ZTE C77 Users Manual

0 (0)

ZTE Corporation

ZTE C77 CDMA 1X Digital Mobile Phone

User Manual

No part of this publication may be excerpted, reproduced, translated, or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation.

ZTE Corporation operates a policy of continuous development. ZTE Corporation reserves the right to make changes and improvements to any of the products described in this document without prior notice.

Release: V1.0

Manual number:

10 09, 2008

		C77 User Manual
	Contents
1.	For Your Safety........................................................................	10
	General Care ..........................................................................................................	10
	Aircraft Safety .........................................................................................................	13
	Hospital Safety........................................................................................................	14
	General Guidelines .................................................................................................	14
	Road Safety ............................................................................................................	15
	Vehicles Equipped with an Airbag ..........................................................................	16
	Third Party Equipment ............................................................................................	17
	Efficient Use............................................................................................................	17
	Radio Frequency (RF) Energy................................................................................	17
	Emergency Services...............................................................................................	19
	FCC Notice .............................................................................................................	20
	Turn on the HAC Setting.........................................................................................	21
	Copyright Notice .....................................................................................................	21
2.	Introduction .............................................................................	22
	Overview.................................................................................................................	22
	What’s Included ......................................................................................................	22
	C77 Technical Specifications..................................................................................	23
	Phone at a Glance ..................................................................................................	24
	Key Definitions........................................................................................................	25
	3

C77 User Manual

User Interface.........................................................................................................	27
Indicators and Icons ...............................................................................................	28

3. Set up Your Phone	..................................................................30
Battery ....................................................................................................................	30
Install the Battery ..............................................................................................	31
Charge the Battery............................................................................................	32
Remove the Battery ..........................................................................................	33
Power On/Off Your Phone......................................................................................	34
Keyguard Mode ......................................................................................................	34
Connect to the Network..........................................................................................	35
Activate Your Phone...............................................................................................	35

4. Basic Operations.....................................................................	36
Make Voice Calls....................................................................................................	36
Use the Keypad ................................................................................................	36
Use the Contacts List........................................................................................	36
Use the Last Number Dialed.............................................................................	37
Use the Number from the Call History ..............................................................	37
Use Speed Dials ...............................................................................................	37
Answer Voice Calls...........................................................................................	38
In-Call Features......................................................................................................	39
Three-Way Call ......................................................................................................	40
4

		C77 User Manual
	Call Waiting.............................................................................................................	40
5.	Entering Text ...........................................................................	42
	Key Functions .........................................................................................................	42
	Text Input Modes ....................................................................................................	43
6.	Contacts ...................................................................................	46
	Contact List.............................................................................................................	47
	New Contact ...........................................................................................................	48
	Groups ....................................................................................................................	49
	Speed Dials ............................................................................................................	49
7.	Calls..........................................................................................	50
	All Calls...................................................................................................................	50
	Missed Calls ...........................................................................................................	51
	Incoming Calls ........................................................................................................	51
	Outgoing Calls ........................................................................................................	51
	Call Timers..............................................................................................................	51
8.	Messaging................................................................................	52
	Send New ...............................................................................................................	52
	Insert .................................................................................................................	53
	Slide ..................................................................................................................	54
	Preview..............................................................................................................	54
	Erase Item.........................................................................................................	54
		5

C77 User Manual

Cc/Bcc/Sub .......................................................................................................	55
Save To Drafts..................................................................................................	55
Quick Text.........................................................................................................	55
Signature ..........................................................................................................	55
Message Priority ...............................................................................................	56
Inbox.......................................................................................................................	56
Read a Message...............................................................................................	56
Reply to a Message ..........................................................................................	57
Outbox....................................................................................................................	57
Drafts......................................................................................................................	57
Sent ........................................................................................................................	58
Saved .....................................................................................................................	58
Voice Mail...............................................................................................................	58
Web Alerts..............................................................................................................	59
Settings ..................................................................................................................	59
Message Settings .............................................................................................	59
Quick Text Settings...........................................................................................	60
Memory Info ...........................................................................................................	60
9. Calendar ...................................................................................	61
Add an Appointment...............................................................................................	61
View an Appointment .............................................................................................	61
Calendar Options ...................................................................................................	62
	6

		C77 User Manual
10.	WEB ..........................................................................................	63
11.	Music & Media .........................................................................	66
MyTunes .................................................................................................................		66
	Play Your Tunes................................................................................................	66
	Manage Your Tunes..........................................................................................	67
MyImages ...............................................................................................................		68
Preloaded Files.......................................................................................................		68
	Tunes ................................................................................................................	68
	Images...............................................................................................................	68
Memory Info............................................................................................................		69
12.	Games ......................................................................................	70
13.	Tools.........................................................................................	71
Calculator................................................................................................................		71
Alarm Clock ............................................................................................................		72
	Edit an Alarm.....................................................................................................	72
	Alarm Options ...................................................................................................	73
Update Phone.........................................................................................................		73
Tip Calc...................................................................................................................		74
World Clock ............................................................................................................		74
14.	Settings ....................................................................................	75
Sound Settings .......................................................................................................		75
		7

