3B SCIENTIFIC
Diesel Engine, Transparent 1002996
Instruction sheet
04/12 JS
®
PHYSICS
1 Outlet
2 Inlet
3 Piston
4 Combustion chamber
5 Valve control
6 Crankshaft
1. Description
The diesel engine is an internal combustion
engine which requires four strokes to work (intake, compression, ignition or power stroke and
exhaust stroke) wherein the mixture of air and
fuel ignites of its own accord.
The crankshaft conveys the force and also controls the changes in the gas mixture.
2. Operation
Additionally recommended:
Overhead Projector (230 V, 50/60 Hz) 1003264
or
Overhead Projector (115 V, 50/60 Hz) 1003263
• Lay the transparency on the daylight projec-
tor.
• Move the components by hand to the places
which correspond to the various strokes.
3B Scientific GmbH ▪ Rudorffweg 8 ▪ 21031 Hamburg ▪ Germany ▪ www.3bscientific.com
Subject to technical amendments
© Copyright 2012 3B Scientific GmbH
