ZyXEL Communications P-2612HW User Manual
P-2612HW Series
802.11g Wireless ADSL VoIP IAD
Default Login Details
IP Address http://192.168.1.1
User Login User Name: user
Password: user
Administrator
Login
Firmware Version 3.70
Edition 2, 5/2009
www.zyxel.com
User Name: admin
Password: 1234
www.zyxel.com
Copyright © 2009
ZyXEL Communications Corporation
About This User's Guide
About This User's Guide
Intended Audience
This manual is intended for people who want to configure the Zy XEL Device using
the web configurator. You should have at least a basic knowledge of TCP/IP
networking concepts and topology.
Related Documentation
•Quick Start Guide
The Quick Start Guide is designed to help you get up and running right away. It
contains information on setting up your network and configuring for Internet
access.
Note: It is recommended you use the web configurator to configure the ZyXEL
Device.
• Supporting Disc
Refer to the included CD for support documents.
• ZyXEL Web Site
Please refer to www.zyxel.com
product certifications.
for additional support documentation and
User Guide Feedback
Help us help you. Send all User Guide-related comments, questi ons or suggestions
for improvement to the following address, or use e-mail instead. Thank you!
The Technical Writing Team,
ZyXEL Communications Corp.,
6 Innovation Road II,
Science-Based Industrial Park,
Hsinchu, 300, Taiwan.
E-mail: techwriters@zyxel.com.tw
Customer Support
In the event of problems that cannot be solved by using this manual, you should
contact your vendor. If you cannot contact your vendor, then contact a ZyXEL
office for the region in which you bought the device. See ht t p ://www.zyxel.com/
web/contact_us.php for contact information. Please have the following information
ready when you contact an office.
P-2612HW Series User’s Guide
3
About This User's Guide
• Product model and serial number.
•Warranty Information.
• Date that you received your device.
• Brief description of the problem and the steps you took to solve it.
4
P-2612HW Series User’s Guide
Document Conventions
Document Conventions
Warnings and Notes
These are how warnings and notes are shown in this User’s Guide.
Warnings tell you about things that could harm you or your device.
Note: Notes tell you other important information (for example, other things you may
need to configure or helpful tips) or recommendations.
Syntax Conventions
• The P-2612HW Series may be referred to as the “ZyXEL Device”, the “device”,
the “system” or the “product” in this User’s Guide.
• Product labels, screen names, field labels and field choices are all in bold font.
• A key stroke is denoted by square brackets and uppercase text, for example,
[ENTER] means the “enter” or “retu rn” key on your keyboard.
• “Enter” means for you to type on e or more characters and then press the
[ENTER] key. “Select” or “choose” means for you to use one of the predefined
choices.
• A right angle bracket ( > ) within a screen name denotes a mouse click. For
example, Maintenance > Log > Log Setting means you first click
Maintenance in the navigation panel, then the Log sub menu and finally the
Log Setting tab to get to that screen.
• Units of measurement may denote the “metric” value or the “scientific” value.
For example, “k” for kilo may denote “1000” or “1024”, “M” for mega may
denote “1000000” or “1048576” and so on.
• “e.g.,” is a shorthand for “for instance”, and “i.e.,” means “that is” or “in other
words”.
P-2612HW Series User’s Guide
5
Document Conventions
Icons Used in Figures
Figures in this User’s Guide may use the following generic icons. The Z yXEL Device
icon is not an exact representation of your device.
ZyXEL Device Computer Notebook computer
Server DSLAM Firewall
Telephone Switch Router
6
P-2612HW Series User’s Guide
Safety Warnings
Safety Warnings
• Do NOT use this product near water, for example, in a wet basement or near a swimming
pool.
• Do NOT expose your device to dampness, dust or corrosive liquids.
• Do NOT store things on the device.
• Do NOT install, use, or service this device during a thunderstorm. There is a remote risk
of electric shock from lightning.
• Connect ONLY suitable accessories to the device.
• Do NOT open the device or unit. Opening or removing covers can expose you to
dangerous high voltage points or other risks. ONLY qualified service personnel should
service or disassemble this device. Please contact your vendor for further information.
• Make sure to connect the cables to the correct ports.
• Place connecting cables carefully so that no one will step on them or stumble over them.
• Always disconnect all cables from this device before servicing or disassembling.
• Use ONLY an appropriate power adaptor or cord for your device.
• Connect the power adaptor or cord to the right supply voltage (for example, 110V AC in
North America or 230V AC in Europe).
• Do NOT allow anything to rest on the power adaptor or cord and do NOT place the
product where anyone can walk on the power adaptor or cord.
• Do NOT use the device if the power adaptor or cord is damaged as it might cause
electrocution.
• If the power adaptor or cord is damaged, remove it from the device and the power
source.
• Do NOT attempt to repair the power adaptor or cord. Contact your local vendor to order a
new one.
• Do not use the device outside, and make sure all the connections are indoors. There is a
remote risk of electric shock from lightning.
• Do NOT obstruct the device ventilation slots, as insufficient airflow may harm your
device.
• Use only No. 26 AWG (American Wire Gauge) or larger telecommunication line cord.
• Antenna Warning! This device meets ETSI and FCC certification requirements when using
the included antenna(s). Only use the included antenna(s).