C77 User Manual

	Ringers .............................................................................................................	76
	Keypad Tone ....................................................................................................	76
	Volume..............................................................................................................	77
	Power On/Off Tone...........................................................................................	77
	Alerts.................................................................................................................	77
	Systems Switch Tone .......................................................................................	78
Display Settings......................................................................................................		78
Language ...............................................................................................................		79
GPS........................................................................................................................		79
System ...................................................................................................................		79
	Call Setup .........................................................................................................	79
	Automatic Keyguard .........................................................................................	80
	Memory Info......................................................................................................	80
	Phone Info ........................................................................................................	80
	System Settings................................................................................................	80
	TTY Mode .........................................................................................................	81
	Security.............................................................................................................	82
	HAC Mode ........................................................................................................	83
Airplane Mode On/Off.............................................................................................		83
15.	Glossary ...................................................................................	85
16.	Troubleshooting ......................................................................	86
		8

C77 User Manual

17. Index .........................................................................................

C77 User Manual

1. For Your Safety

General Care

Your handset contains delicate electronic circuitry, magnets and battery systems. You should treat it with care and give particular attention to the following points:

Do not allow the handset, battery or accessories to come into contact with liquids or moisture at any time. Do not immerse it in any liquid.

Do not place the handset alongside computer disks, credit cards, travel cards or other magnetic media. The information contained on the disks or cards may be affected by the handset.

Do not place anything inside the folded handset.

Do not paint the handset.

Do not leave the handset or battery in places where the temperature could exceed 140˚F, e.g., on a car dashboard or a windowsill, behind glass in direct sunlight, etc.

Do not remove the handset battery while the handset is switched on.

Take care not to allow metal objects, such as coins or key rings to contact or short circuit the battery terminals.

C77 User Manual

Do not dispose of batteries in fire. The handset’s Li-Ion batteries may be safely disposed of at a Li-Ion recycling point.

Do not put the handset’s battery in your mouth, as battery electrolytes may be toxic if swallowed.

Only use the battery with a charging system that has been qualified with the system per this standard. Use of an unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard.

Do not disassemble or open, crush, bend or deform, puncture, or shred.

Do not short circuit a battery or allow metallic or conductive objects to contact the battery terminals.

Promptly dispose of used batteries in accordance with local regulations.

Improper battery use may result in a fire, explosion, or other hazard.

Do not put a battery into a microwave oven, dryer or high-pressure container.

Do not contact battery directly into an electric outlet or cigarette lighter charger. Use only authorized chargers.

Do not puncture the battery with a sharp object such as a needle.

When the battery is disposed, be sure it is non-conducting by applying vinyl tape to the (+) and (-) terminals.

C77 User Manual

Do not drop, throw, or subject the handset to rough treatment.

Stop using the battery if abnormal heat, odor, discoloration, deformation, or abnormal condition is detected during use, charge or storage.

Do not use with a damaged or deformed battery.

Do not solder the battery directly.

Remove the battery whose life cycle has expired from equipment immediately.

The earpiece may become warm during normal use. Also, the handset itself may become warm while the battery is being charged.

When a handset is in vibration mode, the vibration may cause the handset to move.

Be careful not to place the handset near heat sources (such as a heater).

Use a damp or anti-static cloth to clean the handset. Do not use an ordinary dry cloth or electrostatic cloth. Do not use chemical or abrasive cleaners as these could damage the casing.

Third party equipment: The use of third party equipment, cables, or accessories, not made or authorized by ZTE, may invalidate the warranty of your phone and also adversely affect the phone’s safety and operation.

C77 User Manual

Remember to make backup copies of all important data on your handset.

Remember to recycle: The cardboard packing supplied with this handset is ideal for recycling.

Warning: In the unlikely event of a battery leak, take care to keep the battery discharge away from your eyes and skin. If the leakage does come into contact with the eyes or skin, flush thoroughly with clean water and consult with a doctor.

Aircraft Safety

Switch off your phone or activate the airplane mode when inside or near an aircraft. Use of handsets in an aircraft may be dangerous to the operation of the aircraft and may disrupt the cellular network. Failure to observe this instruction may lead to suspension or denial of phone service to the offender, or legal action, or both.

Airplane mode allows you to use many of your phone’s features, such as games, calculator, voice memos, and many others when you are in an airplane or other area where wireless signals may cause interference. In the airplane mode, you are prohibited from making or receiving voice/data calls.

