3COM 3C990BSVR, 3C990B-TX-M User Manual

User Guide

10/100 PCI Network Interface Card with 3XP Processor

3C990B-TX-M 3C990BSVR

10/100 Mbps PCI Client/Server Network Interface Cards

http://www.3com.com htt;://www.3com.com/productreg

09-1742-002 Published July 2001

3Com Corporation

Copyright © 2001 3Com Corporation. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from 3Com Corporation.

3Com Corporation reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of 3Com Corporation to provide notification of such revision or change.

3Com Corporation provides this documentation without warranty, term, or condition of any kind, either implied or expressed, including, but not limited to, the implied warranties, terms or conditions of merchantability, satisfactory quality, and fitness for a particular purpose. 3Com may make improvements or changes in the product(s) and/or the program(s) described in this documentation at any time.

If there is any software on removable media described in this documentation, it is furnished under a license agreement included with the product as a separate document, in the hard copy documentation, or on the removable media in a directory file named LICENSE.TXT or !LICENSE.TXT. If you are unable to locate a copy, please contact 3Com and a copy will be provided to you.

UNITED STATES GOVERNMENT LEGEND

If you are a United States government agency, then this documentation and the software described herein are provided to you subject to the following:

All technical data and computer software are commercial in nature and developed solely at private expense. Software is delivered as “Commercial Computer Software” as defined in DFARS 252.227-7014 (June 1995) or as a “commercial item” as defined in FAR 2.101(a) and as such is provided with only such rights as are provided in 3Com’s standard commercial license for the Software. Technical data is provided with limited rights only as provided in DFAR 252.227-7015 (Nov 1995) or FAR 52.227-14 (June 1987), whichever is applicable. You agree not to remove or deface any portion of any legend provided on any licensed program or documentation contained in, or delivered to you in conjunction with, this User Guide.

Portions of this documentation are reproduced in whole or in part with permission from (as appropriate).

Unless otherwise indicated, 3Com registered trademarks are registered in the United States and may or may not be registered in other countries.

3Com, Dynamic Access , EtherCD, and EtherDisk are registered trademarks and the 3Com logo is a trademark of 3Com Corporation or its subsidiaries.

OpenView is a registered trademark of Hewlett-Packard Company. Intel and Pentium are registered trademarks of Intel Corporation. Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation. Netscape is a registered trademark of Netscape Communications Corporation. NetWare and Novell are registered trademarks of Novell, Inc. All other company and product names may be trademarks of the respective companies with which they are associated.

All other company and product names may be trademarks of the respective companies with which they are associated.

5400 Bayfront Plaza

■

Santa Clara, California

■

95052-8145

■

U.S.A.

■

Contents

About This Guide

Conventions 1

Introduction

Onboard 3XP Processor 3 Data Encryption 3

High Encryption Pack for Windows 2000 4

3C990B Client and Server NIC Features 4

Windows 2000 Ofﬂoad Features 5 Remote Wake-Up 5

Remote Wake-Up Requirements 6

Remote Wake-Up and Multiple NIC Installations 6 Integrated Boot ROM with Managed PC Boot Agent (MBA) 6 Desktop Management Interface (DMI) 2.0 6 Remote System Alerts 7 Remote Control 7 Keep-Alive 7 Hot Plug NIC Installation 8 Flow Control Features 8

Pause Frames 8

Link Negotiation 8 Ofﬂine Diagnostics 8

3C990BSVR Server NIC Features 9

3Com Dynamic

Load Balancing 9

Self-Healing Drivers 9

Failover 10

VLANs 10

Trafﬁc Prioritization 11 Server Features Using Other NICs 11

Access Advanced Server Features 9

Installing and Connecting the NIC

Installation Overview 13

Safety Precautions 13 Installation Requirements 14 Installing Multiple NICs 14 Upgrading Windows 95 to Windows 98 14 Upgrading Windows 98 to Windows Me 15 Updating the Network Driver and NIC Software 15

Contents

Installing From Diskette 15

Making a DOS-Bootable Diskette 15

Creating Installation Diskettes 15 Product Registration 16 Preparing the NIC and the Computer 16 Installing and Connecting the NIC 18 Connecting the Remote Wake-Up Cable 19 Installing Software 20

Installing NIC Drivers and Diagnostics For Windows

Software Installation Requirements 21 Getting Help 21 Installing the Network Driver Using the

Before Installing the Network Driver 21

Windows 2000 22

Installing the Driver 22 Verifying the Driver Installation 23

Windows NT 4.0 23

Installing the Driver 23 Verifying the Driver Installation 24

Windows Me 25

Installing the Driver 25 Verifying the Driver Installation 25

Windows 98 26

Installing the Driver 26 Verifying the Driver Installation 26

Windows 95 27

Installing the Driver 27

Verifying the Driver Installation 29 Installing the 3Com NIC Diagnostics Program 29 Starting the 3Com NIC Diagnostics Program 30 Updating the Network Driver and NIC Software 31 Installing Multiple NICs 31

Windows 2000, Windows Me, Windows 98, and Windows 95 31 Windows NT 4.0 32

EtherCD 21

Installing and Conﬁguring Data Encryption Ofﬂoads

Overview 33

Ofﬂoading Encryption Processing 33 Selecting Basic or Strong Encryption Processing 34

Enabling Data Encryption 34

Overview 34 Downloading the 3Com Security Software Utility 34

Installing Data Encryption 36 Disabling Data Encryption 37 Upgrading Data Encryption 37

Conﬁguring IPSec In Windows 2000 38

Creating a Security Policy 38

Deﬁning the Console 38 Creating the Policy 39 Creating a Filter 39 Binding the Filter 40 Creating the Filter Action 40 Binding the Filter Action 41 Enabling Encryption 41 Disabling Encryption 41

Installing 3Com Advanced Server Features For Windows

Installing 3Com Advanced Server Software 43

Verifying Successful Installation 44 Conﬁguring Groups and VLANs for a Server NIC 44

