3COM 6200 User Manual

Page 1
Security Switch 6200
Hardware and Software Users Guides
2468
1357
10 12 14 16
9111315
10/100/1000
17
FIBER PACKET LINK
18
FIBER PACKET LINK
CONSOLE
PWR
(max) 9800,8,N,1
MGMT1 MGMT2 SYS HDD
December 2003
Page 2
Copyright © 2003, 3Com Corporation. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from 3Com Corporation.
3Com Corporation reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of 3Com Corporation to provide notification of such revision or change.
3Com Corporation provides this documentation without warranty, term, or condition of any kind, either implied or expressed, including, but not limited to, the implied warranties, terms or conditions of merchantability, satisfactory quality, and fitness for a particular purpose. 3Com may make improvements or changes in the product(s) and/or the program(s) described in this documentation at any time.
If there is any software on removable media described in this documentation, it is furnished under a license agreement included with the product as a separate document, in the hard copy documentation, or on the removable media in a directory file named LICENSE.TXT or !LICENSE.TXT. If you are unable to locate a copy, please contact 3Com and a copy will be provided to you.
UNITED STATES GOVERNMENT LEGEND
If you are a United States government agency, then this documentation and the software described herein are provided to you subject to the following:
All technical data and computer software are commercial in nature and developed solely at private expense. Software is delivered as “Commercial Computer Software” as defined in DFARS 252.227-7014 (June 1995) or as a “commercial item” as defined in FAR 2.101(a) and as such is provided with only such rights as are provided in 3Com’s standard commercial license for the Software. Technical data is provided with limited rights only as provided in DFAR 252.227-7015 (Nov 1995) or FAR 52.227-14 (June 1987), whichever is applicable. You agree not to remove or deface any portion of any legend provided on any licensed program or documentation contained in, or delivered to you in conjunction with, this User Guide.
Unless otherwise indicated, 3Com registered trademarks are registered in the United States and may or may not be registered in other countries.
3Com, SuperStack, and Transcend are registered trademarks of 3Com Corporation. The 3Com logo and CoreBuilder are trademarks of 3Com Corporation.
Intel and Pentium are registered trademarks of Intel Corporation. Microsoft, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft Corporation. Novell and NetWare are registered trademarks of Novell, Inc. UNIX is a registered trademark in the United States and other countries, licensed exclusively through X/Open Company, Ltd.
Netscape Navigator is a registered trademark of Netscape Communications.
JavaScript is a trademark of Sun Microsystems
All other company and product names may be trademarks of the respective companies with which they are associated.
ENVIRONMENTAL STATEMENT
It is the policy of 3Com Corporation to be environmentally-friendly in all operations. To uphold our policy, we are committed to:
Establishing environmental performance standards that comply with national legislation and regulations.
Conserving energy, materials and natural resources in all operations.
Reducing the waste generated by all operations. Ensuring that all waste conforms to recognized environmental standards. Maximizing the recyclable and reusable content of all products.
Ensuring that all products can be recycled, reused and disposed of safely.
Ensuring that all products are labelled according to recognized environmental standards.
Improving our environmental record on a continual basis.
End of Life Statement
3Com processes allow for the recovery, reclamation and safe disposal of all end-of-life electronic components.
Regulated Materials Statement
3Com products do not contain any hazardous or ozone-depleting material.
Environmental Statement about the Documentation
The documentation for this product is printed on paper that comes from sustainable, managed forests; it is fully biodegradable and recyclable, and is completely chlorine-free. The varnish is environmentally-friendly, and the inks are vegetable-based with a low heavy-metal content.
Page 3
Contents
About this Guide
Intended Audience ........................................................................................ v
Conventions................................................................................................... v
Related Documentation ............................................................................... vi
Customer Support........................................................................................ vi
1 Introduction
System Components .................................................................................. 1-1
Chassis ................................................................................................... 1-2
Management Options ............................................................................ 1-3
First Time Startup Interview......................................................... 1-3
Configuration Tool .......................................................................... 1-3
2 Installation
Before You Start ........................................................................................ 2-1
Site Requirements ................................................................................. 2-2
Shipment Check .................................................................................... 2-2
Additional Equipment........................................................................... 2-4
Required Equipment ............................................................................. 2-4
Tools................................................................................................. 2-4
Cables .............................................................................................. 2-4
Terminal or PC................................................................................ 2-5
Chassis Rack Installation ......................................................................... 2-5
Front Rack Mounting ............................................................................ 2-5
Tabletop Mounting ................................................................................ 2-6
3
Interface Connections and First Time Start-Up
Making Connections .................................................................................. 3-1
Management Serial Port Connections ................................................. 3-1
Connecting a Terminal or PC to the System Front Serial
Craft Port ........................................................................................ 3-2
Connecting Remotely ...................................................................... 3-3
Power Connections ................................................................................ 3-3
Startup and Normal Operation LED Displays ........................................ 3-4
POST Error Beep Codes ............................................................................ 3-5
First Time Startup..................................................................................... 3-7
3COM Security Switch 6200 Hardware and Software Users Guide
Page 4
4 Configuring the Security Switch 6200 System
Configuring System Parameters............................................................... 4-2
Configuring User Accounts ....................................................................... 4-5
Configuring the Network Time Protocol (NTP) ....................................... 4-6
Configuring Domain Name Resolution..................................................... 4-6
Configuring the Simple Network Management Protocol (SNMP) .......... 4-7
Configuring Physical Interfaces.............................................................. 4-10
Configuring Tap Interfaces ..................................................................... 4-12
Configuring Network Interfaces ............................................................. 4-13
Configuring IP Aliases ............................................................................ 4-14
Configuring Static Routes ....................................................................... 4-16
Configuring Static ARP Entries.............................................................. 4-17
Configuring the Virtual Router Redundancy Protocol (VRRP)............. 4-18
Exiting from the Configuration Tool ...................................................... 4-21
Saving Your System Configuration ........................................................ 4-21
Restoring Your System Configuration.................................................... 4-21
Displaying Your System Configuration.................................................. 4-21
Restoring the system to Factory Default Settings ................................. 4-25
Getting Help Within the Configuration Tool ......................................... 4-25
5 Upgrading the System Software
Upgrading the System Software ............................................................... 5-1
6 Upgrading the System Software Using the Safe Upgrade and
Rollback Features
Using Multiple Versions of Software (Safe Upgrade) .............................. 6-1
Upgrading from Version 2.0 ................................................................. 6-1
Upgrading from Version 2.1 and Greater ............................................ 6-3
Upgrading from Software to a UP While an RP is
Operational (Rollback)............................................................................... 6-4
7 Technical Support
Online Technical Services ......................................................................... 7-1
World Wide Web Site ............................................................................ 7-1
3Com Knowledgebase Web Services .................................................... 7-2
3Com FTP Site....................................................................................... 7-2
Support from Your Network Supplier ...................................................... 7-2
Support from 3Com ................................................................................... 7-3
Email Support ....................................................................................... 7-3
Telephone Support ................................................................................ 7-3
Returning Products for Repair.................................................................. 7-6
A Technical Specifications
Physical Characteristics........................................................................... A-1
Environmental Characteristics................................................................ A-1
Power Characteristics .............................................................................. A-1
3COM Security Switch 6200 Hardware and Software Users Guide
Page 5
B Connector Pin Assignments
C Regulatory Information
Regulatory Standards Compliance .......................................................... C-1
CE marking for the EEA (European Economic Area) ........................ C-1
Safety .................................................................................................... C-1
Factory Approvals ................................................................................ C-1
EMI Compliance ....................................................................................... C-2
Radio Frequency Interference ............................................................. C-2
VCCI Statement V-3/2000.04 .............................................................. C-2
Other EMI Approvals........................................................................... C-2
Immunity Compliance .............................................................................. C-2
3COM Security Switch 6200 Hardware and Software Users Guide
Page 6
3COM Security Switch 6200 Hardware and Software Users Guide
Page 7

About this Guide

This guide describes how to install and configure the 3COM Security Switch 6200 hardware and system software. The Security Switch 6200 is based on the 3COM system software and may be referred to as the system.

Intended Audience

This guide is intended for system integrators and other qualified service personnel responsible for installing, configuring, and managing the system.

Conventions The following conventions are used throughout this guide to

emphasize certain information, such as, user input, screen options and output, and menu selections.
italics Indicates book titles and user input variables.
Courier Indicates user input and program output.
Courier italics Indicates variables in commands.
Menu => Indicates to select an Option from the menu pull-down.
Warnings, Cautions, and Notes indicate the following:
NOTES Provide helpful suggestions or reference to materials not contained in this
manual.
!
WARNING:
Warnings notify you to proceed carefully in order to avoid personal harm.
!
CAUTION:
Cautions notify you to proceed carefully in order to avoid damaging
equipment or losing data.
3COM Security Switch 6200 Hardware and Software Users Guide v
Page 8
About this Guide

Related Documentation

Customer Support

The following guides provide additional installation and configuration information for the system.
Security Switch 6200 Product Release Notes Install Server Installation and Configuration Guide Security Switch 6200 Applications Guide
To obtain technical tips or support, refer to the Technical Support chapter of this guide.
vi 3COM Security Switch 6200 Hardware and Software Users Guide
Page 9

Introduction

The Security Switch 6200 is a high performance, turnkey security services switch that integrates best-in-class firewall, virtual private networks, intrusion detection, and content security engines. The system offers high port density, high availability, and simplicity of management in a compact, expandable form factor.

System Components

The system is a Network Processor-based security platform that provide exceptional performance while maintaining flexibility for security application support. The system’s unique flow management and acceleration technology enables simultaneous processing of traffic by multiple services.
The system is used by medium to large enterprises to consolidate the functions of multiple appliances at a fraction of the cost.
This chapter describes the system components.
The system has a compact, expandable form factor and is either rack or table­top mountable. The system provides the following features:
Fixed 16-10/100 Ethernet and 2-fiber or copper Gigabit Ethernet (GE)
interfaces.
Network Interface Module (NIM) powered by the Network Processor.
Dual-processor motherboard (Application Module) with high-speed
Pentium III processors.
High-speed Ethernet backplane connecting the network and
application processing modules.
40 GB hard drive.
Two out-of-band 10/100 Ethernet management ports.
Two USB ports (may be used for modem support).
3COM Security Switch 6200 Hardware and Software Users Guide 1-1
Page 10
Introduction
ly
One serial console port.
Two redundant, hot-swappable power supplies.
Five expansion slots for optional VPN or other security
acceleration cards.

Chassis The chassis is front rack mountable, in a standard 19 inch rack.

