ZILOG Z8C520PSC, Z8C520SSC, Z8E520PSC, Z8E520SSC Datasheet

DS97KEY2005

P R E L I M I N A R Y

1

P

RELIMINARY

P

RODUCT

S

PECIFICATION

Z8E520/C520

1

1.5 MBPS USB L

OW

-P

OWER

D

EVICE

C

ONTROLLER

F

OR

M

ULTIPROTOCOL

P

OINTING

D

EVICES

FEATURES

■

Six Vectored Interrupts with Fixed Priority

■

Processor Speed Dividable by Firmware Control

■

Operating Current: 5 mA typical in USB Mode; 2.5 mA
typical in Serial Mode (@ 3 MHz); 5 mA typical in PS/2
Mode

■

16 Total Input/Output Pins (Open-Drain/Push-Pull)
Configurable

■

6 inputs with 3 level Programmable Reference
Comparators

■

16-Bit Programmable Watch-Dog Timer (WDT) with
Internal RC Oscillator

■

Software Programmable Timers Configurable as:
– Two 8-Bit Standard Timers and One 16-Bit

Standard Timer or

– One 16-Bit Standard Timer and One 16-Bit Pulse

Width Modulator (PWM) Timer

■

Identical Masked ROM Version (Z8C520)

■

On-Chip Oscillator that accepts a Ceramic Resonator or
External Clock

■

Hardware Support for PS/2, Serial, USB, and General­Purpose I/O (GPIO)

■

Power Reduction Modes:
– STOP Mode (functionality shut down e xcept SMR)
– HALT Mode (XTAL still running-peripherals active)

■

USB SIE Compliant with USB Spec 1.0

■

4.0 VDC to 6.0 VDC Operating Range @ 0 ° C to +70 ° C

GENERAL DESCRIPTION

Zilog’s Z8E520 (OTP) and Z8C520 (Masked ROM) micro­controllers are low-power Z8

Plus

MCUs, designed for the
cost-effective implementation of USB and multiprotocol
pointing devices.

For applications demanding powerful I/O capabilities, the
Z8E520's input and output lines are grouped into two ports,
and are configurable under software control to provide tim­ing, status signals, or parallel I/O.

Both 8-bit and 16-bit timers, with a large number of user se­lectable modes, off-load the system of administering real­time tasks such as counting/timing and I/O data communi­cations.

The microcontroller clock frequency is derived from the
system clock by a programmable divider under firmware
control.

The device is capable of functioning in four distinct, select­able communications modes: PS/2, RS232, GPIO (Gener­al-purpose I/O), and USB. The communications mode de­termines the functionality of the two special serial
communications pins (PB6 and PB7). The device is placed
in the required mode when firmware sets the specified
mode bit in the communications control register. The firm­ware interface is similar in all modes. The same buffer area
in RAM will accept the data to be transmitted. Up to 8 bytes
may be loaded, and the data will actually be transmitted as
soon as the appropriate command is issued (setting In
Packet Ready in USB mode, for example).

Part ROM RAM Speed
Number (KB) (Bytes) (MHz)

Z8E520 (OTP) 6 176 12
Z8C520 (ROM) 6 176 12

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

2

P R E L I M I N A R Y

DS97KEY2005

GENERAL DESCRIPTION (Continued)

Power connections follow conventional descriptions at
right:

Connection Circuit Device

Power

V

CC

V

DD

Ground GND

V

SS

Figure 1. Z8E520 Functional Block Diagram

One 16-bit

Std. Timer

Interrupt

Control

6 Analog

Comparators

ALU

FLAG

Register

Pointer

RAM

Register File

(160 Bytes)

Machine Timing

& Inst. Control

6 K Bytes

Prg. Memory

Program

Counter

V

CC

GND

Ceramic Resonator

Port A

Port B

I/O

Two 8-bit Timers

or
One 16-bit PWM
Timer

I/O

ZIE

WDT

RC OSC

INTERNAL

Port B

(6–7)

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005

P R E L I M I N A R Y

3

1

COMMUNICATION MODES

The Z8E520/C520 allows its user to function in a variety of
communication modes. Having this freedom within a sin­gle chip opens up many possibilities when utilizing multiple
protocol applications. The modes incorporated into the
Z8E520/C520 include PS/2, RS232, GPIO, and USB. A
description of each mode is detailed below.

PS/2 Mode . The serial baud rate is fixed at 12.5 K baud.

Received data is automatically checked for parity and
framing errors while HOST abort is supported. The serial
communications pins function as PS/2 compatible DATA
(PB6) and CLOCK (PB7).

RS232 Mode. The data rate is fixed at 1200 baud. The se-

rial communications pins function as RxD (PB6) and TxD
(PB7).

GPIO Mode . In General-Purpose I/O Mode, the serial

communications pins function as standard I/O pins, with
Input, Output P/P (Push/Pull) and OD (Open Drain) Out­put.

USB Mode . The Z8E520 includes two bidirectional end-

points that support communications compliant to the USB
Specification version 1.0. The serial communications pins
function as D– (PB6) and D+ (PB7). The detailed behavior
of the SIE is controllable by the firmware, and three sepa­rate power states are provided for USB Suspend Mode
support (see section below).

USB SUSPEND/RESUME FUNCTIONALITY

Suspend is dedicated through firmware by timing the Ac­tivity bit which is set by the SIE.

In Stop Mode, with the WDT disabled, power requirements
are minimized. No power is consumed by the voltage reg­ulator, the Z8

Plus

core, nor differential detector. Only the

Stop Mode Recovery (SMR) is enabled, so an input signal

or Resume from the host can be detected and used to
wake up the microcontroller.

In Stop Mode, with the WDT enabled, slightly more power
is consumed, but the device can wake up periodically to
perform maintenance and detect a change of state in the
application.

USB FUNCTIONAL BLOCK DESCRIPTION

The USB portion of the chip is divided into two areas, the
transceiver and the Serial Interface Engine (SIE). The
transceiver handles incoming differential signals and “sin­gle ended zero (SE0)”. It also converts output data in digi­tal form to differential drive at the proper levels (Figure 2).

The SIE performs all other processing on incoming and out
going data, including signal recovery timing, bit stuffing,
validity checking, data sequencing, and handshaking to

the host. Data flow into and out of the MCU portions are
dedicated registers mapped into Expanded Register File
Memory.

The USB SIE handles three endpoints (control at Endpoint
0, data into the host from Endpoint 1 and data out from the
host as Endpoint 2). All communications are at the

1.5 MB/sec data rate. Endpoint 1 and 2 can be combined
as Control EP1.

Figure 2. Data To/From Z8E520/C520

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

4

P R E L I M I N A R Y

DS97KEY2005

PIN IDENTIFICATION

Figure 3. 20-Pin DIP/SOIC Pin Assignments

PA6

PA7
PB0
PB1
PB2
PB3
PB4
PB5

PA0

PA1

PA5
PA4
XTAL (2)
GND
XTAL (1)
VCC
PB7
PB6
PA3
PA2

20

20-Pin

DIP/SOIC

1

10 11

Table 1. 20-Pin DIP/SOIC Pin Identification

STANDARD Mode
Pin # Symbol Function Direction

1, 2 PA X(6,7) Digital I/O + I SINK Bidirectional
3–8 PB X(0–5) Digital I/O +Comparators Bidirectional
9–12 PA X(0–3) Digital I/O Bidirectional
13–14 PB X (6–7) Digital I/O + Communications Bidirectional
15 V

cc

Power

16 XTAL (1) Clock
17 GND Power
18 XTAL (2) Clock
19, 20 PA X(4,5) Digital I/O + I SINK Bidirectional

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005

P R E L I M I N A R Y

5

1

Figure 4. 20-Pin DIP/SOIC Pin Assignments:

EPROM Programming Mode

D0

D1

D2

D3

D4

D5

D6

D7

TST_CLR

PGM

CLK (1 MHz)
GND
(CLK OUT)
VCC

VPP
ADDRCLK

20

20-Pin

DIP/SOIC

1

10 11

Table 2. 20-Pin DIP/SOIC Pin Identification:

EPROM Programming Mode

EPROM PROGRAMMING Mode
Pin # Symbol Function Direction

1–8 D0–D7 Data Bus I/O
9 TST_CLR Reset Internal Address Counter In
10 PGM Program Pin In
11 ADDRCLK Clock to Address Counter In
12 V

PP

High Voltage to Program Device Power

13–14 Unused
15 V

CC

Power Power

16 CLKOUT Output from Clock Inverter Out
17 GND Power Ref Power
18 CLK 1 MHz to chip In
19 Unused
20 Unused

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

6

P R E L I M I N A R Y

DS97KEY2005

ABSOLUTE MAXIMUM RATINGS

Stresses greater than those listed under Absolute Maxi­mum Ratings may cause permanent damage to the de­vice. This rating is a stress rating only; functional operation
of the device at any condition above those indicated in the
operational sections of these specifications is not implied.
Exposure to absolute maximum rating conditions for an
extended period may affect device reliability. Total power
dissipation should not exceed 880 mW for the package.
Power dissipation is calculated as follows:

