ZTE F100
User Manual
ZTE CORPORATION
NO.55, Hi-tech Road South, ShenZhen, P. R. China
Postcode: 518057
Tel: (86) 755 26779999
URL: http://www.zte.com.cn
E-mail: mobile@zte.com.cn
LEGAL INFORMATION
Copyright © 2010 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by
any means, electronic or mechanical, including photocopying and microfilm, without the prior
written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to make modifications on print
errors or update specifications without prior notice.
Version No. : R1.0
Edition Time : 20100115
Manual No. :
Contents
Contents ................................................................................................................................ 3
For Your Safety ..................................................................................................................... 6
General Care ..................................................................................................................... 6
Aircraft Safety ................................................................................................................... 7
Hospital Safety .................................................................................................................. 7
General Guidelines ............................................................................................................ 7
Road Safety ....................................................................................................................... 7
Vehicles Equipped with an Airbag ................................................................................... 8
Third Party Equipment ...................................................................................................... 8
Radio Frequency (RF) Energy .......................................................................................... 8
FCC Compliance ............................................................................................................... 9
Emergency Services .......................................................................................................... 9
Information on the Privacy ............................................................................................... 9
Copyright Notice ............................................................................................................... 9
Introduction ......................................................................................................................... 11
Overview ......................................................................................................................... 11
Key Definition................................................................................................................. 12
Technical Parameters ...................................................................................................... 13
Indicators and Icons ........................................................................................................ 14
Setting Up Your Phone ....................................................................................................... 15
Battery ............................................................................................................................. 15
Installing the battery.................................................................................................... 15
Removing the battery .................................................................................................. 16
Charging the battery .................................................................................................... 17
(U)SIM card .................................................................................................................... 18
Installing the (U)SIM card .......................................................................................... 18
Removing the (U)SIM card ......................................................................................... 19
microSD Card ................................................................................................................. 19
Inserting the microSD card ......................................................................................... 19
Removing the microSD card ....................................................................................... 20
Accessing the microSD card on the phone ................................................................. 20
Starting Up ...................................................................................................................... 20
Standby Mode ................................................................................................................. 21
Signal Strength ................................................................................................................ 21
Basic Operations ................................................................................................................. 22
Navigating the Menus ..................................................................................................... 22
Making a Call .................................................................................................................. 22
Making a Voice Call ................................................................................................... 22
Making a Video Call ................................................................................................... 22
Making an International Call ...................................................................................... 23
Calling an Extension Number ..................................................................................... 23
Calling a Number from Phonebook ............................................................................ 23
Calling a Previous Dialed Number ............................................................................. 23
Calling a Speed Dial Number ..................................................................................... 23
Answering a Call ............................................................................................................. 24
Answering a Voice Call .............................................................................................. 24
Answering a Video Call .............................................................................................. 24
Setting Volume ........................................................................................................... 24
Rejecting a Call ........................................................................................................... 24
Ending a Call ............................................................................................................... 24
Call Options ................................................................................................................ 24
Locking/Unlocking Your Keypad ................................................................................... 24
Locking the Keypad .................................................................................................... 25
Unlocking the Keypad ................................................................................................ 25
Text Entry ........................................................................................................................... 26
Text Input Modes ............................................................................................................ 26
Word Predictive Text Mode ........................................................................................ 26
Alphabetic Mode ......................................................................................................... 26
Number Mode ............................................................................................................. 27
Inserting Symbols ....................................................................................................... 27
Menus .................................................................................................................................. 28