Figure 1-1 displays the 6200 system’s major components.
2468
1357
10/100
10 12 14 16
9111315
17
FIBER PACKET LINK
10/100/1000
18
FIBER PACKET LINK
CONSOLE
PWR
(max) 9800,8,N,1
MGMT1 MGMT2 SYS HDD
Figure 1-1 6200 Front View
Figure 1-2 displays the rear panel components.
NOTE: This figure is shown for reference only. The console connections should be made from the 6200 front panel, with the management connections taking place in the rear of the chassis.
PCI Slots
PCI Slots
Primary Power Supply
Secondary Power Supp
Video
RJ45 Serial Port
Connector
Managemet Port 2
Managemet Port 1
PS/2 Mouse/Keyboard Connector
Figure 1-2 Rear Panel Component Layout
1-2 3COM Security Switch 6200 Hardware and Software Users Guide
Page 11
Introduction

Management Options

The system provides two system management options:
First time startup interview
Configuration Tool

First Time Startup Interview

The system uses a built in, easy to configure, interview tool (cos_interview) that allows you to quickly configure your system for basic operations. For further information on the startup interview, refer to the Interface Connections and First Time Start-Up chapter of this guide.

Configuration Tool

The system uses a menu driven configuration interface (cos_config) for configuration purposes. This tool supports adding, modifying, or deleting any of the system configuration parameters. For further information on this tool, refer to the Configuring the System chapter of this guide.
3COM Security Switch 6200 Hardware and Software Users Guide 1-3
Page 12
Introduction
1-4 3COM Security Switch 6200 Hardware and Software Users Guide
Page 13

Installation

This chapter describes the system installation, covering the following topics:
Pre-installation considerations
Chassis installation
Interface connections

Before You Start

!
WARNING:
To ensure power connectivity, if you are using more than one power supply, be sure to use separate power sources.
Before installing your system, be sure that the site’s environmental and space requirements allow optimal chassis access and operation. In addition, you need to verify that you have the equipment and the tools necessary to complete this installation.
3COM Security Switch 6200 Hardware and Software Users Guide 2-1
Page 14
Installation

Site Requirements

The system installation site should meet the following requirements:
Requirement Description
Operating Temperature 0 to 40 degrees C
Relative Humidity 10% - 90%, non-condensing
Minimum Ventilation 6 inches (15.2 cm) to the front, back, and sides of
the chassis
Service Clearance 30 inches (76.2 cm) at the front of the chassis
Power Sources 100 to 240 VAC outlets, with grounding and power
surge protection
Rack Standard 19-inch rack with grounding

Shipment Check Using the packing slip as a reference, inspect package contents for missing or

damaged items. If parts are missing or damaged, call your 3COM Systems Support Representative (Refer to Chapter 5, for contact information.). The following items, as a minimum, are included with your system:
Chassis
Mounting screws
Rubber feet
Two power cables
One serial console port cable
CDs containing the system software, product documentation, and
applications
Warranty card
Figure 2-1 shows the standard shipping contents:
2-2 3COM Security Switch 6200 Hardware and Software Users Guide
Page 15
Installation
2
4
6
10/100
8
10
1
12
14
3
5
7
16
9
11
13
15
10/100/1000
17
FIBER
PACKET
LINK
18
FIBER PACKET
LINK
PWR
CONSOLE
MGMT1 MGMT2 SYS
(max) 9800,8,N,1
HDD
Figure 2-1 3COM Security Switch 6200 Shipping Contents
NOTE: 3COM recommends that you save the shipping containers in the event you need to send back one or more components.
3COM Security Switch 6200 Hardware and Software Users Guide 2-3
Page 16
Installation

Additional Equipment

Required Equipment

PC running RedHat Linux 6.2 or greater software. This software is
used to support the Security Switch 6200 Graphical User Interface
(GUI) and for hosting the Check Point™ FireWall-1
Server.
PC running WinNT4/Win2K software. This software is used for
launching the Check Point FireWall-1 GUI and the system’s embedded
WEB GUI.
Security applications licenses to activate installed software on
the system.
To install the chassis in a standard rack you need certain hand tools, appropriate cabling, and additional hardware not included in the chassis shipment.
®
Management

Tools

To install the chassis into a standard rack you need, as a minimum, a Phillips screwdriver (9” minimum, #2).

Cables

Cabling requirements are installation-specific. Prior to installation you should know:
The kind and number of cables required for each type of interface.
The distance limitations for each signal type. Table 2-1: provides the
approximate cable distance limitations.
Table 2-1: Cable Distance Limitations
Cable Description Distance Limitation
Craft port: RS-232 DB9 directly from the system
Management Link port: 10/100 Cat 5 cable, 100 meters (328 feet)
Copper Ethernet Link Port: 10/100/ 1000
Fiber Ethernet Link Port: Gigabit 62.5 micro-fiber - 275 meters
Table 2-2: shows the cables that ship with chassis.
Table 2-2: System Cables
Cable Description
Power Cabling Standard AC power cable.
Console Port Serial shielded straight-through 9-pin D-sub female to 9-
pin male cable.
15 meters maximum (50 feet maximum)
Cat 5 cable, 100 meters (328 feet)
(902 feet) 50 micro-fiber - 550 meters (1805 feet)
2-4 3COM Security Switch 6200 Hardware and Software Users Guide
Page 17
Installation

Terminal or PC

A VT-100 terminal or a Personal Computer (PC) is required during installation. The terminal or PC is connected to the chassis’s craft port, allowing you to monitor start-up diagnostics and to configure the unit for remote management access.

Chassis Rack Installation

Front Rack Mounting

The chassis can be installed in the front or center of a standard 19” rack.
To install the chassis in the front of your rack:
1. Remove the center brackets (one on each side) from the system.
2. Position the chassis in the rack by aligning the holes on its integrated front mounting brackets with the holes in the rack.
3. Insert the appropriate screws through the brackets and tighten. If the rack holes are not threaded, use cage-nuts over them. Figure 2-2 shows a chassis installation example.
2
46
8
10/100
1
10
3
12 14
5
7
16
9
11 13
15
17
FIBER
10/100/1000 PACKET LINK
18
FIBER
PACKET LINK
PWR
CONSOLE
MGMT1
(max) 9800,8,N,1
MGMT2
SYS
HDD
Rear Mounting Bracket
Front Mounting Bracket
Figure 2-2 Front Rack Mounting the Chassis
3COM Security Switch 6200 Hardware and Software Users Guide 2-5
Page 18
Installation

Tabletop Mounting

The system can be mounted on any desk or table top. To do this you first need to attach the four rubber feet, supplied with the system, to the bottom of the box. To do this, complete the following:
1. Turn the system over onto its top with the bottom facing up.
2. Locate the indented feet locators, as shown in the following figure.
Place rubber feet here.
3. Peel backing off of the rubber feet and press them down firmly on the indents.
Once the rubber feet are installed you can mount the system on a solid flat surface.
2-6 3COM Security Switch 6200 Hardware and Software Users Guide
Page 19
Interface Connections and
First Time Start-Up
This chapter describes the procedure for powering up the system for the first time. Specifically covered are the following:
Connecting to the Management Console
Powering Up the System

Making Connections

Management Serial Port Connections

First time configuration
This section describes connections to the chassis interfaces, including:
Management serial port
Ethernet port
Power connections
The system provides you with multiple ways to access the Management Console. You can connect to the console by either connecting a terminal or a PC to the system’s serial (craft) connector or by Telneting into the system Management Console remotely.
For the initial configuration you can connect to the system through the craft port. Alternatively, you can connect to the system through telnet if you have the DHCP service in your network. By default, DHCP is enabled on your system, after your intital configuration you can disble the DHCP service.
3COM Security Switch 6200 Hardware and Software Users Guide 3-1
Page 20
Interface Connections and First Time Start-Up
To connect to the serial connector use the DB9 serial connector located on the front panel of the system.
NOTE: If you are connecting to the system Management Console using a terminal or PC, the serial port on the terminal or PC must be configured for 9600 baud, 8 data bits, 1 stop bit, no parity, and no flow control.

Connecting a Terminal or PC to the System Front Serial Craft Port

To connect a terminal or PC to the system front serial craft port:
1. Connect one end of a DB9-to-DB9 cable into the terminal or PC.
2. Connect the other end into the system serial craft port. Figure 3-1 shows the system connected to a laptop computer.
2468
1357
10/100
10 12 14 16
9111315
10/100/1000
17
FIBER PACKET LINK
18
FIBER PACKET LINK
CONSOLE
PWR
(max) 9800,8,N,1
Personal Computer
Figure 3-1 Connecting a Laptop Computer to the system Front Serial
Craft Port
3. Set to VT-100 terminal emulation mode.
MGMT1 MGMT2 SYS HDD
3-2 3COM Security Switch 6200 Hardware and Software Users Guide
Page 21
Interface Connections and First Time Start-Up

Connecting Remotely

To access the system remotely:
1. Connect one end of an RJ45-to-RJ45 cable into a remote access device.
2. Connect the other end into the Management port. Figure 3-2 shows the Management port module connected to a hub.
Figure 3-2 Connecting to the System Remotely
3. Telnet to configure IP.
Hub
Power Connections
CAUTION: To ensure power connectivity, if you are using more than one power supply, be sure to use separate power sources.
To connect power cabling:
1. Place the female end of the power cable into the power supply connector located on the back of the chassis. Refer to Figure 3-3 for the exact location.
Power Supply Audible Alarm Reset Button
Primary Power Supply Connection
Figure 3-3 System Rear View Power Connections
NOTE: Before applying power to the system, be sure you have connected a terminal or PC to the craft port. This allows you enter commands needed at startup.
Secondary Power Supply Connection
3COM Security Switch 6200 Hardware and Software Users Guide 3-3
Page 22
Interface Connections and First Time Start-Up
2. Attach the male end of the power cable into an AC power source. The system is powered up when power is applied to the power supplies.
NOTE: If the system is powered up with one power supply or if one of the power supplies experiences a loss of power, an audible alarm sounds. To silence this sound, press the red button located on the left side of the primary power supply.
Startup and Normal Operation
During power up and normal operation, you can observe start-up activity by checking LED activity on the system front panel.
Table 3-1 describes the various front panel LEDs and their function.
LED Displays
Table 3-1 Front Panel LED Descriptions
LED Color/Label State Description
10/100 Fast Ethernet Green On Ethernet connectivity present.
Yellow Flashing Traffic is present.
10/100/100 Fast Ethernet/Gigabit Ethernet
Power/Sleep(PWR) Green On Power on.
MGMT1/MGMT2 Green Random Flash NIC activity present.
System Status (SYS) Green On Running with normal operation.
Disk Activity (HDD) Green Random Flash Disk activity present.
Fiber/Green On Fiber connectivity present.
Activity/Green Flashing Traffic is present.
Link/Green On Ethernet connectivity present.
Flashing
1
In sleep state.
Off Off Power is off.
Flashing
2
Degraded.
Amber On Critical or non-recoverable condition.
Flashing
2
Non-critical condition.
Off Off Post/system stop.
Off Off
3
No hard disk activity detected.
1. The PWR LED sleep indication is maintained on standby by the system. If the system is powered down without going through BIOS, the LED state in effect at the time of power off, is restored when the system is powered on until cleared by the BIOS. If the system is not powered down normally, the PWR LED may blink even though the SYS LED may be off due to a failure or configuration change that prevents the BIOS from running.
2. The Amber status takes precedence over the Green status. When the Amber LED is on or flashing, the Green LED is off.
3. This LED is also off when the system is powered off or in a sleep state.
3-4 3COM Security Switch 6200 Hardware and Software Users Guide
Page 23
Interface Connections and First Time Start-Up

