Edition Time: March 2014
Manual No.: Z8090161500MT
Table of Contents
About This Manual
Thank you for choosing this ZTE mobile device. In order to keep your device in its best
condition, please read this manual and keep it for future reference.
All rights reserved.
No part of this publication may be quoted, reproduced, translated or used in any form or by
any means, electronic or mechanical, including photocopying and microfilm, without the
prior written permission of ZTE Corporation.
Notice
ZTE Corporation reserves the right to make modifications on print errors or update
specifications in this manual with-out prior notice. This manual has been designed with the
utmost care to ensure the accuracy of its content. However, all statements, information
and recommendations contained therein do not constitute a warranty of any kind, either
expressed or implied. Please refer to chapter For Your Safety to be sure to use your
phone properly and safely.
We offer self-service for our smart terminal device users. Please visit the ZTE official
website (at www.ztedevice.com) for more information on self-service and supported
product models. Information on the website takes precedence.
Disclaimer
ZTE Corporation expressly disclaims any liability for faults and damages caused by
unauthorized modifications of the software.
Images and screenshots used in this manual may differ from the actual product. Content in
this manual may differ from the actual product or software.
Trademarks
ZTE and the ZTE logos are trademarks of ZTE Corporation.
Google and Android are trademarks of Google, Inc.
The Bluetooth® trademark and logos are owned by the Bluetooth SIG, Inc. and any use of
such trademarks by ZTE Corporation is under license.
microSDHC Logo is a trademark of SD-3C, LCC.
Other trademarks and trade names are the property of their respective owners.
2
Table of Contents
Qualcomm Snapdragon™ processors are products of Qualcomm Technologies, Inc.®
Qualcomm and Snapdragon are trademarks of Qualcomm Incorporated, registered in the
United States and other countries. Used with permission.
Table of Contents
Installing the Battery and a microSDHC Card .................................................... 1
Charging the Battery ........................................................................................... 2
To lock the screen and keys: ............................................................................ 3
To unlock the screen and keys: ........................................................................ 3
Using the Touch Screen ...................................................................................... 3
Getting to Know Your Phone .............................................................................. 5
Interference in Cars ........................................................................................ 92
Gas Stations and Explosive Atmospheres ....................................................... 93
Blasting Caps and Areas ................................................................................ 93
GettingStarted
Getting Started
Installing the Battery and a
microSDHC Card
Switch off your phone before installing or
replacing the battery. You have the option to
install a microSDHC card of up to 32GB to
expand your phone’s storage capacity. The
microSDHC card can be installed and
removed while the phone is turned on.
Unmount the microSDHC card before
removing it.
1. Place your finger in the slot at the bottom of
the back cover to lift and remove the cover.
2. Insert the battery by aligning the metal
contacts on the battery with the gold
contacts in the battery compartment. Gently
push down on the battery until it clicks into
place.
WARNING!
leaking Li-Ion battery as you can be burned.
3. Open memory card cover at the left side of
the phone an insert the microSDHC card.
NOTE:
pre-installed microSDHC card. Some
applications may not function normally after
you remove the card, pre-installed or
otherwise.
4. Push tightly until the card is installed in the
right position and close the card cover.
Do not handle a damaged or
Your phone may come with a
1
Charging the Battery
WARNING!
chargers and cables. The use of unapproved
accessories could damage your phone or
cause the battery to explode.
1. Connect the adapter to the charging port.
Ensure that the adapter is inserted with the
correct orientation. Do not force the
connector into the charging port.
2. Connect the charger to a standard AC wall
outlet. If the phone is on, you’ll see a
charging icon, such as or , appear in
the Status Bar.
3. Disconnect the charger when the battery is
fully charged.
Use only ZTE-approved
Switching Your Phone On/Off
Getting Started
• Press and hold the Power/Lock Key to
turn on
your phone.
• To turn it off, press and hold the
Power/Lock Key to open the options
menu. Tap Power off and then tap OK.
Setting Up Your Phone for
the First Time
When you first power on your phone after you
purchase it or reset it to factory settings (see
Settings – Personal – Backup and Reset), you
may need to set it up before using it.
1. Tap the language field, select the language
you want, and tap Start.
2. Set the date, time, and time zone, or use
date and time data provided by the network.
Then tap Next.
3. If you have a Google™ account, tap Yes to
sign in. Tap No if you do not have an
account. Tap Get an account to create a
Google account or tap Not now to set up an
account later.
4. Configure the Google location options and
tap Next.
5. Enter your name, which the phone uses to
personalize some apps, and then tap Next.
6. You will be prompted to accept the Google
2
Getting Started
terms of service. Tap Next to continue.
7. Tap Finish to complete the setup.
If the phone is not activated, it would
NOTE:
prompt you to connect to a Wi-Fi network
before asking you to sign in to a Google
account.