Your product is marked with this symbol, which is known as the WEEE mark. WEEE
stands for Waste Electronics and Electrical Equipment. It means that used electrical
and electronic products should not be mixed with general waste. Used electrical and
electronic equipment should be treated separately.
P-2612HW Series User’s Guide
7
Safety Warnings
8
P-2612HW Series User’s Guide
Contents Overview
Contents Overview
Introduction ............................................................................................................................23
Introducing the ZyXEL Device ...................................................................................................25
Introducing the Web Configurator .............................................................................................. 31
Wizards...................................................................................................................................... 39
Tutorial ...................................................... ............................................. .................................... 57
Advanced ................................................................................................................................87
Status Screens .......................................................................................................................... 89
WAN Setup ............................ ... ... .... ... ... ................................................ .... ... ............................. 99
LAN Setup ............................................................................................................................... 121
Wireless LAN ............................................................................. ... ... ........................................ 137
Network Address Translation (NAT) ........................................................................................ 169
Voice ............................................................ .................................................... ........................185
Phone Usage ................................... ... ................................................ ... .... .............................. 221
Firewall .................................................................................................................................... 229
Content Filtering ....... ... ................................................. ... ... ... .... ... ........................................... 251
VPN .........................................................................................................................................257
Certificates ................................... ....................... ....................... ...................... ........................ 291
Static Route ............................................................................................................................. 321
802.1Q/1P ............................................................................................................................... 325
Quality of Service (QoS) .............................. .... ... ... ... .... ... ... ................................................ ..... 337
Dynamic DNS Setup ................................................................................................................353
Remote Management Configuration ......................... ....................... .......................... .............. 357
Universal Plug-and-Play (UPnP) ............................................................................................. 369
Maintenance, Troubleshooting and Specifications ..........................................................383
System ................................... ...................... ....................... ....................... .............................. 385
Logs ........................................................................................................................................391
Call History ............................................................................................................................. 407
Tools ........................................................................................................................................ 413
Diagnostic ................................... .... ... ... ... ................................................. ... ... ... .... ... ..............433
Troubleshooting ..................................................... .................................................................. 437
Product Specifications ............................................................................................................. 445
Appendices and Index .........................................................................................................457
P-2612HW Series User’s Guide
9
Contents Overview
10
P-2612HW Series User’s Guide
Table of Contents
Table of Contents
About This User's Guide..........................................................................................................3
Document Conventions............................................................................................................5
Safety Warnings ........................................................................................................................7
Contents Overview ...................................................................................................................9
Table of Contents....................................................................................................................11
Part I: Introduction................................................................................. 23
Chapter 1
Introducing the ZyXEL Device...............................................................................................25
1.1 Overview ............. ................................................ .... ................................................ ............. 25
1.1.1 Internet Access ................................................ ... ... .... ................................................25
1.1.2 VoIP Features .............. .... ... ... ... ... ................................................. ... ... .......................27
1.2 Ways to Manage the ZyXEL Device ....................... ... ................................................ ... .... ... 27
1.3 Good Habits for Managing the ZyXEL Device .....................................................................28
1.4 LEDs (Lights) ......................... .... ... ... ... ... .... ... ... ................................................. ... ... .............28
1.5 The RESET Button ................................ .... ... ... ... ................................................. ... ... ..........29
1.6 The WLAN Button ............... ... .... ... ................................................ ... .... ... ... ... ....................... 30
Chapter 2
Introducing the Web Configurator ........................................................................................31
2.1 Web Configurator Overview ................................................................................................. 31
2.1.1 Accessing the Web Configurator ................................................................................ 31
2.2 Web Configurator Main Screen ........................................................................................... 33
2.2.1 Title Bar .................................. ... ... .... ... ... .................................................................... 33
2.2.2 Navigation Panel .......... .... ... ... ... ... .... ... ....................................................................... 34
2.2.3 Main Window .......................... ... ................................................. ... ... ..........................38
2.2.4 Status Bar ............................................... ... .............................................. ... ... ... ... ....... 38
Chapter 3
Wizards....................................................................................................................................39
3.1 Overview ............. ................................................ .... ................................................ ............. 39
3.2 Internet Access Wizard Setup ............................................................................................. 39
3.2.1 Manual Configuration .......... ... ... ... .... ................................................ ... .... ... ... ... ... .... ... 42
P-2612HW Series User’s Guide
11
Table of Contents
3.3 Wireless Connection Wizard Setup ..................................................................................... 46
3.3.1 Manually Assign a WPA-PSK key ................................. ... ... ... .... ... ... ... .... ................... 49
3.3.2 Manually Assign a WEP Key ...................................................................... ... ... ... .... ... 50
3.4 VoIP Setup Wizard ....... ... ... ... .... ... ... ... ... .............................................................................. 51