POST Error Beep Codes

The following tables list POST error beep codes. Before system video initialization, the BIOS and BMC use these beep codes to inform users on error conditions.
BMC Generated POST Beep Codes
Code Description
1-5-1-1 FRB failure (processor failure)
1-5-2-1 Empty Processor
1-5-2-2 No Processor
1-5-4-2 Power fault: DC power unexpectedly lost (power
control failures)
1-5-4-3 Chipset control failure
1-5-4-4 Power control failure
BIOS Generated POST Error Beep Codes
Beeps Error message Description
1 Refresh timer failure The memory refresh circuitry on the
motherboard is faulty.
2 Parity error Parity can not be reset.
3 Base memory failure Base memory test failure. See Table 53.
POST Memory Error 3-Beep Codes for additional error details.
4 System timer System timer is not operational.
5 Processor failure Processor failure detected.
6 Keyboard controller Gate
A20 failure
7 Processor exception
interrupt error
8 Display memory read/write
error
9 ROM checksum error System BIOS ROM checksum error.
10 Shutdown register error Shutdown CMOS register read/write
11 Invalid BIOS General BIOS ROM error.
The keyboard controller may be bad. The BIOS cannot switch to protected mode.
The CPU generated an exception interrupt.
The system video adapter is either missing or its memory is faulty. This is not a fatal error.
error detected.
3COM Security Switch 6200 Hardware and Software Users Guide 3-5
Page 24
Interface Connections and First Time Start-Up
3-6 3COM Security Switch 6200 Hardware and Software Users Guide
Page 25
Interface Connections and First Time Start-Up
POST Memory Error 3-Beep Codes
Beep Code
3 00h Off Off Off Off No memory was found in the system
3 01h Off Off Off G Memory mixed type detected.
3 02h Off Off G Off EDO is not supported.
3 03h Off Off G G First row memory test failure.
3 04h Off G Off Off Mismatched DIMMs in a row.
3 05h Off G Off G Base memory test failure.
3 06h Off G G Off Failure on decompressing post
3 07h-odh Off G G G Generic memory error.
3 0Eh G G G Off SMBUS protocol error.
3 0F-FFh All other combinations. Generic memory error.
Debug port 80h error Codes
Daignostic LED Decoder
G=Green, R=Red, A=Amber
Hi Low
G Off Off Off
G Off Off G
G Off G Off
G Off G G
G G Off Off
G G Off G
Meanings
module.
3COM Security Switch 6200 Hardware and Software Users Guide 3-7
Page 26
Interface Connections and First Time Start-Up

First Time Startup

The system uses a built in, easy to configure, interview script that allows you to quickly configure your system for basic operations.
Once you have completed this interview, you can use the system Configuration Tool to set additional parameters.
The interview script is launched from the UNIX root prompt. To launch the interview script, complete the following.
NOTE: Within this interview, you can type the initial letter of an option and the press the Tab key to complete the entire string on supported choices. The Enter key is used to select default values.
1. Log into your system as root.
NOTE: The password is admin.
2. Change to the bin directory within admin and list the files within this directory to locate the necessary interview file.
[admin@xxxxx admin]# cd /usr/os/bin [admin@xxxxx bin]# ls
3. Locate the file cos_interview and execute the following command at the admin prompt:
[admin@xxxxx bin]# ./cos_interview
Once the interview is launched, you are presented with an interactive interview. To begin your initial configuration, answer the following questions.
======================================================
Welcome to the Configuration Interview
This program is designed to guide you through the configuration of your system by prompting you with a series of questions. ======================================================
1. Enter the Hostname.
Hostname ========
Enter the system hostname:
2. Enter the System time.
System Time ===========
The current date and time on this system is Mon Mar 10 13:04:23 EST 2003
Would you like to modify System time <Y or N>[N]: y
3-8 3COM Security Switch 6200 Hardware and Software Users Guide
Page 27
Interface Connections and First Time Start-Up
Please provide the date in "Mon DD YYYY" format, where Mon : month in the form Jan, Feb, etc. DD : day of month (1 - 31), YYYY: for example 2002
Enter the Date :
3. Define the Time Zone.
Select a time zone based on the location of your system.
The current Time Zone is “present-time-zone
Would you like to Modify the Time Zone <Y or N> [N]: y Select a continent or ocean.
1) Africa
2) Americas
3) Antarctica
4) Arctic Ocean
5) Asia
6) Atlantic Ocean
7) Australia
8) Europe
9) Indian Ocean
10) Pacific Ocean
11) Other (Enter GMT offset) Enter choice <1 - 11>:
Select a country.
1)Antigua & Barbuda 18)Ecuador 35)Panama
2)Anguilla 19)Grenada 36)Peru
3)Netherlands Antilles 20)French Guiana 37)St Pierre & Miquelon
4)Argentina 21)Greenland 38)Puerto Rico
5)Aruba 22)Guadeloupe 39)Paraguay
6)Barbados 23)Guatemala 40)Suriname
7)Bolivia 24)Guyana 41)El Salvador
8)Brazil 25)Honduras 42)Turks & Caicos Is
9)Bahamas 26)Haiti 43)Trinidad & Tobago
10)Belize 27)Jamaica 44)United States
11)Canada 28)St Kitts & Nevis 45)Uruguay
12)Chile 29)Cayman Islands 46)St Vincent
13)Colombia 30)St Lucia 47)Venezuela
14)Costa Rica 31)Martinique 48)Virgin Islands (UK)
15)Cuba 32)Montserrat 49)Virgin Islands (US)
16)Dominica 33)Mexico
17)Dominican Republic 34)Nicaragua
Enter choice <1 - 49>:
3COM Security Switch 6200 Hardware and Software Users Guide 3-9
Page 28
Interface Connections and First Time Start-Up
4. Select a region.
1) Eastern Time
2) Eastern Time - Michigan - most locations
3) Eastern Time - Kentucky - Louisville area
4) Eastern Time - Kentucky - Wayne County
5) Eastern Standard Time - Indiana - most locations
6) Eastern Standard Time - Indiana - Crawford County
7) Eastern Standard Time - Indiana - Starke County
8) Eastern Standard Time - Indiana - Switzerland County
9) Central Time
10) Central Time - Michigan - Wisconsin border
11) Central Time - North Dakota - Oliver County
12) Mountain Time
13) Mountain Time - south Idaho & east Oregon
14) Mountain Time - Navajo
15) Mountain Standard Time - Arizona
16) Pacific Time
17) Alaska Time
18) Alaska Time - Alaska panhandle
19) Alaska Time - Alaska panhandle neck
20) Alaska Time - west Alaska
21) Aleutian Islands
Enter choice <1 - 21>:
5. Define the Management Services.
Management Services ===================
Several methods are available for managing your system through the 10/100 Ethernet interface on the host. Select the desired management services.
Enable Telnet Server <disabled, enabled>[enabled]: Enable FTP Server <disabled, enabled>[enabled]:
Add DNS Lookups <Y or N>[N]:
DNS Server IP Address [0.0.0.0]:
6. Configure the SNMP parameters.
Configure SNMP Network Management <Y or N>[N]:
Enabling SNMP ...
Enable SNMP Network Management <disabled, enabled> [disabled]: Enter SNMP Contact []: Enter SNMP Location []:
The SNMP community string is the access string to permit access to the SNMP protocol. A read-only "ro" or read-write "rw" access may be specified. By default, SNMP community string permits read-only access.
3-10 3COM Security Switch 6200 Hardware and Software Users Guide
Page 29
Interface Connections and First Time Start-Up
SNMP Communities ================
Community Address Netmask Access middle 10.1.1.22 255.255.255.255 read-write
Add the SNMP Communities <Y or N>[N]:
7. Configure the individual user accounts.
Accounts Configuration =======================
This section allows you to change your “root” password. Additionally, you can set up accounts for users to log into once the Interview is complete.
Set 'root' Password <Y or N>[Y]:
Additional user accounts can be defined, each with its own username and password.
Add or Modify User Accounts <Y or N>[Y]: Enter User Name []: Enter password: Verify password: Enable Login Access <disabled, enabled>[disabled]: Enter Access Level <Guest, Network Operator, Service Operator, Administrator>[Guest]:
The following is an example display showing configured users.
User Accounts =============
User Name Login Access Access Level
admin enabled Administrator
foobar enabled Guest
Add or Modify User Accounts <Y or N>[Y]: n
8. Configure the host interfaces.
Host Interfaces ===============
This section will help you configure interfaces on the Host. The system has two management ports, two GigaBit Ethernet ports, and 16 10/100 ports.
NOTE: At least one management port must be configured on the system.
3COM Security Switch 6200 Hardware and Software Users Guide 3-11
Page 30
Interface Connections and First Time Start-Up
Enter choice.
1) fastethernet 1 12) fastethernet 12
2) fastethernet 2 13) fastethernet 13
3) fastethernet 3 14) fastethernet 14
4) fastethernet 4 15) fastethernet 15
5) fastethernet 5 16) fastethernet 16
6) fastethernet 6 17) gigabitethernet 17
7) fastethernet 7 18) gigabitethernet 18
8) fastethernet 8 19) management 1
9) fastethernet 9 20) management 2
10) fastethernet 10 X) Exit
11) fastethernet 11
Enter choice <1 - 20, X>[X]:
Enter IP Address [0.0.0.0/0]:
9. Configure all additional interfaces.
Continue configuring interfaces <Y or N>[N]:
Enter choice.
1) fastethernet 1
2) fastethernet 2
3) fastethernet 3 . . .
19) management 1
20) management 2
21) None
Enter choice <1 - 21>[1]:
Enter IP address and mask :
Continue configuring interfaces <Y or N>[N]:
Continue this step until all interfaces are configured.
10. Configure your default gateway.
Default gateway ================
This section allows you to configure a default gateway for the system. Please provide an IP address, in dotted decimal format.
Default gateway [0.0.0.0]:
3-12 3COM Security Switch 6200 Hardware and Software Users Guide
Page 31
Interface Connections and First Time Start-Up
11. Configure NTP to achieve time synchronization.
Synchronizing the system’s clock with an accurate source is important for proper correlation of security events. The system uses the Network Time Protocol (NTP) to achieve time sychronization. The IP address of an NTP server must be specified.
NTP Server ==========
Add NTP Server <Y or N>[Y]: Enter NTP Server IP Address [0.0.0.0]:
======================================================
Congratulations, you have finished the Interview.
To activate your interview settings, you MUST reboot the system using the following command at the prompt:
# reboot Exiting the Interview... ======================================================
3COM Security Switch 6200 Hardware and Software Users Guide 3-13
Page 32
Interface Connections and First Time Start-Up
3-14 3COM Security Switch 6200 Hardware and Software Users Guide
Page 33
Configuring the
Security Switch 6200
System
The system uses a menu driven configuration interface (cos_config) for configuration purposes. This tool supports adding, modifying, or deleting any of the system configuration parameters.
This configuration interface is launched from the UNIX admin prompt. To launch this tool, complete the following:
1. Log into your system as admin.
username: admin password: admin
2. Change to the bin directory within admin and list the files within this directory to locate the necessary interview file.
[admin@xxxxx admin]# cd /usr/os/bin [admin@xxxxx bin]# ls
3. Execute the file cos_config and execute the following command at the admin prompt:
[admin@xxxxx bin]# ./cos_config
Once the configuration tool is launched, you are presented with an interactive main menu.
3COM Security Switch 6200 Hardware and Software Users Guide 4-1
Page 34
Configuring the Security Switch 6200 System
Configuration =========
1) System Parameters
2) User Accounts
3) Network Time Protocol (NTP)
4) Domain Name Service (DNS)
5) Simple Network Management Protocol (SNMP)
6) Physical Interfaces
7) Tap Interfaces
8) Network Interfaces
9) IP Aliases
10) Static Routes
11) Static ARP Entries
12) Virtual Router Redundancy Protocol (VRRP) X) Exit
To begin your configuration, select the desired option from the main menu.
NOTE: Within this configuration tool, you can type the initial letter of an option and the press the Tab key to complete the entire string on supported choices. The Enter key is used to select default values.

