ZTE C132
CDMA 1X Digital Mobile Phone
User Manual
Copyright © 2013 by ZTE Corporation
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means,
electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE
Corporation.
The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update
specifications without prior notice. The information on the package is only for your reference. Images are for your
reference only. Please check the product model before purchasing.
ZTE Corporation
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Http://www.zte.com.cn Service Hotline: +86-755-26779999
E-mail: mobile@zte.com.cn Manual No.: 07958450XXXX
1
Contents
Know your Phone ....................................................................................................................................................... 2
Key Instruction ............................................................................................................................................................ 3
Interface Icons ............................................................................................................................................................ 4
Installing the RUIM Card and Battery ...................................................................................................................... 4
Charging the Battery .................................................................................................................................................. 5
Powering on/ off Your Phone .................................................................................................................................... 6
Making and Answering a Call ................................................................................................................................... 6
Menu Tree.................................................................................................................................................................... 7
Text Input ..................................................................................................................................................................... 8
Message ...................................................................................................................................................................... 8
Menu Functions .......................................................................................................................................................... 9
Phone Lock ............................................................................................................................................................... 11
PIN Code and PUK Code........................................................................................................................................ 11
Warning and Maintenance ...................................................................................................................................... 11
Specific Absorption Rate (SAR) ............................................................................................................................. 12
Safety Information (General Care) ........................................................................................................................ 12
Warranty Terms ........................................................................................................................................................ 12
Limitation of Liability ................................................................................................................................................. 12
2
Know your Phone
SP: To “press” the key and release it.
LP: To “hold” the key (keep pressing the key for two seconds or more).
OK key
SP: My MTS PLANET
LP: -
Left select key
SP: Main Menu
LP: -
UP key
SP: Profile
LP: Games
“*” key
SP: Input *
LP: Lock keypad
Earpiece
Left key
SP: Games
LP: -
Down key
SP: New Message
LP: Open/Close torch
Right select key
SP: Contacts
LP: -
Charger connector
Right key
SP: MTS Info
LP: -
“#” key
SP: Input #
LP: -
End key
SP: Return to idle
LP: Power on/off
Earphone
Send key
SP: Call history
LP: -
Torch
3
Key Instruction
Key
Function Description
Send key
Make or answer a call.
Press the Send key in standby mode to enter All Calls list.
End key
End an active call or reject a call.
Long press to Power on/Power off the phone.
Exit from any interface to standby mode.
Left select key
Enter main Menu in standby mode.
Switch to the options of left bottom submenu.
Right select key
Enter All list in Contacts in standby mode.
Switch to the options of right bottom submenu.
Erase character(s) while editing text.
Cancel operation, exit to previous window.
OK key
Enter My MTS PLANET in standby mode.
Press the OK key to confirm the commands and options selected.
Confirm the character chosen while inputting characters.
Up/Down key
Scroll the cursor up and down.
Used as selection key up and down for keying in commands and
selecting options shown on the display.
In standby mode, press the Down key to write message.
In standby mode, hold the Down key to open or close the torch.
In standby mode, press the Up key to enter Profile menu.
In standby mode, hold the Up key to access games on the phone.
Used as direction key in games.
Left /Right key
Scroll the cursor left and right.
Used as selection key to scroll cursor left and right for keying in
commands and selecting options shown on the display.
In standby mode, press the Left key to access games on the phone.
In standby mode, press the Right key to enter MTS Info.
Adjust volume in conversation.
Used as direction key in games.
0~9 key
Key in numbers or characters.
Make a Speed Dial call (2-9).
Hold 0 key to input + in standby mode.
# key
* key
Press the # key to select text mode when edit text.
Hold the * key in standby mode to lock phone’s keypad.
Press the * key once to enter Symbols mode in text input mode.
4
Interface Icons
Icon
Indication
Signal strength
Earphone in use
Roaming
New message
Silent
Alarm
Power indicator
Installing the RUIM Card and Battery
Switch off your phone before installing or replacing the battery and RUIM card.
1. Remove the back cover.
2. Hold the RUIM card with the cut corner oriented as shown and slip it into the card holder.
3. Insert the battery by aligning the gold contacts on the battery with the gold contacts in the battery compartment.
Gently push down on the battery until it clicks into place.
5
4. Press the cover gently back into place until you hear a click.
Charging the Battery
1. Plug out rubber away from the jack
on the bottom of the handset and
connect the lead from the charger
to the socket on the bottom of the
phone. (Note: The side with arrow
should be upright while connecting).
