ZTE X176 User Manual
ZTE X176
CDMA 1X Digital Mobile Phone
User Manual
Copyright © 2008 by ZTE Corporation
All rights reserved.
No part of this publication may be excerpted, reproduced,
translated or utilized in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without the prior
written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right
to make modifications on print errors or update specifications without
prior notice.
Version No.: Release 1.0*
Edition Time: Aug. 2008
Manual No.: 056584500000
ZTE
Declaration
We, ZTE Corporation, declared that:
The product is installed with battery separately in the box. The
FCC ID label is placed on the mobile phone clearly visible to all
persons at the time of purchase.
The user is cautioned that changes or modifications not expressly
approved by the manufacturer could void the user’s authority to
operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Do not attempt to disassemble the mobile phone and battery by
yourself. Non-expert handling of the devices may damage them.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed limits for exposure to
radio frequency (RF) energy set by the Federal Communications
Commission (FCC) of the U.S. Government. These limits are part
of comprehensive guidelines and establish permitted levels of RF
energy for the general population. The guidelines are based on
standards that were developed by independent scientific
3
ZTE
organizations through periodic and thorough evaluation of
scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons, regardless of
age or health. The exposure standard for wireless fixed phoned
employs a unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limits set by the FCC are 1.6W/kg. Tests
for SAR are conducted using standard operating positions
accepted by the FCC with the phone transmitting as its highest
certified power level in all tested frequency bands. Although the
SAR is determined at the highest certified power level, the actual
SAR level of the phone while operating can be well below the
maximum value. This is because the phone is designed to
operate at multiple power levels so as to use only the power
required to reach the network. In general, the closer you are to a
wireless base station, the lower the output power.
The Highest SAR Values for this model phone when tested for
use on the right head was 1.304 W/Kg, on body was 0.121w/Kg
4
ZTE
Content
1 General Inform ation....................................................... 2
1.1 W elcom e....................................................................................2
1.2 Security.....................................................................................2
1.3 Safety Warnings ..............................................................3
1.4 Limit Warranty..........................................................................7
1.5 Limitation of Liability...............................................................8
1.6 Declaration................................................................................8
2 Know Your Phone............................................................ 9
2.1 Keypad......................................................................................9
2.2 Instruction of Interface Icon.................................................... 11
2.3 Technic al Parameters...............................................................12
2.4 Battery.....................................................................................12
2.4.1 Remove and Installation of Battery.................................13
2.4.2 Charging the Battery........................................................14
2.5 Connect to the Network ..........................................................15
2.5.1 UIM Card ........................................................................15
2.5.2 Insertion and Extraction of UIM Card.............................16
2.5.3 Power on/off Phone.........................................................17
2.5.4 Connect the Network.......................................................17
i
ZTE
3 Basic Operations............................................................ 18
3.1 Make a Call.............................................................................18
3.2 Answer a Call..........................................................................19
3.2.1 Headset Ringing..............................................................20
3.2.2 Headset Autoanwer..........................................................20
3.2.3 Set any Key Answer........................................................20
3.2.4 Incoming Call Silence.....................................................21
3.3 In Conversation.......................................................................21
3.3.1 Silence in Conversation...................................................21
3.3.2 Adjust V olume in Conversation.......................................21
3.3.3 Select Options in Conversation .......................................21
3.4 Menu Functions ......................................................................22
4 Contacts.......................................................................... 23
4.1 Find Records...........................................................................23
4.2 Add New Record.....................................................................25
4.3 View Records .......................................................................... 27
4.4 Erase Records..........................................................................27
4.4.1 Erase a Record.................................................................27
4.4.2 Erase all Contacts............................................................28
4.5 Edit Name of the Contacts......................................................28
4.6 Edit Phone Number................................................................. 28
4.7 Select Group............................................................................29
4.8 Set Number T ype.....................................................................29
ii
ZTE
4.9 Set Speed Dial.........................................................................29
4.10 V iew and M ake Speed Dial...................................................30
4.11 Memory Status ......................................................................30
4.12 Copy all Contacts..................................................................31
5 Messages......................................................................... 32
5.1 Send a New Message..............................................................32
5.2 Send Messages........................................................................33
5.3 Receive Incoming Call while Editing Message.......................34
5.4 Read Message.........................................................................34
5.5 View OutBox...........................................................................35