Configuring System Parameters

This section describes how to change your system settings. Specifically, how to:
Change the system host name and domain name
Change system information
Change time information
Enable external access ability
To configure system parameters:
1. Select Option 1 from the main menu.
The present System Configuration is displayed. For example:
System ====== Host Name helios Domain Name Date and Time Mon Apr 07 15:28:27 EDT 2003 Time Zone Telnet Server enabled FTP Server enabled WEB Timeout 20 Default Gateway 192.168.10.1
Would You Like to Modify the System Parameters <Y or N>[N]:
4-2 3COM Security Switch 6200 Hardware and Software Users Guide
Page 35
Configuring the Security Switch 6200 System
2. To change any of the system parameters enter y, or press the Return key to leave system parameters unchanged.
Enter the System Host Name [hostname]: Enter the System Domain Name []: Enter the Time [15:28:40]: Enter the Date [Apr 07 2003]: Would You Like to Modify the Time Zone <Y or N>[N]:
3. To change the time zone enter y or press the Return key to leave system parameters unchanged.
Select a time zone based on the location of your system.
Select a continent or ocean.
1) Africa
2) Americas
3) Antarctica
4) Arctic Ocean
5) Asia
6) Atlantic Ocean
7) Australia
8) Europe
9) Indian Ocean
10) Pacific Ocean
11) Other (Enter GMT offset) Enter choice <1 - 11>:
Select a country.
1)Antigua & Barbuda 18)Ecuador 35)Panama
2)Anguilla 19)Grenada 36)Peru
3)Netherlands Antilles 20)French Guiana 37)St Pierre & Miquelon
4)Argentina 21)Greenland 38)Puerto Rico
5)Aruba 22)Guadeloupe 39)Paraguay
6)Barbados 23)Guatemala 40)Suriname
7)Bolivia 24)Guyana 41)El Salvador
8)Brazil 25)Honduras 42)Turks & Caicos Is
9)Bahamas 26)Haiti 43)Trinidad & Tobago
10)Belize 27)Jamaica 44)United States
11)Canada 28)St Kitts & Nevis 45)Uruguay
12)Chile 29)Cayman Islands 46)St Vincent
13)Colombia 30)St Lucia 47)Venezuela
14)Costa Rica 31)Martinique 48)Virgin Islands (UK)
15)Cuba 32)Montserrat 49)Virgin Islands (US)
16)Dominica 33)Mexico
17)Dominican Republic 34)Nicaragua
Enter choice <1 - 49>:
3COM Security Switch 6200 Hardware and Software Users Guide 4-3
Page 36
Configuring the Security Switch 6200 System
4. Select a region.
1) Eastern Time
2) Eastern Time - Michigan - most locations
3) Eastern Time - Kentucky - Louisville area
4) Eastern Time - Kentucky - Wayne County
5) Eastern Standard Time - Indiana - most locations
6) Eastern Standard Time - Indiana - Crawford County
7) Eastern Standard Time - Indiana - Starke County
8) Eastern Standard Time - Indiana - Switzerland County
9) Central Time
10) Central Time - Michigan - Wisconsin border
11) Central Time - North Dakota - Oliver County
12) Mountain Time
13) Mountain Time - south Idaho & east Oregon
14) Mountain Time - Navajo
15) Mountain Standard Time - Arizona
16) Pacific Time
17) Alaska Time
18) Alaska Time - Alaska panhandle
19) Alaska Time - Alaska panhandle neck
20) Alaska Time - west Alaska
21) Aleutian Islands
Enter choice <1 - 21>:
5. Define the Management Services.
Enable Telnet Server <disabled, enabled>[enabled]: Enable FTP Server <disabled, enabled>[enabled]: Enter WEB Timeout [20]: Enter Default Gateway [0.0.0.0]:
6. Select option 1 from the main menu to display your changed system parameters. For example:
Enter choice <1 - 12, X>[X]: 1
System ====== Host Name helios Domain Name 3com.com Date and Time Mon Apr 07 15:29:03 EDT 2003 Time Zone America/New_York Telnet Server enabled FTP Server enabled WEB Timeout 20 Default Gateway 192.168.10.1
Would You Like to Modify the System Parameters <Y or N>[N]:
7. Enter y to make further changes or press the Enter key to return to the main menu.
4-4 3COM Security Switch 6200 Hardware and Software Users Guide
Page 37
Configuring the Security Switch 6200 System

Configuring User Accounts

Each system user is defined by the user’s name, password, and access level. Collectively, these properties define each user’s profile. Login access allows you to login into the unix shell, setting this to disabled allows you to only have WEB access. To configure individual user accounts:
1. Select Option 2 from the main menu.
Accounts Configuration ====================== Additional user accounts can be defined, each with there own username and password.
User Accounts =============
User Name Login Access Access Level
admin enabled Administrator
Modify the User Accounts <Add, Delete, Modify or eXit>[eXit]:
2. Enter the desired option and make changes as necessary or enter X to return to the main menu. The following is an example of a user being added:
Modify the User Accounts <Add, Delete, Modify or eXit>[eXit]: a
Enter User Name []: fred Enter password: Verify password: Enable Login Access <disabled, enabled>[disabled]: enabled Enter Access Level <Guest, Network Operator, Service Operator, Administrator>[Guest]: administrator
User Accounts =============
User Name Login Access Access Level
admin enabled Administrator
fred enabled Administrator
3. Enter the desired option and make more changes or enter X to return to the main menu.
Modify the User Accounts <Add, Delete, Modify or eXit>[eXit]:
3COM Security Switch 6200 Hardware and Software Users Guide 4-5
Page 38
Configuring the Security Switch 6200 System

Configuring the Network Time Protocol (NTP)

Configuring Domain Name Resolution

The Network Time Protocol (NTP) is used to synchronize the time of a computer client or server to another server or reference time source, such as a radio or satellite receiver or modem. It provides accuracies typically within a millisecond on LANs and up to a few tens of milliseconds on WANs relative to Coordinated Universal Time (UTC) through a Global Positioning Service (GPS) receiver, for example. Typical NTP configurations utilize multiple redundant servers and diverse network paths in order to achieve high accuracy and reliability.
To configure NTP:
1. Select Option 3 from the main menu.
NTP Servers ===========
xxx.xxx.xx.x
Modify the NTP Servers <Add, Delete or eXit>[eXit]:
2. Enter the desired option and add or delete an NTP server or enter X to return to the main menu.
Domain name resolution allows you translate and search domain names. The Domain Name System (DNS) is a global network of servers that translate host names like www.mycompany.com into numerical IP (Internet Protocol) addresses, for example 24.62.13.19.
To configure domain name resolution:
1. Select Option 4 from the main menu.
Domain Name Resolution Configuration ====================================
1) DNS Servers
2) DNS Search Domains X) Exit
Enter choice <1 - 2, X>[X]: 1
2. Enter the desired option. For example:
Enter choice <1 - 2, X>[X]: 1
DNS Servers =========== Modify the DNS Server List <Add, Delete or eXit>[eXit]: a
DNS Server's IP Address [0.0.0.0]: 10.1.1.50
DNS Servers ===========
10.1.1.50
Modify the DNS Server List <Add, Delete or eXit>[eXit]:
Domain Name Resolution Configuration ====================================
1) DNS Servers
4-6 3COM Security Switch 6200 Hardware and Software Users Guide
Page 39
Configuring the Security Switch 6200 System
2) DNS Search Domains X) Exit
Enter choice <1 - 2, X>[X]: 2
DNS Search Domains ==================
Modify the DNS Domain Search List <Add, Delete or eXit>[eXit]: a
Enter DNS Search Domain []: 3com.com
DNS Search Domains ================== 3com.com
Modify the DNS Domain Search List <Add, Delete or eXit>[eXit]:
Domain Name Resolution Configuration ====================================
1) DNS Servers
2) DNS Search Domains X) Exit

Configuring the Simple Network Management Protocol (SNMP)