Messages ......................................................................................................................... 28
Messages ..................................................................................................................... 28
E-mail .......................................................................................................................... 30
Games.............................................................................................................................. 31
STK ( SIM Tool Kit ) ...................................................................................................... 32
Camera ............................................................................................................................ 32
Services ........................................................................................................................... 33
Home ........................................................................................................................... 33
New Link..................................................................................................................... 33
Bookmark .................................................................................................................... 33
History ......................................................................................................................... 34
Saved Page .................................................................................................................. 34
Settings ........................................................................................................................ 34
Version ........................................................................................................................ 34
Multimedia ...................................................................................................................... 34
Camera ........................................................................................................................ 34
Video camera .............................................................................................................. 34
FM radio ...................................................................................................................... 34
Media player ............................................................................................................... 35
Voice recorder ............................................................................................................. 36
Playlist ......................................................................................................................... 36
Slide show ................................................................................................................... 37
Streaming URL ........................................................................................................... 37
Applications .................................................................................................................... 37
Tools............................................................................................................................ 37
Calls ............................................................................................................................ 41
File Manager ............................................................................................................... 41
Phonebook ....................................................................................................................... 46
All................................................................................................................................ 46
(U)SIM, Mates, Family, Friends, Work, VIP and Unclassified .................................. 46
Settings ............................................................................................................................ 46
Screen .......................................................................................................................... 46
Handset........................................................................................................................ 47
Profiles ........................................................................................................................ 47
Security ....................................................................................................................... 48
Call .............................................................................................................................. 49
Questions & Answers.......................................................................................................... 50
Glossary .............................................................................................................................. 52
INFORMATION ON PRODUCTS DISPOSAL ................................................................ 53
Declaration of RoHS Compliance....................................................................................... 54
Confidential and Proprietary Information of ZTE CORPORATION 6
C h a p t e r 1
For Your Safety
General Care
Your handset contains delicate electronic circuitry, magnets and battery systems. You should treat it with
care and give particular attention to the following points:
• Do not allow the handset, battery or accessories to come into contact with liquids or moisture at any time.
Do not immerse the handset in any liquid.
• Do not place the handset alongside computer disks, credit cards, travel cards and other magnetic media.
The information contained on disks or cards may be affected by the handset.
• Do not paint the handset.
• Do not leave the handset or the battery in places where the temperature could exceed 60°C, e.g. on a car
dashboard or a windowsill, behind glass in direct sunlight, etc.
• Do not remove the handset‟s battery while the handset is switched on.
• Take care not to allow metal objects, such as coins or key rings to contact or short-circuit the battery
terminals.
• Do not dispose of battery in a fire. The handset‟s Li-ION batteries may be safely disposed of at a Li-ION
recycling point. Follow local requirements for recycling.
• Do not put the handset‟s battery in your mouth, as battery electrolytes may be poisonous if swallowed.
• Do not attempt to dismantle the handset or any of its accessories.
• Do not put a battery into a microwave oven, dryer, or high-pressure container.
• Do not contact battery directly to an electric outlet or cigarette lighter charger. Use only approved
charger units.
• Do not pierce battery with a sharp object such as a needle.
• Do not disassemble or modify the battery.
• Do not use a damaged or deformed battery.
• Do not drop, throw, or subject the handset to rough treatment.
• Do not solder the battery directly.
• Stop using the battery if abnormal heat, odor, discoloration, deformation, or abnormal condition is
detected during use, charge, or storage.
• Remove the battery whose life cycle has expired from equipment immediately.
• This equipment is fitted with an internal battery. Take it to a qualified service engineer when the
replacement of the battery is required.
• The earpiece may become warm during normal use. Also, the handset itself may become warm while the
battery is being charged.
• When a handset is in vibration mode, the vibration can sometimes cause the handset to move.
• Be careful not to place the handset near heat sources (such as a heater) or too close to the edge of the
table.
• Power off your phone before you clean it. Use a damp or anti-static cloth to clean the handset. Do not
use an ordinary dry cloth or electrostatic cloth. Do not use chemical or abrasive cleaners as these could
ZTE F100 User Manual
Confidential and Proprietary Information of ZTE CORPORATION 7
damage the casing.
• Remember to make backup copies of all important data on your handset.
• Remember to recycle: the cardboard packing supplied with this handset is ideal for recycling.