C77 User Manual

Hospital Safety

Switch off your phone and remove its battery in areas where handset use is prohibited.

Follow the instructions given by any respective medical facility regarding the use of cellular handsets on their premises.

General Guidelines

Many jurisdictions have laws and regulations about taking pictures in public or private areas regarding the processing and further use of such pictures. ZTE encourages its customers to obey all laws and to honor the personal rights of others.

Check the roaming agreement availability with your network operator.

The use of mobile phones is not allowed in some radiation sensitive areas, such as hospitals, research centers, and airplanes. The user is responsible to poweroff the device. If there is any uncertainty, the battery should be removed.

Observe any signs that indicate to power off your handset, such as those near gas stations, or explosives and power off the handset/device upon them.

If you have a heart condition, be careful with the setting of call vibration or tone volume.

Do not allow children to play with the handset, charger, or batteries.

C77 User Manual

The operation of some medical electronic devices, such as hearing aids and pacemakers, may be affected if a handset is used next to them. Observe any Caution signs and the manufacturer’s recommendations.

Take care not to put your phone in the back pocket of your pants and then sit on the phone. Also, do not put your phone at the bottom of a bag where it may be subject to excessive weight or pressure as this may damage the LCD and cause them to malfunction.

Your phone contains metal, which may cause you to develop an itch, rash or eczema depending on your physical condition.

Do not leave the phone discharged or without a battery for a long period of time. Otherwise some data may be erased.

Road Safety

You must exercise proper control of your vehicle at all times. Give your full attention to driving.

Observe all of the recommendations contained in your local traffic safety documentation.

Pull off the road and park before making or answering a call, if driving conditions require so. Check if local laws and/or regulations restrict the use of cellular phones while driving.

C77 User Manual

You must not stop on the hard shoulder of a motorway to answer or make a call, except in emergency situations.

Switch off your handset at a refueling point, such as a gas station, even if you are not refueling your own car.

Do not store or carry flammable or explosive materials in the same compartment as the handset.

Electronic systems in vehicle, such as anti-lock brakes, speed control and fuel injection systems are not normally affected by radio transmissions. The manufacturer of such equipment may advise if it is adequately shielded from radio transmissions. If you suspect vehicle problems caused by the radio transmitter in handset, consult your dealer and do not switch on the handset until your handset has been checked by a qualified technician.

Vehicles Equipped with an Airbag

An airbag inflates with great force. Do not place objects, including either installed or portable wireless equipment, in the area over the airbag or in the airbag deployment area. If in-vehicle wireless equipment is improperly installed and the airbag inflates, serious injury could result.

C77 User Manual

Third Party Equipment

The use of third party equipment, cables or accessories, not made or authorized by ZTE, may invalidate the warranty of the handset and also adversely affect the handset’s operation. For example, use only the ZTE charger supplied with the handset.

Efficient Use

For optimum performance with minimum power consumption, do not cover the antenna area (it is on the bottom of your phone) with your hand. Covering the antenna affects the call quality, may cause the handset to operate at higher power levels than otherwise needed, and may shorten talk and standby times.

Radio Frequency (RF) Energy

This model phone meets the government’s requirements for exposure to radio waves. This phone is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government:

The exposure standard for wireless mobile phones employs a unit of

measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests for SAR are conducted using standard operating positions accepted by the FCC with the phone transmitting at its

C77 User Manual

highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the poser required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.

The highest SAR value for the model phone as reported to the FCC when tested for use at the ear is 1.45 W/kg and when worn on the body, as described in this user guide, is 0.723 W/kg (Body-worn measurements differ among phone models, depending upon available enhancements and FCC requirements.)

While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement.

The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID: Q78-ZTEC77.

For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines for use with an accessory that contains no metal and the

C77 User Manual

positions the handset a minimum of 1.5 cm from the body. Use of other enhancements may not ensure compliance with FCC RF exposure guidelines. If you do no t use a body-worn accessory and are not holding the phone at the ear, position the handset a minimum of 1.5 cm from your body when the phone is switched on.

Emergency Services

To make an emergency call in any country:

1.Ensure your handset is ON and in service.

2.Press the End Key as many times as needed to clear the display and ready the device for calls.

3.Enter a local emergency number.

4.Press the Send Key to dial the number. Follow instructions received and do not end the call until told to do so.

Note: Tell the operator which service you require: Police, Ambulance, Fire Engine, Coastguard or Mountain Rescue Service. Give your position and, if possible, remain stationary and maintain contact. Due to the nature of the cellular system, the connection of emergency calls cannot be guaranteed. You should never rely on any wireless device for essential communication such as medical emergencies.

