ZTE C330 User Manual
C330
CDMA 1X Digital Mobile Phone
User Manual
Copyright © 2007 by ZTE Corporation
All rights reserved.
No part of this publication may be excerpted, reproduced,
translated or utilized in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without the prior
written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right
to make modifications on print errors or update specifications without
prior notice.
Version: Release 1.0
Date: Sep 2007
Manual number:0000000000
Content
1 General Information....................................................... 1
1.1 W elcom e....................................................................................1
1.2 Security.....................................................................................1
1.3 Safety Warnings ..............................................................2
1.4 Limit Warranty..........................................................................6
1.5 Limitation of Liability...............................................................7
2 Know Your Phone............................................................ 8
2.1 Keypad......................................................................................8
2.2 Instruction of Interface Icon.................................................... 11
2.3 Technic al Parameters...............................................................11
2.4 Battery.....................................................................................12
2.4.1 Remove and Installation of Battery.................................12
2.4.2 Charging the Battery........................................................13
2.5 Connecting to the Network.....................................................15
2.5.1 UIM Card ........................................................................15
2.5.2 Insertion and Extraction of UIM Card.............................15
2.5.3 Power on/off Phone.........................................................16
2.5.4 PIN Code......................................................................... 16
2.5.5 Connecting the Network..................................................17
i
3 Basic Operations............................................................ 18
3.1 Making a Call..........................................................................18
3.2 Answering a Call.....................................................................20
3.2.1 Setting Any Key Answer ................................................. 20
3.2.2 Incoming Call Silence.....................................................20
3.3 In Conversation.......................................................................21
3.3.1 Silence in Conversation...................................................21
3.3.2 Adjusting V olum e in Conversation..................................21
3.3.3 Selecting Options in Conversation..................................21
3.4 Menu Functions ......................................................................21
4 Names............................................................................. 23
4.1 Finding Records......................................................................23
4.2 Adding New Record................................................................24
4.3 Viewing Records.....................................................................26
4.4 Erasing Records......................................................................27
4.4.1 Erasing a Record..............................................................27
4.4.2 Erasing All Contacts........................................................27
4.5 Editing Records.......................................................................28
4.6 Setting Speed Dial...................................................................28
4.7 Viewing and Making Speed Dial.............................................29
4.8 Editing Group..........................................................................29
4.9 Memory Status........................................................................30
ii
5 Messages......................................................................... 31
5.1 Sending a New Message.........................................................31
5.2 Receiving Incoming Call while Editing Message...................32
5.3 Reading Message....................................................................32
5.4 Viewing OutBox .....................................................................33
5.5 Reading Voice Mail.................................................................33
5.6 Sending Templates Messages..................................................34
5.7 Setting Message Groups..........................................................34
5.8 Erasing Messages....................................................................35
5.8.1 Erasing a Message...........................................................35
5.8.2 Erasing All Messages ......................................................35
5.9 Message Settings.....................................................................36
5.9.1 Msg Priority.....................................................................36
5.9.2 Delivery Acknowledging................................................. 36
5.9.3 Save Sent Message..........................................................36
5.9.4 Automatically Erasing Inbox...........................................37
5.9.5 Save Position...................................................................37
5.9.6 Memory Status.................................................................37
6 Call History.................................................................... 39
6.1 Viewing Recent Calls..............................................................39
6.2 Erasing Recent Calls List........................................................ 40
6.3 Call Duration...........................................................................40
iii
7 Profiles............................................................................ 41
8 Display............................................................................ 42
8.1 Selecting Wallpaper.................................................................42
8.2 Setting Backlighting................................................................42
8.3 Setting Intensity......................................................................43
8.4 Adjusting Contrast...................................................................43
8.5 Selecting Language.................................................................43
8.6 Setting Time Format................................................................43
8.7 Changing Banner.....................................................................43
