ZTE C78

CDMA 1X Digital Mobile Phone

User Manual

C78 User Manual

No part of this publication may be excerpted, reproduced, translated, or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation.

ZTE Corporation operates a policy of continuous development. ZTE Corporation reserves the right to make changes and improvements to any of the products described in this document without prior notice.

Release: V1.0

Manual number: 079584500746

2009.11.18

		C78 User Manual
	Contents
1.	For Your Safety........................................................................	10
	General Care ..........................................................................................................	10
	Aircraft Safety .........................................................................................................	12
	Hospital Safety........................................................................................................	13
	General Guidelines .................................................................................................	13
	Road Safety ............................................................................................................	14
	Vehicles Equipped with an Airbag ..........................................................................	15
	Third Party Equipment ............................................................................................	15
	Efficient Use............................................................................................................	16
	Radio Frequency (RF) Energy................................................................................	16
	Emergency Services...............................................................................................	17
	FCC Notice .............................................................................................................	18
	IC Notice .................................................................................................................	19
2.	Introduction .............................................................................	20
	Overview.................................................................................................................	20
	What’s Included ......................................................................................................	21
	C78 Technical Specifications..................................................................................	21
	Phone at a Glance ..................................................................................................	22
	Key Definitions........................................................................................................	23
	User Interface .........................................................................................................	25

C78 User Manual

Indicators and Icons ...............................................................................................	26
3. Set up Your Phone ..................................................................	27
Battery ....................................................................................................................	27
Install the Battery ..............................................................................................	27
Charge the Battery............................................................................................	28
Remove the Battery ..........................................................................................	30
Power On/Off Your Phone......................................................................................	31
Keyguard Mode ......................................................................................................	31
Connect to the Network..........................................................................................	32
Activate Your Phone...............................................................................................	32
4. Basic Operations.....................................................................	33
Make Voice Calls....................................................................................................	33
Use the Keypad ................................................................................................	33
Use the Contacts List........................................................................................	33
Use the Last Number Dialed.............................................................................	34
Use the Number from the Call History ..............................................................	34
Use Speed Dials ...............................................................................................	35
Answer Voice Calls ................................................................................................	35
In-Call Features......................................................................................................	36
Three-Way Call ......................................................................................................	37
Call Waiting ............................................................................................................	38

		C78 User Manual
5.	Entering Text	...........................................................................39
	Key Functions .........................................................................................................	39
	Text Input Modes ....................................................................................................	40
6.	Contacts ...................................................................................	43
	Contact List.............................................................................................................	44
	New Contact ...........................................................................................................	45
	Groups ....................................................................................................................	46
	Speed Dials ............................................................................................................	46
7.	Calls ..........................................................................................	47
	All Calls...................................................................................................................	47
	Missed Calls ...........................................................................................................	47
	Incoming Calls ........................................................................................................	48
	Outgoing Calls ........................................................................................................	48
	Call Timers..............................................................................................................	48
8.	Messaging................................................................................	49
	Send New ...............................................................................................................	49
	Save To Drafts ..................................................................................................	50
	Quick Text .........................................................................................................	50
	Signature ...........................................................................................................	51
	Message Priority ...............................................................................................	51
	Inbox .......................................................................................................................	51

C78 User Manual

	Read a Message...............................................................................................	51
	Reply to a Message ..........................................................................................	52
Outbox....................................................................................................................		52
Drafts......................................................................................................................		52
Sent ........................................................................................................................		53
Saved .....................................................................................................................		53
Voice Mail...............................................................................................................		53
Settings ..................................................................................................................		54
	Message Settings .............................................................................................	54
	Quick Text Settings...........................................................................................	55
Memory Info ...........................................................................................................		55
9.	Alarm Clock .............................................................................	56
	Edit an Alarm ....................................................................................................	56
	Alarm Options ...................................................................................................	57
10.	Camera .....................................................................................	58
	Take Pictures....................................................................................................	58
	View Your Photos .............................................................................................	59
11.	Media ........................................................................................	60
Camera...................................................................................................................		60
MyTunes.................................................................................................................		60
	Play Your Tunes ...............................................................................................	61

