Introduction
This manual describes how to set up Zilog’s Z51F3221 Development Kit (Zilog part num-
ber Z51F3221000ZCOG) and use it to evaluate your Z8051-based designs and applica-
tions.
The Kit features a development board consisting of five LEDs, five pushbuttons, a buzzer,
eight 14-segment LCD digits, port pin headers and a UART-to-USB port. The Board fea-
tures the Z51F3221 MCU in a 80-pin LQFP package, plus a DBG connector to connect
the Board to a host development PC using the Z8051 USB On-Chip Debugger (OCD)
cable. For more details about the Z51F3221 MCU, please refer to the Z51F3221 Product
Specification (PS0300).
This document guides you through the following tasks:
Z51F3221 Development Kit
User Manual
1
•
Install the Z8051 OCD Software and Documentation – see page 7
•
Configure the Z8051 OCD and Z51F3221 Development Board – see page 17
•
Build and Run the Z51F3221 Demo Project – see page 20
Figure 1 shows an image of the Z51F3221 Development Kit.
UM025801-1112 Introduction
Z51F3221 Development Kit
User Manual
2
Kit Contents
Table 1 lists the contents of the Z51F3221 Development Kit.
Item Description Quantity
1 Z51F3221 Development Board 1
2 Z8051 USB On-Chip Debugger (OCD) 1
3 Z8051 OCD Target Cable (10ckt) 1
4 USB Cable: A (male) to Mini-B 2
5 Z51F3221 Development Kit Insert (FL0149) 1
Figure 1. The Z51F3221 Development Kit
Table 1. Z51F3221000ZCOG Contents
UM025801-1112 Kit Contents
Z51F3221 Development Kit
Figure 2 shows an image of the Z51F3221 Development Board.
User Manual
3
Figure 2. Z51F3221 Development Board
Supported Operating Systems
The Z51F3221 Development Board and the Z8051 On-Chip Debugger support the fol low-
ing operating systems:
•
Microsoft Windows XP
•
Microsoft Windows Vista (32-bit/64-bit)
•
Microsoft Windows 7 (32-bit/64-bit)
Z51F3221 Development Board Block Diagram
Figure 3 shows a block diagram of the Z51F3221 Development Board.
UM025801-1112 Supported Operating Systems
Z51F3221 Development Kit
User Manual
4
Figure 3. Block Diagram of the Z51F3221 Development Board
Z51F3221 Development Board Description
The Z51F3221 Development Board consists of the following components:
•
Z51F3221: U1, 80-pin LQFP chip
•
3 LEDs: Green (D2), Red (D3) and Yellow (D4) connected to the GPIO pins of the
Z51F3221 MCU
•
1 green LED to indicate USB power: D5
•
1 red LED to indicate an overcurrent condition: D6
•
5 pushbuttons:
– SW1: RESET
– SW2–SW5: connected to the GPIO pins of the Z51F3221 MCU
•
USB connector: P1
•
OCD connector: J3
UM025801-1112 Z51F3221 Development Board Description
Z51F3221 Development Kit
•
USB-to-UART interface: U7
•
USB interface providing power and communication to the Board
•
Power supply level that can be adjusted with potentiometer R20
•
Overcurrent protection circuit on the Board: U6 and D6
•
External source of reference voltage (2.5 V) for the on-chip ADC: VR1
•
MCU current consumption measurement resistor R5 with test points J6 and J7
•
Buzzer: U4
•
8-digit, 14-segment LCD panel
•
Test points, headers and prototype area with two footprints
User Manual
5
Figure 4. Z51F3221 Development Board: Highlighted Components
If a short on the Board should occur, or if its attached component(s) require more than
500 mA, the overcurrent protection functionality will trigger the red LED D6 to illuminate.
UM025801-1112 Z51F3221 Development Board Description
Z51F3221 Development Kit
User Manual
In this instance, power to the Board will be terminated, and the USB port of the PC will be
protected from shorting.
Schematic diagrams of the Z51F3221 Development Board are presented on pages 38 and
39 of this document.
The physical dimensions of the Board are 4.01" x 2.50" (101.8 mm x 63.5 mm).
6
UM025801-1112 Z51F3221 Development Board Description
Z51F3221 Development Kit
Note:
Note:
Install the Z8051 OCD Software and Document ation
The Z8051 On-Chip Debugger (OCD) interface is the interface by which your PC will
communicate with the Z51F3221 MCU to download and execute code. In addition to the
OCD, software such as development tools and sample applications will be installed.
Supported Operating Systems
The Software and Documentation for this reference design supports Microsoft W indows 7
(32-bit/64-bit), Windows Vista (32-bit/64-bit) and Windows XP.
User Manual
7
If you have already downloaded the Z8051 software and documentation from the Zilog
Store and installed it following the procedure on the paper insert in your kit (FL0149), skip
this section and proceed to the Z8051 OCD Driver Installation section, below.
Observe the following procedure to install the Z8051 On-Chip Debugger software and
documentation on your computer.