Warning:
In the unlikely event of a battery leak, take care to keep the battery discharge away from your eyes or skin.
If the leakage does come into contact with the eyes or skin, please flush thoroughly in clean water and
consult with a doctor.
Aircraft Safety
• Power off your phone before the airplane takes off. In order to protect airplane‟s communication system
from interference, it is prohibited to use mobile phone in flight. If you want to use mobile phone before
the airplane takes off, you should get aircrew‟s permission according to safety regulations.
• If the mobile phone has the function of automatic timing power-on, please check your alarm setting to
ensure that your phone will not be automatically powered on during the flight.
Hospital Safety
• Power off your phone and remove the battery in areas where the use of handsets is prohibited.
• Follow the instructions given by the respective medical facility regarding the use of handsets on their
premises.
General Guidelines
• In some countries, national law prohibits private copying of copyrighted material. Please check the
national legislation of the applicable country concerning the use of such material.
• Please check roaming agreement availability with your service provider.
• The use of mobile phones is not allowed in some radiation sensitive areas, such as hospitals, research
centers and airplanes. The user is responsible to power-off the device. If there is any uncertainty, you
should remove the battery from the handset.
• Observe any signs that indicate powering off handsets, such as those near gas stations, or explosives, and
power off the handset/device immediately.
• If you have a heart condition, be careful with the settings of call vibration or tone volume.
• Do not allow children to play with the handset, charger or batteries.
• Do not use the handset where blasting is in progress.
• Do not try to make a call or conversation while the temperature of charging battery is above 50°C.
• Take care not to put your handset in the back pocket of your trousers or skirt and then sit on it. Also, do
not put your phone at the bottom of bag where it may subject to excessive weight or pressure.
• The operation of some medical electronic devices, such as hearing aids and pacemakers, may be affected
if a handset is used next to them. Observe any caution signs and the manufacturer‟s recommendations.
• Do not leave the handset discharged or without a battery for a long time, otherwise some data may be
erased.
• Your phone contains metal, which may cause you an itch, a rash or eczema depending on your physical
condition.
Road Safety
• You must exercise proper control of your vehicle at all times. Give your full attention to driving.
• Observe all of the recommendations contained in your local traffic safety documentation.
ZTE F100 User Manual
8 Confidential and Proprietary Information of ZTE CORPORATION
• Pull off the road and park before making or answering a call, if driving conditions require so. Check if
local laws and/or regulations restrict the use of handsets while driving.
• You MUST NOT stop on the hard shoulder of a motorway to answer or make a call, except in an
emergency.
• Power off your handset at a refueling point, such as a gas station, even if you are not refueling your own
car.
• Do not store or carry flammable or explosive materials in the same compartment as the handset.
• Electronic systems in vehicle, such as anti-lock brakes, speed control and fuel injection systems are not
normally affected by radio transmissions. The manufacturer of such equipment can advise if it is
adequately shielded from radio transmissions. If you suspect vehicle problems caused by radio
transmissions, consult your dealer and do not power on the handset until it has been checked by a
qualified technician.
Vehicles Equipped with an Airbag
An airbag inflates with great force. Do not place objects, including either installed or portable wireless
equipment, in the area over the airbag or in the airbag deployment area. If in-vehicle wireless equipment
is improperly installed and the airbag inflates, serious injury could result.
Third Party Equipment
The use of third party equipment, cables or accessories, not made or authorized by network operator, may
invalidate the warranty of your handset and also adversely affect the phone‟s safety/operation.
Radio Frequency (RF) Energy
This model phone meets the government‟s requirements for exposure to radio waves.
This phone is designed and manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission of the U.S. Government:
The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. *Tests for SAR are conducted using
standard operating positions accepted by the FCC with the phone transmitting at its highest certified
power level in all tested frequency bands. Although the SAR is determined at the highest certified power
level, the actual SAR level of the phone while operating can be well below the maximum value. This is
because the phone is designed to operate at multiple power levels so as to use only the poser required to
reach the network. In general, the closer you are to a wireless base station antenna, the lower the power
output.