2. Connect the charger to a standard wall AC socket.
3. When the charging animation on the screen stops, the charging is completed. The charging takes usually up to
2～3 hours. During charging, it is a normal phenomenon that the battery, phone and charger may get hot.
4. After the completion of charging, disconnect the charger from the phone and AC socket.
6
Powering on/ off Your Phone
Please hold the End key to power on/off the phone. The phone will automatically search for the network.
Besides sending and receiving calls in standby mode, you can also:
Press the Left select key to enter main Menu.
Press the OK key to enter MY MTS PLANET.
Press the Right select key to enter Contacts list menu.
Press the Up key to enter Profile menu.
Press the Down key to write new message.
Press the Left key to access games on the phone.
Press the Right key to enter MTS Info menu.
Press the Send key to enter all calls list.
Hold the * key to lock the keypad in manual way.
Note: To “press” key in this manual means to press the key and release it. To “hold” key means to keep
pressing the key for two seconds or more.
Making and Answering a Call
Making a call
Enter the phone number
Press the Send key to make the call.
Press the End key to end the call.
Answering a call
Press the Send key to answer the call.
Press the End key to end the call.
7
Menu Tree
1. Contacts
1.1 Add Contact
1.2 All List
1.3 Groups
1.4 Speed Dial
1.5 Memory Status
2. Messages
2.1 New Message
2.2 Inbox
2.3 Drafts
2.4 Outbox
2.5 Sent
2.6 Message Settings
2.7 Message Template
2.8 Delete Message
2.9 Memory Status
3. Profile
3.1 Silent
3.2 General
3.3 Outdoor
3.4 Meeting
3.5 Flight
4. Call History
4.1 Call History
4.2 Call Duration
5. My MTS
5.1 My MTS PLANET
5.2 Games & Applications
6. Tools
6.1 Alarm
6.2 Calculator
6.3 Voice Recorder
6.4 World Time
6.5 Stopwatch
7. File Manager
7.1 My Record
7.2 BREW
8. MTS Info
9. Settings
9.1 Display Settings
9.2 Phone Settings
9.3 Call Settings
9.4 Times & Date Settings
9.5 Security Settings
10. Games
10.1 Cluster Fruits
11. Facebook
12. Scheduler
8
Text Input
Your phone offers text input modes: Multi Tap Input (Abc/abc/ABC), eHiText Input(eZi), Numbers Input (123)
and Symbol Input (Symbols).
Operation
Method
Input Letters
Multi Tap Input—“Abc/abc/ABC” press corresponding letter key till the
letter appears.
Input Words
eHiText Input—“eZi”, press any key once to key in any word.
Input Digits
Numbers Input—“123”, press digit key once.
Input Symbol
Symbols Input —Press * key to enter the symbols mode and press the
corresponding digit key.
Or press the “1” key till the symbol (common symbols) appears except
for Numbers Input mode.
Input Space
Press the “0” key, except for being in numbers mode.
Erase
Character
Press the Right select key.
Move cursor
left or right
Press the Left/Right key.
Move cursor up
or down
Press the Up/Down key.
Change input
mode
Press the # key to select another text mode.
Capitalization
Press the # key to switch between capitalization and lowercase as
“abc/ABC”.
Message
1. Select Messages in main Menu to enter Messages menu.
2. Select New Message or press the Down key in standby mode to write and edit message text.
3. Input receiver’s phone number in number field. Press right key to input “;”, you can input the multi-receivers’
phone number, or select phone number directly from Contacts (the OK key).
4. Press the OK key to send the message. Or press the Left select key to select Option, then select Send to send
the message or Save message in Drafts.
Select Inbox to view messages received.
Select Drafts to view the messages saved as drafts.
Select Outbox to view the unsent messages.
Select Sent to view the sent messages.
Select Message Settings to set the messages’ functions.
Select default common templates of words and sentences to edit or send directly in Message Template.
Select Delete Message to erase message.
9
Menu Functions
Hereinafter are brief instructions on menu functions of the phone.
Function
Selection
Description
View all contacts
Menu→Contacts→All List
View the corresponding records in all lists. Press the
left/right key to view different group.
View details
Menu→Contacts→All List→View(OK
key)
View the details information of the record in the
contacts.
Find contact
Menu→Contacts→All List
Input character(s) to search for a phonebook entry.
Add contact
Menu→Contacts→Add Contact
Add a new entry in contacts.
Edit
Menu→Contacts→All
List →Option→Edit
Modify the contents of record.
Delete
Menu→Contacts→All
List →Option→Delete
Delete a record in Contacts.
