotato di dentellatura ed il modulo di memoria
è dotato di intagli così che possono combaciare in una sola
direzione.

• Installare il modulo di memoria nell’alloggiamento premendo

verso il basso con fermezza. I fermagli dell’alloggiamento
scattano verso l’alto automaticamente bloccando i lati del modulo
di memoria.

• Per rimuovere il modulo di memoria, spingere

contemporaneamente verso il basso i fermagli su entrambi i lati
dell’alloggiamento, quindi estrarre il modulo di memoria.

Collegamento dei dispositivi d’archiviazione

Collegamento dell’unità dischetti floppy: [FDC1]
Collegamento dei dischi rigidi IDE: [IDE1], [IDE2]
Collegamento di dischi rigidi Serial ATA: [SATA1] ~ [SATA4]

Collegamenti del pannello posteriore

• Mouse: collega al mouse PS/2.

• Keyboard: collega alla tastiera PS/2.

• LPT1: collega alla stampante o ad altri dispositivi che supportano

il protocollo di comunicazione parallela.

• COM1: collega al modem esterno, al mouse o ad altri dispositivi

che supportano il protocollo di comunicazione seriale.

• OPT-IN1: Questo connettore fornisce un collegamento in entrata

di tipo S/PDIF attraverso fibra ottica da apparecchi multimediali
digitali.

• OPT-OUT1: Questo connettore fornisce un collegamento in

uscita di tipo S/PDIF attraverso fibra ottica ad apparecchi
multimediali digitali.

• AUDIO1: Questo connettore fornisce un collegamento canale

audio in entrata/in uscita di tipo 7.1.

• IEEE1394: collega ai dispositivi del protocollo IEEE1394.

• LAN1: collega alla rete locale LAN (Local Area Network).

• USB1/USB2: collega a dispositivi USB come scanner, casse

digitali, monitor, mouse, tastiere, hub, macchine fotografiche
digitali, joystick ecc.

Multilingual QIG

AN52S/AN52 4-3

4.4 Español//Guía rápida de instalación

Esta “Guía de instalación rápida” contiene solamente la
información básica sobre el hardware que puede necesitar
durante la instalación de la placa base abit. Para conocer el
funcionamiento avanzado, es necesario consultar la
versión completa.

Precauciones durante la configuración del hardware

• Apague siempre la fuente de alimentación y desenchufe el

cable antes de instalar la placa base o cambiar su
configuración.

• Conéctese a una toma de tierra utilizando una muñequera

de seguridad estática antes de retirar la placa base de la
bolsa antiestática.

• Sujete la placa por los bordes. Evite tocar los componentes.

• Evite tocar los contactos del módulo y los chips IC

• Coloque la placa en una superficie antiestática con toma de

tierra o en la bolsa en la que se suministre la placa.

Instalación de la placa en el chasis

El chasis del ordenador para esta placa base debe:

• Acomodar el factor forma de esta placa base.

• Admitir todas las conexiones de cable de la placa base a los

indicadores e interruptores del chasis.

• Ser capaz de suministrar suficiente energía y espacio para

todas las unidades que desee instalar.

• La etiqueta I/O del panel trasero debe coincidir con los

puertos I/O y las ranuras de expansión de la placa base.

Para instalar la placa base en el chasis, debe:

• Colocar el lado de los puertos I/O hacia la parte trasera del

chasis.

• Localizar los orificios de los tornillos en la placa base y en el

chasis.

• Colocar todos los pernos o separadores en el chasis y

apretarlos.

• Alinear todos los orificios de los tornillos de la placa base

con los pernos o los separadores del chasis.

• Apretar todos los tornillos.

Para evitar un cortocircuito en el circuito PCB, RETIRE los
pernos o separadores de metal si ya están instalados en el
chasis y que se encuentren sin orificios de montaje en la
placa base con los que alinearse.

Puente de borrado de la CMOS

Este Puente se utiliza para borrar la memoria CMOS para
reiniciar el contenido de la BIOS. Puede que sea necesario
borrar la memoria CMOS si la configuración de la BIOS es
incorrecta y hace que la placa base no funcione.

Para borrar la memoria de la CMOS, desconecte todos los
cables de alimentación de la placa base, conecte puente en la
configuración "Borrar CMOS" durante unos segundos y, a
continuación, vuelva a colocar el puente en la posición de
"Normal". Tras reconectar la alimentación y reiniciar el equipo,
el contenido de la BIOS se reiniciará a la configuración
predeterminada.

Conexión de los componentes del chasis

Fuente de alimentación ATX: [ATXPWR1], [ATX12V1]
Conexiones de ventilador: [CPUFAN1], [SYSFAN1],

[AUXFAN1], [NBFAN1]
Conexiones del panel frontal: [FPIO1]

• [HLED]: Conecte el cable del LED del disco duro.

• [RST]: Conecte el cable del interruptor de reinicio.

• [SPKR]: Conecte el cable del altavoz del sistema.

4-4 AN52S/AN52

• [SLED]: Conecte el cable del LED de suspensión.

• [PWR]: Conecte el cable del interruptor de encendido.

• [PLED]: Conecte el cable del LED de encendido.

Terminal de puerto USB adicional: [FP-USB1], [FP-USB2]
Terminal de puerto IEEE1394 adicional: [FP-1394-1],

[FP-1394-2]
Terminal de conexión de audio del panel frontal:

[FP-AUDIO1]
Conexiones de audio internas: [CD1], [AUX1]

Instalación de la CPU y el juego de disipador de calor

Dado que existen tres tipos de unidades de procesamiento
central (CPU) y disipadores de calor entre los que elegir, cada
uno con una forma de instalación distinta, siga exactamente las
instrucciones de instalación que encontrará en la caja del
producto. La CPU es un dispositivo electrónico delicado que
proporciona una gran cantidad de calor cuando se encuentra
en funcionamiento. Preste mucha atención a su instalación.

Tras completar la instalación del disipador de calor en el
procesador, conecte la alimentación del ventilador de
refrigeración de la CPU en la conexión [CPUFAN1] en la placa
base.

Instalación de los módulos de memoria

• Empuje los cierres situados a ambos lados del zócalo.

• Alinee el modulo de memoria con el zócalo. El zócalo está

marcado con una protuberancia y el módulo incluye una
ranura para que sólo pueda ajustar en una dirección.

• Instale el modulo de memoria en el zócalo apretando

firmemente. El zócalo empujará automáticamente hacia
arriba los cierres de los bordes y fijará el módulo de
memoria.

• Para retirar el modulo de memoria, pulse en los cierres de

los lados del zócalo simultáneamente y tire del módulo.

Conexión de dispositivos de almacenamiento

Conexión de una unidad de disco: [FDC1]
Conexión de unidades de disco duro: [IDE1], [IDE2]
Conexión de unidades de disco duro de serie ATA: [SATA1]

~ [SATA4]

Conexión del panel trasero

• Mouse: Conecte el ratón PS/2.

• Keyboard: Conecte el teclado PS/2.

• LPT1: Conecte la impresora u otros dispositivos que

admitan el protocolo de comunicaciones paralelo.

• COM1: Conecte un módem externo, ratón u otros

dispositivos que admitan el protocolo de comunicación de
serie.

• OPT-IN1: Este conector proporciona una conexión de

entrada S/PDIF a través de fibra óptica procedente de
dispositivos multimedia digitales.

• OPT-OUT1: Este conector proporciona una conexión de

salida S/PDIF a través de fibra óptica hacia dispositivos
multimedia digitales.

• AUDIO1: Este conector proporciona una conexión de

entrada y salida de audio de 7.1 canales.

• IEEE1394: Conecte dispositivos de protocolo IEEE1394.

• LAN1: Conecte una red de área local.

• USB1/USB2: Conecte dispositivos USB como, por ejemplo,

un escáner, altavoces digitales, monitor, ratón, teclado,
concentrador, cámara digital, joystick etc.

4.5 Português//Guia de instalação rápida

Este “Guia de instalação rápida” contém apenas
informação essencial sobre o hardware e necessária à
instalação da sua placa principal abit. Para mais
informações, terá de consultar a versão integral deste guia.

Normas de segurança a ter em conta durante a montagem do
hardware

• Desligue sempre a fonte de alimentação e desligue o cabo de

alimentação da tomada a.c. antes de instalar a placa ou alterar
quaisquer definições.

• Antes de remover a placa da embalagem anitestática, ligue-se à

terra utilizando uma pulseira antiestática.

• Segure a placa pelas extremidades. Evite tocar em qualquer

componente.

• Evite tocar nos contactos do módulo e nos chips do circuito

integrado.

• Coloque a placa principal sobre uma superfície antiestática ou na

embalagem antiestática onde a mesma vinha.

Instalar a placa principal no chassis

Para instalar esta placa principal, o chassis do computador deve:

• Acomodar o formato específico desta placa.

• Suportar a ligação de todos os conectores existentes na placa

principal aos indicadores e comutadores do chassis.

• Ter capacidade para fornecer energia e espaço suficiente para

todas as unidades que pretender instalar.

• As ranhuras de entrada/saída no painel traseiro devem

corresponder à localização das portas de entrada/saída e às
ranhuras de expansão da placa principal.

Para instalar a placa principal no chassis, deve:

• Fazer corresponder a localização das portas de entrada/saída

com as ranhuras existentes na parte traseira do chassis.

• Localizar os orifícios dos parafusos tanto na placa principal como

no chassis.

• Colocar todos os pinos e espaçadores necessários no chassis e

apertá-los.

• Alinhar todos os orifícios dos parafusos na placa principal com

os pinos e espaçadores no chassis.

• Aparafusar todos os parafusos.

Para evitar o curto-circuito da placa de circuito impresso,
REMOVA os pinos metálicos caso estes estejam já colocados
no chassis e não estejam alinhados com os orifícios
correspondentes na placa principal.

Jumper para limpeza do CMOS

Este jumper é utilizado para limpar a memória CMOS de forma a
restaurar o conteúdo da BIOS. Pode ser necessário limpar a
memória CMOS caso as definições da BIOS estejam incorrectas
fazendo com que a placa principal não funcione.

Para limpar a memória CMOS, desligue todos os cabos de
alimentação da placa principal, coloque o shunt do jumper na
posição “Clear CMOS” durante alguns segundos e de seguida volte
a colocar o shunt do jumper na posição “Normal”. Depois de ligar e
reiniciar o computador, o conteúdo da BIOS é restaurado para a
configuração predefinida.

Ligar os componentes do chassis

Fonte de alimentação ATX: [ATXPWR1], [ATX12V1]
Conectores da ventoinha: [CPUFAN1], [SYSFAN1], [AUXFAN1],

[NBFAN1]
Conectores de painel frontal: [FPIO1]

• [HLED]: Faz a ligação ao cabo do LED da unidade de disco

rígido.

• [RST]: Faz a ligação ao cabo do botão Reset.

• [SPKR]: Faz a ligação ao cabo do sistema de colunas.

• [SLED]: Faz a ligação ao cabo do LED de suspensão.

• [PWR]: Faz a ligação ao cabo do botão de alimentação.

• [PLED]: Faz a ligação ao cabo do LED do botão de alimentação.

Suporte adicional à porta USB: [FP-USB1], [FP-USB2]
Suporte adicional para porta IEEE1394: [FP-1394-1], [FP-1394-2]
Suporte da ligação áudio do painel frontal: [FP-AUDIO1]
Conectores internos de áudio: [CD1], [AUX1]

Instalar a CPU & Montar o dissipador de calor

Uma vez que existem vários tipos de Unidades centrais de
processamento (CPUs) e respectivos dissipadores de calor com
modos diferentes de instalação, siga cuidadosamente as instruções
de instalação que constam da embalagem. A CPU é um dispositivo
electrónico delicado que gera uma enorme quantidade de calor
durante o seu funcionamento. Proceda à sua instalação com
cuidado.

Após instalar o dissipador de calor no processador, ligue a ventoinha
de arrefecimento da CPU ao conector [CPUFAN1] existente na
placa principal.

Instalar os módulos de memória

• Exerça pressão em sentido descendente sobre as patilhas

situadas em ambos os lados da ranhura.

• Alinhe o módulo de memória com a ranhura. A ranhura

apresenta alguns entalhes e o módulo de memória alguns
recortes que fazem com que o módulo de memória apenas
encaixe numa direcção.

• Introduza o módulo de memória na ranhura exercendo pressão

sobre o mesmo em sentido descendente. As patilhas da ranhura
encaixam automaticamente nas extremidades do módulo de
memória.

• Para remover o módulo de memória, pressione as patilhas

localizadas em ambos os lados da ranhura em simultâneo e em
sentido descendente, e de seguida puxe o módulo de memória
para fora.

Ligar dispositivos de armazenamento

Ligar a unidade de disquete: [FDC1]
Ligar as unidades de disco rígido IDE: [IDE1], [IDE2]
Ligar unidades de disco rígido série ATA : [SATA1] ~ [SATA4]

Ligações no painel traseiro

• Mouse: Ligação do rato PS/2.

• Keyboard: Ligação do teclado PS/2.

• LPT1: Ligação da impressora ou de outros dispositivos que

suportem o protocolo de comunicação paralela.

• COM1: Ligação do modem externo, do rato ou de outros

dispositivos que suportem o protocolo de comunicação série.

• OPT-IN1: Este conector permite a ligação da entrada S/PDIF a

partir de dispositivos multimédia digitais e através de fibras
ópticas.

• OPT-OUT1: Este conector permite a ligação da saída S/PDIF a

partir de dispositivos multimédia digitais e através de fibras
ópticas.

• AUDIO1: Este conector permite a ligação de uma entrada/saída

de áudio de canal 7.1.

• IEEE1394: Ligação de dispositivos do protocolo IEEE1394.

• LAN1: Ligação da rede local.

• USB1/USB2: Ligação de dispositivos USB tais como scanners,

colunas digitais, monitor, rato, teclado, hub, câmara digital,
joystick,etc.

Multilingual QIG

AN52S/AN52 4-5

4.6 Русский//Краткое руководство по установке

В “Кратком руководстве по установке” содержится только
основная информация о техническом обеспечении, которая
вам может понадобиться при установке материнской платы
abit. Описание дополнительных операций вы найдете в
полной версии руководства.

Предостережения по установке технического обеспечения

• Перед тем, как установить плату или поменять установку,

обязательно выключите питание и выдерните шнур

питания из розетки.