1. Ensure that the OCD interface hardware is not connected to your PC.
2. In a web browser, download the Z8051 Software and Documentation v2.1 or later
from the Zilog Store
drive and double-click to launch the installation file named
3. From the main menu, select
lowing options:
– If you do not plan to use the Keil µVision4 IDE, select
SDCC
.
– If you will be using the Keil µVision4 IDE, select
µVision4 IDE Debugging Support
– If you only plan to use the programming features and do not plan to perform any
development, select
– To install all files, select
. When the download is complete, unzip the file to your hard
Z8051_<version>.exe.
Go to the installation page, then select one of the fol-
Zilog OCD + Samples +
Zilog OCD + Samples + Keil
.
Zilog OCD.
All of the above.
In this filename, <version_number> refers to the version number of the OCD Software
and Documentation release. For example, this version number may be 2.1.
UM025801-1112 Install the Z8051 OCD Software and Documentation
4. Follow the on-screen instructions to complete the OCD software installation.
Note:
Z8051 OCD Driver Installation
The driver programs for the Z8051 On-Chip Debugger are copied du ring the software and
documentation installation. In the following procedure for PCs running t he W indows 7 32and 64-bit operating systems, ensure that the target side of the OCD will remain unconnected while you install these drivers.
If you are running Windows Vi sta, see Appendix B on page 40 to install your device drivers. If you are running Windows XP, see Appendix C on page 43.
Z51F3221 Development Kit
User Manual
8
1. Connect the OCD hardware to the USB port of your PC by connecting the A (male)
end of one of the two USB A (male)-to-Mini-B cables with the host PC’s USB port.
Connect the Mini-B end to the OCD device.
2. After the PC detects the new hardware, it will display the Installing device driver soft-
ware dialog shown in Figure 5.
Figure 5. Install Device Driver Dialog, Windows 7
IMPORTANT NOTE: If you should encounter the scenarios presented in Figures 9 or 10, right-click
your mouse on
and select
ZILOG OCD I/F (highlighted in Figure 9) or Unknown device (highlighted in Figure 10)
Update Driver Software...
3. Select
Browse my computer for driver software (advanced) to display the dialog
shown in Figure 6, which prompts you to key in or browse for the location of the
file. Depending on the type of computer you use (32- bit or 64-bit), use the
button to navigate to one of the following paths, then click the
Next button.
.inf
Browse
– On 32-bit machines, use the following path:
<Z8051 Installation>\Z8051_<version_number>\device drivers\OCD USB\x32
UM025801-1112 Z8051 OCD Driver Installation
Z51F3221 Development Kit
– On 64-bit machines, use the following path:
<Z8051 Installation>\Z8051_<version_number>\device drivers\OCD USB\x64
User Manual
9
Figure 6. Browse For Driver Dialog, Windows Vista
4. When Windows prompts you whether to install or not install, as shown in Figure 7,
Install this driver software anyway and wait until the installation is completed
click
(Windows may prompt you more than once).
UM025801-1112 Z8051 OCD Driver Installation
Z51F3221 Development Kit
User Manual
10
Figure 7. Can’t Verify Publisher Dialog, Windows Vista
5. When the installation is complete, the screen shown in Figure 8 will appear. Click
Close to exit the OCD driver installation.
UM025801-1112 Z8051 OCD Driver Installation
Z51F3221 Development Kit
Note:
User Manual
11
Figure 8. Successfully Installed Dialog, Windows Vista
On some installations, the Found New Hardware screen shown in Figure 8 may also display the text string,
Zilog Z8051 USB OCD - No Firmware. This occurrence is normal
and can be disregarded.
UM025801-1112 Z8051 OCD Driver Installation
Z51F3221 Development Kit
User Manual
12
Figure 9. Unsuccessful Installation, Scenario 1
UM025801-1112 Z8051 OCD Driver Installation
Z51F3221 Development Kit
User Manual
13
Figure 10. Unsuccessful Installation, Scenario 2
UM025801-1112 Z8051 OCD Driver Installation
Z51F3221 Development Kit
User Manual
6. If Zilog Z8051 USB OCD appears in the Device Manager (as highlighted in
Figure 11), the OCD driver software has been successfully installed.
14
Figure 11. Device Manager Dialog, Windows 7
UM025801-1112 Z8051 OCD Driver Installation
FTDI USB-to-UART Driver Installation
Note:
An FTDI USB-to-UART driver is required to allow your PC to communicate th ro ugh its
USB port to the on-chip UART of the Z51F3221 MCU. Observe the following procedu re to
perform these connections.
1. Ensure that the USB cable is not plugged in to the Z51F3221 Development Board’s P1
connector.
Z51F3221 Development Kit
User Manual
15
2. Navigate to the following filepath and double-click the
CDM20802_setup.exe file to
begin the driver installation.
<Z8051 Installation>\Z8051_<version_number>\device drivers\FTDI Uart
3. The installation process will begin and you should observe output similar to the following messages on the screen of your PC:
32-bit OS detected
<installation path>\dpinstx86.exe
Installation driver
FTDI CDM driver installation process completed.