C77 User Manual

FCC Notice

This mobile phone complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This mobile phone has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

C77 User Manual

Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Turn on the HAC Setting

When the HAC setting is on, your C77 sends the audio from your phone calls to the telecoil rather than to the microphone of your hearing aid. You are likely to hear calls much better because volume is increased and background noise and feedback are diminished. The HAC setting improves only the calls you listen to through the earpiece. HAC requires extra battery power, so watch your battery consumption when it's turned on.

The video/audio recordings you make/download are protected by copyright laws. They are for personal use only and must not be otherwise used without the permission of the copyright owner.

C77 User Manual

2. Introduction

Overview

Thank you for purchasing the ZTE C77 Mobile Phone. The C77 is capable of making voice calls and data connections to CDMA 1x networks. It has the default functionality of E911 GPS. This phone provides many functions which are practical for daily use, including wireless internet browser, calendar, etc.

To guarantee this mobile phone is always in its best condition, read this manual carefully and keep it for future reference. To ensure your safety, read the section For Your Safety thoroughly before using this handset for the first time.

The pictures and icons shown in the manual are just schematic drawings for function demonstration. If they are inconsistent with your handset, please take your handset as the standard. If the inconsistency exits in the manual because of the handset function updating, please refer to the follow-up public information from ZTE Company.

What’s Included

Your ZTE C77 Mobile Phone package contains the following components. Check the box carefully to ensure all items are present.

C77 Handset

C77 User Manual

Battery

User Manual and literature pack

AC Travel Charger

We, ZTE Corporation, declare that that the product is packaged with battery separate in the box. The FCC ID label is placed on the mobile phone clearly visible to all persons at the time of purchase.

C77 Technical Specifications

	Handset Type	C77

	Dimensions (L x W x H)	111.36 × 48.22 × 14.6 mm
	Dimensions (L x W x H)	(4.38 × 1.90× 0.57 in)
		(4.38 × 1.90× 0.57 in)
	Weight	Less than 100 g (3.53 oz) including battery

	Continuous Standby Time	180 hours (subject to the network)

	Continuous Talk Time	220 minutes (subject to the network)

C77 User Manual

Phone at a Glance

[1]	Display Screen	[4]	USB Charger Port
[2]	Handset Jack	[5]	Calendar Key
[3]	Volume Key	[6]	Battery Cover

C77 User Manual

Key Definitions

Left Soft Key – Execute prompts that appear in the lower-left corner of the screen, directly above the button. These prompts change according to the screen content.

Right Soft Key – Execute prompts that appear in the lower-right corner of the screen, directly above the button. These prompts change according to the screen content.

Send Key – Make and answer calls. This button is also a short cut key to “All Calls” from the idle screen.

End Key – End calls and close applications. Holding this key for a while in the idle screen, it will power off the handset.

Calendar Key – Holding this key for a while will launch the calendar in standby mode.

Vol. up / Vol. down Keys– Adjusts the volume of calls and music play.

C77 User Manual

Navigation Keys – These keys (up, down, left and right) allow for navigation through menu options. Use for quick access to All Contacts (Up), WEB (Left), Music & Media (Right) and Messaging (Down) when in standby mode.

OK Key – Confirm actions and make selections. This key also executes prompts that appear on the lower-middle button on the screen, above the key. These prompts change according to screen content.

0-9 Number/Alphabetic Keys – These keys are used for entering numbers and letters to a text, dialing a speed call, and

~selecting options while navigating menus. Press 1 key in standby mode to launch Voice Mail for shortcut.

¿ and # Keys – These keys have different functions, depending on the mode or function menu. Hold the ¿ key for a while in standby mode to switch between vibrate on and vibration off of your phone. Hold the # key to enter Keyguard mode.

Back Key – Deletes characters during text entry. This key returns to the previous page during menu navigation and web browsing.

Speaker Key – Activates and de-activates the speakerphone function during voice calls.

C77 User Manual

User Interface

User Interface is constituted by three parts. They are icon area, text & graphic area, and soft key indictor area.

Icon Area: Shows the function icons running

Text & Graphics Area: Shows the text, commands, and all information entered

Soft Key Indicator Area: Shows the current functions for the related soft keys

C77 User Manual

Indicators and Icons

Signal Strength	1x Service
Airplane Mode Is Active	Alarm Indicator
Calendar	Call Connect
Data Dormant	Data Transfer
Earphone Mode	Incoming Calls
Missed Calls	New MMS Message
High MMS Priority	New MMS and SMS Message
Battery Status	No Battery
No Signal	Outgoing Calls
Ringer Off	Ringer Mode
Roaming	Silent Mode
New SMS Message	High SMS Priority
SSL (Web Security)	TTY Mode
Vibration Mode	Vibration and Ringer Mode
	28

C77 User Manual

	New Voice Mail and Web	New Voice Mail
	Message	New Voice Mail
	Message
	New Web Message

+ 65 hidden pages