Planning the Conﬁguration 45

Working With Server Features 46

Windows 2000 46

Windows NT 47 Creating a Group 47 Adding NICs to a Group 47 Specifying a Dedicated IP Address 48 Changing an IP Address 48 Creating a VLAN 49 Specifying Trafﬁc Priorities 49 Saving the Conﬁguration 49 Disabling Load Balancing for a Group 50 Changing the Primary NIC 50 Removing a NIC from a Group 50 Deleting or Editing a VLAN 50 Displaying NIC Properties 51 Displaying Group Properties 51 Troubleshooting a Load Balancing Conﬁguration 51 Changing Windows 2000 Property Settings 52 Identifying Windows 2000 Miniport and LAN Connections 52

Using Windows 2000 Ofﬂoad Features 52

Enabling Ofﬂoads 53 Conﬁguring Ofﬂoads for a Group of Different NICs 54

Contents

Installing NetWare Drivers

Installing and Conﬁguring the NetWare Driver 55

Using the Latest Support Packs 55 Obtaining NetWare Loadable Modules 56 Server Software Installation Requirements 56

Netware Packet Receive Buffers 56

Slot Numbers for Multiple NICs 57

Obtaining Slot Numbers 57

Contents

Installing the NetWare 3.12 Server Driver 57 Installing the Server Driver for NetWare 4.11 and 5.x Using INETCFG 58 Installing the Server Driver and Advanced Server Features Using AUTOEXEC.NCF 59

Loading the 3Com

Copying the Driver 60

Specifying the Slot Number 60

Loading the Driver 60

Setting Up Another NIC 61 Installing Multiple Server NICs 61 Verifying the PCI Slot Number 61 Installing Server Features 62 Conﬁguring Groups 62 Verifying the Installation and Conﬁguration 64

Changing NetWare Driver Conﬁguration Parameters 65 Maintaining Groups 65

Planning the Conﬁguration 66 Adding a Secondary NIC to a Group 66 Adding a Group 67 Server Feature Commands 69

group 69

display status 69

help 70

link timeout 70

probe interval 70

receive timeout 70

retry count 71

send timeout 71

ungroup 71

wait timeout 72 Troubleshooting a Group Conﬁguration 72

EtherCD 59

Conﬁguring the NIC

Default NIC Settings 73 Conﬁguration Methods 75 Changing General NIC Conﬁguration Settings 76

Using the 3Com NIC Diagnostics Program 76 Using the 3Com DOS Conﬁguration Program 77

Conﬁguring the Managed PC Boot Agent (MBA) 77

Enabling or Disabling the Boot ROM Setting 77 Booting From the Network 78

BBS BIOS-Compatible PCs 78

Non-BBS BIOS-Compatible PCs 79

Disabling the 3Com Logo 79

Troubleshooting the NIC

Interpreting the NIC LEDs 81

Viewing the NIC LEDs in the Diagnostics Program 82 Troubleshooting Problems with the LEDs 82

Accessing 3Com Support Databases 82

Accessing the 3Com Knowledgebase 82 Accessing the 3Com NIC Help System 82 Accessing Release Notes and Frequently Asked Questions 83

Troubleshooting the NIC Installation 83

Problems/Error Messages 83 Cleaning Up a Broken Installation 83

Troubleshooting the Network Connection 84 Troubleshooting Remote Wake-Up 85 Troubleshooting a Network Connection 86

Troubleshooting Hubs 87 Cabling Pinouts 87

Removing the Network Driver 87

Windows 2000 87 Windows NT 4.0 88 Windows 95, 98, and Me 88

Removing 3Com Dynamic

Windows NT 4.0 89 Windows 2000 89 NetWare 90

Access Advanced Server Features 89

Contents

Running NIC Diagnostics

Running the 3Com DOS Diagnostics Program 91 Running the NIC Diagnostics Tests 92

Running the Network Test 93 Running the NIC Test 93

Viewing the NIC LEDs in the 3Com Diagnostics Program 93 Viewing Network Statistics 94 Using the 3Com Icon in the Windows System Tray 94

Enabling the Icon 94 Displaying Network Statistics 95

Removing the 3Com NIC Diagnostics Program 95

Speciﬁcations and Cabling Requirements

3C990B NIC Speciﬁcations 97 Cabling Requirements 98 RJ-45 Connector Pin Assignments 98

Installing the 3Com DMI Agent

About the 3Com DMI Agent 99 System Requirements 99

Client PC Requirements 99 Network Management Requirements 100

Installing the 3Com DMI Agent 100

Contents

EtherCD Content and Navigation

Root Subdirectories List 104 Enabling Auto Insert 104 Text Files List 105

Installing a 3Com NIC While Installing the NOS

Windows Fresh Installation 107

Windows NT 107 Windows 2000 107

NetWare Fresh Installation 107

Requirements 107 Installation Instructions 107

Technical Support

Online Technical Services 109

World Wide Web Site 109 3Com Knowledgebase Web Services 109 3Com FTP Site 109

Support from Your Network Supplier 110 Support from 3Com 110 Returning Products for Repair 112

Index

Regulatory Compliance Information

FCC Class B Statement FCC Declaration of Conformity Industry Canada Class B Emission Compliance Statement Avis de Conformité à la Réglementation d’Industrie Canada VCCI Class B Statement

About This Guide

This guide describes how to install, conﬁgure, and troubleshoot the following 3Com 10/100 PCI network interface cards (NICs):

NIC/Description Model Number

3Com 10/100 Mbps PCI NIC with 3XP processor

Client NIC for 3DES (168-bit) and DES (56-bit) encryption

3Com 10/100 Mbps PCI Server NIC with 3XP processor

Server NIC for 3DES (168-bit) and DES (56-bit) encryption

This guide is intended for those who install and conﬁgure Ethernet NICs. Some familiarity with Ethernet networks and NICs is assumed.

NOTE: If release notes are shipped with your product and the information there differs

from the information in this guide, follow the instructions in the release notes.

Most user guides and release notes are available in Adobe Acrobat Reader Portable Document Format (PDF) on the 3Com World Wide Web site:

http://www.3com.com/

You can download Acrobat Reader from the EtherCD or from the Adobe Systems Incorporated Web site:

http://www.adobe.com/

3C990B-TX-M

3C990BSVR

Conventions

The following tables list conventions that are used throughout this guide.