3.4.1 SIP Settings .............................................. .... ... ... ... .... ... ... .......................................... 52
3.4.2 Registration Complete ...................... ............. ............. ............ .......... ............. ............. 53
Chapter 4
Tutorial.....................................................................................................................................57
4.1 Overview ............. ................................................ .... ................................................ ............. 57
4.2 How to Set up a Wireless Network ...................................................................................... 57
4.2.1 Example Parameters ........................... ... ... .... ... ... ... .... ... ............................................. 57
4.2.2 Configuring the AP ........... ... ................................................ ... .... ... ... .......................... 58
4.2.3 Configuring the Wireless Client .................................................................................. 60
4.3 Using NAT with Multiple Public IP Addresses ..... ....... ...... ....... ...... ....... ... ...... ....... ...... ....... ... 66
4.3.1 Example Parameters and Scenario ........................................................................... 66
4.3.2 Configuring the WAN Connection with a Static IP Address ........................................ 67
4.3.3 Public IP Address Mapping .......... .... ... ... ... ................................................. ... ... ... .... ... 70
4.3.4 Forwarding Traffic from the WAN to a Local Computer .............................................. 74
4.3.5 Allow WAN-to-LAN Traffic through the Fi rew all ...... .... ...... ...... ....... ...... ....... ...... ....... ... 75
4.3.6 Testing the Connections ................................................................... ... ....................... 83
4.4 Using NAT with Multiple Game Players ...............................................................................83
4.5 How to Make a VoIP Call .....................................................................................................84
4.5.1 VoIP Calls With a Registered SIP Account ................................................................ 84
Part II: Advanced.................................................................................... 87
Chapter 5
Status Screens........................................................................................................................89
5.1 Status Screen .................................. ... ... .... ... ... ... .... ................................................ ... .......... 89
5.2 Any IP Table .............................................................................. ... ... .................................... 94
5.3 WLAN Status ...................................... ... .... ... ... ... .... ... ... .......................................................94
5.4 Packet Statistics . ... ... .... ................................................ ... .................................................... 95
5.5 VoIP Statistics ........... ................................................. ..........................................................97
Chapter 6
WAN Setup...............................................................................................................................99
6.1 Overview ............. ................................................ .... ................................................ ............. 99
6.1.1 What Yo u Can Do in the WAN Screens ..................................................................... 99
6.1.2 What You Need to Know About WAN ........................................... ... ... ..................... 100
6.1.3 Before You Begin ............................................. ... ... .... ... ... ... ... .... .............................. 100
12
P-2612HW Series User’s Guide
Table of Contents
6.2 The Internet Access Setup Screen ................................................................................... 101
6.2.1 Advanced Internet Access Setup .............................................................................104
6.3 The More Connections Screen ......................................................................................... 105
6.3.1 More Connections Edit .................................... ... ... ................................................. . 107
6.3.2 Configuring More Connections Advanced Setup .......... ... ... ... .... ... ... ... .... ... ... ... ... .... ..110
6.4 The WAN Backup Setup Screen ....... ... .... ... ... ... .... ... ... ... .... ... ... ... ... .... ...............................112
6.5 WAN Technical Reference ..................................................................................................113
6.5.1 Encapsulation ................... ... ... ... ... ................................................. ... .........................113
6.5.2 Multiplexing ............ ... ... .... ... ... ... ... ................................................. ... ... ......................115
6.5.3 VPI and VCI ........................................................ ... .... ... ... .........................................115
6.5.4 IP Address Assignment .......................................... .... ... ... ... ... .... ... ... ... .... ... ...............115
6.5.5 Nailed-Up Connection (PPP) ....................................................................................116
6.5.6 NAT .... .... ... ... ............................................. .... ... ... ... .... ...............................................116
6.5.7 Metric ....................................................... ................................................................116
6.5.8 Traffic Shaping .... ... ... ... .... ................................................ ... ......................................117
6.6 Traffic Redirect ...................................................................................................................119
Chapter 7
LAN Setup..............................................................................................................................121
7.1 Overview ............. ................................................ .... ................................................ ........... 121
7.1.1 What Yo u Can Do in the LAN Screens ..................................................................... 121
7.1.2 What You Need To Know About LAN .................................. ... .................................. 122
7.1.3 Before You Begin ............................................. ... ... .... ... ... ... ... .... ... ........................... 122
7.2 The LAN IP Screen ............................................................................................................122
7.2.1 The Advanced LAN Setup Screen ........................................................................... 124
7.2.2 Configuring the Advanced LAN Setup Screen . ... ... .... ... ... ... ... .... .............................. 125
7.3 The LAN Client List Screen ............................................................................................... 126
7.4 The LAN IP Alias Screen ................................................................................................... 128
7.5 LAN Technical Reference ...................... ................................................. ... ... .... ... ... ...........129
7.5.1 LANs, WANs and the ZyXEL Device ........................................................................ 130
7.5.2 DHCP Setup ..................... ... ... ... ... .... ... ... ... ................................................. ... ...........130
7.5.3 DNS Server Addresses ................................................. ... ... ..................................... 130
7.5.4 TCP/IP ................. ... ............................................. ... .... ... ... ... ... .................................. 131
7.5.5 RIP Setup ..................................... .... ... ... ... ................................................. ... ... ........132
7.5.6 Multicast . ... ... ... .... ... ... ... ............................................................................................ 133
7.5.7 Any IP ....................................................................................................................... 133
Chapter 8
Wireless LAN.........................................................................................................................137
8.1 Overview ............. ................................................ .... ................................................ ........... 137
8.1.1 What You Can Do in the Wireless LAN Screens ...................................................... 137
8.1.2 What You Need to Know About Wireless ................................... ... ... ... .... ... ... ... ... .... . 138
8.1.3 Before You Start ..................................... ................................................. ... ... ...........140