Locking/Unlocking the Screen and
Keys
Your phone allows you to quickly lock the
screen and keys (put the phone into Sleep
mode) when not in use, and also to turn the
screen back on and unlock it when you need it.
To lock the screen and keys:
To quickly turn the screen off and lock the
keys, press the Power/Lock Key.
To save battery power, the phone
NOTE:
automatically turns off the screen after a
certain period of time when you leave it idle.
You will still be able to receive messages and
calls while the phone screen is off.
To unlock the screen and keys:
1. Press the Power/Lock Key to turn the
screen on.
2. Long press screen to unlock.
If you have set an unlock pattern, PIN,
NOTE:
or password for your phone (see Personalizing
– Protecting Your Phone With Screen Locks),
you’ll need to draw the pattern or enter the
PIN/password to unlock your screen.
Using the Touch Screen
Your phone’s touch screen lets you control
actions through a variety of touch gestures.
• Tap – When you want to type using the
on-screen keyboard, select items
on-screen (such as application and
settings icons), or press on-screen buttons,
simply tap them with your finger.
• Tap and Hold – To open the available
options for an item (for example, a
message or link in a web page), tap and
hold the item.
• Swipe or Slide – To swipe or slide means
to quickly drag your finger vertically or
horizontally across the screen.
• Drag – To drag, press and hold your finger
with some pressure before you start to
3
move your finger. While dragging, do not
release your finger until you have reached
the target position.
• Pinch – In some apps (such as Maps,
Browser, and Gallery), you can zoom in
and out by placing two fingers on the
screen at once and pinching them together
(to zoom out) or spreading them apart (to
zoom in).
• Rotate the screen – For most screens,
you can automatically change the screen
orientation from portrait to landscape by
turning the phone sideways.
Getting Started
4
Getting Started
3.5mm
Headset Jack
End/Powerkey
Micro USB
Charging Port
Earpiece
Volume
Up/Down Keys
Back Key
Microphone
micro SD
card slot
Battery
Cover
Camera
Speaker
Menu Key
Getting to Know Your Phone
5
Key Functions
Key
Description
Power/Lock
Key
Press and hold to turn on or off Airplane mode, enable silent
mode/vibration mode/sound, or to power off.
Press to switch your phone to Sleep mode.
Press to wake up your phone.
Home Key
Press to return to the Home Screen from any application or screen.
Press and hold to see recently used applications.
Menu Key
Press for current screen options.
Back Key
Press to go to the previous screen.
Volume Keys
Press or hold to turn the volume up or down.
Getting Started
6
Getting Started
Earpiece
Shortcut
Tap to open
the main
Wallpaper
Widget
Tap to open
contacts
Tap to open
messaging
Tap to open
the web
browser
Tap to
open the
Home Screen
You can customize your Home Screen. Set
your own wallpaper, add the widgets or
application shortcuts you need, or remove
them as you like.
Arrange & work with apps
Too see all your apps, touch the All Apps Icon
on any Home screen. After opening the All
Apps, press an icon to enter the corresponding
application. Touch the Back key to return to
the previous screen. Touch the Home key to
return to the home screen.
From All Apps, you can:
•Explore your widgets: Touch the widgets
tab at the top of any All Apps screen.
•Get more apps.: Touch the Play Store
icon at the top of any All Apps screen.
On the home screen, touch & hold the Home key, opens a list of thumbnail images of apps
you’ve worked with recently. To open an app,
touch it. To remove a thumbnail from the list,
swipe it left or right.
7
Changing the System Language
Personalizing
1. Press the Home Key > Menu Key >
System settings > Language & input >
Language.
2. Select the language you need.
Changing the Ringtone
You can customize the default ringtone for
incoming calls by taking the following steps.
1. Press the Home Key > Menu Key >Settings > Sound.
2. Tap Phone ringtone.
3. Scroll through the ringtone list and select the
ringtone you want to use.
4. Tap OK.
See People – Editing Contacts – Setting
TIP:
a Ringtone for a Contact for how to assign a
special ringtone to an individual contact.
Personalizing
4. Tap OK.
Turning On/Off Touch Sounds
1. Press the Home Key > Menu Key >
System settings > Sound.
2. Check or uncheck Touch sounds.
Adjusting Volumes
1. Press the Home Key > Menu Key >
System settings > Sound > Volumes.
2. Drag the sliders to adjust the volume for
each type of audio.
3. Tap OK to save.
You can adjust the media volume when a
TIP:
media application is in use by pressing the
Volume Up/Down Keys. If no media
application is active, press the Volume Up/Down Keys to adjust ringtone volume (or
the earpiece volume during a call).
Changing the Notification Sound
You can customize the default notification
sound by taking the following steps.
