Introduction
This Quick Start Guide provides instructions to use Zilog’s Wireless Zdots® Single Board
Computer (SBC) with the Demo project
WLANDemo.zdsproj. WLANDemo.zdsproj is a
sample project in which the communication of a PC to a web page is wireless, it is run by
Zdots SBC. The
WLANDemo.zdsproj is used along with standard Zilog TCP/IP (ZTP)
software suite. This Demo project can only be used on Wireless Zdots SBC. Do not use
this Demo project on Zilog’s eZ80Acclaim!
®
development kit. This project can also be
used as the starting point for your application development.
Figure 1. Wireless Zdots
®
SBC Development Kit
Wireless Zdots
®
Single Board
Computer Development Kit
Quick Start Guide
QS007504-0410
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 2 of 19
Figure 2. Wireless Zdots® SBC and Base Board
Figure 3. Wireless Zdots
®
SBC
Wireless Module
RS-232
Adapter
Wireless Development kit Base Board
Prototype Area
ZDI Interface
eZ80F91
NOR Flash
SRAM
RS-232/PWR
MII Input/Output
On-Board Antenna
Input/Output
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 3 of 19
Figure 4. Wireless Base Board
Kit Contents
This section describes the hardware and software requirements for installing and using
Wireless Zdots
®
Single Board Computer Development Kit.
Hardware
The hardware included in this kit are:
• eZ80AcclaimPlus! Wireless Zdots SBC
• eZ80AcclaimPlus! Wireless Zdots SBC Development Kit Base Board
• RS-232 Adapter
• USB Smart Cable
• 5 V DC Power Supply
• RS-232 Cable
Wireless module Plug-in Headers
ZDI
DC Power Input
Prototype
Test Points
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 4 of 19
The additional hardware that are required to run the Demo (not included
in the kit) are:
1. A USB to Serial Adapter for host PC that do not have a serial COM
port.
2. Wireless LAN router.
Software and Documentation (on CD-ROM)
The software included in this kit are:
• Zilog Developer Studio II (ZDS II)-eZ80 Acclaim!
®
• Zilog TCP/IP Stack (ZTP) ZDS - Object Code
1. For latest revision, visit www.zilog.com
.
2. For procedure to download the ZTP software, see Downloading the
ZTP Software on page 18.
System Requirements
Table 1 lists the system requirements for running
ZDS II
.
Table 1. ZDS II System Requirements
Recommended Configuration Minimum Configuration
PC running Microsoft Windows XP
Professional
PC running Microsoft Windows XP Professional/
Windows 2000 SP4/Windows 98 SE
Pentium III/500 MHz or higher
processor
Pentium II/233 MHz processor
128 MB RAM 96 MB RAM
110 MB hard disk space 25 MB hard disk space (documentation not installed)
Super VGA video adapter Super VGA video adapter
CD-ROM drive CD-ROM drive
One or more RS-232
communications ports
One or more RS-232 communications ports
USB high-speed port USB high-speed port
Notes:
Notes:
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 5 of 19
Installing the ZDSII Software and Kit Documentation
Follow the steps below to install the ZDS II and documentation:
1. Insert the ZDS II CD into the CD-ROM drive. DemoShield launches automatically. If
the DemoShield does not launch automatically, open the Windows Explorer, browse
to your CD-ROM drive, and double-click
launch.exe to launch the installer.
2. From the product installer list you can choose to install ZDS II alone, or both ZDS II
and associated documentation. You can also copy the documentation directly from
your CD-ROM drive to your hard disk using Windows Explorer or read the documentation directly from the CD-ROM itself.
For customer service and technical support, Zilog
®
recommends you to create an account
on http://support.zilog.com
.
Installing the USB Smart Cable
Follow the steps below for installing the USB Smart Cable and associated driver software.
Windows Vista-32
Follow the steps below to install the USB Smart Cable for Windows Vista-32.
1. Connect the USB Smart Cable to the Host PC. The Found New Hardware dialog box
is displayed.