The highest SAR value for the model phone as reported to the FCC when tested for use at the ear is
1.43W/kg and when worn on the body, as described in this user guide, is 1.45W/kg (Body-worn
measurements differ among phone models, depending upon available enhancements and FCC
requirements.)
While there may be differences between the SAR levels of various phones and at various positions, they
all meet the government requirement.
The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone
is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid
after searching on
FCC ID: Q78-ZTEF100
For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines for use
with an accessory that contains no metal and the positions the handset a minimum of 1.5 cm from the
body. Use of other enhancements may not ensure compliance with FCC RF exposure guidelines. If you do
not use a body-worn accessory and are not holding the phone at the ear, position the handset a minimum
ZTE F100 User Manual
Confidential and Proprietary Information of ZTE CORPORATION 9
of 1.5 cm from your body when the phone is switched on.
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user„s authority to operate the equipment.
The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Emergency Services
To make an emergency call in any country:
1. Ensure that your handset is on and in service.
2. Press End Key as many times as needed to clear the display and ready the device for calls.
3. Enter the official emergency number for your present location, for example, 112 (the international
emergency number).
4. Press Send Key to dial the number. Follow instructions received and do not end the call until told to do
so.
When the (U)SIM card is not inserted, press Right Soft Key [SOS] and then enter the official emergency
number for your present location. Press Send Key or OK Key [Call] to dial the number.
Notes:
• Tell the operator which service you require: Police, Ambulance, Fire Brigade, Coastguard or Mountain
Rescue Service. Tell them where you are and remain stationary to maintain contact if possible.
• Due to the nature of the cellular system, the connection of emergency calls cannot be guaranteed. You
should never rely solely on any wireless device for essential communications like medical emergencies.
Information on the Privacy
Audio recordings carried out with the handset can offend the confidentiality of the subjects. The user
therefore is held to respect legislation in confidentiality matter and remains the only responsible subject in
case of eventual violations of the enforced norm.
Copyright Notice
The audio recordings you make/download are protected by copyright laws. They are for personal use only
ZTE F100 User Manual
10 Confidential and Proprietary Information of ZTE CORPORATION
and must not be otherwise used without the permission of the copyright owner.
Confidential and Proprietary Information of ZTE CORPORATION 11
Earpiece
Display Screen
Navigation Keys
OK Key
Left Soft Key
Back Key
Send Key
Alphanumeric
Keypad
Right Soft Key
Clear Key
End (Power) Key
Front Camera
C h a p t e r 2
Introduction
Overview
Thank you for purchasing the F100 WCDMA/GSM/GPRS Mobile Phone.
This F100 is a mobile phone operating in UMTS (Universal Mobile Telecommunication System), known
as 3G, GSM (Global System for Mobile Communications) or 2G, and GPRS (General Packet Radio
Service) or 2.5G and achieves seamless handover between different networks.
Empowered by the latest 3G technology, F100 is so powerful and versatile, it converges real-life
experiences with real-time connectivity by sharing highlights of your day.
ZTE F100 User Manual
12 Confidential and Proprietary Information of ZTE CORPORATION
Left Soft Key
- Execute prompts that appear in the lower left corner of the screen directly above it. These prompts change according to the
screen content.
Right Soft Key
- Execute prompts that appear in the lower right corner of the screen directly above it. These prompts change according to
the screen content.
Send Key
• Press to send or answer calls.
• In standby mode: Press to show all calls.
End Key
• Press and hold to turn the phone on/off.
• Press to end a call.
• Press to reject an incoming call.
• Press to cancel dialing.
Navigation Keys (Up/Down/Left/ Right Key) and center OK Key
Loud Speaker
Earphone Jack
Memory
Card Slot
Charger/USB
Jack
Back Cover
Back
Camera
Key Definition
ZTE F100 User Manual
Confidential and Proprietary Information of ZTE CORPORATION 13
Navigation Keys
• In standby mode: Used as shortcut keys to enter the designated functions.