Total Power Dissipation = V

DD

x [I

DD

– (sum of I

OH

)]

+ sum of [(V

DD

– V

OH

) x I

OH

]

+ sum of (V

0L

x I

0L

)

Parameter Min Max Units Note

Ambient Temperature under Bias –40 +105 C
Storage Temperature –65 +150 C
Voltage on any Pin with Respect to V

SS

–0.6 +7 V

Voltage on V

DD

Pin with Respect to V

SS

–0.3 +7 V

Total Power Dissipation 880 mW
Maximum Allowable Current out of V

SS

80 mA

Maximum Allowable Current into V

DD

80 mA

Maximum Allowable Current into an Input Pin –600 +600

µ

A 1

Maximum Allowable Current into an Open-Drain Pin –600 +600

µ

A 2
Maximum Allowable Sink Output Current by Any I/O Pin 25 mA
Maximum Allowable Source Output Current by Any I/O Pin 25 mA
Maximum Allowable Sink Output Current by Port A 40 mA
Maximum Allowable Source Output Current by Port A 40 mA
Maximum Allowable Sink Output Current by Port B 40 mA
Maximum Allowable Source Output Current by Port B 40 mA

Notes:

1. Excludes XTAL pins.

2. Device pin is not at an output Low state.

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005

P R E L I M I N A R Y

7

1

STANDARD TEST CONDITIONS

The characteristics listed here apply for standard test con­ditions as noted. All voltages are referenced to GND. Pos­itive current flows into the referenced pin (Figure 5).

CAPACITANCE

T

A

= 25 ° C; V

CC

= GND = 0V; f = 1.0 MHz; unmeasured pins returned to GND.

Figure 5. Test Load Diagram

From Output

Under Test

150 pF

Parameter Max

Input Capacitance 12 pF
Output Capacitance 12 pF
I/O Capacitance 12 pF

Note: Frequency tolerance ±10%

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

8 P R E L I M I N A R Y DS97KEY2005

DC CHARACTERISTICS: USB MODE

V

cc

= 4.4V – 5.25V

TA = 0°C to +70°C

Sym Parameter

V

CC

Min Max Units Conditions Notes

V

CH

Clock Input High
Voltage

0.7V

CC

VCC+0.3 V Driven by External

Clock Generator

V

CL

Clock Input Low
Voltage

VSS–0.3 0.2V

CC

V Driven by External

Clock Generator

V

IH

Input High Voltage 0.7V

CC

VCC+0.3 V

V

IL

Input Low Voltage VSS–0.3 0.2V

CC

V

V

OH

Output High Voltage
(Port A, B)

VCC–0.4 V IOH = –2.0 mA

V

OL1

Output Low Voltage
(Port A, B)

0.6 V IOL = +4.0 mA 4

V

OL2

Output Low Voltage
(Port A, B)

1.2 V IOL = +6 mA, 4

V

OFFSET

Comparator Input Offset
Voltage

25.0 mV

I

IL

Input Leakage –1.0 2.0 µA VIN = 0V, V

CC

I

OL

Output Leakage –1.0 2.0 µA VIN = 0V, V

CC

V

ICR

Comparator Input
Common Mode
Voltage Range

VSS–0.3 V

CC

–1.0 V

I

CC

Supply Current 6.0V 5.25 6.0 mA @ 6 MHz (Internal open

drain)

1,2

I

CC1

HALT Mode 6.0V 3.5 mA @ 6 MHz (no CPU; RC/WDT

& Detect; D+/D–; I/O active)

1,2

I

CC2

Stop Current 60 µA

I

CC3

Stop Current w/o RC/WDT 40 µA

D+, D– Differential Signaling D– > D+ D+ > D– mV @ >200 mV Difference 3

Notes:

1. All outputs unloaded, I/O pins floating, and all inputs are at V

CC

or VSS level.

2. CL1 = CL2 = 22 pF

3. Except for SE0 for EOP and Reset (see 7.1.4 of USB Specification)

4. General-Purpose I/O Mode.

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 9

1

DC CHARACTERISTICS: PS/2 MODE

V

cc

= 4.5V – 5.5V

TA = 0°C to +70°C

Sym Parameter

V

CC

Min Max Units Conditions Notes

V

CH

Clock Input High
Voltage

0.7V

CC

VCC+0.3 V Driven by External

Clock Generator

V

CL

Clock Input Low
Voltage

VSS–0.3 0.2V

CC

V Driven by External

Clock Generator

V

IH

Input High Voltage 0.7V

CC

VCC+0.3 V

V

IL

Input Low Voltage VSS–0.3 0.2V

CC

V

V

OH

Output High Voltage VCC–0.4 V IOH = –2.0 mA

V

OL1

Output Low Voltage 0.6 V IOL = +4.0 mA

V

OL2

Output Low Voltage 1.2 V IOL = +6 mA,

V

OFFSET

Comparator Input Offset
Voltage

25.0 mV

I

IL

Input Leakage –1.0 2.0 µA VIN = 0V, V

CC

I

OL

Output Leakage –1.0 2.0 µA VIN = 0V, V

CC

V

ICR

Comparator Input
Common Mode
Voltage Range

VSS–0.3 V

CC

–1.0 V

I

CC

Supply Current 5.5V 6.0 mA @ 6 MHz 1,2

I

CC1

HALT Current 5.5V 3.5 mA @ 6 MHz (no CPU; no SIE) 1,2

I

CC2

Stop Current 60 µA

I

CC3

Stop Current w/o RC/WDT 40 µA

Notes:

1. All outputs unloaded, I/O pins floating, and all inputs are at V

CC

or VSS level.

2. CL1 = CL2 = 22 pF.

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

10 P R E L I M I N A R Y DS97KEY2005

DC CHARACTERISTICS: RS232 MODE

V

cc

= 4.0V – 6.0V

TA = 0°C to +70°C

Sym Parameter

V

CC

Min Max Units Conditions Notes

V

CH

Clock Input High
Voltage

0.7V

CCVCC

+0.3 V Driven by External

Clock Generator

V

CL

Clock Input Low
Voltage

VSS–0.3 0.2V

CC

V Driven by External

Clock Generator

V

IH

Input High Voltage 0.7V

CCVCC

+0.3 V

V

IL

Input Low Voltage VSS–0.3 0.2V

CC

V

V

OH

Output High Voltage VCC–0.4 V IOH = –2.0 mA

V

OL1

Output Low Voltage 0.6 V IOL = +4.0 mA

V

OL2

Output Low Voltage 1.2 V IOL = +6 mA,

V

OFFSET

Comparator Input Offset
Voltage

25.0 mV

I

IL

Input Leakage –1.0 2.0 µA VIN = 0V, V

CC

I

OL

Output Leakage –1.0 2.0 µA VIN = 0V, V

CC

V

ICR

Comparator Input
Common Mode
Voltage Range

VSS–0.3 V

CC

–1.0 V

I

CC

Supply Current 6.0V 4.0 mA @ 3 MHz (6 MHz/2) 1,2

I

CC1

HALT Mode 6.0V 3.5 mA @ 3 MHz 1,2

I

CC2

Stop Current 60 µA

I

CC3

Stop Current w/o
RC/WDT

40 µA

Notes:

1. All outputs unloaded, I/O pins floating, and all inputs are at V

CC

or VSS level.

2. CL1 = CL2 = 22 pF.

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 11

1

DC CHARACTERISTICS: I/O MODE

V

cc

= 4.0V – 6.0V

TA = 0°C to +70°C

Sym Parameter

V

CC

Min Max Units Conditions Notes

V

CH

Clock Input High
Voltage

0.7V

CC

VCC+0.3 V Driven by External

Clock Generator

V

CL

Clock Input Low
Voltage

VSS–0.3 0.2V

CC

V Driven by External

Clock Generator

V

IH

Input High Voltage 0.7V

CC

VCC+0.3 V

V

IL

Input Low Voltage VSS–0.3 0.2V

CC

V

V

OH

Output High Voltage VCC–0.4 V IOH = –2.0 mA

V

OL1

Output Low Voltage 0.6 V IOL = +4.0 mA

V

OL2

Output Low Voltage 1.2 V IOL = +6 mA,

V

OFFSET

Comparator Input Offset
Voltage

25.0 mV

I

IL

Input Leakage –1.0 2.0 µA VIN = 0V, V

CC

I

OL

Output Leakage –1.0 2.0 µA VIN = 0V, V

CC

V

ICR

Comparator Input
Common Mode
Voltage Range

VSS–0.3 V

CC

–1.0 V

I

CC

Supply Current 6.0V 6.0 mA @ 6 MHz 1,2

I

CCA

5.5V 6.0 mA @ 5.5V 1,2

I

CCB

4.0 mA @ 6.0V (6 MHz/2)

I

CC1

HALT w/ RC and WDT 60 µA

I

CC2

50 µA

Notes:

1. All outputs unloaded, I/O pins floating, and all inputs are at V

CC

or VSS level.