2. Select Locate and install the driver software (recommended). The Driver Soft-
ware Installation window is displayed, and then the Found New Hardware-USB
Smart Cable dialog box is displayed.
3. Select I don’t have the disc. Show me other options.
4. Select Browse my computer for driver software (advanced).
5. Browse to the following driver directory:
<ZDS II Installation Directory>\device drivers\USB
The Windows Security dialog box is displayed.
6. Select Install this driver software anyway.
7. When the software is installed, click Closed.
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 6 of 19
Windows XP
Follow the steps below to install the USB Smart Cable for Windows XP:
1. Connect the Zilog USB device to the Host PC. The Found New Hardware Wizard
should activate automatically after connecting the Zilog USB device for the first time;
select No, not at this time if asked to connect to Windows Update.
2. Select Install from a list or specific location (Advanced); then click Next.
If the Windows Logo testing dialog appears, select Continue Anyway.
3. Select Search for the best driver in these locations and Include this location in
search:.
4. Browse to the following driver directory and click Next.
<ZDS installation>\device drivers\USB\
5. Click Next after the appropriate driver is found.
6. Click Finish to complete the installation.
Windows 2000
Follow the steps below to install the USB Smart Cable for Windows 2000:
1. Connect the Zilog USB device to the Host PC. The Found New Hardware Wizard
should activate automatically after connecting the Zilog USB device for the first time.
2. Click Next in the Found New Hardware Wizard after it has been activated.
3. Select Search for a suitable driver for my device (Recommended) and click Next.
4. Select Specify a location and click Next.
5. Browse to the following driver directory and click OK.
<ZDS installation>\device drivers\USB\
6. Click Next after the appropriate driver is found.
7. Click Finish to complete the installation.
Note:
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 7 of 19
Windows 98SE
Follow the steps below to install the USB Smart Cable for Windows 98SE:
1. Connect the Zilog USB device to the Host PC. The Add New Hardware Wizard
should activate automatically after connecting the Zilog USB device for the first time.
2. Click Next in the Add New Hardware Wizard after it has been activated.
3. Select Search for the best driver for your device (Recommended) and click Next.
4. Select Specify a location: and browse to the following driver directory, and click
Next.
<ZDS installation>\device drivers\USB\
5. Click Next after the appropriate driver is found.
6. Click Finish to complete the installation.
Hardware Setup
Figure 5 displays the hardware setup for the ZTP Wireless Local Area Network (WLAN)
Demo application that is used to demonstrate wireless data transfer.
Figure 5. Hardware Setup for the ZTP WLAN Demo Application
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 8 of 19
Figure 6. RS-232 Adapter
Follow the steps below to set up the hardware:
1. Connect Zdots SBC to J1 of the Wireless base board. See Figure 2 on page 2 for actual
image. The SBC must be connected before applying the power.
Pin 1 of Zdots SBC should match the pin 1 of the base board; this is
indicated by square solder around the pin.
2. Connect the RS-232 adapter (99C1067-001G) to the WLAN Zdots SBC J3 header.
Pin 1 is indicated by the square solder on the solder side.
3. Connect the USB Smart cable (or any Zilog Debug tool) to the 6-pins ZDI interface on
the Wireless Base Board on your development PC. See Connecting the USB Smart
Cable to the Development Board on page 9.
4. Connect the RS-232 cable to the RS-232 adapter P1 connector and the other end to the
communication port (COM1) of the PC.
This is connected on your PC as displayed in Figure 5 on page 7.
5. Connect the power supply (5 V DC) cable to the Wireless Base board J4 connector.
6. Set up an access point (AP) in the test area and power it ON. For information on how
to set up the wireless router, see Configuring the Router on page 15.
RS-232 Driver
6 Pin TTL Level
TX, RX, RTS, CTS,
3.3 V and Ground
RS-232 DB9
Note:
Note:
Note:
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 9 of 19
Connecting the USB Smart Cable to the Development Board
The power to the development board must be disconnected or turned
OFF before connecting or disconnecting the USB Smart Cable.