P-2612HW Series User’s Guide
13
Table of Contents
8.2 AP Screen ........................................................................................................................ 140
8.2.1 No Security .......................... ... ................................................ .... .............................. 142
8.2.2 WEP Encryption ..................................................... .... .............................................. 143
8.2.3 WPA(2)-PSK ............................................................................................................ 144
8.2.4 WPA(2) Authentication Screen ............................................... .... ... ... ... .... ... ... ... ... .... . 146
8.2.5 Wireless LAN Advanced Setup ...............................................................................148
8.3 More AP Screen ................................................................................................................ 149
8.3.1 More AP Edit ............................................................................................................ 150
8.4 MAC Filter ..................................................................................................................... 151
8.5 WPS ............................................. ..................................................................................... 152
8.6 WPS Station ....... ... ... .... ... ... ... .... ... ................................................ ... .... ... ... ... .....................153
8.7 WDS Screen ................................ ... ................................................ .... ... ........................... 154
8.8 Scheduling Screen ........................................................................................................... 156
8.9 Wireless LAN Technical Reference ........................................................ ... ... .... ... .............. 157
8.9.1 Additional Wireless Terms ........................................................................................ 157
8.9.2 Wireless Security Overview .....................................................................................157
8.9.3 MBSSID .............................................. ... ... ...............................................................160
8.9.4 Wireless Distribution System (WDS) ........................................................................ 160
8.9.5 WiFi Protected Setup ............................................................................................... 161
Chapter 9
Network Address Translation (NAT)....................................................................................169
9.1 Overview ............... ................................................. ... ........................................................ 169
9.1.1 What You Can Do in the NAT Screens ..................................................................... 169
9.1.2 What You Need To Know About NAT ..................... .... ... ... ... ... .... .............................. 169
9.2 NAT General Setup ... .... ... ... ... .... ... ... ... ................................................. ... ... ... .... ... ... ... ... ..... 170
9.3 Port Forwarding .......................................... ... ... .... ................................................ ... ........ 172
9.3.1 Configuring the Port Forwarding Screen ............................. ..................................... 173
9.3.2 Port Forwarding Rule Edit .......................................................................................175
9.4 Address Mapping ..............................................................................................................176
9.4.1 Address Mapping Rule Edit ..................................................................................... 177
9.4.2 SIP ALG ..................................................................................................................178
9.5 NAT Technical Reference .................................................................................................. 179
9.5.1 NAT Definitions ............ .... ... ... ... ... .... ................................................ ... .... ................. 179
9.5.2 What NAT Does ............... ... ... ... ... .... ... ................................................ .... ................. 1 80
9.5.3 How NAT Works ....................................................................................................... 180
9.5.4 NAT Application ...................................................... .... ... ... ... ..................................... 182
9.5.5 NAT Mapping Types ......................... ... ... ... ................................................. ... ...........182
Chapter 10
Voice.......................................................................................................................................185
14
10.1 Overview .......................................................................................................................... 185
10.1.1 What You Can Do in the VoIP Screens ............................................. .....................185
P-2612HW Series User’s Guide
Table of Contents
10.1.2 What You Need to Know About VoIP .....................................................................186
10.1.3 Before You Begin ................................................................................................... 187
10.2 The SIP Settings Screen .............. ... ... .... ................................................ ... .... ... ... ... ... .... . 187
10.3 The Advanced SIP Setup Screen ................................................................................... 190
10.4 The SIP QoS Screen ...................................................................................................... 193
10.5 The Analog Phone Screen ............................................................................................. 194
10.6 The Advanced Analog Phone Setup Screen .................................................................. 194
10.6.1 Configuring the Advanced Analog Phone Screen .................................................. 195
10.7 The Phone Settings Ext. Table Screen ......................... .................................................. 197
10.8 The Common Phone Settings Screen ............................................................................ 198
10.9 The Phone Region Screen ................. .... ... ... ... .... ... ... .....................................................199
10.10 The Speed Dial Screen ..................................................................................................200
10.11 Incoming Call Policy Screen .................................................................... ..................... 2 03
10.12 SIP Prefix Screen ..........................................................................................................205
10.13 SIP Technical Reference ............................................................................................... 206
10.13.1 VoIP ......................................................................................................................206
10.13.2 SIP ......................................................................................................................206
10.13.3 Quality of Service (QoS) ...................................................................................... 215
10.13.4 Phone Services Overview ............ ........................................................................ 216
Chapter 11
Phone Usage.........................................................................................................................221
11.1 Overview .......................................................................................................................... 221
11.2 Dialing a Telephone Number ............................................................................................ 221
11.3 Using Speed Dial to Dial a Telephone Number ........ ............................. ........................... 221
11.4 Using Call Park and Pickup ............................................................................................. 221
11.5 Checking the ZyXEL Device’s IP Address ....................................................................... 222
11.6 Auto Provisioning and Auto Firmware Upgrade .................................... ........................... 222
11.7 Phone Services Overview ................................................................................................ 223
11.7.1 The Flash Key ........................................................................................................223
11.7.2 Europe Type Supplementary Phone Services ........................................................ 223
11.7.3 USA Type Supplementary Services .......................................................................225
11.8 Phone Functions Summary .............................................................................................. 227