9 Settings........................................................................... 45
9.1 Call..........................................................................................45
9.1.1 Call Waiting.....................................................................45
9.1.2 Call Forwarding...............................................................46
9.1.3 Anykey Answer...............................................................47
9.1.4 Voice Privacy...................................................................47
9.1.5 International Call.............................................................47
9.1.6 Call Timer........................................................................48
9.1.7 Call Connect Alert...........................................................48
9.1.8 Fire Proof.........................................................................49
9.2 Security Settings .....................................................................50
9.2.1 Setting PIN Code.............................................................50
9.2.2 Setting Phone Lock.......................................................... 50
iv
9.2.3 Viewing Emergency Numbers.........................................51
9.2.4 Resetting..........................................................................51
9.3 Phone ...................................................................................... 51
9.3.1 Auto Key Guard............................................................... 51
9.3.2 Alert.................................................................................52
9.3.3 Version.............................................................................53
10 Organiser ....................................................................... 54
10.1 Scheduler ..............................................................................54
10.2 Voice Memo..........................................................................54
10.2.1 Recording in Normal.....................................................55
10.2.2 Recording in Conversation............................................55
10.2.3 Recording with Incoming Call/Message........................56
10.3 Alarm ....................................................................................56
10.4 Stopwatch..............................................................................57
10.5 Calculator..............................................................................57
11 Do More ......................................................................... 59
12 Games.............................................................................60
13 Text Input....................................................................... 62
10.1 Multitap Input .......................................................................63
10.2 Numbers Input ......................................................................63
10.3 eHiText Input ........................................................................63
10.4 Symbols Input.......................................................................64
v
14 Troubleshooting.............................................................65
vi
1 General Information
1.1 Welcome
Thank you for choosing C330 CDMA 1X Digital Mobile Phone.
To guarantee the mobile phone always in its best condition, please
read this manual carefully and keep it for future use.
The pictures, symbols and contents in this manual are just for your
reference. They might not be completely identical with your phone.
Please subject to the real object. ZTE operates a policy of continuous
development and reserves the right to update and modify the technical
specifications in this document at any time without prior notice.
1.2 Security
If your mobile phone is lost or stolen, please report to your service
provider or agencies of banning the use of your lost UIM card and
phone, which will protect you from economic losses resulted from
unauthorized use.
You need to provide the phone’s ESN number labeled. You can
see ESN number after removing the battery. Please keep ESN
number for future use.
To protect your mobile phone from illegal use, please take the
security measures as follows:
¾ Set PIN code of the UIM card.
1
¾ Take it with you as you can.
1.3 Safety Warnings
To t he Ow ne r
Some electronic devices are susceptible to electromagnetic
interference sent by mobile phone if inadequately shielded, such
as electronic system of vehicles. Please consult the manufacturer
on the device before using the phone if necessary.
Operating of mobile phone may interfere with medical devices like
hearing aides and pacemakers. Please always keep the mobile
phone more than 20 centimeters away from such medical devices
when the phone is powered on. Do not carry the mobile phone in
the breast pocket. Power the mobile phone off if necessary.
Consult a physician or the manufacturer on the medical device
before using the phone.
Be aware of the usage limitation when using a mobile phone at
places such as oil warehouses or chemical factories, where there
are explosive gases or explosive products being processed,
because even if your phone is in standby mode, it still transmits
radio frequency (RF) energy. Therefore, power off your phone if
required.
Pay attention to traffic safety. Do not use your mobile phone while
driving. Park before making or answering a call.
Store the phone out of the reach of little children. The phone may
2
cause injury if used as a toy.
Mobile Phone
Please use original accessories or accessories that are
authorized by the manufacturer. Using any unauthorized
accessories may affect your mobile phone’s performance, and
violate related national regulations about telecom terminals, or
even endanger your body
If you want to clean your phone, please use clean fabric that is a
bit wet or anti-static. Do not use harsh chemical cleaning solvents
or strong detergents to clean it. Turn off your phone before you
clean it.
As your mobile phone can produce electromagnetic field, do not
place it near magnetic items such as computer disks.
Using the phone near electrical appliances such as TV, telephone,
radio and personal computer can cause interference, which
affects the function of the phone.
Do not expose your mobile phone to direct sunlight or store it in
hot areas. High temperatures can shorten the life of electronic
devices.
Prevent liquid from leaking into your phone.
Do not drop, knock or harshly treat your phone. Rough handling
can break internal circuit boards.
Do not connect the phone with other unauthorized peripheral
equipments.
3
Do not attempt to disassemble the mobile phone and battery by
yourself. Non-expert handling of the devices may damage them.
