Zyxel P-660R EE User Manual [ru]

Download
Prestige 660R-6xC Series
ADSL/ADSL2/ADSL2+ Router

User’s Guide

Version 3.40
November 2004
Prestige 660R-6xC Series User’s Guide

Copyright

Copyright © 2004 by ZyXEL Communications Corporation.
The contents of this publication may not be reproduced in any part or as a whole, transcribed, stored in a retrieval system, translated into any language, or transmitted in any form or by any means, electronic, mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without the prior written permission of ZyXEL Communications Corporation.
Published by ZyXEL Communications Corporation. All rights reserved.
Disclaimer
ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein. Neither does it convey any license under its patent rights nor the patent rights of others. ZyXEL further reserves the right to make changes in any products described herein without notice. This publication is subject to change without notice.
Trademarks
ZyNOS (ZyXEL Network Operating System) is a registered trademark of ZyXEL Communications, Inc. Other trademarks mentioned in this publication are used for identification purposes only and may be properties of their respective owners.
Prestige 660R-6xC Series User’s Guide
Federal Communications
Commission (FCC) Interference
Statement
This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause undesired operations.
This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
If this equipment does cause harmful interference to radio/television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Notice 1
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Certifications
1 Go to www.zyxel.com.
2 Select your product from the drop-down list box on the ZyXEL home page to go to that
product's page.
3 Select the certification you wish to view from this page.

3 Federal Communications Commission (FCC) Interference Statement

Prestige 660R-6xC Series User’s Guide

ZyXEL Limited Warranty

ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to two years from the date of purchase. During the warranty period, and upon proof of purchase, should the product have indications of failure due to faulty workmanship and/or materials, ZyXEL will, at its discretion, repair or replace the defective products or components without charge for either parts or labor, and to whatever extent it shall deem necessary to restore the product or components to proper operating condition. Any replacement will consist of a new or re-manufactured functionally equivalent product of equal value, and will be solely at the discretion of ZyXEL. This warranty shall not apply if the product is modified, misused, tampered with, damaged by an act of God, or subjected to abnormal working conditions.
Note
Repair or replacement, as provided under this warranty, is the exclusive remedy of the purchaser. This warranty is in lieu of all other warranties, express or implied, including any implied warranty of merchantability or fitness for a particular use or purpose. ZyXEL shall in no event be held liable for indirect or consequential damages of any kind of character to the purchaser.
To obtain the services of this warranty, contact ZyXEL's Service Center for your Return Material Authorization number (RMA). Products must be returned Postage Prepaid. It is recommended that the unit be insured when shipped. Any returned products without proof of purchase or those with an out-dated warranty will be repaired or replaced (at the discretion of ZyXEL) and the customer will be billed for parts and labor. All repaired or replaced products will be shipped by ZyXEL to the corresponding return address, Postage Paid. This warranty gives you specific legal rights, and you may also have other rights that vary from country to country.
Safety Warnings
1 To reduce the risk of fire, use only No. 26 AWG or larger telephone wire.
2 Do not use this product near water, for example, in a wet basement or near a swimming
pool.
3 Avoid using this product during an electrical storm. There may be a remote risk of
electric shock from lightening.
Prestige 660R-6xC Series User’s Guide
Please have the following information ready when you contact customer support.
• Product model and serial number.
• Warranty Information.
• Date that you received your device.
• Brief description of the problem and the steps you took to solve it.

Customer Support

METHOD
LOCATION
WORLDWIDE
NORTH AMERICA
GERMANY
FRANCE
SPAIN
DENMARK
NORWAY
SWEDEN
FINLAND
SUPPORT E-MAIL TELEPHONE
SALES E-MAIL FAX FTP SITE
support@zyxel.com.tw +886-3-578-3942 www.zyxel.com
sales@zyxel.com.tw +886-3-578-2439 ftp.zyxel.com
support@zyxel.com +1-800-255-4101
+1-714-632-0882
sales@zyxel.com +1-714-632-0858 ftp.us.zyxel.com
support@zyxel.de +49-2405-6909-0 www.zyxel.de ZyXEL Deutschland GmbH.
sales@zyxel.de +49-2405-6909-99
info@zyxel.fr +33 (0)4 72 52 97 97 www.zyxel.fr Z yX E L F r an c e
+33 (0)4 72 52 19 20
support@zyxel.es +34 902 195 420 www.zyxel.es Z y X E L C o m mu n i c a t i o ns
sales@zyxel.es +34 913 005 345
support@zyxel.dk +45 39 55 07 00 www.zyxel.dk Z y X E L C o m m u n i c a t i o n s A / S
sales@zyxel.dk +45 39 55 07 07
support@zyxel.no +47 22 80 61 80 www.zyxel.no Z y X E L C o m m u n i c a t i o n s A / S
sales@zyxel.no +47 22 80 61 81
support@zyxel.se +46 31 744 7700 www.zyxel.se ZyXEL Communications A/S
sales@zyxel.se +46 31 744 7701
support@zyxel.fi +358-9-4780-8411 www.zyxel.fi Z yXEL Comm un i cations O y
sales@zyxel.fi +358-9-4780 8448
A
WEB SITE
REGULAR MAIL
ZyXEL Communications Corp.
www.europe.zyxel.com
ftp.europe.zyxel.com
www.us.zyxel.com ZyXEL Communications Inc.
6 Innov ati on Roa d II Sc ience Park Hs inchu 3 00 Ta iw a n
1130 N. Miller St. Ana hei m CA 92806- 2001 U.S.A.
Adenauerstr. 20/A2 D-52146 Wuerselen Germany
1 rue de s Ve rg er s Ba t. 1 / C 69760 Limonest France
A l e j a n d r o V i l l e g a s 3 3 1 º , 2 8 0 4 3 M a d r i d Spain
Col um bu sv ej 5 2860 Soeborg Denmark
Ni ls Hansens vei 13 0667 Oslo Norway
Sjöporten 4, 41764 Göteborg Sweden
Mal mi nk aa ri 10 00700 Helsinki Finland
a. “+” is the (prefix) number you enter to make an international telephone call.
5 Customer Support
Prestige 660R-6xC Series User’s Guide

Table of Contents

Copyright .................................................................................................................. 2
Federal Communications Commission (FCC) Interference Statement ............... 3
ZyXEL Limited Warranty.......................................................................................... 4
Customer Support.................................................................................................... 5
Table of Contents..................................................................................................... 6
List of Figures ........................................................................................................ 16
List of Tables .......................................................................................................... 22
Preface .................................................................................................................... 26
Introduction to DSL................................................................................................ 28
Chapter 1
Getting To Know Your Prestige............................................................................. 30
1.1 Introducing the Prestige .....................................................................................30
1.1.1 Features of the Prestige ...........................................................................30
1.1.2 Applications for the Prestige .....................................................................34
1.1.2.1 Internet Access ...............................................................................34
1.1.2.2 LAN to LAN Application ...................................................................34
1.1.3 Prestige Hardware Installation and Connection ........................................35
Chapter 2
Introducing the Web Configurator........................................................................ 36
2.1 Web Configurator Overview ...............................................................................36
2.1.1 Accessing the Prestige Web Configurator ................................................36
2.1.2 Resetting the Prestige ..............................................................................37
2.1.2.1 Using the Reset Button ...................................................................37
2.1.3 Navigating the Prestige Web Configurator ...............................................37
Chapter 3
Wizard Setup ......................................................................................................... 40
3.1 Introduction ........................................................................................................40
3.1.1 Encapsulation ...........................................................................................40
6
Prestige 660R-6xC Series User’s Guide
3.1.1.1 ENET ENCAP .................................................................................40
3.1.1.2 PPP over Ethernet ..........................................................................40
3.1.1.3 PPPoA .............................................................................................40
3.1.1.4 RFC 1483 ........................................................................................41
3.1.2 Multiplexing ...............................................................................................41
3.1.2.1 VC-based Multiplexing ....................................................................41
3.1.2.2 LLC-based Multiplexing ...................................................................41
3.1.3 VPI and VCI ..............................................................................................41
3.1.4 Internet Access Wizard Setup: First Screen .............................................41
3.2 IP Address and Subnet Mask .............................................................................42
3.2.1 IP Address Assignment ............................................................................43
3.2.1.1 IP Assignment with PPPoA or PPPoE Encapsulation .....................43
3.2.1.2 IP Assignment with RFC 1483 Encapsulation .................................43
3.2.1.3 IP Assignment with ENET ENCAP Encapsulation ..........................43
3.2.1.4 Private IP Addresses .......................................................................44
3.2.2 Nailed-Up Connection (PPP) ....................................................................44
3.2.3 NAT ...........................................................................................................44
3.2.4 Internet Access Wizard Setup: Second Screen ........................................44
3.2.5 DHCP Setup .............................................................................................48
3.2.5.1 IP Pool Setup ..................................................................................48
3.2.6 Internet Access Wizard Setup: Third Screen ............................................48
3.2.7 Internet Access Wizard Setup: Connection Test .......................................51
3.2.7.1 Test Your Internet Connection .........................................................51
Chapter 4
Password Setup ..................................................................................................... 52
4.1 Password Overview ...........................................................................................52
4.1.1 Configuring Password ...............................................................................52
Chapter 5
LAN Setup............................................................................................................... 54
5.1 LAN Overview ....................................................................................................54
5.1.1 LANs, WANs and the Prestige ..................................................................54
5.2 DNS Server Address ..........................................................................................55
5.3 DNS Server Address Assignment ......................................................................55
5.4 LAN TCP/IP ........................................................................................................56
5.4.1 Factory LAN Defaults ................................................................................56
5.4.2 IP Address and Subnet Mask ...................................................................56
5.4.3 RIP Setup .................................................................................................56
5.4.4 Multicast ....................................................................................................57
5.5 Configuring LAN .................................................................................................57
7
Prestige 660R-6xC Series User’s Guide
Chapter 6
WAN Setup.............................................................................................................. 60
6.1 WAN Overview ...................................................................................................60
6.2 Metric ................................................................................................................60
6.3 PPPoE Encapsulation ........................................................................................61
6.4 Traffic Shaping ...................................................................................................61
6.5 Configuring WAN Setup .....................................................................................62
6.6 Traffic Redirect ..................................................................................................65
6.7 Configuring WAN Backup ...................................................................................66
Chapter 7
Network Address Translation (NAT) Screens...................................................... 70
7.1 NAT Overview ....................................................................................................70
7.1.1 NAT Definitions .........................................................................................70
7.1.2 What NAT Does ........................................................................................71
7.1.3 How NAT Works .......................................................................................71
7.1.4 NAT Application ........................................................................................72
7.1.5 NAT Mapping Types .................................................................................72
7.2 SUA (Single User Account) Versus NAT ............................................................73
7.3 SUA Server ........................................................................................................74
7.3.1 Default Server IP Address ........................................................................74
7.3.2 Port Forwarding: Services and Port Numbers ..........................................74
7.3.3 Configuring Servers Behind SUA (Example) ............................................75
7.4 Selecting the NAT Mode ....................................................................................75
7.5 Configuring SUA Server .....................................................................................76
7.6 Configuring Address Mapping ............................................................................78
7.7 Editing an Address Mapping Rule ......................................................................79
Chapter 8
Dynamic DNS Setup............................................................................................... 82
8.1 Dynamic DNS .....................................................................................................82
8.1.1 DYNDNS Wildcard ....................................................................................82
8.2 Configuring Dynamic DNS .................................................................................82
Chapter 9
Time and Date......................................................................................................... 84
9.1 Configuring Time and Date ................................................................................84
Chapter 10
Remote Management Configuration .................................................................... 86
10.1 Remote Management Overview .......................................................................86
10.1.1 Remote Management Limitations ...........................................................86
10.1.2 Remote Management and NAT ..............................................................87
8
Prestige 660R-6xC Series User’s Guide
10.1.3 System Timeout .....................................................................................87
10.2 Telnet ................................................................................................................87
10.3 FTP ..................................................................................................................87
10.4 Web ..................................................................................................................87
10.5 Configuring Remote Management ...................................................................87
Chapter 11
Universal Plug-and-Play (UPnP) ........................................................................... 90
11.1 Introducing Universal Plug and Play ................................................................90
11.1.1 How do I know if I'm using UPnP? ..........................................................90
11.1.2 NAT Traversal .........................................................................................90
11.1.3 Cautions with UPnP ................................................................................90
11.2 UPnP and ZyXEL .............................................................................................91
11.2.1 Configuring UPnP ...................................................................................91
11.3 Installing UPnP in Windows Example ...............................................................92
11.4 Using UPnP in Windows XP Example ..............................................................95
Chapter 12
Maintenance ......................................................................................................... 104
12.1 Maintenance Overview ...................................................................................104
12.2 System Status Screen ....................................................................................104
12.2.1 System Statistics ...................................................................................106
12.3 DHCP Table Screen .......................................................................................107
12.4 Diagnostic Screens ........................................................................................108
12.4.1 Diagnostic General Screen ...................................................................108
12.4.2 Diagnostic DSL Line Screen .................................................................109
12.5 Firmware Screen ............................................................................................ 111
Chapter 13
Introducing the SMT ............................................................................................ 114
13.1 SMT Introduction ............................................................................................ 114
13.1.1 Procedure for SMT Configuration via Telnet .........................................114
13.1.2 Entering Password ................................................................................ 114
13.1.3 Prestige SMT Menu Overview .............................................................. 115
13.2 Navigating the SMT Interface .........................................................................115
13.2.1 System Management Terminal Interface Summary .............................. 117
13.3 Changing the System Password .................................................................... 118
Chapter 14
Menu 1 General Setup ......................................................................................... 120
14.1 General Setup ................................................................................................120
14.2 Procedure To Configure Menu 1 ....................................................................120
14.2.1 Procedure to Configure Dynamic DNS .................................................121
9
Prestige 660R-6xC Series User’s Guide
Chapter 15
Menu 2 WAN Backup Setup ................................................................................ 124
15.1 Introduction to WAN Backup Setup ................................................................124
15.2 Configuring Dial Backup in Menu 2 ................................................................124
15.2.1 Traffic Redirect Setup ...........................................................................126
Chapter 16
Menu 3 LAN Setup ...............................................................................................128
16.1 LAN Setup ......................................................................................................128
16.1.1 General Ethernet Setup ........................................................................128
16.2 Protocol Dependent Ethernet Setup ..............................................................129
16.3 CP/IP Ethernet Setup and DHCP ...................................................................129
Chapter 17
Internet Access .................................................................................................... 132
17.1 Internet Access Overview ..............................................................................132
17.2 IP Policies ......................................................................................................132
17.3 IP Alias ...........................................................................................................132
17.4 IP Alias Setup .................................................................................................133
17.5 Route IP Setup ...............................................................................................134
17.6 Internet Access Configuration ........................................................................135
Chapter 18
Remote Node Configuration ............................................................................... 138
18.1 Remote Node Setup Overview .......................................................................138
18.2 Remote Node Setup .......................................................................................138
18.2.1 Remote Node Profile ............................................................................138
18.2.2 Encapsulation and Multiplexing Scenarios ...........................................139
18.2.2.1 Scenario 1: One VC, Multiple Protocols ......................................139
18.2.2.2 Scenario 2: One VC, One Protocol (IP) ......................................139
18.2.2.3 Scenario 3: Multiple VCs .............................................................139
18.2.3 Outgoing Authentication Protocol .........................................................141
18.3 Remote Node Network Layer Options ...........................................................142
18.3.1 My WAN Addr Sample IP Addresses ...................................................143
18.4 Remote Node Filter ........................................................................................144
18.4.1 Web Configurator Internet Security Filter Rules ...................................145
18.4.2 Web Configurator Filter Sets ................................................................146
18.5 Editing ATM Layer Options ............................................................................147
18.5.1 VC-based Multiplexing (non-PPP Encapsulation) ................................148
18.5.2 LLC-based Multiplexing or PPP Encapsulation ....................................148
18.5.3 Advance Setup Options ........................................................................148
10
Prestige 660R-6xC Series User’s Guide
Chapter 19
Static Route Setup ............................................................................................... 150
19.1 IP Static Route Overview ...............................................................................150
19.2 Configuration ..................................................................................................150
Chapter 20
Bridging Setup ..................................................................................................... 154
20.1 Bridging in General ........................................................................................154
20.2 Bridge Ethernet Setup ....................................................................................154
20.2.1 Remote Node Bridging Setup ...............................................................154
20.2.2 Bridge Static Route Setup .....................................................................156
Chapter 21
Network Address Translation (NAT)................................................................... 158
21.1 SUA (Single User Account) Versus NAT ........................................................158
21.2 Applying NAT .................................................................................................158
21.3 NAT Setup ......................................................................................................160
21.3.1 Address Mapping Sets ..........................................................................160
21.3.1.1 SUA Address Mapping Set .........................................................161
21.3.1.2 User-Defined Address Mapping Sets ..........................................162
21.3.1.3 Ordering Your Rules ....................................................................163
21.4 Configuring a Server behind NAT ..................................................................164
21.5 General NAT Examples ..................................................................................166
21.5.1 Example 1: Internet Access Only ..........................................................166
21.5.2 Example 2: Internet Access with an Inside Server ...............................167
21.5.3 Example 3: Multiple Public IP Addresses With Inside Servers .............168
21.5.4 Example 4: NAT Unfriendly Application Programs ...............................171
11
Chapter 22
Filter Configuration.............................................................................................. 174
22.1 About Filtering ................................................................................................174
22.1.1 The Filter Structure of the Prestige .......................................................175
22.2 Configuring a Filter Set for the Prestige .........................................................176
22.3 Filter Rules Summary Menus .........................................................................177
22.4 Configuring a Filter Rule ................................................................................178
22.4.1 TCP/IP Filter Rule .................................................................................178
22.4.2 Generic Filter Rule ................................................................................181
22.5 Filter Types and NAT .....................................................................................183
22.6 Example Filter ................................................................................................183
22.7 Applying Filters and Factory Defaults ............................................................186
22.7.1 Ethernet Traffic .....................................................................................186
22.7.2 Remote Node Filters .............................................................................186
Prestige 660R-6xC Series User’s Guide
Chapter 23
SNMP Configuration ............................................................................................ 188
23.1 About SNMP ..................................................................................................188
23.2 Supported MIBs ............................................................................................189
23.3 SNMP Configuration ......................................................................................189
23.4 SNMP Traps ...................................................................................................190
Chapter 24
System Information and Diagnosis .................................................................... 192
24.1 Overview ........................................................................................................192
24.2 System Status ................................................................................................192
24.3 System Information ........................................................................................194
24.3.1 System Information ...............................................................................194
24.3.2 Console Port Speed ..............................................................................195
24.4 Log and Trace ................................................................................................196
24.4.1 Viewing Error Log .................................................................................196
24.4.2 Syslog and Accounting .........................................................................197
24.5 Diagnostic ......................................................................................................199
Chapter 25
Firmware and Configuration File Maintenance ................................................. 202
25.1 Filename Conventions ...................................................................................202
25.2 Backup Configuration .....................................................................................203
25.2.1 Backup Configuration ...........................................................................203
25.2.2 Using the FTP Command from the Command Line ..............................204
25.2.3 Example of FTP Commands from the Command Line .........................204
25.2.4 GUI-based FTP Clients .........................................................................205
25.2.5 TFTP and FTP over WAN Management Limitations .............................205
25.2.6 Backup Configuration Using TFTP .......................................................206
25.2.7 TFTP Command Example ....................................................................206
25.2.8 GUI-based TFTP Clients ......................................................................206
25.3 Restore Configuration ....................................................................................207
25.3.1 Restore Using FTP ...............................................................................207
25.3.2 Restore Using FTP Session Example ..................................................208
25.4 Uploading Firmware and Configuration Files .................................................209
25.4.1 Firmware File Upload ............................................................................209
25.4.2 Configuration File Upload .....................................................................209
25.4.3 FTP File Upload Command from the DOS Prompt Example ................210
25.4.4 FTP Session Example of Firmware File Upload ...................................211
25.4.5 TFTP File Upload .................................................................................. 211
25.4.6 TFTP Upload Command Example ........................................................212
12
Prestige 660R-6xC Series User’s Guide
Chapter 26
System Maintenance............................................................................................ 214
26.1 Command Interpreter Mode ...........................................................................214
26.2 Call Control Support .......................................................................................215
26.2.1 Budget Management ............................................................................215
26.3 Time and Date Setting ....................................................................................216
26.3.1 Resetting the Time ................................................................................218
Chapter 27
Remote Management ........................................................................................... 220
27.1 Remote Management Overview .....................................................................220
27.2 Remote Management .....................................................................................220
27.2.1 Remote Management Setup .................................................................220
27.2.2 Remote Management Limitations .........................................................221
27.3 Remote Management and NAT ......................................................................222
27.4 System Timeout .............................................................................................222
Chapter 28
IP Policy Routing.................................................................................................. 224
28.1 IP Policy Routing Overview ............................................................................224
28.2 Benefits of IP Policy Routing ..........................................................................224
28.3 Routing Policy ................................................................................................224
28.4 IP Routing Policy Setup .................................................................................225
28.5 Applying an IP Policy .....................................................................................228
28.5.1 Ethernet IP Policies ..............................................................................228
28.6 IP Policy Routing Example .............................................................................229
Chapter 29
Call Scheduling .................................................................................................... 234
29.1 Introduction ....................................................................................................234
Chapter 30
Troubleshooting ................................................................................................... 238
30.1 Problems Starting Up the Prestige .................................................................238
30.2 Problems with the LAN LED ...........................................................................238
30.3 Problems with the DSL LED ...........................................................................239
30.4 Problems with the LAN Interface ....................................................................239
30.5 Problems with the WAN Interface ..................................................................239
30.6 Problems with Internet Access .......................................................................240
30.7 Problems with the Password ..........................................................................240
30.8 Problems with the Web Configurator .............................................................241
30.9 Problems with Remote Management .............................................................241
13
Prestige 660R-6xC Series User’s Guide
Appendix A
Splitters and Microfilters ..................................................................................... 242
Connecting a POTS Splitter ................................................................................... 242
Telephone Microfilters ............................................................................................ 242
Prestige With ISDN ................................................................................................ 243
Appendix B
Setting up Your Computer’s IP Address............................................................ 244
Windows 95/98/Me................................................................................................. 244
Installing Components ..................................................................................... 245
Configuring ...................................................................................................... 246
Verifying Settings............................................................................................. 247
Windows 2000/NT/XP ............................................................................................ 247
Verifying Settings............................................................................................. 251
Macintosh OS 8/9................................................................................................... 251
Verifying Settings............................................................................................. 253
Macintosh OS X ..................................................................................................... 253
Verifying Settings............................................................................................. 254
Appendix C
IP Subnetting ........................................................................................................ 256
IP Addressing......................................................................................................... 256
IP Classes .............................................................................................................. 256
Subnet Masks ........................................................................................................ 257
Subnetting .............................................................................................................. 257
Example: Two Subnets .......................................................................................... 258
Example: Four Subnets.......................................................................................... 260
Example Eight Subnets.......................................................................................... 261
Subnetting With Class A and Class B Networks. ................................................... 262
Appendix D
PPPoE ................................................................................................................... 264
PPPoE in Action..................................................................................................... 264
Benefits of PPPoE.................................................................................................. 264
Traditional Dial-up Scenario................................................................................... 264
How PPPoE Works ................................................................................................ 265
Prestige as a PPPoE Client ................................................................................... 265
Appendix E
Virtual Circuit Topology ......................................................................................266
............................................................................................................................... 266
14
Prestige 660R-6xC Series User’s Guide
Appendix F
Command Interpreter........................................................................................... 268
Command Syntax................................................................................................... 268
Command Usage ................................................................................................... 268
Appendix G
Log Descriptions.................................................................................................. 270
Index...................................................................................................................... 276
15
Prestige 660R-6xC Series User’s Guide