Icon Notice Type Information That

Information note Describes important features

or instructions

Caution Alerts you to potential loss of data or

potential damage to an application, system, or device

Warning Alerts you to potential personal injury

About This Guide

Convention Description

Screen displays

Commands

This typeface represents information as it appears on the screen.

The word “command” means that you must enter the command exactly as shown and then press Return or Enter. Commands appear in bold. Example:

To launch the DOS diagnostics program, enter the following command:

a: install

The words “enter” and “type”

When you see the word “enter” in this guide, you must type something, and then press Return or Enter. Do not press Return or Enter when an instruction simply says “type.”

Words in

italics

Italics are used to:

■

Emphasize a point.

■

Denote a new term at the place where it is defined in the text.

■

Identify menu names, menu commands, and software button names. Examples:

From the

Click

Help menu, select Contents .

Introduction

This chapter describes the following 3Com (NIC) models from the 3C990B NIC family.

Product Name/Description Model Number

3Com 10/100 Mbps PCI NIC with 3XP processor

Client NIC for 3DES (168-bit) and DES (56-bit) encryption

3Com 10/100 Mbps PCI Server NIC with 3XP processor

Server NIC for 3DES (168-bit) and DES (56-bit) encryption

NOTE: Information in this user guide refers to both client and server 3C990B NIC

models unless speciﬁcally indicated.

The 3C990B NIC connects your PCI-compliant PC to a 10 Mbps or 100 Mbps Ethernet network. It provides advanced features for high performance and secure transactions. High performance is achieved through an onboard RISC processor; secure transactions are achieved through data encryption.

10/100 Mbps PCI network interface card

3C990B-TX-M

3C990BSVR

Onboard 3XP Processor

The 3C990B NIC represents a new generation of secure, intelligent client NICs with an onboard RISC processor (3XP processor). The 3XP processor is designed to optimize system and network performance. The NIC off-loads key networking and security tasks from the host PC CPU (central processing unit) to the 3XP processor, even when running bandwidth-intensive applications such as voice, video, imaging, and Internet and intranet applications.

Data Encryption

The 3C990B NIC provides Data Encryption Standard (DES) 56-bit encryption and 3DES (3DES 168-bit) encryption. Encryption processing is handled entirely by the 3XP processor on the NIC.

The 3XP processor enables true end-to-end network security (IPSec) at the data capacity of the connected network cable (wire speed), without sacriﬁcing performance.

The 3C990B NIC is shipped with encryption disabled. Once you have installed the NIC, you can upgrade it to the appropriate level of encryption acceleration (DES or 3DES) through the Security Software Utility provided on the 3Com EtherCD . See “Installing and Conﬁguring Data Encryption Ofﬂoads” on page 33 for more information.

1 Introduction

High Encryption Pack for Windows 2000

Microsoft Windows 2000 features a built-in VPN client. The Windows 2000 High Encryption Pack allows you to enhance your system with the highest available encryption level (168-bit). You can download the High Encryption Pack from the following Microsoft World Wide Web site:

http://www.microsoft.com/WINDOWS2000/downloads/recommended/ encryption/default.asp

NOTE: The Windows 2000 High Encryption Pack is eligible for export from the

U.S. to all customers worldwide, except to U.S. embargoed destinations. Please see http://www.microsoft.com/exporting/ for details. Other countries may exercise separate jurisdiction over the import, export, or use of encryption products. Users who download this product should observe any local regulations that may apply to the distribution or use of encryption products.

3C990B Client and Server NIC Features

The 3C990B NIC and accompanying software provide features that relieve network congestion and ensure high performance and maximum bandwidth availability.

Remote Wake-Up (RWU) connector

3XP Processor

YEL/100 GRN/10

YEL/100

ACT

3C990BSVR

GRN/10

ACT

3C990B-TX-M

The 3C990B NIC provides these features for supported IP and IPX environments:

Support for Windows 2000 Ofﬂoad Features — Off loading of key TCP/IP networking

■

and security tasks from the Windows 2000 operating system.

■

Remote Wake-Up — Lets you power on a computer remotely for after-hours administration.

■

Integrated Boot ROM with Managed PC Boot Agent (MBA) — Adds management capabilities by enabling the computer to boot from a network server, rather than from its local drive. MBA is compliant with the Preboot Execution Environment (PXE) speciﬁcation.

3C990B Client and Server NIC Features

■

Desktop Management Interface (DMI) 2.0 — Enables managed computers and net computers to report details about themselves and their peripheral devices across the network to a DMI 2.0-compliant management application.

Remote System Alerts (heartbeat packets) — Can signal a possible computer power

■

loss or theft.

■

Remote Control — Lets you troubleshoot and resolve system issues across the network.

■

Keep-Alive — Prevents the computer workstation address from being aged-out of switch router tables.

Hot Plug NIC Installation — Lets you add a new NIC or remove and replace a NIC

■

without turning off power to the computer.

■

Flow Control Features — prevents the loss of packets by keeping the input buffers of a device from overﬂowing.

■

Ofﬂine Diagnostics — Provides ofﬂine diagnostics programs for conﬁguring, testing, and troubleshooting NICs.

■

3Com DynamicAccess Advanced Server Features (for 3C990BSVR server NICs only) — Improved network performance, management, and control.

Windows 2000 Ofﬂoad Features

The 3C990B NIC supports Windows 2000 ofﬂoad features in an IP environment. The Windows 2000 ofﬂoad features are designed to enhance the Windows 2000 operating system capabilities by off-loading key TCP/IP networking and security tasks from the Windows 2000 operating system:

IPSec Ofﬂoad — reduces CPU utilization by allowing the 3XP processor and a crypto

■

chip on the NIC to perform data encryption operations. (For more information, see Chapter 4, “Installing and Conﬁguring Data Encryption Ofﬂoads.”)

NOTE: The 3C990B NIC is shipped with the IPSec ofﬂoad capability disabled. To learn about enabling IPSec ofﬂoads, see Chapter 4, “Installing and Conﬁguring Data Encryption Ofﬂoads.”

■ TCP Segmentation Ofﬂoad — reduces CPU utilization by allowing the 3XP processor

on the NIC to perform segmentation of TCP packets.