Enter choice <1 - 2, X>[X]:
3. Enter the desired option or enter X to return to the main menu.
To configure SNMP:
1. Select Option 5 from the main menu.
SNMP configuration ==================
1) SNMP Server
2) Communities
3) Trap Destinations X) Exit
2. Configure SNMP Servers. For example:
Enter choice <1 - 3, X>[X]: 1
SNMP Server =========== Enabled enabled Contact Root <root@localhost> (configure /etc/snmp/ snmp.local.conf)
Location Unknown (edit /etc/snmp/snmpd.conf)
Would You Like to Modify the SNMP Configuration <Y or N>[N]: y
Enable SNMP Network Management <disabled, enabled>[enabled]: Enter SNMP Contact [Root <root@localhost> (configure /
3COM Security Switch 6200 Hardware and Software Users Guide 4-7
Page 40
Configuring the Security Switch 6200 System
etc/snmp/snmp.local.conf)]: srhen@crossbeamsys.com Enter SNMP Location [Unknown (edit /etc/snmp/ snmpd.conf)]: Lab
SNMP configuration ==================
1) SNMP Server
2) Communities
3) Trap Destinations X) Exit
Enter choice <1 - 3, X>[X]: 1
SNMP Server =========== Enabled enabled Contact lab@3com.com Location The Lab
Would You Like to Modify the SNMP Configuration <y or n>[n]:
3. Enter y to modify the SNMP configuration or n to return to the SNMP Configuration menu.
SNMP configuration ==================
1) SNMP Server
2) Communities
3) Trap Destinations X) Exit
4. Configure SNMP Communities. For example:
Enter choice <1 - 3, X>[X]: 2
SNMP Communities ================
Community Address Netmask Access
Change the SNMP Communities <Add, Delete or eXit>[eXit]: a Enter Community Name []: foobar Enter IP Source Addresses [0.0.0.0/32]: 10.2.1.48/32 Enter Access Mode <read-only, read-write>[read-only]: read-write
4-8 3COM Security Switch 6200 Hardware and Software Users Guide
Page 41
Configuring the Security Switch 6200 System
SNMP Communities ================
Community Address Netmask Access
foobar 10.2.1.48 255.255.255.255 read-write
Change the SNMP Communities <Add, Delete or eXit>[eXit]: a
Enter Community Name []: public Enter IP Source Addresses [0.0.0.0/32]: 10.0.0.0/8 Enter Access Mode <read-only, read-write>[read-only]:
SNMP Communities ================
Community Address Netmask Access
foobar 10.2.1.48 255.255.255.255 read-write
public 10.0.0.0 255.0.0.0 read-only
Change the SNMP Communities <Add, Delete or eXit>[eXit]:
5. Enter the desired option or enter X to return to SNMP Configuration Menu.
SNMP configuration ==================
1) SNMP Server
2) Communities
3) Trap Destinations X) Exit
6. Configure SNMP Trap Destinations. For example:
Enter choice <1 - 3, X>[X]: 3
SNMP Traps ==========
Destination Port Type Version Community
Change the SNMP Trap Destinations <Add, Delete, Modify or eXit>[eXit]: a Enter Trap Destination [0.0.0.0]: 10.2.1.48 Enter Port Number [162]: Enter Trap Type <trap, inform>[trap]: Enter SNMP Version <SNMPv1, SNMPv2c, SNMPv3>[SNMPv1]: Enter Community []: foobar
3COM Security Switch 6200 Hardware and Software Users Guide 4-9
Page 42
Configuring the Security Switch 6200 System
SNMP Traps ==========
Destination Port Type Version Community
10.2.1.48 162 trap SNMPv1 foobar
Change the SNMP Trap Destinations <Add, Delete, Modify or eXit>[eXit]:
7. Enter the desired option or enter X to return to SNMP Configuration Menu.
SNMP configuration ==================
1) SNMP Server
2) Communities
3) Trap Destinations X) Exit
8. Enter the desired option or enter X to return to the main menu.

Configuring Physical Interfaces

There are three types of physical interfaces on the system: management, gigabitethernet, and fastethernet. The management interfaces allow you to manage the configured interfaces.
To configure the physical interfaces:
1. Select Option 6 from the main menu.
Physical Interfaces ===================
MAC Address
Interface
management 1 00:03:47:f1:aa:52 (N) on half 10
management 2 00:03:47:f1:aa:53 (N) on half 10
fastethernet 1 (N) on half 10
fastethernet 2 (N) on half 10
fastethernet 3 (N) on half 10
fastethernet 4 (N) on half 10
fastethernet 5 (N) on half 10
fastethernet 6 (N) on half 10
fastethernet 7 (N) on half 10
fastethernet 8 (N) on half 10
fastethernet 9 (N) on half 10
fastethernet 10 (N) on half 10
fastethernet 11 (N) on half 10
fastethernet 12 (N) on half 10
fastethernet 13 (N) on half 10
(Configured)
Auto neg
Duplex Speed
4-10 3COM Security Switch 6200 Hardware and Software Users Guide
Page 43
Configuring the Security Switch 6200 System
Interface
fastethernet 14 (N) on half 10
fastethernet 15 (N) on half 10
fastethernet 16 (N) on half 10
gigabitethernet 17 (N) on half 10
gigabitethernet 18 (N) on half 10
Modify Physical Interface Parameters <y or n>[n]:
2. Enter y to modify a physical interface or n to return to the main menu. For example:
Modify Physical Interface Parameters <y or n>[n]: y Enter the Interface Name [fastethernet 1]: MAC Address []: 00:00:a2:00:00:01 Auto Negotiate <off, on>[on]: off Duplex <half, full>[half]: full Speed <10, 100, 1000, unknown>[10]:
Physical Interfaces ===================
MAC Address (Configured) Auto
neg
Duplex Speed
MAC Address
Interface
management 1 00:03:47:f1:aa:52 (N) on half 10
management 2 00:03:47:f1:aa:53 (N) on half 10
fastethernet 1 00:00:a2:00:00:01 (Y) off full 10
fastethernet 2 (N) on half 10
fastethernet 3 (N) on half 10
fastethernet 4 (N) on half 10
fastethernet 5 (N) on half 10
fastethernet 6 (N) on half 10
fastethernet 7 (N) on half 10
fastethernet 8 (N) on half 10
fastethernet 9 (N) on half 10
fastethernet 10 (N) on half 10
fastethernet 11 (N) on half 10
fastethernet 12 (N) on half 10
fastethernet 13 (N) on half 10
fastethernet 14 (N) on half 10
fastethernet 15 (N) on half 10
fastethernet 16 (N) on half 10
gigabitethernet 17 (N) on half 10
(Configured)
Auto neg
Duplex Speed
3COM Security Switch 6200 Hardware and Software Users Guide 4-11
Page 44
Configuring the Security Switch 6200 System
Interface
gigabitethernet 18 (N) on half 10
Modify Physical Interface Parameters <Y or N>[N]:
3. Enter y to modify additional physical interfaces or n to return to the main menu.
MAC Address (Configured) Auto
neg
Duplex Speed

Configuring Tap Interfaces

Tap interfaces are used to copy the input and output packets from a physical interface prior to the processing by the firewall acceleration process. These taps can be used by intrusion detection software to sniff the interface. Tap interfaces can be given any device name of up to 15 characters, and a single tap can capture the traffic for multiple physical interfaces. To configure Tap Interfaces:
1. Select Option 7 from the main menu.
Tap Interfaces =============
Name Physical Interfaces
Modify the Tap Interfaces <Add, Delete, Modify or eXit>[eXit]: a
2. Enter the desired option to add, delete, or modify a tap interface or enter x to return to the main menu. For example:
Tap Name []: tap1 Physical Interfaces []: fastethernet 1, fastethernet 2, gigabitethernet 17
Tap Interfaces ============= Name Physical Interfaces tap1 fastethernet 1, fastethernet 2, gigabitethernet 17
Modify the Tap Interfaces <Add, Delete, Modify or eXit>[eXit]:
3. Enter the desired option to add, delete, or modify additional tap interfaces or enter x to return to the main menu. For example:
Tap Name []: tap2 Physical Interfaces []: fastethernet 3
Tap Interfaces ============= Name Physical Interfaces tap1 fastethernet 1, fastethernet 2, gigabitethernet 17 tap2 fastethernet 3
4-12 3COM Security Switch 6200 Hardware and Software Users Guide
Page 45
Configuring the Security Switch 6200 System

Configuring Network Interfaces

A network interface associates an IP address with a physical connection and optionally a VLAN id. To configure network interfaces:
1. Select Option 8 from the main menu.
IP Interfaces =============
Enabled Address Netmask Broadcast MTU
management 1 enabled
2. To add a network interface, select add from the main menu. For example:
Modify the IP Interfaces <Add, Delete, Modify or eXit>[eXit]: a Physical Interface [fastethernet 1]: VLAN Interface <Y or N>[N]: Interface State <disabled, enabled>[enabled]: Enter the IP Address [0.0.0.0/0]: 128.205.1.23/24 Broadcast Address [128.205.1.255]: MTU [1500]:
IP Interfaces =============
192.168.10.6 255.255.255.0 192.168.10.255 1500
Enabled Address Netmask Broadcast MTU
management 1 enabled
fastethernet 1 enabled
3. Enter the desired option to add, delete, or modify additional network interfaces or enter x to return to the main menu. For example:
Modify the IP Interfaces <Add, Delete, Modify or eXit>[eXit]: a Physical Interface [fastethernet 1]: VLAN Interface <Y or N>[N]: y Enter VLAN ID <1 - 4095>: 100 Interface State <disabled, enabled>[enabled]: Enter the IP Address [0.0.0.0/0]: 128.205.2.23/24 Broadcast Address [128.205.2.255]: MTU [1500]:
192.168.10.6 255.255.255.0 192.168.10.255 1500
128.205.1.23 255.255.255.0 128.205.1.255 1500
3COM Security Switch 6200 Hardware and Software Users Guide 4-13
Page 46
Configuring the Security Switch 6200 System
IP Interfaces =============
Enabled Address Netmask Broadcast MTU
management 1 enabled
fastethernet 1 enabled
fastethernet 1 enabled
Modify the IP Interfaces <Add, Delete, Modify or eXit>[eXit]:
4. Enter the desired option to add, delete, or modify additional network interfaces or enter x to return to the main menu.
192.168.10.6 255.255.255.0 192.168.10.255 1500
128.205.1.23 255.255.255.0 128.205.1.255 1500
vlan 100
128.205.2.23
255.255.255.0 128.205.2.255 1500