List of Figures

Figure 1 Prestige Internet Access Application .................................................................... 34
Figure 2 Prestige LAN-to-LAN Application .......................................................................... 35
Figure 3 Password Screen .................................................................................................. 36
Figure 4 Change Password at Login ................................................................................... 37
Figure 5 Web Configurator: Site Map Screen ................................................................... 38
Figure 6 Internet Access Wizard Setup: First Screen ......................................................... 42
Figure 7 Internet Connection with PPPoE ........................................................................... 45
Figure 8 Internet Connection with RFC 1483 ..................................................................... 46
Figure 9 Internet Connection with ENET ENCAP ............................................................... 46
Figure 10 Internet Connection with PPPoA ......................................................................... 47
Figure 11 Internet Access Wizard Setup: Third Screen ...................................................... 49
Figure 12 Internet Access Wizard Setup: LAN Configuration ............................................. 50
Figure 13 Internet Access Wizard Setup: Connection Tests ............................................... 51
Figure 14 Password ............................................................................................................ 52
Figure 15 LAN and WAN IP Addresses .............................................................................. 54
Figure 16 LAN Setup ........................................................................................................... 58
Figure 17 Example of Traffic Shaping ................................................................................. 62
Figure 18 WAN Setup (PPPoE) .......................................................................................... 63
Figure 19 Traffic Redirect Example ..................................................................................... 66
Figure 20 Traffic Redirect LAN Setup ................................................................................. 66
Figure 21 WAN Backup ....................................................................................................... 67
Figure 22 How NAT Works .................................................................................................. 72
Figure 23 NAT Application With IP Alias ............................................................................. 72
Figure 24 Multiple Servers Behind NAT Example ............................................................... 75
Figure 25 NAT Mode ........................................................................................................... 76
Figure 26 Edit SUA/NAT Server Set ................................................................................... 77
Figure 27 Address Mapping Rules ...................................................................................... 78
Figure 28 Address Mapping Rule Edit ................................................................................ 79
Figure 29 Dynamic DNS ..................................................................................................... 83
Figure 30 Time and Date ..................................................................................................... 84
Figure 31 Telnet Configuration on a TCP/IP Network ......................................................... 87
Figure 32 Remote Management ......................................................................................... 88
Figure 33 Configuring UPnP ............................................................................................... 91
Figure 34 Add/Remove Programs: Windows Setup: Communication ................................. 92
Figure 35 Add/Remove Programs: Windows Setup: Communication: Components .......... 93
Figure 36 Network Connections .......................................................................................... 93
16
Prestige 660R-6xC Series User’s Guide
Figure 37 Windows Optional Networking Components Wizard .......................................... 94
Figure 38 Networking Services ........................................................................................... 95
Figure 39 Network Connections .......................................................................................... 96
Figure 40 Internet Connection Properties .......................................................................... 97
Figure 41 Internet Connection Properties: Advanced Settings ........................................... 98
Figure 42 Internet Connection Properties: Advanced Settings: Add ................................... 98
Figure 43 System Tray Icon ................................................................................................ 99
Figure 44 Internet Connection Status .................................................................................. 99
Figure 45 Network Connections .......................................................................................... 100
Figure 46 Network Connections: My Network Places ......................................................... 101
Figure 47 Network Connections: My Network Places: Properties: Example ....................... 102
Figure 48 System Status ..................................................................................................... 105
Figure 49 System Status: Show Statistics ........................................................................... 106
Figure 50 DHCP Table ........................................................................................................ 108
Figure 51 Diagnostic: General ............................................................................................ 109
Figure 52 Diagnostic: DSL Line .......................................................................................... 110
Figure 53 Firmware Upgrade .............................................................................................. 111
Figure 54 Network Temporarily Disconnected .................................................................... 112
Figure 55 Error Message .................................................................................................... 112
Figure 56 Login Screen ....................................................................................................... 115
Figure 57 Prestige SMT Menu Overview ............................................................................ 115
Figure 58 Menu 23 Change Password ................................................................................ 118
Figure 59 Menu 1 General Setup ........................................................................................ 121
Figure 60 Menu 1.1 Configure Dynamic DNS .................................................................... 122
Figure 61 Menu 2 WAN Backup Setup ............................................................................... 125
Figure 62 Menu 2.1Traffic Redirect Setup ........................................................................... 126
Figure 63 Menu 3 LAN Setup .............................................................................................. 128
Figure 64 Menu 3.1 LAN Port Filter Setup .......................................................................... 128
Figure 65 Menu 3.2 TCP/IP and DHCP Ethernet Setup ..................................................... 129
Figure 66 IP Alias Network Example ................................................................................... 133
Figure 67 Menu 3.2 TCP/IP and DHCP Setup ................................................................... 133
Figure 68 Menu 3.2.1 IP Alias Setup .................................................................................. 134
Figure 69 Menu 1 General Setup ........................................................................................ 135
Figure 70 Menu 4 Internet Access Setup ............................................................................ 136
Figure 71 Menu 11 Remote Node Setup ............................................................................. 139
Figure 72 Menu 11.1 Remote Node Profile ........................................................................ 140
Figure 73 Menu 11.3 Remote Node Network Layer Options .............................................. 142
Figure 74 Sample IP Addresses for a TCP/IP LAN-to-LAN Connection ............................. 144
Figure 75 Menu 11.5 Remote Node Filter (RFC 1483 or ENET Encapsulation) ................. 144
Figure 76 Menu 11.5 Remote Node Filter (PPPoA or PPPoE Encapsulation) ................... 145
Figure 77 Internet Security .................................................................................................. 145
Figure 78 Menu 21 Filer Set Configuration ......................................................................... 146
Figure 79 Menu 21.11 WebSet 11 ....................................................................................... 147
17
Prestige 660R-6xC Series User’s Guide
Figure 80 Menu 21.12 WebSet 12 ...................................................................................... 147
Figure 81 Menu 11.6 for VC-based Multiplexing ................................................................. 148
Figure 82 Menu 11.6 for LLC-based Multiplexing or PPP Encapsulation ............................ 148
Figure 83 Menu 11.1 Remote Node Profile ......................................................................... 149
Figure 84 Menu 11.8 Advance Setup Options .................................................................... 149
Figure 85 Sample Static Routing Topology ......................................................................... 150
Figure 86 Menu 12 Static Route Setup ............................................................................... 151
Figure 87 Menu 12.1 IP Static Route Setup ........................................................................ 151
Figure 88 Menu12.1.1 Edit IP Static Route ......................................................................... 151
Figure 89 Menu 11.1 Remote Node Profile ......................................................................... 155
Figure 90 Menu 11.3 Remote Node Network Layer Options .............................................. 155
Figure 91 Menu 12.3.1 Edit Bridge Static Route ................................................................. 156
Figure 92 Menu 4 Applying NAT for Internet Access .......................................................... 159
Figure 93 Applying NAT in Menus 4 & 11.3 ......................................................................... 159
Figure 94 Menu 15 NAT Setup .......................................................................................... 160
Figure 95 Menu 15.1 Address Mapping Sets ...................................................................... 161
Figure 96 Menu 15.1.255 SUA Address Mapping Rules .................................................... 161
Figure 97 Menu 15.1.1 First Set .......................................................................................... 162
Figure 98 Menu 15.1.1.1 Editing/Configuring an Individual Rule in a Set .......................... 164
Figure 99 Menu 15.2 NAT Server Setup ............................................................................. 165
Figure 100 Menu 15.2.1 NAT Server Setup ........................................................................ 165
Figure 101 Multiple Servers Behind NAT Example ............................................................. 166
Figure 102 NAT Example 1 ................................................................................................. 166
Figure 103 Menu 4 Internet Access & NAT Example .......................................................... 167
Figure 104 NAT Example 2 ................................................................................................. 167
Figure 105 Menu 15.2.1 Specifying an Inside Server ......................................................... 168
Figure 106 NAT Example 3 ................................................................................................. 169
Figure 107 Example 3: Menu 11.3 ...................................................................................... 169
Figure 108 Example 3: Menu 15.1.1.1 ................................................................................ 170
Figure 109 Example 3: Final Menu 15.1.1 .......................................................................... 170
Figure 110 Example 3: Menu 15.2.1 ................................................................................... 171
Figure 111 NAT Example 4 .................................................................................................. 171
Figure 112 Example 4: Menu 15.1.1.1 Address Mapping Rule ........................................... 172
Figure 113 Example 4: Menu 15.1.1 Address Mapping Rules ............................................ 172
Figure 114 Outgoing Packet Filtering Process .................................................................... 174
Figure 115 Filter Rule Process ............................................................................................ 175
Figure 116 Menu 21 Filter Set Configuration ...................................................................... 176
Figure 117 NetBIOS_WAN Filter Rules Summary ............................................................. 176
Figure 118 NetBIOS_LAN Filter Rules Summary .............................................................. 177
Figure 119 Menu 21.x.1 TCP/IP Filter Rule ........................................................................ 179
Figure 120 Executing an IP Filter ........................................................................................ 181
Figure 121 Menu 21.5.1 Generic Filter Rule ...................................................................... 182
Figure 122 Protocol and Device Filter Sets ......................................................................... 183
18
Prestige 660R-6xC Series User’s Guide
Figure 123 Sample Telnet Filter .......................................................................................... 184
Figure 124 Menu 21.6.1 Sample Filter ............................................................................... 185
Figure 125 Menu 21.6.1 Sample Filter Rules Summary ..................................................... 185
Figure 126 Filtering Ethernet Traffic .................................................................................... 186
Figure 127 Filtering Remote Node Traffic ........................................................................... 187
Figure 128 SNMP Management Model ............................................................................... 188
Figure 129 Menu 22 SNMP Configuration .......................................................................... 189
Figure 130 Menu 24 System Maintenance ......................................................................... 192
Figure 131 Menu 24.1 System Maintenance : Status ......................................................... 193
Figure 132 Menu 24.2 System Information and Console Port Speed ................................. 194
Figure 133 Menu 24.2.1 System Maintenance: Information ............................................... 195
Figure 134 Menu 24.2.2 System Maintenance : Change Console Port Speed ................... 196
Figure 135 Menu 24.3 System Maintenance: Log and Trace ............................................. 196
Figure 136 Sample Error and Information Messages ......................................................... 197
Figure 137 Menu 24.3.2 System Maintenance: Syslog and Accounting ............................. 197
Figure 138 Syslog Example ................................................................................................ 198
Figure 139 Menu 24.4 System Maintenance : Diagnostic ................................................... 200
Figure 140 Telnet in Menu 24.5 ........................................................................................... 204
Figure 141 FTP Session Example ...................................................................................... 205
Figure 142 Telnet into Menu 24.6 ........................................................................................ 208
Figure 143 Restore Using FTP Session Example ............................................................... 208
Figure 144 Telnet Into Menu 24.7.1 Upload System Firmware .......................................... 209
Figure 145 Telnet Into Menu 24.7.2 System Maintenance ................................................. 210
Figure 146 FTP Session Example of Firmware File Upload ............................................... 211
Figure 147 Command Mode in Menu 24 ............................................................................. 214
Figure 148 Valid Commands ............................................................................................... 214
Figure 149 Menu 24.9 System Maintenance: Call Control .................................................. 215
Figure 150 Menu 24.9.1 System Maintenance: Budget Management ................................ 216
Figure 151 Menu 24 System Maintenance ......................................................................... 217
Figure 152 Menu 24.10 System Maintenance: Time and Date Setting ............................... 218
Figure 153 Menu 24.11 Remote Management Control ....................................................... 221
Figure 154 Menu 25 IP Routing Policy Setup ..................................................................... 225
Figure 155 Menu 25.1 IP Routing Policy Setup .................................................................. 226
Figure 156 Menu 25.1.1 IP Routing Policy .......................................................................... 227
Figure 157 Menu 3.2 TCP/IP and DHCP Ethernet Setup ................................................... 229
Figure 158 Menu 11.3 Remote Node Network Layer Options ............................................ 229
Figure 159 Example of IP Policy Routing ........................................................................... 230
Figure 160 IP Routing Policy Example 1 ............................................................................. 230
Figure 161 IP Routing Policy Example 2 ............................................................................. 231
Figure 162 Applying IP Policies Example ........................................................................... 232
Figure 163 Menu 26 Schedule Setup .................................................................................. 234
Figure 164 Menu 26.1 Schedule Set Setup ....................................................................... 235
Figure 165 Applying Schedule Set(s) to a Remote Node (PPPoE) .................................... 236
19
Prestige 660R-6xC Series User’s Guide
Figure 166 Connecting a POTS Splitter .............................................................................. 242
Figure 167 Connecting a Microfilter .................................................................................... 243
Figure 168 Prestige with ISDN ............................................................................................ 243
Figure 169 WIndows 95/98/Me: Network: Configuration ..................................................... 245
Figure 170 Windows 95/98/Me: TCP/IP Properties: IP Address ......................................... 246
Figure 171 Windows 95/98/Me: TCP/IP Properties: DNS Configuration ............................ 247
Figure 172 Windows XP: Start Menu .................................................................................. 248
Figure 173 Windows XP: Control Panel .............................................................................. 248
Figure 174 Windows XP: Control Panel: Network Connections: Properties ....................... 249
Figure 175 Windows XP: Local Area Connection Properties .............................................. 249
Figure 176 Windows XP: Advanced TCP/IP Settings ......................................................... 250
Figure 177 Windows XP: Internet Protocol (TCP/IP) Properties ......................................... 251
Figure 178 Macintosh OS 8/9: Apple Menu ........................................................................ 252
Figure 179 Macintosh OS 8/9: TCP/IP ................................................................................ 252
Figure 180 Macintosh OS X: Apple Menu ........................................................................... 253
Figure 181 Macintosh OS X: Network ................................................................................. 254
Figure 182 Single-Computer per Router Hardware Configuration ...................................... 265
Figure 183 Prestige as a PPPoE Client .............................................................................. 265
Figure 184 Virtual Circuit Topology ..................................................................................... 266
20
Prestige 660R-6xC Series User’s Guide
21
Prestige 660R-6xC Series User’s Guide