Do not charge the mobile phone without battery.
On occasion of emergent calling, keep your phone in status of
power on and in area of service. On the condition of standby,
press the key to enter emergency phone number, and then press
Send key
The user is cautioned that changes or modifications not expressly
approved by the manufacturer could void the user’s authority to operate
the equipment.
This device meets the government’s requirements for exposure to radio
waves. This device is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF) energy set by the
U.S. Federal Communications Commission.
The exposure standard for wireless devices employs a unit of
measurement known as the Specific Absorption Rate (SAR). The SAR
limit set by the FCC is 1.6 W/kg.
To comply with FCC RF exposure compliance requirements, this grant
is applicable to only Mobile Configurations. The antennas used for this
transmitter must be installed to provide a separation distance of at least
1.5 cm from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter.
to make a phone call.
4
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Battery Using
Do not short-circuit the battery, as this can cause excessive heat
and fire.
Do not store battery in hot areas or dispose of it in a fire to avoid
explosion.
Never use any charger or battery damaged or worn out.
Return the wear-out battery to the provider or put it in the
appointed recycle place. Do not put it in familial rubbish.
Declared that the product is installed with battery separately in
the box. The FCC ID label is placed on the mobile phone clearly
visible to all persons at the time of purchase.
Warning: If the battery is broken, keep away from content. If it
taints your skin, wash your skin with abundant fresh water and
ask doctor for help if necessary.
Safety and General Using in Vehicles
Before making or answering a call, you should pay attention to
the local laws about using wireless mobile phones and take them
into account in practical use.
5
Safety airbag, brake, speed control system and oil eject system
shouldn’t be affected by wireless transmitting. If you do meet
problems above, please contact your automobile provider.
Please power off your mobile phone when refueling your
automobile, and so do the place where duplex wireless
equipments are banned. Don’t put your phone together with
flammable or explosive items, as inner spark may cause fire.
In Aircraft
Follow the restrictions in aircraft. Wireless devices can cause
interference in aircraft.
Please power off your mobile phone before taking off till landing. In
order to protect airplane’s communication system from
interference, it is never allowed to use mobile phone when it is in
flight. Using mobile phone before the plane taking off should get
aircrew’s permission according to safety regulations.
1.4 Limit Warranty
The warranty does not apply to defects or errors in the product
caused by:
(a) Reasonable abrasion.
(b) Misuse including mishandling, physical damage, improper
installation, unauthorized disassembly of the product.
(c) Water or any other liquid damage.
6
(d) Any unauthorized repair or modification.
(e) Power surges, lightning damage, fire, flood or other events
outside ZTE’s reasonable control.
(f) Use of the product with any unauthorized third party
products such as generic chargers.
(g) Any other cause beyond the range of normal usage for
products.
End User shall have no right to reject, return, or receive a
refund for any product from ZTE under the above-mentioned
situations.
This warranty is end user’s sole remedy and ZTE’s sole liability
for defective or nonconforming items, and is in lieu of all other
warranties, expressed, implied or statutory, including but not
limited to the implied warranties of merchantability and fitness for a
particular purpose, unless otherwise required under the mandatory
provisions of the law.
1.5 Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special,
incidental or consequential damages resulting from or arising out of or
in connection with using this product, whether or not ZTE had been
advised, knew or should have known the possibility of such damages.
7
2 Know Your Phone
2.1 Keypad
Earpiece
LCD screen
Scroll key
Left select key
0~9 Number key
Send key
Microphone
Key Tip Function Description
Make or answer a call.
Send
key
Press Send key in standby mode to
enter all calls list.
Press Send key two times directly
to redial the last number.
8
Right select key
End key
Charger connector/Earphone
End
key
Left
/Right
select
key
OK key
Up/Dow
n key
(Scroll
key)
Left/Rig Scroll the cursor left and right.
End an active call or reject a call.
Power on/power off.
Exit from any interface to standby
mode.
Enter main menu in standby mode.
Switch to the options of left/right
bottom submenu.
Confirm the commands and options
selected.
Confirm the character chosen while
character inputting.
Scroll the cursor up and down.
Used as selection key up and down
for keying in commands and
selecting options shown on the
display.
In standby mode, hold Up key to
set Silence All; Press Down key
to enter Ring Tone menu.