2. CL1 = CL2 = 22 pF.

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

12 P R E L I M I N A R Y DS97KEY2005

AC ELECTRICAL CHARACTERISTICS

Timing Diagram

Timing Table

Figure 6. AC Electrical Timing Diagram

1 3

3

2

2

CLOCK

IRQ

N

8

9

TA = 0°C to +70°C

6 MHz

No Symbol Parameter Min Max Units Notes

1 TpC Input Clock Period 83 DC ns 1
2 TrC,TfC Clock Input Rise & Fall Times 5 ns 1
3 TwC Input Clock Width 37 ns 1
4 TwTinL Timer Input Low Width 70 ns 1
5 TwTinH Timer Input High Width 2.5TpC 1
6 TpTin Timer Input Period 4TpC 1
7 TrTin Timer Input Rise & Fall Timer 100 ns 1
8 TwIL Int. Request Low Time 70 ns 1,2
9 TwIH Int. Request Input High Time 3TpC 1,2
10 Twsm Stop-Mode Recovery Width Spec 100TpC ns
11 Tost Oscillator Start-Up Time 0.5 ms
12 Twdt Watch-Dog Timer 1000 ms
13 D+, D– Differential Rise and Fall Times (USB Mode) 70 300 nS 3
14 POR Power supply; POR rate/Volt level
15 TrC RC Clock Period (internal) 12.5 50 µsec 4

Notes:

1. Timing Reference uses 0.7 V

CC

for a logic 1 and 0.2 VCC for a logic 0.

2. Interrupt request

3. See USB Specification 7.1.1.2

4. Corresponds to frequencies of 80 KHz to 20 KHz

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 13

1

PIN FUNCTIONS

Port A. Port A (4–7) includes a Sink configuration. Port A

(3–0) has a Switch configuration.
In Sink, the options include input wakeup, bidirectional,

push-pull or open drain configurations (Figure 7). The Sink
is programmable from 0–15 mA (in 1 mA increments).

In Switch, the options also include input wakeup, bidirec­tional, push-pull or open drain configurations (Figure 8).
The only difference between the two is the programmable
Sink option.

Figure 7. Port A (4–7) Sink Configuration

Table 3. Port A (4–7) Programmable Current Sink Table

Symbol Parameter Min. Max. Units Conditions

N Number of Bits Bits 4 bits, 16 settings, 0–15 mA
DNL Diff Non-Linearity 0.50 LSB
I

0

Zero Code/Disable µA Disabled

I

LSB

LSB Current 0.65 1.35 mA 35%

I

F

Full Scale Current 9.75 20.25 mA 35%, Note 1

T

settle

Settling Time 1600 nS Within 10% of final value

I

overshoot

Overshoot Current 1.05*I

set

µA

V

comp

Compliance Voltage 1.1 V Above V

ss

with I

FMAX

Notes:

1. Setting all (4) I

SNK

cells to full scale is a violation of the Absolute Maximum Rating Spec.

0–15 mA/ 1 mA increments

Pad

100K

In

Vcc

Vcc

Wake

TBD

± 30%

I SINK (3:0)

Pullup Resistor Enable

Typical

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

14 P R E L I M I N A R Y DS97KEY2005

PIN FUNCTIONS (Continued)

Figure 8. Port A (0–3) Switch Configuration

Pad

100K

Pull-down Resistor Enable

In

Wake

Vcc

(± 35%)

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 15

1

Port B. Port B (0–5) includes a Quadrature configuration

(Figure 9), with programmable current sink and an analog

comparator with programmable reference voltages (Ta­bles 4–8).

PORT B (0–5) QUADRATURE CONFIGURATION

Figure 9. Port B (0–5) Quadrature Configuration

Table 4. Programmable Voltage Threshold

Symbol Parameter Min. Max. Units Conditions

V

R1

Voltage Reference 1 0.21 V

CC

0.29 V

CC

V

V

R2

Voltage Reference 2 0.31 V

CC

0.39 V

CC

V

V

R3

Voltage Reference 3 0.41 V

CC

0.49 V

CC

V

Ratio Ratio Accuracy 5 % Note (1)

Note:

1. Greatest delta vs. specified delta.

Pad

AC

AC

Decode

V

R1

VR3

VR2

+ V

+V

AC = Analog Comparator Mode

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

16 P R E L I M I N A R Y DS97KEY2005

PORT B (0–5) QUADRATURE CONFIGURATION (Continued)

Table 5. Programmable Voltage Bit Selections (Register Addresses DA–DF)

Comp Enable—Bit D7

V

REF

— Bits D5:4

Selected Conditions

0 xx Comparator Off Note (1)
1 01 0.25 V

CC

1 10 0.35 V

CC

1 11 0.45 V

CC

Note:

1. If all comparators are off, V

REF

can be powered off. If in Stop Mode, V

REF

is powered off.

Table 6. Programmable Load Resistor

Symbol Parameter Min. Max. Units Conditions

V

MID

Midpoint Voltage 0.13 V

CC

0.15 V

CC

V

R

L1

Load Resistor 1 5.25 8.75 K ohm Pad to VSS, track RL2, R

L3

R

L2

Load Resistor 2 9.00 15.00 K ohm Pad to VSS, track RL1, R

L3

R

L3

Load Resistor 3 13.50 22.50 K ohm Pad to VSS, track RL1, R

L2

R

L4

Load Resistor 4 32.25 53.75 K ohm Pad to VCC

R

L5

Load Resistor 5 55.50 92.50 K ohm Pad to VCC

R

L6

Load Resistor 6 83.25 138.75 K ohm Pad to VCC

Ratio Ratio Accuracy 5 % Note (1)

Note:

1. Greatest ratio vs. specified ratio.

Table 7. Programmable Load Resistor Bit Selections (Register Addresses DA–DF

Divider Bits D2:0

Load Selected to V

SS

Load Selected to V

CC

000 No load Resistors No load Resistors
001 7 K Selected 43 K Selected
010 12 K Selected 74 K Selected
100 18 K Selected 111 K Selected

Table 8. Comparator

Symbol Parameter Min. Max. Units Conditions

VOS Offset Voltage 25 mV
HYS Hysteresis TBD TBD mV Common Mode, Note (1)
VCM Voltage Range VSS–0.3 VCC–1.0 V

T

rf

Response Time Fast 1 µs 700 mV/µs with 25 mV overdrive

T

rs

Response Time Slow 1 µs 15 mV/µs with 25 mV overdrive

IDD Supply Current 100 µA

Note:

1. Zilog will provide specification.

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 17

1

Port B. Port B (6–7) is configured as a serial communica-

tion port as follows:

Port B (6) has a programmable internal pullup of 7.5 K ±
30%. For USB Mode, Port B (7) requires an external pullup
of 7.5 K ± 1% to VCC (Figure 10).

USB PS/2 RS232 GPIO

Port B (6) D– Data R x D Port B (6)
Port B (7) D+ Clock T x D Port B (7)

Figure 10. Port B (6–7) Serial Communication Port

Pad

Pull-up Resistor Enable

In/Wake

VUSB

7.5 K Pullup

Vcc

Vcc

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

18 P R E L I M I N A R Y DS97KEY2005

FUNCTIONAL DESCRIPTION

Program Memory. The 16-bit program counter addresses

6 KB of program memory space at internal locations
(Figure 11).

The first 14 bytes of program memory are reserved for the
rollover and interrupt vectors. These locations have six
16-bit vectors that correspond to the six available inter­rupts.

Figure 11. Z8E520 Program Memory Map

IRQ0

IRQ1

IRQ2

IRQ3

IRQ4

IRQ5

HEX

17FF

00D
00C
00B
00A
009
008
007
006
005
004
003
002
001
000

00E

01F

020

021

LOCATION OF FIRST
BYTE OF INSTRUCTION
EXECUTED AFTER
RESET

AVAILABLE TO USER (AREA INTENDED

FOR FUTURE ADDITIONAL INTERRUPTS)

ON-CHIP EPROM PROGRAM MEMORY

DECIMAL

ADDRESS

6143

33
32
31

14
13
12
11
10

9
8
7
6
5
4
3

2
1

0

IRQ0

IRQ1

IRQ2

IRQ3

IRQ4

IRQ5

PC ROLLOVER VECTOR (Upper Byte)

PC ROLLOVER VECTOR (Lower Byte)

INTERRUPT VECTOR (Lower Byte)
INTERRUPT VECTOR (Upper Byte)

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 19

1

Register File. The register file consists of the following:

160 General-Purpose Registers in group 0–7, SIE Buffers
in group 8–A, SIE Control in group B, Timer/Counters in

group C, Configuration Registers in group D, Virtual Reg­isters in group E and System Registers in Group F
(Figure 12).

