ZTE F102 User Manual

0 (0)

F102

UMTS/GSM/GPRS Mobile Phone

User Manual

LEGAL INFORMATION

No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation.

The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice.

Version No. : R1.1

Edition Time: 20090825

Manual No. :

	F102 User Manual
Contents
For Your Safety ...........................................................................	7
General Care ..................................................................................................	7
Aircraft Safety .................................................................................................	9
Hospital Safety................................................................................................	9
General Guidelines .......................................................................................	10
Road Safety ..................................................................................................	14
Vehicles Equipped with an Airbag .................................................................	15
Third party equipment ...................................................................................	15
Emergency Services .....................................................................................	16
Information on the privacy .............................................................................	17
Copyright Notice ...........................................................................................	17
Introduction ...............................................................................	18
Overview.......................................................................................................	18
Key definition ................................................................................................	20
Technical parameters....................................................................................	23
Indicators and Icons ......................................................................................	24
Setting UP Your Phone.............................................................	27
Battery ..........................................................................................................	27
Installing the battery........................................................................................	27
Removing the battery......................................................................................	28
Charging the battery .......................................................................................	29
USIM card.....................................................................................................	30
Installing the USIM card..................................................................................	31
Removing the USIM card................................................................................	32
Micro SD Card ..............................................................................................	32
	3

Inserting the Micro SD card .............................................................................	33
Removing the Micro SD card...........................................................................	34
Accessing the Micro SD card on the phone .....................................................	34
Starting Up ....................................................................................................	34
Standby Mode ...............................................................................................	35
Signal strength ..............................................................................................	36

Basic Operations ......................................................................	37
Navigating the menus ....................................................................................	37
Making a call .................................................................................................	38
Making a Voice Call.........................................................................................	38
Making a Video Call ........................................................................................	38
Making an International Call ............................................................................	39
Call an Extension Number ...............................................................................	39
Call a Number from Contacts ..........................................................................	39
Call a Previous Dialed Number........................................................................	40
Call a Speed Dial Number ...............................................................................	40
Answering a call ............................................................................................	41
Answering a Voice Call....................................................................................	41
Answering a Video Call ...................................................................................	41
Setting Volume................................................................................................	41
Rejecting a Call...............................................................................................	41
Ending a Call...................................................................................................	42
Call Options ....................................................................................................	42
Locking/Unlocking your keypad .....................................................................	42
Locking the keypad .........................................................................................	43
Unlocking the keypad ......................................................................................	43
Text Input Modes...........................................................................................	43
Word Predictive Text Mode .............................................................................	44
4

	F102 User Manual
Alphabetic Mode.............................................................................................	45
Number Mode.................................................................................................	45
Inserting symbols............................................................................................	45
Menus.........................................................................................	46
Tools.............................................................................................................	46
Bluetooth ........................................................................................................	46
Alarm..............................................................................................................	48
Calendar.........................................................................................................	48
Stopwatch ......................................................................................................	51
World Time.....................................................................................................	51
Calculator .......................................................................................................	51
Currency Converter ........................................................................................	52
STK (SIM Tool Kit)..........................................................................................	53
Browser.........................................................................................................	53
Home .............................................................................................................	53
New Link ........................................................................................................	53
Bookmark .......................................................................................................	53
History............................................................................................................	54
Saved Page....................................................................................................	54
Settings ..........................................................................................................	54
Version...........................................................................................................	55
Games & apps ..............................................................................................	55
Options of Games & apps...............................................................................	56
Install Application............................................................................................	57
Contacts........................................................................................................	58
All...................................................................................................................	58
USIM, Friends, Family and Work ....................................................................	60
Messages .....................................................................................................	60
Message.........................................................................................................	60
	5

Calls ..............................................................................................................	65
Call log............................................................................................................	65
Calls info. ........................................................................................................	66
Settings .........................................................................................................	66
Screen ............................................................................................................	66
Handset ..........................................................................................................	67
Profiles............................................................................................................	68
Security...........................................................................................................	69
Call .................................................................................................................	71
Multimedia .....................................................................................................	72
Camera...........................................................................................................	73
Video camera..................................................................................................	74
Media player ...................................................................................................	75
Voice recorder.................................................................................................	76
Playlist ............................................................................................................	77
Slide show ......................................................................................................	78
Streaming URL................................................................................................	79
File manager .................................................................................................	80
Phone .............................................................................................................	80
Micro SD Card ................................................................................................	88
Questions & Answers ...............................................................	90
Glossary.....................................................................................	95
INFORMATION ON PRODUCTS DISPOSAL ...........................	96

F102 User Manual

For Your Safety

General Care

Your handset contains delicate electronic circuitry, magnets and battery systems. You should treat it with care and give particular attention to the following points:

Do not allow the handset, battery or accessories to come into contact with liquids or moisture at any time. Do not immerse the handset in any liquid.