The above message may appear for a short time, but will then disappear from your window.
This occurrence is normal.
4. When the installation is complete, plug in the Mini-B connector of the second USB
cable into the Board, and the larger A connector into the USB port of your PC. Refer
to Figure 15
on page 19 for guidance.
5. If the driver installation was successful, the Ports (COM & LPT) section of the Device
Manager will display USB Serial Port (COMx) or similar message, as highlighted in
Figure 12.
UM025801-1112 FTDI USB-to-UART Driver Installation
Z51F3221 Development Kit
Note:
User Manual
16
Figure 12. A Successful USB-to-UART Driver Installation
To launch the Device Manager on W ind ows 7 systems, launch the Start menu, enter device
manager in the
Search programs and files field, and press the Enter key.
To open the Device manager on earlier Windows systems, navigate via the following path:
Start → Control Panel → System → Hardware → Device Manager → Ports (COM& LPT)
UM025801-1112 FTDI USB-to-UART Driver Installation
Z51F3221 Development Kit
Caution:
User Manual
Configure the Z8051 OCD and Z51F3221 Development Board
Observe the following procedure to set up and configure the Z8051 On-Chip Debugger
and the Z51F3221 Board.
Steps number 1 to 4 present the power-up sequence. Carefully follow these steps to avoid
encountering an improper connection or disconnection.
1. Connect the Z8051 On-Chip Debugger (OCD) to the host PC’s USB port.
17
2. Connect one end of the 10-circuit cable to the Z8051 OCD.
3. Connect the other end of the 10-circuit cable connector to the Z51F3221 Board’s J3
connector. Pin 1 of the cable connector is indicated by a red stripe, as shown in
Figure 13.
Figure 13. Connecting the 10-Circuit Cable to the Board
UM025801-1112 Configure the Z8051 OCD and Z51F3221
Z51F3221 Development Kit
Note:
User Manual
4. Using the second USB-to-Mini-B cable, connect the standard USB end to the host
PC’s USB port.
5. Connect the other end of this second Mini-B cable to the Z51F3221 Board’s P1 connector to apply power to the Board. Note that the green LED D5 is ON; see Figure 14.
18
Figure 14. Connecting the USB Mini-B Cable to the Board
In the event that you later remove the LCD panel from the Board, observe its orientation in
Figure 14. The panel’s small plastic notch should be located in the position indicated by the
red square.
Figure 15 shows an example of a completed hardware and software setup.
UM025801-1112 Configure the Z8051 OCD and Z51F3221
Z51F3221 Development Kit
User Manual
19
Figure 15. An Example Setup
UM025801-1112 Configure the Z8051 OCD and Z51F3221
Z51F3221 Development Kit
Note:
Note:
Note:
Build and Run the Z51F3221 Demo Project
Observe the following procedure to build and run the Z51F3221 demo project.
If you plan to use the Keil µVision IDE, please skip to the the Using the Keil µVision IDE
on a Demo Project section on page 26.
User Manual
20
1. Browse to the following location and double-click the
build the project:
<Z8051 Installation>\Z8051_<version_number>\samples\Z51F3221\Demo\build_sdcc.bat
Refer to the Z8051 Tools Product User Guide (PUG0033) for additional information about
these project files and Small Device C Compiler (SDCC) development tools.
2. When the build is complete, the command window will prompt the user to press any
key to continue. Proceed by pressing any key on your keyboard; as a result, a hex file
for the demo will be created in the following path:
<Z8051 Installation>\Z8051_<version_number>\samples\Z51F3221\Demo\demo.hex
3. Set up the OCD and Development Board. If you have not already configured these
items, please return to the Configure the Z8051 OCD and
Board section on page 17.
4. Run the Z8051 OCD software. From the
Zilog Z8051 Software and Documentation <version_number>
OCD <version_number>
shown in Figure 16.
. Once launched, the program will display Connected, as
Start menu, navigate to All Programs →
build_sdcc.bat batch file to
Z51F3221 Development
→ Zilog Z8051
If you encounter a message that says Disconnected, return to the Configure the Z8051
OCD and Z51F3221 Development Board section on page 17 to configure the proper
power-up sequence. If the problem persists, Zilog recommends that you review the Z8051
OCD Driver Installation and FTDI USB-to-UART Driver Installation sections.
UM025801-1112 Build and Run the Z51F3221 Demo Project
Z51F3221 Development Kit
Note:
User Manual
21
Figure 16. Initial OCD Screen
For a free download of the latest version of the OCD software, visit the Zilog website and
navigate via the Tools and Software menu to Software Downloads.
5. In the Debugger window, select
Load Hex from the File menu to display the Object
File dialog, which is shown in Figure 17.
UM025801-1112 Build and Run the Z51F3221 Demo Project
Z51F3221 Development Kit
User Manual
22
Figure 17. Object File Dialog
6. In the Object File dialog, browse to the hex file that you created in Step 2 and click
Open.
7. Click the
UM025801-1112 Build and Run the Z51F3221 Demo Project
Download button to open the Configuration dialog box, shown in Figure 18.