Delete all
Menu→Contacts→All
List →Option→Delete All
Delete all records in phone (group, family, friend, and
colleague, etc.).
Send message to
specific number
Menu→Contacts→All
List →Option→Send Message
Send the message to the number of the record.
Make a call to
specific number
Menu→Contacts→All
List →Option→Call
Make a call to the number of the record.
Send name-card
Menu→Contacts→All
List →Option→Send Name Card
Send name-card information of the record.
Edit group
Menu→Contacts→Groups
View, edit and select the ringer for the group.
Speed dial list
Menu→Contacts→Speed Dial
View the speed dial list. In standby mode, hold the
number key to dial the corresponding call.
Memory status
Menu→Contacts→Memory Status
Number of entries saved and maximum number of
entries capacity in phone.
Write and send
new message
Menu→Messages→New Message
Write and send new SMS to other mobile phones. The
message could be sent to multi-receivers.
Read message
Menu→Messages→Inbox/Outbox/Dr
afts/Sent
Read and do more options of the messages.
Message settings
Menu→Messages→Message
Settings
SMS setting options (SMS save position, auto delete,
signature, delivery ACK, message priority, etc.).
Templates
message
Menu→Messages→Message
Template
Some common used messages preformatted in
phone.
Call history
Menu→Call History→Call History→
All Calls/Missed Calls
/Received Calls/ Dialed Calls
View and dial recent calls.
Call timer
Menu→Call History→Call Duration
View and reset call duration of Calls.
Delete all
Menu→Call History→Call
History→Option→Clear List
Delete all lists in Call History.
Profile
Menu→ Profile→Silent/General
/Outdoor /Meeting /Flight
Set phone’s ring/SMS/earpiece/key beep/alert etc.
tone and volume
Wall paper set
Menu→Settings→Display
Settings→Screen
Settings→Wallpaper Settings
Set wall papers as background in idle state.
Backlight
Menu→Settings→Display
Settings→Screen
Set backlight duration.
10
Settings→Backlight Time
Brightness
Menu→Settings→Display
Settings→Screen
Settings→Brightness
Adjust Brightness.
Idle Display
Content
Menu→Settings→Display
Settings→Screen Settings→
Indle Display Content
Edit the idle display content
Keypad light
Menu→Settings→Display
Settings→Keypad Llight Settings
Set keypad and time.
Language
Menu→Settings→Phone
Settings→Language
Set the language of the phone.
Shortcut
Menu→Settings→Phone
Settings→Shortcut
Set default function for the Navigation Key.
Auto key guard
Menu→Settings→Phone
Settings→Auto Keypad Lock
Set phone’s auto key lock and time.
Power save
Menu→Settings→Phone
Settings→Power Save
Open or close the power save.
Auto power on/off
Menu→Settings→Phone
Settings→Auto Power On/Off
Set auto power on/off.
Version
Menu→Settings→Phone
Settings→Version Info.
View present preferred roaming list, software and
hardware version, etc.
Call forwarding
Menu→Settings→Call Settings→Call
Forwarding
Forward an incoming call to a designated number.
Call waiting
Menu→Settings→Call Settings→Call
Waiting
Answer the second call, hold the first call.
Call connect alert
Menu→Settings→Call
Settings→Call
Settings→Connection Reminder
The phone alert when a call is connected.
Any key answer
Menu→Settings→Call
Settings→Answer Settings→Any Key
Answer
Press any key to answer a call except for End key, Left
/Right select key.
Auto answer
Menu→Settings→Call
Settings→Answer Settings→Headset
Auto Answer
Auto answer via earpiece. Answer incoming call
automatically when connecting with an earphone.
Remind alert
Menu→Settings→Call Settings
→Call Information Reminder
Set if the phone alert for reminding minute, missed
call.
Voice privacy
Menu→Settings→Call
Settings→Voice Privacy
Set voice encryption.
International call
Menu→Settings→Call Settings→
International Dial
Dial international call auto or manual.
Time format
Menu→Settings→Time & Date
Settings→Time Format
Set format of time.
Date format
Menu→Settings→Time & Date
Settings→Date Format
Set format of date.
Handset lock
Menu→Settings→Security
Settings→Use/Change Phone Code
Set or change the handset lock.
PIN lock
Menu→Settings→Security
Settings→Use/Change PIN Code
Set or change the PIN lock.
Restore settings
Menu→Settings→Security
Settings→Restore Factory Settings
Restore factory default (Ringtone, Backlight,
Language, Settings, etc. except for SMS, Names, Call
History).