• Перед тем, как вынуть плату из антистатической упаковки

тщательно заземлите себя с помощью предохранительной
статической повязки на запястье.

• Держите плату за края. Старайтесь не касаться ее

компонентов.

• Старайтесь не касаться контактов модуля и чипов IC

• Кладите плату на заземленную антистатическую поверхность

или на антистатическую упаковку от платы.

Установка платы в корпус

Корпус компьютера должен:

• Подходить к форме данной материнской платы.

• Поддерживать кабельные соединения материнской платы с

индикатором и переключателем на корпусе.

• Обеспечивать достаточное питание и пространство для всех

дисководов, которые вы намерены установить.

• Шаблоны входа/выхода на задней панели корпуса

компьютера должны соответствовать портам входа/выхода и
слотам расширения материнской платы.

Чтобы установить материнскую плату в корпусе:

• Направьте порты входа/выхода к задней части корпуса.

• Найдите отверстия для крепежных винтов на материнской

плате и на корпусе.

• Вставьте все необходимые шпильки или прокладки в

основание корпуса и закрепите их.

• Соедините все винтовые отверстия на материнской плате

этими шпильками или прокладками с корпусом.

• Закрепите все винты.

Чтобы избежать короткого замыкания в БУП, просим
УДАЛИТЬ металлические шпильки или прокладки, если
таковые установлены в основании корпуса, а на
материнской плате нет соответствующих им
крепежных отверстий.

Перемычка для очистки CMOS

Перемычка используется для очистки памяти CMOS, чтобы
переустановить содержимое BIOS. Вам может понадобиться
очистить память CMOS, если настройки BIOS неправильны и не
позволяет работать материнской плате.

Чтобы очистить память CMOS, отсоедините все кабели питания
от материнской платы, на несколько секунд присоедините
колодку перемычки к гнезду настройки “Очистить CMOS”, а
потом верните ее обратно в
Потом снова подключите питание и перезагрузите компьютер;
содержимое BIOS настроится на конфигурацию по умолчанию.

гнездо настройки “Нормальная”.

Соединение компонентов корпуса

Электропитание ATX: [ATXPWR1], [ATX12V1]
ВЕНТИЛЯТОРНЫЕ соединения: [CPUFAN1], [SYSFAN1],

[AUXFAN1], [NBFAN1]
Соединения передней панели: [FPIO1]

• [HLED]: Соединяется с кабелем HDD LED.

• [RST]: Соединяется с кабелем включателя перезагрузки.

• [SPKR]: Соединяется с кабелем системного динамика.

• [SLED]: Соединяется с кабелем индикатора приостановки.

• [PWR]: Соединяется с кабелем выключателя питания.

• [PLED]: Соединяется с кабелем индикатора питания.

Дополнительная насадка порта USB: [FP-USB1], [FP-USB2]
Дополнительная насадка порта IEEE1394: [FP-1394-1],

[FP-1394-2]

Насадка аудио соединения на передней панели: [FP-AUDIO1]
Внутренние звуковые разъемы: [CD1], [AUX1]

Установка CPU и блока теплоотвода

Так как существует большой выбор разных типов центральных
процессоров (CPU) и их блоков теплоотвода, и так как каждый
из них устанавливается по-разному, просим строго
придерживаться инструкций по установке, которые вы найдете в
купленном вами пакете. CPU – это тонкое электронное
устройство, которое во время работы выделяет огромное
количество тепла
предельной осторожностью.

Установив теплоотвод на процессор, соедините питание
вентилятора охлаждения CPU с разъемом [CPUFAN1] на
материнской плате.

. Просим приниматься за установку с

Установка модулей памяти

• Надавите вниз на защелки с обеих сторон слота.

• Направьте модуль памяти в слот. Слот снабжен зазубриной,

а модуль памяти снабжен выемкой так, что они могут
совпасть только в одном положении.

• Сильно нажав на модуль памяти вниз, вставьте его в слот.

Защелки слота автоматически защелкнутся по бокам модуля
памяти.

• Желая вынуть модуль памяти, нажмите вниз на обе защелки

слота одновременно и вытащите модуль памяти.

Соединение устройств хранения данных

Соединение дисковода гибких дисков: [FDC1]
Соединение жестких дисков IDE: [IDE1], [IDE2]
Соединение последовательных жестких дисков ATA:

[SATA1] ~ [SATA4]

Соединения задней панели

• Мouse: Соедините с PS/2 мышь.

• Keyboard: Соедините с PS/2 клавиатуру.

• LPT1: Соедините с принтером или другими устройствами,

поддерживающими протокол параллельного
взаимодействия.

• COM1: Соедините с внешним модемом, мышью или другими

устройствами, поддерживающими протокол
последовательного взаимодействия.

• OPT-IN1: Данный разъем обеспечивает подключение

оптоволоконного кабеля S/PDIF от мультимедийных
устройств.

• OPT-OUT1: Данный разъем обеспечивает выходное

подключение оптоволоконного кабеля S/PDIF к
мультимедийным устройствам.

• AUDIO1: Данный разъем обеспечивает входное и выходное

подключение 7.1-канального аудиосигнала.

• IEEE1394: Соедините с устройствами протокола IEEE1394.

• LAN1: Соедините с локальной сетью.

• USB1/USB2: Соедините с такими устройствами USB, как

сканер, цифровые динамики, монитор, мышь, клавиатура,
хаб, цифровая камера, джойстик и т.д.

4-6 AN52S/AN52

4.7 Eesti//Kiirpaigaldusjuhend

Käesolev “Kiirpaigaldusjuhend” sisaldab ainult
abit-emaplaadi paigaldamiseks vajalikku riistvaraalast
põhiteavet. Edasijõudnud kasutamiseks tuleb teil ikkagi
pöörduda täisversiooni poole.

Ettevaatusabinõud riistvara paigaldamisel

• Enne emaplaadi paigaldamist või ümberseadistamist lülitage

alati eelnevalt toide välja ning lahutage toitejuhe
vooluvõrgust.

• Enne plaadi antistaatilisest kotist välja võtmist maandage

end korralikult antistaatilise turvarandmerihma abil.

• Hoidke plaati selle servadest. Vältige suvaliste sellel

paiknevate komponentide puudutamist.

• Vältige mooduli kontaktide ja mikroskeemide puudutamist.

• Asetage plaat maandatud antistaatilisele pinnale või

komplekti kuuluvale antistaatilisele kotile.

Plaadi raamile paigaldamine

Selle emaplaadi jaoks peab arvuti raam:

• Sobima selle emaplaadi kujuga.

• Toetama kõiki emaplaati raami indikaatorite ja lülititega

ühendatavaid konnektoreid.

• Tagama piisavalt võimsust ja ruumi kõikide draivide jaoks,

mida te kavatsete paigaldada.

• S/V-mall selle tagapaneelil peab vastama emaplaadi

S/V-portidele ja laienduspesadele.

Emaplaadi raamile paigaldamiseks tuleb teil:

• Pöörata see S/V-portide küljega raami tagaosa suunas.

• Määrata kruviaukude asukoht nii emaplaadil kui raamil

alusel.

• Paigutada raami alusele vajalikud poldid ja seibid ning neid

pingutada.

• Joondage kõik emaplaadi kruviaugud raamile paiknevate

poltidega.

• Pingutada kõiki kinnitusi.

Trükkplaadi lühiste vältimiseks EEMALDAGE palun kõik
raamil paiknevad metallpoldid ja -seibid, mille jaoks sellel
emaplaadil puuduvad vastavad paigaldusaugud, millega
neid joondada.

CMOS kustutamise sillus

Seda sillust kasutatakse CMOS-mälu kustutamiseks BIOSi
ümberseadistamisel. Teil võib tekkida CMOS-mälu kustutamise
vajadus vale, emaplaadi tööd takistava BIOSi seadistuse korral.

CMOS-mälu kustutamiseks lahutage emaplaadist kõik
toitekaablid, ühendage silluse kork mõneks sekundiks
kustutamisasendisse “Clear CMOS” ning ühendage seejärel
silluse kork uuesti vaikeasendisse “Normal”. Pärast
toitekaablite tagasiühendamist ja taaskäivitamist taastub BIOSi
vaikekonfiguratsioon.

Raami komponentide ühendamine

ATX toiteallikas: [ATXPWR1], [ATX12V1]
Ventilaatorite konnektorid: [CPUFAN1], [SYSFAN1],

[AUXFAN1], [NBFAN1]
Esipaneeli konnektorid: [FPIO1]

• [HLED]: Ühendage HDD LED-kaabliga.

• [RST]: Ühendage lähtestusnupu (Reset) kaabliga.

• [SPKR]: Ühendage süsteemikõlari kaabliga.

• [SLED]: Ühendage peatusindikaatori (Suspend LED)

• [PWR]: Ühendage toitelüliti kaabliga.

• [PLED]: Ühendage toiteindikaatori (Power LED) kaabliga.

Täiendav USB-pordi päis: [FP-USB1], [FP-USB2]
Täiendav IEEE1394 pordi päis: [FP-1394-1], [FP-1394-2]
Esipaneeli audioühenduse päis: [FP-AUDIO1]
Sisemised audiokonnektorid: [CD1], [AUX1]

Protsessori ja jahutusradiaatori paigaldus

Kuna valida on mitmete erineva paigaldusskeemiga
protsessorite (CPU) ja jahutusradiaatorite vahel, järgige palun
täpselt teie poolt ostetud paketi paigaldusjuhiseid. CPU on
tundlik elektroonikaseade, mis oma töö käigus eraldab suurel
hulgal soojust. Palun jätkake ülima ettevaatusega.

Olles lõpetanud jahutusradiaatori paigaldamise protsessorile,
ühendage CPU ja jahutusventilaator emaplaadi [CPUFAN1]
konnektoriga.

Mälumoodulite paigaldamine

• Vajutage pesa mõlemal pool paiknevad riivid alla.

• Joondage mälumoodul pesaga. Pesa on varustatud eendiga

• Mälumooduli pessa paigaldamisel suruge seda kindlalt alla.

• Mälumooduli eemaldamiseks suruge üheaegselt pesa

Salvestusseadmete ühendamine

Disketidraivide ühendamine: [FDC1]
IDE kõvaketaste ühendamine: [IDE1], [IDE2]
Jadaühendusega ATA kõvaketta draivid: [SATA1] ~

[SATA4]

Tagapaneeli ühendus

• Mouse: Ühendage PS/2 hiirega.

• Keyboard Ühendage PS/2 klaviatuuriga.

• LPT1: Ühendage printeri või teiste seadmetega, mis

• COM1: Ühendage välise modemiga, hiirega või teiste

• OPT-IN1: See konnektor koos fiiberoptikaga võimaldab

• OPT-OUT1: See konnektor koos fiiberoptikaga võimaldab

• AUDIO1: See konnektor võimaldab 7.1-kanali audio

• IEEE1394: Ühendage IEEE1394 protokolli seadmega.

• LAN1: Ühendage kohtvõrguga.

• USB1/USB2: Ühendage USB-seadmega, nagu skanner,

kaabliga.

ja mälumoodul väljalõikega, seega saavad nad sobituda
ainult ühes suunas.

Pesa riivid tõusevad automaatselt ülespoole ja haaravad
mälumooduli servi.

mõlemal pool paiknevaid lukusteid allapoole ning tõmmake
seejärel mälumoodul välja.

Multilingual QIG

toetavad paralleelset sideprotokolli.

seadmetega, mis toetavad järjestikulist sideprotokolli.

digitaalsete multimeediaseadmete S/PDIF sisendühendust.

digitaalsete multimeediaseadmete S/PDIFväljundühendust.

sisend/väljundühendust.

digitaalkõlarid, monitor, hiir, klaviatuur, jaotur,
digitaalkaamera, juhtkang jne.

AN52S/AN52 4-7

4.8 Latviski//Ātrās instalēšanas instrukcija

Šī “Ātrās instalēšanas instrukcija” ietver tikai pamata
norādes iekārtai, kas nepieciešamas, instalējot abit
mātesplati. Pilnīgākai darbībai nepieciešams iegūt
instrukcijas paplašināto variantu.

Piesardzības pasākumi iekārtas uzstādīšanā

• Vienmēr pirms plates pievienošanas vai jebkuru uzstādījumu

izmaiņām izslēdziet strāvas padevi un atvienojiet vadu no
maiņstrāvas barošanas avota.

• Pirms plates izņemšanas no antistatiskās somas nodrošiniet

sev pienācīgu zemējumu, uzliekot statiskās drošības aproci.

• Turiet plati aiz malām. Neskarieties pie tās sastāvdaļām.

• Neskarieties pie moduļa kontaktiem un integrētās shēmas

mikroshēmām.

• Novietojiet plati uz zemētas antistatiskas virsmas vai plates

antistatiskās somas.

Plates instalēšanas šasijā

Datora šasijai attiecībā uz šo mātesplati ir:

• Jābūt piemērotai šīs mātesplates formas faktoram.

• Jāatbalsta visi vadu savienojumi mātesplatē ar indikatoriem

un slēdžiem uz šasijas.

• Jāspēj nodrošināt pietiekamu strāvas jaudu un telpu visiem

pievadiem, kurus paredzēts instalēt.

• Tās ievadizvades ierīcei aizmugures panelī ir jāatbilst

ievadizvades portiem un paplašinājuma slotiem uz
mātesplates.

Lai instalētu mātesplati šasijā:

• Pavērsiet ievadizvades portu sānu pret šasijas aizmugures

daļu.

• Saskaņojiet skrūvju caurumus uz mātesplates un šasijas

pamatnes.

• Izvietojiet visus statņus vai starplikas, kas nepieciešami

šasijas pamatnei, un savelciet tos.

• Saskaņojiet visus skrūvju caurumus uz mātesplates ar uz

statņiem vai starplikām esošajiem.

• Savelciet visas skrūves caurumos.

Lai novērstu PCB shēmu, NOŅEMIET tos metāla statņus vai
starplikas, kas jau instalēti uz šasijas pamatnes un ir bez
montāžas caurumiem uz šīs mātesplates to saskaņošanai.

CMOS notīrīšanas tiltslēgs

Šis tiltslēgs tiek izmantots, lai notīrītu CMOS atmiņu BIOS
satura atiestatīšanas nolūkā. CMOS atmiņu var būt
nepieciešams notīrīt, ja BIOS uzstādījumi ir nepareizi un kavē
mātesplates darbību.