Z51F3221 Development Kit
User Manual
23
Figure 18. Configuration Dialog
8. Click the Write button. If you have modified any of the settings in the Configuration
dialog, the Configuration Is Changed dialog shown in Figure 19 will appear.
Figure 19. Configuration Is Changed Dialog
UM025801-1112 Build and Run the Z51F3221 Demo Project
Z51F3221 Development Kit
Note:
User Manual
Please disregard the instructions stated in the Configuration Is Changed dialog, and proceed to Step 9.
24
9. Click
OK to open the On-Chip Debugger’s main window. A typical OCD display is
shown in Figure 20; Figure 21 shows an OCD window with child windows open.
Figure 20. A Typical On-Chip Debugger Window
UM025801-1112 Build and Run the Z51F3221 Demo Project
Z51F3221 Development Kit
Note:
User Manual
25
Figure 21. A Typical On-Chip Debugger Window with Child Windows Open
Use the View menu to open the child windows. For this demonstration, the example windows shown in Figure 21 do not need to be opened.
10. Click the
Reset & Go toolbar icon, shown in Figure 22. As a result, LEDs D2, D3 and
D4 on the Z51F3221 Board will blink in sequence, and the LCD panel will display
Welcome to Zilog’s Z51F3221 Development Kit.
Figure 22. Reset & Go Toolbar Icon
UM025801-1112 Build and Run the Z51F3221 Demo Project
Z51F3221 Development Kit
Note:
Notes:
Similar projects that you can use as references are listed in Table 2 on page 36.
Using the Keil µVision IDE on a Demo Project
Zilog’s On -Ch ip Debu gg er h ardware n ow fu lly supports the Keil µVision IDE. Our target
driver is seamlessly integrated with the Keil debugger, allowing Keil C51 users to work
within the µVision4 environment without switching between the Keil compiler and
Zilog’s external OCD software. In the demo project example that follows, the Z51F3221
MCU-related project is referenced as
This document refers to the Keil µVision IDE V4.53.0.6 (PK51 Prof. Developers Kit) or
later.
Demo.
User Manual
26
Refer to the Z8051 T ools Product User Guide (PUG0033)
for additional information about
these project files and debugging with the Keil µV ision IDE and Zilo g On-Chip Debugger.
Debugger Configuration
Observe the following procedure to build and run a Z51F3221 demonstration project using
the Keil µV ision IDE.
1. Start the Keil µVsion4 IDE.
2. From the
<Installation directory>\Z8051_<version>\samples\Z51F3221\Demo
3. Select the Demo.uvproj file and click Open; see Figure 23.
Project menu, select Open Project and navigate to the following filepath:
UM025801-1112 Using the Keil µVision IDE on a Demo Project
Z51F3221 Development Kit
User Manual
27
Figure 23. Selecting the Dem o Proj ec t Fi le
4. Return to the Project menu and select Options for Target ‘Demo’.
5. In the Options for Target ‘Demo’ dialog that appears, click the
Device tab and ensure
that your target is properly selected for your project, as illustrated in Figure 24.
UM025801-1112 Using the Keil µVision IDE on a Demo Project
Z51F3221 Development Kit
User Manual
28
Figure 24. Selecting the Target
6. After selecting the target, click the Debug tab and select the Zilog Z8051 Target
Driver
from the Use: drop-down menu, as highlighted in Figure 25.
UM025801-1112 Using the Keil µVision IDE on a Demo Project
Z51F3221 Development Kit
User Manual
29
Figure 25. Selecting the Target Driver
7. Click the Settings button, located to the right of this drop-down menu, to configure
your Debug and Flash options. The Settings dialog is displayed with the Debug
Options tab appearing by default, as shown in Figure 26.
UM025801-1112 Using the Keil µVision IDE on a Demo Project
Z51F3221 Development Kit
Notes:
User Manual
30
Figure 26. Configuring the Debug Options
When configuring the appropriate Debug option, be aware of the following stipulations:
•
Checking the Peripheral continues running option means that the timers used in
your project will run while the processor is stopped by the debugger.
•
The Reset at Main option will only work if you have a main file in your project; otherwise you should deselect this option.
8. Click the Flash Options tab. The Flash Options Settings dialog will appear, as shown
in Figure 27. To select the proper options for Flash programming, refer to the
Z51F3221 Product Specification (PS0300)
UM025801-1112 Using the Keil µVision IDE on a Demo Project
.
Z51F3221 Development Kit
User Manual
31
Figure 27. Configuring the Flash Options
9. Click OK to exit the Settings dialog.
10. From the
Options for Target ‘Demo’ dialog, select the Load Application at Startup
checkbox, as shown in Figure 28, so that the IDE will download the code upon connection. There is no need to select or enter an initialization file.
Figure 28. Load Application at Startup Settings
11. Click
12. From the
UM025801-1112 Using the Keil µVision IDE on a Demo Project
OK to exit the Options for Target ‘Demo’ dialog.
Project menu, select Rebuild All Target Files.
