Zte Spark Lite 3G Help Manual

1

Spark Lite 3G

Help Guide

© ZTE 2017 L110 Ver 1.0 July 2017

2

Get to Know Your Phone

Adding a memory card (optional)

The microSDHC memory card can be installed or removed
while the phone is turned on. You need to unmount the
microSDHC card before removing it.

Volume keys

Power key
Flash lamp

Charging/USB
jack

Headset jack

Camera

Speaker

Volume keys

Earpiece

Sensor

Front camera

Touch screen

Home key

Menu key

Back key

LED indicator
Power Key

Back cover

3

Insert your SIM card

WARNING!

To avoid damage to the phone do not use SIM adaptors. Only
insert a standard micro SIM from your service provider.

1. Insert your fingernail into the slot at the bottom left of the
back cover and lift it up gently.

2. Insert the micro SIM card with the cut corner as shown

The microSD memory card is an optional accessory

SIM slot

microSD
slot

4

3. Align the gold connectors on the phone and the battery
and insert the battery.

4. Replace the back cover.

Charging the Battery

The battery comes partially charged so connect the charger to
charge the battery fully.

WARNING!

Use only ZTE-approved chargers and cables. The use of
unapproved accessories could dam age your phone.

Always insert the charger lead carefully.
Check the plug and socket are aligned correctly.
Do NOT use excessive force which may damage the USB

port.
Be careful to avoid tripping on the lead whilst it is plugged in.
Physical damage to the USB port is not covered by warranty.

1.Connect the charger to a standard AC power outlet.

2.Disconnect the charger when the battery is fully charged.

Pow er On and Off

Press and hold the Power Key to turn on your phone.
When already on, press the Power Key to light up your

screen.
Press and hold the Power Key to open the options menu.

Touch “Power off”.

5

TIPS

For general usage of the Android operating system there are
many guides available on line.

Pull down from the top of the scr een tw ice to access the Quic k
Settings panel and press the cog w heel at the top for Set tings.

All Google apps use the three dots for Options in the app.
Press Options or long press on the Homescreen to add

widgets or change the wallpaper to customise your device.
Drag and drop an app from the apps tray to the Homescreen

as a quick shortcut to the app.
New apps downloaded from Play Store will be added to the

Homescreen automatically.

Settings

Pull down twice from the top of the screen and
press the Settings icon or go Apps > Settings

Wi-Fi Switch Wi-Fi on and off. Scan

and join Wi-Fi networks.

Bluetooth Switch Bluetooth on and off.

Connect to Bluetooth devices.

Data usage Switch Data on or off. Check

your data usage details.

More – Flight
mode

Default SMS
app

Switch off all radio functions for
use on aircraft.

You can change your default
SMS app if required.

Tethering &
portable
hotspot

Control USB & Bluetooth
tethering and your Wi-Fi
hotspot.

VPN Configure Virtual Private

Networks.

Hard key Swap the Back and Recent apps

keys if required.

Display Set your display brightness,

sleep time, wallpapers etc.

6

Audio
Profiles

Set your Ringtone,
Notifications, vibrate and other
settings.

Prompt &
notification

Change interruption and
notification prompts for
different features

Storage Check available storage on your

device. Check SD card if fitted.

Battery Check battery level and see

what is using your battery
power.

Apps Review and control Apps,

memory, running processes

Delete
Applications

Delete installed apps (note
stock apps cannot be
uninstalled)

Location Configure location based

services. Touch Mode for GPS
mode.

Security Set lock screen security,

encryption modes and
passwords.

Accounts Manage your Gmail and other

accounts.

Language &
input

Control handset, keyboard,
spelling language options.

Factory data
reset

Backup to Google and perform
a Factory Reset.

Timer Switch
Machine

Schedule your device to switch
on and off automatically.

Date & time Manually set date & time

options and set date & time
formats.

Accessibility Enable features such as large

font, text to speech etc.

7

Printing Connect to Google on line

printing services.

About phone Check phone model, software,

version, IMEI status etc.

Switch to sleep mode (turn off the
display)

The display will automatically dim and turn off
after a pre-set period of time (see Settings >
Display) to save power and prevent inadvertent
operations such as making phone calls in your
pocket. It is also good practice to manually switch
off the display after use. Press the Power key to
turn your screen on or off during normal use.