Configuring IP Aliases

IP aliases are additional network addresses that are assigned to a network interface. To configure IP Aliases:
1. Select Option 9 from the main menu.
IP Aliases ==========
Interface IP Address Netmask Broadcast
Modify the IP Aliases <Add, Delete, Modify or eXit>[eXit]: a
2. Enter the desired option to add, delete, or modify an IP alias or enter x to return to the main menu. For example:
Enter Interface [fastethernet 1]: VLAN Interface <Y or N>[N]: Enter IP Address [0.0.0.0]: 128.205.1.24 Enter Network Mask [255.255.0.0]: 255.255.0.0 Enter Broadcast Address [128.205.255.255]:
IP Aliases ==========
Interface IP Address Netmask Broadcast
fastethernet 1 128.205.1.24 255.255.0.0 128.205.255.255
Modify the IP Aliases <Add, Delete, Modify or eXit>[eXit]: m Enter Interface [fastethernet 1]: VLAN Interface <Y or N>[N]: Enter IP Address [0.0.0.0]: 128.205.1.24 Enter Network Mask [255.255.0.0]: 255.255.255.0 Enter Broadcast Address [128.205.1.255]:
4-14 3COM Security Switch 6200 Hardware and Software Users Guide
Page 47
Configuring the Security Switch 6200 System
IP Aliases ==========
Interface IP Address Netmask Broadcast
fastethernet 1 128.205.1.24 255.255.0.0 128.205.255.255
fastethernet 1 128.205.1.24 255.255.0.0 128.205.1.255
Modify the IP Aliases <Add, Delete, Modify or eXit>[eXit]: a Enter Interface [fastethernet 1]: VLAN Interface <Y or N>[N]: y Enter VLAN ID <1 - 4095>: 100 Enter IP Address [0.0.0.0]: 128.205.2.24 Enter Network Mask [255.255.0.0]: 255.255.255.0 Enter Broadcast Address [128.205.2.255]:
IP Aliases ==========
Interface IP Address Netmask Broadcast
fastethernet 1 128.205.1.24 255.255.0.0 128.205.255.255
fastethernet 1 128.205.1.24 255.255.0.0 128.205.1.255
fastethernet 1 vlan 100
Modify the IP Aliases <Add, Delete, Modify or eXit>[eXit]:
128.205.2.24 255.255.0.0 128.205.2.255
3. Enter the desired option to add, delete, or modify additional IP aliases or enter x to return to the main menu.
3COM Security Switch 6200 Hardware and Software Users Guide 4-15
Page 48
Configuring the Security Switch 6200 System

Configuring Static Routes

Static IP routes are user-defined routes that cause packets moving between a source and a destination to take a specific path.
To configure Static Routes:
1. Select Option 10 from the main menu.
Static Routes =============
Destination Netmask Gateway Metric
2. Enter the desired option to add, delete, or modify a static route or enter x to return to the main menu. For example:
Modify the Static Routes <Add, Delete, Modify or eXit>[eXit]: a Enter Destination [0.0.0.0/0]: 10.0.0.0 Enter Network Mask in dot notation [0.0.0.0]: 255.0.0.0 Enter the Next Hop Gateway [0.0.0.0]: 192.168.10.1 Enter the Metric [1]:
Static Routes =============
Destination Netmask Gateway Metric
10.0.0.0 255.0.0.0 192.168.10.1 1
Modify the Static Routes <Add, Delete, Modify or eXit>[eXit]: a Enter Destination [0.0.0.0/0]: 192.168.20.0/24 Enter the Next Hop Gateway [0.0.0.0]: 192.168.10.1 Enter the Metric [1]: 2
Static Routes =============
Destination Netmask Gateway Metric
10.0.0.0 255.0.0.0 192.168.10.1 1
192.168.20.0 255.255.255.0 192.168.10.1 2
Modify the Static Routes <Add, Delete, Modify or eXit>[eXit]:
3. Enter the desired option to add, delete, or modify additional static routes or enter x to return to the main menu.
4-16 3COM Security Switch 6200 Hardware and Software Users Guide
Page 49
Configuring the Security Switch 6200 System

Configuring Static ARP Entries

You define static Address Resolution Protocol (ARP) entries by relating an IP address to a MAC address.
To configure static ARP entries:
1. Select Option 11 from the main menu.
Static ARP Entries ================== IP Address MAC Address
2. Enter the desired option to add, delete, or modify a static ARP entry or enter x to return to the main menu. For example:
Modify the Static Hosts <Add, Delete, Modify or eXit>[eXit]: a Enter Host IP Address [0.0.0.0]: 128.205.1.30 Enter MAC Address []: 00:00:a2:00:00:02
Static ARP Entries ================== IP Address MAC Address
128.205.1.30 00:00:a2:00:00:02
Modify the Static Hosts <Add, Delete, Modify or eXit>[eXit]: a Enter Host IP Address [0.0.0.0]: 128.205.1.31 Enter MAC Address []: 00:00:a2:00:00:03
Static ARP Entries ================== IP Address MAC Address
128.205.1.30 00:00:a2:00:00:02
128.205.1.31 00:00:a2:00:00:03
Modify the Static Hosts <Add, Delete, Modify or eXit>[eXit]:
3. Enter the desired option to add, delete, or modify additional static ARP entries or enter x to return to the main menu.
3COM Security Switch 6200 Hardware and Software Users Guide 4-17
Page 50
Configuring the Security Switch 6200 System

Configuring the Virtual Router Redundancy Protocol (VRRP)

The Virtual Router Redundancy Protocol (VRRP) dynamically assigns responsibility for one or more virtual routers to the VRRP routers on a LAN, allowing several routers on a multiaccess link to utilize the same virtual IP address. The system can be configured to run the VRRP protocol in conjunction with one or more other systems attached to a LAN.
VRRP which manages automatic switchover from one VPN Concentrator to another in a redundant installation. Automatic switchover provides user access to the VPN even if one VPN is out of service for some reason, for example a system crash, power failure, hardware failure, physical interface failure, system shutdown or reboot.
These functions apply only to installations where two or more VPNs are in parallel, with the Public interfaces of all systems on a common LAN and with the Private and/or External interfaces of all systems on different common LANs. One VPN is the Master system, and the others are Backup systems. A Backup system acts as a virtual Master system when a switchover occurs. VRRP works only on LAN (Ethernet) interfaces, not on WAN interfaces.
To configure VRRP:
1. Select Option 12 from the main menu.
VRRP Configuration ==================
Virtual Router Redundancy Protocol can be defined, each with its own identifier.
4-18 3COM Security Switch 6200 Hardware and Software Users Guide
Page 51
Configuring the Security Switch 6200 System
VRRP Configurations ===================
VRRP ID : 1
Enabled : disabled
VRRP Interface : fastethernet 1
Enable VRRP MAC : disabled
Preemption : disabled
Priority : 100
Advertisement Interval (seconds) : 1
Group ID : 1
IP Addresses : 30.0.0.10
2. Enter the desired option to add, delete, or modify a VRRP entry or enter x to return to the main menu. For example:
Modify the VRRP Configuration <Add, Delete, Modify or eXit>[eXit]: m Enter VRRP ID [0]: 1 Enable <disabled, enabled>[disabled]: enabled Enter Interface [fastethernet 1]: VLAN Interface <Y or N>[N]: Enable VRRP MAC <disabled, enabled>[disabled]: Enable Preemption <disabled, enabled>[disabled]: Enter Priority [100]: Enter Advertisement Interval (seconds) [1]: Enter Group ID [1]: Enter IP Addresses Separated by Comma [30.0.0.10]:
VRRP Configurations ===================
VRRP ID : 1
Enabled : enabled
VRRP Interface : fastethernet 1
Enable VRRP MAC : disabled
Preemption : disabled
Priority : 100
Advertisement Interval (seconds) : 1
Group ID : 1
IP Addresses : 30.0.0.10
Modify the VRRP Configuration <Add, Delete, Modify or eXit>[eXit]: a
3COM Security Switch 6200 Hardware and Software Users Guide 4-19
Page 52
Configuring the Security Switch 6200 System
Enter VRRP ID [0]: 2 Enable <disabled, enabled>[disabled]: Enter Interface [management 0]: fastethernet 1 VLAN Interface <Y or N>[N]: y Enter VLAN ID <1 - 4095>: 100 Enable VRRP MAC <disabled, enabled>[disabled]: enabled Enable Preemption <disabled, enabled>[disabled]: Enter Priority [0]: 100 Enter Advertisement Interval (seconds) [1]: Enter Group ID [0]: 1 Enter IP Addresses Separated by Comma []: 30.0.0.10
VRRP Configurations ===================
VRRP ID : 1
Enabled : enabled
VRRP Interface : fastethernet 1
Enable VRRP MAC : disabled
Preemption : disabled
Priority : 100
Advertisement Interval (seconds) : 1
Group ID : 1
IP Addresses : 30.0.0.10
VRRP ID : 2
Enabled : disabled
VRRP Interface : fastethernet 1
vlan 100
Enable VRRP MAC : enabled
Preemption : disabled
Priority : 100
Advertisement Interval (seconds) : 1
Group ID : 1
IP Addresses : 30.0.0.10
4-20 3COM Security Switch 6200 Hardware and Software Users Guide
Page 53
Configuring the Security Switch 6200 System

Exiting from the Configuration Tool

Saving Your System Configuration

Restoring Your System Configuration

To exit from the system Configure Tool, select Option X from the main menu.
Enter choice <1 - 12, X>[X]: X
To save your configuration, at the admin prompt, use the following command:
[admin@xxxxx bin]# ./cos_show_system -f /directory/ filename
Where the directory specifies the directory where the file is located, and the filename is the actual configuration file. The following is an example of this command:
[admin@helios bin]$ ./cos_show_system -f /tmp/foo
To restore your configuration to its previous configuration, at the admin prompt, use the following command:
[admin@xxxxx bin]# ./cos_set_system -f /directory/ filename
Where the directory specifies the directory where the file is located, and the filename is the actual configuration file. The following is an example of this command:
[admin@helios bin]$ ./cos_set_system -f /tmp/foo

Displaying Your System Configuration

To display a configuration, at the admin prompt, use the following command:
[admin@xxxxx bin]# ./cos_show_system
The following is an example of this command:
[admin@helios bin]$ ./cos_show_system
<system>
<data hostname="helios" domainname="3com.com" timezone="America/New_York" telnet_server="enabled" ftp_server="enabled" gateway="192.168.10.1" </data> </system>
<ntp_server> <data address="127.127.1.0" ></data>
</ntp_server> <dns_server> <data
3COM Security Switch 6200 Hardware and Software Users Guide 4-21
Page 54
Configuring the Security Switch 6200 System
address="10.1.1.50" ></data> </dns_server>
<dns_search> <data domainname="3com.com" ></data> </dns_search>
<snmp_server> <data enable="enabled" contact="lab@3com.com" location="The Lab" ></data> </snmp_server>
<snmp_community> <data community="foobar" address="10.2.1.48" access="read-write" ></data> <data community="public" address="10.0.0.0" mask="255.0.0.0" ></data>
</snmp_community> <snmp_trap_destination> <data host="10.2.1.48" community="foobar" ></data> </snmp_trap_destination>
<physical_interface> <data ifname="fastethernet 1" mac_addr="00:00:a2:00:00:01" autoneg="off" duplex="full" speed="10" ></data> <data ifname="fastethernet 15" autoneg="off" duplex="half" speed="100" ></data> </physical_interface>
4-22 3COM Security Switch 6200 Hardware and Software Users Guide
Page 55
Configuring the Security Switch 6200 System
<ip_interface> <data ifname="management 1" address="192.168.10.6" ></data> <data ifname="fastethernet 1" address="128.205.1.23" mask="255.255.255.0" ></data> <data ifname="fastethernet 1" vlan="100" address="128.205.2.23" mask="255.255.255.0" ></data> </ip_interface>
<ip_alias> <data ifname="fastethernet 1" address="128.205.1.24" mask="255.255.255.0" ></data> <data ifname="fastethernet 1" vlan="100" address="128.205.2.24" mask="255.255.255.0" ></data> </ip_alias>
<static_route> <data destination="10.0.0.0" mask="255.0.0.0" gateway="192.168.10.1" ></data> <data destination="192.168.20.0" mask="255.255.255.0" gateway="192.168.10.1" metric="2" ></data> </static_route>
<static_host> <data ip_addr="128.205.1.30" mac_addr="00:00:a2:00:00:02" ></data> <data
3COM Security Switch 6200 Hardware and Software Users Guide 4-23
Page 56
Configuring the Security Switch 6200 System
ip_addr="128.205.1.31" mac_addr="00:00:a2:00:00:03" ></data> </static_host>
<account> <data username="admin" shell="enabled" access_level="Administrator" ></data> <data username="foobar" shell="enabled" ></data> <data username="fred" shell="enabled" access_level="Administrator" ></data> </account>
<tap_interface> <data tapname="tap1" ifnames="fastethernet 1, fastethernet 2, gigabitethernet 17" ></data> <data tapname="tap2" ifnames="fastethernet 3" ></data> </tap_interface>
<vrrp> <data enabled="enabled" name="fastethernet 1" id="1" priority="100" group_id="1" ip_addr="30.0.0.10" ></data> <data name="fastethernet 1" vlan="100" id="2" use_vmac="enabled" priority="100" group_id="1" ip_addr="30.0.0.10"
4-24 3COM Security Switch 6200 Hardware and Software Users Guide
Page 57
Configuring the Security Switch 6200 System
></data> </vrrp>