Lai notīrītu CMOS atmiņu, atvienojiet visus vadus no
mātesplates, savienojiet tiltslēga uzgali uz dažām sekundēm
uzstādījumā “Clear CMOS” (Notīrīt CMOS) un pēc tam
savienojiet tiltslēga uzgali atpakaļ uzstādījumā “Normal”
(Normāls). Pēc tam pievienojiet strāvu un atsāknējiet; BIOS
saturs tiks atiestatīts tā noklusējuma konfigur

ācijā.

Šasijas sastāvdaļu pievienošana

ATX barošanas avots: [ATXPWR1], [ATX12V1]
VENTILATORA savienotāji: [CPUFAN1], [SYSFAN1],

[AUXFAN1], [NBFAN1]
Priekšējā paneļa savienotāji: [FPIO1]

• [HLED]: Pievieno HDD LED kabeli.

• [RST]: Pievieno atiestates slēdža kabeli.

• [SPKR]: Pievieno sistēmas skaļruņa kabeli.

• [SLED]: Pievieno LED pārtraukšanas kabeli.

• [PWR] (Barošana): Pievieno barošanas slēdža kabeli.

• [PLED]: Pievieno barošanas LED kabeli.

Papildu USB porta galvene: [FP-USB1], [FP-USB2]
Papildu IEEE1394 porta galvene: [FP-1394-1], [FP-1394-2]
Priekšējā paneļa audio savienotāja galvene: [FP-AUDIO1]
Iekšēji audio savienotāji: [CD1], [AUX1]

Centrālā procesora un karstuma iegrimes bloka instalēšana

Tā kā izvēlei tiek piedāvāti vairāki centrālā procesora un tā
karstuma iegrimes bloka veidi, katrs ar atšķirīgu instalēšanas
paņēmienu, ievērojiet precīzi instalēšanas norādes, kuras varat
meklēt pirkuma paketē. Centrālais procesors ir smalka
elektroniska ierīce, kas darbības laikā rada lielu karstumu.
Ievērojiet īpašu uzmanību.

Pēc karstuma iegrimes bloka uz procesora instalēšanas
pabeigšanas pievienojiet centrālā procesora dzesēšanas
ventilatoru barošanu [CPUFAN1] savienotājam uz mātesplates.

Atmiņas moduļu instalēšana

• Nospiediet aizturus abās slota pusēs uz leju.

• Pieskaņojiet atmiņas moduli slotam. Slots ir iezīmēts ar

ierobu, un atmiņas modulis ir iezīmēts ar izgriezumu,
tādējādi tie ir salāgojami tikai vienā virzienā.

• Instalējiet atmiņas moduli slotā, stingri to nospiežot uz leju.

Slots automātiski noslēdz slēdzējus uz augšu un nostiprinās
atmiņas moduļa malās.

• Lai izņemtu atmiņas moduli, vienlaikus nospiediet aizturus

abās slota pusēs uz leju un izvelciet atmiņas moduli.

Uzglabāšanas ierīču pievienošana

Disketes diskdziņa pievienošana: [FDC1]
IDE cieto diskdziņu pievienošana: [IDE1], [IDE2]
Seriālā ATA cietā diska diskdziņu pievienošana: [SATA1] ~

[SATA4]

Aizmugures paneļa savienojums

• Mouse: Pievieno PS/2 peli.

• Keyboard: Pievieno PS/2 klaviatūru.

• LPT1: Pievieno printeri vai citas iekārtas, kas atbalsta

paralēldarbības komunikācijas protokolu.

• COM1: Pievieno ārējo modemu, peli vai citas ierīces, kas

atbalsta seriālās komunikācijas protokolu.

• OPT-IN1: Savienotājs nodrošina S/PDIF ieejas pieslēgumu

ar optiskās šķiedras vadu no ciparu multimediju ierīcēm.

• OPT-OUT1: Savienotājs nodrošina S/PDIF izejas

pieslēgumu ar optiskās šķiedras vadu uz ciparu multimediju
ierīcēm.

• AUDIO1: Savienotājs nodrošina 7.1 kanālu skaņas

ieejas/izejas pieslēgumu.

• IEEE1394: Pievieno IEEE1394 protokola ierīces

• LAN1: Savienojums ar lokālo tīklu.

• USB1/USB2: Pievieno USB ierīces, piemēram, skeneri,

ciparu skaļruņus, monitoru, peli, klaviatūru, centrmezglu,
ciparu kameru, kursorsviru.

4-8 AN52S/AN52

4.9 Lietuvių//Trumpas instaliavimo vadovas

Šiame “Trumpame instaliavimo vadove” pateikta tik esminė
informacija apie techninę įrangą, kurios jums gali prireikti
instaliuojant pagrindinę plokštę abit. Papildomų operacijų
aprašymą rasite pilnoje vadovo versijoje.

Atsargumo priemonės instaliuojant techninę įrangą

• Prieš instaliuodami plokštę ar keisdami parametrus visuomet

išjunkite maitinimą ir ištraukite laidą iš elektros rozetės.

• Prieš išimdami plokštę iš antistatinio įpakavimo gerai

įsižeminkite antistatiniu saugos raiščiu ant riešo.

• Laikykite plokštę už kraštų. Stenkitės neliesti jos

komponentų.

• Stenkitės neliesti modulio kontaktų ir IC lustų.

• Dėkite plokštę ant įžeminto antistatinio paviršiaus ar

antistatinio plokštės įpakavimo.

Plokštės montavimas į korpusą

Privalomos kompiuterio korpuso savybės:

• Jis turi būti suderinamas su šios pagrindinės plokštės forma.

• Visi korpuso indikatoriai ir jungikliai turi būti suderinami su

šios pagrindinės plokštės kabeliais.

• Turi pakakti galingumo ir erdvės visiems diskasukiams,

kuriuos manote instaliuoti.

• Korpuso įeigos/išeigos (I/O) šablonai užpakaliniame

panelyje turi atitikti pagrindinės plokštės I/O prievadus ir
plėtros griovelius.

Instaliuojant pagrindinę plokštę į korpusą reikia:

• Nukreipti I/O prievadų kraštus į užpakalinę korpuso dalį.

• Rasti varžtų angas ant pagrindinės plokštės ir korpuso

pagrindo.

• Sudėlioti visus reikiamus varžtus ar tarpiklius į korpuso

pagrindą ir juos užveržti.

• Visas varžtų angas ant pagrindinės plokštės sujungti su

varžtais ar tarpikliais korpuso pagrinde.

• Užveržti varžtus.

Trumpam PCB sujungimui išvengti prašome IŠIMTI
metalinius varžtus ar tarpiklius, jei tokių yra korpuso
pagrinde, o pagrindinėje plokštėje nėra juos atitinkančių
montažinių angų.

Jungė CMOS ištrinti

Ši jungė yra naudojama CMOS atminčiai ištrinti, kad būtų
galima atitaisyti BIOS turinį. Ištrinti CMOS atmintį gali prireikti,
jei BIOS nuostatos yra neteisingos ir dėl to neveikia pagrindinė
plokštė.

Norėdami ištrinti CMOS atmintį, atjunkite nuo pagrindinės
plokštės visus maitinimo kabelius, keletai sekundžių sujunkite
jungės trinkelę su aptaisu “Ištrinti CMOS”, o po to vėl įjunkite
jungės trinkelę į jos “Normos” aptaisą. Po to vėl įjunkite
maitininimą ir įkelkite kompiuterį iš naujo - BIOS turinys grįš į
pradinę numatytąją sąranką.

Korpuso komponentų sujungimas

ATX elektros tiekimas: [ATXPWR1], [ATX12V1]
VĖDINTVŲ jungtys: [CPUFAN1], [SYSFAN1], [AUXFAN1],

[NBFAN1]
Priekinio panelio jungtys: [FPIO1]

• [HLED]: Sujunkite su HDD LED kabeliu.

• [RST]: Sujunkite su pakartotinos kelties jungiklio kabeliu.

• [SPKR]: Sujunkite su sistemos garsiakalbio kabeliu.

• [SLED]: Sujunkite su darbo pristabdymo indikatoriaus

kabeliu.

• [PWR]: Sujunkite su maitinimo tinklo jungiklio kabeliu.

• [PLED]: Sujunkite su maitinimo indikatoriaus kabeliu.

Papildomas USB prievado antgalis: [FP-USB1], [FP-USB2]
Papildomas IEEE1394 prievado antgalis: [FP-1394-1],

[FP-1394-2]
Audio jungties antgalis priekiniame panelyje: [FP-AUDIO1]
Vidinės audio jungtys: [CD1], [AUX1]

CPU ir šilumos šalinimo bloko instaliavimas

Esant dideliam centrinių procesorių (CPU) ir jų šilumos šalinimo
blokų pasirinkimui, kai kiekvienas iš jų yra instaliuojamas savaip,
prašome tiksliai laikytis instaliavimo instrukcijų, lydinčių jūsų
pirkinį. CPU yra subtilus elektroninis įrenginys, darbo metu
išskiriantis didelį šilumos kiekį. Instaliavimo operacijas prašome
atlikti ypatingai įdėmiai.

Sumontavę šilumos šalintoją į procesorių sujunkite CPU
vėdintuvo maitinimą su [CPUFAN1] jungtimi ant pagrindinės
plokštės.

Atminties modulių instaliavimas

• Nuspauskite spragtukus abiejose griovelio pusėse žemyn.

• Nukreipkite atminties modulį į griovelį. Griovelyje yra

dantukas, o atminties modulyje yra išpjova, todėl jie sutampa
tik vienoje padėtyje.

• Tvirtai spausdami žemyn įstatykite atminties modulį į griovelį.

Griovelio spragtukai automatiškai pakyla ir užsišauna ant
atminties modulio kraštų.

• Norėdami išimti atminties modulį tuo pat metu nuspauskite

abu griovelio spragtukus ir ištraukite atminties modulį.

Duomenų saugojimo įrenginių sujungimas

Diskelių diskasukio sujungimas: [FDC1]
Standžiojo disko IDE sujungimas: [IDE1], [IDE2]
Nuosekliųjų standžiųjų diskų ATA sujungimas: [SATA1] ~

[SATA4]

Užpakalinio panelio sujungimai

• Mouse: Sujunkite su PS/2 pele.

• Keyboard: Sujunkite su PS/2 klaviatūra.

• LPT1: Sujunkite su spausdintuvu ar kitais įrenginiais,

palaikančiais lygiagretaus ryšio protokolą.

• COM1: Sujunkite su išoriniu modemu, pele ar kitais

įrenginiais, palaikančiais nuoseklaus ryšio protokolą.

• OPT-IN1: Šia jungtimi S/PDIF įvadas optiniu kabeliu

jungiamas nuo skaitmeninių multimedijos prietaisų.

• OPT-OUT1: Šia jungtimi S/PDIF išvadas optiniu kabeliu

jungiamas prie skaitmeninių multimedijos prietaisų.

• AUDIO1: Šia jungtimi prijungiami 7.1-channel garso įvadas

ir išvadas.

• IEEE1394: Sujunkite su IEEE1394 protokolo įrenginiais.

• LAN1: Sujunkite su vietiniu tinklu.

• USB1/USB2: Sujunkite su tokiais USB įrenginiais, kaip

skeneris, skaitmeniniai garsiakalbiai, vaizduoklis, pelė,
klaviatūra, koncentratorius, skaitmeninis fotoaparatas,
valdymo svirtis ir pan.

Multilingual QIG

AN52S/AN52 4-9

4.10 Polski//Instrukcja szybkiej instalacji

Ta “Instrukcja szybkiej instalacji” zawiera tylko
podstawowe informacje dotyczące sprzętu, wymagane
podczas instalacji płyty głównej abit. Przy
zaawansowanych operacjach, niezbędne będzie
skorzystanie z kompletnej wersji instrukcji.

Środki bezpieczeństwa przy instalacji sprzętu

• Przed instalacją płyty lub zmianą jakichkolwiek ustawień,

należy zawsze wyłączyć zasilanie i odłączyć przewód
zasilający od źródła zasilania prądem zmiennym.

• Przed wyjęciem płyty z opakowania antystatycznego, należy

się odpowiednio uziemić zakładając antystatyczną
nadgarstkową taśmę ochronną.

• Płytę należy trzymać za brzegi. Nie dotykać komponentów

płyty.

• Nie dotykać styków modułów i układów elektronicznych IC.

• Płytę należy umieścić na uziemionej antystatycznej

powierzchni lub na antystatycznym opakowaniu, w którym
dostarczona była płyta.

Instalacja płyty w obudowie

Obudowa komputera, w której instalowana będzie płyta,
powinna:

• Być przystosowana do rozmiarów tej płyty.

• Obsługiwać wyprowadzenia wszystkich złączy kablowych

płyty głównej na wskaźniki i przełączniki obudowy.

• Zapewniać odpowiednie zasilanie i miejsce dla wszystkich

napędów, jakie mają zostać zainstalowane.

• Mieć dostosowaną budowę I/O panela tylnego do portów I/O

oraz do gniazd rozszerzeń płyty głównej.

Aby zainstalować płytę główną w obudowie, należy:

• Ustawić płytę stroną z portami I/O w kierunku tylnej części

obudowy.

• Zlokalizować otwory na śruby w płycie głównej i w podstawie

obudowy.

• Ustawić wszystkie podkładki i pierścienie dystansowe

wymagane do instalacji płyty w obudowie i dokręcić je.

• Wyrównać wszystkie otwory na śruby w płycie głównej z

podkładkami i pierścieniami dystansowymi obudowy.

• Dokręcić wszystkie śruby montażowe.

Aby zapobiec zwarciu obwodu PCB, należy USUNĄĆ
metalowe podkładki lub pierścienie dystansowe
zainstalowane w podstawie obudowy, ale nie pasujące do
otworów montażowych płyty głównej.

Zerowanie zworki CMOS

Zworka ta służy do zerowania pamięci CMOS, w celu
skasowania zawartości BIOS. Zerowanie pamięci CMOS może
być potrzebne, jeżeli ustawienia BIOS są nieprawidłowe i
uniemożliwiają działanie płyty głównej.

Aby wyzerować pamięć CMOS, należy odłączyć od płyty
głównej wszystkie kable zasilające i nałożyć na kilka sekund
nasadkę zworki zgodnie z ustawieniem “Zerowanie CMOS
(Clear CMOS)”, a następnie założyć nasadkę zworki z
powrotem, zgodnie z ustawieniem “Normalne (Normal)”. Po
ponownym podłączeniu przewodów zasilających i uruchomieniu
komputera, zostanie przywrócona konfiguracja domyślna BIOS.