Figure 12. Register Files

Table 9. EP Modes for SIE Buffer (In USB Mode)

EP Mode Description

Buffer Address

0x88–0x8F 0x98–0x9F 0xA8–0xAF

000 EP1 OFF, EP2 OFF GPR GPR GPR
001 EP1 IN, EP2 OFF GPR GPR EPI IN Buffer
010 EP1 OUT, EP2 OFF GPR GPR EP1 OUT Buffer
011 EP1 CONTROL EP1 SETUP Buffer EP1 OUT Buffer EP1 IN Buffer
100 EP1 OUT, EP2 OUT GPR EP2 OUT Buffer EP1 OUT Buffer
101 EP1 IN, EP1 OUT GPR EP1 OUT Buffer EP1 IN Buffer
110 EP1 OUT, EP1 IN GPR EP1 IN Buffer EP1 OUT Buffer
111 EP1 IN, EP2 IN GPR EP2 IN Buffer EP1 IN Buffer

0

1

4

2

3

5

6

7

8

9

A

B

C

D

E

F

General-Purpose

Registers

System Registers

Virtual Registers

I/O Configuration

Timer/Counter

SIE Control

EP0 OUT Buffer

EP0 IN Buffer

EP0 SETUP Buffer

XMIT Buffer

RECEIVE Buffer

General Purpose RAM

A
9
8

Depends on

EP Mode

(See Table Below)

SIE Buffers
(for PS/2 or RS232-C Mode)

SIE Buffers

(for USB Mode)

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

20 P R E L I M I N A R Y DS97KEY2005

FUNCTIONAL DESCRIPTION (Continued)

Figure 13. System Registers

F0

F1

F4

F2

F3

F5

F6

F7

F8

F9

FA

FB

FC

FD

FE

FF

IREQ

IMASK

FLAGS

REGPTR

RESERVED

STACK POINTER

RESERVED

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 21

1

Figure 14. T/C Control Registers

C0

C1

C4

C2

C3

C5

C6

C7

C8

C9

CA

CB

CC

CD

CE

CF

TCTLLO

TCTLHI

WDTLO

WDTHI

T0ARLO

T1ARLO

T0ARHI

T1ARHI

T2AR

T3AR

T2CNT

T3CNT

T0CNT

T1CNT

RESERVED

RESERVED

READ
ONLY

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

22 P R E L I M I N A R Y DS97KEY2005

FUNCTIONAL DESCRIPTION (Continued)

Figure 15. COMM Registers (USB Mode: B0–BF)

ADDR

B0

B1

B2

B3

B4

B5

B6

B7

B8

B9

BA

BB

BC

BD

BE

BF

NAME

D7 D6

D5 D4 D3

D2 D1 D0

PORT A

PORT B

ADDR

SIE MODE

USB CSR

LOW

PRIORITY

INTR

LOW

PRIORITY

MASK

HIGH

PRIORITY

INTR
HIGH

PRIORITY

MASK

EP0

CSR

USB ADDRESS 6:0

SIE

POWER

RESUME

FORCE

RESUME

NAK

SENT

EP1

ACTIVITY

NAK

SENT

EP0

SIE MODE 7:0

STALL

SENT

EP2

A7 A6 A5 A4 A3 A2 A1 A0

B5 B4 B3 B2 B1 B0

EP MODE 2:0

DEPENDS ON EP MODE

(SEE TABLE 10)

DEPENDS ON EP MODE

(SEE TABLE 10)

STALL

SENT

EP1

STALL

SENT

EP0

SETUP

EP1

SETUP

EP0

SAME AS HIGH PROIORITY INTR

ACK

STATUS

OUT

SETUP

BUFFER

VOLATILE

OUT

SERVICED

OUT

DATA

TOGGLE

FORCE

STALL

FORCE

NAK

IN

PACKET

READY

IN

DATA

TOGGLE

EP1/2

CSR

DEPENDS ON EP MODE

(SEE TABLE 11)

EP0

COUNT

EP0 OUT COUNT 3:0 EP0 IN COUNT 3:0

EP1/2

COUNT

DEPENDS ON EP MODE

(SEE TABLE 12)

RS232 PS/2

USB

J STATE

B7 B6

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 23

1

COMMUNICATION REGISTER DEFINITIONS (USB MODE)

The following definitions on pages 23–26 describe in detail
the specific USB mode registers as illustrated in Figure 15.

PORT A, PORT B: I/O Port data registers. At all times, a
read to this port should indicate the current state at the
pins. Read/Write.

ADDR: Determines the USB Device Address. Cleared by
USB or POR Reset. Read/Write.

SIE MODE: Determines the mode of the SIE communica­tion pins (Port B7:6). Read/Write. The SIE modes are as
follows:

GPIO: The SIE is off and the communication lines are
standard I/O pins on Port B.

USB: Port B7 is D+, which connects to pin 3 on a series A,
or series B USB connector and whose conductor is green.
Port B6 is D–, which connects to pin 2 on a series A or se­ries B USB connector and whose conductor is white. An
external 7.5K pull-up should be provided for D–.

PS/2: Port B7 is CLOCK, which connects to pin 5 on a
male 6-pin Mini-DIN connector and Port B6 is DATA, which
connects to pin 1 on a male 6-pin Mini-DIN connector.
These signals are open-drain. The CLOCK pin has an

available 7.5 K ohm pull-up internal to the chip. An external

7.5 K ohm pull-up should be provided for DATA.
RS232: Port B7 is serial data out (T x D). Port B6 is serial

data in (R x D). These signals are CMOS-level signals,
positive logic. Appropriate transceiver circuitry must be
added externally to comply with RS232-C signal levels at
the device connector.

SIE POWER: Powers up the SIE when USB Resume sig­naling has been received, or shuts down SIE in prepara­tion for USB Suspend. Read/Write.

FORCE RESUME: Forces a K state on the USB pins.
Read/Write.

ACTIVITY: This bit is set by the SIE when the state of the
USB pins changes. Read/Write.

J STATE: This bit is set when the USB is in the ‘J’ state
and cleared when in ‘K’ or ‘SE0’. Read only.

EP MODE: These bits define the operation of the non-zero
endpoints of the SIE. Changing this mode resets the SIE,
while writing the same value does not. Read/Write. The
EP modes are as follows:

SIE Mode Description Port B7 Port B6

00000000 GPIO I/O I/O
00000001 USB D+ D–
00000010 PS/2 CLOCK DATA
00000100 RS232-C 1200 Baud

N81 Full Duplex

DATA IN DATA OUT

Other Reserved Reserved Reserved

EP Mode Description

000 EP1 OFF, EP2 OFF
001 EP1 IN, EP2 OFF
010 EP1 OUT, EP2 OFF
011 EP1 CONTROL
100 EP1 OUT, EP2 OUT
101 EP1 IN, EP1 OUT
110 EP1 OUT, EP1 IN
111 EP1 IN EP2 IN

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

24 P R E L I M I N A R Y DS97KEY2005

COMMUNICATION REGISTER DEFINITIONS (USB MODE) (Continued)

LOW PRIORITY INTR: This register contains the IRQ

source flags of a low-priority communications interrupt.
The ISR should check these bits to determine the cause of
the interrupt. The definition of these bits depends on the
EP Mode as specified in the USB CSR. Writing a 1 to their
position clears interrupt sources. Read/Write.

LOW PRIORITY MASK: This register contains mask bits
for the IRQ sources specified in the LOW PRIORITY INTR
register. A set bit indicates that the corresponding interrupt
source is unmasked.

Table 10 illustrates both Low Priority MASK and INTR con­ditions according to EP Mode:

IN DONE: The SIE received a valid IN token, sent the data
packet and received an ACK from the host. Setting this bit
by the SIE, clears IN PACKET READY and IN NAK SENT.
SIE may never write to the IN buffer.

IN NAK SENT: The SIE sent a NAK on an IN transmission
because IN PACKET READY was clear.

OUT PACKET READY: The SIE received a valid OUT
packet and placed the received data, if any, in the buffer,
thereby updating the OUT count register and sending an
ACK. Setting this bit by the SIE clears OUT SERVICED
and OUT NAK SENT. Firmware may never write to the
OUT buffer.

OUT NAK SENT: The SIE sent a NAK on an OUT trans­action because OUT SERVICED was clear. If an OUT
packet was NAK’d, OUT DATA TOGGLE and the OUT
buffer

must not be affected.

Table 10. Low Priority MASK and INTR Conditions

EP

MODE Description EP 2 EP 1 EP 0

000 EP1 OFF, EP2 OFF OUT

NAK

SENT

OUT

PACKET

READY

IN

NAK

SENT

IN

DONE

001 EP1 IN EP2 OFF IN

NAK

SENT

IN

DONE

OUT
NAK

SENT

OUT

PACKET

READY

IN

NAK

SENT

IN

DONE

010 EP1 OUT, EP2 OFF OUT

NAK

READY

OUT

PACKET

READY

OUT
NAK

SENT

OUT

PACKET

READY

IN

NAK

SENT

IN

DONE

011 EP1 CONTROL OUT

NAK

SENT

OUT

PACKET

READY

IN

NAK

SENT

IN

DONE

OUT

NAK

SENT

OUT

PACKET

READY

IN

NAK

SENT

IN

DONE

100 EP1 OUT, EP2 OUT OUT

NAK

SENT

OUT

PACKET

READY

OUT
NAK

SENT

OUT

PACKET

READY

OUT
NAK

SENT

OUT

PACKET

READY

IN

NAK

SENT

IN

DONE

101 EP1 IN, EP1 OUT OUT

NAK

SENT

OUT

PACKET

READY

IN

NAK

SENT

IN

DONE

OUT

NACK

SENT

OUT

PACKET

READY

IN

NAK

SENT

IN

DONE

110 EP1 OUT, EP1 IN IN

NAK

SENT

IN

DONE

OUT
NAK

SENT

OUT

PACKET

READY

OUT
NAK

SENT

OUT

PACKET

READY

IN

NAK

SENT

IN

DONE

111 EP1 IN EP2 IN IN

NAK

SENT

IN

DONE

IN

NAK

SENT

IN

DONE

OUT

NACK

SENT

OUT

PACKET

READY

IN

NAK

SENT

IN

DONE

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 25

1

HIGH PRIORITY INTR: This register contains the IRQ

source flags of a high-priority communications interrupt.
The ISR should check these bits to determine the cause of
the interrupt. Writing a 1 to their position clears interrupt
sources. Read/Write.

