Introduction

Z8 Encore! XP® F042A Series 8-Pin Development Kit

User Manual

1

Zilog’s Z8 Encore! XP® F042A Series 8-pin microc ontroller unit (MCU)
is part of the Zilog MCU products. The Z8 Encore! XP
Pin development kit (Z8F04A08100KITG) enable s you to become famil­iar with the hardware and software tools available with this produc t. This
kit consists of 4 KB version of the Z8 Encore! development board that
supports and presents the features of the Z8 Encore! XP F042A Series 8­pin package. This kit allows you to write application software and con­tains all supporting documents. Z8F042ASB020 is the silicon used in the
board. For more information, refe r to Z8 Encore! XP
Product Specification (PS0228).

This user manual acquaints you with the Z8 Encore! XP F042A Series 8­pin MCU development kit, and gives instructions on setting up and using
the tools to start building desi gns and applications.

Kit Contents

The Z8 Encore! XP F042A Series 8-Pin MCU development kit contains
the following:

Hardware

The hardware components include:

F042A Series 8-

®

F082A Series

•

Z8 Encore! XP F042A Series 8-pin development board

•

USB Smart Cable for PC to Z8 Encore! XP F042A Series 8-pin
development board

•

5 V DC power supply

UM018705-0508 Introduction

Packaging

Z8 Encore! XP® F042A Series 8-Pin Development Kit

User Manual

CD-ROM Containing

Documentation

Power

Supply

USB Smart Cable

2

Development
Board

Figure 1. Z8 Encore! XP F042A Series 8-Pin Development Kit Contents

(Printed Quick Start Guide Not Shown)

Software (on CD-ROM)

The software components include:

•

ZDS II—Z8 Encore!® IDE with ANSI C-Compiler

•

Sample code

•

Document browser

•

Acrobat Reader

UM018705-0508 Introduction

Documentation

The documentation includes:

•

Quick Start Guide (QS0055)

•

Z8 Encore! XP F042A Series 8-pin technical documentation (on CD­ROM)

– Development Kit User Manual
– ZDS II—IDE User Manual (UM0130)
–eZ8
– Application Notes

Z8 Encore! XP® F042A Series 8-Pin Development Kit

User Manual

TM

CPU User Manual (UM0128)

3

The sample code is installed with ZDS II and is located at

tion directory>\samples

The documentation can be insta lled with the DemoShield interface or can
be viewed on the CD-ROM using the DemoShield menus and a PDF
reader. A copy of the acrobat installer is provide d on the
CD-ROM and can be installe d from the DemoShield install screen. After
installing the documenta tion on the system Windows Explore r can be
used to select any document to be viewed with the PDF file viewer.

System Requirements

IBM PC (or compatible computer) with the followi ng minimum
configurations is requi red:

•

Microsoft Wi ndows XP Professional SP1/Windows 2000 SP3/
Windows 98 SE

•

Pentium II/233 MHz processor or higher up to Pentium IV, 2.8 GHz

•

96 MB RAM or more

•

35 MB hard disk space or more

•

Super VGA video adapter

<installa-

in the disk drive.

UM018705-0508 Introduction

Z8 Encore! XP® F042A Series 8-Pin Development Kit

•

CD-ROM

•

One USB high-speed or full-speed port on the host chassis or a
powered Hu b

Designing with the USB Smart Cable

Z8 Encore! XP® F042A Series 8-pin development kit uses the USB Smart
Cable provided in the kit. The Z8 Encore! Serial Smart Cable and
associated TIM will not work with the Z8F04A08100KITG kit. Include
the following when designing the targe t board a nd application:

•

The target design’s debug interface must include a RESET pin.

•

The target application must allow the RESET pin to be pulled LOW.

For more details, refer to Z8 Encore! XP
cation (PS0228).

®

User Manual

4

F082A Series Produ ct Specifi-

Installation

For details on software installation and setup of the Z8 Encore! XP
F042A Series 8-pin development kit refer to Z8 Encore! XP® F042A 8­Pin Development Kit Quick Start Guide (QS0055).