List of Tables

Table 1 ADSL Standards .................................................................................................... 30
Table 2 Web Configurator Screens Summary .................................................................... 38
Table 3 Internet Access Wizard Setup: First Screen .......................................................... 42
Table 4 Internet Connection with PPPoE .......................................................................... 45
Table 5 Internet Connection with RFC 1483 ...................................................................... 46
Table 6 Internet Connection with ENET ENCAP ................................................................ 47
Table 7 Internet Connection with PPPoA ........................................................................... 48
Table 8 Internet Access Wizard Setup: LAN Configuration ................................................ 50
Table 9 Password ............................................................................................................... 52
Table 10 LAN Setup ........................................................................................................... 58
Table 11 WAN Setup .......................................................................................................... 63
Table 12 WAN Backup ....................................................................................................... 67
Table 13 NAT Definitions .................................................................................................... 70
Table 14 NAT Mapping Types ............................................................................................ 73
Table 15 Services and Port Numbers ................................................................................. 74
Table 16 NAT Mode ............................................................................................................ 76
Table 17 Edit SUA/NAT Server Set .................................................................................... 77
Table 18 Address Mapping Rules ...................................................................................... 78
Table 19 Address Mapping Rule Edit ................................................................................. 80
Table 20 Dynamic DNS ...................................................................................................... 83
Table 21 Time and Date ..................................................................................................... 85
Table 22 Remote Management .......................................................................................... 88
Table 23 Configuring UPnP ................................................................................................ 91
Table 24 System Status ...................................................................................................... 105
Table 25 System Status: Show Statistics ........................................................................... 107
Table 26 DHCP Table ......................................................................................................... 108
Table 27 Diagnostic: General ............................................................................................. 109
Table 28 Diagnostic: DSL Line ........................................................................................... 110
Table 29 Firmware Upgrade ............................................................................................... 111
Table 30 Navigating the SMT Interface .............................................................................. 116
Table 31 SMT Main Menu .................................................................................................. 117
Table 32 Main Menu Summary .......................................................................................... 117
Table 33 Menu 1 General Setup ........................................................................................ 121
Table 34 Menu 1.1 Configure Dynamic DNS ..................................................................... 122
Table 35 Menu 2 WAN Backup Setup ................................................................................ 125
Table 36 Menu 2.1Traffic Redirect Setup ........................................................................... 126
22
Prestige 660R-6xC Series User’s Guide
Table 37 DHCP Ethernet Setup ......................................................................................... 130
Table 38 TCP/IP Ethernet Setup ........................................................................................ 130
Table 39 Menu 3.2.1 IP Alias Setup ................................................................................... 134
Table 40 Menu 4 Internet Access Setup ............................................................................ 136
Table 41 Menu 11.1 Remote Node Profile ......................................................................... 140
Table 42 Menu 11.3 Remote Node Network Layer Options ............................................... 142
Table 43 Menu 11.8 Advance Setup Options ..................................................................... 149
Table 44 Menu12.1.1 Edit IP Static Route .......................................................................... 152
Table 45 Remote Node Network Layer Options: Bridge Fields .......................................... 155
Table 46 Menu 12.3.1 Edit Bridge Static Route .................................................................. 156
Table 47 Applying NAT in Menus 4 & 11.3 ......................................................................... 160
Table 48 SUA Address Mapping Rules .............................................................................. 161
Table 49 Menu 15.1.1 First Set .......................................................................................... 163
Table 50 Menu 15.1.1.1 Editing/Configuring an Individual Rule in a Set .......................... 164
Table 51 Abbreviations Used in the Filter Rules Summary Menu ...................................... 177
Table 52 Rule Abbreviations Used ..................................................................................... 178
Table 53 Menu 21.x.1 TCP/IP Filter Rule ........................................................................... 179
Table 54 Menu 21.1.5.1 Generic Filter Rule ....................................................................... 182
Table 55 Filter Sets Table ................................................................................................... 186
Table 56 Menu 22 SNMP Configuration ............................................................................. 190
Table 57 SNMP Traps ........................................................................................................ 190
Table 58 Ports and Permanent Virtual Circuits ................................................................... 191
Table 59 Menu 24.1 System Maintenance : Status ............................................................ 193
Table 60 Menu 24.2.1 System Maintenance: Information .................................................. 195
Table 61 Menu 24.3.2 System Maintenance : Syslog and Accounting .............................. 197
Table 62 Menu 24.4 System Maintenance Menu: Diagnostic ............................................ 200
Table 63 Filename Conventions ......................................................................................... 203
Table 64 General Commands for GUI-based FTP Clients ................................................. 205
Table 65 General Commands for GUI-based TFTP Clients ............................................... 207
Table 66 Menu 24.9.1 System Maintenance : Budget Management .................................. 216
Table 67 Menu 24.10 System Maintenance: Time and Date Setting ................................ 218
Table 68 Menu 24.11 Remote Management Control .......................................................... 221
Table 69 Menu 25.1 IP Routing Policy Setup ..................................................................... 226
Table 70 Menu 25.1.1 IP Routing Policy ............................................................................ 227
Table 71 Menu 26.1 Schedule Set Setup ........................................................................... 235
Table 72 Troubleshooting the Start-Up of Your Prestige .................................................... 238
Table 73 Troubleshooting the LAN LED ............................................................................. 238
Table 74 Troubleshooting the DSL LED ............................................................................. 239
Table 75 Troubleshooting the LAN Interface ...................................................................... 239
Table 76 Troubleshooting the WAN Interface ..................................................................... 239
Table 77 Troubleshooting Internet Access ......................................................................... 240
Table 78 Troubleshooting the Password ............................................................................ 240
Table 79 Troubleshooting the Web Configurator ................................................................ 241
23
Prestige 660R-6xC Series User’s Guide
Table 80 Troubleshooting Remote Management ............................................................... 241
Table 81 Classes of IP Addresses ..................................................................................... 256
Table 82 Allowed IP Address Range By Class ................................................................... 257
Table 83 “Natural” Masks .................................................................................................. 257
Table 84 Alternative Subnet Mask Notation ....................................................................... 258
Table 85 Two Subnets Example ......................................................................................... 258
Table 86 Subnet 1 .............................................................................................................. 259
Table 87 Subnet 2 .............................................................................................................. 259
Table 88 Subnet 1 .............................................................................................................. 260
Table 89 Subnet 2 .............................................................................................................. 260
Table 90 Subnet 3 .............................................................................................................. 260
Table 91 Subnet 4 .............................................................................................................. 261
Table 92 Eight Subnets ...................................................................................................... 261
Table 93 Class C Subnet Planning ..................................................................................... 261
Table 94 Class B Subnet Planning ..................................................................................... 262
Table 95 System Maintenance Logs .................................................................................. 270
Table 96 System Error Logs ............................................................................................... 271
Table 97 Packet Filter Logs ................................................................................................ 271
Table 98 ICMP Logs ........................................................................................................... 271
Table 99 CDR Logs ............................................................................................................ 271
Table 100 PPP Logs ........................................................................................................... 272
Table 101 ICMP Notes ....................................................................................................... 272
Table 102 Syslog Logs ....................................................................................................... 273
Table 103 RFC-2408 ISAKMP Payload Types ................................................................... 273
24
Prestige 660R-6xC Series User’s Guide
25
Prestige 660R-6xC Series User’s Guide

Preface

Congratulations on your purchase of the Prestige 660R-6xC ADSL/ADSL2/ADSL2+ Router.
Note: Register your product online to receive e-mail notices of firmware upgrades and information at www.zyxel.com
www.us.zyxel.com
Your Prestige is easy to install and configure.
for North American products.
About This User's Guide
This manual is designed to guide you through the configuration of your Prestige for its various applications. The web configurator parts of this guide contain background information on features configurable by web configurator. The SMT parts of this guide contain background information solely on features not configurable by web configurator.
for global products, or at
Note: Use the web configurator, System Management Terminal (SMT) or command interpreter interface to configure your Prestige. Not all features can be configured through all interfaces.
Syntax Conventions
• “Enter” means for you to type one or more characters. “Select” or “Choose” means for you to use one predefined choices.
• The SMT menu titles and labels are in Bold Times New Roman font. Predefined field choices are in Bold Arial font. Command and arrow keys are enclosed in square brackets. [ENTER] means the Enter, or carriage return key; [ESC] means the Escape key and [SPACE BAR] means the Space Bar.
• Mouse action sequences are denoted using a comma. For example, “click the Apple icon, Control Panels and then Modem” means first click the Apple icon, then point your mouse pointer to Control Panels and then click Modem.
• For brevity’s sake, we will use “e.g.,” as a shorthand for “for instance”, and “i.e.,” for “that is” or “in other words” throughout this manual.
• The Prestige 660R-6xC series may be referred to as the Prestige in this user’s guide. This refers to both models (ADSL over POTS and ADSL over ISDN) unless specifically identified.
Related Documentation
• Supporting Disk
Refer to the included CD for support documents.
• Quick Start Guide
Preface 26
Prestige 660R-6xC Series User’s Guide
The Quick Start Guide is designed to help you get up and running right away. They contain connection information and instructions on getting started.
• Web Configurator Online Help
Embedded web help for descriptions of individual screens and supplementary information.
• ZyXEL Glossary and Web Site
Please refer to www.zyxel.com for an online glossary of networking terms and additional support documentation.
User Guide Feedback
Help us help you. E-mail all User Guide-related comments, questions or suggestions for improvement to techwriters@zyxel.com.tw or send regular mail to The Technical Writing Team, ZyXEL Communications Corp., 6 Innovation Road II, Science-Based Industrial Park, Hsinchu, 300, Taiwan. Thank you.
Graphics Icons Key
Prestige Computer Notebook computer
Server DSLAM Telephone
Router Switch
27 Preface
Prestige 660R-6xC Series User’s Guide

Introduction to DSL

DSL (Digital Subscriber Line) technology enhances the data capacity of the existing twisted­pair wire that runs between the local telephone company switching offices and most homes and offices. While the wire itself can handle higher frequencies, the telephone switching equipment is designed to cut off signals above 4,000 Hz to filter noise off the voice line, but now everybody is searching for ways to get more bandwidth to improve access to the Web ­hence DSL technologies.
There are actually seven types of DSL service, ranging in speeds from 16 Kbits/sec to 52 Mbits/sec. The services are either symmetrical (traffic flows at the same speed in both directions), or asymmetrical (the downstream capacity is higher than the upstream capacity). Asymmetrical services (ADSL) are suitable for Internet users because more information is usually downloaded than uploaded. For example, a simple button click in a web browser can start an extended download that includes graphics and text.
As data rates increase, the carrying distance decreases. That means that users who are beyond a certain distance from the telephone company’s central office may not be able to obtain the higher speeds.
A DSL connection is a point-to-point dedicated circuit, meaning that the link is always up and there is no dialing required.
Introduction to ADSL
It is an asymmetrical technology, meaning that the downstream data rate is much higher than the upstream data rate. As mentioned, this works well for a typical Internet session in which more information is downloaded, for example, from Web servers, than is uploaded. ADSL operates in a frequency range that is above the frequency range of voice services, so the two systems can operate over the same cable.
Introduction to DSL 28
Prestige 660R-6xC Series User’s Guide
29 Introduction to DSL

Getting To Know Your Prestige

This chapter describes the key features and applications of your Prestige.