Podłączanie elementów obudowy

Zasilacz ATX: [ATXPWR1], [ATX12V1]
Złącza WENTYLATOR (FAN): [CPUFAN1], [SYSFAN1],

[AUXFAN1], [NBFAN1]
Złącza panela przedniego: [FPIO1]

• [HLED]: Podłączenie kabla HDD LED.

• [RST]: Podłączenie kabla przełącznika restartu.

4-10 AN52S/AN52

• [SPKR]: Podłączenie kabla głośnika systemowego.

• [SLED]: Podłączenie kabla diody LED wstrzymania pracy.

• [PWR]: Podłączenie kabla przełącznika zasilania.

• [PLED]: Podłączenie kabla diody LED zasilania.

Dodatkowy blok połączeń portu USB: [FP-USB1],
[FP-USB2]

Dodatkowy blok portu IEEE1394: [FP-1394-1], [FP-1394-2]
Blok połączeń audio panela przedniego: [FP-AUDIO1]
Wewnętrzne złącza audio: [CD1], [AUX1]

Instalacja procesora i zespołu chłodzącego

Istnieje wiele typów CPU (Central Processing Unit [Procesora
głównego]) i ich zespołów chłodzących, z których każdy
wymaga innego sposobu instalacji, należy dokładnie stosować
się do instrukcji instalacji znajdującej się w opakowaniu
zakupionego pakietu. Procesor jest delikatnym urządzeniem
elektronicznym wytwarzającym podczas działania duże ilości
ciepła. Podczas jego instalacji należy zachować szczególną
ostrożność.

Po zakończeniu instalacji zespołu chłodzącego procesora,
podłącz wentylator chłodzący procesora do złącza [CPUFAN1]
na płycie głównej.

Instalacja modułów pamięci

• Naciśnij w dół zatrzaski po obu stronach gniazda.

• Dopasuj położenie modułu pamięci do gniazda. Gniazdo ma

karb a moduł wycięcie, umożliwiające wyłącznie jeden
kierunek połączenia.

• Zainstaluj moduł pamięci w gnieździe mocno naciskając

moduł w dół. Dźwignie zatrzasków gniazda automatycznie
uniosą się w górę blokując krawędzie modułu pamięci.

• Aby wyjąć moduł pamięci, naciśnij jednocześnie zatrzaski po

obu stronach gniazda, a następnie wyjmij moduł pamięci.

Podłączanie urządzeń pamięci

Podłączanie napędu dyskietek elastycznych: [FDC1]
Podłączanie napędów dysku twardego IDE: [IDE1], [IDE2]
Podłączanie napędów dysku twardego Serial ATA: [SATA1]

~ [SATA4]

Połączenia panela tylnego

• Mouse: Podłączenie myszy PS/2.

• Keyboard: Podłączenie klawiatury PS/2.

• LPT1: Podłączenie drukarki lub innych urządzeń

obsługujących protokół komunikacji równoległej.

• COM1: Podłączenie zewnętrznego modemu, myszy lub

innych urządzeń obsługujących protokół komunikacji
szeregowej.

• OPT-IN1: To złącze umożliwia podłączenie do S/PDIF,

poprzez światłowód z cyfrowego urządzenia
multimedialnego.

• OPT-OUT1: To złącze umożliwia podłączenie z S/PDIF,

poprzez światłowód z cyfrowego urządzenia
multimedialnego..

• AUDIO1: To złącze umożliwia połączenie wejście/wyjście

sygnału kanału audio 7.1.

• IEEE1394: Podłączenie urządzeń obsługujących protokół

IEEE1394.

• LAN1: Podłączenie do sieci lokalnej.

• USB1/USB2: Podłączenie urządzeń USB takich jak skaner,

głośniki cyfrowe, monitor, mysz, klawiatura, hub, kamera
cyfrowa, joystick itd.

4.11 Magyar//Gyorstelepítési útmutató

Ez a “Gyorstelepítési útmutató” csak azt az alapvető
hardver információt tartalmazza, amely az abit alaplap
telepítéséhez szükséges. Az előrehaladott üzemeltetéshez,
továbbra is a teljes útmutatót kell használnia.

Hardver beállítási óvintézkedések

• Minding kapcsolják ki a tápot ás áramtalanítsák a készüléket

az alaplap telepítése vagy a beállítások módosítása előtt.

• Mielőtt kivennék az alaplapot antisztatikus zacskójából,

biztonsági fémkarkötő segítségével földeljék le magukat.

• Az alaplapot csak széleinél fogják meg. Ne érintsék meg a

rajta lévő komponenseket.

• Ne érintsék meg a modul kontaktusait vagy az IC lapkákat

• Helyezzék az alaplapot leföldelt antisztatikus felületre vagy

arra az antisztatikus zacskóra amelyben csomagolva volt.

Az alaplap telepítése a házba

A számítógép háza a következő feltéteknek kell megfeleljen:

• Kell tudja fogadni ennek az alaplapnak az alakját.

• Támogatja az alaplap minden huzaljának, jelzőjének és

kapcsolójának a csatlakoztatását a házhoz.

• Képes kell legyen megfelelő tápot és teret biztosítani minden

telepíteni kívánt meghajtónak.

• A hátlapon lévő I/O idomszernek illeszkednie kell az alaplap

I/O portjaihoz és bővítő-helyeihez.

Az alaplap beszerelésére a házba a következőképpen kell
eljárni:

• Az I/O portos oldalt irányítsa a ház hátsó része felé.

• Azonosítsák be a csavarok helyét az alaplapon és a ház

alsó részén.

• Helyezzenek bele a ház alapjába minden érintkező-peceket

vagy távtartót és szorítsák meg őket.

• Állítsák síkba az alaplapon lévő minden csavarrést a házon

lévő érintkező-pecekekkel vagy távtartókkal.

• Szorítsanak meg minden csavart.

Annak érdekében, hogy megelőzzék a NYÁK rövidre
zárását, kérjük TÁVOLÍTSÁK el minden érintkező-peceket
vagy távtartót amennyiben ezek már rá vannak szerelve a
ház alapjára és ezen az alaplapon nincsenek olyan
illesztések amelyekkel síkba kellene hozni.

Törlő CMOS átkötés

Ennek az átkötésnek a szerepe a CMOS memória törlése,
amely lehetővé teszi a BIOS tartalmának reszettelését.
Szükség lehet a CMOS memória törlésére, amennyiben a BIOS
beállítások nem megfelelőek, és így lehetetlenné teszik az
alaplap használatát.

A CMOS memória törléséhez, bontsanak minden tápot az
alaplappal, csatlakoztassák az átkötés végét a „CMOS törlése”
ponthoz néhány másodpercre, majd csatlakoztassák vissza az
átkötést a „Normális” ponthoz. Miután ismét bekötik a tápot és
újraindítják a gépet, a BIOS visszaáll az alapértelmezett
konfigurációba.

Készülékház komponenseinek csatlakoztatása

ATX táp: [ATXPWR1], [ATX12V1]
Ventilátor csatlakozók: [CPUFAN1], [SYSFAN1], [AUXFAN1],

[NBFAN1]
Előlap csatlakozók: [FPIO1]

• [HLED]: Csatlakoztassa a HDD LED kábelhez.

• [RST]: Csatlakoztassa a reszettelés-kapcsoló kábeléhez.

• [SPKR]: Csatlakoztassa a rendszerhangszóró kábeléhez.

• [SLED]: Csatlakoztassa a LED szüneteltet kábelhez

AN52S/AN52 4-11

• [PWR]: Csatlakoztassa a tápkapcsoló kábelhez.

• [PLED]: Csatlakoztasson a táp LED kábelhez

Kiegészítő USB port fejrész: [FP-USB1], [FP-USB2]
További IEEE1394 port fejek: [FP-1394-1], [FP-1394-2]
Előlap audio csatlakoztatási fej: [FP-AUDIO1]
Belső audio csatlakozók: [CD1], [AUX1]

CPU és a hűtőborda telepítése

Mivel többféle központi egység (CPU) és hűtőborda közül lehet
választani és mivel mindegyiket másképpen kell beszerelni,
kérjük kövessék pontosan az Önök által vásárolt csomagban
lévő szerelési utasításokat. A központi egység (CPU) kényes
elektronikus eszköz amely működése közben nagyon sok hőt
termel. Kérjük járjanak el kiemelt gondossággal.

Miután rászerelték a hűtőbordát a processzorra,
csatlakoztassák a CPU hűtőventilátorának a csatlakozóját
[CPUFAN1] az alaplap csatlakozójához.

Memóriamodulok telepítése

• A rés mindkét oldalán lévő reteszeket nyomják lefelé.

• A memóriamodult hozzák síkba a nyílással. A rés ékes

bemetszésű, és a memóriamodul úgy van kialakítva, hogy
csak egyféleképpen, egy irányba lehet beilleszteni.

• Helyezzék a memóriamodult a résbe és nyomják

határozottan lefelé. A rés reteszei automatikusan felfelé
mozdulnak el, majd rákattannak a memóriamodul széleire.

• A memóriamodul eltávolításához a rés mindkét oldalán lévő

reteszeket nyomják egyszerre lefelé, majd húzzák ki a
memóriamodult.

Tárolóegységek csatlakoztatása

Hajlékonylemez meghajtó csatlakoztatása: [FDC1]
IDE merevlemezek csatlakoztatása: [IDE1], [IDE2]
Soros ATA merevlemez meghajtók csatlakoztatása: [SATA1]

~ [SATA4]

Hátlapi csatlakozások

• Mouse: csatlakoztassa a PS/2 egeret.

• Keyboard: csatlakoztassa a PS/2 billentyűzetet.

• LPT1: csatlakozzon a nyomtatóhoz vagy egyéb

eszközökhöz amelyek támogatják a párhuzamos
kommunikációs protokollt.

• COM1: csatlakozzon a külső modemhez, egérhez vagy

egyéb eszközökhöz amelyek támogatják a soros
kommunikációs protokollt.

• OPT-IN1: Ez a csatlakozó S/PDIF bemeneti csatlakozást

biztosít digitális multimédiás eszközök által kibocsátott jel
fogadására, optikai kábel segítségével.

• OPT-OUT1: Ez a csatlakozó S/PDIF kimeneti csatlakozást

biztosít digitális multimédiás eszközök által fogadott jel
küldéséhez, optikai kábel segítségével.

• AUDIO1: Ez a csatlakozó 7.1 csatornás audió

bemeneti/kimeneti jelhez.

• IEEE1394: Csatlakoztassa az IEEE1394 protokoll szerinti

eszközökhöz.

• LAN1: Csatlakoztassa a helyi hálózathoz.

• USB1/USB2: Csatlakoztassa az olyan USB eszközökhöz,

mint a szkenner, digitális hangszórók, monitor, egér,
billentyűzet, központi elosztóhoz, digitális fényképezőgéphez,
botkormányhoz, stb.

Multilingual QIG

4.12 Türkçe//Hızlı Kurulum Kılavuzu

Bu “Hızlı Kurulum Kılavuzu”, abit anakartınızı takmanızda
gerekebilecek sadece temel donanım bilgisini içermektedir.
İleri işlemler için daha geniş olan tam versiyonuna
başvurmanız gerekecektir.

Donanım Kurmada Alınacak Önlemler

• Anakartı takmadan veya ayarları değiştirmeden önce daima

güç beslemeyi kapatarak güç kablosunu elektrik prizinden
çekin.

• Anakartı antistatik poşetinden çıkartmadan önce bileğinize

takacağınız bir statik güvenlik bandıyla uygun şekilde
kendinize topraklama yapınız.

• Anarkatı kenarlarından tutun. Üzerindeki herhangi bir

bileşene dokunmaktan sakının.

• Modül kontaklarına ve IC yongalarına dokunmaktan sakının.

• Anakartı topraklaması yapılmış antistatik bir yüzeye veya

beraberinde verilen antistatik torbanın üzerine koyun.

Anakartın Kasaya Takılması

Bu anakart için bilgisayar kasası şu aşağıdaki özellikleri
desteklemelidir:

• Bu anakartın biçim faktörüne uyumlu olmalı.

• Anakart üzerinden kasa üzerindeki gösterge ve anahtarlara

yapılan kablolama konnektörlerinin tümünü desteklemeli.

• Kuracağınız tüm sürücüler için yeterli güç ve yeri

sağlayabilmeli.

• Arka panelindeki I/O (Giriş/Çıkış) şablonu anakart üzerindeki

I/O (Giriş-Çıkış) bağlantı noktaları ve genişleme yuvalarıyla
eşleşmelidir.

Anakartı kasaya takmak için aşağıdaki talimatları izleyin:

• I/O bağlantı noktalarının kenarını kasanın arka kısmına

bakacak şekilde hizalayın.

• Anakart ve kasa kaidesi üzerindeki cıvata yuvalarının yerini

belirleyin.

• Kasa kaidesi üzerine gerekli tüm destek pimi ve ara

parçalarını yerleştirin ve sıkılayın.

• Anakart üzerindeki bütün bu cıvata deliklerini kasa

üzerindeki destek pimi veya ara parçalarıyla hizalayın.

• Tüm cıvataları sıkılayın.

PCB devresinin kısa devre yapmasını önlemek için
önceden kasa kaidesinde takılı ve anakart üzerindeki
montaj delikleriyle hizalanmayan metal destek pimi ve ara
parçaları ÇIKARTIN.

CMOS Silme Jumperı (Atlatıcısı )

Bu jumper BIOS içeriğini sıfırlamak için CMOS belleğini silmede
kullanılır. BIOS ayarlarınız hatalıysa ve anakartınızın
çalışmasına engel oluyorsa CMOS belleğini silmeniz
gerekebilir.

CMOS belleğini silmek için anakarttan çıkan tüm güç kablolarını
ayırınız, jumper kepini bir kaç saniye süreyle "Clear CMOS"
(CMOS'u Sil) ayarı üzerine takın ve ardından jumper kepini
"Normal" ayarına takın. Tüm güç kablolarını yeniden bağlayıp
bilgisayarı yeniden başlattıktan sonra BIOS içeriği varsayılan
yapılandırmasına döner.

Kasa Bileşenlerinin Bağlanması

ATX Güç Kaynağı: [ATXPWR1], [ATX12V1]
FAN Konnektörleri: [CPUFAN1], [SYSFAN1], [AUXFAN1],

[NBFAN1]

Ön Panel Konnektörleri: [FPIO1]

• [HLED]: Sabit Disk Sürücü LED kablosuna bağlayın.