■ RESUME: This bit is set when the ACTIVITY bit is set in

the USB CSR, allowing the device to wake up on any
activity of the USB.

■ STALL SENT EP2: This bit is set when a STALL is sent

on EP2. This bit is valid only in EP modes 100, 101, 110
and 111.

■ STALL SENT EP1: This bit is set when a STALL is sent

on EP1. This bit is not valid in EP mode 000.

■ STALL SENT EP0: This bit is set when a STALL is sent

on EP0.

■ SETUP EP1: This bit is set after the completion of the

setup stage of a control transfer on EP1. This bit is valid
only in EP mode 011.

■ SETUP EP0: This bit is set after the completion of the

setup stage of a control transfer on EP0.

HIGH PRIORITY MASK: This register contains mask bits
for the IRQ sources specified in the HIGH PRIORITY INTR
register. A set bit indicates that the corresponding interrupt
source is unmasked.

EP0 CSR: Control/Status register of Endpoint 0 (Control
pipe).

EP1/2 CSR: Control/Status register of additional end­points. The definition of these bits depends on the EP
Mode as specified in the USB CSR. Read/Write.

Table 11 illustrates the EP1/2 CSR registers according to
EP Mode:

FORCE STALL: Forces the SIE to stall all IN and OUT
transactions. The successful receipt of a setup token
clears this bit. STALL takes priority over NAK or ACK.
Read/Write.

IN PACKET READY: When clear, IN transactions are
NAK’d. This bit cannot be cleared by firmware. To clear it,
firmware should be set FORCE NAK. Firmware must not
write to the IN buffer or IN COUNT while this bit is set. It is
cleared when the SIE sets IN DONE or when the SIE re-

Table 11. EP 1/2 CSR Registers (BA)

EP

MODE Description EP 1

000 EP1 OFF, EP2 OFF FORCE

STALL

FORCE

NAKINPACKET

READY

IN

DATA

TOGGLE

001 EP1 IN EP2 OFF FORCE

STALL

FORCE

NAKINPACKET

READY

IN

DATA

TOGGLE

010 EP1 OUT, EP2 OFF FORCE

STALL

FORCE

NAK

OUT

PACKET

READY

OUT

DATA

TOGGLE

011 EP1 CONTROL ACK

STATUS

OUT

SETUP

BUFFER

VOLATILE

OUT

SERVICED

OUT

DATA

TOGGLE

FORCE

STALL

FORCE

NAKINPACKET

READY

IN

DATA

TOGGLE

100 EP1 OUT, EP2 OUT FORCE

STALL

FORCE

NAK

OUT

SERVICED

OUT

DATA

TOGGLE

FORCE

STALL

FORCE

NAK

OUT

PACKET

READY

OUT

DATA

TOGGLE

101 EP1 IN, EP1 OUT FORCE

STALL

FORCE

NAK

OUT

SERVICED

OUT

DATA

TOGGLE

FORCE

STALL

FORCE

NAKINPACKET

READY

IN

DATA

TOGGLE

110 EP1 OUT, EP1 IN FORCE

STALL

FORCE

NAK

IN

PACKET

READY

IN

DATA

TOGGLE

FORCE

STALL

FORCE

NAK

OUT

PACKET

READY

OUT

DATA

TOGGLE

111 EP1 IN EP2 IN FORCE

STALL

FORCE

NAK

IN

PACKET

READY

IN

DATA

TOGGLE

FORCE

STALL

FORCE

NAKINPACKET

READY

IN

DATA

TOGGLE

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

26 P R E L I M I N A R Y DS97KEY2005

COMMUNICATION REGISTER DEFINITIONS (USB MODE) (Continued)

ceives a valid setup token (via FORCE NAK). Setting IN
PACKET READY clears IN NAK SENT. Read/Set.

FORCE NAK: Setting this bit clears IN PACKET READY if
no IN transaction are in progress, and clears OUT SER­VICED and ACK STATUS OUT if no OUT transactions are
in progress. This bit is cleared by a setup token or by firm­ware. Read/Write.

IN DATA TOGGLE: Indicates what type of PID to use in
the data phase of the next IN transaction. SIE may never
write to this bit. Read/Write.

OUT SERVICED: When cleared, OUT transactions are
NAK’d. It is cleared when the SIE sets OUT PACKET
READY or receives a valid setup token (via FORCE NAK).
This bit cannot be cleared by firmware. To clear it, firm­ware should be set FORCE NAK. When set, OUT COUNT
and OUT buffer are volatile. Setting OUT SERVICED
clears OUT N AK SENT. Read/Set.

OUT DATA TOGGLE: Indicates what type of PID was re­ceived in the data phase of the most recent successful
OUT transaction. Read only.

SETUP BUFFER VOLATILE: Indicates that the SIE has
entered the data stage of a control transfer. The successful
receipt of a setup token sets and locks this bit. The bit re­mains locked as set until the data phase is complete and
error free. If the data phase has an error, this bit will re­mained locked, but a setup interrupt will still occur to inform
the firmware that a new transfer was attempted. After the
data phase is received without errors, firmware may clear
this bit. Read/Clear (if unlocked).

ACK STATUS OUT: This bit serves to filter the response
to an OUT transaction. Setting this bit also sets OUT SER­VICED. This bit cannot be cleared by firmware. To clear it,
firmware should be set FORCE NAK. Read/Set.

While ACK STATUS OUT is set:

■ If IN NAK SENT is clear, the SIE will ACK an empty OUT

DATA 1 transaction.

■ If IN NAK SENT is set, the SIE will NAK an empty OUT

DATA 1 transaction.

■ Any other kind of OUT transaction will be stalled and set

the STALL SENT interrupt. It is possible to have both
STALL SENT and OUT PACKET READY set on a
single, incorrect OUT transaction.

■ Any out transaction will cause the SIE to set FORCE

NAK and OUT PACKET READY. As a result, ACK
STATUS OUT is cleared. ACK STATUS OUT has “one­shot” behavior. It only handles one OUT transaction.

■ The successful receipt of a setup token sets FORCE

NAK, which clears this bit.

EP0 COUNT: Contains counts of bytes in the endpoint
buffers.

EP1/2 COUNT: Contains counts of bytes in the endpoint
buffers. Definition of this register depends on the EP Mode
as illustrated in Table 12:

EP OUT COUNT: Set by the SIE to indicate the number of
bytes received in the most recent OUT transaction. Invalid
while OUT SERVICED is set.

EP IN COUNT: Set by firmware to indicate the number of
bytes to transfer in the next IN transaction. Invalid while IN
PACKET READY is set.

Table 12. EP 1/2 Counts

EP MODE Description EP1/2 COUNT

000 EP1 OFF, EP2 OFF GPR
001 EP1 IN EP2 OFF GPR EP1 IN COUNT 3:0
010 EP1 OUT, EP2 OFF GPR EP1 OUT COUNT 3:0
011 EP1 CONTROL EP1 OUT COUNT 3:0 EP1 IN COUNT 3:0
100 EP1 OUT, EP2 OUT EP2 OUT COUNT 3:0 EP1 OUT COUNT 3:0
101 EP1 IN, EP1 OUT EP1 OUT COUNT 3:0 EP1 IN COUNT 3:0
110 EP1 OUT, EP1 IN EP1 IN COUNT 3:0 EP1 OUT COUNT 3:0
111 EP1 IN EP2 IN EP2 IN COUNT 3:0 EP1 IN COUNT 3:0

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 27

1

Figure 16. COMM Registers (Non-USB Modes: B0–BF)

ADDR

B0

B1

B2

B3

B4

B5

B6

B7

B8

B9

BA

BB

BC

BD

BE

BF

NAME

D7 D6

D5 D4 D3

D2 D1 D0

PORT A

PORT B

SIE MODE

LOW

PRIORITY

INTR

MODE 3:0

A7 A6 A5 A4 A3 A2 A1 A0

B7 B6 B5 B4 B3 B2 B1 B0

BYTE

RCV

XMIT

DONE

LOW

PRIORITY

MASK

SAME AS LOW PRIORITY INTR

HIGH

PRIORITY

INTR
HIGH

PRIORITY

MASK

OVER-

RUN

ERROR

RCV

COMM

ERROR

RCV

DONE

SAME AS HIGH PRIORITY INTR

COMM

CSR

RCV

READY

XMIT

READY

PACKET

SIZE

RCV PACKET SIZE XMIT PACKET SIZE

BYTE

OFFSETS

LAST BYTE RECEIVED OFFSET NEXT SEND BYTE OFFSET

1200

BAUD

SERIAL

PS/2

USB

COMM

ERROR

HOST

ABORT

PB7

INTR

PB7

MSK

PB6

INTR

PB6

MSK

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

28 P R E L I M I N A R Y DS97KEY2005

COMMUNICATION REGISTER DEFINITIONS (NON-USB MODES)

The following definitions describe in detail the specific non­USB mode registers as illustrated in Figure 16.