Restoring the system to Factory Default Settings

Getting Help Within the Configuration Tool

To delete the current configuration and return the system to its factory defaults, use the following command at the admin prompt.
NOTE: The IP address of interface Management 1, telnet, and the default gateway are left in tact. This done in the event you telneted into the box.
[admin@xxxxx bin]$ ./cos_reset_system
To receive help from within the system Configuration Tool, use the following command at the admin prompt.
[admin@xxxxx bin]$ ./cos_show_system --help
The following options can be used within this Help system:
cos_show_system [OPTION...]
-v, --version - displays the current configuration tool version number.
-h, --help - displays the configuration tool’s help system.
-f, --file=STRING - displays the configuration output file. The default value is stdout.
-d, --default - tells the Help system to include default values.
3COM Security Switch 6200 Hardware and Software Users Guide 4-25
Page 58
Configuring the Security Switch 6200 System
4-26 3COM Security Switch 6200 Hardware and Software Users Guide
Page 59
Upgrading the System
Software
This chapter describes how to update your 3COM Security Switch 6200 system software.

Upgrading the System Software

If you are upgrading your system from a previously configured release, you do not need to use the full system software. Instead, you can use the software upgrade patch.
NOTE: "upgradepack-ocode-A*-1.0.0-11-2.1.4-17.shar.gz" is the upgrade pack that will enable you to upgrade from 2.1.x to 2.1.4 (x = 0,1,2). To do this, complete the following:
1. Login to your system Console port as Root.
2. Change to the root directory, using the following command:
cd /root
3. Create a directory, using the following command:
mkdir upgradepack-X.X.X-X
Where X.X.X-X, is the current software version. For this release X sequence is 2.1.4-17
4. FTP or copy the file called cos-upgradepack-ocode-AZZZ-Y.Y.Y-Y- X.X.X-X.shar.gz from your system Software CDROM or software package to the /root/upgradepack-X.X.X-X.
5. Change the directory to upgradepack-X.X.X-X, using the following command:
cd upgradepack-X.X.X-X
6. Enter the following command at the root prompt:
gzip –d upgradepack-ocode-AZZZ-Y.Y.Y-Y-X.X.X-X.shar.gz
3COM Security Switch 6200 Hardware and Software Users Guide 5-1
Page 60
Upgrading the System Software
7. Once the above command completes, enter the following command at
8. Once the above command completes, enter the following command at
NOTE: Once this action completes successfully, your system software is upgraded.
You may notice "Exec'ed Program Error" being displayed on your screen during the upgrade process if upgrading from a release prior to 2.1.3. Please ignore these error messages. Your system will still be upgraded properly
9. Reboot your system.
the root prompt:
chmod 700 cos-upgradepack-ocode-AZZZ-Y.Y.Y-Y-X.X.X­X.shar
the root prompt:
./cos-upgradepack-ocode-AZZZ-Y.Y.Y-Y-X.X.X-X.shar
Answer "Y" when this command prompts you.
5-2 3COM Security Switch 6200 Hardware and Software Users Guide
Page 61
Upgrading the System
Software Using
the Safe Upgrade and
Rollback Features
Your system ships with two disk partitions, one partition is used for the current runtime (RP) version of software and the other partition is for the upgraded (UP) version of software. Each partition provides 20 Gigabytes of disk space.
This chapter describes how to update your system software, and how to utilize these partitions.

Using Multiple Versions of Software (Safe Upgrade)

Upgrading from Version
2.0
Using two partitions, your system allows you to upgrade your system software while maintaining a previous version of your configuration. The following sections describe how to accomplish this.
To upgrade your system from Version 2.0 to a newer release, while saving your current configuration, complete the following:
1. Connect to Console port as described in the previous section.
2. Partition your disk for dual boot. Note that this only has to be accomplished once. To do this, from root prompt, enter the following command:
fdisk /dev/ataraid/d0
3. Within the fdisk command, display a print(p) disk layout by entering the letter “p”. A display similar to the following displays:
/dev/ataraid/d0p1 * 1 13 104422 83 Linux
# /boot
3COM Security Switch 6200 Hardware and Software Users Guide 6-1
Page 62
Upgrading the System Software Using the Safe Upgrade and Rollback Features
/dev/ataraid/d0p2 14 79 530145 82 Linux swap /dev/ataraid/d0p5 80 882 6450097 83 Linux # / /dev/ataraid/d0p6 883 2070 9542609+ 83 Linux
# /opt /dev/ataraid/d0p7 2071 2435 2931862 83 Linux
# /var
4. Duplicate the above table for the dual boot by entering the letter “n” five times. This adds the following partitions:
Add(n) the following logical(l) partitions in cylinders
partition cylinders partition
8 +12 /boot
9 +65 swap
10 +802 /
11 +1187 /opt
12 +* /var
5. Toggle(t) the swap partition identification from 9 to 82 by entering the letter “t”.
6. Save(w) the partition table by entering the letter “w”.
7. Reboot your system.
You can also perform the software upgrade when you reboot your system using the Install Server. To do this, complete the following:
1. Check to make sure you have the right version of install-cos. To do this:
At root prompt, enter:
/usr/os/sbin/install-cos -h
The following displays:
Usage: /usr/os/sbin/install-cos [OPTION]... <COS RPM DIR>
Install a C30 release h, help p <id>, part of disk to install to, 1 or 2
2. Execute the following command:
shell> dd if=/dev/zero of=/dev/ataraid/d0 bsQ2 count=1
3. Execute the following:
/usr/os/bin/install
4. Reboot and re-run /usr/os/bin/install.
6-2 3COM Security Switch 6200 Hardware and Software Users Guide
Page 63
Upgrading the System Software Using the Safe Upgrade and Rollback Features
Upgrading from Version
2.1 and Greater
Newer versions of Version 2.1 and greater allow you to do a full copy of the Running Partition (RP) to an Upgrade Partition (UP) before actually upgrading your system software.
To do this:
1. Make sure you are connected to the console.
2. Reboot your system into single user mode. To do this, at the root prompt, enter:
init 1
3. Once the system boots into single user prompt, enter the following:
/usr/os/sbin/cos-copy-dist -p 2
This copies your entire RP disk contents into the UP. This is a total disk copy and everything on the RP is copied to UP, including the application configurations.
4. Once the copy is complete, enter the following:
/usr/os/bin/cos_toggle other
5. Reboot your system. Your system is booted into the UP.
6. Upgrade your system software or applications, as needed.
7. Reboot if necessary.
If all upgrades are working normally, you are now on the UP (partition set 2). If, however, your upgrades fail, your system fails to boot up, or crashes, then you must reboot and when you get the bootup choices for the kernel under Grub, select the Chains option. Alternatively, if you are able to get to the root prompt but still do not want to upgrade, enter the following:
/usr/os/bin/cos_toggle other
NOTE: To view the current partition, enter the following:
/usr/os/bin/cos_toggle
The default value is “/vmlinuz-2.4.18-5” and indicates your original RP.
To list possible selections, enter the following:
/usr/os/bin/cos_toggle -l
The “other” value indicates the second part of the disk, which is your UP.
Then reboot system.
To go back to the original partition (RP) that was working properly, reboot the system.
3COM Security Switch 6200 Hardware and Software Users Guide 6-3
Page 64
Upgrading the System Software Using the Safe Upgrade and Rollback Features

Upgrading from Software to a UP While an RP is Operational (Rollback)

Newer versions than 2.1 and greater allow you to install the system software to a UP while an RP is operational. This is done using /usr/os/sbin/install-cos. Install-cos can install to either part 1 or 2 of the disk. You can run install-cos while the system is booted from the install server or the system is running off the disk.
!
CAUTION:
Caution: Reboot into the UP first, making sure the UP is working, then upgrade within the UP, leaving the good RP alone.
To install to the UP of your system while the system is running with the RP:
1. Enter the following command:
/usr/os/sbin/install-cos -p 2 <release directory>
2. Manually configure the UP identically to the RP (System configuration and applications).
3. Switch to the RP and upgrade the RP.
4. If upgrades work correctly you are done. If, however, the upgrades fail, reboot the system. By default the system boots with the functional UP.
6-4 3COM Security Switch 6200 Hardware and Software Users Guide
Page 65

Technical Support

3Com provides easy access to technical support information through a variety of services. This chapter describes these services.
Information contained in this chapter is correct at time of publication. For the most recent information, 3Com recommends that you access the 3Com Corporation World Wide Web site.