Do not place the handset alongside computer disks, credit cards, travel cards and other magnetic media. The information contained on disks or cards may be affected by the handset.

Do not paint the handset.

Do not leave the handset or the battery in places where the temperature could exceed 60°C, e.g. on a car dashboard or a windowsill, behind glass in direct sunlight, etc.

Do not remove the handset‟s battery while the handset is switched on.

Take care not to allow metal objects, such as coins or key rings to contact or short-circuit the battery terminals.

Do not dispose of battery in a fire. The handset‟s Li-ION batteries may be safely disposed of at a Li-ION recycling point. Follow local requirements for recycling.

Do not put the handset‟s battery in your mouth, as battery electrolytes may be poisonous if swallowed.

Do not attempt to dismantle the handset or any of its accessories.

Do not put a battery into a microwave oven, dryer, or high-pressure container.

Do not contact battery directly to an electric outlet or cigarette lighter charger. Use only approved charger units.

Do not pierce battery with a sharp object such as a needle.

Do not disassemble or modify the battery.

Do not use a damaged or deformed battery.

Do not drop, throw, or subject the handset to rough treatment.

Do not solder the battery directly.

Stop using the battery if abnormal heat, odor, discoloration, deformation, or abnormal condition is detected during use, charge, or storage.

Remove the battery whose life cycle has expired from equipment immediately.

This equipment is fitted with an internal battery. Take it to a qualified service engineer when the replacement of the battery is required.

The earpiece may become warm during normal use. Also, the handset itself may become warm while the battery is being charged.

When a handset is in vibration mode, the vibration can sometimes cause the handset to move.

Be careful not to place the handset near heat sources (such as a heater) or too close to the edge of the table.

Power off your phone before you clean it. Use a damp or anti-static cloth to clean the handset. Do not use an ordinary dry cloth or electrostatic cloth. Do not use chemical or abrasive cleaners as these could damage the casing.

Remember to make backup copies of all important data on your handset.

F102 User Manual

Remember to recycle: the cardboard packing supplied with this handset is ideal for recycling.

Warning:

In the unlikely event of a battery leak, take care to keep the battery discharge away from your eyes or skin. If the leakage does come into contact with the eyes or skin, please flush thoroughly in clean water and consult with a doctor.

Aircraft Safety

Power off your phone before the airplane takes off. In order to protect airplane‟s communication system from interference, it is prohibited to use mobile phone in flight. If you want to use mobile phone before the airplane takes off, you should get aircrew‟s permission according to safety regulations.

If the mobile phone has the function of automatic timing power-on, please check your alarm setting to ensure that your phone will not be automatically powered on during the flight.

Hospital Safety

Power off your phone and remove the battery in areas where the use of handsets is prohibited.

Follow the instructions given by the respective medical facility regarding the use of handsets on their premises.

General Guidelines

In some countries, national law prohibits private copying of copyrighted material. Please check the national legislation of the applicable country concerning the use of such material.

Many jurisdictions have laws and regulations about taking pictures in public or private areas and regarding the processing and further use of such pictures. The manufacturer encourages its customers to obey all laws and to respect the personal rights of others.

Please check roaming agreement availability with your service provider.

The use of mobile phones is not allowed in some radiation sensitive areas, such as hospitals, research centers and airplanes. The user is responsible to power-off the device. If there is any uncertainty, you should remove the battery from the handset.

Observe any signs that indicate powering off handsets, such as those near gas stations, or explosives, and power off the handset/device immediately.

If you have a heart condition, be careful with the settings of call vibration or tone volume.

Do not allow children to play with the handset, charger or batteries.

Do not use the handset where blasting is in progress.

Do not try to make a call or conversation while the temperature of charging battery is above 50°C.

Take care not to put your handset in the back pocket of your trousers or skirt and then sit on it. Also, do not put your phone at the bottom of bag where it may

F102 User Manual

subject to excessive weight or pressure. Doing so may damage the LCD and camera lens and cause them malfunction.

The operation of some medical electronic devices, such as hearing aids and pacemakers, may be affected if a handset is used next to them. Observe any caution signs and the manufacturer‟s recommendations.

Do not leave the handset discharged or without a battery for a long time, otherwise some data may be erased.

Your phone contains metal, which may cause you an itch, a rash or eczema depending on your physical condition.

RF Exposure

General Statement on RF Energy

Your phone contains a transmitter and a receiver. When it is ON, it receives and transmits RF energy. When you communicate with your phone, the system handling your call controls the power level at which your phone transmits.