PORT A, PORT B: Same as USB mode. Port B6 and B7
are I/O in the GPIO Mode.

SIE MODE: Same as USB mode.
LOW PRIORITY INTR: This register contains the IRQ

flags of a low-priority communications interrupt.
Read/Write.

LOW PRIORITY MASK: This register contains mask bits
for the IRQ sources specified in the LOW PRIORITY INTR
register. A set bit indicates that the corresponding interrupt
source is unmasked.

■ XMIT COMM ERROR: Indicates that a communications

error occurred while transmitting a byte. Valid only when
the SIE is in PS/2 mode. Indicates that the host aborted
the transfer.

■ XMIT DONE: Indicates that XMIT PACKET SIZE bytes

have been sent since XMIT READY was set.

HIGH PRIORITY INTR: This register contains the IRQ
source flags of a low-priority communications interrupt.
The ISR should check these bits to determine the cause of
the interrupt. Read/Write.

HIGH PRIORITY MASK: This register contains mask bits
for the IRQ sources specified in the HIGH PRIORITY INTR
register. A set bit indicates that the corresponding interrupt
source is unmasked.

■ OVERRUN ERROR: Indicates that RCV READY was

clear when RCV DONE was set.

■ RCV COMM ERROR: Indicates that a communications

error occurred while receiving a byte, resulting in a
framing or parity error. In PS/2 mode, it may also
indicate that the host aborted its own transmission.

■ RCV DONE: Indicates that RCV PACKET SIZE bytes

have been received since RCV READY was set.

COMM CSR: Controls the SIE in PS/2 and RS232-C
mode.

■ XMIT READY: Indicates to the SIE that the XMIT buffer

is valid. Cleared by SIE when XMIT DONE is set.
Cannot be cleared by firmware. Read/Write.

■ RCV READY: Indicates to the SIE that the most recent

packet received has been handled. Cleared by the SIE
after RCV DONE is set. Cannot be cleared by firmware.
Read/Write.

■ RCV PACKET SIZE: Number of bytes to receive before

BYTE RECEIVED interrupt. Value may not exceed the
size specified in RCV BUFFER SIZE. A “0” indicates that
the packet size = the buffer size. Read/Write.

■ XMIT PACKET SIZE: The number of bytes to send

before the XMIT DONE interrupt. A “0” indicates that the
packet size = the buffer size

■ LAST BYTE RECEIVED OFFSET: Indicates the offset

in the RECEIVE buffer of the most recent byte received.
Read only.

■ NEXT SEND BYTE OFFSET: Indicates the offset in the

XMIT buffer of the next byte to be sent. If the host has
aborted a PS/2 transmission, it is the offset of the byte
that was aborted. Read only.

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 29

1

INITIAL STATES: COMM REGISTERS, UPON CHANGING MODES:

INITIAL STATES: PORT CONFIGURATION REGISTERS:

All Registers in this state are cleared to 0 on POR.

ADDR NAME D7 D6 D5 D4 D3 D2 D1 D0

0 PORT A Cleared by POR,or not changed
1 PORT B Same as Port A
2
3
4
5 SIE
6 CONTROL ALL 0
7 REGS
8

9
A
B
C
D
E Uninitialized
F

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

30 P R E L I M I N A R Y DS97KEY2005

PORT CONFIGURATION REGISTERS

Figure 17. Port Configuration Registers ( D0–DF)

ADDR

D0

D1

D2

D3

D4

D5

D6

D7

D8

D9

DA

DB

DC

DD

DE

DF

NAME

D7 D6

D5 D4 D3

D2 D1 D0

PORT A

CONFIG

01

PORT A
CONFIG

23

PORT A
CONFIG

45

PORT A

CONFIG

67

PORT B

CONFIG

01

PORT B

CONFIG

23

PORT B

CONFIG

45

PORT B

CONFIG

67

PORT A

SINK

45

PORT A

SINK

67

PORT B0

PORT B1

PORT B2

PORT B3

PORT B4

PORT B5

WAKE

PUSH/

PULL

PULLDWN

ON

OUTPUT WAKE

PUSH/

PULL

PULLDWN

ON

OUTPUT

WAKE

PUSH/

PULL

PULLUP

ON

OUTPUT

WAKE

PUSH/

PULL

PULLUP

ON

OUTPUT

WAKE

PUSH/

PULL

PULLUP

ON

OUTPUT

WAKE

PUSH/

PULL

PULLUP

ON

OUTPUT

WAKE

PUSH/

PULL

PULLUP

ON

OUTPUT

WAKE

PUSH/

PULL

PULLUP

ON

OUTPUT

PUSH/

PULL

PULLUP

ON

OUTPUT

COMP

ENABLE

VREF 5:4

WAKE

PUSH/

PULL

PULLDWN

ON

OUTPUT

WAKE

PUSH/

PULL

PULLUP

ON

OUTPUT

WAKE

PUSH/

PULL

PULLUP

ON

OUTPUT

WAKE

PUSH/

PULL

PULLUP

ON

OUTPUT

WAKE

PUSH/

PULL

PULLUP

ON

OUTPUT

WAKE

PUSH/

PULL

PULLUP

ON

OUTPUT

PUSH/

PULL

PULLUP

ON

OUTPUT

DIVIDER 2:0

A0

A2

A4

A6

B0

B2

B4

B6

A1

A3

A5

A7

B1

B3

B5

B7

COMP

ENABLE

VREF 5:4 DIVIDER 2:0

COMP

ENABLE

COMP

ENABLE

COMP

ENABLE

VREF 5:4

VREF 5:4

VREF 5:4

DIVIDER 2:0

DIVIDER 2:0

DIVIDER 2:0

COMP

ENABLE

VREF 5:4

DIVIDER 2:0

A5

SINK 3:0 SINK 3:0

SINK 3:0

SINK 3:0

A4

A7 A6

B0

B1

B2

B3

B4

B5

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 31

1

PORT REGISTER DEFINITIONS

The following definitions describe in detail the specific port
registers as illustrated in Figure 17.

WAKE: When set, this pin is capable of waking the device
on any edge.

PUSH/PULL: When set, this pin is a push-pull output.
When clear, this pin is an open-drain output. Ignored if
OUTPUT is clear.

PULLUP ON: When set, the pull-up resistor is on.
OUTPUT: When set, the pin’s output drivers are enabled.

However, the pin may be read at any time regardless of the
configuration.

SINK: Indicates the level of current drawn by the current
sink on the pin. When SINK ≠ 0, the n-channel output tran­sistor is disabled. When SINK = 0, the sink is off and the n­channel output transistor may be enabled according to the
OUTPUT bit.

DIVIDER: Selects one of the three voltage dividers to be
placed on the pin. Divider 0 indicates no divider.

VREF: Indicates the voltage reference level for the com­parator. Ignored if COMP ENABLED is clear.

COMP ENABLE: When set, the comparator is powered.
When clear, the comparator and VREF circuitry are pow­ered down.

FUNCTIONAL DESCRIPTIONS

Counter/Timers. For the Z8E20, 8-bit timers T0 and T1

are available to function as a pair of independent 8-bit
standard timers, or they can be cascaded to function as a
16-bit PWM timer. In addition, 8-bit timers T2 and T3 are
provided but they can only operate in cascade to function
as a 16-bit standard timer (Figure 18).

Each 8-bit timer is provided a pair of registers, which are
both readable and writable. One of the registers is defined
to contain the auto-initialization value for the timer, while
the second register contains the current value for the timer.
When a timer is enabled, the timer will decrement whatev­er value is currently held in its count register, and will then
continue decrementing until it reaches 0, at which time an
interrupt will be generated and the contents of the auto-ini­tialization register are optionally copied into the count val­ue register. If auto-initialization is not enabled, the timer
will stop counting upon reaching 0 and control logic will
clear the appropriate control register bit to disable the tim­er. This occurrence is referred to as “single-shot” opera­tion. If auto-initialization is enabled, the timer will continue
counting from the initialization value. Software should not
attempt to use registers that are defined as having timer
functionality.

Software is allowed to write to any register at any time, but
it is not recommended that timer registers be updated
while the timer is enabled. If software updates the count
value while the timer is in operation, the timer will continue
counting based upon the software-updated value. This oc­currence can produce strange behavior if the software up­date occurred at exactly the point that the timer was reach­ing 0 to trigger an interrupt and/or reload.