• [RST]: Sıfırlama Anahtarı kablosuna bağlayın.

• [SPKR]: Sistem Hoparlör kablosuna bağlayın.

• [SLED]: Askıda LED’i kablosuna bağlayın.

• [PWR]: Güç Anahtarı kablosuna bağlayın.

• [PLED]: Güç LED’i kablosuna bağlayın.

Ek USB Bağlantı Noktası Başlığı: [FP-USB1], [FP-USB2]
Ek EEE1394 Bağlantı Noktası Başlığı: [FP-1394-1],

[FP-1394-2]
Ön Panel Ses Bağlantı Başlığı: [FP-AUDIO1]

Dahili Ses Konnektörleri: [CD1], [AUX1]

CPU ve Soğutucu (Heatsink) Montaj Grubunun Takılması

Tercihe bağlı Merkezi İşlem Ünitesi (CPU) ve soğutucu montaj
grubu seçeneklerinin farklı takma prosedürleri olduğundan,
lütfen satın aldığınız ürünün paketinden çıkan takma
talimatlarını tam olarak takip ediniz. CPU çalışırken büyük
miktarda ısı çıkaran hassas bir elektronik aygıttır. Lütfen işlem
yaparken özen gösterin.

Soğutucuyu mikroişlemcinin üzerine takma işlemini
tamamladıktan sonra CPU soğutucu fanı güç bağlantısını ana
kart üzerindeki [CPUFAN1] konnektörüne bağlayın.

Bellek Modüllerinin Takılması

• Yuvanın iki tarafındaki mandalları aşağı bastırın.

• Bellek modülünü yuvaya hizalayın. Yuvanın çentik kılavuzu

ve bellek modülünün bir bölüm kertiği kılavuzu vardır ve
sadece bir yönde birbirine uyarlar.

• Bellek modülünü yuvaya kuvvetlice bastırarak oturtun. Yuva

mandalları otomatik olarak kalkar ve bellek modülünün
kenarlarını tutar.

• Bellek modülünü çıkarmak için her iki taraftaki mandal aynı

anda bastırın ve bellek modülünü çekerek çıkartın.

Depolama Aygıtlarının Bağlanması

Disket Sürücüsünün Bağlanması: [FDC1]
IDE Sabit Disk Sürücülerinin Bağlanması: [IDE1], [IDE2]
Seri ATA Sabit Disk Sürücülerin Bağlanması [SATA1] ~

[SATA4]

Arka Panel Bağlantısı

• Mouse: PS/2 fare bağlamak içindir.

• Keyboard: PS/2 klavye bağlamak içindir.

• LPT1: Yazıcı veya paralel iletişim protokolünü destekleyen

diğer aygıtları bağlamak içindir.

• COM1: Harici modem, fare veya seri iletişim protokolünü

destekleyen diğer aygıtları bağlamak içindir.

• OPT-IN1: Bu konektör optik fiber aracılığıyla dijital

multimedya aygıtları için S/PDIF giriş bağlantısı sağlar.

• OPT-OUT1: Bu konektör optik fiber aracılığıyla multimedya

aygıtları için S/PDIF çıkış bağlantısı sağlar.

• AUDIO1: Bu konektör 7.1 kanallı ses giriş/çıkış bağlantısı

sağlar.

• IEEE1394: IEEE1394 protokolü aygıtlarına bağlantı içindir.

• LAN1: Yerel Ağa bağlantı içindir.

• USB1/USB2: Tarayıcı, dijital hoparlör, monitör, fare, klavye,

dijital kamera, joystick vb. gibi USB aygıtlarını bağlamak
içindir.

4-12 AN52S/AN52

4.13 ﺔﻴﺑﺮﻌﻟا ﺔﻐﻠﻟا//ﻊﻳﺮﺴﻟا ﺐﻴآﺮﺘﻟا ﻞﻴﻟد

AN52S/AN52 4-13

Multilingual QIG

4.14 ﯽﺳرﺎﻓ //ﻊﻳﺮﺳ ﺐﺼﻧ ﯼﺎﻤﻨهار

4-14 AN52S/AN52

4.15 日本語//クイックインストールガイド

この「クイックインストールガイド」には、abit マ
ザーボードを取り付けるときに必要となるハードウ
ェアの基本情報のみが含まれています。詳細な操作
については、その完全版を参照してください。

ハードウェアのセットアップに関する注意事項

• ボードを取り付けたり設定を変更するときは、事前に

電源装置をオフにし、AC コンセントからプラグを必
ず抜いてください。

• 静電気防止バッグからボードを取り外す前に、静電気

安全リストストラップを着用して、正しくアースして
ください。

• ボードは、端を持つようにしてください。コンポーネ

ントには触れないでください。

• モジュールの接点や IC チップには触れないでくださ

い、

• ボードはアースされた静電気防止面またはボードに

付属する静電気防止バッグの上に置いてください。

ボードのシャーシへの取り付け

このマザーボードのコンピュータシャーシは、以下の点
を満たしている必要があります。

• このマザーボードのフォームファクタに適合するこ

と。

• シャーシのインジケータやスイッチとマザーボード

上のすべてのケーブルコネクタをサポートすること。

• 取り付けるすべてのドライブに対して、十分な電力と

スペースを提供可能なこと。

• 背面パネルのその I/O テンプレートが、マザーボード

の I/O ポートと拡張スロットに一致すること。
マザーボードをシャーシに取り付けるには、次の手順に
従う必要があります。

• I/O ポートの側面をシャーシの背面部分に向ける。

• マザーボードとシャーシ台のネジ穴を探す。

• 必要なすべてのスタッドやスペーサーをシャーシ台

に置き、しっかり締め付ける。

• マザーボードのすべてのネジ穴をシャーシのこれら

のスタッドやスペーサーと一列に並べる。

• すべてのネジ穴をしっかり締める。

PCB 回路がショートしないように、スタッドやスペーサ
ーがシャーシ台にすでに取り付けられ一致する取り付け
穴がこのマザーボードにない場合、それらのスタッドや
スペーサーを取り外してください。

CMOS ジャンパの消去

このジャンパは CMOSメモリを消去して BIOS の内容を
リセットするために使用されます。BIOS 設定が間違っ
ているためにマザーボードが作動しない場合、CMOS メ
モリを消去する必要があります。
CMOS メモリを消去するには、すべての電源ケーブルを
マザーボードから抜き、ジャンパキャップを「CMOS の
消去」設定に数秒間取り付け、その後ジャンパキャップ
をその「標準」設定に戻します。すべての電源を再び接
続し再起動すると、BIOS の内容はその初期設定にリセ
ットされます。

シャーシコンポーネントの接続

ATX 電源装置: [ATXPWR1]、[ATX12V1]

ファンコネクタ: [CPUFAN1], [SYSFAN1], [AUXFAN1],
[NBFAN1]

前面パネルコネクタ: [FPIO1]

• [HLED]: HDD LED ケーブルに接続

• [RST]: リセットスイッチケーブルに接続

AN52S/AN52 4-15

• [SPKR]: システムスピーカーケーブルに接続

• [SLED]: サスペンド LED ケーブルに接続

• [PWR]: 電源スイッチケーブルに接続

• [PLED]: 電源 LED ケーブルに接続

追加 USB ポートヘッダ: [FP-USB1]、[FP-USB2]

追加 IEEE1394 ポートヘッダ: [FP-1394-1]、[FP-1394-2]

前面パネルオーディオ接続ヘッダ: [FP-AUDIO1]

内部オーディオコネクタ: [CD1]、[AUX1]

CPU およびヒートシンクアセンブリの取り付け

中央処理装置(CPU)とそのヒートシンクアセンブリには、
それぞれ取り付ける方法が異なるタイプがあるため、お
買い求めになったパッケージの取付方法説明書に正確に
従ってください。CPU は精巧な電子装置で、動作時に大
量の熱を発生します。取り付けに当たっては、十分注意
してください。
プロセッサにヒートシンクを取り付けた後、CPU 冷却フ
ァンの電源をマザーボードの[CPUFAN1]コネクタに接
続します。

メモリモジュールの取り付け

• スロットの両側のラッチを下に押します。

• メモリモジュールをスロットに一直線に合わせます。

スロットはノッチに固定され、メモリモジュールは切
り出しに固定されるため、一方向にしかフィットしま
せん。

• メモリモジュールを下にしっかり押してスロットに

取り付けます。スロットラッチは上方向に自動的に動
き、メモリモジュールのエッジにパチンとはまります。

• メモリモジュールを取り外すには、スロットの両側の

ラッチを下に同時に押し、メモリモジュールを引き上
げます。

記憶装置の接続

フロッピーディスクドライブの接続: [FDC1]

IDE ハードドライブの接続: [IDE1]、[IDE2]

シリアル ATA ハードディスクドライブの接続: [SATA1] ~
[SATA4]

背面パネルの接続

• Mouse: PS/2 マウスに接続

• Keyboard: PS/2 キーボードに接続します。

• LPT1: プリンタ、またはパラレル通信プロトコルを

サポートするその他のデバイスに接続します。

• COM1: 外部モデム、マウス、またはシリアル通信プ

ロトコルをサポートするその他のデバイスに接続し
ます。

• OPT-IN1: このコネクタは、光ファーバーを通してデ

ジタルマルチメディアデバイスに S/PDIF イン接続を
提供します。

• OPT-OUT1: このコネクタは、光ファーバーを通して

デジタルマルチメディアデバイスに S/PDIFアウト接
続を提供します。

• AUDIO1: 7.1ch オーディオ 入力/出力 コネクター。

• IEEE1394: IEEE1394 プロトコルのデバイスに接続

します。

• LAN1: 構内通信網(LAN)に接続します。

• USB1/USB2: スキャナ、デジタルスピーカー、モニ

タ、マウス、キーボード、ハブ、デジタルカメラ、ジ
ョイスティックなどの USB デバイスに接続します。

Multilingual QIG

4.16 한국어//빠른 설치 가이드

본 “빠른 설치 가이드”는 빅빔 abit 메인보드
설치에 필요한 중요한 하드웨어 정보만을
포함하고 있습니다. 보다 상세한 정보 및 과정은
사용자 설명서를 참고하시기 바랍니다.

하드웨어 설치시 주의사항

• 메인보드 설치 또는 설정을 변경하시기 전에는

항상 전 원을 끄고, AC 콘센트를 제거하시기

바랍니다.

• 정전기 방지 비닐에서 메인보드를 빼 낼때는

정전기 안전 손목 접지대를 착용하고 메인보드의

가장 자리를 잡으시기 바랍니다.

• 컨넥터나 IC 류는 만지지 마십시오

• 메인보드를 정전기가 일어나지 않는 표면에

보관하거나 함께 제공된 정전기 방지 비닐에

보관하시기 바랍니다.

케이스에 대하여

구입하신 메인보드에 대한 컴퓨터 케이스는

• 메인보드 형태(form factor)에 맞는 케이스를

사용하시기 바랍니다.

• 메인보드 상의 모든 케이블이 연결될 수 있도록

연결 부를 지원해야만 합니다.

• 설치하려는 모든 드라이브에 대한 충분한 전원과

공간 을 제공할 수 있어야 합니다.

• 후면에 장착된 I/O 판넬이 메인보드에 제공되는 I/O

포트 와 확장 슬롯과 일치해야 합니다.
마더보드를 섀시에 설치하기 위해서:

• I/O 판넬의 측면을 컴퓨터 케이스 뒷부분을

향하도록 설치 합니다.

• 메인보드와 컴퓨터 케이스 바닥의 나사 구멍을

일치 시킵니다.

• 컴퓨터 케이스 바닥 위에 필요한 모든 볼트와

스페이서 를 위치시키고 고정합니다.

• 모든 나사 구멍을 고정합니다.

회로의 단선을 방지하기 위하여, 금속 볼트 혹은

PCB

스페이서들이 이미 컴퓨터 케이스 바닥에 설치되어
있고, 메인보드 상에 고정 홀이 없다면 이들을
제거하시기 바랍니다

.

CMOS 점퍼 지우기

이 점퍼는 롬 바이오스의 내용을 처음상태로 초기화
하기 위하여 롬 바이오스의 내용을 지우기 위한
점퍼입니다.
롬 바이오스 설정이 부정확하거나 메인보드 동작에
이상 이 있을 경우 롬 바이오스의 내용을 초기화 한
후 사용하시기 바랍니다.

롬 바이오스의 내용을 초기화하기 위해서는
메인보드에 연결된 모든 전원 케이블을 분리하고,
점퍼 캡을 약 30 초

동안 “CMOS 지움” 설정으로 변경한
후. 점퍼 캡을 다시 “정상” 설정으로 연결하십시오.
이후 모든 전원을 다시 연결하고 재부팅하면, 롬
바이오스 내용이 처음상태로 초기화될 것입니다.

컴퓨터 케이스 각종 컨넥터 연결

전원공급장치: [ATXPWR1], [ATX12V1]

팬 연결부: [CPUFAN1], [SYSFAN1], [AUXFAN1], [NBFAN1]

전면 판넬 연결 컨넥터: [FPIO1]

• [HLED]: HDD LED 케이블에 연결하세요.

• [RST]: 초기화 스윗치 케이블에 연결하세요.

4-16 AN52S/AN52

• [SPKR]: 시스템 스피커 케이블에 연결하세요.

• [SLED]: 유휴(Suspend) LED 케이블에 연결하세요.

• [PWR]: 전원 스위치 케이블에 연결하세요.

• [PLED]: 전원 LED 케이블에 연결하세요.

추가 USB 포트 헤더: [FP-USB1], [FP-USB2]

추가 IEEE1394 포트 헤더: [FP-1394-1], [FP-1394-2]

전면 판넬 오디오 연결 헤더: [FP-AUDIO1]

내부 오디오 연결부: [CD1], [AUX1]

CPU 및 방열판 설치

구입하신 프로세서에 따라 방열판 조립방법이 다를 수
있으므로 구입하신 패키지에서 지시하는 방법에 따라
정확하게 설치하시기 바랍니다. CPU 는 동작시 높은
양의 열을 발산하는 섬세한 전자 장치로 각별한
주의를 가지고 취급하시기 바랍니다.

프로세서 위에 방열판 설치를 마치고 나서, CPU 냉각
팬의 전원을 메인보드 상에 있는 [CPUFAN1] 연결부에
연결 하십시오.