Attach one end of the six-conductor ribbon cable (included) to the USB Smart Cable sixpin DBG connector (see Figure 7). Attach the free end of the ribbon cable to the DBG connector (ZDI Interface) on the development board. Ensure that pin 1 on the ribbon cable
(indicated by the dark stripe) is aligned with pin 1 on the target connector (indicated by a
square solder on the DBG pin).
Figure 7. Connecting the Six-Conductor Ribbon Cable to the USB Smart Cable
Configuring the HyperTerminal Application
The HyperTerminal program must be configured before starting the Demo application.
Follow the steps below to configure the HyperTerminal application:
1. In Windows operating system, launch the HyperTerminal application by navigating to
Start All Programs Accessories Communications HyperTerminal.
The Connection Description dialog box is displayed.
2. Enter the name for a new connection in the Connection Description dialog, and click
OK. The Connect To dialog box is displayed.
3. In the Connect Using text field, select the port (COM1 or COM2) to which the serial
cable is connected. Click OK to open the Port Settings dialog box for the selected
port.
Caution:
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 10 of 19
4. In the Port Settings tab of dialog box, enter the following values in the respective text
fields:
5. Click OK to establish connection to the eZ80
®
development platform using the serial
port.
How to Execute WLAN Demo Application
Running the RAM-Based WLAN Demo Project using the ZDS II
Toolset
Follow the steps below to execute the WLAN Demo project in the Zilog Developer Studio
II (ZDS II) development environment:
The following procedures reference the
WLANDemo.zdsproj located in the
CD-ROM. Insert Zilog TCP/IP Stack (ZTP) ZDS - Object Code Version
X.Y.Z
1
CD into the CD-ROM drive. InstallShield Wizard appears and starts
installation. Follow the on-screen procedures. By default, it is installed at
C:\Program Files\ZiLOG\ZTP_X.Y.Z_Lib_ZDS.
1. Set up the hardware as displayed in Figure 5 on page 7.
2. To launch ZDS II, navigate to Start All Programs Zilog ZDS
IIeZ80Acclaim!_<Version> _ZDS II-eZ80Acclaim!_<Version>.
3. Select Open Project from the File menu in ZDS II to open the sample ZTP Demo
project located in the following path:
For ZDSII - eZ80Acclaim! 5.1.0:
C:\Program Files\ZiLOG\ZDSII_eZ80Acclaim!_5.1.0\ZTP\ZTP2.3.1_Lib\ZTP\
SamplePrograms\WLANDemo\WLANDemo.zdsproj
Bits per second 57600 bps
Data bits 8
Parity None
Stop Bits 1
Flow control None
1
Where X.Y.Z refers to the major, minor, and revision number of the release.
Note:
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 11 of 19
<ZTP Installed Dir>\ZTP_X.Y.Z_Lib_ZDS\ZTP\SamplePrograms\WLANDemo\WLANDemo.zdsproj>
where
<ZTP Installed Dir> is the path to the ZTP folder that you set when you
installed the
ZTP_X.Y.Z_Lib_ZDS. The default location of
<ZTP Installed Dir> is C:\Program Files\ZiLOG.
4. Select Build Set Active Configuration to open the Select Configuration dialog
box, and select the RAM configuration.
5. From the Project menu in ZDS II, select Settings. The Project Settings dialog box
appears.
6. In the Project Settings dialog box, select the Debugger tab. In the Debugger tab,
ensure eZ80F91_WiFi_RAM option is checked and the correct debug tool is
selected. In this Demo, USB Smart Cable is used as the Debug Tool.
7. Click OK to close the Project Settings dialog box.
If the ZDS II prompts to Rebuild the Project, click YES to enable the
configuration on Project Settings.
8. After the successful build, run the Demo application using Debug Go.
This is observed on Hyper Terminal window:
Initializing SPI
Initializing SDIO card
get SYSCLKR=c0000000
set SYSCLKR=c0000003
get SYSCLKR=c0000003
RTL8711_3rdCUT
SYSCTRL : 68 !