Similarly, if software updates the initialization value regis­ter while the timer is active, the next time that the timer
reaches 0, it will be initialized using the updated value.
Again, strange behavior could result if the initialization val-

ue register is being written while the timer is in the process
of being initialized. Whether initialization is done with the
new or old value is a function of the exact timing of the
write operation. In all cases, the Z8E520 will prioritize the
software write above that of a decremented writeback.
However, when hardware clears a control register bit for a
timer that is configured for single-shot operation; the clear­ing of the control bit will override a software write. Reading
either register can be done at any time, and will have no
effect on the functionality of the timer.

If a timer pair is defined to operate as a single 16-bit entity,
the entire 16-bit value must reach 0 before an interrupt is
generated. In this case, a single interrupt will be generat­ed, and the interrupt will correspond to the even 8-bit time.
For example, timers T2 and T3 are cascaded to form a sin­gle 16-bit timer, so the interrupt for the combined timer will
be defined to be that of timer T2 rather than T3. When a
timer pair is specified to act as a single 16-bit timer, the
even timer registers in the pair (timer T0 or T2) will be de­fined to hold the timer’s least significant byte; while the odd
timer in the pair will hold the timer’s most significant byte.

In parallel with the posting of the interrupt request, the in­terrupting timer’s count value will be initialized by copying
the contents of the auto-initialization value register to the
count value register.

Note: Any time that a timer pair is defined to act as a
single 16-bit timer, that the auto-reload function will be
performed automatically. All 16-bit timers will continue
counting while their interrupt requests are active, and will
operate in a free-running manner.

If interrupts are disabled for a long period of time, it is pos­sible for the timer to decrement to 0 again before its initial
interrupt has been responded to. This occurrence is a de­generate case, and hardware is not required to detect this

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

32 P R E L I M I N A R Y DS97KEY2005

FUNCTIONAL DESCRIPTIONS (Continued)

condition. When the timer control register is written, all tim­ers that are enabled by the write will begin counting using
the value that is held in their count register. An auto-initial­ization is not performed. All timers can receive an internal
clock source only, so synchronization of timer updates is
not an issue. Each standard timer that is enabled will be
updated every 8th XTAL clock cycle.

If T0 and T1 are defined to work independently, then each
will work as an 8-bit timer with a single auto-initialization
register; T0ARLO for T0, and T1ARLO for T1. Each timer
will assert its predefined interrupt when it times out, and
will optionally perform the auto-initialization function. If T0
and T1 are cascaded to form a single 16-bit timer, then the
single 16-bit timer will be capable of performing as a Pulse­Width Modulator (PWM). This timer is referred to as T01 to
distinguish it as having special functionality that is not
available when T0 and T1 act independently.

When T01 is enabled, it can use a pair of 16-bit auto-initial­ization registers. In this mode, one 16-bit auto-initialization
value is composed of the concatenation of T1ARLO and
T0ARLO, and the second auto-initialization value is com­posed of the concatenation of T1ARHI and T0ARHI. When
T01 times out, it will alternately initialize its count value us­ing the Lo auto-init pair followed by the Hi auto-init pair.
This functionality corresponds to a PWM where the T1 in­terrupt will define the end of the High section of the wave-

form, and the T0 interrupt will mark the end of the Low por­tion of the PWM waveform.

To use the cascaded timers as a PWM, one must initialize
the T0/T1 count registers to work in conjunction with the
port pin. The user should initialize the T0 and T1 count reg­isters to the PWM hi auto-init value to obtain the required
PWM behavior. The PWM is arbitrarily defined to use the
Low auto-reload registers first, implying that it had just
timed out after beginning in the High portion of the PWM
waveform. As such, the PWM is defined to assert the T1
interrupt after the first timeout interval.

After the auto-initialization has been completed, decre­menting occurs for the number of counts defined by the
auto-init_lo registers. When decrementing again reaches
0, the T0 interrupt is asserted; and auto-init using the auto­init_hi registers occurs. Decrementing occurs for the num­ber of counts defined by the auto-init_hi registers until
reaching 0, at which time the the T1 interrupt is asserted,
and the cycle begins again. The internal timers can be
used to trigger external events by toggling port output
when generating an interrupt. This functionality can only
be achieved in conjunction with the port unit defining the
appropriate pin as an output signal with the timer output
special function enabled. In this mode, the appropriate port
output will be toggled when the timer count reaches 0, and
will continue toggling each time that the timer times out.

Figure 18. Z8E520 Timers Block Diagram

XTAL
÷8

T0ARHI

Register Data Bus

T1ARHI

T0

T1

T1ARLO

T0ARLO

PWM

PA1

÷ 8

XTAL

= Bidirectional

OUF

OUF

IRQ0

LOAD

LOAD

IRQ1

T

REG C0–0

REG C0–1

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 33

1

Watch-Dog Timer. The WDT can be programmed at any-

time in the program operation.
Default value (Reset) = 98 ms
The RC oscillator is under firmware control. If the oscillator

is enabled during USB Suspend/Chip Stop Mode, the de­vice will be periodically woke up by the WDT timeout. If the
application does not require “motion detect,” the current
that drives the internal oscillator/WDT can be saved.

WDT Control Registers. Select time-out values for the
WDT are programmable –0 to +100%.

Interrupts. The Z8E520 has six different interrupts. These
interrupts are maskable and prioritized (Figure 19 ). The
six sources are divided as follows:

.

When more than one interrupt is pending, priorities are re­solved by a programmable priority encoder that is con-

trolled by the Interrupt Priority register. All interrupts are
vectored through locations in the program memory. When
an interrupt machine cycle is activated an interrupt request
is granted. All of the subsequent interrupts are thus dis­abled, saving the Program Counter and status flags, and
branching to the program memory vector location reserved
for that interrupt. This memory location and the next byte
contain the 16-bit address of the interrupt service routine
for that particular interrupt request.

EMI. Lower EMI on the Z8E520 is achieved through circuit
modifications.

The Z8E520 also accepts external clock from XTAL IN pin
(Figure 20).

Power-On-Reset (POR). A timer circuit is triggered by the
system oscillator and is used for the Power-On Reset
(POR) timer function. The POR time allows V

CC

and the os­cillator circuit to stabilize before instruction execution be­gins. POR period is defined as:

The POR timer circuit is a one-shot timer triggered by pow­er fail to Power OK status. The POR time is a nominal 100
ms at 6 MHz. The POR time is bypassed after Stop-Mode
Recovery.

HALT. HALT turns off the internal CPU clock, but not the
oscillator. The counter/timer and external interrupts
IRQ0–5 remain active. The Z8E520 recovers by interrupts,
either externally or internally.

USB Reset. Detection by the SIE of a reset from the Host
will cause the chip to reset. The reset will be remembered
so that the program can decide the source of the reset.
The USB Reset will act even if the chip is in the STOP
mode.

Priority IRQ

0 TCO
1 TC1
2 TC2
3 COMM HIGH
4 COMM LOW
5 Port

Figure 19. Interrupt Block Diagram

IRQ

IMR

6

6

IRQ0–IRQ4

Vector Select

Interrupt
Request

Global
Interrupt
Enable

Figure 20. Oscillator Configuration

POR (ms) = 98 ms

XTAL1 (in)

XTAL2 (out)

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

34 P R E L I M I N A R Y DS97KEY2005

FUNCTIONAL DESCRIPTIONS (Continued)

V

BO

Circuit. The Voltage Brown Out circuit will detect

when voltage has dropped below the normal operating
voltage. The chip will maintain full core functionality and
RAM values will be preserved during the range from V

MIN

(VCC = 4V) to VBO; however, it may not meet worst case
AC and DC limits. At VBO, the chip will be placed in reset
and maintained in that state until VCC exceeds VBO. When
this condition is reached, the chip will resume operation.
VBO is set by design to 2.7 V ± 0.2 V.

STOP. This instruction turns off the internal clock and ex­ternal ceramic resonator oscillation. It reduces the standby
current to less than 60 µA. The STOP Mode is terminated
by an interrupt. An interrupt from any of the active (en­abled) interrupts will remove the chip from the STOP Mode
(Ports 31–33 including the USB reset.

Note: The timer cannot generate an interrupt in STOP
Mode because the clock is stopped.

The interrupt causes the processor to restart the applica­tion program at the address or the vector of the interrupt
and continue the program at the end of the interrupt ser­vice routine. In order to enter STOP (or HALT) Mode, it is
necessary to first flush the instruction pipeline to avoid sus­pending execution in mid-instruction. As a result, the user
must execute a NOP (Opcode=FFH) immediately before
the appropriate sleep instruction, such as:

FF NOP ; clear the pipeline
6F STOP ; enter STOP Mode

or
FF NOP ; clear the pipeline
7F HALT ; enter HALT Mode

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 35

1

Z8

PLUS

SYSTEM REGISTERS

The registers displayed in Figures 21–27 represent Zilog’s
new Z8

Plus

architecture. For a complete overview of this

new technology, please refer to the Z8

Plus

user’s manual

(UM97Z8X0300) available at your local Zilog sales office.