Z51F3221 Development Kit
User Manual
13. Start your debugging session by clicking the Start/Stop Debug Session icon, as indicated in Figure 29. A default Windows configuration of the debug session is shown in
Figure 30.
Figure 29. Beginning a Debug Session
32
Figure 30. A Default On-Chip Debugger Window
UM025801-1112 Using the Keil µVision IDE on a Demo Project
Z51F3221 Development Kit
Note:
Note:
Note:
User Manual
The following buttons in the Keil µV ision IDE are not supported by the Zilog OCD d river:
T o learn more about the full functionality of the Keil µVision IDE, please refer to the Keil
µVision4 IDE documentation.
33
14. From the
Debug menu, select Run, or simply press the F5 key on your Windows key-
board to run the demo project. As a result, LEDs D2, D3 and D4 will blink in
sequence and the LCD panel will display
Development Kit
15. To stop code execution, select
on the Z51F3221 Development Board’s LCD panel.
Stop from the Debug menu.
16. To stop your debugging session, click the
Refer to Appendix D on page 46 for a discussion of Stand-Alone Flash Programming
Using the Keil µVision IDE.
HyperTerminal Configuration
A communications program such as HyperTerminal can be used on Windows XP systems
to view the messages from the Z51F3221 Development Board. The following procedure
examines how to configure HyperTerminal for the Z51F3221 demo project.
The HyperT ermi nal application is not availabl e in Windows V ista and Windows 7 systems.
If you are using either of these operating systems, consider using/installing different communication software, such as Tera Term. Please refer to the documentation for the particular emulation software you use to configure it for communication with the Z51F3221
Development Board.
Welcome to Zilog’s Z51F3221
Start/Stop Debug Session icon.
1. In HyperT erminal, select the COM port assigned to the USB-to-UART interface cable
that is connected to the P1 connector on the Development Board.
UM025801-1112 HyperTerminal Configuration
Z51F3221 Development Kit
Note:
User Manual
This COM port can be determined from the Device Manager, as described in the the FTDI
USB-to-UART Driver Installation section on page 15.
2. Configure this port to reflect the following settings:
– 9600 bps
– 8 data bits
– No parity
– 1 stop bit
– No flow control
34
3. Click the
Call button to connect to the Z51F3221 Board. Upon connection, you should
be able to see the Demo program menu shown in Figure 31.
Figure 31. Demo Program Menu in HyperTerminal
At this point, you have successfully run the Z51F3221 demo project, but you are welcome
to continue evaluating the demo in HyperTerminal. For additional information about how
UM025801-1112 HyperTerminal Configuration
Z51F3221 Development Kit
Note:
User Manual
to create, edit, run and debug this project, please see the Z8051 Tools Product User Guide
(PUG0033) and/or the Z8051 On-Chip Debugger and In-System Programmer User Manual (UM0240).
Turn off the power by removing the USB cable from the P1 connector on the Development
Board.
35
UM025801-1112 HyperTerminal Configuration
Z51F3221 Development Kit
Sample Projects and Documentation
A number of sample projects are included on the CD that ships with the Z51F3221 Development Kit, and their locations, listed in Table 2, will be accessible upon installation.
Table 2. Z51F3221 Development Kit Sample Projects
Description Location
Demo samples\Z51F3221\Demo
Led Blink samples\Z51F3221\Led_Blink
samples\Z51F3221\Led_Blink_Asm
User Manual
36
A number of Z8051-related documents are included in the Z51F3221 Development Kit,
and their locations, listed in T able 3, will be accessible upon installation. You can also find
current versions of each of these documents on the Zilog website
Table 3. Z51F3221 Development Kit Documentation
Description Document Location
Z51F0410 Product Specification PS0295 Documentation\Chip_Documentation
Z51F0811 Product Specification PS0296 Documentation\Chip_Documentation
Z51F3220 Product Specification PS0299 Documentation\Chip_Documentation
Z51F3221 Product Specification PS0300 Documentation\Chip_Documentation
Z51F6412 Product Specification PS0303 Documentation\Chip_Documentation
Z51F0410 Product Brief PB0237 Documentation\Chip_Documentation
Z51F0811 Product Brief PB0238 Documentation\Chip_Documentation
Z51F3220 Product Brief PB0239 Documentation\Chip_Documentation
Z51F3221 Product Brief PB0240 Documentation\Chip_Documentation
Z51F6412 Product Brief PB0241 Documentation\Chip_Documentation
Z8051 OCD and ISP User Manual UM0240 Documentation\Tools_Documentation
Z51F0410 Evaluation Kit User Manual UM0257 Documentation\Tools_Documentation
.