1.1 Introducing the Prestige

Your Prestige integrates high-speed 10/100Mbps auto-negotiating LAN interface(s) and a high-speed ADSL port into a single package. The Prestige is ideal for high-speed Internet browsing and making LAN-to-LAN connections to remote networks. The Prestige is an ADSL router compatible with the ADSL/ADSL2/ADSL2+ standards. Maximum data rates attainable by the Prestige for each standard are shown in the next table.
Table 1 ADSL Standards
Prestige 660R-6xC Series User’s Guide
CHAPTER 1
DATA RATE STANDARD UPSTREAM DOWNSTREAM
ADSL
ADSL2
ADSL2+
Note: The standard your ISP supports determines the maximum upstream
and downstream speeds attainable. Actual speeds attained also depend on the distance from your ISP, line quality, etc.
By integrating DSL and NAT, the Prestige provides ease of installation and Internet access.
Models ending in "1", for example P660R-61C, denote a device that works over the analog telephone system, POTS (Plain Old Telephone Service). Models ending in "3" denote a device that works over ISDN (Integrated Synchronous Digital System). Models ending in "7" denote a device that works over T-ISDN (UR-2).
Note: Only use firmware for your Prestige’s specific model. Refer to the label on the bottom of your Prestige.
832 kbps 8Mbps
3.5Mbps 12Mbps
3.5Mbps 24Mbps
The web browser-based Graphical User Interface (GUI) provides easy management.

1.1.1 Features of the Prestige

The following sections describe the features of the Prestige.
Chapter 1 Getting To Know Your Prestige 30
Prestige 660R-6xC Series User’s Guide
High Speed Internet Access
Your Prestige ADSL/ADSL2/ADSL2+ router can support downstream transmission rates of up to 24Mbps and upstream transmission rates of 3.5Mbps. Actual speeds attained depend on ISP DSLAM environment.
Traffic Redirect
Traffic redirect forwards WAN traffic to a backup gateway when the Prestige cannot connect to the Internet, thus acting as an auxiliary if your regular WAN connection fails.
Universal Plug and Play (UPnP)
Using the standard TCP/IP protocol, the Prestige and other UPnP enabled devices can dynamically join a network, obtain an IP address and convey its capabilities to other devices on the network.
PPPoE Support (RFC2516)
PPPoE (Point-to-Point Protocol over Ethernet) emulates a dial-up connection. It allows your ISP to use their existing network configuration with newer broadband technologies such as ADSL. The PPPoE driver on the Prestige is transparent to the computers on the LAN, which see only Ethernet and are not aware of PPPoE thus saving you from having to manage PPPoE clients on individual computers.
Network Address Translation (NAT)
Network Address Translation (NAT) allows the translation of an Internet protocol address used within one network (for example a private IP address used in a local network) to a different IP address known within another network (for example a public IP address used on the Internet).
10/100M Auto-negotiating Ethernet/Fast Ethernet Interface(s)
This auto-negotiation feature allows the Prestige to detect the speed of incoming transmissions and adjust appropriately without manual intervention. It allows data transfer of either 10 Mbps or 100 Mbps in either half-duplex or full-duplex mode depending on your Ethernet network.
Auto-Crossover (MDI/MDI-X) 10/100 Mbps Ethernet Interface(s)
These interfaces automatically adjust to either a crossover or straight-through Ethernet cable.
Dynamic DNS Support
With Dynamic DNS support, you can have a static hostname alias for a dynamic IP address, allowing the host to be more easily accessible from various locations on the Internet. You must register for this service with a Dynamic DNS service provider.
31 Chapter 1 Getting To Know Your Prestige
Prestige 660R-6xC Series User’s Guide
Multiple PVC (Permanent Virtual Circuits) Support
Your Prestige supports up to 8 PVC’s.
ADSL Standards
• Full-Rate (ANSI T1.413, Issue 2; G.dmt (G.992.1) with line rate support of up to 8 Mbps downstream and 832 Kbps upstream.
• G.lite (G.992.2) with line rate support of up to 1.5Mbps downstream and 512Kbps upstream.
• Supports Multi-Mode standard (ANSI T1.413, Issue 2; G.dmt (G.992.1); G.lite (G992.2)).
• TCP/IP (Transmission Control Protocol/Internet Protocol) network layer protocol.
• ATM Forum UNI 3.1/4.0 PVC.
• Supports up to 8 PVCs (UBR, CBR, VBR).
• Multiple Protocol over AAL5 (RFC 1483).
• PPP over AAL5 (RFC 2364).
• PPP over Ethernet over AAL5 (RFC 2516).
• RFC 1661.
• PPP over PAP (RFC 1334).
• PPP over CHAP (RFC 1994).
Protocol Support
• DHCP Support
DHCP (Dynamic Host Configuration Protocol) allows the individual clients (computers) to obtain the TCP/IP configuration at start-up from a centralized DHCP server. The Prestige has built-in DHCP server capability enabled by default. It can assign IP addresses, an IP default gateway and DNS servers to DHCP clients. The Prestige can now also act as a surrogate DHCP server (DHCP Relay) where it relays IP address assignment from the actual real DHCP server to the clients.
•IP Alias
IP Alias allows you to partition a physical network into logical networks over the same Ethernet interface. The Prestige supports three logical LAN interfaces via its single physical Ethernet interface with the Prestige itself as the gateway for each LAN network.
• IP Policy Routing (IPPR)
Traditionally, routing is based on the destination address only and the router takes the shortest path to forward a packet. IP Policy Routing (IPPR) provides a mechanism to override the default routing behavior and alter the packet forwarding based on the policy defined by the network administrator.
• PPP (Point-to-Point Protocol) link layer protocol.
• Transparent bridging for unsupported network layer protocols.
• RIP I/RIP II
• IGMP Proxy
Chapter 1 Getting To Know Your Prestige 32
Prestige 660R-6xC Series User’s Guide
• ICMP support
• ATM QoS support
• MIB II support (RFC 1213)
Networking Compatibility
Your Prestige is compatible with the major ADSL DSLAM (Digital Subscriber Line Access Multiplexer) providers, making configuration as simple as possible for you.
Multiplexing
The Prestige supports VC-based and LLC-based multiplexing.
Encapsulation
The Prestige supports PPPoA (RFC 2364 - PPP over ATM Adaptation Layer 5), RFC 1483 encapsulation over ATM, MAC encapsulated routing (ENET encapsulation) as well as PPP over Ethernet (RFC 2516).
Network Management
• Menu driven SMT (System Management Terminal) management
• Embedded web configurator
• CLI (Command Line Interpreter)
• Remote Management via Telnet or Web
•SNMP manageable
• DHCP Server/Client/Relay
• Built-in Diagnostic Tools
•Syslog
• Telnet Support (Password-protected telnet access to internal configuration manager)
• TFTP/FTP server, firmware upgrade and configuration backup/support supported
• Supports OAM F4/F5 loop-back, AIS and RDI OAM cells
Other PPPoE Features
• PPPoE idle time out
• PPPoE Dial on Demand
Diagnostics Capabilities
The Prestige can perform self-diagnostic tests. These tests check the integrity of the following circuitry:
• FLASH memory
• ADSL circuitry
•RAM
33 Chapter 1 Getting To Know Your Prestige
• LAN port
Packet Filters
The Prestige's packet filtering functions allows added network security and management.
Ease of Installation
Your Prestige is designed for quick, intuitive and easy installation.
Housing
Your Prestige's compact and ventilated housing minimizes space requirements making it easy to position anywhere in your busy office.

1.1.2 Applications for the Prestige

Here are some example uses for which the Prestige is well suited.
Prestige 660R-6xC Series User’s Guide
1.1.2.1 Internet Access
The Prestige is the ideal high-speed Internet access solution. Your Prestige supports the TCP/ IP protocol, which the Internet uses exclusively. It is compatible with all major ADSL DSLAM (Digital Subscriber Line Access Multiplexer) providers. A DSLAM is a rack of ADSL line cards with data multiplexed into a backbone network interface/connection (for example, T1, OC3, DS3, ATM or Frame Relay). Think of it as the equivalent of a modem rack for ADSL. A typical Internet access application is shown below.
Figure 1 Prestige Internet Access Application
Internet Single User Account
For a SOHO (Small Office/Home Office) environment, your Prestige offers the Single User Account (SUA) feature that allows multiple users on the LAN (Local Area Network) to access the Internet concurrently for the cost of a single IP address.
1.1.2.2 LAN to LAN Application
You can use the Prestige to connect two geographically dispersed networks over the ADSL line. A typical LAN-to-LAN application for your Prestige is shown as follows.
Chapter 1 Getting To Know Your Prestige 34
Prestige 660R-6xC Series User’s Guide
Figure 2 Prestige LAN-to-LAN Application

1.1.3 Prestige Hardware Installation and Connection

Refer to the Quick Start Guide for information on hardware installation and connection and LED descriptions.
35 Chapter 1 Getting To Know Your Prestige
Introducing the Web
This chapter describes how to access and navigate the web configurator.

2.1 Web Configurator Overview

The web configurator is an HTML-based management interface that allows easy Prestige setup and management via Internet browser. Use Internet Explorer 6.0 and later or Netscape Navigator 7.0 and later versions with JavaScript enabled. Recommended screen resolution is 1024 by 768 pixels.
Prestige 660R-6xC Series User’s Guide
CHAPTER 2
Configurator

2.1.1 Accessing the Prestige Web Configurator

1 Make sure your Prestige hardware is properly connected (refer to the Quick Start Guide).
2 Prepare your computer/computer network to connect to the Prestige (refer to the Quick
Start Guide).
3 Launch your web browser.
4 Type "192.168.1.1" as the URL.
5 An Enter Network Password window displays. Enter the user name (“admin” is the
default), password (“1234” is the default). Click Login to proceed to a screen asking you to change your password. Click Cancel to revert to the default password in the password field.
Figure 3 Password Screen
Chapter 2 Introducing the Web Configurator 36
Prestige 660R-6xC Series User’s Guide
6 It is highly recommended you change the default password! Enter a new password, retype
it to confirm and click Apply; alternatively click Ignore to proceed to the main menu if you do not want to change the password now.
Note: If you do not change the password, the following screen appears every time you log in.
Figure 4 Change Password at Login
7 You should now see the SITE MAP screen.
Note: The Prestige automatically times out after five minutes of inactivity.
Simply log back into the Prestige if this happens to you.

2.1.2 Resetting the Prestige

If you forget your password or cannot access the web configurator, you will need to use the RESET button at the back of the Prestige to reload the factory-default configuration file. This means that you will lose all configurations that you had previously and the password will be reset to “1234”.
2.1.2.1 Using the Reset Button
1 Make sure the PWR/SYS LED is on (not blinking).
2 Press the RESET button for ten seconds or until the PWR/SYS LED begins to blink and
then release it. When the PWR/SYS LED begins to blink, the defaults have been restored and the Prestige restarts.

2.1.3 Navigating the Prestige Web Configurator

The following summarizes how to navigate the web configurator from the SITE MAP screen.
37 Chapter 2 Introducing the Web Configurator
Prestige 660R-6xC Series User’s Guide
• Click Wizard Setup to begin a series of screens to configure your Prestige for the first time.
• Click a link under Advanced Setup to configure advanced Prestige features.
• Click a link under Maintenance to see Prestige performance statistics, upload firmware and back up, restore or upload a configuration file.
• Click Site Map to go to the Site Map screen.
• Click Logout in the navigation panel when you have finished a Prestige management session.
Figure 5 Web Configurator: Site Map Screen
Note: Click the icon (located in the top right corner of most screens) to
view embedded help.
Table 2 Web Configurator Screens Summary
LINK SUB-LINK FUNCTION
Wizard Setup Connection
Setup
Advanced Setup
Password Use this screen to change your password.
LAN Use this screen to configure LAN DHCP and TCP/IP settings.
WAN WAN Setup Use this screen to change the Prestige’s WAN remote node
WAN Backup Use this screen to configure your traffic redirect properties and
NAT SUA Only Use this screen to configure servers behind the Prestige.
Full Feature Use this screen to configure network address translation
Security Use this screen to configure Internet security and apply the
Dynamic DNS Use this screen to set up dynamic DNS.
Time and Date Use this screen to change your Prestige’s time and date.
Use these screens for initial configuration including general setup, ISP parameters for Internet Access and WAN IP/DNS Server/MAC address assignment.
settings.
WAN backup settings.
mapping rules.
predefined filter rules.
Chapter 2 Introducing the Web Configurator 38
Prestige 660R-6xC Series User’s Guide
Table 2 Web Configurator Screens Summary (continued)
LINK SUB-LINK FUNCTION
Remote Management
UPnP Use this screen to enable UPnP on the Prestige.
Maintenance
System Status This screen contains administrative and system-related
DHCP Table This screen displays DHCP (Dynamic Host Configuration
Diagnostic General These screens display information to help you identify problems
DSL Line These screens display information to help you identify problems
Firmware Use this screen to upload firmware to your Prestige
LOGOUT Click this label to exit the web configurator.
Use this screen to configure through which interface(s) and from which IP address(es) users can use Telnet/FTP/Web to manage the Prestige.
information.
Protocol) related information and is READ-ONLY.
with the Prestige general connection.
with the DSL line.
39 Chapter 2 Introducing the Web Configurator
This chapter provides information on the Wizard Setup screens for Internet access in the web configurator.

3.1 Introduction

Use the Wizard Setup screens to configure your system for Internet access with the information (provided by your ISP) that you fill in the Internet Account Information table in the Quick Start Guide. Your ISP may have already configured some of the fields in the wizard screens for you.

3.1.1 Encapsulation

Prestige 660R-6xC Series User’s Guide
CHAPTER 3

Wizard Setup

Be sure to use the encapsulation method required by your ISP. The Prestige supports the following methods.
3.1.1.1 ENET ENCAP
The MAC Encapsulated Routing Link Protocol (ENET ENCAP) is only implemented with the IP network protocol. IP packets are routed between the Ethernet interface and the WAN interface and then formatted so that they can be understood in a bridged environment. For instance, it encapsulates routed Ethernet frames into bridged ATM cells. ENET ENCAP requires that you specify a gateway IP address in the ENET ENCAP Gateway field in the second wizard screen. You can get this information from your ISP.
3.1.1.2 PPP over Ethernet
PPPoE provides access control and billing functionality in a manner similar to dial-up services using PPP. The Prestige bridges a PPP session over Ethernet (PPP over Ethernet, RFC 2516) from your computer to an ATM PVC (Permanent Virtual Circuit) which connects to ADSL Access Concentrator where the PPP session terminates. One PVC can support any number of PPP sessions from your LAN. For more information on PPPoE, see the appendices.
3.1.1.3 PPPoA
PPPoA stands for Point to Point Protocol over ATM Adaptation Layer 5 (AAL5). A PPPoA connection functions like a dial-up Internet connection. The Prestige encapsulates the PPP session based on RFC1483 and sends it through an ATM PVC (Permanent Virtual Circuit) to the Internet Service Provider’s (ISP) DSLAM (digital access multiplexer). Please refer to RFC 2364 for more information on PPPoA. Refer to RFC 1661 for more information on PPP.
Chapter 3 Wizard Setup 40
Prestige 660R-6xC Series User’s Guide
3.1.1.4 RFC 1483
RFC 1483 describes two methods for Multiprotocol Encapsulation over ATM Adaptation Layer 5 (AAL5). The first method allows multiplexing of multiple protocols over a single ATM virtual circuit (LLC-based multiplexing) and the second method assumes that each protocol is carried over a separate ATM virtual circuit (VC-based multiplexing). Please refer to the RFC for more detailed information.

3.1.2 Multiplexing

There are two conventions to identify what protocols the virtual circuit (VC) is carrying. Be sure to use the multiplexing method required by your ISP.
3.1.2.1 VC-based Multiplexing
In this case, by prior mutual agreement, each protocol is assigned to a specific virtual circuit; for example, VC1 carries IP, etc. VC-based multiplexing may be dominant in environments where dynamic creation of large numbers of ATM VCs is fast and economical.
3.1.2.2 LLC-based Multiplexing
In this case one VC carries multiple protocols with protocol identifying information being contained in each packet header. Despite the extra bandwidth and processing overhead, this method may be advantageous if it is not practical to have a separate VC for each carried protocol, for example, if charging heavily depends on the number of simultaneous VCs.