Online Technical Services

World Wide Web Site

3Com offers worldwide product support 24 hours a day, 7days a week, through the following online systems:
World Wide Web site
3Com Knowledgebase Web Services
3Com FTP site
To access the latest networking information on the 3Com Corporation World Wide Web site, enter this URL into your Internet browser:
http://www.3com.com/
This service provides access to online support information such as technical documentation and software library, as well as support options that range from technical education to maintenance and professional services.
3COM Security Switch 6200 Hardware and Software Users Guide 7-1
Page 66
Technical Support

3Com Knowledgebase Web Services

The 3Com Knowledgebase is a database of technical information to help you install, upgrade, configure, or support 3Com products. The Knowledgebase is updated daily with technical information discovered by 3Com technical support engineers. This complimentary service, which is available 24 hours a day, 7 days a week to 3Com customers and partners, is located on the 3Com Corporation World Wide Web site at:
http://www.knowledgebase_3com.com/

3Com FTP Site

Download drivers, patches, software, and MIBs across the Internet from the 3Com public FTP site. This service is available 24 hours a day, 7 days a week.
To connect to the 3Com FTP site, enter the following information into your FTP client:
Hostname: ftp.3com.com
Username: anonymous

Support from Your Network Supplier

Password: <your Internet e-mail address>
Note: You do not need a user name and password with Web browser software such as Netscape Navigator and Internet Explorer.
If you require additional assistance, contact your network supplier. Many suppliers are authorized 3Com service partners who are qualified to provide a variety of services, including network planning, installation, hardware maintenance, application training, and support services.
When you contact your network supplier for assistance, have the following information ready:
Product model name, part number, and serial number
A list of system hardware and software, including revision levels
Diagnostic error messages
Details about recent configuration changes, if applicable
If you are unable to contact your network supplier, see the following section on how to contact 3Com.
7-2 3COM Security Switch 6200 Hardware and Software Users Guide
Page 67
Technical Support

Support from 3Com

Email Support

If you are unable to obtain assistance from the 3Com online technical resources or from your network supplier, 3Com offers email and telephone technical support services. To find out more about your support options, email or call the 3Com technical support services at the location nearest you.
Some 3Com regions offer an email support service. To access this service for your region, use the appropriate URL or email address from the list below.
Asia, Pacific Rim
From this region, email: apr_technical_support@3com.com
Europe, Middle East and Africa
Enter the URL: http://emea.3com.com/support/email.html
Latin America
Spanish speakers, enter the URL: http://lat.3com.com/lat/support/ form.html
Portuguese speakers, enter the URL: http://lat.3com.com/br/support/ form.html
English speakers, email: lat_support_anc@3com.com

Telephone Support

When you contact 3Com for assistance, have the following information ready:
The following table provides a list of worldwide technical telephone support numbers. These numbers are correct at the time of publication. Refer to the 3Com Web site for updated information.
Product model name, part number, and serial number
A list of system hardware and software, including revision levels
Diagnostic error messages
Details about recent configuration changes, if applicable
3COM Security Switch 6200 Hardware and Software Users Guide 7-3
Page 68
Technical Support
Telephone Support Numbers
Country Telephone Number Country Telephone Number
Asia, Pacific Rim
Australia India
Indonesia Malaysia New Zealand Pakistan Philippines
Singapore S. Korea
Taiwan Thailand
1 800 678 515 +61 2 9424 5179 or 000800 6501111 001 803 61 009 1800 801 777 0800 446 398 +61 2 9937 5083 1235 61 266 2602 or +61 2 9937 5076 800 6161 463 00798 611 2230 or 02 3455 6455 0080 611 261 001 800 611 2000
Europe, Middle East and Africa
From anywhere in these regions, call:
Austria Belgium (Flemish) Belgium (French) Denmark Finland France Germany Hungary Ireland Israel Italy Luxembourg Netherlands Norway Poland Portugal South Africa Spain Sweden Switzerland U.K.
+44 (0)1442 435529 phone
01 7956 7124 070 700 000 070 700 770 7010 7289 01080 2783 0825 809 622 01805 404 747 06800 14466 1800 509359 1800 943 2632 199 161346 800 29880 0900 777 7737 815 33 047 00800 441 1357 707 200 123 0800 991196 9 021 60455 07711 14453 08488 50112 0870 241 3901
7-4 3COM Security Switch 6200 Hardware and Software Users Guide
Page 69
Technical Support
Country Telephone Number Country Telephone Number
Latin America
North America 1 800 876 3266
From the Caribbean, Central and South America, call: Antigua Argentina Aruba Bahamas Barbados Belize Bermuda Bonaire Brazil Cayman Chile Colombia Costa Rica Curacao Ecuador Dominican Republic Guatemala Haiti Honduras Jamiaca Martinique Mexico Nicaragua Panama Paraguay Peru Puerto Rico Salvador Trinidad and Tobago Uruguay Venezuela Virgin Islands
1 800 988 2112 0 810 444 3COM 1 800 998 2112 1 800 998 2112 1 800 998 2112 52 5 201 0010 1 800 998 2112 1 800 998 2112 0800 13 3COM 1 800 998 2112 AT&T +800 998 112 AT&T +800 998 2112 AT&T +800 998 2112 1 800 998 2112 AT&T +800 998 2112 AT&T +800 998 2112 AT&T +800 998 2112 57 1 657 0888 AT&T +800 998 2112 1 800 998 2112 571 657 0888 01 800 849CARE AT&T +800 998 2112 AT&T +800 998 2112 54 11 4894 1888 AT&T +800 998 2112 1 800 998 2112 AT&T +800 998 2112 1 800 998 2112 AT&T +800 998 2112 AT&T +800 998 2112 57 1 657 0888
3COM Security Switch 6200 Hardware and Software Users Guide 7-5
Page 70
Technical Support

Returning Products for Repair

Before you send a product directly to 3Com for repair, you must first obtain an authorization number. Products sent to 3Com without authorization numbers will be returned to the sender unopened, at the sender's expense.
You can obtain an authorization number (called an RMA) by entering the following URL into your Internet browser:
http://www.3com.com/support/en_US/repair
Alternatively, you can obtain an RMA by calling or faxing one of the numbers in the following table:
Fax Numbers for return authorization numbers
Country Telephone Number Fax Number
Asia, Pacific Rim +65 543 6500 +65 543 6348
Europe, Middle East and Africa
Austria Belgium (Flemish) Belgium (French) Denmark Finland France Germany Hungary Ireland Israel Italy Luxembourg Netherlands Norway Poland Portugal South Africa Spain Sweden Switzerland U.K.
USA and Canada 1 800 876 3266 1 508 323 6061 (not toll free)
+44 (0)1442 435529
01 7956 7124 070 700 000 070 700 770 7010 7289 01080 2783 0825 809 622 01805 404 747 06800 14466 1800 509359 1800 943 2632 199 161346 800 29880 0900 777 7737 815 33 047 00800 441 1357 707 200 123 0800 991196 9 021 60455 07711 14453 08488 50112 0870 241 3901
7-6 3COM Security Switch 6200 Hardware and Software Users Guide
Page 71
Technical Support
Country Telephone Number Fax Number
Latin America
Antigua Argentina Aruba Bahamas Barbados Belize Bermuda Bonaire Brazil Cayman Chile Colombia Costa Rica Curacao Ecuador Dominican Republic Guatemala Haiti Honduras Jamiaca Martinique Mexico Nicaragua Panama Paraguay Peru Puerto Rico Salvador Trinidad and Tobago Uruguay Venezuela Virgin Islands
1-800-988-2112 0-810-444-3COM 1-800-998-2112 1-800-998-2112 1-800-998-2112 52-5-201-0010 1-800-998-2112 1-800-998-2112 0800-13-3COM 1-800-998-2112 AT&T +800-998-2112 AT&T +800-998-2112 AT&T +800-998-2112 1-800-998-2112 AT&T +800-998-2112 AT&T +800-998-2112 AT&T +800-998-2112 57-1-657-0888 AT&T +800-998-2112 1-800-998-2112 57-1-657-0888 01-800-849CARE AT&T +800-998-2112 AT&T +800-998-2112 54-11-4894-1888 AT&T +800-998-2112 1-800-998-2112 AT&T +800-998-2112 1-800-998-2112 AT&T +800-998-2112 AT&T +800-998-2112 57-1-657-0888
3COM Security Switch 6200 Hardware and Software Users Guide 7-7
Page 72
Technical Support
7-8 3COM Security Switch 6200 Hardware and Software Users Guide
Page 73

Technical Specifications

This appendix lists the physical, environmental, and power characteristics of the 3COM Security Switch 6200.

Physical Characteristics

A
Size (Inches): 3.5 H x 17.5 W x 25.5 D Weight: approximately 32 lbs

Environmental Characteristics

Operating Temperature: 0 to +40 degrees C Storage Temperature: -20 to +65 degrees C Relative Humidity: 10 to 95 percent, non-conducting Operating Altitude: 0 to 10,000 feet above sea level

Power Characteristics

Power: 100 to 240 VAC, 350W
3COM Security Switch 6200 Hardware and Software Users Guide A-1
Page 74
Technical Specifications
A-2 3COM Security Switch 6200 Hardware and Software Users Guide
Page 75

Connector Pin Assignments

This appendix describes the craft port pin assignments:
The Craft port, located on the front of the system, uses a DB- 9 connector with the following pin identifications and associated signals.
DB-9 Connector Pin Number Signal
B
1 No Connection
2 TDX
3 RXD
4 DSR
5 GND
6 DTR
7 CTS
8 RTS
9 No Connection
3COM Security Switch 6200 Hardware and Software Users Guide B-1
Page 76
Connector Pin Assignments
B-2 3COM Security Switch 6200 Hardware and Software Users Guide
Page 77

Regulatory Information

This appendix provides the following compliance statements:
Regulatory Standards Compliance
Radio Frequency Interference
VCCI Statement
C

Regulatory Standards Compliance

The following regulatory agencies have approved the 3COM Security Switch 6200 and have found it to be fully compliant with their environmental, safety, and emissions standards.

CE marking for the EEA (European Economic Area)

Low Voltage Directive 73/23/EEC
EMC Directive 89/336/EEC

Safety

IEC 60950
UL 60950
CSA C22.2 No. 60950

Factory Approvals

UL/CSA
3COM Security Switch 6200 Hardware and Software Users Guide C-1
Page 78
Regulatory Information

EMI Compliance

Radio Frequency Interference

In accordance with FCC Part 15 Subpart B requirements, changes or modifications made to this equipment not expressly approved by 3COM Corporation could void the user’s authority to operate this equipment.
The 3COM Security Switch 6200 is designed for Class A use only. Do not attempt to use this equipment in a domestic environment, which requires Class B distinction. The system may cause interference with domestic products.
This equipment produces electromagnetic energy at radio frequencies and, if not installed and operated in accordance with 3COM instructions, as contained in this document, could cause interference to radio communications and/or interfere with the operation of other RF devices. This equipment has been tested and found to comply with the limits for a Class A Computing Device pursuant to Subpart B of Part 15 of the FCC Rules, which are designed to provide reasonable protection against such interference when the equipment is operated in a commercial environment. Operation of this equipment in a residential area may cause interference. Should this occur, the user may be required to discontinue operation of the equipment, or take other such measures as may be adequate to rectify the condition at the user’s expense.
NOTE

VCCI Statement V-3/2000.04

This is a Class A product based on the standards of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions.

Other EMI Approvals

EN 55022
AS/NZS 3548:95
BSMI CNS 13438 Class A

Immunity Compliance

The system meets all EN 55024 immunity testing.
C-2 3COM Security Switch 6200 Hardware and Software Users Guide