		C78 User Manual
	Manage Your Tunes..........................................................................................	61
MyImages ...............................................................................................................		62
	View Your Image ...............................................................................................	62
	Manage Your Images ........................................................................................	62
Preloaded Files.......................................................................................................		63
	Tunes ................................................................................................................	63
	Images...............................................................................................................	63
Memory Info............................................................................................................		64
12.	Games ......................................................................................	65
13.	Tools .........................................................................................	66
Calculator................................................................................................................		66
Alarm Clock ............................................................................................................		67
Calendar .................................................................................................................		67
	Add an Appointment..........................................................................................	67
	View an Appointment ........................................................................................	67
	Calendar Options ..............................................................................................	68
Tip Calc...................................................................................................................		68
World Clock ............................................................................................................		69
14.	Settings ....................................................................................	70
Sound Settings .......................................................................................................		70
	Ringers ..............................................................................................................	70

C78 User Manual

Keypad Tone ....................................................................................................	71
Volume..............................................................................................................	71
Power On/Off Tone...........................................................................................	72
Alerts.................................................................................................................	72
Systems Switch Tone .......................................................................................	72
Display Settings......................................................................................................	73
Language ...............................................................................................................	73
Bluetooth ................................................................................................................	74
Bluetooth Manager ...........................................................................................	74
Bluetooth Device...............................................................................................	75
Pair with a New Bluetooth Device.....................................................................	75
GPS........................................................................................................................	76
System ...................................................................................................................	76
Call Setup .........................................................................................................	76
Automatic Keyguard .........................................................................................	76
Memory Info ......................................................................................................	77
Phone Info ........................................................................................................	77
System Settings ................................................................................................	77
Security.............................................................................................................	77
Airplane Mode: On/Off............................................................................................	78
15. Glossary ...................................................................................	80

		C78 User Manual
16.	Troubleshooting	......................................................................82
17.	Index .........................................................................................	84

C78 User Manual

1. For Your Safety

General Care

Your handset contains delicate electronic circuitry, magnets and battery systems. You should treat it with care and give particular attention to the following points:

Do not allow the handset, battery or accessories to come into contact with liquids or moisture at any time. Do not immerse it in any liquid.

Do not place the handset alongside computer disks, credit cards, travel cards or other magnetic media. The information contained on the disks or cards may be affected by the handset.

Do not paint the handset.

Do not leave the handset or battery in places where the temperature could exceed 140 ˚F, e.g. on a car dashboard or a windowsill, behind glass in direct sunlight, etc.

Do not remove the handset battery while the handset is switched on.

Take care not to allow metal objects, such as coins or key rings, to contact or short circuit the battery terminals.

Do not dispose of batteries in fire. The handset’s Li-ION batteries may be safely disposed of at a Li-ION recycling point. Follow local requirements for recycling.

Do not put the handset’s battery in your mouth, as battery electrolytes may be toxic if swallowed.

C78 User Manual

Only use the battery with a charging system that has been qualified with the system per this standard. Use of an unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard.

Do not disassemble, open, crush, bend, deform, puncture, or shred the handset.

Do not short circuit a battery or allow metallic or conductive objects to contact the battery terminals.

Promptly dispose of used batteries in accordance with local regulations.

Improper battery use may result in a fire, explosion, or other hazard.

Do not put a battery into a microwave oven, dryer or high-pressure container.

Do not contact battery directly into an electric outlet or cigarette lighter charger. Use only authorized chargers.

Do not puncture the battery with a sharp object such as a needle.

When the battery is disposed, be sure it is non-conducting by applying vinyl tape to the (+) and (-) terminals.

Do not drop, throw, or subject the handset to rough treatment.