NOTE: Windows 2000 does not allow IPSec ofﬂoads and TCP Segmentation ofﬂoads for the same session. Though all ofﬂoad types may be enabled, TCP Segmentation ofﬂoading will not occur during an IPSec session.

■ IP and TCP Checksum Ofﬂoad — reduced CPU utilization by allowing the 3XP processor

on the NIC to perform the checksum calculation of TCP/IP and UDP/IP packets.

■ 802.1P Packet Priority Ofﬂoad — reduces CPU utilization by allowing the 3XP processor

on the NIC to perform the insertion of the 802.1Q tag header into the packet.

For more information on enabling and disabling ofﬂoads for Windows 2000, see “Using Windows 2000 Ofﬂoad Features” on page 52.

Remote Wake-Up

Remote Wake-Up provides the ability to remotely power-on a network computer for afterhours administration. When the PC is in sleep mode and receives a wake-up packet (Magic Packet frame) through the LAN, the NIC turns on the power to the PC. Remote Wake-Up also requires using a desktop management application that is able to generate a Magic Packet Remote Wake-Up signal.

1 Introduction

If the computer complies with PCI 2.2, Remote Wake-Up is automatically enabled through the PCI bus. If the computer complies with PCI 2.1, Remote Wake-Up support is enabled by connecting a Remote Wake-Up cable from the NIC’s Remote Wake-Up (RWU) connector to a 3-pin Remote Wake-Up connector on the computer motherboard.

NOTE: The NIC provides a network connection with or without the Remote Wake-Up cable installed.

Remote Wake-Up Requirements

The following conditions are required to use Remote Wake-Up:

■ Management application that supports Remote Wake-Up

■ BIOS that supports Remote Wake-Up

■ PCI 2.2-compliant bus or a 3-pin Remote Wake-Up connector on the computer

motherboard and a 5-volt standby power supply unit rated at a minimum of 375 milliamperes

If you are unsure whether your computer meets the requirements listed above, refer to the computer documentation or consult the computer manufacturer.

Remote Wake-Up and Multiple NIC Installations

To use multiple NICs as Remote Wake-Up NICs in the same computer, the computer must have a power supply that can support multiple Remote Wake-Up devices.

Refer to your computer documentation if you are unsure whether your computer power supply can accommodate more than one Remote Wake-Up device.

Integrated Boot ROM with Managed PC Boot Agent (MBA)

The Managed PC Boot Agent (MBA) software adds management capabilities to the NIC by enabling the computer to boot from a network server, rather than from the computer’s local drive. MBA is compliant with the Preboot Execution Environment (PXE) speciﬁcation. This preboot support allows you to use management applications to perform various tasks remotely. For example, you can:

■ Install and conﬁgure a new computer that has never been connected to the network.

■ Upgrade software.

■ Conﬁgure or reconﬁgure multiple systems simultaneously.

■ Scan for viruses.

■ Backup hard drives and perform disaster recovery tasks.

For information on conﬁguring the MBA to boot from the network, see “Conﬁguring the Managed PC Boot Agent (MBA)” on page 77.

For detailed information on the MBA, refer to the Managed PC Boot Agent User Guide, located with the MBA software on the 3Com EtherCD.

Desktop Management Interface (DMI) 2.0

Desktop Management Interface (DMI) is a network management standard that is widely accepted for managing Intel-based computers.

DMI 2.0 enables managed computers and net computers to report details about themselves and their peripheral devices across the network to a DMI 2.0-compliant management application.

3C990B Client and Server NIC Features

The 3Com DMI Agent allows any DMI management application to access information such as:

■ NIC driver location, version, and size

■ Packets-sent statistics

■ Cyclic Redundancy Check (CRC) receive errors

A network administrator can then use this type of information to remotely conﬁgure and manage a client or server computer.

The 3Com DMI Agent consists of a DMI browser with the following components:

■ DMI service layer

■ DMI agent

■ GUI installer

■ NDIS drivers

For detailed information about the 3Com DMI Agent, refer to the 3Com DMI Agent User Guide included with the DMI software on the EtherCD. For information about installing

the 3Com DMI Agent and downloading the 3Com DMI Agent User Guide, see Appendix B, "Installing the 3Com DMI Agent."

Remote System Alerts

You can conﬁgure the 3C990B NIC to transmit a number of different packet alerts to the management server to notify the network administrator that there is a system issue that requires attention. These alerts support the Alert Standard Forum (ASF) speciﬁcation and provide system monitoring in the OS-absent environment. The alerting capability is present whether the system is powered off, booting up, in sleep mode, or the OS has hung. There are many different alert types, including those that relate to:

■ Physical security — chassis intrusion, heartbeat, loss of connection

■ Environmental conditions — fan speed, temperature, voltage deviations

■ BIOS issues — ROM initialization, system memory

Remote Control

The 3C990B NIC can also receive commands via Remote Control and Management Protocol (RMCP). This feature is also speciﬁed in the ASF speciﬁcation and lets network administrators troubleshoot and resolve system issues across the network. Commands include:

■ Power on

■ Power off

■ Reboot

■ Reboot from an alternative device (for example: MBA, CD-ROM, and so forth)

Both monitoring alerts and sending commands are available in the system console through the 3Com Remote System Alert Manager. This management plug-in is available for HP OpenView Network Node Manager, Microsoft Systems Management Server, and Intel LANDesk Client Manager.

Keep-Alive

The 3C990B NIC can also transmit a workgroup keep-alive packet periodically while the computer is in a sleep state. This packet prevents the computer workstation address from being aged-out of switch router tables.

1 Introduction

Hot Plug NIC Installation

If your computer supports PCI hot plug speciﬁcations, you can add a new 3Com NIC or remove and replace a 3Com NIC without turning off power to the computer. Hot plug NIC installation allows you to expand connections without taking the computer out of service. It makes troubleshooting faster and easier because you do not need to wait for the computer to reboot.

For instructions on performing a hot plug NIC installation, refer to your computer documentation.