• In lists, messages and menus: scroll up, down, left and right.
OK Key
• In standby mode: Press to open the web browser and access to a certain web page.
• In lists and menus: Start an application/function.
Back Key
• Return to the previous screen.
Clear Key
• Delete the selected items
• Delete text in the text editor.
Alphanumeric Keys ~
• Press to enter alphabet or numbers.
• In standby mode: Press and hold 2 to 9 key to start speed dial.
Press and hold 1key to call the voicemail number.
* Key
• Press to enter "*".
• Press and hold * key and then press the right soft key to lock the keypad.
• In an editing screen: Press to input punctuation and symbols.
# Key
• Press to enter "#".
• In an editing screen: Press to change the input method.
• In standby mode: Press and hold to activate silent mode with vibration.
Technical Parameters
Handset
Type
F100
Dimensions（W×L×H）
46mm×106mm×13.6mm
Weight
Approximately 80g (with a 1000 mAh battery)
Battery
1000mAh, Lithium ion ( Li-ion )
Continuous standby time ( WCDMA )
Minimum 280 hours ( subject to network status )
Continuous standby time ( GSM )
Minimum 220 hours ( subject to network status )
ZTE F100 User Manual
14 Confidential and Proprietary Information of ZTE CORPORATION
Continuous voice talk time ( WCDMA )
Minimum 300 minutes ( subject to network status )
Continuous voice talk time ( GSM )
Minimum 240 minutes ( subject to network status )
Continuous video talk time (WCDMA)
Minimum 180 minutes ( subject to network status )
Notes:
Indicates the 3G signal strength.
Indicates the GSM/GPRS signal strength.
Indicates the data communication is available.
Indicates the data communication in progress.
Indicates you have new text messages.
Indicates you have new multimedia messages.
Indicates you have new E-mails.
Indicates your text messages Inbox is full.
Indicates you are roaming.
Indicates the amount of charge in your battery.
Indicates you have missed calls.
Indicates call divert is active.
Indicates the ringtone is set to shut-off.
Indicates your earphone is inserted.
Indicates Earphone and vibrate mode is activated.
Indicates the outdoor mode is activated.
Indicates the meeting mode is activated.
Indicates the alarm clock has been set.
The phone‟s talk and standby time are based on ideal working environments. The use of extended
backlighting, browser, and network conditions can reduce battery life and talk/standby time.
Indicators and Icons
ZTE F100 User Manual
Confidential and Proprietary Information of ZTE CORPORATION 15
C h a p t e r 3
Setting Up Your Phone
Battery
The accessory lithium battery of the handset can be immediately used after unpacking. A new battery will
have the best performance after full charge/discharge cycles for the first three times.
Installing the battery
1. Insert the battery carefully with the contacts located against the gold springs.
2. Push down the battery until it clicks into place.
3. Install the battery cover.
ZTE F100 User Manual
16 Confidential and Proprietary Information of ZTE CORPORATION
Notes:
• The phone automatically switches off if the battery voltage is too low.
• When not using the battery for a long period, remove it from the phone and store it in a cool dry place.
Removing the battery
1. Make sure the power is off.
2. Remove the back cover of your phone.
3. Use a fingernail to hook the edge of the battery and lift it away from the phone.
ZTE F100 User Manual
Confidential and Proprietary Information of ZTE CORPORATION 17
Charging the battery
Your phone is powered by a rechargeable battery. The battery is not fully charged when first unpacked,
but there may be enough power to power your phone on. You should use it up completely before charging
the battery for the first time. Charge the battery with the procedure indicated below.
1. Insert the charger‟s USB adapter into the USB port. See the following pictures.
2. Connect the charger to a standard AC wall outlet.
3. Remove the charger from both the wall outlet and the phone once the charging is completed.
Loading...