Press Up key to enter Messages
menu.
Used as direction key in games.
9
ht key
(Scroll
key)
~
0~9
Number
key
*key，
#key
Used as selection key to scroll
cursor left and right for keying in
commands and selecting options
shown on the display.
In standby mode, press Left key
to enter MobileShop menu, press
Right key to enter Games menu.
Adjust volume in conversation.
Used as direction key in games.
Key in numbers or characters.
Make a Speed Dial call.
# key:
Hold # key in standby mode to lock
phone’s keypad.
Press # key to select text mode.
* key:
Hold
Press
* key in standby mode to
enable/disable vibration.
* key once to enter Symbols
mode in text input mode.
Note: To “press” the key in this manual means to press the key and
release it. To “hold” the key means to keep pressing the key for two
10
seconds or more.
2.2 Instruction of Interface Icon
Icon Indication
2.3 Technical Parameters
Handset
Type ZTE C330
Dimensions
Weight About 70g(Battery Included)
Battery
Signal strength
Roaming
New message
Vibration
Silence All
Alarm
Power indicator
（Width×Height×Thickness）
45.4mm×104mm×13mm
Continuous standby
time
Continuous talk time
Note: Please refer to the real phone for other relative parameters
of the battery and charger.
About 80h～160h (Subject to Network)
About 2h～4h (Subject to Network)
11
2.4 Battery
The attached Li-ion battery along with the phone can be used after
unpacking. For the first three times, please use up the power and
charge it fully for a new battery to perform well.
2.4.1 Remove and Installation of Battery
Remove：(1) Press and push the back-cover of the phone down to
release and remove it off the phone. (2) Put finger on the side
finger grips, and then lift up the battery from the finger grips to
remove the battery.
Installation：(1) Replace the battery into the battery slot, to be
noted that the lower end of the battery firstly inserted. (2) Put the
back-cover of the phone flatly upon the body of phone. Direct the
back cover towards the locking catches on the both sides of the
phone and push the back-cover of the phone upward to lock the
cover into its place.
12
2.4.2 Charging the Battery
Plug out rubber away (turn 180° as shown in the picture) from
the jack on the bottom of the handset and connect the lead from
the charger to the socket on the bottom of the phone. (Note:
The side with arrow should be upright while connecting).
Connect the charger to a standard wall AC socket.
Meanwhile, the charging indicator in up-right corner of the
display flops cyclically, indicating the charging is going. In
power-off mode while charging, the display only shows the
charge indicator. If the battery is completely flat in storage or
13
used up, it may take for a while before the charging indicator
appears on the display or any calls can be made.
When the charging indicator on the screen stops flopping, the
charging is completed. The charging takes usually up to 2～3
hours. In the process of charging, it is a normal phenomenon
that the battery, phone and charger get into hot accordingly.
After the completion of charging, disconnect the charger from
the phone and AC socket.
Note：
When it is in charge, place the phone on condition of good
ventilation and temperature between -5℃～＋45℃. Ensure to
use the charger offered by the manufacturer. Using unauthorized
charger may cause danger and violate the authorization of the
phone and the guarantee article.
When the phone is automatically switched off or indicates the
alarm information of power shortage, please charge the battery in
time.
The duration time of the standby status or conversation of the
phone is based on ideal working environment. In practice, the
working time of battery varies with network condition, working
environment and application methods.
14
2.5 Connecting to the Network
2.5.1 UIM Card
Before using the phone, please insert effective UIM (User Identity
Module) card into the phone.
All the information related to the network connection is recorded
in the metal plane area of UIM card together with the information you
stored in your Contacts in the UIM card. The UIM card can be inserted
into any CDMA phone to use (new phone automatically reads UIM
card).
Please do not touch the metal plane area of the card to avoid
missing and damaging information in the card and put UIM card in
place far away from electricity and magnetism.
Warning：Please power off the phone before taking out UIM card.
It is prohibited to insert or taking out UIM card in the condition of
connecting with external power.
2.5.2 Insertion and Extraction of UIM Card
Power off the phone, remove the battery and other external
power.
Insert UIM card into UIM card slot in the phone.
Pull out UIM card out of slot, as shown in picture hereinafter.
15
Loading...