5.6 Erase Messages.......................................................................35
5.6.1 Erase a Message..............................................................36
5.6.2 Erase all Messages...........................................................36
5.7 UIM.........................................................................................37
5.8 Send Preformatted Messages..................................................37
5.9 Read Voice Mail......................................................................38
5.10 Message Settings...................................................................38
5.10.1 Change Voice Mail Box Number...................................38
5.10.2 Message Alert................................................................39
5.10.3 Automatically Erase InBox............................................39
6 Recent Calls................................................................... 40
6.1 View Recent Calls...................................................................40
iii
ZTE
6.2 Erase Recent Calls List...........................................................41
7 Settings........................................................................... 42
7.1 Auto Key Guard......................................................................42
7.2 Supp.Services..........................................................................43
7.2.1 Call Waiting.....................................................................43
7.2.2 Call Forwarding...............................................................44
7.3 Sound......................................................................................45
7.3.1 Volume............................................................................. 45
7.3.2 Alert T ype........................................................................45
7.3.3 Ringer of Incoming Call..................................................46
7.3.4 Key Beep.........................................................................46
7.3.5 Key Tone Length.............................................................46
7.3.6 SMS Ringer.....................................................................46
7.3.7 ClockRinger Type............................................................47
7.4 Display....................................................................................47
7.4.1 Set Backlighting..............................................................47
7.4.2 Change Banner................................................................47
7.4.3 Select Language ..............................................................48
7.4.4 Adjust Contrast................................................................48
7.4.5 Set Menu Format.............................................................48
7.4.6 Set Time Format..............................................................48
7.4.7 Screensaver......................................................................49
7.5 Alert ........................................................................................49
iv
ZTE
7.6 Call Timers..............................................................................50
7.7 Security Settings .....................................................................50
7.7.1 Modify PIN Code............................................................51
7.7.2 Erase All Recent Calls.....................................................51
7.7.3 Erase all Contacts............................................................51
7.7.4 Restore Factory Default...................................................51
7.8 Accessories..............................................................................52
7.8.1 Set Headset Ring............................................................. 52
7.8.2 Set Headset Autoanswer..................................................52
7.8.3 Any Key Answer..............................................................53
8 Extra............................................................................... 54
8.1 Games.....................................................................................54
8.1.1 BlackJack ........................................................................54
8.1.2 Video Poker.....................................................................54
8.2 Stopwatch................................................................................55
8.3 Alarm ......................................................................................55
8.4 Calendar..................................................................................56
8.5 Calculator................................................................................56
8.6 Voice Memo............................................................................57
8.6.1 Record in Normal............................................................57
8.6.2 Record in Conversation...................................................58
8.6.3 Record with Incoming Call/Message...............................58
9 Text Input....................................................................... 60
v
ZTE
9.1 Multitap Input.........................................................................61
9.2 Numbers Input ........................................................................61
9.3 eZiText Input...........................................................................62
9.4 Symbols Input.........................................................................62
10 Troubleshooting............................................................. 63
vi
ZTE
Explanation for
Mobile Phone with/without UIM Card
There are two types of ZTE CDMA Mobile phone, one need UIM
card inserted and another does not need. Sections or functions in this
manual are for the phone with UIM card. If your phone could be used
without UIM card, please pay attention to the following items:
1. The phone can be used without the UIM card.
2. Some functions are only available concerning with UIM and won't
display, such as,
z The new contact can be saved only in Phone, not in UIM.
z The new message can be saved only in Phone, not in UIM.
z The message in Inbox can not be moved to UIM.
z There is no PIN Lock function in Security Setting.
1
ZTE
1 General Information
1.1 Welcome
Thank you for choosing ZTEX176 CDMA 1X Digital Mobile Phone.
To guarantee the mobile phone always in its best condition, please
read this manual carefully and keep it for future use.
The pictures, symbols and contents in this manual are just for your
reference. They might not be completely identical with your phone.
Please subject to the real object. ZTE operates a policy of continuous
development and reserves the right to update and modify the technical
specifications in this document at any time without prior notice.
1.2 Security
If your mobile phone is lost or stolen, please report to your service
provider or agencies of banning the use of your lost UIM card and
phone, which will protect you from economic losses resulted from
unauthorized use.