Chapter 12
Firewall...................................................................................................................................229
12.1 Overview .......................................................................................................................... 229
12.1.1 What You Can Do in the Firewall Screens ............................................................. 229
12.1.2 What You Need to Know About Firewall ................................................................ 230
12.1.3 Firewall Rule Setup Example ......... ... ... ... ................................................. ... ... ... .... . 230
12.2 The Firewall General Screen ........................................................................................... 234
12.3 The Firewall Rule Screen ........ ... ... ... ... .... ... ... ... .... ... ... ................................................ .... . 236
12.3.1 Configuring Firewall Rules .................................................................................... 237
P-2612HW Series User’s Guide
15
Table of Contents
12.3.2 Customized Services ............................................................................................240
12.3.3 Configuring a Customized Service ......................................... ... ... ... .... ................. 2 41
12.4 The Firewall Threshold Screen ........................................................................................ 241
12.4.1 Threshold Values ................................................................................................... 242
12.4.2 Configuring Firewall Thresholds ............................... ............ ............. ............. ........ 243
12.5 Firewall Technical Reference ................... .......................... ......................... ..................... 245
12.5.1 Firewall Rules Overview ......................................................................................... 245
12.5.2 Guidelines For Enhancing Security With Your Firewall .......................................... 246
12.5.3 Security Considerations ......................................................................................... 247
12.5.4 Triangle Route ........................................................................................................ 247
Chapter 13
Content Filtering...................................................................................................................251
13.1 Overview ......................................................................................................................... 251
13.1.1 What You Can Do in the Content Filter Screens .. .... ... ... ... ... .... ... ........................... 251
13.1.2 What You Need to Know About Content Filtering .................................................. 251
13.1.3 Before You Begin ................................................................................................... 251
13.1.4 Content Filtering Example ......................................................................................252
13.2 The Keyword Screen ...................................................................................................... 254
13.3 The Schedule Screen ..................................................................................................... 255
13.4 The Trusted Screen ........................................................................................................ 256
Chapter 14
VPN.........................................................................................................................................257
14.1 Overview .......................................................................................................................... 257
14.1.1 What You Can Do in the VPN Screens ..................................................................257
14.1.2 What You Need to Know About IPSec VPN ........................................................... 258
14.1.3 Before You Begin ................................................................................................... 259
14.2 VPN Setup Screen .........................................................................................................260
14.3 The VPN Edit Screen ................................................... .... ... ... ... ... .... ... ... ... .... ... ..............262
14.4 Configuring Advanced IKE Settings ...............................................................................268
14.5 Manual Key Setup ...........................................................................................................271
14.5.1 Security Parameter Index (SPI) ............................................................................ 271
14.6 Configuring Manual Key .................................................................................................272
14.7 Viewing SA Monitor ........................................................................................................ 275
14.8 Configuring VPN Global Setting ..................................................................................... 277
14.9 IPSec VPN Technical Reference ..................................................................................... 277
14.9.1 IPSec Architecture ................................................................................................. 278
14.9.2 IPSec and NAT .......................................................................................................278
14.9.3 VPN, NAT, and NAT Traversal ............................................................................... 279
14.9.4 Encapsulation ......................................................................................................... 281
14.9.5 IKE Phases ...........................................................................................................282
14.9.6 Negotiation Mode ...................................................................................................283
16
P-2612HW Series User’s Guide
Table of Contents
14.9.7 Keep Alive ..............................................................................................................283
14.9.8 Remote DNS Server .............................................................................................. 283
14.9.9 ID Type and Content .............................................................................................. 284
14.9.10 Pre-Shared Key .................................................................................................... 286
14.9.11 Diffie-Hellman (DH) Key Groups .................................. ... ... .................................. 286
14.9.12 Telecommuter VPN/IPSec Examples ................................................................... 286
Chapter 15
Certificates ............................................................................................................................291
15.1 Overview .......................................................................................................................... 291
15.1.1 What You Can Do in the Certificate Screens .........................................................291
15.1.2 What You Need to Know About Certificates ........................................................... 291
15.1.3 Verifying a Certificate .............................................................................................293
15.2 My Certificates ................................................................................................................. 295
15.3 My Certificate Details .............. ... ... ... ... .... ... ... ... ................................................. ... ... ... ..... 297
15.3.1 Using the My Certificate Import Screen ................................................................. 301
15.4 My Certificate Create ...................................................................................................... 301
15.5 Trusted CAs ...................................................................................................................304
15.6 Trusted CA Import ......................................................................................................... 306
15.7 Trusted CA Details ........................................................................................................... 307
15.8 Trusted Remote Hosts ....................................................................................................311
15.9 Trusted Remote Host Certificate Details ....................................................................... 312
15.10 Trusted Remote Hosts Import ......................................................................................315
15.11 Direct ory Servers ................................................................ ... ... ... .... .............................. 316
15.12 Directory Server Add and Edit ......................................................................................318
Chapter 16
Static Route...........................................................................................................................321