3.1.3 VPI and VCI

Be sure to use the correct Virtual Path Identifier (VPI) and Virtual Channel Identifier (VCI) numbers assigned to you. The valid range for the VPI is 0 to 255 and for the VCI is 32 to 65535 (0 to 31 is reserved for local management of ATM traffic). Please see the appendix for more information.

3.1.4 Internet Access Wizard Setup: First Screen

In the SITE MAP screen click Wizard Setup to display the first wizard screen.
41 Chapter 3 Wizard Setup
Figure 6 Internet Access Wizard Setup: First Screen
The following table describes the labels in this screen.
Table 3 Internet Access Wizard Setup: First Screen
Prestige 660R-6xC Series User’s Guide
LABEL DESCRIPTION
Mode From the Mode drop-down list box, select Routing (default) if your ISP allows
Encapsulation Select the encapsulation type your ISP uses from the Encapsulation drop-down list
Multiplex Select the multiplexing method used by your ISP from the Multiplex drop-down list
Virtual Circuit IDVPI (Virtual Path Identifier) and VCI (Virtual Channel Identifier) define a virtual circuit.
VPI Enter the VPI assigned to you. This field may already be configured.
VCI Enter the VCI assigned to you. This field may already be configured.
Next Click this button to go to the next wizard screen. The next wizard screen you see
multiple computers to share an Internet account. Otherwise select Bridge.
box. Choices vary depending on what you select in the Mode field. If you select Bridge in the Mode field, select either PPPoA or RFC 1483. If you select Routing in the Mode field, select PPPoA, RFC 1483, ENET ENCAP or
PPPoE.
box either VC-based or LLC-based.
Refer to the appendix for more information.
depends on what protocol you chose above. Click on the protocol link to see the next wizard screen for that protocol.

3.2 IP Address and Subnet Mask

Similar to the way houses on a street share a common street name, so too do computers on a LAN share one common network number.
Where you obtain your network number depends on your particular situation. If the ISP or your network administrator assigns you a block of registered IP addresses, follow their instructions in selecting the IP addresses and the subnet mask.
Chapter 3 Wizard Setup 42
Prestige 660R-6xC Series User’s Guide
If the ISP did not explicitly give you an IP network number, then most likely you have a single user account and the ISP will assign you a dynamic IP address when the connection is established. If this is the case, it is recommended that you select a network number from
192.168.0.0 to 192.168.255.0 and you must enable the Network Address Translation (NAT) feature of the Prestige. The Internet Assigned Number Authority (IANA) reserved this block of addresses specifically for private use; please do not use any other number unless you are told otherwise. Let's say you select 192.168.1.0 as the network number; which covers 254 individual addresses, from 192.168.1.1 to 192.168.1.254 (zero and 255 are reserved). In other words, the first three numbers specify the network number while the last number identifies an individual computer on that network.
Once you have decided on the network number, pick an IP address that is easy to remember, for instance, 192.168.1.1, for your Prestige, but make sure that no other device on your network is using that IP address.
The subnet mask specifies the network number portion of an IP address. Your Prestige will compute the subnet mask automatically based on the IP address that you entered. You don't need to change the subnet mask computed by the Prestige unless you are instructed to do otherwise.

3.2.1 IP Address Assignment

A static IP is a fixed IP that your ISP gives you. A dynamic IP is not fixed; the ISP assigns you a different one each time. The Single User Account feature can be enabled or disabled if you have either a dynamic or static IP. However the encapsulation method assigned influences your choices for IP address and ENET ENCAP gateway.
3.2.1.1 IP Assignment with PPPoA or PPPoE Encapsulation
If you have a dynamic IP, then the IP Address and ENET ENCAP Gateway fields are not applicable (N/A). If you have a static IP, then you only need to fill in the IP Address field and not the ENET ENCAP Gateway field.
3.2.1.2 IP Assignment with RFC 1483 Encapsulation
In this case the IP Address Assignment must be static with the same requirements for the IP Address and ENET ENCAP Gateway fields as stated above.
3.2.1.3 IP Assignment with ENET ENCAP Encapsulation
In this case you can have either a static or dynamic IP. For a static IP you must fill in all the IP Address and ENET ENCAP Gateway fields as supplied by your ISP. However for a dynamic IP, the Prestige acts as a DHCP client on the WAN port and so the IP Address and ENET ENCAP Gateway fields are not applicable (N/A) as the DHCP server assigns them to
the Prestige.
43 Chapter 3 Wizard Setup
3.2.1.4 Private IP Addresses
Every machine on the Internet must have a unique address. If your networks are isolated from the Internet, for example, only between your two branch offices, you can assign any IP addresses to the hosts without problems. However, the Internet Assigned Numbers Authority (IANA) has reserved the following three blocks of IP addresses specifically for private networks:
• 10.0.0.0 — 10.255.255.255
• 172.16.0.0 — 172.31.255.255
• 192.168.0.0 — 192.168.255.255
You can obtain your IP address from the IANA, from an ISP or it can be assigned from a private network. If you belong to a small organization and your Internet access is through an ISP, the ISP can provide you with the Internet addresses for your local networks. On the other hand, if you are part of a much larger organization, you should consult your network administrator for the appropriate IP addresses.
Note: Regardless of your particular situation, do not create an arbitrary IP address; always follow the guidelines above. For more information on address assignment, please refer to RFC 1597, Address Allocation for
Private Internets and RFC 1466, Guidelines for Management of IP Address Space.
Prestige 660R-6xC Series User’s Guide

3.2.2 Nailed-Up Connection (PPP)

A nailed-up connection is a dial-up line where the connection is always up regardless of traffic demand. The Prestige does two things when you specify a nailed-up connection. The first is that idle timeout is disabled. The second is that the Prestige will try to bring up the connection when turned on and whenever the connection is down. A nailed-up connection can be very expensive for obvious reasons.
Do not specify a nailed-up connection unless your telephone company offers flat-rate service or you need a constant connection and the cost is of no concern

3.2.3 NAT

NAT (Network Address Translation - NAT, RFC 1631) is the translation of the IP address of a host in a packet, for example, the source address of an outgoing packet, used within one network to a different IP address known within another network.

3.2.4 Internet Access Wizard Setup: Second Screen

The second wizard screen varies depending on what mode and encapsulation type you use. All screens shown are with routing mode. Configure the fields and click Next to continue.
Chapter 3 Wizard Setup 44
Prestige 660R-6xC Series User’s Guide
Figure 7 Internet Connection with PPPoE
The following table describes the labels in this screen.
Table 4 Internet Connection with PPPoE
LABEL DESCRIPTION
Service Name Type the name of your PPPoE service here.
User Name Enter the user name exactly as your ISP assigned. If assigned a name in the form
user@domain
exactly as given.
Password Enter the password associated with the user name above.
IP Address A static IP address is a fixed IP that your ISP gives you. A dynamic IP address is not
Connection Select Connect on Demand when you don't want the connection up all the time and
Network Address Translation
Back Click Back to go back to the first wizard screen.
Next Click Next to continue to the next wizard screen.
fixed; the ISP assigns you a different one each time you connect to the Internet. Select Obtain an IP Address Automatically if you have a dynamic IP address;
otherwise select Static IP Address and type your ISP assigned IP address in the text box below.
specify an idle time-out (in seconds) in the Max. Idle Timeout field. The default setting selects Connection on Demand with 0 as the idle time-out, which means the Internet session will not timeout.
Select Nailed-Up Connection when you want your connection up all the time. The Prestige will try to bring up the connection automatically if it is disconnected.
The schedule rule(s) in SMT menu 26 has priority over your Connection settings.
Select None, SUA Only or Full Feature from the drop-sown list box. Refer to the NAT chapter for more details.
where domain identifies a service name, then enter both components
45 Chapter 3 Wizard Setup
Prestige 660R-6xC Series User’s Guide
Figure 8 Internet Connection with RFC 1483
The following table describes the labels in this screen.
Table 5 Internet Connection with RFC 1483
LABEL DESCRIPTION
IP Address This field is available if you select Routing in the Mode field.
Type your ISP assigned IP address in this field.
Network Address Translation
Back Click Back to go back to the first wizard screen.
Next Click Next to continue to the next wizard screen.
Select None, SUA Only or Full Feature from the drop-down list box. Refer to
Chapter 7, on page 70 for more details.
Figure 9 Internet Connection with ENET ENCAP
Chapter 3 Wizard Setup 46
Prestige 660R-6xC Series User’s Guide
The following table describes the labels in this screen.
Table 6 Internet Connection with ENET ENCAP
LABEL DESCRIPTION
IP Address A static IP address is a fixed IP that your ISP gives you. A dynamic IP address is not
fixed; the ISP assigns you a different one each time you connect to the Internet. . Select Obtain an IP Address Automatically if you have a dynamic IP address;
otherwise select Static IP Address and type your ISP assigned IP address in the IP Address text box below.
Subnet Mask Enter a subnet mask in dotted decimal notation.
Refer to Appendix C IP Subnetting to calculate a subnet mask If you are implementing subnetting.
ENET ENCAP Gateway
Network Address Translation
Back Click Back to go back to the first wizard screen.
Next Click Next to continue to the next wizard screen.
You must specify a gateway IP address (supplied by your ISP) when you use ENET ENCAP in the Encapsulation field in the previous screen.
Select None, SUA Only or Full Feature from the drop-sown list box. Refer to the NAT chapter for more details.
Figure 10 Internet Connection with PPPoA
47 Chapter 3 Wizard Setup
Prestige 660R-6xC Series User’s Guide
The following table describes the labels in this screen.
Table 7 Internet Connection with PPPoA
LABEL DESCRIPTION
User Name Enter the login name that your ISP gives you.
Password Enter the password associated with the user name above.
IP Address This option is available if you select Routing in the Mode field.
A static IP address is a fixed IP that your ISP gives you. A dynamic IP address is not fixed; the ISP assigns you a different one each time you connect to the Internet.
Click Obtain an IP Address Automatically if you have a dynamic IP address; otherwise click Static IP Address and type your ISP assigned IP address in the IP Address text box below.
Connection Select Connect on Demand when you don't want the connection up all the time and
specify an idle time-out (in seconds) in the Max. Idle Timeout field. The default setting selects Connection on Demand with 0 as the idle time-out, which means the Internet session will not timeout.
Select Nailed-Up Connection when you want your connection up all the time. The Prestige will try to bring up the connection automatically if it is disconnected.
The schedule rule(s) in SMT menu 26 has priority over your Connection settings.
Network Address Translation
Back Click Back to go back to the first wizard screen.
Next Click Next to continue to the next wizard screen.
This option is available if you select Routing in the Mode field. Select None, SUA Only or Full Feature from the drop-sown list box. Refer to
Chapter 7, on page 70 for more details.

3.2.5 DHCP Setup

DHCP (Dynamic Host Configuration Protocol, RFC 2131 and RFC 2132) allows individual clients to obtain TCP/IP configuration at start-up from a server. You can configure the Prestige as a DHCP server or disable it. When configured as a server, the Prestige provides the TCP/IP configuration for the clients. If you turn DHCP service off, you must have another DHCP server on your LAN, or else the computer must be manually configured.
3.2.5.1 IP Pool Setup
The Prestige is pre-configured with a pool of 32 IP addresses starting from 192.168.1.33 to
192.168.1.64 for the client machines. This leaves 31 IP addresses, 192.168.1.2 to
192.168.1.32 (excluding the Prestige itself which has a default IP of 192.168.1.1) for other server machines, for example, server for mail, FTP, telnet, web, etc., that you may have.

3.2.6 Internet Access Wizard Setup: Third Screen

Verify the settings in the screen shown next. To change the LAN information on the Prestige, click Change LAN Configurations. Otherwise click Save Settings to save the configuration and skip to the section 3.13.
Chapter 3 Wizard Setup 48
Prestige 660R-6xC Series User’s Guide
Figure 11 Internet Access Wizard Setup: Third Screen
If you want to change your Prestige LAN settings, click Change LAN Configuration to display the screen as shown next.
49 Chapter 3 Wizard Setup
Prestige 660R-6xC Series User’s Guide
Figure 12 Internet Access Wizard Setup: LAN Configuration
The following table describes the labels in this screen.
Table 8 Internet Access Wizard Setup: LAN Configuration
LABEL DESCRIPTION
LAN IP Address Enter the IP address of your Prestige in dotted decimal notation, for example,
192.168.1.1 (factory default).
Note: If you changed the Prestige's LAN IP address, you must use the new IP address if you want to access the web configurator again.
LAN Subnet Mask Enter a subnet mask in dotted decimal notation.
DHCP
DHCP Server From the DHCP Server drop-down list box, select On to allow your Prestige to
assign IP addresses, an IP default gateway and DNS servers to computer systems that support the DHCP client. Select Off to disable DHCP server.
When DHCP server is used, set the following items:
Client IP Pool Starting Address
Size of Client IP Pool This field specifies the size or count of the IP address pool.
Primary DNS Server Enter the IP addresses of the DNS servers. The DNS servers are passed to
Secondary DNS Server As above.
Back Click Back to go back to the previous screen.
Finish Click Finish to save the settings and proceed to the next wizard screen.
This field specifies the first of the contiguous addresses in the IP address pool.
the DHCP clients along with the IP address and the subnet mask.
Chapter 3 Wizard Setup 50
Prestige 660R-6xC Series User’s Guide

3.2.7 Internet Access Wizard Setup: Connection Test

The Prestige automatically tests the connection to the computer(s) connected to the LAN ports. To test the connection from the Prestige to the ISP, click Start Diagnose. Otherwise click Return to Main Menu to go back to the Site Map screen.
Figure 13 Internet Access Wizard Setup: Connection Tests
3.2.7.1 Test Your Internet Connection
Launch your web browser and navigate to www.zyxel.com. Internet access is just the beginning. Refer to the rest of this User’s Guide for more detailed information on the complete range of Prestige features. If you cannot access the Internet, open the web configurator again to confirm that the Internet settings you configured in the Wizard Setup are correct.
51 Chapter 3 Wizard Setup
This chapter provides information on the Password screen.

4.1 Password Overview

It is highly recommended that you change the password for accessing the Prestige.

4.1.1 Configuring Password

To change your Prestige’s password (recommended), click Password in the Site Map screen. The screen appears as shown.
Prestige 660R-6xC Series User’s Guide
CHAPTER 4

Password Setup

Figure 14 Password
The following table describes the fields in this screen.
Table 9 Password
LABEL DESCRIPTION
Old Password Type the default password or the existing password you use to access the system
New Password Type the new password in this field.
Retype to Confirm Type the new password again in this field.
Apply Click Apply to save your changes back to the Prestige.
Cancel Click Cancel to begin configuring this screen afresh.
in this field.
Chapter 4 Password Setup 52
Prestige 660R-6xC Series User’s Guide
53 Chapter 4 Password Setup
This chapter describes how to configure LAN settings.

5.1 LAN Overview

A Local Area Network (LAN) is a shared communication system to which many computers are attached. A LAN is a computer network limited to the immediate area, usually the same building or floor of a building. The LAN screens can help you configure a LAN DHCP server and manage IP addresses.