You need to provide the phone’s ESN (Electronic Series Number)
number labeled. You can see ESN number after removing the
battery. Please keep ESN number for future use.
To prevent your mobile phone from illegal use, please take the
security measures as follows:
¾ Set PIN code of the UIM card.
2
ZTE
¾ Take it with you as you can.
1.3 Safety Warnings
To t h e O w n e r
Some electronic devices are susceptible to electromagnetic
interference sent by mobile phone if inadequately shielded, such
as electronic system of vehicles. Please consult the manufacturer
on the device before using the phone if necessary.
Operating of mobile phone may interfere with medical devices like
hearing aides and pacemakers. Please always keep the mobile
phone more than 20 centimeters away from such medical devices
when the phone is powered on.
The phone with internal antenna has been tested for compliance
with FCC RF Exposure (SAR) limits and is complied with FCC RF
exposure compliance requirements.
Do not carry the mobile phone in the breast pocket. Power the
mobile phone off if necessary. Consult a physician or the
manufacturer on the medical device before using the phone.
Be aware of the usage limitation when using a mobile phone at
places such as oil warehouses or chemical factories, where there
are explosive gases or explosive products being processed,
because even if your phone is in standby mode, it still transmits
radio frequency (RF) energy. Therefore, power off your phone if
required.
3
ZTE
Pay attention to traffic safety. Do not use your mobile phone while
driving. Park before making or answering a call.
Store the phone out of the reach of little children. The phone may
cause injury if used as a toy.
The phone complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) The phone may not cause harmful interference, and (2) the
phone must accept any interference received, including
interference that may cause undesired operation.
Mobile Phone
Please use original accessories or accessories that are
authorized by the manufacturer. Using any unauthorized
accessories may affect your mobile phone’s performance, and
violate related national regulations about telecom terminals, or
even endanger your body
If you want to clean your phone, please use clean fabric that is a
bit wet or anti-static. Do not use harsh chemical cleaning solvents
or strong detergents to clean it. Turn off your phone before you
clean it.
As your mobile phone can produce electromagnetic field, do not
place it near magnetic items such as computer disks.
Using the phone near electrical appliances such as TV, telephone,
radio and personal computer can cause interference, which
4
ZTE
affects the function of the phone.
Do not expose your mobile phone to direct sunlight or store it in
hot areas. High temperatures can shorten the life of electronic
devices.
Prevent liquid from leaking into your phone.
Do not drop, knock or harshly treat your phone. Rough handling
can break internal circuit boards.
Do not connect the phone with other unauthorized peripheral
equipments.
Do not attempt to disassemble the mobile phone and battery by
yourself. Non-expert handling of the devices may damage them.
Do not attempt to disassemble the mobile phone and battery by
yourself. Changes and modifications made to the phone without
the approval of manufacturer could void your authority to operate
this phone.
Do not charge the mobile phone without battery.
On occasion of emergent calling, keep your phone in status of
power on and in area of service. On the condition of standby,
press the key to enter emergency phone number, and then press
Send key
Battery Using
The battery and the phone are separately deposited in the
to make a phone call.
5
ZTE
package and packed in well condition. Please make use of the battery
carefully following the instructions.
Do not short-circuit the battery, as this can cause excessive heat
and fire.
Do not store battery in hot areas or dispose of it in a fire to avoid
explosion.
Never use any charger or battery damaged or worn out.
Return the wear-out battery to the provider or put it in the
appointed recycle place. Do not put it in familial rubbish.
Warning : If the battery is broken, keep away from content. If it
taints your skin, wash your skin with abundant fresh water and
ask doctor for help if necessary.
Safety and General Using in Vehicles
Before making or answering a call, you should pay attention to
the local laws about using wireless mobile phones and take them
into account in practical use.
Safety airbag, brake, speed control system and oil eject system
shouldn’t be affected by wireless transmitting. If you do meet
problems above, please contact your automobile provider.
Please power off your mobile phone when refueling your
automobile, and so do the place where duplex wireless
equipments are banned. Don’t put your phone together with
flammable or explosive items, as inner spark may cause fire.
6
ZTE
In Aircraft
Follow the restrictions in aircraft. Wireless devices can cause
interference in aircraft.
Please power off your mobile phone before taking off till landing. In
order to protect airplane’s communication system from
interference, it is never allowed to use mobile phone when it is in
flight. Using mobile phone before the plane taking off should get
aircrew’s permission according to safety regulations.