16.1 Overview ....................................................................................................................... 321
16.1.1 What You Can Do in the Static Route Screens ...................................................... 321
16.2 Configuring Static Route ..................................................................................................322
16.2.1 Static Route Edit ...................................................................................................323
Chapter 17
802.1Q/1P...............................................................................................................................325
17.1 Overview .......................................................................................................................... 325
17.1.1 What You Can Do in the 802.1Q/1P Screens ........................................................ 325
17.1.2 What You Need to Know About 802.1Q/1P ........................................................... 325
17.1.3 802.1Q/1P Example ............................................................................................... 327
17.2 The 802.1Q/1P Group Setting Screen ............................................................................. 332
17.2.1 Editing 802.1Q/1P Group Setting ................................... ... ... .... ... ... ... .... ... ... ...........333
17.3 The 802.1Q/1P Port Setting Screen ................................................................................335
P-2612HW Series User’s Guide
17
Table of Contents
Chapter 18
Quality of Service (QoS).......................................................................................................337
18.1 Overview .......................................................................................................................... 337
18.1.1 What You Can Do in the QoS Screens .................................................................. 337
18.1.2 What You Need to Know About QoS .....................................................................338
18.1.3 QoS Class Setup Example ..................................................................................... 338
18.2 The QoS General Screen ............................................................................................... 341
18.3 The Class Setup Screen ................................................................................................ 343
18.3.1 The Class Configuration Screen ...........................................................................345
18.4 The QoS Monitor Screen ................................................................................................ 349
18.5 QoS Technical Reference ................................................................................................ 349
18.5.1 IEEE 802.1Q Tag ................................................................................................... 350
18.5.2 IP Precedence ........................................................................................................ 350
18.5.3 DiffServ .................................................................................................................350
18.5.4 Automatic Priority Queue Assignment ................................................................... 351
Chapter 19
Dynamic DNS Setup .............................................................................................................353
19.1 Overview ......................................................................................................................... 353
19.1.1 What You Can Do in the DDNS Screen ................................................................. 353
19.1.2 What You Need To Know About DDNS .................................................................. 353
19.2 Configuring Dynamic DNS .............................................................................................. 354
Chapter 20
Remote Management Configuration...................................................................................357
20.1 Overview ......................................................................................................................... 357
20.1.1 What You Can Do in the Remote Management Screens ....................................... 358
20.1.2 What You Need to Know About Remote Management .......................................... 358
20.2 The WWW Screen ........................................................................................................... 359
20.3 The Telnet Screen ........................................................................................................... 360
20.4 The FTP Screen ................. .... ... ... ................................................ .... ... ... ... .... ... ... ... ... ..... 361
20.5 The SNMP Screen ...........................................................................................................362
20.5.1 Configuring SNMP .................................................................................................364
20.6 The DNS Screen .................................................... ... ... .... ... ... ... ... .................................. 365
20.7 The ICMP Screen ............................................................................................................ 366
Chapter 21
Universal Plug-and-Play (UPnP)..........................................................................................369
18
21.1 Overview ......................................................................................................................... 369
21.1.1 What You Can Do in the UPnP Screen .................................................................. 369
21.1.2 What You Need to Know About UPnP ................................................................... 369
21.2 The UPnP Screen ............................................................................................................371
21.3 Installing UPnP in Windows Example .............................................................................. 371
P-2612HW Series User’s Guide
Table of Contents
21.4 Using UPnP in Windows XP Example ............................................................................. 375
Part III: Maintenance, Troubleshooting and Specifications............. 383
Chapter 22
System...................................................................................................................................385
22.1 Overview .......................................................................................................................... 385
22.1.1 What You Can Do in the System Settings Screens ................................................385
22.1.2 What You Need to Know About System Settings ........................................ ........... 385
22.2 The General Screen ........................................................................................................386
22.3 The Time Setting Screen ................................................................................................ 388
Chapter 23
Logs ......................................................................................................................................391
23.1 Overview ......................................................................................................................... 391
23.1.1 What You Can Do in the Log Screens ....................................................................391
23.1.2 What You Need To Know About Logs ....................................................................391
23.2 The View Log Screen ...................................................................................................... 391
23.3 The Log Settings Screen ......... ... ... ... ... .... ........................................................................ 392
23.4 SMTP Error Messages ....................................................................................................395
23.4.1 Example E-mail Log ............................................................................................... 395
23.5 Log Descriptions .............................................................................................................. 396
Chapter 24
Call History ...........................................................................................................................407
24.1 Overview .......................................................................................................................... 407
24.1.1 What You Can Do in the Call History Screens ....................................................... 407
24.2 Call History Summary Screen ........................................................................................ 407
24.3 Viewing the Call History .................................................................................................. 408
24.4 Configuring Call History Settings .................................................................................... 409
Chapter 25