Flow Control Features

The 3C990B NICs use ﬂow control technology to throttle the incoming data packet stream and prevent the loss of packets. IEEE 803.2x ﬂow control prevents the input buffers of a device from overﬂowing. By using pause frames to communicate buffer status between linked transmitting and receiving devices (transmitters and receivers). A receiver sends a pause frame to tell a transmitter to stop the transmission of data frames for a speciﬁed period, allowing the receiver’s input port buffers to empty before receiving new packets.

Pause Frames

When a transmitter receives pause frames, it suspends transmission for the speciﬁed period. When the receiver’s input buffers can store packets again, it can either send another pause frame to tell the transmitter to resume transmission, or wait for transmission to resume at the end of the speciﬁed period.

With asymmetric ﬂow control, only one of two linked devices can receive pause frames. With symmetric ﬂow control, both linked devices can send and receive pause frames.

Link Negotiation

Related to ﬂow control is the auto negotiation capability, in which linked devices advertise their ﬂow control capabilities and automatically select the best common mode of communication.

Rare cases (for example, linking to a device that does not support auto-negotiation) may require that auto-negotiation be disabled on a port, thereby enabling forced link on that port. When forced link is enabled, linked devices must have matching ﬂow control capabilities. For example, a port that is set for forced link and reception ﬂow control can connect successfully only with a port that is set for forced link and transmission ﬂow control.

Ofﬂine Diagnostics

The NIC software includes ofﬂine diagnostics programs for conﬁguring, testing, and troubleshooting NICs. The conﬁguration program within the DOS diagnostics program is used for a PC running DOS or NetWare. The 3Com NIC diagnostics program (3Com NIC Doctor) is a Windows-based program used for a PC running Windows 2000, Windows NT 4.0, Windows Millennium Edition (Windows Me), Windows 98, or Windows 95.

3C990BSVR Server NIC Features

The 3C990BSVR NIC and accompanying software provide a variety of features that relieve network congestion and ensure high performance and maximum bandwidth availability.

NOTE: Advanced server features are available for the 3C990BSVR server NIC only. They are not available for the 3C990B-TX-M client NIC. Only system administrators should conﬁgure these features.

3Com DynamicAccess Advanced Server Features

3Com DynamicAccess Advanced Server software adds intelligence to the NIC to improve network performance, management, and control. Advanced server features relieve network congestion and ensure high performance and maximum bandwidth availability.

■ Load Balancing groups share the network load over resilient server links (RSLs) that

keep trafﬁc ﬂowing even if a NIC in a group is temporarily disconnected.

■ Self-Healing Drivers (SHDs) detect common error conditions and correct them while

maintaining server link performance.

■ Failover fault tolerance provides a backup solution in the event of a NIC failure.

■ VLANs (IEEE 802.1Q multiple virtual LANs) let you divide network segments into

logical partitions that simplify conﬁguration changes, organize work groups efﬁciently, help to control trafﬁc, and provide extra security.

■ Trafﬁc Prioritization (IEEE 802.1p/Q) ensures that business-critical and delay-sensitive

trafﬁc (such as multimedia applications) has priority over normal data.

3C990BSVR Server NIC Features

Load Balancing

Load balancing maximizes bandwidth at the server through the use of multiple parallel resilient server links (RSLs) that share the network load as shown in the next ﬁgure.

An RSL consists of two or more NICs that form a virtual NIC. Each virtual NIC has multiple physical NICs bound to it, forming a group. Each NIC in a group uses the same protocols and frame types. One NIC is designated the primary NIC and the others secondary NICs.

Bidirectional

Primary

Secondaries

Server

Switch

Clients

Transmit-only

Primary

Secondaries

® ®

Self-Healing Drivers

Self-healing drivers (SHDs) are automatically installed with the NIC software, and work together with RSLs to maintain the network connection. An SHD monitors the NIC continuously for error conditions and makes corrections. These corrections can include resetting the NIC, rebuilding software data structures, temporarily disabling features, or transferring all network trafﬁc to secondary NICs (termed a failover event). An SHD can also continuously monitor the status of the physical NICs in a virtual NIC group before and after failover. Errors and actions are reported to the system console and to the system log ﬁle. Error threshold values can be conﬁgured at any time.

1 Introduction

Failover

In addition to load balancing, RSLs provide failover fault tolerance between a server and a switch—if one NIC in a group fails, the others assume the network load of the failed NIC. The failover behavior of secondary NICs depends on how you set load balancing:

■ In a transmit load balancing arrangement, the primary NIC is the only one that

receives packets. If the primary NIC fails, a secondary NIC assumes the conﬁguration proﬁle, network trafﬁc, and active status of the failed primary NIC.

■ In a bidirectional load balancing arrangement, all NICs receive packets. If any NIC fails,

receive load balancing is disabled, and the other NICs continue transmit-only load balancing activity. Receive load balancing is restored when new connections are established with clients.

If the primary NIC fails, a secondary NIC takes over packet reception for the group. Bidirectional load balancing is restored after a failure when applications create new

connections and new clients log in as illustrated in the following ﬁgure.

Server

Switch

Clients

Bidirectional

load balancing

Primary

Secondaries

® ® ®

Primary failure Secondary failure

Primary

Secondaries

Primary

Secondaries

VLANs

A virtual LAN (VLAN) is a group of location-independent and topology-independent devices that communicate as if they were on the same physical LAN. Network devices on different LAN segments and of different media types can be members of the same VLAN. Membership in a VLAN is determined by a VLAN tag that is transmitted with the Ethernet frame for use by a switch.

With VLANs, you can deﬁne a network according to:

■ Organizational groups—For example, you can have one VLAN for the Marketing

department and one for the Finance department.

■ Application groups—For example, you can have one VLAN for e-mail users and one

for multimedia users.

Implementing VLANs on a network has these advantages:

■ It eases the change and movement of devices on IP networks.

With traditional IP networks, if users move to a different IP subnet, the IP addresses of each workstation must be updated manually. With VLANs installed, if an end station on VLAN 1 is moved to a port elsewhere on the network, you need only to specify that the new port is on VLAN 1.

3C990BSVR Server NIC Features

■ It helps to control trafﬁc.

With traditional networks, congestion can be caused by broadcast trafﬁc that is directed to all network devices whether they require it or not. Each VLAN can be set up to contain only those devices that need to communicate with each other, increasing network efﬁciency.