메모리 모듈 설치

• 슬롯 양쪽에 있는 걸쇠를 눌러서 내리십시오.

• 메모리 모듈을 슬롯에 정렬시키십시오. 슬롯은

홈으로 구분되고, 메모리 모듈도 절단된 부분으로
구분되어 있어 오로지 한 방향으로만 맞습니다.

• 메모리 모듈을 강하게 눌러 슬롯에 설치시키십시오.

슬롯 걸쇠가 자동적으로 올라가고 메모리 모듈의
끝부분에 고정될 것입니다.

• 메모리 모듈을 제거하기 위해서는, 슬롯 양쪽에

있는 걸쇠를 동시에 눌러 내리십시오. 그러면
메모리 모듈이 빠질 것입니다.

저장 장치 연결

플로피 디스크 드라이브 연결: [FDC1]

IDE 하드 드라이브 연결: [IDE1], [IDE2]

시리얼 ATA 하드 디스크 드라이브 연결: [SATA1] ~

[SATA4]

후면 판넬 연결

• Mouse: PS/2 마우스에 연결하십시오.

• Keyboard: PS/2 키보드에 연결하십시오.

• LPT1: 프린터 혹은 병렬 통신 프로토콜을 지원하는

다른 장치들에 연결하십시오.

• COM1: 외부 모뎀, 마우스 혹은 시리얼 통신

프로토콜을 지원하는 다른 장치들에 연결하십시오.

• OPT-IN1: 이 커넥터는 디지털 멀티미디어 장치에서

옵티컬 파이버를 통한 S/PDIF 입력 연결을 제공합니
다.

• OPT-OUT1: 이 커넥터는 디지털 멀티미디어 장치로

옵티컬 파이버를 통한 S/PDIF 출력 연결을 제공합니
다.

• AUDIO1: 이 커넥터는 7.1 채널 오디오 입/출력 연결

을 제공합니다.

• IEEE1394: IEEE1394 프로토콜 장치들에 연결하십시오.

• LAN1: 근거리 통신망(LAN)에 연결하십시오.

• USB1/USB2: 스캐너, 디지털 스피커, 모니터, 마우스,

키보드, 허브, 디지털 카메라, 조이스틱 등과 같은
USB 장치들에 연결하십시오.

4.17 Bahasa Malaysia//Panduan Pemasangan Ringkas

“Panduan Pemasangan Ringkas” ini hanya mengandungi
maklumat perkakasan asas yang anda mungkin perlu
semasa memasang papan induk abit anda. Untuk
pengendalian lanjutan, anda perlu rujuk ke versi
lengkapnya.

Langkah Berjaga-jaga bagi Penyediaan Perkakasan

• Sentiasa matikan bekalan kuasa dan keluarkan kord kuasa

dari alur keluar AU sebelum memasang papan atau
menukarkan apa-apa pengesetan.

• Bumikan diri anda dengan sempurna dengan memakai

pengikat tangan keselamatan statik sebelum mengeluarkan
papan dari beg anti-statik.

• Pegang bahagian tepi papan.. Elak daripada menyentuh

apa-apa komponen di atasnya.

• Elak daripada menyentuh modul penghubung dan cip-cip IC.

• Letakkan papan pada permukaan anti statik yang telah

dibumikan atau di atas beg anti statik papan itu.

Memasang Papan Ke Casis

Casis komputer bagi papan induk ini harus:

• Menampung faktor bentuk papan induk ini.

• Menyokong semua kabel penyambung pada papan induk

termasuk penunjuk dan suis pada casis.

• Dapat membekalkan kuasa dan ruang yang mencukupi bagi

semua pemacu yang anda ingin pasang.

• Templat I/O di panel belakang sepadan dengan port I/O dan

lubang alur tambahan pada papan induk.

Untuk memasang papan induk ke dalam casis, anda harus:

• Hadapkan bahagian sisi port I/O ke bahagian belakang

casis.

• Kenal pasti lokasi lubang-lubang skru pada kedua-dua tapak

papan induk dan casis.

• Letakkan semua stad atau peruang yang diperlukan pada

tapak casis dan ketatkannya.

• Bariskan semua lubang skru di atas papan induk agar

sejajar dengan stad atau peruang pada casis.

• Ketatkan semua skru.

Untuk mengelak daripada berlaku litar pintas pada litar
PCB, sila KELUARKAN semua stad atau peruang logam
sekiranya ia sudah dipasang pada tapak casis dan tidak
ada lubang cagak untuk disejajarkan pada papan induk ini.

Padamkan Pelompat CMOS

Pelompat ini digunakan untuk memadamkan ingatan CMOS
untuk pengesetan semula kandungan BIOS. Anda mungkin
perlu memadamkan ingatan CMOS sekiranya pengesetan
BIOS tidak betul dan mengelak papan induk anda daripada
berfungsi.

Untuk memadamkan ingatan CMOS, tanggalkan semua kabel
kuasa dari papan induk, pasangkan tukup pelompat pada
pengesetan “Clear CMOS” untuk beberapa saat, kemudian
pasangkan semula tukup pelompat ke pengesetan “Normal”.
Selepas bekalan kuasa disambung semula dan anda telah
reboot komputer, kandungan BIOS akan diset semula kepada
tata rajah lalainya.

Menyambungkan Komponen-komponen Casis

Bekalan Kuasa ATX: [ATXPWR1], [ATX12V1]
Penyambung KIPAS: [CPUFAN1], [SYSFAN1], [AUXFAN1],

[NBFAN1]
Penyambung Panel Depan: [FPIO1]

• [HLED]: Sambungkan ke kabel HDD LED.

AN52S/AN52 4-17

• [RST]: Sambungkan ke kabel Suis Pengesatan Semula.

• [SPKR]: Sambungkan ke kabel Sistem Pembesar Suara.

• [SLED]: Sambungkan ke kabel Gantung LED.

• [PWR]: Sambungkan ke kabel Suis Kuasa.

• [PLED]: Sambungkan ke kabel Kuasa LED.

Port Kepala USB Tambahan: [FP-USB1], [FP-USB2]
Kepala Port Tambahan IEEE1394: [FP-1394-1], [FP-1394-2]
Panel Depan Kepala Penyambung Audio: [FP-AUDIO1]
Penyambung Audio Dalam: [CD1], [AUX1]

Memasang CPU dan Pasangan Penenggelam Haba

Oleh kerana terdapat pelbagai pilihan bagi Unit Pemprosesan
Pusat (CPU) dan pasangan penenggelam habanya, dan setiap
satu dengan cara pemasangan yang berlainan, sila ikut arahan
pemasangan yang terdapat pada bungkusan produk yang telah
dibeli, CPU merupakan satu peranti elektronik halus yang
mengeluarkan haba yang banyak semasa berfungsi. Sila
teruskan dengan berhati-hati.

Selepas pemasangan penenggelam siap dipasang pada
pemproses, sambungkan kuasa bagi pendingin kipas CPU
kepada penyambung [CPUFAN1] pada papan induk.

Memasang Modul Ingatan

• Tolak selak pada kedua-dua bahagian sisi slot ke bawah.

• Sejajarkan modul ingatan dengan slot. Slot akan berkunci

dengan takuk sementara modul ingatan akan berkunci
dengan potongan supaya ia hanya dapat dipasang dalam
satu arah.

• Pasangkan modul ingatan ke dalam slot dengan

menekannya ke bawah dengan kukuh. Slot akan menyelak
tuil ke atas secara automatik dan mencangkuk bahagian tepi
modul ingatan.

• Untuk mengeluarkan modul ingatan, tolak selak pada

kedua-dua bahagian slot ke bawah secara serentak,
kemudian tarik keluar modul ingatan.

Menyambung Peranti Storan

Menyambung Pemacu Cakera Liut: [FDC1]
Menyambung Pemacu Cakera Keras IDE: [IDE1], [IDE2]
Menyambungkan Pemacu Cakera Keras Bersiri ATA:

[SATA1] ~ [SATA4]

Sambungan Panel Belakang

• Mouse: Sambungkan ke tetikus PS/2.

• Keyboard: Sambungkan ke papan kekunci PS/2.

• LPT1: Sambungkan pencetak atau peranti-peranti yang

menyokong protokol komunikasi selari.

• COM1: Sambungkan ke modem luar, tetikus atau peranti

lain yang menyokong protokol komunikasi bersiri.

• OPT-IN1: Penyambung ini adalah sambungan masuk

S/PDIF melalui fiber optik dari alat-alat multimedia digital

• OPT-OUT1: Penyambung ini adalah sambungan keluar S/

PDIF melalui fiber optik ke alat-alat multimedia digital

• AUDIO1: Penyambung ini adalah audio 7.1-channel

sambungan masukan/keluaran

• IEEE1394: Sambungkan ke peranti yang berprotokol

IEEE1394.

• LAN1: Sambungkan ke Rangkaian Kawasan Tempatan

(LAN).

• USB1/USB2: Sambungkan ke peranti USB seperti

pengimbas , pembesar suara digital, monitor, tetikus, papan
kekunci, hab, kamera digital, kayu bedik dan sebagainya.

Multilingual QIG

4.18 ไทย//คู่มือการติดตั้งอย่างย่อ

ข้อมูลทางเทคนิคของอุปกรณ์ที่ปรากฎใน “คู่มือการ
ติดตั้งอย่างย่อ”นี้ เป็นเพียงข้อมูลพื้นฐานที่จำเป็นใน
การติดตั้งแผงวงจรหลัก abit ของคุณเท่านั้น กรุณา
อ่านข้อมูลในการติดตั้งและใช้งานในระดับสูงขึ้นจาก
คู่มือฉบับเต็มที่แนบมาด้วยเพื่อการติดตั้งและใช้งานที่
สมบูรณ์ที่สุด

สิ่งที่ควรระมัดระวังในระหว่างการติดตั้งอุปกรณ์

• ให้ปิดสวิทช์ไฟของเครื่องและถอดสายไฟออกจากผนังก่อน

การติดตั้งแผงวงจรหรือเปลี่ยนแปลงอุปกรณ์ใดเสมอ

• ทำการลดระดับไฟสถิตที่ร่างกาย โดยใช้สายถ่ายเทไฟฟ้า

สถิตย์หรือแตะที่ตัวถังส่วนที่เป็นโลหะ ก่อนนำเอาแผงวงจร
ออกจากซองกันไฟฟ้าสถิตย์

• กรุณาหลีกเลี่ยงการแตะอุปกรณ์ใดๆในแผงวงจรและสัมผัส

เฉพาะบริเวณขอบ

• หลีกเลี่ยงการแตะบริเวณที่เป็นตัวอุปกรณ์ IC และหน้าสัมผัส

ต่างๆ

• วางแผงวงจรในบริเวณที่ไม่มีไฟฟ้าสถิตย์หรือบนซองบรรจุ

ซึ่งสามารถป้องกันไฟฟ้าสถิตย์ที่บรรจุแผงวงจรมาเสมอ.

การติดตั้งแผงวงจรลงในตัวถังเครื่อง

ตัวถังเครื่องที่สามารถบรรจุแผงวงจรหลักนี้ควรจะ

• โครงสร้างตำแหน่งจุดยึดต่างๆที่รองรับกับแผงวงจรหลักนี้

• มีจุดต่อและขั้วต่อของสายแสดงสถานะและเปิดปิดที่ตรงกับ

แผงวงจรหลัก

• สามารถจ่ายกำลังไฟฟ้าเพียงพอและมีว่างพอในการติดตั้ง

อุปกรณ์ต่างๆ

• ด้านหลังต้องตรงกับตำแหน่งจุดต่อและช่องต่อเพิ่มของแผง

วงจรหลัก

ในการติดตั้งแผงวงจรหลัก กรุณาปฎิบัติและระมัดระวังดังนี้

• หันด้านจุดต่อของแผงวงจรหลักไปด้านหลังของตัวกล่อง

• หาตำแหน่งของรูจุดยึดทั้งบนแผงวงจรหลักและบนตัวกล่อง

• ใส่ตัวรองแท่นหรือที่รองที่จำเป็นให้เรียบร้อย

• วางตำแหน่งของรูจุดยึดของแผงวงจรให้ตรงกับจุดยึดต่างๆ

ที่อยู่บนแผงวงจรหลักพร้อมใส่ตัวยึดให้เรียบร้อย

• ไขตัวยึดต่างให้แน่นพอสมควรทุกจุด

เพื่อป้องกันการช๊อตของแผงวงจร กรุณาหลีกเลี่ยง
วางอุปกรณ์หรือชิ้นส่วนโลหะใดๆไว้ใกล้กับแผงวงจร
หลักหลังจากที่ติดตั้งจุดยึดแล้ว

จุดเชื่อมเพื่อการเคลียร์ CMOS

จุดเชื่อมนี้ใช้ในการลบข้อมูลของการกำหนดคุณสมบัติทำง
านของ BIOSเดิมที่อยู่ในหน่วยความจำแบบ CMOS
ให้เป็นค่าเดิมที่กำหนด โดยโรงงาน ในกรณีที่
ค่าที่กำหนดเอาไว้นั้นไม่ถูกต้องทำให้แผงวงจรหลักทำงาน
ไม่ได้ เมื่อต้องการลบหน่วยความจำ CMOS ให้ถอดสายไฟ
ที่จ่ายกำลังไฟฟ้าออกจากแผงวงจรหลัก แล้วนำตัวเชื่อม
สัญญาณ (Jumper) เลื่อนจากตำแหน่ง Normal ไปยัง
Clear CMOS ประมาณ 2-3 วินาที แล้วนำตัวเชื่อมกลับมา
ไว้ที่ตำแหน่ง Normal ดังเดิม หล

ังจากนั้นให้ต่อสายไฟทั้ง
หมดกลับเหมือนเดิมและเปิดเครื่อง ข้อมูลของ BIOS จะถูก
กำหนดใหม่ให้เป็นข้อมูลเดิมที่กำหนดจากโรงงาน

การต่อเข้าอุปกรณ์ของตัวถัง

จุดต่อแหล่งจ่ายไฟ: [ATXPWR1], [ATX12V1]
จุดต่อพัดลม: [CPUFAN1], [SYSFAN1],

[AUXFAN1], [NBFAN1]
จุดต่อกับหน้าปัด: [FPIO1]