5.1.1 LANs, WANs and the Prestige

Prestige 660R-6xC Series User’s Guide
CHAPTER 5

LAN Setup

The actual physical connection determines whether the Prestige ports are LAN or WAN ports. There are two separate IP networks, one inside the LAN network and the other outside the WAN network as shown next.
Figure 15 LAN and WAN IP Addresses
Chapter 5 LAN Setup 54
Prestige 660R-6xC Series User’s Guide

5.2 DNS Server Address

DNS (Domain Name System) is for mapping a domain name to its corresponding IP address and vice versa. The DNS server is extremely important because without it, you must know the IP address of a machine before you can access it. The DNS server addresses that you enter in the DHCP setup are passed to the client machines along with the assigned IP address and subnet mask.
There are two ways that an ISP disseminates the DNS server addresses. The first is for an ISP to tell a customer the DNS server addresses, usually in the form of an information sheet, when s/he signs up. If your ISP gives you the DNS server addresses, enter them in the DNS Server fields in the LAN Setup screen, otherwise, leave them blank.
Some ISP’s choose to pass the DNS servers using the DNS server extensions of PPP IPCP (IP Control Protocol) after the connection is up. If your ISP did not give you explicit DNS servers, chances are the DNS servers are conveyed through IPCP negotiation. The Prestige supports the IPCP DNS server extensions through the DNS proxy feature.
If the Primary and Secondary DNS Server fields in the LAN Setup screen are not specified, for instance, left as 0.0.0.0, the Prestige tells the DHCP clients that it itself is the DNS server. When a computer sends a DNS query to the Prestige, the Prestige forwards the query to the real DNS server learned through IPCP and relays the response back to the computer.
Please note that DNS proxy works only when the ISP uses the IPCP DNS server extensions. It does not mean you can leave the DNS servers out of the DHCP setup under all circumstances. If your ISP gives you explicit DNS servers, make sure that you enter their IP addresses in the LAN Setup screen. This way, the Prestige can pass the DNS servers to the computers and the computers can query the DNS server directly without the Prestige’s intervention.

5.3 DNS Server Address Assignment

Use DNS (Domain Name System) to map a domain name to its corresponding IP address and vice versa. The DNS server is extremely important because without it, you must know the IP address of a computer before you can access it.
There are two ways that an ISP disseminates the DNS server addresses.
• The ISP tells you the DNS server addresses, usually in the form of an information sheet, when you sign up. If your ISP gives you DNS server addresses, enter them in the DNS Server fields in the LAN Setup screen.
• The Prestige acts as a DNS proxy when the Primary and Secondary DNS Server fields are left blank in the LAN Setup screen.
55 Chapter 5 LAN Setup

5.4 LAN TCP/IP

The Prestige has built-in DHCP server capability that assigns IP addresses and DNS servers to systems that support DHCP client capability.

5.4.1 Factory LAN Defaults

The LAN parameters of the Prestige are preset in the factory with the following values:
• IP address of 192.168.1.1 with subnet mask of 255.255.255.0 (24 bits)
• DHCP server enabled with 32 client IP addresses starting from 192.168.1.33.
These parameters should work for the majority of installations. If your ISP gives you explicit DNS server address(es), read the embedded web configurator help regarding what fields need to be configured.

5.4.2 IP Address and Subnet Mask

Prestige 660R-6xC Series User’s Guide
Refer to the IP Address and Subnet Mask section in Chapter 3 Wizard Setupfor this information.

5.4.3 RIP Setup

RIP (Routing Information Protocol) allows a router to exchange routing information with other routers. The RIP Direction field controls the sending and receiving of RIP packets. When set to:
• Both - the Prestige will broadcast its routing table periodically and incorporate the RIP information that it receives.
• In Only - the Prestige will not send any RIP packets but will accept all RIP packets received.
• Out Only - the Prestige will send out RIP packets but will not accept any RIP packets received.
• None - the Prestige will not send any RIP packets and will ignore any RIP packets received.
The Version field controls the format and the broadcasting method of the RIP packets that the Prestige sends (it recognizes both formats when receiving). RIP-1 is universally supported; but RIP-2 carries more information. RIP-1 is probably adequate for most networks, unless you have an unusual network topology.
Both RIP-2B and RIP-2M sends the routing data in RIP-2 format; the difference being that RIP-2B uses subnet broadcasting while RIP-2M uses multicasting.
Chapter 5 LAN Setup 56
Prestige 660R-6xC Series User’s Guide

5.4.4 Multicast

Traditionally, IP packets are transmitted in one of either two ways - Unicast (1 sender - 1 recipient) or Broadcast (1 sender - everybody on the network). Multicast delivers IP packets to a group of hosts on the network - not everybody and not just 1.
IGMP (Internet Group Multicast Protocol) is a network-layer protocol used to establish membership in a Multicast group - it is not used to carry user data. IGMP version 2 (RFC
2236) is an improvement over version 1 (RFC 1112) but IGMP version 1 is still in wide use. If you would like to read more detailed information about interoperability between IGMP version 2 and version 1, please see sections 4 and 5 of RFC 2236. The class D IP address is used to identify host groups and can be in the range 224.0.0.0 to 239.255.255.255. The address
224.0.0.0 is not assigned to any group and is used by IP multicast computers. The address
224.0.0.1 is used for query messages and is assigned to the permanent group of all IP hosts (including gateways). All hosts must join the 224.0.0.1 group in order to participate in IGMP. The address 224.0.0.2 is assigned to the multicast routers group.
The Prestige supports both IGMP version 1 (IGMP-v1) and IGMP version 2 (IGMP-v2). At start up, the Prestige queries all directly connected networks to gather group membership. After that, the Prestige periodically updates this information. IP multicasting can be enabled/ disabled on the Prestige LAN and/or WAN interfaces in the web configurator (LAN; WA N ). Select None to disable IP multicasting on these interfaces.

5.5 Configuring LAN

Click LAN and LAN Setup to open the following screen.
57 Chapter 5 LAN Setup
Figure 16 LAN Setup
Prestige 660R-6xC Series User’s Guide
The following table describes the labels in this screen.
Table 10 LAN Setup
LABEL DESCRIPTION
DHCP
DHCP If set to Server, your Prestige can assign IP addresses, an IP default gateway
and DNS servers to Windows 95, Windows NT and other systems that support the DHCP client.
If set to None, the DHCP server will be disabled. If set to Relay, the Prestige acts as a surrogate DHCP server and relays DHCP
requests and responses between the remote server and the clients. Enter the IP address of the actual, remote DHCP server in the Remote DHCP Server field in this case.
When DHCP is used, the following items need to be set:
Client IP Pool Starting Address
Size of Client IP Pool
Primary DNS Server Enter the IP addresses of the DNS servers. The DNS servers are passed to the
Secondary DNS Server
Remote DHCP Server
TCP/IP
This field specifies the first of the contiguous addresses in the IP address pool.
This field specifies the size or count of the IP address pool.
DHCP clients along with the IP address and the subnet mask.
As above.
If Relay is selected in the DHCP field above then enter the IP address of the actual remote DHCP server here.
Chapter 5 LAN Setup 58
Prestige 660R-6xC Series User’s Guide
Table 10 LAN Setup (continued)
LABEL DESCRIPTION
IP Address Enter the IP address of your Prestige in dotted decimal notation, for example,
192.168.1.1 (factory default).
IP Subnet Mask Type the subnet mask assigned to you by your ISP (if given).
RIP Direction Select the RIP direction from None, Both, In Only and Out Only.
RIP Version Select the RIP version from RIP-1, RIP-2B and RIP-2M.
Multicast IGMP (Internet Group Multicast Protocol) is a network-layer protocol used to
Apply Click Apply to save your changes back to the Prestige.
Cancel Click Cancel to begin configuring this screen afresh.
establish membership in a multicast group. The Prestige supports both IGMP version 1 (IGMP-v1) and IGMP-v2. Select None to disable it.
59 Chapter 5 LAN Setup
This chapter describes how to configure WAN settings.

6.1 WAN Overview

A WAN (Wide Area Network) is an outside connection to another network or the Internet.
See Chapter 3 Wizard Setupfor more information on the fields in the WAN screens.

6.2 Metric

Prestige 660R-6xC Series User’s Guide
CHAPTER 6

WAN Setup

The metric represents the "cost of transmission". A router determines the best route for transmission by choosing a path with the lowest "cost". RIP routing uses hop count as the measurement of cost, with a minimum of "1" for directly connected networks. The number must be between "1" and "15"; a number greater than "15" means the link is down. The smaller the number, the lower the "cost".
The metric sets the priority for the Prestige’s routes to the Internet. If any two of the default routes have the same metric, the Prestige uses the following pre-defined priorities:
• Normal route: designated by the ISP (see the Configuring WAN Setup section)
• Traffic-redirect route (see the Traffic Redirect section)
• WAN-backup route, also called dial-backup (see the Configuring WAN Backup section)
For example, if the normal route has a metric of "1" and the traffic-redirect route has a metric of "2" and dial-backup route has a metric of "3", then the normal route acts as the primary default route. If the normal route fails to connect to the Internet, the Prestige tries the traffic­redirect route next. In the same manner, the Prestige uses the dial-backup route if the traffic­redirect route also fails.
If you want the dial-backup route to take first priority over the traffic-redirect route or even the normal route, all you need to do is set the dial-backup route’s metric to "1" and the others to "2" (or greater).
Note: IP Policy Routing overrides the default routing behavior and takes priority over all of the routes mentioned above (see
Chapter 28 IP Policy Routing).
Chapter 6 WAN Setup 60
Prestige 660R-6xC Series User’s Guide

6.3 PPPoE Encapsulation

The Prestige supports PPPoE (Point-to-Point Protocol over Ethernet). PPPoE is an IETF Draft standard (RFC 2516) specifying how a personal computer (PC) interacts with a broadband modem (DSL, cable, wireless, etc.) connection. The PPPoE option is for a dial-up connection using PPPoE.
For the service provider, PPPoE offers an access and authentication method that works with existing access control systems (for example Radius). PPPoE provides a login and authentication method that the existing Microsoft Dial-Up Networking software can activate, and therefore requires no new learning or procedures for Windows users.
One of the benefits of PPPoE is the ability to let you access one of multiple network services, a function known as dynamic service selection. This enables the service provider to easily create and offer new IP services for individuals.
Operationally, PPPoE saves significant effort for both you and the ISP or carrier, as it requires no specific configuration of the broadband modem at the customer site.
By implementing PPPoE directly on the Prestige (rather than individual computers), the computers on the LAN do not need PPPoE software installed, since the Prestige does that part of the task. Furthermore, with NAT, all of the LANs’ computers will have access.

6.4 Traffic Shaping

Traffic Shaping is an agreement between the carrier and the subscriber to regulate the average rate and fluctuations of data transmission over an ATM network. This agreement helps eliminate congestion, which is important for transmission of real time data such as audio and video connections.
Peak Cell Rate (PCR) is the maximum rate at which the sender can send cells. This parameter may be lower (but not higher) than the maximum line speed. 1 ATM cell is 53 bytes (424 bits), so a maximum speed of 832Kbps gives a maximum PCR of 1962 cells/sec. This rate is not guaranteed because it is dependent on the line speed.
Sustained Cell Rate (SCR) is the mean cell rate of each bursty traffic source. It specifies the maximum average rate at which cells can be sent over the virtual connection. SCR may not be greater than the PCR.
Maximum Burst Size (MBS) is the maximum number of cells that can be sent at the PCR. After MBS is reached, cell rates fall below SCR until cell rate averages to the SCR again. At this time, more cells (up to the MBS) can be sent at the PCR again.
If the PCR, SCR or MBS is set to the default of "0", the system will assign a maximum value that correlates to your upstream line rate.
The following figure illustrates the relationship between PCR, SCR and MBS.
61 Chapter 6 WAN Setup
Figure 17 Example of Traffic Shaping

6.5 Configuring WAN Setup

To change your Prestige’s WAN remote node settings, click WA N and WAN Setup. The screen
differs by the encapsulation.
Prestige 660R-6xC Series User’s Guide
Chapter 6 WAN Setup 62
Prestige 660R-6xC Series User’s Guide
Figure 18 WAN Setup (PPPoE)
The following table describes the labels in this screen.
Table 11 WAN Setup
LABEL DESCRIPTION
Name Enter the name of your Internet Service Provider, e.g., MyISP. This information is
for identification purposes only.
Mode Select Routing (default) from the drop-down list box if your ISP allows multiple
computers to share an Internet account. Otherwise select Bridge.
63 Chapter 6 WAN Setup
Prestige 660R-6xC Series User’s Guide
Table 11 WAN Setup (continued)
LABEL DESCRIPTION
Encapsulation Select the method of encapsulation used by your ISP from the drop-down list
box. Choices vary depending on the mode you select in the Mode field. If you select Bridge in the Mode field, select either PPPoA or RFC 1483. If you select Routing in the Mode field, select PPPoA, RFC 1483, ENET
ENCAP or PPPoE.
Multiplex Select the method of multiplexing used by your ISP from the drop-down list.
Virtual Circuit ID VPI (Virtual Path Identifier) and VCI (Virtual Channel Identifier) define a virtual
VPI The valid range for the VPI is 0 to 255. Enter the VPI assigned to you.
VCI The valid range for the VCI is 32 to 65535 (0 to 31 is reserved for local
ATM QoS Type Select CBR (Continuous Bit Rate) to specify fixed (always-on) bandwidth for
Cell Rate Cell rate configuration often helps eliminate traffic congestion that slows
Peak Cell Rate Divide the DSL line rate (bps) by 424 (the size of an ATM cell) to find the Peak
Sustain Cell Rate The Sustain Cell Rate (SCR) sets the average cell rate (long-term) that can be
Maximum Burst Size Maximum Burst Size (MBS) refers to the maximum number of cells that can be
Choices are VC or LLC.
circuit. Refer to the appendix for more information.
management of ATM traffic). Enter the VCI assigned to you.
voice or data traffic. Select UBR (Unspecified Bit Rate) for applications that are non-time sensitive, such as e-mail. Select VBR (Variable Bit Rate) for bursty traffic and bandwidth sharing with other applications.
transmission of real time data such as audio and video connections.
Cell Rate (PCR). This is the maximum rate at which the sender can send cells. Type the PCR here.
transmitted. Type the SCR, which must be less than the PCR. Note that system default is 0 cells/sec.
sent at the peak rate. Type the MBS, which is less than 65535.
Login Information (PPPoA and PPPoE encapsulation only)
Service Name (PPPoE only) Type the name of your PPPoE service here.
User Name Enter the user name exactly as your ISP assigned. If assigned a name in the
form user@domain where domain identifies a service name, then enter both components exactly as given.
Password Enter the password associated with the user name above.
IP Address This option is available if you select Routing in the Mode field.
A static IP address is a fixed IP that your ISP gives you. A dynamic IP address is not fixed; the ISP assigns you a different one each time you connect to the Internet.
Select Obtain an IP Address Automatically if you have a dynamic IP address; otherwise select Static IP Address and type your ISP assigned IP address in the IP Address field below.
Connection (PPPoA and PPPoE
encapsulation only)
Nailed-Up Connection
Connect on Demand Select Connect on Demand when you don't want the connection up all the time
The schedule rule(s) in SMT menu 26 have priority over your Connection settings.
Select Nailed-Up Connection when you want your connection up all the time. The Prestige will try to bring up the connection automatically if it is disconnected.
and specify an idle time-out in the Max Idle Timeout field.
Chapter 6 WAN Setup 64
Prestige 660R-6xC Series User’s Guide
Table 11 WAN Setup (continued)
LABEL DESCRIPTION
Max Idle Timeout Specify an idle time-out in the Max Idle Timeout field when you select Connect
on Demand. The default setting is 0, which means the Internet session will not
timeout.
PPPoE Passthrough This field is available when you select PPPoE encapsulation.
PPPoE + PPPoE_Client_PC (PPPoE encapsulation only)
Subnet Mask (ENET ENCAP
encapsulation only)
ENET ENCAP Gateway
(ENET ENCAP encapsulation only)
Back Click Back to return to the previous screen.
Apply Click Apply to save the changes.
Cancel Click Cancel to begin configuring this screen afresh.
In addition to the Prestige's built-in PPPoE client, you can enable PPPoE pass through to allow up to ten hosts on the LAN to use PPPoE client software on their computers to connect to the ISP via the Prestige. Each host can have a separate account and a public WAN IP address.
PPPoE pass through is an alternative to NAT for application where NAT is not appropriate.
Disable PPPoE pass through if you do not need to allow hosts on the LAN to use PPPoE client software on their computers to connect to the ISP.
Enter a subnet mask in dotted decimal notation. Refer to Appendix C IP Subnetting in the to calculate a subnet mask If you are
implementing subnetting.
You must specify a gateway IP address (supplied by your ISP) when you select
ENET ENCAP in the Encapsulation field