Stop using the battery if abnormal heat, odor, discoloration, deformation, or abnormal condition is detected during use, charge or storage.

Do not use your handset with a damaged or deformed battery.

Do not solder the battery directly.

Remove the battery whose life cycle has expired from equipment immediately.

The earpiece may become warm during normal use. Also, the handset itself may become warm while the battery is being charged.

C78 User Manual

When a handset is in vibration mode, the vibration may cause the handset to move.

Be careful not to place the handset near heat sources (such as a heater).

Use a damp or anti-static cloth to clean the handset. Do not use an ordinary dry cloth or electrostatic cloth. Do not use chemical or abrasive cleaners as these could damage the casing.

Third party equipment: The use of third party equipment, cables, or accessories, not made or authorized by ZTE, may invalidate the warranty of your phone and also adversely affect the phone’s safety and operation.

Remember to make backup copies of all important data on your handset.

Remember to recycle: The cardboard packing supplied with this handset is ideal for recycling.

Warnings: In the unlikely event of a battery leak, take care to keep the battery discharge away from your eyes and skin. If the leakage does come into contact with the eyes or skin, flush thoroughly with clean water and consult with a doctor.

Aircraft Safety

Switch off your phone or activate the airplane mode when inside or near an aircraft. Use of handsets in an aircraft may be dangerous to the operation of the aircraft and may disrupt the cellular network. Failure to observe this instruction may lead to suspension or denial of phone service to the offender, or legal action, or both.

C78 User Manual

Airplane mode allows you to use many of your phone’s features, such as games, calculator, voice memos, and many others when you are in an airplane or other area where wireless signals may cause interference. In the airplane mode, you are prohibited from making or receiving calls.

Hospital Safety

Switch off your phone and remove its battery in areas where handset use is prohibited.

Follow the instructions given by any respective medical facility regarding the use of cellular handsets on their premises.

General Guidelines

Many jurisdictions have laws and regulations about taking pictures in public or private areas regarding the processing and further use of such pictures. ZTE encourages its customers to obey all laws and to honor the personal rights of others.

Check the roaming agreement availability with your network operator.

The use of mobile phones is not allowed in some radiation sensitive areas, such as hospitals, research centers, and airplanes. The user is responsible for poweringoff the device. If there is any uncertainty, the battery should be removed.

Observe any signs that indicate powering off your handset, such as those near gas stations or explosives.

If you have a heart condition, be careful with the setting of call vibration or tone volume. This phone is capable of producing loud noises which may damage your

C78 User Manual

hearing. Turn down the volume before using headphones, Bluetooth stereo headsets or other audio devices.

Do not allow children to play with the handset, charger or batteries.

The operation of some medical electronic devices, such as hearing aids and pacemakers, may be affected if a handset is used next to them. Observe any caution signs and the manufacturer’s recommendations.

Take care not to put your phone in the back pocket of your pants and then sit on the phone. Also, do not put your phone at the bottom of a bag where it may be subject to excessive weight or pressure as this may damage the LCD and camera lens and cause them to malfunction.

The phone contains metal and may cause a reaction for overly sensitive skin types.

Do not leave the phone discharged or without a battery for a long period of time. Otherwise some data may be erased.

Road Safety

You must exercise proper control of your vehicle at all times. Give your full attention to driving.

Observe all of the recommendations contained in your local traffic safety documentation.

Pull off the road and park before making or answering a call, if driving conditions require so. Check if local laws and/or regulations restrict the use of cellular phones while driving.

C78 User Manual

You must not stop on the hard shoulder of a motorway to answer or make a call, except in emergency situations.

Switch off your handset at a refueling point, such as a gas station, even if you are not refueling your own car.

Do not store or carry flammable or explosive materials in the same compartment as the handset.

Electronic systems in a vehicle, such as anti-lock brakes, speed control and fuel injection systems are not normally affected by radio transmissions. The manufacturer of such equipment may advise if it is adequately shielded from radio transmissions. If you suspect vehicle problems caused by the radio transmitter in the handset, consult your dealer and do not switch on the handset until your handset has been checked by a qualified technician.