Figure 21. Interrupt Request Register

D7 D6 D5 D4 D3 D2 D1 D0

0FA

IRQ

IRQ0 = TIMER0 TIMEOUT

IRQ1 = TIMER1 TIMEOUT

IRQ2 = TIMER2 TIMEOUT

IRQ3 = HIGH PRIORITY COMM

IRQ4 = LOW PRIORITY COMM

IRQ5 = PORTS

RESERVED (MUST BE 0)

RESERVED (MUST BE 0)

FIXED INTERRUPT PRIORITY: IRQ0 > IRQ1 > IRQ2 > IRQ3 > IRQ4 > IRQ5

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

36 P R E L I M I N A R Y DS97KEY2005

Z8PLUS SYSTEM REGISTERS (Continued)

Figure 22. Interrupt Mask Register

Figure 23. Stack Pointer

D7 D6 D5 D4 D3 D2 D1 D0

0FB

IMR

RESERVED (MUST BE 0)

1 = IRQ BIT N ENABLED

0 = IRQ BIT N MASKED

1= GLOBAL INTERRUPTS ENABLED
0 = GLOBAL INTERRUPTS DISABLED

D7 D6 D5 D4 D3 D2 D1 D0

0FF

STACK POINTER

NEXT STACK ADDRESSES

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 37

1

Figure 24. TCTLHI Register

D7 D6 D5 D4 D3 D2 D1 D0

0C1

TCTLHI

RESET SOURCE

0 = STOP MODE ENABLED
1 = STOP MODE DISABLED

D6 D5 D4 WDT TIMEOUT VALUE

0 0 0 DISABLED
0 0 1 65,536

0 1 0 131,072
0 1 1 262,144
1 0 0 524,288
1 0 1 1,048,576
1 1 0 2,097,152 156 400 1200.0
1 1 1 4,194,304

(RC CLOCKS TO TIMEOUT†)

1 = RC ENABLED
0 = RC DISABLED

5 12 39.3 mS
10 25 78.0 mS

19 50 156.0 mS

38 100 312.0 mS

78 200 624.0 mS

COUNTS MIN NOM MAX

300 800 2400.0 mS

UNITS

mS

SIE WDT POR

†: RC FREQUENCY = 40 KHz (Range: 20 TO 100 KHz)

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

38 P R E L I M I N A R Y DS97KEY2005

Z8PLUS SYSTEM REGISTERS (Continued)

Figure 25. TCTLLO Register

D7 D6 D5 D4 D3 D2 D1 D0

0C0

TCTLLO

TIMER STATUS

D2 D1 D0 T0 T1
0 0 0 DISAB. DISAB.

0 0 1 ENAB. DISAB.
0 1 0 DISAB. ENAB.
0 1 1 ENAB. ENAB.
1 0 0 T01 (PWM)
1 0 1 ENAB.(*) DISAB.
1 1 0 DISAB. ENAB.(*)
1 1 1 T32 (16 BIT)

(NOTE: (*) INDICATES AUTO-RELOAD
IS ACTIVE.)

1 = T32 16-BIT TIMER ENABLED WITH
AUTO-RELOAD ACTIVE
0 = T2 AND T3 TIMERS DISABLED

D6 1: PWM MODE IN T0 (PA1 IS OUTPUT)

NOTE: TIMER T01 IS A 16-BIT PWM TIMER FORMED BY CASCADING 8-BIT TIMERS
T1 (MSB) AND T0 (LSB). TIMER T32 IS A STANDARD 16-BIT TIMER FORMED
BY CASCADING 8-BIT TIMERS T3(MSB) AND T2(LSB).

D3 0: 6 MHz CR

NOTE: CLOCK “DIVIDE BY” MODE (÷) ALLOWS FOR LOWER POWER FOR RS232 OR FASTER
CPU EXECUTION WITH ZIE AT NORMAL 6 MHZ CLOCK RATE.

D3 1: 12 MHz CR
D4 0: CORE CLK = ÷ (XTAL VALUE)
D4 1: CORE CLK = XTAL ÷ 2

D7 1: CAPTURE MODE IN T0 (PA0 IS INPUT)

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 39

1

Figure 26. Z8E520 Register Pointe

D7 D6 D5 D4 D3 D2 D1 D0

0FD

RP

MUST BE 0. (ONLY PAGE0 IS
IMPLEMENTED ON Z8E520.)

DF
D0

CF
C0

3F
30

2F
20
1F
10
0F

00

The upper nibble of the register file address
provided by the register pointer specifies
the active working register group.

Register Pointer

R15

R0

R15

R0

R15

R0

R15

R0

R15

R0

R15

R0

Register Group 0

Register Group 1

Register Group 2 * (ACTIVE)

Register Group 3

Register Group C

Register Group D

The lower nibble of the register
file address provided by the
instruction points to the
specific register.

* Register Group 2 is active if RP = 20H.

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

40 P R E L I M I N A R Y DS97KEY2005

Z8PLUS SYSTEM REGISTERS (Continued)

Figure 27. Flags Register

D7 D6 D5 D4 D3 D2 D1 D0

0FC

FLAGS

STOP MODE RECOVERY FLAG (SMR)

WDT RESET FLAG (WDT)

HALF-CARRY FLAG (HC)

DECIMAL ADJUST FLAG (DA)

OVERFLOW FLAG (OVF)

SIGN FLAG (S)

ZERO FLAG (Z)

CARRY FLAG (C)

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 41

1

PACKAGE INFORMATION

Figure 28. 20-Pin DIP Package

Figure 29. 20-Pin SOIC Package

Z8E520/C520

1.5 MBPS USB Device Controller Zilog

42 P R E L I M I N A R Y DS97KEY2005

ORDERING INFORMATION

For fast results, contact your Zilog sales office for assistance in ordering the part required.

CODES

Package

P = Plastic DIP
V = Plastic Leaded Chip Carrier
F = Quad Flat Pack

Speed

06 = 6 MHz

Environment

C = Plastic Standard

Temperature

S = 0°C to +70°C

6 MHz 6 MHz

20-Pin DIP 20-Pin SOIC

Z8E520PSC Z8E520SSC
Z8C520PSC Z8C520SSC

Example:

Z 8E520 06 P S C

Environmental Flow
Temperature
Package
Speed
Product Number
Zilog Prefix

is a Z8E520, 6 MHz, SOIC , 0°C to +70°C, Plastic Standard Flow

Z8E520/C520

Zilog 1.5 MBPS USB Device Controller

DS97KEY2005 P R E L I M I N A R Y 43

1

Development Projects:

Customer is cautioned that while reasonable efforts will be
employed to meet performance objectives and milestone
dates, development is subject to unanticipated problems

and delays. No production release is authorized or
committed until the Customer and Zilog have agreed upon
a Customer Procurement Specification for this product.

Pre-Characterization Product:

The product represented by this CPS is newly introduced
and Zilog has not completed the full characterization of the
product. The CPS states what Zilog knows about this
product at this time, but additional features or
nonconformance with some aspects of the CPS may be

found, either by Zilog or its customers in the course of
further application and characterization work. In addition,
Zilog cautions that delivery may be uncertain at times, due
to start-up yield issues.

Low Margin:

Customer is advised that this product does not meet
Zilog's internal guardbanded test policies for the
specification requested and is supplied on an exception
basis. Customer is cautioned that delivery may be
uncertain and that, in addition to all other limitations on

Zilog liability stated on the front and back of the
acknowledgment, Zilog makes no claim as to quality and
reliability under the CPS. The product remains subject to
standard warranty for replacement due to defects in
materials and workmanship.

© 1998 by Zilog, Inc. All rights reserved. No part of this
document may be copied or reproduced in any form or by
any means without the prior written consent of Zilog, Inc.
The information in this document is subject to change
without notice. Devices sold by Zilog, Inc. are covered by
warranty and patent indemnification provisions appearing
in Zilog, Inc. Terms and Conditions of Sale only.

ZILOG, INC. MAKES NO WARRANTY, EXPRESS,
STATUTORY, IMPLIED OR BY DESCRIPTION,
REGARDING THE INFORMATION SET FORTH HEREIN
OR REGARDING THE FREEDOM OF THE DESCRIBED
DEVICES FROM INTELLECTUAL PROPERTY
INFRINGEMENT. ZILOG, INC. MAKES NO WARRANTY
OF MERCHANTABILITY OR FITNESS FOR ANY
PURPOSE.

Zilog, Inc. shall not be responsible for any errors that may
appear in this document. Zilog, Inc. makes no commitment

to update or keep current the information contained in this
document.

Zilog’s products are not authorized for use as critical
components in life support devices or systems unless a
specific written agreement pertaining to such intended use
is executed between the customer and Zilog prior to use.
Life support devices or systems are those which are
intended for surgical implantation into the body, or which
sustains life whose failure to perform, when properly used
in accordance with instructions for use provided in the
labeling, can be reasonably expected to result in
significant injury to the user.

Zilog, Inc. 210 East Hacienda Ave.
Campbell, CA 95008-6600
Telephone [phone]
FAX [phone]
Internet: http://www.zilog.com