1. Press the Home Key > Menu Key > Settings >Sound.
2. Tap Notification ringtone.
3. Scroll through the list and select the ringtone
you want to use.
8
Switching to Silent Mode
You can set the phone to silent mode by using
one of the following methods:
• Press and hold the Power/Lock Key and
then tap to enable silent mode, tap
to enable silent
to disable silent mode.
• Keep pressing the Volume Down Key
mode with vibration, or tap
Personalizing
when no media application is active. When
the icon appears in the Status Bar, the
phone is set to silent mode with vibration.
When the icon appears in the Status
Bar, the phone is in silent mode.
• Press the Home Key > Menu Key >
System settings > Sound > Silent mode,
and tap Vibrate or Mute.
Applying New Wallpapers
You can set the wallpaper for the Home
Screen or Lock Screen.
1. Press the Home Key > Menu Key >
Wallpaper.
2. Tap Home or Lock screen.
3. Select a wallpaper source from Gallery,
Live Wallpapers, or Wallpapers and
choose the image or animation you want to
use as the wallpaper. Some cropping may
be needed for Gallery images.
4. Tap Set wallpaper.
Live Wallpapers are not available for
NOTE:
the Lock Screen.
Changing the Screen Brightness
1. Press the Home Key > Menu Key >
System settings > Display > Brightness.
2. Check the Automatic brightness box to
make the phone adjust the screen
brightness automatically, or clear the check
box to adjust the brightness manually.
3. Tap OK.
Protecting Your Phone With
Screen Locks
You can protect your phone by creating a
screen lock. When enabled, you need to draw
a pattern or enter a numeric PIN or password
to unlock the phone’s screen and keys.
1. Press the Home Key > Menu Key >
System settings > Security.
2. Tap Screen lock.
3. Tap Pattern, PIN, or Password.
• If you tap Pattern, you’ll need to create a
pattern you must draw to unlock the screen.
The first time you do this, a short tutorial
about creating an unlock pattern appears.
Then you’ll be prompted to draw and
redraw your own pattern.
• If you tap PIN or Password, you’ll be
prompted to set a numeric PIN or a
password that you must enter to unlock
your screen.
The next time you turn on your phone or wake
up the screen, you must draw your unlock
pattern or enter your PIN or password to
unlock it.
9
IMPORTANT:
set, try five times and tap Forget pattern? to
sign in to the Google account you have added
on the phone and reset the screen lock. You
will need an active Internet connection. You
can also upgrade the phone software.
If you forget the pattern you
Protecting Your Phone With
Encryption
You can encrypt all the data on your phone:
Google accounts, application data, music and
other media, downloaded information, and so
on. If you do, you must enter a numeric PIN or
password each time you power on your phone.
WARNING!
only way to revert to an unencrypted phone is
to perform a factory data reset, which erases
all your data.
Encryption provides additional protection in
case your phone is stolen, and may be
required or recommended in some
organizations. Consult your system
administrator before turning it on. In many
cases the PIN or password you set for
encryption is controlled by the system
administrator.
Before turning on encryption, prepare
as follows:
Encryption is irreversible. The
Personalizing
1. Set a lock screen PIN or password.
2. Charge the battery.
3. Keep the phone connected to the charger.
4. Schedule an hour or more for the encryption
process. You must not interrupt it or you will
lose some or all of your data.
When you’re ready to turn on
encryption:
1. Press the Home Key > Menu Key >
System settings > Security > Encrypt
phone.
2. Read the information about encryption
carefully.
The Encrypt phone button is dimmed if
your battery is not charged or your phone is
not plugged in. If you change your mind
about encrypting your phone, press the
Back Key.
WARNING!
process, you will lose data.
3. Tap Encrypt phone.
4. Enter your lock screen PIN or password and
tap Next.
5. Tap Encrypt phone again.
The encryption process starts and displays its
If you interrupt the encryption
10
Personalizing
progress. Encryption can take an hour or more,
during which time your phone may restart
several times.
When encryption is complete, you’ll be
prompted to enter your PIN or password.
Subsequently, you must enter your PIN or
password each time you power on your phone
to decrypt it.
11
KnowingtheBasics
Indicator
What it means
Indicator
What it means
1X network connected
No signal
3G network connected
Signal strength
Flight mode
Ringer off
Battery empty
Vibrate mode
Battery low
Bluetooth on
Battery partly drained
Connected to a Wi-Fi network
Battery full
Wi-Fi in use
/
Battery charging
Wired headset connected
Alarm set
Knowing the Basics
Monitoring the Phone Status
The Status Bar at the top of the Home Screen provides phone and service status icons on the
right side.
Below are some of the icons you may see.
Indicators and Icons
12
Loading...
+ 83 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