Z51F0811 Evaluation Kit User Manual UM0242 Documentation\Tools_Documentation
Z51F3220 Development Kit User Manual UM0243 Documentation\Tools_Documentation
Z51F3221 Development Kit User Manual UM0258 Documentation\Tools_Documentation
UM025801-1112 Sample Projects and Documentation
Z51F3221 Development Kit
User Manual
Table 3. Z51F3221 Development Kit Documentation (Continued)
Description Document Location
Z51F6412 Development Kit User Manual UM0259 Documentation\Tools_Documentation
Z8051 Tools Product User Guide PUG0033 Documentation\Tools_Documentation
37
UM025801-1112 Sample Projects and Documentation
Appendix A. Schematic Diagrams
Current measurement
PROTOTYPE AREA (.1X.1 GRID)
DO NOT POPULATE HEADERS
RESETB
DSCL
VCCVCCVCC_T
DSDA
RESETB
DSCL
DSDA
COM0
COM1
COM2
COM3
SEG0
SEG1
SEG2
SEG3
SEG5
SEG4
SEG7
SEG6
SEG8
SEG10
SEG9
SEG12
SEG11
SEG14
SEG13
SEG16
SEG15
SEG18
SEG17
SEG20
SEG19
SEG22
SEG21
SEG24
SEG23
SEG26
SEG25
SEG28
SEG27
SEG29
SEG30
SEG31
P82/REM
P83/PWM0
P84/EC0
P85/EINT10
P86/TxD
P87/RxD
P92
P00
P01
P02
P03
P04
P06
P07
P16
P15
P14
P21/AN1
P20/AN0VCC
P24/AN4
P23/AN3
P22/AN2
P26/AN6
P25/AN5
P12
P34
P33
P32
P31
P27/AN7
P13
P03P01 P02P00
P31
P32
P33
P82/REM
P83/PWM0
P84/EC0
P85/EINT10
P92
P04
P06
P07
P12
P13
P15
P14
P16
P21/AN1
P20/AN0
P23/AN3
P24/AN4
P22/AN2
P25/AN5
P26/AN6
P34
P27/AN7
SEG0
SEG1
SEG2
SEG3
SEG4
SEG5
SEG6
SEG7
SEG8
SEG9
SEG10
SEG11
SEG12
SEG13
SEG14
SEG15
COM0
SEG31
SEG30
SEG29
SEG28
SEG27
SEG26
SEG25
SEG24
SEG23
SEG22
SEG21
SEG20
SEG19
SEG18
SEG17
SEG16
COM3
COM1 COM2
VCC_T
VCC_T
VCC_TVCC_T VCC_TVCC_T
VCC_T
VCC_T
VCC_T
TxD
RxD
Title
Size
Rev
Zilog
1590 Buckeye Drive
Milpitas, CA 95035
408-513-1500
Website: www.zilog.com
Page
Zilog Confidential All Rights Reserved
Z51F3221ATX Development Board
MCU
Title
Size
Rev
Zilog
1590 Buckeye Drive
Milpitas, CA 95035
408-513-1500
Website: www.zilog.com
Page
Zilog Confidential All Rights Reserved
Z51F3221ATX Development Board
MCU
Title
Size
Rev
Zilog
1590 Buckeye Drive
Milpitas, CA 95035
408-513-1500
Website: www.zilog.com
Page
Zilog Confidential All Rights Reserved
Z51F3221ATX Development Board
MCU
Y1
12 MHz
1 3
2
J7
1
C3
0.1uF
C5
0.1uF
SW1
B3U-1000P
12
J1
1x18
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
PROTO1
proto 15x8
1
1
2
2
3
3
4
4
7
7
5
5
8
8
6
6
R6 49.9K
U4
CEM1206S
+
1
-
2
C4
18pF
C2
18pF
SW2
B3U-1000P
1 2
SW5
B3U-1000P
1 2
R11
470
C1
0.1uF
R15
49.9K
SW3
B3U-1000P
1 2
R10
470
R14
49.9K
SW4
B3U-1000P
1 2
D1
LL4148
21
R9
470
R7
200
VR1
2.5V
1
2
3
Y2
32.768KHZ
J2
1x18
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
R13
49.9K
R3
10K
D4
YELL
21
R8
2.2K
U2
spare
1
1
2
2
3
3
4
4
5
5
6
6
7
7
889
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
R12
49.9K
D3
RED
21
D2
GREEN
21
1
23
4
U1
Z51F322
P77/SEG3/RXD
1
P80/SEG32
2
P81/SEG33
3
P82/SEG34/REM
4
P83/SEG35/PWM0O/T0O
5
P84/SEG36/EC0
6
P85/SEG37/EINT10/ACK
7
P86/SEG38/TXD
8
P87/SEG39/RXD
9
VDD
10
VSS
11
XOUT
12
XIN
13
P92
14
SXIN
15
SXOUT
16
RESETB
17
VREG
18
P00/EINT0
19
P01/EINT1
20
P02/EINT2
21
P03/EINT3
22
P04/EINT4
23
P05/EINT5/EC3/BUZO
24
P06/EINT6
25
P07/EINT7
26
P10/DSCL
27
P11/DSDA
28
P12/EINT13/PWM3O/T3O