Radio Frequency (RF) Energy

This model phone meets the government‟s requirements for exposure to radio waves.

This phone is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government:

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.

Tests for SAR are conducted using standard operating positions accepted by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.

The highest SAR value for this model phone as reported to the FCC when tested for use at the ear is 1.42 W/kg and when worn on the body, as described in this user guide, is 1.34 W/kg (Body-worn measurements differ among phone models, depending upon available enhancements and FCC requirements.)

While there may be differences between the SAR levels of individual VF945 phones and at various positions, they all meet the government requirement.

The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/ea/fccid after searching on

FCC ID: Q78-ZTEF102

For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines for use with an accessory that contains no metal and that positions the handset a minimum of 1.5 cm from the body. Use of other enhancements may not ensure compliance with FCC RF exposure guidelines. If you do not use a body-worn accessory and are not holding the phone at the ear, position the handset a minimum of 1.5 cm from your body when the phone is switched on.

F102 User Manual

FCC Compliance

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

Caution: Changes or modifications not expressly approved by the manufacturer could void the user‟s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Body-worn Operation

Important safety information regarding radio frequency radiation (RF) exposure:

To ensure compliance with RF exposure guidelines the phone must be used with a minimum of 15 mm separation from the body.

Failure to observe these instructions could result in your RF exposure exceeding the relevant guideline limits.

Limiting Exposure to Radio Frequency (RF) Fields

For individuals concerned about limiting their exposure to RF fields, the World Health Organization (WHO) provides the following advice:

Precautionary measures: Present scientific information does not indicate the need for any special precautions for the use of mobile phones. If individuals are concerned, they might choose to limit their own or their children‟s RF exposure by limiting the length of calls, or using „hands-free‟ devices to keep mobile phones away from the head and body.

Further information on this subject can be obtained from the WHO home page http://www.who.int/peh-emf WHO Fact sheet 193: June 2000.

Road Safety

You must exercise proper control of your vehicle at all times. Give your full attention to driving.

Observe all of the recommendations contained in your local traffic safety documentation.

F102 User Manual

Pull off the road and park before making or answering a call, if driving conditions require so. Check if local laws and/or regulations restrict the use of handsets while driving.

You MUST NOT stop on the hard shoulder of a motorway to answer or make a call, except in an emergency.

Power off your handset at a refueling point, such as a gas station, even if you are not refueling your own car.

Do not store or carry flammable or explosive materials in the same compartment as the handset.

Electronic systems in vehicle, such as anti-lock brakes, speed control and fuel injection systems are not normally affected by radio transmissions. The manufacturer of such equipment can advise if it is adequately shielded from radio transmissions. If you suspect vehicle problems caused by radio transmissions, consult your dealer and do not power on the handset until it has been checked by a qualified technician.

Vehicles Equipped with an Airbag

An airbag inflates with great force. Do not place objects, including either installed or portable wireless equipment, in the area over the airbag or in the airbag deployment area. If in-vehicle wireless equipment is improperly installed and the airbag inflates, serious injury could result.

Third party equipment

The use of third party equipment, cables or accessories, not made or authorized by ZTE, may invalidate the warranty of your handset and also adversely affect the

phone‟s safety/operation.

Emergency Services

To make an emergency call in any country:

1.Ensure that your handset is on and in service.

2.Press End Key as many times as needed to clear the display and ready the device for calls.

3.Enter the official emergency number for your present location, for example, 112 (the international emergency number).

4.Press Send Key to dial the number. Follow instructions received and do not end the call until told to do so.

When the USIM card is not inserted, press Right Soft Key [SOS] and then enter the official emergency number for your present location. Press Send Key or OK Key [Call] to dial the number. If the dial lock is on, enter the emergency number directly and press Send Key.

Notes:

Tell the operator which service you require: Police, Ambulance, Fire Brigade, Coastguard or Mountain Rescue Service. Tell them where you are and remain stationary to maintain contact if possible.

Due to the nature of the cellular system, the connection of emergency calls cannot be guaranteed. You should never rely solely on any wireless device for essential communications like medical emergencies.

F102 User Manual

Information on the privacy

Camera usage and photo/audio/video recordings carried out with the handset can offend the confidentiality of the subjects. The user therefore is held to respect legislation in confidentiality matter and remains the only responsible subject in case of eventual violations of the enforced norm.

The video/audio recordings you make/download are protected by copyright laws. They are for personal use only and must not be otherwise used without the permission of the copyright owner.

Introduction

Overview

Thank you for purchasing the F102 UMTS/GSM/GPRS Mobile Phone.