1.4 Limit Warranty
The warranty does not apply to defects or errors in the product
caused by:
(a) Reasonable abrasion.
(b) Misuse including mishandling, physical damage, improper
installation, unauthorized disassembly of the product.
(c) Water or any other liquid damage.
(d) Any unauthorized repair or modification.
(e) Power surges, lightning damage, fire, flood or other events
outside ZTE’s reasonable control.
(f) Use of the product with any unauthorized third party
products such as generic chargers.
(g) Any other cause beyond the range of normal usage for
products.
End User shall have no right to reject, return, or receive a
7
ZTE
refund for any product from ZTE under the above-mentioned
situations.
This warranty is end user’s sole remedy and ZTE’s sole liability
for defective or nonconforming items, and is in lieu of all other
warranties, expressed, implied or statutory, including but not
limited to the implied warranties of merchantability and fitness for a
particular purpose, unless otherwise required under the mandatory
provisions of the law.
1.5 Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special,
incidental or consequential damages resulting from or arising out of or
in connection with using this product, whether or not ZTE had been
advised, knew or should have known the possibility of such damages.
1.6 Declaration
We,ZTE Corporation, declared that the product is installed with
battery separately in the box.The FCC ID label is placed on the mobile
phone clearly visible to all persons at the time of purchase.
8
ZTE
2 Know Your Phone
2.1 Keypad
Earpiece
LCD Display
4-way scroll Key
Earphone
OK Key
Send Key
0~9 Number Key
Microphone
Key Tip Function Description
Make or answer a call.
Send key
Press Send key in standby mode to
enter All Recent Calls list.
9
Cancel Key
End Key
Charge connector
ZTE
Press Send key two times directly
to redial the last number.
End an active call or reject a call.
End key
Clear key
OK key
Up/Down key
(Scroll key)
Power on/power off.
Exit from any interface to standby
mode.
Erase character(s) while editing.
Cancel operation, eixt to previous
pop-up window.
In standby mode, hold Clear key to
lock keypad.
Enter main menu in standby mode,
as shown on the screen.
Switch to options of submenu.
Confirm the character chosen while
character inputting.
Scroll the cursor up and down.
Used as selection key up and
down for keying in commands
and selecting options shown on
the display.
In standby mode, hold Up key to
set Silence All; Press Down key
to enter Messages menu.
10
ZTE
Adjust volume in conversation.
Used as direction key in games.
Scroll the cursor left and right.
Used as selection key to scroll
cursor left and right for keying in
Left/Right key
(Scroll key)
~
Note: To “press” the key in this manual means to press the key
and release it. To “hold” the key means to keep pressing the key for two
seconds or more.
0~9 Number
key
*key，#key Differs in different mode, option or
commands and selecting options
shown on the display.
In standby mode, press Left key
to enter Extra menu, press Right
key to view All Contacts.
Used as direction key in games.
Key in numbers or characters.
Make a speed Dial call.
function menu.
2.2 Instruction of Interface Icon
Icon Indication
Signal strength
Incoming call or calling
11
ZTE
Keypad locked
Roaming
New message
Vibration
Silence All
Alarm
Power indicator
2.3 Technical Parameters
Handset
Type ZTEX176
Dimensions (Width×Height×Thickness)
43.4 mm×100mm×13.4mm
Weight About 85g(Battery Included)
Battery
Continuous standby
time
Continuous talk time
Note: Please refer to the real phone for other relative parameters
of the battery and charger.
About 80h～160h (Subject to Network)
About 2h～4h (Subject to Network)
2.4 Battery
The attached Li-ion battery along with the phone can be used after
unpacking. For the first three times, please use up the power and
charge it fully for a new battery to perform well.
12
ZTE
2.4.1 Remove and Installation of Battery
Remove：(1) Press and push the back-cover of the phone down to
release and remove it off the phone. (2) Put finger on the top
finger grip, and then lift up the battery from the finger grip to
remove the battery.
Installation：(1) Replace the battery into the battery slot, to be
noted that the lower end of the battery firstly inserted. (2) Put
the back-cover of the phone flatly upon the body of phone. Direct
the back cover towards the locking catches on the both sides of
the phone and push the back-cover of the phone upward to lock
the cover into its place.
13
Loading...