Vehicles Equipped with an Airbag

An airbag inflates with great force. Do not place objects, including either installed or portable wireless equipment, in the area over the airbag or in the airbag deployment area. If in-vehicle wireless equipment is improperly installed and the airbag inflates, serious injury could result.

Third Party Equipment

The use of third party equipment, cables or accessories, not made or authorized by ZTE, may invalidate the warranty of the handset and also adversely affect the handset’s operation. For example, use only the ZTE charger supplied with the handset.

C78 User Manual

Efficient Use

For optimum performance with minimum power consumption, do not cover the antenna area (It’s on the bottom of your phone.) with your hand. Covering the antenna affects the call quality, may cause the handset to operate at higher power levels than needed, and may shorten talk and standby times.

Radio Frequency (RF) Energy

Your handset is a low-power radio transmitter and receiver. When it is turned on, it intermittently receives and transmits Radio Frequency (RF) energy in radio waves to handle and control the power level at which the handset transmits. Exposure to radio frequency energy:

Radio wave exposure and Specific Absorption Rate (SAR) information. The handset is designed to comply with safety requirements for exposure to radio waves. This requirement is based on scientific guidelines that include safety margins designed to assure the safety of all persons, regardless of age and health.

The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate, or SAR. Tests for SAR are conducted using a standardized method with the phone transmitting at its highest certified power level in all used frequency bands.

While there may be differences between the SAR levels of various ZTE phone models, they are all designed to meet the relevant guidelines for exposure to radio waves.

C78 User Manual

The SAR limit recommended is 1.6 W/kg averaged over one (1) gram of tissue. The highest SAR value for this model phone tested for use at the head is

1.53 W/kg (1g).

The highest SAR value for this model phone tested for use at the body is 0.662 W/kg (1g). SAR compliance for body-worn operations is restricted to belt clips, holsters, or similar accessories that have no metallic component in the assembly and which provide at least 1.5 cm separation between the device, including its antenna, and the user’s body.

Emergency Services

To make an emergency call in any country:

1.Ensure your handset is ON and in service.

2.Press the End Key as many times as needed to clear the display and ready the device for calls.

3.Enter a local emergency number, i.e., 911.

4.Press the Send Key to dial the number. Follow instructions received and do not end the call until told to do so.

Note: Tell the operator which service you require: Police, Ambulance, Fire Engine, Coastguard or Mountain Rescue Service. Give your position, and if possible, remain stationary and maintain contact. Due to the nature of the cellular system, the connection of emergency calls cannot be guaranteed. You should never rely on any wireless device for essential communication such as medical emergencies.

C78 User Manual

FCC Notice

This mobile phone complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This mobile phone has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

C78 User Manual

IC Notice

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

This Category II radiocommunication device complies with Industry Canada Standard RSS-310.

Ce dispositif de radiocommunication de catégorie II respecte la norme CNR -310 d’Industrie Canada.

IMPORTANT NOTE:

IC Radiation Exposure Statement

This EUT is compliance with SAR for general population/uncontrolled exposure limits in IC RSS-102 and had been tested in accordance with the measurement methods and procedures specified in IEEE 1528. This equipment should be installed and operated with minimum distance 1.5cm between the radiator & your body.

This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter.

C78 User Manual

2. Introduction

Overview

Thank you for purchasing the ZTE C78 Mobile Phone. The C78 is capable of making voice calls, sending and receiving SMS messages in CDMA 1x networks. This phone provides many functions which are practical for daily use, including a 0.3-megapixel camera, calendar, calculator, alarm clock, etc. It can be connected to Bluetooth wireless devices and accessories. Its A2DP Bluetooth profile means you can enjoy the music play via a Bluetooth headset.

