ZTE WP850 User Manual
ZTE WP850
CDMA Wireless Phone
User Guide
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Tel: (86) 755 26779999
URL: http://www.zte.com.cn
E-mail: mobile@zte.com.cn
LEGAL INFORMATION
Copyright © 2012 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by
any means, electronic or mechanical, including photocopying and microfilm, without the prior
written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to make modifications on print
errors or update specifications without prior notice.
Version No. : R1.2
Edition Time : 2012.05.25
C h a p t e r 1
Know Your Phone
Earpiece
LCD Screen
1
2
3
4
5
7
8
9
10
There are two ZTE WP850 models. One needs UIM card inserted in, the other does not need.
Section or function marked with “★” is only available to the model with UIM card. Otherwise, it is
available to both models.
6
11
Confidential and Proprietary Information of ZTE CORPORATION 1
t
C h a p t e r 2
Key Instruction
Key Description
1, 3, 8: Scrolling keys
(Up/Down/Left/Right key)
2: Left select key
4: CALL/REDIAL key
5: Number keys
6, 11: * key, # key
7: Right select key
9: End key
Press these keys to scroll cursor to the left, right, up or down
when inputting characters or selecting items.
Enter main menu.
Select or confirm options in menu.
Enter the left-bottom menu.
Make a call or answer an incoming call.
In standby mode, press this key to enter recent calls list.
Input numbers and characters.
Perform different functions under different conditions.
Enter righ
Erase character(s) while editing text.
Return to the previous page during menu navigation.
End an active call or reject a call.
Hold this key to Power on/Power off the phone.
Exit from any interface to standby mode.
-bottom submenu on the screen.
10: OK key
Notes:
In this guide, “press” a key means to press the key once, “hold” a key means to press the key for 2 or 3
seconds.
Confirm the commands and options selected.
Confirm the characters inputting.
Confidential and Proprietary Information of ZTE CORPORATION 2
C h a p t e r 3
Interface Icons
Icon Description Icon Description
Signal strength
Silent
Power indicator
New message
Roaming
Alarm clock
Confidential and Proprietary Information of ZTE CORPORATION 3
C h a p t e r 4
Installation
1. Charge the battery
z Connect the desk charger and external AC socket via power adapter.
z Put the phone on the desk charger. The charge spring of the desk charger should be inserted in
the apertures at the bottom of the phone.
z Meanwhile, power indicator in the upper-right corner of the display blinks, indicating the
charging is in progress. While charging in power-off mode, the display only shows the charge
indicator. If the battery is completely flat, it may take a while before the charge indicator appears
on the display.
z When the power indicator on the screen stops blinking, the charging is completed. The normal
charging time is 4 hours. In the process of charging, it is a normal phenomenon that the battery,
phone and charger get hot.
z After the completion of charging, disconnect the charger from the phone and AC socket.
Note：
When charging the battery, place the phone in an environment with good ventilation and
temperature between 0℃～＋45℃. Make sure to use the charger offered by the phone
manufacturer. Using unauthorized charger may cause danger and violate the guarantee articles.
When the phone is automatically switched off or indicates power shortage, charge the battery in
time.
The standby time and the talk time of the phone are based on ideal working environment. In
practice, the working time of battery varies with network condition, working environment and
application methods.
2. ★UIM Card
z Power off the phone and remove other external power.
z Take off the back cover and remove the battery of the phone.
z Insert UIM card into UIM card slot in the phone or pull out UIM card out of slot.
z Direct the back cover towards the locking catches on the both sides of the phone and push the
back cover of the phone upward to lock the cover into its place.
Confidential and Proprietary Information of ZTE CORPORATION 4
C h a p t e r 5
How to Power On/Off
Hold the End key to power on the phone.
When the phone is powered on, hold the End key to power off the phone.
Confidential and Proprietary Information of ZTE CORPORATION 5