Wake up your phone

After the phone switches to sleep mode the
screen will be turned off and locked. Press the
power key to wake up your device.

1. Press the Power key to turn on the screen.

2. Slide the icon up to unlock the screen.
If you've set an unlock PIN, pattern or password,

you need to draw the unlock pattern or input the
password to enter the main interface.

Secure your device

Go to Settings > Security > Screen Lock to apply a
lock screen to your device. Locking your device
will prevent unauthorised use.

8

Make and answer calls

Make a call from the Dialler

On the home screen, touch the button to
open the Dialler. Touch a recently called number

or press to open the Dial Pad and touch
to make the call.

Make a call from Contacts

On the home screen, touch the Contacts
icon, touch the desired contact and touch the
phone number to make a call.

Make a call from Call log

On the home screen, touch the button, the
recents tab shows recent calls. Touch the phone
icon to make a call.

Make an international call

On the home screen, touch the button >

to display the dial pad. Press & hold the “0”
key to get the “+” symbol for international calls.
Enter the country code, area code and phone
number, dropping the leading zero as normal.

Dial from Messaging

1. On the home screen, touch the Messaging icon

2. Touch a message or conversation to select it

3. Touch the icon at the top of the phone to
dial.

Answer a call

Your phone will ring or vibrate (depending on your
current settings) for an incoming call.

9

- Slide the icon from middle to right to
answer the call.

- If you are using another application press the
Answer or Reject button displayed at the top of
the screen. If you inadvently dismiss this panel,
pull down the Notifications Panel to retrieve the
Answer Call panel.

- If the earphone is inserted, press the key on the
earphone to answer the call.

Reject a call

Slide the icon from middle to left to reject
the call.

End a call

Touch the button to hang up the call.

Adjust the volume

In a call, you can raise or lower the volume by
using the volume keys.

Turn the speaker on or off

In a call, touch the button to turn on the
speaker, and touch it again to turn off speaker.

Add a multi party or Conference
call

In a call, touch for Options then Add call. Dial
a number and touch the phone icon to add one
call and put the current caller on hold. Press
Options > Merge to join the two (or more) parties
together.

Use touch tones during a call for
automated call systems

Touch the

button to open the dial pad to

10

enter numbers during a call.

Contacts

You can place calls from the Phone app , the
Contacts app , or other apps or widgets that

display contact information. Wherever you see a
phone number or call icon, you can usually touch
it to dial.

The contacts interface can be divided into the
following tab pages:

- All Contacts: View the list of contacts.

- Favorites: Display the numbers you usually call.

All of your contacts are displayed alphabetically in
a scrollable list. Slide your finger up or down to
scroll through the list.

Add new contact

1. In Contacts, touch the add contacts icon
at the bottom right hand corner of the screen.

2. Select a memory location.

3. Input all contact information. Slide up to move
to the next field.

4. Touch the icon to save your contact.

Batch delete

1. In Contacts, touch the and then select
Delete contact.

2. Touch the contacts you want to delete or touch

, then touch the Done.

Edit contact details

1. In Contacts, touch the contact whose details
you want to edit.

11

2. Touch the .

3. Edit the contact information.

Search contacts

1. In Contacts, touch the icon.

2. Type a key word of a contact name. The phone
will automatically list all matched contacts.

Add a contact to Favorites

You can tap the contact you want to add to
favorites in the contact interface, and then touch

in the upper right corner to add it to

Favorites directly.

Import/Export contacts

1. In Contacts, touch the to select
Import/export.

2. You can select SIM card, Phone, Phone storage,
SD Card.

Share a contact

You can share a contact with someone.

1. In Contacts, tap the contact you want to share.

2. Touch the and then touch Share.

3. Select application with which to share
(Bluetooth

®

, Gmail, MMS, SMS and EMAIL).

Using Google Contacts

When you are signed into your Google account (ie
Gmail) all your existing Contacts are downloaded
and synced to your device. Also if you add a
Contact to your device, for example by importing
from your SIM card or entering a new Contact
manually, it is automatically synced to your Google