29
P13/EC3/BUZO
30
P14/SO
31
P15/SCK
32
P16/SI
33
P20/AN0
34
P21/AN1
35
P22/AN2
36
P23/AN3
37
P24/AN4
38
P25/AN5
39
P26/AN6
40
LVIREF/AN7/P27
41
AVREF
42
AVSS
43
VLC0/P31
44
VLC1/P32
45
VLC2/P33
46
VLC3/P34
47
COM0/P35
48
COM1/P36
49
SEG0/COM2/P40
50
SEG1/COM3/P41
51
SEG2/COM4/P42
52
SEG3/COM5/P43
53
SEG4/COM6/P44
54
SEG5/COM7/P45
55
SEG6/P46
56
SEG7/P47
57
SEG8/P50
58
SEG9/P51
59
SEG10/P52
60
SEG11/P53
61
SEG12/P54
62
SEG13/P55
63
SEG14/P56
64
SEG15/P57
65
SEG16/P60
66
SEG17/P61
67
SEG18/P62
68
SEG19/P63
69
SEG20/P64
70
SEG21/P65
71
SEG22/P66
72
SEG23/P67
73
SEG24/P70
74
SEG25/P71
75
REM/SEG26/P72
76
T0O/PWM0O/SEG27/P73
77
EC0/SEG28/P74
78
ACK/EINT10/SEG29/P75
79
TXD/SEG30/P76
80
U3
spare
1
1
2
2
3
3
4
4
5
5
6
6
7
7
889
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
J3
HDR/PIN 2x5
1 2
3 4
5 6
7 8
9 10
LCD1
VIM-878
1D_1E_1F_CA1
1
1L_1K_1J_1I
2
2D_2E_2F_CA2
3
2L_2K_2J_2I
4
3D_3E_3F_CA3
5
3L_3K_3J_3I
6
4D_4E_4F_CA4
7
4L_4K_4J_4I
8
5D_5E_5F_CA5
9
5L_5K_5J_5I
10
6D_6E_6F_CA6
11
6L_6K_6J_6I
12
7D_7E_7F_CA7
13
7L_7K_7J_7I
14
8D_8E_8F_CA8
15
8L_8K_8J_8I
16
COM0
17
COM1
18
COM2
19
COM3
20
8A-8B_8C_DP8
21
8H_8G_8N_8M
22
7A_7B_7C_DP7
23
7H_7G_7N_7M
24
6A_6B-6C_DP6
25
6H_6G_6N_6M
26
5A_5B_5C_DP5
27
5H_5G_5N_5M
28
4A_4B_4C_DP4
29
4H_4G_4N_4M
30
3A_3B_3C_DP3
31
3H_3G_3N_3M
32
2A_2B_2C_DP2
33
2H_2G_2N_2M
34
1A_1B_1C_DP1
35
1H_1G_1N_1M
36
R2
10K
C6
0.1uF
J6
1
J8
HDR/PIN 1x24
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
R5
1 ohm
Figures 32 and 33 display schematic diagrams of the Z51F3221 Development Board.
Z51F3221 Development Kit
User Manual
38
UM025801-1112 Schematic Diagrams
Figure 32. Z51F3221 Development Board, #1 of 2
Z51F3221 Development Kit
PWR_EN-
VCC_T
RxD
TxD
VCC_T
VCC_5V
VCC_5V
VCC_T
RxD
TxD
J12
1
R23
4.7K
C7
4.7uF
R22
470
C15
0.1uF
U6
TPS2051B
OUT
1
GND
2
OC
3
EN
4
IN
5
D6
RED
2 1
C8
0.1uF
R19
20K
C11
4.7uF
R17
20K
J13
1
J11
1
L1
FERRITE BEAD
J10
1
P1
USB, mini B
VBUS
1
DM
2
DP
3
ID
4
GND
5
SH1
6
SH2
7
SH3
8
SH4
9
h1
10
h2
11
C9
1uF
R16
470
R18
1.5K
J9
1
D5
GREEN
21
R21
4.75K
C10
1uF
C13
0.01uF
C12
0.1uF
R20
20K
1 3
2
U5
MIC5318
GND
2
EN
1
IN
3
ADJ
5
OUT
4
BYP
6
Center Pad
7
C14
0.01uF
U7
FT232RL
USBDM
16
RTS
3
GND1
7
RI
6
NC1
8
DTR
2
VCCIO
4
3v3 OUT
17
NC
24
RESET
19
TXD
1
USBDP
15
CBUS3
14
OSCI
27
OSCO
28
GND218TEST
26
CBUS1
22
GND3
21
DCD
10
CTS
11
DSR
9
RXD
5
CBUS4
12
CBUS2
13
AGND
25
CBUS0
23
VCC
20
R24
100K
User Manual
39
Figure 33. Z51F3221 Development Board, #2 of 2
UM025801-1112 Schematic Diagrams
Z51F3221 Development Kit
User Manual
Appendix B. OCD Driver Installation on Windows Vista Systems
The driver programs for the Z8051 On-Chip Debugger are copied to the development PC
during the software and documentation installation. In the following procedure for PCs
running Windows Vista 32- and 64-bit operating systems, ensure that the target side of the
OCD will remain unconnected while you install these drivers.
1. Connect the OCD hardware to the USB port of your PC by connecting the A (male)
end of one of the two USB A (male)-to-Mini-B cables with the development PC’s
USB port. Connect the Mini-B end to the OCD device.