6.6 Traffic Redirect

Traffic redirect forwards traffic to a backup gateway when the Prestige cannot connect to the Internet. An example is shown in the figure below.
65 Chapter 6 WAN Setup
Prestige 660R-6xC Series User’s Guide
Figure 19 Traffic Redirect Example
The following network topology allows you to avoid triangle route security issues when the backup gateway is connected to the LAN. Use IP alias to configure the LAN into two or three logical networks with the Prestige itself as the gateway for each LAN network. Put the protected LAN in one subnet (Subnet 1 in the following figure) and the backup gateway in another subnet (Subnet 2). Configure filters that allow packets from the protected LAN (Subnet 1) to the backup gateway (Subnet 2).
Figure 20 Traffic Redirect LAN Setup

6.7 Configuring WAN Backup

To change your Prestige’s WAN backup settings, click WA N, then WAN Backup. The screen appears as shown.
Chapter 6 WAN Setup 66
Prestige 660R-6xC Series User’s Guide
Figure 21 WAN Backup
The following table describes the labels in this screen.
Table 12 WAN Backup
LABEL DESCRIPTION
Backup Type Select the method that the Prestige uses to check the DSL connection.
Select DSL Link to have the Prestige check if the connection to the DSLAM is up. Select ICMP to have the Prestige periodically ping the IP addresses configured in the Check WAN IP Address fields.
Check WAN IP Address1-3
Configure this field to test your Prestige's WAN accessibility. Type the IP address of a reliable nearby computer (for example, your ISP's DNS server address).
Note: If you activate either traffic redirect or dial backup, you must configure at least one IP address here.
When using a WAN backup connection, the Prestige periodically pings the addresses configured here and uses the other WAN backup connection (if configured) if there is no response.
Fail Tolerance Type the number of times (2 recommended) that your Prestige may ping the IP
addresses configured in the Check WAN IP Address field without getting a response before switching to a WAN backup connection (or a different WAN backup connection).
Recovery Interval When the Prestige is using a lower priority connection (usually a WAN backup
Timeout Type the number of seconds (3 recommended) for your Prestige to wait for a ping
connection), it periodically checks to whether or not it can use a higher priority connection.
Type the number of seconds (30 recommended) for the Prestige to wait between checks. Allow more time if your destination IP address handles lots of traffic.
response from one of the IP addresses in the Check WAN IP Address field before timing out the request. The WAN connection is considered "down" after the Prestige times out the number of times specified in the Fail Tolerance field. Use a higher value in this field if your network is busy or congested.
67 Chapter 6 WAN Setup
Prestige 660R-6xC Series User’s Guide
Table 12 WAN Backup (continued)
LABEL DESCRIPTION
Traffic Redirect
Active Select this check box to have the Prestige use traffic redirect if the normal WAN
connection goes down.
Note: If you activate traffic redirect, you must configure at least one Check WAN IP Address.
Metric This field sets this route's priority among the routes the Prestige uses.
The metric represents the "cost of transmission". A router determines the best route for transmission by choosing a path with the lowest "cost". RIP routing uses hop count as the measurement of cost, with a minimum of "1" for directly connected networks. The number must be between "1" and "15"; a number greater than "15" means the link is down. The smaller the number, the lower the "cost".
Backup Gateway Type the IP address of your backup gateway in dotted decimal notation. The
Prestige automatically forwards traffic to this IP address if the Prestige's Internet connection terminates.
Back Click Back to return to the previous screen.
Apply Click Apply to save the changes.
Cancel Click Cancel to begin configuring this screen afresh.
Chapter 6 WAN Setup 68
Prestige 660R-6xC Series User’s Guide
69 Chapter 6 WAN Setup
Network Address Translation
This chapter discusses how to configure NAT on the Prestige.

7.1 NAT Overview

NAT (Network Address Translation - NAT, RFC 1631) is the translation of the IP address of a host in a packet, for example, the source address of an outgoing packet, used within one network to a different IP address known within another network.
Prestige 660R-6xC Series User’s Guide
CHAPTER 7
(NAT) Screens

7.1.1 NAT Definitions

Inside/outside denotes where a host is located relative to the Prestige, for example, the computers of your subscribers are the inside hosts, while the web servers on the Internet are the outside hosts.
Global/local denotes the IP address of a host in a packet as the packet traverses a router, for example, the local address refers to the IP address of a host when the packet is in the local network, while the global address refers to the IP address of the host when the same packet is traveling in the WAN side.
Note that inside/outside refers to the location of a host, while global/local refers to the IP address of a host used in a packet. Thus, an inside local address (ILA) is the IP address of an inside host in a packet when the packet is still in the local network, while an inside global address (IGA) is the IP address of the same inside host when the packet is on the WAN side. The following table summarizes this information.
Table 13 NAT Definitions
ITEM DESCRIPTION
Inside This refers to the host on the LAN.
Outside This refers to the host on the WAN.
Local This refers to the packet address (source or destination) as the packet travels on the
LAN.
Global This refers to the packet address (source or destination) as the packet travels on the
WAN.
Chapter 7 Network Address Translation (NAT) Screens 70
Prestige 660R-6xC Series User’s Guide
Note: NAT never changes the IP address (either local or global) of an outside host.

7.1.2 What NAT Does

In the simplest form, NAT changes the source IP address in a packet received from a subscriber (the inside local address) to another (the inside global address) before forwarding the packet to the WAN side. When the response comes back, NAT translates the destination address (the inside global address) back to the inside local address before forwarding it to the original inside host. Note that the IP address (either local or global) of an outside host is never changed.
The global IP addresses for the inside hosts can be either static or dynamically assigned by the ISP. In addition, you can designate servers, for example, a web server and a telnet server, on your local network and make them accessible to the outside world. If you do not define any servers (for Many-to-One and Many-to-Many Overload mapping – see Table 14), NAT offers the additional benefit of firewall protection. With no servers defined, your Prestige filters out all incoming inquiries, thus preventing intruders from probing your network. For more information on IP address translation, refer to RFC 1631, The IP Network Address Translator (NAT).

7.1.3 How NAT Works

Each packet has two addresses – a source address and a destination address. For outgoing packets, the ILA (Inside Local Address) is the source address on the LAN, and the IGA (Inside Global Address) is the source address on the WAN. For incoming packets, the ILA is the destination address on the LAN, and the IGA is the destination address on the WAN. NAT maps private (local) IP addresses to globally unique ones required for communication with hosts on other networks. It replaces the original IP source address (and TCP or UDP source port numbers for Many-to-One and Many-to-Many Overload NAT mapping) in each packet and then forwards it to the Internet. The Prestige keeps track of the original addresses and port numbers so incoming reply packets can have their original values restored. The following figure illustrates this.
71 Chapter 7 Network Address Translation (NAT) Screens
Figure 22 How NAT Works

7.1.4 NAT Application

The following figure illustrates a possible NAT application, where three inside LANs (logical LANs using IP Alias) behind the Prestige can communicate with three distinct WAN networks. More examples follow at the end of this chapter.
Prestige 660R-6xC Series User’s Guide
Figure 23 NAT Application With IP Alias

7.1.5 NAT Mapping Types

NAT supports five types of IP/port mapping. They are:
Chapter 7 Network Address Translation (NAT) Screens 72
Prestige 660R-6xC Series User’s Guide
• One to One: In One-to-One mode, the Prestige maps one local IP address to one global IP address.
• Many to One: In Many-to-One mode, the Prestige maps multiple local IP addresses to one global IP address. This is equivalent to SUA (for instance, PAT, port address translation), ZyXEL’s Single User Account feature that previous ZyXEL routers supported (the SUA Only option in today’s routers).
• Many to Many Overload: In Many-to-Many Overload mode, the Prestige maps the multiple local IP addresses to shared global IP addresses.
• Many-to-Many No Overload: In Many-to-Many No Overload mode, the Prestige maps each local IP address to a unique global IP address.
• Server: This type allows you to specify inside servers of different services behind the NAT to be accessible to the outside world.
Note: Port numbers do not change for One-to-One and Many­to-Many No Overload NAT mapping types.
The following table summarizes these types.
Table 14 NAT Mapping Types
TYPE IP MAPPING SMT ABBREVIATION
One-to-One ILA1ÅÆ IGA1 1:1
Many-to-One (SUA/PAT) ILA1ÅÆ IGA1
ILA2ÅÆ IGA1 …
Many-to-Many Overload ILA1ÅÆ IGA1
ILA2ÅÆ IGA2 ILA3ÅÆ IGA1 ILA4ÅÆ IGA2 …
Many-to-Many No Overload ILA1ÅÆ IGA1
ILA2ÅÆ IGA2 ILA3ÅÆ IGA3 …
Server Server 1 IPÅÆ IGA1
Server 2 IPÅÆ IGA1 Server 3 IPÅÆ IGA1
M:1
M:M Ov
M:M No OV
Server

7.2 SUA (Single User Account) Versus NAT

SUA (Single User Account) is a ZyNOS implementation of a subset of NAT that supports two types of mapping, Many-to-One and Server. The Prestige also supports Full Feature NAT to map multiple global IP addresses to multiple private LAN IP addresses of clients or servers using mapping types as outlined in Tab le 14 .
73 Chapter 7 Network Address Translation (NAT) Screens
Note: 1. Choose SUA Only if you have just one public WAN IP address for your Prestige.
2. Choose Full Feature if you have multiple public WAN IP addresses for your Prestige.

7.3 SUA Server

A SUA server set is a list of inside (behind NAT on the LAN) servers, for example, web or FTP, that you can make visible to the outside world even though SUA makes your whole inside network appear as a single computer to the outside world.
You may enter a single port number or a range of port numbers to be forwarded, and the local IP address of the desired server. The port number identifies a service; for example, web service is on port 80 and FTP on port 21. In some cases, such as for unknown services or where one server can support more than one service (for example both FTP and web service), it might be better to specify a range of port numbers. You can allocate a server IP address that corresponds to a port or a range of ports.
Prestige 660R-6xC Series User’s Guide
Many residential broadband ISP accounts do not allow you to run any server processes (such as a Web or FTP server) from your location. Your ISP may periodically check for servers and may suspend your account if it discovers any active services at your location. If you are unsure, refer to your ISP.

7.3.1 Default Server IP Address

In addition to the servers for specified services, NAT supports a default server IP address. A default server receives packets from ports that are not specified in this screen.
Note: If you do not assign an IP address in Server Set 1 (default server) the Prestige discards all packets received for ports that are not specified here or in the remote management setup.

7.3.2 Port Forwarding: Services and Port Numbers

The most often used port numbers are shown in the following table. Please refer to RFC 1700 for further information about port numbers.
Table 15 Services and Port Numbers
SERVICES PORT NUMBER
ECHO 7
FTP (File Transfer Protocol) 21
Chapter 7 Network Address Translation (NAT) Screens 74
Prestige 660R-6xC Series User’s Guide
Table 15 Services and Port Numbers (continued)
SERVICES PORT NUMBER
SMTP (Simple Mail Transfer Protocol) 25
DNS (Domain Name System) 53
Finger 79
HTTP (Hyper Text Transfer protocol or WWW, Web) 80
POP3 (Post Office Protocol) 110
NNTP (Network News Transport Protocol) 119
SNMP (Simple Network Management Protocol) 161
SNMP trap 162
PPTP (Point-to-Point Tunneling Protocol) 1723

7.3.3 Configuring Servers Behind SUA (Example)

Let's say you want to assign ports 21-25 to one FTP, Telnet and SMTP server (A in the example), port 80 to another (B in the example) and assign a default server IP address of
192.168.1.35 to a third (C in the example). You assign the LAN IP addresses and the ISP assigns the WAN IP address. The NAT network appears as a single host on the Internet.
IP address assigned by ISP.
Figure 24 Multiple Servers Behind NAT Example

7.4 Selecting the NAT Mode

Click NAT to open the following screen.
75 Chapter 7 Network Address Translation (NAT) Screens
Prestige 660R-6xC Series User’s Guide
Figure 25 NAT Mode
The following table describes the labels in this screen.
Table 16 NAT Mode
LABEL DESCRIPTION
None Select this radio button to disable NAT.
SUA Only Select this radio button if you have just one public WAN IP address for your Prestige.
The Prestige uses Address Mapping Set 1 in the NAT - Edit SUA/NAT Server Set screen.
Edit Details Click this link to go to the NAT - Edit SUA/NAT Server Set screen.
Full Feature Select this radio button if you have multiple public WAN IP addresses for your Prestige.
Edit Details Click this link to go to the NAT - Address Mapping Rules screen.
Apply Click Apply to save your configuration.

7.5 Configuring SUA Server

Note: If you do not assign an IP address in Server Set 1
(default server), the Prestige discards all packets received for ports that are not specified here or in the remote management setup.
Click NAT, select SUA Only and click Edit Details to open the following screen.
Refer to Table 15 for port numbers commonly used for particular services.
Chapter 7 Network Address Translation (NAT) Screens 76
Prestige 660R-6xC Series User’s Guide
Figure 26 Edit SUA/NAT Server Set
The following table describes the labels in this screen.
Table 17 Edit SUA/NAT Server Set
LABEL DESCRIPTION
Start Port No. Enter a port number in this field.
To forward only one port, enter the port number again in the End Port No. field. To forward a series of ports, enter the start port number here and the end port
number in the End Port No. field.
End Port No. Enter a port number in this field.
To forward only one port, enter the port number again in the Start Port No. field above and then enter it again in this field.
To forward a series of ports, enter the last port number in a series that begins with the port number in the Start Port No. field above.
IP Address Enter your server IP address in this field.
Save Click Save to save your changes back to the Prestige.
Cancel Click Cancel to return to the previous configuration.
77 Chapter 7 Network Address Translation (NAT) Screens

7.6 Configuring Address Mapping

Ordering your rules is important because the Prestige applies the rules in the order that you specify. When a rule matches the current packet, the Prestige takes the corresponding action and the remaining rules are ignored. If there are any empty rules before your new configured rule, your configured rule will be pushed up by that number of empty rules. For example, if you have already configured rules 1 to 6 in your current set and now you configure rule number 9. In the set summary screen, the new rule will be rule 7, not 9. Now if you delete rule 4, rules 5 to 7 will be pushed up by 1 rule, so old rules 5, 6 and 7 become new rules 4, 5 and 6.
To change your Prestige’s address mapping settings, click NAT, Select Full Feature and click Edit Details to open the following screen.
Figure 27 Address Mapping Rules
Prestige 660R-6xC Series User’s Guide
The following table describes the labels in this screen.
Table 18 Address Mapping Rules
LABEL DESCRIPTION
Local Start IP This is the starting Inside Local IP Address (ILA). Local IP addresses are N/A for
Server port mapping.
Local End IP This is the end Inside Local IP Address (ILA). If the rule is for all local IP addresses,
Global Start IP This is the starting Inside Global IP Address (IGA). Enter 0.0.0.0 here if you have a
Global End IP This is the ending Inside Global IP Address (IGA). This field is N/A for One-to-one,
Chapter 7 Network Address Translation (NAT) Screens 78
then this field displays 0.0.0.0 as the Local Start IP address and 255.255.255.255 as the Local End IP address. This field is N/A for One-to-one and Server mapping types.
dynamic IP address from your ISP. You can only do this for Many-to-One and
Server mapping types.
Many-to-One and Server mapping types.
Prestige 660R-6xC Series User’s Guide
Table 18 Address Mapping Rules (continued)
LABEL DESCRIPTION
Type 1-1: One-to-one mode maps one local IP address to one global IP address. Note that
port numbers do not change for the One-to-one NAT mapping type. M-1: Many-to-One mode maps multiple local IP addresses to one global IP address.
This is equivalent to SUA (i.e., PAT, port address translation), ZyXEL's Single User Account feature that previous ZyXEL routers supported only.
M-M Ov (Overload): Many-to-Many Overload mode maps multiple local IP addresses to shared global IP addresses.
MM No (No Overload): Many-to-Many No Overload mode maps each local IP address to unique global IP addresses.
Server: This type allows you to specify inside servers of different services behind the NAT to be accessible to the outside world.
Back Click Back to return to the NAT Mode screen.