• [HLED]: ต่อเข้ากับสาย HDD LED

• [RST]: ต่อเข้ากับสายปุ่ม Reset

• [SPKR]:ต่อเข้ากับสายลำโพงของระบบ

• [SLED]:ต่อเข้ากับสาย LED

• [PWR]: ต่อเข้ากับสายปุ่ม Power

• [PLED]:ต่อเข้ากับสาย LED แสดงสภาวะทำงานปกติ

ชุดจุดต่อ USB เพิ่มเติม: [FP-USB1], [FP-USB2]
ชุดจุดต่อ IEEE1394: [FP-1394-1], [FP-1394-2]
จุดต่อกับหน้าปัดส่วนระบบเสียง: [FP-AUDIO1]
จุดต่อสัญญาณเสียงภายใน: [CD1], [AUX1]

การติดตั้ง CPU และชุดระบายความร้อน CPU

เนื่องจาก CPU และชุดระบายความร้อนมีหลายแบบ ซึ่งแต่
ละแบบจะมีวิธีการติดตั้งแตกต่างกันไป กรุณาปฎิบัติตาม
คำแนะนำการตั้งที่มาพร้อมกับอุปกรณ์โดยละเอียด ข้อควร ระวัง

CPU

เป็นอุปกรณ์อิเลคทรอนิคส์ที่เมื่อมีการทำงานจะให้ความร้อนออ
กมาสูงมาก ดังนั้นต้องติดตั้งชุดระบายความร้อน
CPUให้ถูกต้องเพื่อป้องกันความเสียหายที่อาจเกิดขึ้น
เมื่อติดตั้งเรียบร้อยแล้วให้ต่อสายไฟเลี้ยงชุดระบายความ ร้อน
CPU เข้ากับจุดต่อ [CPUFAN1]

การติดตั้งแผงหน่วยความจำ

ไฟฟ้าสถิตย์สามารถทำลายอุปกรณ์อิเล็คทรอนิคส์ใน
คอมพิวเตอร์หรืออุปกรณ์อื่นๆได้ ดังนั้น ก่อนแตะต้อง
อุปกรณ์อิเล็คทรอนิคส์ใดๆให้ทำการลดไฟฟ้าสถิตย์ในร่างกาย
โดยทำการแตะที่ตัวถังก่อนติดตั้งแผง หน่วยความจำ

การติดตั้งอุปกรณ์เก็บข้อมูล

การต่อ Floppy Disk Drive: [FDC1]
การต่อ IDE Hard Drives: [IDE1], [IDE2]
การต่อ Serial ATA Hard Disk Drives: [SATA1] ~

[SATA4]

การต่ออุปกรณ์ด้านหลัง

• Mouse: ต่อกับเมาส์แบบ PS/2

• Keyboard: ต่อกับแป้นพิมพ์แบบ PS/2

• LPT1:

• COM1: ต่อกับโมเด็มภายนอก เมาส์ หรืออุปกรณ์อื่นที่

• OPT-IN1: จุดต่อนี้ใช้รับสัญญาณ S/PDIF

• OPT-OUT1: จุดต่อนี้ใช้ส่งสัญญาณ S/PDIF

• AUDIO1: จุดต่อสัญญาณเสียงเข้า/ออกแบบ 7.1

• IEEE1394: ต่อกับอุปกรณ์ที่ใช้การสื่อสารแบบ

• LAN1: ต่อกับระบบ Local Area Network.

• USB1/USB2: ต่อกับอุปกรณ์ USB เช่น สแกนเนอร์,

ที่แสดงสภาวะหยุดชั่วคราว

บนแผงวงจรหลัก

ต่อกับเครื่องพิมพ์หรืออุปกรณ์อื่นที่สื่อสารแบบขนาน

สื่อสารแบบอนุกรม

ผ่านทางสาย เส้น
ใยนำแสงกับอุปกรณ์มัลติมีเดียแบบดิจิตอล

ผ่านทางสาย
เส้นใยนำแสงกับอุปกรณ์มัลติมีเดียแบบดิจิตอล

ช่องทาง

IEEE1394

เมาส์, จอภาพ, ลำโพงดิจิตอล, แป้นพิมพ์,
กล้องถ่ายภาพดิจิตอล, กล้องถ่ายภาพยนต์ดิจิตอล, ฮับ,
จอยสติกส์ เป็นต้น

4-18 AN52S/AN52

4.19 繁體中文

4.19.1 規格

處理器

• 支援採用 Hyper Transport™技術、
2000MT/s 系統匯流排的AMD Socket
AM2 940 處理器

• 支援 AMD CPU Cool ‘n’ Quiet 技術

內部輸入/輸出接頭

晶片組

• NVIDIA NF520 單晶片

記憶體

• 4 條 240 針腳 DIMM 插槽支援最大 8GB
記憶體容量

• 支援雙通道DDR2 800 無緩衝ECC/非 ECC
記憶體

後面板輸入/輸出接頭

網路

• 內建 Gigabit 網路

音效

• 支援 7.1 聲道HD 音效

• 支援自動插孔偵測與自動重新指派音訊

插座功能

abit Engineered

Serial ATA

• 4 組 SATA 3Gb/s 支援 SATA RAID 0、1、
0+1、5 功能

擴充插槽

• 1 個 PCI-E X16 插槽

• 2 個 PCI-E X1 插槽

• 3 個 PCI 插槽

※ 本手冊的規格與資訊若有變動，恕不另行通知。

RoHS

其他

• 1 個軟碟埠

• 1 個 Ultra ATA 133 IDE 接頭

• 4 個 SATA 3Gb/s 接頭

• 3 個 USB 2.0 接頭

• 1 個 FP-Audio 接頭

• 1 個 CD-In 接頭

• 1 個 PS/2 鍵盤接頭

• 1 個 PS/2 滑鼠接頭

• 1 個 COM 連接埠

• 1 個外部 CMOS 清除開關

• 1 個 7.1 聲道音效接頭

• 4 個 USB 2.0 接頭

• 1 個 RJ-45 網路接頭

• abit SoftMenu™技術

• abit Silent OTES

• 外部 CMOS 清除開關

• 100%無鉛處理與 RoHS 相容

• ATX 主機板規格（305mm x 245mm）

• 符合 Vista 硬體需求

(只用於 AN52S)

(只用於 AN52S)

™

技術

(只用於 AN52S)

(只用於 AN52S)

Multilingual QIG

AN52S/AN52 4-19

4.19.2 快速安裝略說

本「快速安裝略說」僅包含安裝 abit 主機板時所需的
基本硬體資訊。詳細的操作方式，仍請參閱其完整的
手冊版本。

硬體安裝注意事項

• 安裝機板或變換任何設定之前，請先關閉電源並拔

掉電源插頭。

• 從抗靜電袋中取出機板前，請先戴上靜電安全手

環，以確保自己已確實接地。

• 請握住機板的邊緣。請勿接觸機板上的任何元件。

• 請勿接觸模組及 IC 晶片

• 請將機板置於已接地的抗靜電平面上，或置於隨附

的抗靜電袋。

將機板安裝至機殼內

本主機板的電腦機殼應符合以下條件：

• 與本主機板的規格相容。

• 機殼上的指示燈及開關支援主機板上的連接線插

座。

• 能提供足夠的電力及空間，以容納所有您想安裝的

磁碟機。

• 背面的 I/O 必須配合主機板上的 I/O 連接埠及擴充插

槽。

要將主機板安裝至機殼，您應該：

• 將 I/O 連接埠的內部面向機殼的後面。

• 將螺絲孔置於主機板與機殼的底座。

• 將所需的銅柱或塑膠腳座置於機殼底座並鎖緊。

• 將主機板上所有的螺絲孔與機殼上的銅柱或塑膠腳

座對齊。

• 將螺絲孔鎖緊。

要避免造成
底座上，及本主機板上沒有安裝孔可對齊的的金屬銅
柱及腳柱。

清除 CMOS 跳線

這個跳線是用來清除 CMOS 記憶體以便重新設定 BIOS
的內容。如果BIOS 設定有誤導致主機板無法運作，您
可能需要清除 CMOS 記憶體。
若要清除 CMOS 記憶體，拔除主機板上所有的電源線，
將跳線連接到標有「清除 CMOS」的設定數秒鐘，然後
再將跳線插回「一般」設定。插回所有電源並重新啟
動電源時，BIOS 內容將重新設定成預設值。

連接機殼元件

ATX 電源供應器：[ATXPWR1]、[ATX12V1]

風扇插座：[CPUFAN1], [SYSFAN1], [AUXFAN1], [NBFAN1]

• [CPUFAN1]：CPU 冷卻風扇插座。

• [SYSFAN1]：系統冷卻風扇插座。

• [AUXFAN1]：輔助冷卻風扇插座。

• [NBFAN1]：北橋冷卻風扇插座。

前面板插座：[FPIO1]

• [HLED]：連接至硬碟 LED 連接線。

• [RST]：連接至重新啟動開關連接線。

• [SPKR]：連接至系統喇叭連接線。

• [SLED]：連接至暫停 LED 連接線。

• [PWR]：連接至電源開關連接線。

• [PLED]：連接至電源 LED 連接線。

PCB

電路短路，請「移除」已安裝在機殼

附加的 USB 連接埠接頭：[FP-USB1]、[FP-USB2]
除了位於 I/O 面板上的內建 USB 接頭外，您可透過帶有
支架的延長線，連接這些各有兩個附加 USB 連接埠的
接頭。

附加的 IEEE1394 連接埠接頭：[FP-1394-1]、[FP-1394-2]
除了位於 I/O 面板上的內建 IEEE1394 接頭外，您可透
過帶有支架的延長線，連接這些各有一個附加
IEEE1394 連接埠的接頭。

前面板音效接頭：[FP-AUDIO1]
本接頭提供前面板 HD (高品質) 音效連接。

內部音源連接頭：[CD1]、[AUX1]
這個連接頭可選擇內部光碟機或附加卡的音源輸出。

安裝 CPU 和散熱片配件

由於市面上有多種中央處理器 (Central Processing Unit,
CPU) 和專用的散熱片可供選擇，而安裝方式也各有不
同，請確實遵循所購買產品包裝中隨附的安裝指示。
CPU 是一種精密的電子裝置，運作時會散發大量的熱
能。請務必小心處理。
將散熱片安裝到處理器上以後，請將散熱風扇的電源
連接到主機板上的 [CPUFAN1] 插座。

安裝記憶體模組

• 將插槽兩側的卡榫向下推開。

• 將記憶體模組對準插槽。記憶體模組兩側和底下的

缺口必須與插槽吻合才能固定，只有一個方向能放
入記憶體模組。

• 向下按壓記憶體模組，直到記憶體模組穩固地安裝

在插槽中。插槽卡榫會自動向上移動，並扣住記憶
體模組的兩側。

• 若要移除記憶體模組，請同時將插槽兩側的卡榫向

下推開，即可拿出記憶體模組。

連接儲存裝置

連接軟碟機：[FDC1]

連接 IDE 硬碟：[IDE1]、[IDE2]

連接序列 ATA 硬碟機：[SATA1] ~ [SATA4]

背面板線路連接

• Mouse：連接 PS/2 滑鼠。

• Keyboard：連接 PS/2 鍵盤。

• LPT1：連接印表機或其他支援平行通訊協定的裝

置。

• COM1：連接外接數據機、滑鼠或其他支援序列通訊

協定的裝置。

• OPT-IN1：本插座提供透過光纖連接到數位多媒體裝

置的 S/PDIF 輸入。

• OPT-OUT1：本插座提供透過光纖連接到數位多媒體

裝置的 S/PDIF 輸出。

• AUDIO1: 7.1 聲道音效輸入/輸出連接。

• IEEE1394：連接 IEEE1394 通訊協定裝置。

• LAN1：連接區域網路。

• USB1/USB2：連接 USB 裝置，例如掃描器、數位喇

叭、顯示器、滑鼠、鍵盤、集線器、數位相機或搖
桿等。

4-20 AN52S/AN52

4.20 简体中文

4.20.1 规格

处理器

• 支持采用 Hyper Transport™（超传输）技
术、2GHz 系统总线的 AMD Socket AM2
940 处理器

• 支持 AMD CPU Cool ‘n’ Quiet（降温静音）
技术

内部输入/输出接头

芯片组

• NVIDIA NF520 单芯片

后面板输入/输出接头

内存

• 4 条 240 针脚 DIMM 插槽支持最大 8GB
内存容量

• 支持双信道 DDR2 800 无缓冲ECC/非 ECC
内存

网络

• 主板内建 Gigabit 网络

音效

• 支持 7.1 声道 HD 音效

• 支持自动插孔侦测与自动重新指派音讯

插座功能

串行 ATA

• 4 组 SATA 3Gb/s，支 持 SATA RAID 0、1、
0+1、5 功能

扩充插槽

• 1 个 PCI-E X16 插槽

• 2 个 PCI-E X1 插槽

• 3 个 PCI 插槽

※ 本手册的规格与信息若㈲变动，恕不另行通知。

abit Engineered

RoHS

其它

• 1 个软盘端口

• 1 个 Ultra ATA 133 IDE 接头

• 4 个 SATA 3Gb/s 接头

• 3 个 USB 2.0 接头

• 1 个 FP-Audio 接头

• 1 个 CD-In 接头

• 1 个 PS/2 键盘接头

• 1 个 PS/2 鼠标接头

• 1 个 COM 连接埠

• 1 个外部 CMOS 清除开关

• 1 个 7.1 声道音效接头

• 4 个 USB 2.0 接头

• 1 个 RJ-45 网络接头

• abit SoftMenu™技术

• abit Silent OTES

• 外部 CMOS 清除开关

• 100%无铅工艺，符合 RoHS 规范

• ATX 主机板规格（305mm x 245mm）

• 符合 Vista 硬件需求

(只用于 AN52S)

™

技术

(只用于 AN52S)

(只用于 AN52S)

(只用于 AN52S)