UM018705-0508 Introduction

Z8 Encore! XP® F042A Series 8-Pin Development Kit

Development Board

Introduction

Z8 Encore! XP® F042A Ser ies 8-pin de velopment boar d is a development
and prototyping board for the Z8 Encore! XP F042A Series 8-pin MCU.
The board provides a tool to evaluate features of Z8 Encore! XP F042A
Series 8-pin MCU, and to start developing an application be fore building
the hardware.

User Manual

5

Resonator
not installed
on production
units

DBG
Pin 1

Figure 2. Z8 Encore! XP F042A Series 8-Pin Developmen t Board

UM018705-0508 Development Board

Features

Z8 Encore! XP® F042A Series 8-Pin Development Kit

User Manual

The features of Z8 Encore! XP® F042A Series 8-pin development board
include:

•

Z8 Encore!® MCU (8-pin SOIC)

•

3 LEDs

•

RS-232 interface

•

IrDA transceiver

•

T wo pushbuttons: RESET and TEST

•

5 V DC power connector

•

On-Chip Debugger interface

6

•

Prototyping area

•

External interface connectors JP1 and JP2

•

2.7 V–3.6 V operating voltage with 5 V-tolerant inputs

MCU

Z8 Encore! XP F042A Series 8-pin MCU is member of a family of
Zilog® MCU products based upon the 8-bit eZ8™ core CPU. The Flash
in-circuit programming capa bility a llows for faste r development ti me and
program changes in the field. The eZ8 core CPU is upward compatible
with existing Z8® instructions. The rich peripheral set of the Z8 Encore!
XP F042A Series makes it suitabl e for a variety of applicati ons including
motor control, security systems, home appliances, personal electronic
devices, and sensors.

The development board contains circuitry to support and present all the
features of the Z8 Encore! XP F042A Series.

UM018705-0508 Development Board

Z8 Encore! XP® F042A Series 8-Pin Development Kit

User Manual

The key features of the Z8 Encore! XP® F042A Series 8-pin MCU
include:

•

eZ8™ core CPU

•

4 KB Flash memory with in-circuit programming capability

•

1 KB register RAM

•

5-channel, 10-bit analog-to-digital convert er (ADC)

•

Full-duplex UART

•

Infrared Data Associati on (IrDA)-compl iant infrar ed encoder/ decoder

•

T wo 16-bit timers with capture, compare, a nd PWM capability

•

W atchdog Timer (WDT) with internal RC oscillator

•

Six I/O pins

7

•

Programmable priority int errupts

•

On-Chip Debugger

•

Voltage Brownout (VBO) Protection

•

Power-On Reset (POR)

•

2.7 V–3.6 V operating voltage with 5 V-tolerant inputs

•

Operating temperatures: 20 °C ±10 °C

®

For more information on the Z8 Encore!
Encore! XP® F082A Series P roduct Specification (PS0228), ava il ab l e fo r
download at www.zilog.com.

family of devices, refer to Z8

UART with IrDA ENDEC

Z8 Encore! XP F042A Series 8-pin MCU (component U5) contains a
fully-functional, high-perf ormance UAR T with Infrared Encoder/Decoder
(endec). The Infrared endec is integr ated with an on-chip UART allowing
easy communication between the Z8 Encore! XP F042A Series

UM018705-0508 Development Board

Z8 Encore! XP® F042A Series 8-Pin Development Kit

User Manual

8-pin MCU and IrDA transceivers. Infrar ed communication provides
secure, reliable, low-cost, point-to-point communication between PCs,
PDAs, cell phones, printers, and other infrared enabled devices.

Jumpers and Settings

T able 1 lists information on jumper funct ions.

Table 1. Z8F04A08100KITG Jumper Functions

Jumper State Description Default

J1* OUT Enables RS-232 interface X

IN Disables RS-232 interface

J2* OUT Enables IrDA interface

IN Disables IrDA interface X

J3 1-2 Connects U5 pin PA0 to Green LED D2 X

2-3 Connects U5 pin PA0 to JP2 pin 18

J4 OUT Disconnects PA0 from debug (DBG) pin X

IN Connects PA0 to DBG pin 4 on ZDI port P3

J5 1-2 Connects U5 pin PA1 to yellow LED D3 X

2-3 Connects U5 pin PA1 to JP2 pin 20

J6 1-2 Connects U5 pin PA2 to red LED D4 X

2-3 Connects U5 pin PA2 to JP2 pin 22

8

UM018705-0508 Development Board

Z8 Encore! XP® F042A Series 8-Pin Development Kit

User Manual

Table 1. Z8F04A08100KITG Jumper Functions (Continued)