Clear data
Menu→Settings→Security
Restore factory default and delete all the records of
11
Settings→Clear User Data
user data.
Alarm clock
Menu→Tools→Alarm
Set alarm alert time.
Calculator
Menu→Tools→Calculator
Execute basic math calculation.
Voice recorder
Menu→Tools→Voice Recorder
Record voice.
World time
Menu→Tools→World Time
Check the world time.
Stopwatch
Menu→Tools→Stopwatch
Stopwatch timing.
Games
Menu→Games
Play games.
Facebook
Menu→Facebook
Use Facebook to access social network.
Calendar
Menu→Scheduler
View calendar.
MTS menu
Menu→My MTS/MTS Info
Enjoy services which are available to the subscribers.
Phone Lock
Phone lock could prevent your phone from illegal use. The default phone code is 0000. Please change it to your own
as soon as possible.
Note: Please remember the code; otherwise some service expense may happen.
PIN Code and PUK Code
PIN Code: PIN code could prevent your UIM card from illegal use. When PIN lock is on, you should enter the PIN
code when opening the handset again.
PUK Code: Consecutive inputting wrong PIN code for three times can cause locking of UIM card. To unlock, you
need PUK code.
Note:
PIN code and PUK code may be offered together with the UIM card. If not, please contact with network operator.
The limitation times for consecutive wrong code may vary with different UIM card.
Please change default PIN code to your own as soon as possible.
Warning and Maintenance
• Keep the phone out of the reach of little children. The phone may cause injury if used as a toy.
• Please use original accessories or accessories that are authorized by the manufacturer.
• Please keep the phone dry and store in shady and cool place.
• Do not expose your mobile phone to direct sunlight or store it in hot areas. High temperatures can shorten the life
of electronic devices.
• Prevent liquid from seeping into your phone.
• Do not drop or harshly treat the phone. Rough handling can break internal circuit boards.
• Do not connect the phone with other unauthorized peripheral equipments.
• Do not attempt to dismantle the mobile phone and battery by yourself.
• Power off your phone before you clean the phone. Please use clean fabric that is anti-static to clean your phone.
• As your mobile phone can produce electromagnetic field, do not use the phone near electrical appliances.
• Do not charge the mobile phone without battery.
• Beware of the usage limitation when using a mobile phone at places such as oil warehouses or chemical factories.
• The user is cautioned that changes or modifications not expressly approved by the manufacturer could void the
user’s authority to operate the equipment.
12
Specific Absorption Rate (SAR)
Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio
waves recommended by international guidelines. These guidelines were developed by the independent scientific
organization ICNIRP and include safety margins designed to assure the protection of all persons, regardless of age
and health.
The guidelines use a unit of measurement known as Specific Absorption Rate, or SAR. The SAR limit for mobile
devices is 1.6 W/kg and the highest SAR value for this device when tested was 1.15 W/kg. As mobile devices offer a
range of functions, they can be used in other positions, such as on the body.
As SAR is measured utilizing the device’s highest transmitting power, the actual SAR of this device while operating
is typically below that indicated above. This is due to automatic changes to the power level of the device to ensure it
only uses the minimum power required to communicate with the network.
Safety Information (General Care)
• Use a wireless hands-free system (headphone, headset) with a low power Bluetooth emitter.
• Make sure the cell phone has a low SAR.
• Keep your calls short or send a text message (SMS) instead. This advice applies especially to children,
adolescents and pregnant women.
• Use cell phone when the signal quality is good.
• People having active medical implants should preferably keep the cell phone at least 15 cm away from the implant.
Warranty Terms
The warranty does not apply to defects or errors in the product caused by:
(a) Reasonable abrasion.
(b) Misuse including mishandling, physical damage, improper installation, unauthorized disassembly of the product.
(c) Water or any other liquid damage.
(d) Any unauthorized repair or modification.
(e) Power surges, lightning damage, fire, flood or other events outside ZTE’s reasonable control.
(f) Use of the product with any unauthorized third party products such as generic chargers.
(g) Any other cause beyond the range of normal usage for products.
End User shall have no right to reject, return, or receive a refund for any product from ZTE under the
above-mentioned situations.
This warranty is end user’s sole remedy and ZTE’s sole liability for defective or nonconforming items, and is in lieu of
all other warranties, expressed, implied or statutory, including but not limited to the implied warranties of
merchantability and fitness for a particular purpose, unless otherwise required under the mandatory provisions of the
law.
Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential damages resulting from
or arising out of or in connection with using this product, whether or not ZTE had been advised, knew or should have
known the possibility of such damages.
Loading...