2. After the PC detects the new hardware, it will display the Found New Hardware Wizard dialog box, shown in Figure 34. Click
ommended)
.
Locate and install driver software (rec-
40
Figure 34. Found New Hardware Dialog, Windows Vista
3. Depending on your development PC’s User Account Control settings, Windows may
ask for permission to continue the installation. Click
UM025801-1112 OCD Driver Installation on Windows Vista Systems
Continue.
Z51F3221 Development Kit
User Manual
4. When the Insert the Disc dialog appears, as shown in Figure 35, select I don’t have
the disc. Show me other options.
Click the Next button to display the dialog that
follows, which is shown in Figure 36.
41
Figure 35. Install Device Driver Dialog, Windows Vista
UM025801-1112 OCD Driver Installation on Windows Vista Systems
Z51F3221 Development Kit
User Manual
42
Figure 36. Couldn’t Find Driver Dialog, Windows Vista
5. Return to page 8 and follow Steps 3 through 6.
UM025801-1112 OCD Driver Installation on Windows Vista Systems
Z51F3221 Development Kit
User Manual
Appendix C. OCD Driver Installation on Windows XP Systems
The driver programs for the Z8051 On-Chip Debugger are copied du ring the software and
documentation installation. In the following procedure for Windows XP systems, ensure
that the target side of the OCD will remain unconnected while you install these drivers.
1. Connect the OCD hardware to the USB port of your PC by connecting the A-Male end
of one of the two USB A (male)-to-Mini-B cables with the host PC’s USB port, and
connect the Mini-B end to the OCD device.
43
2. After the PC detects the new hardware, it will display the
ard
dialog box, shown in Figure 37. Select Install from a list or specific location
(Advanced)
; then click Next.
Found New Hardware Wiz-
Figure 37. The Found New Hardware Wizard Welcome Screen
UM025801-1112 OCD Driver Installation on Windows XP Systems
Z51F3221 Development Kit
Note:
User Manual
3. The next dialog box, shown in Figure 38, prompts you to enter a path or navigate to
the directory in which the
you use (32- bit or 64-bit), use the
paths and click the
.inf file was installed. Depending on the type of computer
Browse button to navigate to one of the following
Next button, leaving all other selections at their default settings.
– On 32-bit machines, use the following path:
<Z8051 Installation>\Z8051_<version_number>\device drivers\OCD USB\x32
– On 64-bit machines, use the following path:
<Z8051 Installation>\Z8051_<version_number>\device drivers\OCD USB\x64
On some installations, the Found New Hardware screen shown in Figure 37 may also display the text string,
Zilog Z8051 USB OCD - No Firmware. This occurrence is normal
and can be disregarded.
44
Figure 38. The Found New Hardware Wizard’s Browse Screen
UM025801-1112 OCD Driver Installation on Windows XP Systems
Z51F3221 Development Kit
User Manual
4. When Windows prompts you whether to continue the installation or stop, click the
Continue Anyway button and wait until the installation is completed (Windows may
prompt you more than once). When the installation is complete, click
Finish.
45
UM025801-1112 OCD Driver Installation on Windows XP Systems
Z51F3221 Development Kit
User Manual
Appendix D. Stand-Alone Flash Programming Using the Keil µVision IDE
Observe the following procedure to program Flash memory without debugging.
46
1. From the
Utilities tab. In the Use Target Driver for Flash Programming drop-down menu
within the Configure Flash Menu Command pane, ensure that
Driver
Project menu, open the Options for Target 'your project’, and click the
Zilog Z8051 Target
is selected, as indicated in Figure 39.
Figure 39. Selecting A Target Driver For Flash Programming
2. Click the
will appear, as shown in Figure 40.
UM025801-1112 Stand-Alone Flash Programming Usin g the Keil
Settings button to change any additional Flash options. The Settings dialog
Z51F3221 Development Kit
User Manual
47
Figure 40. Configuring Additional Flash Options
3. After you have selected your Flash options, click OK to exit the Flash Options dia-
log.
4. Click
5. From the
OK to exit the Options For Target ‘Demo’ dialog.
Flash menu of the Keil IDE (see Figure 41), select either of the following
options:
– Select
– Select
Download to program Flash memory with the current project
Erase to perform a mass erase of internal Flash memory
Figure 41. The Keil IDE Flash Menu
UM025801-1112 Stand-Alone Flash Programming Usin g the Keil
Customer Support
To share comments, get your technical questions answered, or report issues you may be
experiencing with our products, please visit Zilog’s Technical Support page at http://sup-
port.zilog.com.
To learn more about this product, find additional documentation, or to discover other facets about Zilog product offerings, please visit the Zilog Knowledge Base
ticipating in the Zilog Forum
This publication is subject to replacement by a later edition. To determine whether a later
edition exists, please visit the Zilog website at http://www.zilog.com
.
Z51F3221 Development Kit
User Manual
48
or consider par-
.
UM025801-1112 Customer Support
Loading...