Jumper State Description Default

J7 OUT DEMO mode setting X

IN Chip U5 resets when SW1 pressed

J8 1-2 Connects U5 pin PA3 to J11 pin 1 (CTS0

EN)

2-3 Connects U5 pin PA3 to JP2 pin 35

J9 1-2 Connects U5 pin PA4 to RXD RS232 signal X

2-3 Connects U5 pin PA4 to JP2 pin 35

J10 1-2 Connects U5 pin PA5 to TXD RS232 signal X

2-3 Connects U5 pin PA5 to JP2 pin 36

J11 OUT Disconnects PA3 from CTS0 RS232 signal X

IN Connects PA3 to CTS0 RS232 signal

*These jumpers must not be OUT at the same time

X

9

The board has two modes of operation: DEMO and USER DEBUG. Use
DEMO mode to run the sample program included with the kit. Run the
board in USER DEBUG mode:

•

When using the ZDI port to debug your code.

•

When configuring the board to run your own prototyp e code.

UM018705-0508 Development Board

Z8 Encore! XP® F042A Series 8-Pin Development Kit

DEMO Mode Jumper Settings

When running the board in DEMO mode, the following jumpers must be
set:

•

J3 1-2

•

J4 OUT

•

J5 1-2

•

J6 1-2

•

J7 OUT

•

J8 1-2

•

J9 1-2

•

J10 1-2

User Manual

10

•

J11 OUT

USER DEBUG Mode Jumper Settings

When running the board in USER DEBUG mode, the following jumpers
must be set:

•

J3 OUT

•

J4 IN

•

J6 OUT

•

J7 IN

Switches S1 , S2 , and SW 1

Switches S1, S2, and SW1 on the Z8 Encore! XP® F042A Series 8-pin
development board perform the following functions:

•

S1–Test switch

UM018705-0508 Development Board

Z8 Encore! XP® F042A Series 8-Pin Development Kit

•

S2–Power ON/OFF switch

•

SW1–RESET

External Interface Headers JP1 and JP2

External interf ace header s JP1 and JP2 are displ ayed in the Schematics on
page 12.

Use of Ceramic Resonator Y1

User Manual

11

When using ceramic resonator Y1, pins PA0, PA1, and DBG are
unavailable. For m ore information , re fer t o Z8 Enc or e ! XP
Product Specification (PS0228).

Zilog Help Options

Refer to the readme.txt and FAQ.html included in the ZDS II installa­tion directory; ZDS II On-Li ne Help and Developmen t Kit User Manuals.
For Silicon issues, refer to the related Silicon Product Specific ation. To
locate all documentatio n included in the kit, refer to the documentation
browser located at:

<Installation Directory>\ZDSII_Z8Encore!_
<Version_Number>\Documentation

For latest updates on FAQs and to find answers, please contact Customer
Support.

®

F082A Series

UM018705-0508 Development Board

Schematics

Figure 3 and Figure 4 on page 13 display the schematic s for Z8 Encore! XP F042A Series 8-pin development board.