Tools.......................................................................................................................................413
25.1 Overview .......................................................................................................................... 413
25.1.1 What You Can Do in the Tool Screens ................................................................... 413
25.1.2 What You Need To Know About Tools .................................................................... 413
25.1.3 Before You Begin ................................................................................................... 415
25.1.4 Tool Examples ........................................................................................................ 415
25.2 Firmware Upgrade Screen ................................................. ... ... ... .... ... ... ... .... ... ... ... ... .....420
25.3 The Configuration Screen ................................................................................................ 423
25.3.1 Reset to Factory Defaults ...................................................................................... 425
P-2612HW Series User’s Guide
19
Table of Contents
25.4 Restart ............................................................................................................................. 426
25.5 Using FTP or TFTP to Back Up Configuration ................................................................ 426
25.5.1 Using the FTP Commands to Back Up Configuration ....................... ..................... 426
25.5.2 FTP Command Configuration Backup Example ................................................... 427
25.5.3 Configuration Backup Using GUI-based FTP Clients ............................................ 427
25.5.4 Backup Configuration Using TFTP ......................................................................... 427
25.5.5 TFTP Command Configuration Backup Example .................................................. 428
25.5.6 Configuration Backup Using GUI-based TFTP Clients .......................................... 429
25.6 Using FTP or TFTP to Restore Configuration ............................................................... 429
25.6.1 Restore Using FTP Session Example .................................................................... 430
25.7 FTP and TFTP Firmware and Configuration File Uploads .............................................. 430
25.7.1 FTP File Upload Command from the DOS Prompt Example ................................. 430
25.7.2 FTP Session Example of Firmware File Upload .................................................... 431
25.7.3 TFTP File Upload ................................................................................................... 431
25.7.4 TFTP Upload Command Example ......................................................................... 432
Chapter 26
Diagnostic .............................................................................................................................433
26.1 Overview .......................................................................................................................... 433
26.1.1 What You Can Do in the Diagnostic Screens ....... .................................... .............. 433
26.2 The General Diagnostic Screen ...................................................................................... 433
26.3 The DSL Line Diagnostic Screen ....................................................................................434
Chapter 27
Troubleshooting....................................................................................................................437
27.1 Overview .......................................................................................................................... 437
27.2 Power, Hardware Connections, and LEDs ................................. ... .... ... ... ... .... ... ... ... ... .... . 437
27.3 ZyXEL Device Access and Login ....................................................................................438
27.4 Internet Access ................................................................................................................ 440
27.5 Phone Calls and VoIP ......................................................................................................441
27.6 Multiple SIP Accounts ......................................................................................................442
27.6.1 Outgoing Calls ........................................................................................................ 442
27.6.2 Incoming Calls ........................................................................................................ 443
Chapter 28
Product Specifications.........................................................................................................445
Part IV: Appendices and Index ........................................................... 457
Appendix A Setting Up Your Computer’s IP Address...........................................................459
Appendix B Pop-up Windows, JavaScripts and Java Permissions......................................485
20
P-2612HW Series User’s Guide
Table of Contents
Appendix C IP Addresses and Subnetting ...........................................................................495
Appendix D Wireless LANs ..................................................................................................507
Appendix E Common Services.............................................................................................531
Appendix F Legal Information ..............................................................................................535
Index.......................................................................................................................................537
P-2612HW Series User’s Guide
21
Table of Contents
22
P-2612HW Series User’s Guide
PART I
Introduction
Introducing the ZyXEL Device (25)
Introducing the Web Configurator (31)
Wizards (39)
Tutorial (57)
23
24
CHAPTER 1
Introducing the ZyXEL Device
1.1 Overview
The P-2612HW Series is an Integrated Access Device (IAD) that combines an
ADSL2+ router with Voice over IP (VoIP) communication capabilities to allow you
to use a traditional analog telephone to make Internet calls. By integrating DSL
and NAT, you are provided with ease of installation and high-speed, shared
Internet access. The ZyXEL Device is also a c om p l e t e security solution with a
robust firewall and content filtering.
Please refer to the following description of the product name format.
• “H” denotes an integrated 4-port hu b (s wi tc h) .
• “W” denotes wireless functionality. There is an embedded mini-PCI module for
IEEE 802.11g wireless LAN connectivity . All wirel ess features documented in this
user’s guide refer to the “W” models only.
Only use firmware for your ZyXEL Device’s specific model. Refer
to the label on the bottom of your ZyXEL Device.
See the chapter on product specifications for a full list of features.
1.1.1 Internet Access
Your ZyXEL Device provides shared Internet access by connecting the DSL port to
the DSL or MODEM jack on a splitter or your telephone jack. If you prefer not to
use a DSL line and you have another broadb and modem or router (such as ADSL)
available, you can push the DSL/WAN switch (on the rear panel) to the WAN
side and connect the WAN port to the broadband modem or router. This way, you
can access the Internet via an Ethernet connection and still use the QoS, Firewall
and VoIP functions on the ZyXEL Device.
P-2612HW Series User’s Guide
25
Chapter 1 Introducing the ZyXEL Device
Computers can connect to the ZyXEL Device’s LAN ports (or wirelessly).
Figure 1 ZyXEL Device’s Router Features
LAN
You can also configure firewall and content filtering on the ZyXEL Device for
secure Internet access. When the firewall is on, all incoming traffic from the
Internet to your network is blocked unless it is initiated from your network. This
means that probes from the outside to your network are not allowed, but you can
safely browse the Internet and download files.
Internet
Use content filtering to block access to specific web sites, with URLs containing
keywords that you specify. You can define time periods and days during which
content filtering is enabled and include or exclude particular computers on your
network from content filtering. For example, you could bl ock access to certain web
sites for the kids.
Use QoS to efficiently manage traffic on your network by giving priority to certain
types of traffic and/or to particular c omput ers. For example, you could make sure
that the ZyXEL Device gives voice over Internet calls hi gh priority, and/or limit
bandwidth devoted to the boss’s excessive file downloading.
26
P-2612HW Series User’s Guide
1.1.2 VoIP Features
You can register up to 2 SIP (Session Initiation Protocol) accounts and use the
ZyXEL Device to make and receive VoIP telephone calls:
Figure 2 ZyXEL Device’s VoIP Features
Chapter 1 Introducing the ZyXEL Device
A
Internet
B
PSTN
• Peer-to-Peer calls (A) - Use the Z yXEL Device to make a call to the recipient’s IP
address without using a SIP proxy server.