7.7 Editing an Address Mapping Rule

To edit an address mapping rule, click the rule’s link in the NAT Address Mapping Rules screen to display the screen shown next.
Figure 28 Address Mapping Rule Edit
The following table describes the labels in this screen.
79 Chapter 7 Network Address Translation (NAT) Screens
Prestige 660R-6xC Series User’s Guide
Table 19 Address Mapping Rule Edit
LABEL DESCRIPTION
Type Choose the port mapping type from one of the following.
• One-to-One: One-to-One mode maps one local IP address to one global IP address. Note that port numbers do not change for One-to-one NAT mapping type.
• Many-to-One: Many-to-One mode maps multiple local IP addresses to one global IP address. This is equivalent to SUA (i.e., PAT, port address translation), ZyXEL's Single User Account feature that previous ZyXEL routers supported only.
• Many-to-Many Overload: Many-to-Many Overload mode maps multiple local IP addresses to shared global IP addresses.
• Many-to-Many No Overload: Many-to-Many No Overload mode maps each local IP address to unique global IP addresses.
• Server: This type allows you to specify inside servers of different services behind the NAT to be accessible to the outside world.
Local Start IP This is the starting local IP address (ILA). Local IP addresses are N/A for Server port
mapping.
Local End IP This is the end local IP address (ILA). If your rule is for all local IP addresses, then
enter 0.0.0.0 as the Local Start IP address and 255.255.255.255 as the Local End IP address.
This field is N/A for One-to-One and Server mapping types.
Global Start IP This is the starting global IP address (IGA). Enter 0.0.0.0 here if you have a dynamic
IP address from your ISP.
Global End IP This is the ending global IP address (IGA). This field is N/A for One-to-One, Many-
to-One and Server mapping types.
Server Mapping Set
Edit Details Click this link to go to the NAT - Edit SUA/NAT Server Set screen to edit a server set
Apply Click Apply to save your changes back to the Prestige.
Cancel Click Cancel to return to the previously saved settings.
Delete Click Delete to exit this screen without saving.
Only available when Type is set to Server. Select a number from the drop-down menu to choose a server set from the NAT -
Address Mapping Rules screen.
that you have selected in the Server Mapping Set field.
Chapter 7 Network Address Translation (NAT) Screens 80
Prestige 660R-6xC Series User’s Guide
81 Chapter 7 Network Address Translation (NAT) Screens
This chapter discusses how to configure your Prestige to use Dynamic DNS.

8.1 Dynamic DNS

Dynamic DNS allows you to update your current dynamic IP address with one or many dynamic DNS services so that anyone can contact you (in NetMeeting, CU-SeeMe, etc.). You can also access your FTP server or Web site on your own computer using a domain name (for instance myhost.dhs.org, where myhost is a name of your choice) that will never change instead of using an IP address that changes each time you reconnect. Your friends or relatives will always be able to call you even if they don't know your IP address.
Prestige 660R-6xC Series User’s Guide
CHAPTER 8

Dynamic DNS Setup

First of all, you need to have registered a dynamic DNS account with www.dyndns.org. This is for people with a dynamic IP from their ISP or DHCP server that would still like to have a domain name. The Dynamic DNS service provider will give you a password or key.

8.1.1 DYNDNS Wildcard

Enabling the wildcard feature for your host causes *.yourhost.dyndns.org to be aliased to the same IP address as yourhost.dyndns.org. This feature is useful if you want to be able to use, for example, www.yourhost.dyndns.org and still reach your hostname.
Note: If you have a private WAN IP address, then you cannot use Dynamic DNS.

8.2 Configuring Dynamic DNS

To change your Prestige’s DDNS, click Dynamic DNS. The screen appears as shown.
Chapter 8 Dynamic DNS Setup 82
Prestige 660R-6xC Series User’s Guide
Figure 29 Dynamic DNS
The following table describes the labels in this screen.
Table 20 Dynamic DNS
LABEL DESCRIPTION
Active Select this check box to use dynamic DNS.
Service Provider This is the name of your Dynamic DNS service provider.
Host Names Type the domain name assigned to your Prestige by your Dynamic DNS provider.
E-mail Address Type your e-mail address.
User Type your user name.
Password Type the password assigned to you.
Enable Wildcard Select the check box to enable DYNDNS Wildcard.
Apply Click Apply to save your changes back to the Prestige.
Cancel Click Cancel to begin configuring this screen afresh.
83 Chapter 8 Dynamic DNS Setup
This screen is not available on all models. Use this screen to configure the Prestige’s time and date settings.

9.1 Configuring Time and Date

To change your Prestige’s time and date, click Time And Date. The screen appears as shown. Use this screen to configure the Prestige’s time based on your local time zone.
Figure 30 Time and Date
Prestige 660R-6xC Series User’s Guide
CHAPTER 9

Time and Date

The following table describes the labels in this screen.
Chapter 9 Time and Date 84
Prestige 660R-6xC Series User’s Guide
Table 21 Time and Date
LABEL DESCRIPTION
Time Server
Use Protocol when Bootup
IP Address or URL Enter the IP address or URL of your time server. Check with your ISP/network
Time and Date Choose the time zone of your location. This will set the time difference between
Daylight Savings Select this option if you use daylight savings time. Daylight saving is a period from
Start Date Enter the month and day that your daylight-savings time starts on if you selected
End Date Enter the month and day that your daylight-savings time ends on if you selected
Synchronize system clock with Time Server now.
Date
Current Date This field displays the date of your Prestige.
New Date (yyyy­mm-dd)
Time
Current Time This field displays the time of your Prestige.
New Time This field displays the last updated time from the time server.
Apply Click Apply to save your changes back to the Prestige.
Cancel Click Cancel to begin configuring this screen afresh.
Select the time service protocol that your time server sends when you turn on the Prestige. Not all time servers support all protocols, so you may have to check with your ISP/network administrator or use trial and error to find a protocol that works.
The main difference between them is the format.
Daytime (RFC 867) format is day/month/year/time zone of the server. Time (RFC 868) format displays a 4-byte integer giving the total number of
seconds since 1970/1/1 at 0:0:0. NTP (RFC 1305) is similar to Time (RFC 868). Select None to enter the time and date manually.
administrator if you are unsure of this information.
your time zone and Greenwich Mean Time (GMT).
late spring to early fall when many countries set their clocks ahead of normal local time by one hour to give more daytime light in the evening.
Daylight Savings.
Daylight Savings.
Select this option to have your Prestige use the time server (that you configured above) to set its internal system clock.
Please wait for up to 60 seconds while the Prestige locates the time server. If the Prestige cannot find the time server, please check the time server protocol and its IP address. If the IP address was entered correctly, try pinging it for example to test the connection.
Each time you reload this page, the Prestige synchronizes the time with the time server.
This field displays the last updated date from the time server. When you select None in the Use Protocol when Bootup field, enter the new
date in this field and then click Apply.
Each time you reload this page, the Prestige synchronizes the time with the time server.
When you select None in the Use Protocol when Bootup field, enter the new time in this field and then click Apply.
85 Chapter 9 Time and Date
CHAPTER 10
Remote Management
This chapter provides information on configuring remote management.

10.1 Remote Management Overview

Remote management allows you to determine which services/protocols can access which Prestige interface (if any) from which computers.
You may manage your Prestige from a remote location via:
Prestige 660R-6xC Series User’s Guide
Configuration
• Internet (WAN only)
• ALL (LAN and WAN)
• LAN only,
• Neither (Disable).
To disable remote management of a service, select Disable in the corresponding Server Access field.
You may only have one remote management session running at a time. The Prestige automatically disconnects a remote management session of lower priority when another remote management session of higher priority starts. The priorities for the different types of remote management sessions are as follows.
1 Teln et
2 HTTP

10.1.1 Remote Management Limitations

Remote management over LAN or WAN will not work when:
• A filter in SMT menu 3.1 (LAN) or in menu 11.5 (WAN) is applied to block a Telnet, FTP or Web service.
• You have disabled that service in one of the remote management screens.
• The IP address in the Secured Client IP field does not match the client IP address. If it does not match, the Prestige will disconnect the session immediately.
• There is already another remote management session with an equal or higher priority running. You may only have one remote management session running at one time.
Chapter 10 Remote Management Configuration 86
Prestige 660R-6xC Series User’s Guide

10.1.2 Remote Management and NAT

When NAT is enabled:
• Use the Prestige’s WAN IP address when configuring from the WAN.
• Use the Prestige’s LAN IP address when configuring from the LAN.

10.1.3 System Timeout

There is a default system management idle timeout of five minutes (three hundred seconds). The Prestige automatically logs you out if the management session remains idle for longer than this timeout period. The management session does not time out when a statistics screen is polling.

10.2 Telnet

You can configure your Prestige for remote Telnet access as shown next.
Figure 31 Telnet Configuration on a TCP/IP Network

10.3 FTP

You can upload and download Prestige firmware and configuration files using FTP. To use this feature, your computer must have an FTP client.

10.4 Web

You can use the Prestige’s embedded web configurator for configuration and file management. See the online help for details.

10.5 Configuring Remote Management

Click Remote Management to open the following screen.
87 Chapter 10 Remote Management Configuration
Figure 32 Remote Management
The following table describes the labels in this screen.
Table 22 Remote Management
LABEL DESCRIPTION
Prestige 660R-6xC Series User’s Guide
Server Type Each of these labels denotes a service that you may use to remotely manage the
Access Status Select the access interface. Choices are All, LAN Only, WAN Only and Disable.
Port This field shows the port number for the remote management service. You may
Secured Client IPThe default 0.0.0.0 allows any client to use this service to remotely manage the
Apply Click Apply to save your settings back to the Prestige.
Cancel Click Cancel to begin configuring this screen afresh.
Prestige.
change the port number for a service in this field, but you must use the same port number to use that service for remote management.
Prestige. Type an IP address to restrict access to a client with a matching IP address.
Chapter 10 Remote Management Configuration 88
Prestige 660R-6xC Series User’s Guide
89 Chapter 10 Remote Management Configuration
Prestige 660R-6xC Series User’s Guide
CHAPTER 11

Universal Plug-and-Play (UPnP)

This chapter introduces the UPnP feature in the web configurator.

11.1 Introducing Universal Plug and Play

Universal Plug and Play (UPnP) is a distributed, open networking standard that uses TCP/IP for simple peer-to-peer network connectivity between devices. A UPnP device can dynamically join a network, obtain an IP address, convey its capabilities and learn about other devices on the network. In turn, a device can leave a network smoothly and automatically when it is no longer in use.

11.1.1 How do I know if I'm using UPnP?

UPnP hardware is identified as an icon in the Network Connections folder (Windows XP). Each UPnP compatible device installed on your network will appear as a separate icon. Selecting the icon of a UPnP device will allow you to access the information and properties of that device.

11.1.2 NAT Traversal

UPnP NAT traversal automates the process of allowing an application to operate through NAT. UPnP network devices can automatically configure network addressing, announce their presence in the network to other UPnP devices and enable exchange of simple product and service descriptions. NAT traversal allows the following:
• Dynamic port mapping
• Learning public IP addresses
• Assigning lease times to mappings
Windows Messenger is an example of an application that supports NAT traversal and UPnP.
See the Network Address Translation (NAT) Screens chapter for further information about NAT.

11.1.3 Cautions with UPnP

The automated nature of NAT traversal applications in establishing their own services and opening firewall ports may present network security issues. Network information and configuration may also be obtained and modified by users in some network environments.
Chapter 11 Universal Plug-and-Play (UPnP) 90
Prestige 660R-6xC Series User’s Guide
All UPnP-enabled devices may communicate freely with each other without additional configuration. Disable UPnP if this is not your intention.

11.2 UPnP and ZyXEL

ZyXEL has achieved UPnP certification from the Universal Plug and Play Forum Creates UPnP™ Implementers Corp. (UIC). ZyXEL's UPnP implementation supports IGD 1.0 (Internet Gateway Device). At the time of writing ZyXEL's UPnP implementation supports Windows Messenger 4.6 and 4.7 while Windows Messenger 5.0 and Xbox are still being tested.
UPnP broadcasts are only allowed on the LAN.
See later sections for examples of installing UPnP in Windows XP and Windows Me as well as an example of using UPnP in Windows.

11.2.1 Configuring UPnP

From the Site Map in the main menu, click UPnP under Advanced Setup to display the screen shown next.
Figure 33 Configuring UPnP
The following table describes the labels in this screen.
Table 23 Configuring UPnP
LABEL DESCRIPTION
Enable the Universal Plug and Play (UPnP) Service
Allow users to make configuration changes through UPnP
Apply Click Apply to save the setting to the Prestige.
Cancel Click Cancel to return to the previously saved settings.
Select this checkbox to activate UPnP. Be aware that anyone could use a UPnP application to open the web configurator's login screen without entering the Prestige's IP address (although you must still enter the password to access the web configurator).
Select this check box to allow UPnP-enabled applications to automatically configure the Prestige so that they can communicate through the Prestige, for example by using NAT traversal, UPnP applications automatically reserve a NAT forwarding port in order to communicate with another UPnP enabled device; this eliminates the need to manually configure port forwarding for the UPnP enabled application.
91 Chapter 11 Universal Plug-and-Play (UPnP)
Prestige 660R-6xC Series User’s Guide

11.3 Installing UPnP in Windows Example

This section shows how to install UPnP in Windows Me and Windows XP.
Installing UPnP in Windows Me
Follow the steps below to install the UPnP in Windows Me.
1 Click Start and Control Panel. Double-click Add/Remove Programs.
2 Click on the Windows Setup tab and select Communication in the Components
selection box. Click Details.
Figure 34 Add/Remove Programs: Windows Setup: Communication
3 In the Communications window, select the Universal Plug and Play check box in the
Components selection box.
Chapter 11 Universal Plug-and-Play (UPnP) 92
Prestige 660R-6xC Series User’s Guide
Figure 35 Add/Remove Programs: Windows Setup: Communication: Components
4 Click OK to go back to the Add/Remove Programs Properties window and click Next.
5 Restart the computer when prompted.
Installing UPnP in Windows XP
Follow the steps below to install the UPnP in Windows XP.
1 Click Start and Control Panel.
2 Double-click Network Connections.
3 In the Network Connections window, click Advanced in the main menu and select
Optional Networking Components ….
Figure 36 Network Connections
4 The Windows Optional Networking Components Wizard window displays. Select
Networking Service in the Components selection box and click Details.
93 Chapter 11 Universal Plug-and-Play (UPnP)
Prestige 660R-6xC Series User’s Guide
Figure 37 Windows Optional Networking Components Wizard
5 In the Networking Services window, select the Universal Plug and Play check box.
Chapter 11 Universal Plug-and-Play (UPnP) 94
Prestige 660R-6xC Series User’s Guide
Figure 38 Networking Services
6 Click OK to go back to the Windows Optional Networking Component Wizard
window and click Next.

11.4 Using UPnP in Windows XP Example

This section shows you how to use the UPnP feature in Windows XP. You must already have UPnP installed in Windows XP and UPnP activated on the Prestige.
Make sure the computer is connected to a LAN port of the Prestige. Turn on your computer and the Prestige.
Auto-discover Your UPnP-enabled Network Device
1 Click Start and Control Panel. Double-click Network Connections. An icon displays
under Internet Gateway.
2 Right-click the icon and select Properties.
95 Chapter 11 Universal Plug-and-Play (UPnP)
Figure 39 Network Connections
Prestige 660R-6xC Series User’s Guide
3 In the Internet Connection Properties window, click Settings to see the port mappings
there were automatically created.
Chapter 11 Universal Plug-and-Play (UPnP) 96
Prestige 660R-6xC Series User’s Guide
Figure 40 Internet Connection Properties
4 You may edit or delete the port mappings or click Add to manually add port mappings.
97 Chapter 11 Universal Plug-and-Play (UPnP)
Prestige 660R-6xC Series User’s Guide
Figure 41 Internet Connection Properties: Advanced Settings
Figure 42 Internet Connection Properties: Advanced Settings: Add
5 When the UPnP-enabled device is disconnected from your computer, all port mappings
will be deleted automatically.
6 Select Show icon in notification area when connected option and click OK. An icon
displays in the system tray.
Chapter 11 Universal Plug-and-Play (UPnP) 98
Prestige 660R-6xC Series User’s Guide
Figure 43 System Tray Icon
7 Double-click on the icon to display your current Internet connection status.
Figure 44 Internet Connection Status
Web Configurator Easy Access
With UPnP, you can access the web-based configurator on the Prestige without finding out the IP address of the Prestige first. This comes helpful if you do not know the IP address of the Prestige.
Follow the steps below to access the web configurator.
1 Click Start and then Control Panel.
2 Double-click Network Connections.
3 Select My Network Places under Other Places.
99 Chapter 11 Universal Plug-and-Play (UPnP)