Z8 Encore! XP

®

F042A Series 8-Pin Development Kit

User Manual

12

GND

P1

PWR JACK

GND

2
3
1

R3

0

R4

0

R8

0

R9

0

S2

ON

F

OF

SW KEY-SPDT

VCC_33V

147

3 4

GND

VCC_33V

147

5 6

GND

VCC_33V

147

11 10

VCC_33V

147

13 12

U3B

74LVC04/SO

U3C

74LVC04/SO

U3E

74LVC04/SO

GND

U3F

74LVC04/SO

GND

U2

3 2

VIN

VOUT

1

GND

SPX2815AU-3

.3

C2

PA5_TX

D0

0

147

1 2

R7
10K

E

-RESET
DBG

0.1uF

C6

0.1uF
D0

GND

PA4_RXD

U3A

74LVC04/SO

VCC_33V

GND

R10
10K

2
4
5
6

13
12

15

0

10

1

20

147

9 8

-RESE
DBG

5V

C4

0.1uF

0.1uF

C8

TP1

+

C3

10/6

12345

GND

10/6

VCC

+

J11
HEADER 2

VCC_33V

VCC_33V

R1

C7

68

LED

21

GND

0

D1

3.3 OK

TP

2

PA3_CTS

VCC_33V

12345

0

PA3_CTS

VCC_33V

GND

0

CTS0

VCC_33V

-DIS_232

1

2

EN

R2
10K

J1

1
2

DIS RS

-DIS_IRDA

J2

DIS IR

P3
12

34
56

Header 3x2

PA5_TX

PA4_RXD

GND

232

1
2

DA

DBG
INTERFAC

U1
C1+

C1­C2+
C2-

T1IN
T2IN

R1OUT
R2OUT

EN
SHDN

U3D

74LVC04/SO

T

VCC_33V

1918

VCCGND

T1OUT
T2OUT

3

V+

7

V-

17
8

16

R1IN

9

R2IN

14

NC

11

NC

SP3222EBCA
GND

Title

C5

0.1uF

R5

68

R6
2R7

PA5_TX

D0

IRDA_SD

PA4_RXD

XP 4K 8 pin MD

C1

0.1uF

0

U4

P2
1
6
2
7
3
8
4
9
5

DB9 Female

USER

T

ZHX181

0

CONSO

0

GND

TXD0
CTS0
RXD

C9

330nF

5

VCC

1

LEDA

2

TXD

4

SD

0

3

RXD

6

GND

S Processor Module. Schematic.

LE

Figure 3. Schematic for Z8 Encore! XP F042A Series 8-Pin MCU Development Board

UM018705-0508 Schematics

Z8 Encore! XP

PA0_JP

®

F042A Series 8-Pin Development Kit

User Manual

13

PA0_JP

PA1_JP
R17

0

R19
0

VCC_33VVCC_33VVCC_33VVCC_33VVCC_33VVCC_33V

R12
10K

S1

1 2

TES

VCC_33V

PA0
PA1
PA2_JP

R21

220K

Y1

1

1

2

2

20 MHz

TABLE

3

3

1

T

PA3_CTS

0

C13

8 pin foot

print

U5

VSS

VDD

2 7

PA0 PA5

3

PA1

PA4

4

PA2

PA3

Z8F04xA_8pin

R20
0

C11

NOTE

2

81

PA5_JP
PA4_JP

6

PA3_JP

5

VCC_33V

GND

R16

0

C10

Clock Mode R16 R17 R19 R20

Internal Note 2 Note 2 none none no

Ceramic Res none none 0 Ohm 0 Ohm 22

Crystal none none 0 Ohm 0 Ohm 22

GND

R11

10

0

R13

10

0

R15

10

0

D2

2 1

LED

D3

2 1

LED

D4

2 1

LED

PA3_CTS

0

PA4_RXD

0

PA5_TX

D0

R21 C10 C11 Y1

ne none none none

0K 10-20pF 10-20pF user

select

0K 10-20 pF 10-20 pF user

select

LED_G

DEMO USER

GREEN

LED_Y

YEL

DEMO USER

LED_R

RED

DEMO USER

PA3_CTS

0

DEMO USER

PA4_RXD

0

DEMO USER

PA5_T

XD0

PA1_JP

PA2_JP

PA3_JP

PA4_JP

PA5_JP

123

Header 3

PA0

123

Header 3

123

Header 3

123

Header 3

123

Header 3

123

Header 3

PA0_MDS

J3

J4

PA1

PA2

J5

J6

J8

PA3

J9

PA4

1
2

HEADER 2

PA1_MDS

PA2_MDS

J7

HEADER 2

PA3_MDS

PA4_MDS

PA5_MDS

DBG

DBG

1
2

RESET

USERDEMO

J10

PA5

Note 2:
The XP supports internal oscillator, extern
resonator, external R/C and external CMOS dr
R17, R19, R20, R21, C10, C11 and Y1 are used to
selected. The development board is shipped c
oscillator. When using internal oscilator, p
as GPIO ports PA0 and PA1. Table 1 shows th
configurati

ons.