■ It provides extra security.

Devices within each VLAN can communicate only with member devices in the same VLAN. If a device in VLAN 1 needs to communicate with devices in VLAN 2, the trafﬁc must cross a router.

The 3C990B NIC multiple VLAN capability supports IEEE 802.1Q VLAN tagging and works with any switch that complies with IEEE 802.1Q speciﬁcations. Refer to your Ethernet switch documentation for more information on IEEE 802.1Q VLANs.

Trafﬁc Prioritization

Trafﬁc prioritization (IEEE 802.1p/Q) ensures that business-critical and delay-sensitive trafﬁc (such as multimedia applications) has priority over normal data.

Server Features Using Other NICs

Up to two foreign NICs (those that are not 3Com server NICs) are allowed in one group per server. For guidelines on using foreign NICs, see these topics:

■ Windows NT and Windows 2000 — “Planning the Conﬁguration” on page 45

■ NetWare — “Planning the Conﬁguration” on page 66

Installing and

Connecting the NIC

This chapter describes how to install the NIC in your PC and connect it to an Ethernet or Fast Ethernet network.

Before starting the installation procedure, you can gain some familiarity with the directory structure and various ﬁles on the EtherCD supplied with the 3C990B NIC by reading Appendix C, "EtherCD Content and Navigation."

Installation Overview

Installing the NIC involves your carrying out the following tasks:

■ Registering the product

■ Installing the NIC in the PC

■ Connecting the NIC to the network

■ Installing the network driver

■ Enabling data encryption ofﬂoads (the 3C990B NIC is shipped with encryption

Safety Precautions

Observe the following safety precautions.

ofﬂoading disabled)

WARNING: Computers operate with voltages that can be lethal. Before removing the cover, turn off the computer and unplug it. Disconnect all cables that are connected to the main system unit. Remove jewelry from your hands and wrists. Use insulated or nonconductive tools.

CAUTION: The NIC is packed in an antistatic container to protect it during shipment. Do not touch the components or any metal parts on the NIC, except for the backplate. To avoid damaging the NIC or the computer, reduce static electricity on your body by wearing an electrostatic discharge wrist strap attached to the chassis or by touching an unpainted metal part of the chassis before unplugging the computer and before handling the NIC.

CAUTION: Install the NIC in a PCI slot that conforms to PCI 2.1 or higher speciﬁcations. Do not attempt to install the NIC in an ISA or EISA slot. Doing so may damage the NIC and the computer.

WARNING: Make sure that the computer power cord is unplugged. Only properly trained and authorized personnel should perform service. Contact the computer manufacturer for information about safe service techniques.

2 Installing and Connecting the NIC

Installation Requirements

The following items are required for hardware and software installation.

■ Network Interface Card (NIC)—At least one 3Com 10/100 Mbps PCI 3C990B NIC

(included)

■ Processor:

■ Server: Intel-based CPU (Pentium-class processor)

■ Client: 80486 or Pentium-class processor

■ RAM:

■ Server: 128 MB minimum; 256 MB recommended

■ Client: 32 MB RAM recommended for running 3Com Advanced Server Technology

■ PCI slot—For each NIC, one bus master slot that conforms to PCI 32-bit

speciﬁcations, revision 2.1 or higher

■ Drive—CD-ROM

■ Cable—Category 5 UTP (included) with RJ-45 connectors for Fast Ethernet

(100 Mbps) connectivity. Category 3, 4, or 5 UTP with RJ-45 connectors for Ethernet (10 Mbps) connectivity. (See cable speciﬁcations in “Preparing the NIC and the Computer” on page 16.)

■ Software—One 3Com EtherCD with 3Com Advanced Server software and network

drivers (included)

■ Operating system—One of the following:

■ Microsoft Windows 2000

■ Microsoft Windows NT 4.0, Service Pack 6a

■ Microsoft Windows 95, 98, Me

■ Novell NetWare server version 3.12, 4.11, or 5.x with the most recent patches and

updates available from Novell technical support (www.novell.com)

NOTE: You can install the NIC base network driver on any Windows PC without having to also install a speciﬁc Microsoft Service Pack; however, 3Com recommends that you always try to use the most recent Service Pack available from Microsoft technical support (www.microsoft.com).

Running 3Com 3Com Advanced Server software on Windows NT 4.0 requires Service Pack 6 or greater from Microsoft.

■ Computer BIOS—Latest version. Contact the computer manufacturer to verify.

■ Remote Wake-Up—For requirements, see “Remote Wake-Up” on page 5.

Installing Multiple NICs

If you are installing multiple 3Com 10/100 PCI NICs in one computer running Windows, see the instructions in “Installing Multiple NICs” on page 31. If you are installing multiple 3Com 10/100 PCI NICs in one computer running NetWare, follow the instructions in “Installing Multiple Server NICs” on page 61.

Upgrading Windows 95 to Windows 98

If you are upgrading a computer from Windows 95 to Windows 98, and the computer already has a 3Com 10/100 PCI NIC installed, follow the instructions in the WIN98.TXT ﬁle located in the HELP directory on the EtherCD.

Upgrading Windows 98 to Windows Me

If you are upgrading a computer from Windows 98 to Windows Me, and the computer already has a 3Com 10/100 PCI NIC installed, follow the instructions in the WINME.TXT ﬁle located in the HELP directory on the EtherCD.

Updating the Network Driver and NIC Software

If you already have a 3Com 10/100 PCI NIC installed and want to update the network driver, follow the instructions in “Updating the Network Driver and NIC Software” on page 31.

Installing From Diskette

If your computer does not have a CD-ROM drive, use a PC that has a CD-ROM drive and create installation diskettes from the EtherCD.

Making a DOS-Bootable Diskette

For installation and conﬁguration procedures that require you to boot from DOS, you cannot successfully use the MS-DOS prompt from within Windows. Perform a “clean” boot from DOS or use a DOS boot diskette.

Installing From Diskette

NOTE: The installation diskettes allow you to install the network driver and DOS Diagnostics software only. If you want to install the Windows NIC Diagnostics program or desktop management software, you must install them from the EtherCD.