To guarantee this mobile phone is always in its best condition, read this manual carefully and keep it for future reference. To ensure your safety, read Section 1 - For Your Safety thoroughly before using this handset for the first time.

Note: The pictures and icons presented in this manual are meant for illustrative purposes only and may not accurately represent the actual pictures and icons found on the phone. Your phone contains the most up to date information.

C78 User Manual

What’s Included

Your ZTE C78 Mobile Phone package contains the following components. Check the box carefully to ensure all items are present.

C78 Handset

Battery

User Manual and literature pack

AC Travel Charger

We, ZTE Corporation, declare that the product is packaged with battery separate in the box. The FCC ID label is placed on the mobile phone clearly visible to all persons at the time of purchase.

C78 Technical Specifications

	Handset Type	C78

	Dimensions (L x W x H)	111 × 48 × 15 mm (4.4 × 1.9 × 0.6 in.)

	Weight	Less than 100 g (3.53 oz) including
	Weight	battery
		battery
	Continuous Standby Time	180 hours (subject to the network)

	Continuous Talk Time	220 minutes (subject to the network)

C78 User Manual

Phone at a Glance

2		5

[1]	Display Screen	[5]	USB Charger Port
[2]	Earpiece	[6]	Camera Key
[3] Earphone Jack		[7] Camera
[4] Volume Key		[8] Back Cover

C78 User Manual

Key Definitions

Left Soft Key – Execute prompts that appear in the lower-left corner of the screen, directly above the button. These prompts change according to the screen content.

Right Soft Key – Execute prompts that appear in the lower-right corner of the screen, directly above the button. These prompts change according to the screen content.

Send Key – Make and answer calls. This button is also a short cut key to “All Calls” from the idle screen.

End Key – End calls and close applications. Holding this key for a while in the idle screen will power off the handset.

Camera Key – Holding this key for a while will launch the camera in standby mode.

Volume up / Volume down Keys– Adjust the volume of calls.

C78 User Manual

Navigation Keys – These keys (up, down, left and right) allow for navigation through menu options and quick access to some function menus in standby mode: All Contacts (Up), Media (Left), Bluetooth (Right) and Messaging (Down).

OK Key – Confirm actions and make selections. This key also executes prompts that appear on the lower-middle button on the screen, above the key. These prompts change according to screen content.

0-9 Number/Alphabetic Keys – These keys are used for entering numbers and letters, dialing a speed call, and selecting

~options while navigating through menus. Press the 1 key in standby mode as a shortcut to launch Voice Mail.

 and # Keys – These keys have different functions, depending on the mode or function menu. Hold the * key for a while in standby mode to turn on/off vibration mode. Hold the # key for a while in standby mode to lock the keypad.

Back Key – Delete characters during text entry. Press the key to return to the previous page during menu navigation.

Speaker Key – Activate and de-activate the speakerphone function during voice calls.

C78 User Manual

User Interface

The user interface is constituted of three parts. They are the icon area, the text and graphics area and the soft key indicator area.

Icon Area: Displays the function icons running.

Text and Graphics Area: Displays the text, commands, and all information entered.

Soft Key Indicator Area: Displays the current functions for the related soft keys.

C78 User Manual

Indicators and Icons

1x Service	Airplane Mode Is Active
Alarm	Battery Status
Call Connect	Calendar
Earphone	High SMS Priority
Incoming Call	Missed Call
New SMS Message	New Voice Mail
No Signal	No Battery
Outgoing Call	Roaming
Ringer On	Ringer Off
Signal Strength	Silent Mode
Vibration Mode
Vibration and Ringer Mode	Bluetooth
Bluetooth Headset

C78 User Manual

3. Set up Your Phone

This chapter outlines the steps required to set up your phone, power-on and activate on your service provider’s network. Follow the procedure below step-by-step to get started.

Battery

Please switch off your phone and disconnect the charger with it before removing the battery. Avoid touching electronic components on the battery and battery compartment of the phone.

Install the Battery

+ 63 hidden pages