Multilingual QIG

AN52S/AN52 4-21

4.20.2 快速安装略说

本“快速安装略说”仅包含基本的硬件信息，供您在
安装 abit 主板时进行参考。如需了解高级操作，仍请
参阅其完整的手册版本。

硬件设置注意事项

• 在安装主板或更改任何设置前，务必关闭电源并从

交流插座上拔掉电源线。

• 从防静电袋中取出主板前，应戴上静电安全腕带以

使您正确接地。

• 用手拿着主板的边缘。不要触摸主板上的任何元

件。

• 不要触摸模块触点和 IC 芯片。

• 将主板放在接地的防静电表面上或者放在主板附带

的防静电袋中。

将主板安装到底盘上

此主板的计算机底盘应符合下列条件：

• 支持此主板的外形尺寸。

• 支持主板上的所有线缆连接器，能够连接到底盘上

的指示灯和开关。

• 能够为您要安装的所有驱动装置提供充足的电源和

空间。

• 底盘后面板上的 I/O 模板与主板上的 I/O 端口和扩展

槽匹配。

要将主板安装到底盘上，您应该：

• 使 I/O 端口一侧朝向底盘的后部。

• 在主板和底盘上找到螺丝孔。

• 将所有销钉或柱杆放到底盘上，然后拧紧它们。

• 将底盘上的销钉或柱杆对准主板上的螺丝孔。

• 利用这些螺丝孔将主板固定在底盘上。

如果底盘上已经安装了金属销钉或柱杆，并且在主板
上没有它们的安装孔，为防止
这些金属销钉或柱杆。

CMOS 清除跳线

此跳线用于清除 CMOS 存储器以重置 BIOS 内容。当

BIOS 设置不正确并导致主板无法工作时，应清除
CMOS 存储器。

要清除 CMOS 存储器，请断开主板上的所有电源线，
将跳线帽插到“清除 CMOS”位置上几秒钟，然后将跳
线帽插回“正常”位置。重新接通所有电源并启动
后，BIOS 内容将恢复成默认配置。

连接底盘元件

ATX 电源：[ATXPWR1]、[ATX12V1]

风扇连接器：[CPUFAN1], [SYSFAN1], [AUXFAN1],

[NBFAN1]

• [CPUFAN1]：CPU 冷却风扇连接器。

• [SYSFAN1]：系统冷却风扇连接器。

• [AUXFAN1]：辅助冷却风扇连接器。

• [NBFAN1]：北桥冷却风扇连接器。

前面板连接器：[FPIO1]

• [HLED]：连接 HDD LED 电缆。

• [RST]：连接复位开关电缆。

• [SPKR]：连接系统扬声器电缆。

• [SLED]：连接挂起 LED 电缆。

• [PWR]：连接电源开关电缆。

PCB

短路，请“取下”

• [PLED]：连接电源 LED 电缆。

附加的 USB 端口接头：[FP-USB1]、[FP-USB2]
除了位于 I/O 面板上的板载 USB 连接器外，这些接头可
以通过带线卡的延长电缆分别提供两个附加的 USB 端
口连接。

附加的 IEEE1394 端口接头：[FP-1394-1]、[FP-1394-2]
除了位于 I/O 面板上的板载 IEEE1394 连接器外，这些
接头可以通过带线卡的延长电缆分别提供一个附加的
IEEE1394 端口连接。

前面板音频接头：[FP-AUDIO1]
本接头提供前面板 HD (高品质) 音效连接。

内部音频连接器：[CD1]、[AUX1]
此连接器用于从内部 CD-ROM 驱动器或扩展卡的音频
输出中选择音频。

安装 CPU 和过热降温装置

可供选择的中央处理单元 (CPU) 及其过热降温装置有
很多种，每一种的安装方式都不相同，因此请严格按
照产品包装中的安装说明进行操作。CPU 是一种精密
的电子设备，工作时会产生大量热量。操作时，务请
小心谨慎。
将过热降温装置安装到处理器上后，把 CPU 冷却风扇
的电源连接到主板上的 [CPUFAN1] 连接器。

安装内存模块

• 向下按插槽两端的卡销。

• 将内存模块对准插槽。插槽上有槽口，内存模块上

有凹口，因此内存模块只能按一种方式插入插槽。

• 向下用力按内存模块，将其装入插槽中。插槽卡销

自动向上弹起，并卡入内存模块的边缘。

• 若要取下内存模块，请同时向下按插槽两端的卡

销，然后取出内存模块。

连接存储设备

连接软盘驱动器：[FDC1]

连接 IDE 硬盘驱动器：[IDE1]、[IDE2]

连接串行 ATA 硬盘驱动器：[SATA1] ~ [SATA4]

后面板连接

• Mouse：连接 PS/2 鼠标。

• Keyboard：连接 PS/2 键盘。

• LPT1：连接打印机或其它支持并行通信协议的设

备。

• COM1：连接外部调制解调器、鼠标或支持串行通信

协议的其它设备。

• OPT-IN1：此连接器通过光纤提供 S/PDIF 输入连接，

用于连接数码多媒体设备。

• OPT-OUT1：此连接器通过光纤提供 S/PDIF 输出连

接，用于连接数码多媒体设备。

• AUDIO1：7.1 声道音效输入/输出连接。

• IEEE1394：连接支持 IEEE1394 协议的设备。

• LAN1：连接到局域网。

• USB1/USB2：连接 USB 设备，如扫描仪、数码扬声

器、监视器、鼠标、键盘、集线器、数码相机、操
纵杆等。

4-22 AN52S/AN52

5. Appendix

5.1 Troubleshooting (How to Get Technical Support?)

5.1.1 Q & A

Q: Do I need to clear the CMOS before I use a new motherboard to assemble my

new computer system?

A: Yes, we highly recommend that you clear the CMOS before installing a new motherboard.

Please move the CMOS jumper from its default 1-2 position to 2-3 for a few seconds, and
then back. When you boot up your system for the first time, follow the instructions in the
user's manual to load the optimized defaults.

Q: If my system hangs when I update the BIOS or set the wrong CPU parameters,

what should I do?

A: Whenever you update the BIOS or if the system hangs due to wrong CPU parameters

setting, always clear CMOS jumper before booting up again.

Q: Why does the system fail to boot up again right after a mechanical power-off?

A: Please keep a 30-second interval between each mechanical power On/Off.

Q: Why does the system fail to boot up and nothing displays on the screen after I

did some over-clocking or non-standard settings inside the BIOS?

A: It should not cause hardware or permanent damage to motherboard when BIOS settings

were changed from default to over-clocking or non-standard status.

We suggest the following three troubleshooting methods to discharge CMOS data, recover
the hardware default status, and then making the motherboard work again. There is no
need to bother returning the motherboard to where you bought it from or go through an
RMA process.

Step 1. Switch off the power supply unit and then switch it on again after one minute. If

there is no power-switch on the power supply unit, disconnect its power cord for
one minute and then reconnect.

Press and hold the <Insert> key on the keyboard, and press the power-on button
to boot up system. If it works, release the <Insert> key and hit <Del> key to enter
the BIOS setup page to apply the correct settings.

If the situation remains the same, repeat the procedures in Step 1 three times, or
try Step 2.

Step 2. Switch off the power supply unit or disconnect the power cord. Open the chassis

cover. Locate the CCMOS jumper near the button battery. Change the jumper
position from default 1-2 to 2-3 for one minute to discharge the CMOS data, and
then put it back to default 1-2 position.

Close the chassis and switch on the power supply unit or plug in the power cord.
Press the power-on button to boot up system. If it works, hit <Del> key to enter
the BIOS setup page to do the correct settings.

If the situation remains the same, try Step 3.

Step 3. The same procedure as Step 2, but while discharging the CMOS data, pull out the

ATX power connectors from motherboard and remove the button battery during
CMOS discharge.

Appendix

AN52S/AN52 5-1

Q: How to get a quick response for my request on technical support?
A: Please carry out a simple troubleshooting before sending “Technical Support Form”:

System boot-up fails after the system had been assembled:

Check the motherboard’s supporting specifications first to see if all the key components
attached in your system can meet.

To do so, you may:

• Remove all the unnecessary add-on devices (except the CPU, VGA card, DRAM, and
Power Supply), and then reboot.

• If the trouble still exists, try another VGA card of different brand/model to see if the
system will start.

• If the trouble still exists, try another memory module of different brand/model.

• If the trouble still exists, try another CPU and Power Supply.

If the system runs successfully, shut it down and start re-installing the interface cards and
devices that were previously installed in the system. Re-install and start the system one at a
time until the system won’t start.

Malfunction in the OS:

If the system hangs after resuming from S3 or some testing program, if the CPU cannot be
recognized properly, if the display resolution mixed, or if a certain program cannot be
executed, etc, you may:

• Upgrade the motherboard’s latest BIOS version.

• Upgrade the add-on device’s latest driver version.

• Check if there is any conflict in the “Control Panel/System Properties”.

Q: How to fill in the “Technical Support Form”?
A: To fill in this “Technical Support Form”, please refer to the following instructions:

• Region: Type in your country name.

• E-mail: Type in your contact E-mail information.

• First name: Type in your first name.

• Last name: Type in your last name.

• Subject: Type in the model name and the problem of your motherboard.

Example 1: AA8XE and SCSI 29160 malfunction
Example 2: AA8XE boot fails, POST code AF
Example 3: AA8XE (system hang when S3 resume)

• Motherboard: Type in the model name and revision number of your motherboard.
Example: AA8XE REV: 1.00

• BIOS Version: Type in the BIOS version of your motherboard. (You can find it on the
screen during the POST sequence.)

• CPU: Type in the brand name and the speed (MHz) of your CPU. (Illustrate the
over-clocking status if you had done so.)
Example: Intel 650 3.4GHz (OC FSB=220MHz)

• Memory brand: Type in the brand and model name of your memory module.
Example: Memory brand: Kingston (KVR533D2N4/1G)

• Memory size: Type in the size of your memory module.
Example: 512M* 4PCS

5-2 AN52S/AN52

• Memory configuration: Type in the memory configuration in BIOS setting.
Example: Memory Timing: 2.5-3-3-7 @533MHz

• Graphics information: Note Graphics card’s brand, model and driver version

• Graphics card: Type in the brand and model name of your graphics card.

Example: ATI RADEON X850 XT PE

• Graphics driver version: Type in the driver version of your graphics card
Example: Catalyst 5.12V

• Power supply maker: Type in the brand and model name of your power supply unit.

• Power supply wattage: Type in the power wattage of your power supply unit.

• Storage devices: Type in the brand and specifications of your HDD drive and quantity.

Specify if it was inserted on IDE (Master or Slave) or SATA ports, including the RAID
allocation status.
Example 1: WD Caviar WD600 60GB (on IDE2 master), Maxtor DiamondMax 10 SATA
300GB (on SATA 3)
Example 2: Maxtor DiamondMax 10 SATA 300GB *2 (on SATA 3, SATA 4 RAID 1)

• Optical devices: Type in the brand and specifications of your optical drives and
quantity. Specify if it was inserted on IDE (Master or Slave) or SATA ports.

• Other devices: Indicate which add-on cards or USB devices you are
relate to the problem. If you cannot identify the problem’s origin, indicate all the add-on
cards or USB devices inserted on your system.
Example: AHA 29160 (on PCI 2), Sandisk Cruzer mini 256MB USB Flash-disk.

• Operating system: Indicate which OS and language version
Example: Microsoft Windows XP SP2, English version
Example: Microsoft Media Center Edition 2005, Korean version

• Problem description: Describe the problem of your system configuration. Indicate
the steps to duplicate problem if possible.

See the next page for a blank Technical Support Form, or visit our website to fill in the
form on line (

http://www.abit.com.tw/page/en/contact/technical.php).

absolutely sure

Q. Is the motherboard dead? Do I need to return it to where I bought from or go

through an RMA process?

A: After you have gone through the troubleshooting procedures, yet the problem still exists, or

you find an evident damage on the motherboard, please contact our RMA center.
(

http://www2.abit.com.tw/page/en/contact/index.php?pFUN_KEY=18000&pTITLE_IMG)

AN52S/AN52 5-3

Appendix

5.1.2 Technical Support Form

Region:

E-mail:

First name:

Last Name:

Subject:

Motherboard:

BIOS Version:

CPU:

Memory brand:

Memory size:

Memory configuration:

Graphics card:

Graphics driver version:

Power supply maker:

Power supply wattage:

Storage devices:

Optical devices:

Other devices:

Operating system:

Problem description:

5-4 AN52S/AN52

5.1.3 Contact Information

Taiwan Head Office
Universal ABIT Co., Ltd.

6F, No. 323, Yang Guang St., Neihu,
Taipei, 114, Taiwan

Tel: [phone]
Fax: [phone]

Sales:

[e-mail]

Marketing:

[e-mail]

North America, South America

Universal ABIT (USA) Corporation

2901 Bayview Drive,
Fremont, CA 94538, U.S.A.

Tel: [phone]
Fax: [phone]

Website:
Latin America:

RMA Center:

http://www.abit-usa.com

[e-mail]

http://rma.abit-usa.com

UK, Ireland

Universal ABIT UK Co. Ltd.

Unit 3, 24-26 Boulton Road, Stevenage,
Herts SG1 4QX, United Kingdom

Tel: [phone]
Fax: [phone]

For technical support and RMA return:
Tel: [phone]

[e-mail]
[e-mail]

Germany and Benelux (Belgium,
Netherlands, Luxembourg), France, Italy,

Spain, Portugal, Greece, Denmark,
Norway, Sweden, Finland, Switzerland

Universal ABIT NL B.V.

Jan van Riebeeckweg 15, 5928LG,
Venlo, The Netherlands

Tel: [phone]
Fax: [phone]

Chamber of Commerce Venlo – number
12062448

Austria, Czech, Romania, Bulgaria,
Slovakia, Croatia, Bosnia, Serbia,
Macedonia, Slovenia

Universal ABIT Austria Computer
GmbH

Schmalbachstrasse 5, A-2201 Gerasdorf /
Wien, Austria

Tel: [phone]
Fax: [phone]

Contact:
Website:

[e-mail]

http://www.abit-austria.at

Shanghai

Universal ABIT (Shanghai) Co. Ltd.

FL 19 Xuhui Yuan BLOG NO.1089
ZhongShan s 2 RD, ShangHai 200030
The People's Republic of China

Tel: [phone]
Fax: [phone]

Website:

http://www.abit.com.cn

Poland

Universal ABIT Poland (Rep. office)

Strzegomska 310/2, 54-432 Wroclaw
Tel: [phone]

Fax: [phone]
Contact:

[e-mail]

Turkey

Universal ABIT Turkey (Rep. office)

Tel: [phone]

Iran

Universal ABIT (Rep. office)

No.50, Valiasr Computer Center, Valiasr St.
Tehran Iran

Tel: [phone]
Fax: [phone]

Contact:

[e-mail]

Appendix

AN52S/AN52 5-5

P/N: 4310-0000-87
Rev. 2.00

http://www.abit.com.tw