NOTE: If the PC or server is only running DOS and a CD-ROM drive is not installed, you must install the NIC software using installation diskettes. For more information about installation diskettes, see the next section, “Creating Installation Diskettes.”.

To make a DOS-bootable diskette:

1 Insert a blank, formatted diskette in drive A.

2 At the DOS prompt, enter:

sys a:

System ﬁles are copied to the diskette.

3 Remove the diskette from drive A and attach a label for future reference.

Creating Installation Diskettes

If you anticipate having to install the driver for the 3C990B NIC without having access to a CD-ROM drive, you can create a set of installation diskettes beforehand using a computer that does have a CD-ROM drive. To start, you will need three blank, formatted ﬂoppy diskettes. To create installation diskettes from the EtherCD:

1 Turn on the power to the PC and start Windows.

2 Insert the EtherCD in the CD-ROM drive.

The EtherCD Welcome screen appears.

3 Click NIC Software.

4 Click Installation Utilities.

5 Click Create Installation Diskettes.

The EtherCD Diskette Creation Utility Welcome screen appears.

6 Click Next.

2 Installing and Connecting the NIC

7 Insert a blank, formatted diskette labeled Disk 1 in the PC, and then click Next.

Files are copied. Disk 1 contains the installation ﬁles and driver ﬁles for Windows 2000, Windows NT, and Windows 95/98.

8 Remove the disk and insert the disk labeled Disk 2 when prompted, and then

click OK. Files are copied. Disk 2 contains the diagnostic and ﬁrmware images.

9 Remove the disk and insert the disk labeled Disk 3 when prompted, and then

click OK. Files are copied. Disk 3 contains the NetWare drivers.

NOTE: For detailed information about the content of the installation diskettes, refer to the ROADMAP.TXT ﬁle contained on Disk 2.

Product Registration

The United States government places registration requirements on using data encryption products. To obtain customer support for the 3C990B NIC, you are required to electronically register your NIC product with 3Com.

In addition to enabling customer support for your NIC, registration also entitles you to receive upgrade information and advance feature information.

NOTE: To be able to register electronically, a Web browser must be installed on your system. You must also have an active Internet service provider (ISP) connection.

NOTE: The original version of Windows 95 (Build 950) does not automatically allow you to change your default browser, even if Microsoft Internet Explorer is not present. If you are running this version of Windows 95 on your PC, access the following site to register your 3C990B NIC:

http://www.3com.com/productreg

To register electronically:

1 Insert the EtherCD (that shipped with this product) in the CD-ROM drive.

The EtherCD Welcome screen appears. If the Welcome screen does not appear, see “EtherCD Content and Navigation” on

page 103.

2 Click Register Product, and then Register Online.

3 Follow the prompts as they appear.

Preparing the NIC and the Computer

Observe the precautions listed in “Safety Precautions” on page 13. Follow these preparation steps:

1 Decide whether you want to use Remote Wake-Up.

If you want to use the Remote Wake-Up feature on a computer that complies with PCI

2.1, you must obtain a Remote Wake-Up cable for the NIC (for details, see “Remote Wake-Up” on page 5). If the computer complies with PCI 2.2, Remote Wake-Up is automatically enabled through the PCI bus and no Remote Wake-Up cable is required.

Preparing the NIC and the Computer

2 Make sure that cable requirements are met.

The RJ-45 port provides a 10 Mbps or 100 Mbps connection automatically, depending on the speed of the connected hub or switch.

The following table shows the cable requirements and maximum network cable lengths for the RJ-45 port.

Network Environment Cable Required

10 Mbps (10BASE-T)

100 Mbps (100BASE-TX)

Category 3, 4, or 5 unshielded twisted-pair

Category 5 unshielded twisted-pair

Maximum Cable Length

100 m (328 ft)

3 Unpack and inspect the NIC for damage.

4 Exit all open applications and user processes.

5 Turn off the power to the computer and attached devices.

6 Unplug the power cables from the power source.

7 Remove the computer cover.

8 Locate an empty, nonshared bus-mastering PCI slot and remove its slot cover. Save

the screw, if there is one. Do not install the NIC in a shared PCI slot. Avoid any PCI slot next to an ISA slot. This

slot is often shared and does not support bus mastering. If you do not know how to identify a PCI slot, check the computer documentation or

ask the system administrator. If you are planning to install the Remote Wake-Up cable, choose an empty PCI slot

that is close to the Remote Wake-Up connector on the computer motherboard. The Remote Wake-Up cable is only required if the computer complies with PCI 2.1 and you want to use the Remote Wake-Up. The cable is not required if the computer complies with PCI 2.2.

9 Write down the MAC address of the NIC and note the relative position of the

intended PCI slot. The MAC address is the 12-digit hexadecimal number printed on the small bar code

label on the component side of the NIC. This information is helpful when you are installing the network drivers and connecting the cables to the hub or switch.

The next step is to install the NIC in the computer and connect it to the network.

2 Installing and Connecting the NIC

Installing and Connecting the NIC

Observe the safety precautions listed in “Safety Precautions” on page 13.

Prepare the NIC and the computer as described in “Preparing the NIC and the Computer” on page 16.

The following instructions apply to installing the NIC in most computers. If these instructions are not appropriate for your computer, refer to the documentation that accompanied the computer.

Remove slot cover

Insert NIC

PCI slots

1 Carefully insert the NIC in the empty PCI slot, as shown in the illustration.

Press ﬁrmly to ensure that the NIC is fully seated in the slot. Secure the NIC with the screw if you removed one earlier.

NOTE: If you want to install the Remote Wake-Up cable, go to the next section, “Connecting the Remote Wake-Up Cable,” to continue the installation. If you do not want to connect the cable, continue with step 2.

2 Replace the computer cover and plug in the power cord.

Do not turn on the power to the computer.

Connecting the Remote Wake-Up Cable

ACT

STATUS

3 Plug the RJ-45 connector on the twisted-pair network cable into the RJ-45 port on the

NIC backplate as shown in the ﬁgure.

4 Connect the other end of the network cable to an active network port.

The next step is to install the software, as described in “Installing Software” on page 20.