Note

1:
If Module is plugged onto the De
RS232 interface is disabled

VCC_33V

SW1

GND

RESET

-RESET

al crystal, or ceramic

ive clock modes. R16,

support the clock mode

onfigured for internal

ins 2 and 3 could be used

e recommended clock mode

R14

10K

v Platform the local

by pin 50 of JP2

VCC_33V

GND

PA3_MDS
PA4_MDS PA5_MDS

GND

-RESET-RESE
VCC_33V

T

VCC_33V

1
3
5
7

9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59

Connector
for referen
only

-TRS

TN

-F91_WE

GND

A6 A0
A10

GND

A8
A13
A15

A19
A11

A4
A5

A21
A22

-CS0

-CS2
D1
D3
D5
D7

-MREQ

GND

-WR

-BUSACK

Title

XP 4K 8pin

SizeDocument Number

B

Date:

MDS Processor Module. Schematic.

Tuesday, December 14, 2004

96C

JP2

connecto

HEADER 30x2/SM

JP1

1
3
5
7

9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59

HEADER 30x2/SM

0964-001

2
4
6
8

GND

10
12
14
16

PA0_MDS

18

PA1_MDS

20

PA2_MDS

22
24
26
28

GND

30
32
34
36
38
40
42
44
46
48
50

-DIS_IrDA

52
54
56
58
60

JP1

ce

2
4
6
8

VCC_33V

10
12

A3

14

VCC_33V

16

A7

18

A9

20

A14

22

A16A18

24

GND

26

A1A2

28

A12

30

A20

32

A17

34

-DIS_FLASH

36

VCC_33V

38

A23

40

-CS1

42

D0

44

D2

46

D4

48

GND

50

D6

52

-IOREQ

54

-RD

56

-INSTRD

58

-BUSREQ

60

Sheet

22

GND

GND

of

r 2

-DIS_232

-DIS_IRDA

Rev

B

Figure 4. Schematic for Z8 Encore! XP F042A Series 8-Pin MCU Development Board

UM018705-0508 Schematics

Z8 Encore ! XP® F042A Series 8-Pin Development Kit

Customer Support

For answers to technical questi ons about the product, documentation, or
any other issues with Zilog’s offerings, please visit Zilog’s Knowledge
Base at http://www.zilog.com/kb

For any comments, detail technical questions, or reporting problems,
please visit Zilog’s Technical Support at http://support.zilog.com

User Manual

14

.

.

UM018705-0508 Customer Support

Z8 Encore ! XP® F042A Series 8-Pin Development Kit

User Manual

15

Warning:

DO NOT USE IN LIFE SUPPORT

LIFE SUPPORT POLICY

ZILOG’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL
COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE
EXPRESS PRIOR WRITTEN APPROVAL OF THE PRESIDENT AND GENERAL
COUNSEL OF ZILOG CORPORATION.

As used herein

Life support devices or systems are devices which (a) are intended for surgical implant
into the body, or (b) support or sustain life and whose failure to perform when properly
used in accordance with instructions for use provided in the labeling can be reasonably
expected to result in a significant injury to the user. A critical component is any
component in a life support device or system whose failure to perform can be reasonably
expected to cause the failure of the life support device or system or to affect its safety or
effectiveness.

Document Disclaimer

©2008 by Zilog, Inc. All rights reserved. Information in this publication concerning the
devices, applications, or technology described is intended to suggest possible uses and
may be superseded. ZILOG, INC. DOES NOT ASSUME LIABILITY FOR OR
PROVIDE A REPRESENTATION OF ACCURACY OF THE INFORMATION,
DEVICES, OR TECHNOLOGY DESCRIBED IN THIS DOCUMENT. ZILOG ALSO
DOES NOT ASSUME LIABILITY FOR INTELLECTUAL PROPERTY
INFRINGEMENT RELATED IN ANY MANNER TO USE OF INFORMATION,
DEVICES, OR TECHNOLOGY DESCRIBED HEREIN OR OTHERWISE.The
information contained within this document has been verified according to the general
principles of electrical and mechanical engineering.

Z8, Z8 Encore!, and Z8 Encore! XP are registered trademarks of Zilog, Inc. All other
product or service names are the property of their respective owners.

UM018705-0508