• Calls via a VoIP service provider (B) - The ZyXEL Device sends your call to a
VoIP service provider’s SIP server which forwards your calls to either VoIP or
PSTN phones.
1.2 Ways to Manage the ZyXEL Device
Use any of the following methods to manage the ZyXEL Device.
• Web Configur ator. This is recommended for everyday management of the ZyXEL
Device using a (supported) web browser.
• Command Line Interface. Line commands are mostly used for troubleshooting
by service engineers.
• FTP for firmware upgrades and configuration backup/restore.
• SNMP. The device can be monitored by an SNMP manager. See the SNMP
chapter in this User’s Guide.
• SPTGEN. SPTGEN is a text configuration file that allows you to configure the
device by uploading an SPTGEN file. This is especially con v enient if y ou need to
configure many devices of the same type.
P-2612HW Series User’s Guide
27
Chapter 1 Introducing the ZyXEL Device
1.3 Good Habits for Managing the ZyXEL Device
Do the following things regularly to make the ZyXEL Device more secure and to
manage the ZyXEL Device more effectively.
• Change the password. Use a password that’s not easy to guess and that consists
of different types of characters, such as numbers and letters.
• Write down the password and put it in a safe place.
• Back up the configuration (and make sure you know how to restore it).
Restoring an earlier working configuration may be useful if the device becomes
unstable or even crashes. If you forget y our password, you will hav e to reset the
ZyXEL Device to its factory default settings . If yo u backed up an earlier
configuration file, you would not have to totally re-configure the ZyXEL Device.
You could simply restore your last configuration.
1.4 LEDs (Lights)
The following graphic displays the labels of the LEDs.
Figure 3 LEDs on the Top of the Device
None of the LEDs are on if the ZyXEL Device is not receiving power.
Table 1 LED Descriptions
LED COLOR STATUS DESCRIPTION
POWER Green On The ZyXEL Device is receiving power and ready for use.
Blinking The ZyXEL Device is self-testing.
Red On The Z yXEL Device detected an error while self-testing, or
there is a device malfunction.
Off The ZyXEL Device is not receiving power.
ETHERNET
1-4
Green On The ZyXEL Device has an Ethernet connection with a
device on the Local Area Network (LAN).
Blinking The ZyXEL Device is sending/receiving data to /from the
LAN.
Off The ZyXEL Device does not have an Ethernet connection
with the LAN.
28
P-2612HW Series User’s Guide
Chapter 1 Introducing the ZyXEL Device
Table 1 LED Descriptions
LED COLOR STATUS DESCRIPTION
WLAN Green On The wireless network is activated and is operating in
IEEE 802.11b/g mode.
Blinking The ZyXEL Device is communicating with other wireless
clients.
Off The wireless network is not activated.
DSL Green On This light applies when the ZyXEL Device is in DSL WAN
mode. The DSL line is up.
Blinking The ZyXEL Device is initializing the DSL line.
Off The DSL line is down.
INTERNET Green On The ZyXEL Device has an IP connection but no traffic.
Your device has a WAN IP address (either static or
assigned by a DHCP server), PPP negotiation was
successfully completed (if used) and the DSL connection
is up.
Blinking The ZyXEL Device is sending or receiving IP traffic.
Red On The ZyXEL Device attempted to make an IP connection
but failed. Possible causes are no response from a DHCP
server, no PPPoE response, PPPoE authentication failed.
Off The ZyXEL Device does not have an IP connection.
WAN Green On This light applies when the ZyXEL Device is in Ethernet
WAN mode. The ZyXEL Device has an Ethernet
connection with a device on the WAN.
Blinking The ZyXEL Device is sending/receiving data to/from the
WAN.
Off The ZyXEL Device does not have an Ethernet connection
with the WAN.
PHONE Green On A SIP account is registered for the phone port.
Blinking A telephone connected to the phone port has its receiver
off of the hook or there is an incoming call.
Orange On A SIP account is registered for the phone port and there
is a voice message in the corresponding SIP account.
Blinking A telephone connected to the phone port has its receiver
off of the hook and there is a voice message in the
corresponding SIP account.
Off The phone port does not have a SIP account registered.
Refer to the Quick Start Guide for information on hardware connections.
1.5 The RESET Button
If you forget your password or cannot access the web configurator, you will need
to use the RESET button at the back of the device to reload the factory-default
P-2612HW Series User’s Guide
29
Chapter 1 Introducing the ZyXEL Device
configuration file. This means that you will lose all configurations that you had
previously and the passwords will be reset to the defaults.
1 Make sure the POWER LED is on (not blinking).
2 To set the device back to the factory default settings, press the RESET button for
ten seconds or until the POWER LED begins to blink and then release it. When the
POWER LED begins to blink, the defaults have been restored and the device
restarts.
1.6 The WLAN Button
Use the WLAN button ( ) on the top of the device to turn the wireless LAN off
or on. Make sure the POWER LED is on (not blinking) before using the WLAN
button.
•Press the WLAN button for one second and release it. The WLAN LED should
change from on to off or vice versa.
• Press the WLAN button for five seconds to turn on WPS. See Section 8.9.5.1 on
page 161 for more on using WPS to configure your wireless clients.
30
P-2612HW Series User’s Guide
Loading...