The F102 is a mobile phone operating in UMTS (Universal Mobile Telecommunication System), known as 3G, GSM (Global System for Mobile Communications) or 2G, and GPRS (General Packet Radio Service) or 2.5G networks and achieves seamless handover between different networks.

Empowered by the latest 3G technology, F102 is so powerful and versatile, it converges real-life experiences with real-time connectivity by sharing your daily highlights.

This F102Mobile phone is also equipped with high-end business tools that will enhance your professional life. Enjoy the feature of high-speed, broadband-quality connectivity wherever you go.

F102 User Manual

Key definition

Left Soft Key

- Execute prompts that appear in the lower left corner of the screen directly above it. These prompts change according to the screen content.

F102 User Manual

Right Soft Key

- Execute prompts that appear in the lower right corner of the screen directly above it. These prompts change according to the screen content.

Send Key

Press to send or answer calls.

In standby mode: Press to show all calls.

End Key

Press and hold to turn the phone on/off.

Press to end a call.

Press to reject an incoming call.

Press to cancel dialing.

Press to return to standby mode.

Navigation Keys (Up/Down/Left/ Right Key)

In standby mode: Used as shortcut keys to enter the designated functions.

In lists, messages and menus: scroll up, down, left and right.

OK Key

In standby mode: Press to open the main menu.

In lists and menus: Start an application/function.

Dedicated Switch Key

Press to enter Task Manager Screen, from which you can view or manage the events and running applications. You can also set the shortcut keys.

C Key

Return to the previous screen, except in the cases when deletable items are selected, in which it is to delete the selected items.

Delete text in the text editor.

Delete the selected items

Alphanumeric Keys ~

Press to enter numbers.

In standby mode: Press and hold ~ to start speed dial.

F102 User Manual

* Key

Press to enter "*".

Press and hold to lock the keypad.

In an editing screen: Press to input punctuation and symbols.

# Key

Press to enter "#".

In an editing screen: Press to change the input method.

In standby mode: Long press to activate silent mode with vibration.

Technical parameters

Handset

Type	F102

Dimensions W×L×H	47mm×105.7mm×12.6mm

Weight	Approximately 80g (with a 1000 mAh battery)

Battery	1000mAh, Lithium ion ( Li-ion )

Continuous standby time	Minimum 150 hours ( subject to network status )

Continuous talk time ( UMTS )	Minimum 300 minutes( subject to network status )

Continuous talk time ( GSM )	Minimum 240 minutes( subject to network status )

Continuous video call time	Minimum 180 minutes( subject to network status )

Notes:

The phone‟s talk and standby time are based on ideal working environments. The use of extended backlighting, browser, and network conditions can reduce battery life and talk/standby time.

Indicators and Icons

Indicates the 3G signal strength.

Indicates the 2.5G signal strength.

Indicates you have new text messages.

Indicates you have new multimedia messages.

Indicates you have new PUSH messages.

F102 User Manual

Indicates your message Inbox is full.

Indicates the data communication in progress.

Indicates call divert (Always) is active.

Indicates you have missed voice calls.

Indicates you have missed video calls.

Indicates the alarm clock has been set.

Indicates the amount of charge in your battery.

Indicates low battery.

Indicates Bluetooth is active.

Indicates your earphone is inserted.

Earphone and vibrate mode.

Indicates the vibration mode is activated.

Indicates the ringtone is set to shut-off.

Indicates the meeting mode is activated.

Indicates you are roaming.

F102 User Manual

Setting UP Your Phone

Battery

The accessory lithium battery of the handset can be immediately used after unpacking. A new battery will have the best performance after full charge/discharge cycles for the first three times.

Installing the battery

1. Insert the battery carefully with the contacts located against the gold springs.

2.Push down the battery until it clicks into place.

3.Install the battery cover.

Notes:

The phone automatically switches off if the battery voltage is too low.

When not using the battery for a long period, remove it from the phone and store it in a cool dry place.

Removing the battery

1.Make sure the power is off.

2.Remove the back cover of your phone.

i.Use a fingernail to hook the edge of the cover, as shown in the picture.

ii.Lift the cover up to remove it.

F102 User Manual

3.Lift the battery away from the phone.

i.Use a fingernail to hook the edge of the battery, as shown in the picture.

ii.Lift the battery up to remove it.

Charging the battery

Your phone is powered by a rechargeable battery. The battery is not fully charged when first unpacked, but there may be enough power to power your phone on. You should use it up completely before charging the battery for the first time. Charge the battery with the procedure indicated below.

1.Insert the charger‟s USB adapter into the USB port. See the following picture.

2.Connect the charger to a standard AC wall outlet.

3.Remove the charger from both the wall outlet and the phone once the charging completed.

+ 67 hidden pages
