ZTE WF821E User Manual

Getting started with your device.

ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park, Nanshan District, Shenzhen, Guangdong, P.R.China Postcode: 518057

WF821E

Let’s go

ZTE WF821E Getting Started

LEGAL INFORMATION

No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation.

The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice.

Version No. : R1.0 Edition Time : 2015.6.12

Confidential and Proprietary Information of ZTE CORPORATION

Confidential and Proprietary Information of ZTE CORPORATION 2

ZTE WF821E Getting Started

Getting to Know Your Device

Packing list

Upon receiving the product, please unpack the product package carefully. Each product is shipped with the following items:

Outdoor CPE Products Quantity

IDU unit 1 12 VDC Power Adapter 1 PC Ethernet Cable 1

If you find any of the items is missing, please contact our local distributor immediately.

Unpacking the Equipment

All the standard parts that are supplied in your LTE CPE Unit Installation Package. Please take time to unpack the package and check its contents against this list.

LED Indicators

LED Function Description

SYS Power Indicator

NET WAN Indicator

RF 4G Signal Indicator

SIM SIM Card status

WiFi WiFi status WPS WPS Service Access

ETH LAN port status

Orange Color – Device is power on and booting Green Color – Device at work OFF – NO WAN cable connected. Blinking Green – WAN data transmission in progress. 1st: -140 dBm <=RSRP <-115 dBm 2nd: -115 dBm <= RSRP < -110 dBm 3rd: -110 dBm <= RSRP < -105 dBm 4th: -105 dBm <= RSRP

Light is on – SIM Card state ready

Green Light is on –WiFi is enabled and working Blinking Orange – Device WPS at work

OFF – No LAN cable connected Solid Green – The LAN port is up Blinking Green – LAN data transmission in progress

LED Function Description

MSG Message Indicator

Light is on – Message received

Connection Scenario

To power on the device, the Indoor CPE uses a 12V DC power supply from the adapter. All power adapters can operate in 90-250V AC range and therefore can be used in different countries. Once the device is powered, the operator should wait for about 2 minutes before the device becomes operational. The CPE PWR LED indicator will changes from Blinking to Solid orange light to indicate the device has completed the startup procedure.

To connect PC, LAN switch or other type of IP device to the CPE product, the operator should use standard CAT5 Ethernet cable and connect to the appropriate LAN port. Once connected, the corresponding CPE LAN LED indicator should light up.

To use the phone service(For WF821+ Only), operator can simply plug the phone line to the CPE RJ11 port in the back. If the line is not registered or configured, a fast busy tone will be provided and the corresponding LINE LED light will be off.

For FIX CPE product, it is recommended that the installation shall be operated by professional engineer. For the phone and LAN connection, it is recommended that to keep a distance of at least 80cm.

As following pictures show, the pedestal should be fixed by 3 screws, and then the CPE can be stuck by the pedestal in horizontal or on the wall.

Confidential and Proprietary Information of ZTE CORPORATION 3

Confidential and Proprietary Information of ZTE CORPORATION 4