NOTE: If you are installing multiple 3Com 10/100 PCI NICs in one computer running Windows, see the instructions in “Installing Multiple NICs” on page 31. If you are installing multiple 3Com 10/100 PCI NICs in one computer running NetWare, follow the instructions in “Installing Multiple Server NICs” on page 61.

NOTE: If your site network installation procedures require you to verify that installed hardware is functional before you install software, run the 3C99XCFG.EXE DOS diagnostics program before installing the driver. This program is located on the 3Com EtherCD. For more information, see “Using the 3Com DOS Conﬁguration Program” on page 77.

Connecting the Remote Wake-Up Cable

This section describes how to connect the Remote Wake-Up cable from the NIC to the PC motherboard. Connecting the Remote Wake-Up cable is optional. Connect this cable only if your NIC supports Remote Wake-Up and you want to use this feature.

WARNING: Make sure that the PC power cord is unplugged. Only properly trained and authorized personnel should perform service. Contact your PC manufacturer for information about safe service techniques.

NOTE: If your PC is compliant with PCI 2.2, Remote Wake-Up is automatically enabled through the PCI bus. You do not need to connect the Remote Wake-Up cable.

2 Installing and Connecting the NIC

To connect the Remote Wake-Up cable:

1 Make sure that the NIC is properly installed in a PCI slot.

2 Insert the Remote Wake-Up cable into the RWU connector on the NIC as shown in

the next ﬁgure. Twist the cable twice before attaching the cable to the PC.

Installing Software

3 Attach the other end of the cable to the connector on the PC motherboard.

Refer to your PC documentation if you need help locating the connector.

4 Replace the PC cover and plug in the power cord.

Do not turn on the power to the PC. Continue at step 3 in “Installing and Connecting the NIC” on page 18.

See the following topics for requirements and instructions on installing software for various operating systems:

■ “Installing NIC Drivers and Diagnostics For Windows” on page 21

■ “Updating the Network Driver and NIC Software” on page 31

■ “Installing NetWare Drivers” on page 55

The next step is to install the network driver.

Go to “Installing NIC Drivers and Diagnostics For Windows” on page 21 or “Installing NetWare Drivers” on page 55.

For a list of additional network drivers that are not included on the EtherCD (for example, SCO UnixWare 7, SCO OpenServer 5, Linux 2.2, Solaris) and instructions on how to install them, go to the 3Com Web site and search for “3C990B” and “drivers.”

Installing NIC Drivers and

Diagnostics For Windows

This chapter explains the following tasks on a computer running Windows 2000, Windows NT, Windows Millennium Edition (Windows Me), Windows 98, or Windows 95:

■ Install the network driver and NIC software using EtherCD

■ Update the network driver or NIC diagnostics program

■ Install multiple NICs

To obtain the latest version of a driver, go to:

http://www.3com.com/

Search for “3C990B” and “drivers.” The network driver can be used in both Microsoft and NetWare network environments.

NOTE: For instructions on using the installation diskettes (which can be created from the EtherCD) to install the network driver, see “Installing From Diskette” on page 15. For additional information, refer to the text ﬁle for your operating system in the HELP directory on the EtherCD.

Software Installation Requirements

If your site network installation procedures require you to verify that installed hardware is functional before you install software, you can verify that the installed NIC is functional or change its conﬁguration settings by running the DOS diagnostics. Use the 3C99XCFG.EXE program located on the EtherCD. For more information, see “Using the 3Com DOS Conﬁguration Program” on page 77.

If you are installing the software during the installation of the network operating system, see “Installing a 3Com NIC While Installing the NOS” on page 107.

For a list of minimum installation prerequisites, see “Installation Requirements” on page 14.

Getting Help

To display the Help system during the software installation, click Help on any 3Com window.

Installing the Network Driver Using the EtherCD

To install the network driver using the EtherCD, follow the steps in the section that is speciﬁc to your Windows operating system.

Before Installing the Network Driver

Before installing the network driver, make sure that:

■ The NIC is installed in the PC and connected to the network. For instructions, see

“Installing and Connecting the NIC” on page 18.

■ All software installation requirements are met. See “Installation Requirements” on

page 14.

3 Installing NIC Drivers and Diagnostics For Windows

■ You have the Windows installation ﬁles (for Windows 95, 98, Me only). These ﬁles

may be on a CD or diskettes, or they may have been copied to your hard drive when Windows was installed on your PC.

NOTE: If you encounter problems during the installation, refer to the TROUBLE.TXT ﬁle (located in the HELP directory on the EtherCD) for troubleshooting tips.

Windows 2000

This section describes how to install the network driver and NIC software in a PC client or server running Windows 2000.

NOTE: The 3C990B NIC supports Windows 2000 ofﬂoad features in an IP environment. For more information, see “Windows 2000 Ofﬂoad Features” on page 5 and “Using Windows 2000 Ofﬂoad Features” on page 52.

Use the following procedure to install the driver for the ﬁrst time in a computer that is running Windows 2000. (If you are updating a previous installation, see “Updating the Network Driver and NIC Software” on page 31.)

Installing the Driver

1 Turn on the power to the PC.

2 Start Windows 2000 and log in to the Windows 2000 Administrator account.

The Windows 2000 Found New Hardware Wizard starts. The wizard detects the new NIC(s) and begins the driver installation. The Welcome to the Found New Hardware Wizard screen appears.

3 Click Next to continue.

The Install Hardware Device Drivers screen appears.

4 Insert the EtherCD in the CD-ROM drive.

5 Select Search for a suitable driver for my device (recommended), and then click Next.

The Locate Driver Files screen appears.

6 Select the CD-ROM drives option, clear any other checked options, and click Next.

The Driver Files Search Results screen appears. Windows ﬁnds the driver on the EtherCD.

7 Click Next to install the driver.

The Hardware Install screen appears. Files are copied. Then the Completing the Found New Hardware Wizard screen appears, displaying the message “Windows has ﬁnished installing the software for this device.”

8 Click Finish to close the wizard.

If the System Settings Change dialog box appears, requesting that you restart your computer, click Ye s to restart.

The driver installation is complete for Windows 2000. Next, verify the driver installation to conﬁrm that the NIC is properly installed.

+ 98 hidden pages