EEPROM ID=8711
EEPROM MAC Address = 0-90-23-0-4e-ab
Downloading FW# totlen=118300, img sz=118200, hdrsz=100...Done
Firmware Init OK[ZTP ]>
9. Once the shell prompt appears, use the scan command on the Hyper Terminal
window and press Enter to search the access points (AP) available in the range.
Note:
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 12 of 19
Firmware Init OK[ZTP ]>scan
SSID Scanning
.................Done
Number of Aps 2
SSID MAC Address Ch RSSI Secure
================== ================= == ==== =====
00:20:a6:50:f3:65 11 ffa2 WEP
NETGEAR 00:18:f8:4a:62:48 11 ffa2 WEP
[ZTP ]>
Then use the wep [<SSID> <keyld=0-3> [keyDataHex]]shell command to
specify the hexadecimal WEP key. To display the current WEP key information just
issue the ‘wep’ command with no parameters. Use the join<SSID> shell command to
connect to a specified AP.
[ZTP ]>wep NETGEAR 0 378E919303657C6DBCA9B29A5E
Active WEP key for SSID NETGEAR is 0
37 8e 91 93 03 65 7c 6d bc a9 b2 9a 5e
[ZTP ]>wep
Active WEP key for SSID NETGEAR is 0
37 8e 91 93 03 65 7c 6d bc a9 b2 9a 5e
[ZTP ]>join NETGEAR
Sending Auth....
Joining BSS....SSID NETGEAR
Querying DHCP Server...DHCP OK
Initializing network stack...
IF IP addr Def Gtway state type
0 10.20.2.39 10.20.2.39 UP Ethernet
HTTPD ready
TELNET ready[ZTP ]>
For more details on shell commands, refer to Zilog TCP/IP Software Suite
Programmer’s Guide (RM0041).
SSID and WEPKEY are provided by the wireless router. In this demo NETGEAR and 378E919303657C6DBCA9B29A5E key are used. See Figure 9
and Figure 10 on page 17.
10. After successful connection to the BSS (AP) the network stack will be initialized and
Zdots
®
SBC behaves as a complete wireless station.
Note:
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 13 of 19
1. To support FLASH and COPY_TO_RAM configuration on Wireless
Zdots SBC (due to new external SPANSION Flash) ZDS II Flash driver
configuration file must be modified. Replace the
FlashDevice.xml
file in the
...\ZDSII_eZ80Acclaim!_4.x.x\config folder with
the file given in the WLANDemo folder. In the Project Settings
Debugger;
eZ80F91_WiFi_Flash must be selected for FLASH and
COPY_TO_RAM configurations. After replacing the
FlashDevice.xml file close all ZDS II instances and reopen again.
2. By default the
wlan_conf.c file contains WLAN parameters set to
zero. In this case, you can configure these parameters through shell
and connect to a BSS (AP).
3. If the WLAN parameters in
wlan_conf.c are valid (that is, not initial-
ized to NULL), the Demo connects to the specified BSS (AP) without
the user interaction.
4. In FLASH and COPY_TO_RAM configurations the SSID and WEP key
can be set through the
configwlan shell command. For more details,
refer to Zilog TCP/IP Software Suite Programmer’s Guide (RM0041).
5. The Zdots
®
WLAN solution cannot be configured to work as an Access
Point.
Web Server Demonstration
Follow the steps below to use the features of WLAN Demo:
1. When you run the WLAN Demo application Zdots SBC accesses the BSS with the
specified SSID and displays the network parameters such as IP address and a login
prompt on the HyperTerminal. You can type
help on the prompt to know other
command line applications.
2. Use
ping command from any PC in the same BSS/ESS as Zdots SBC running ZTP.
Ping command can be used from Zdots SBC shell to other PC also.
3. Open an Internet Explorer from a PC/laptop where the router is connected and browse
the eZ80
®
WLAN Zdots SBC with the IP specified on the Hyper Terminal. In this
demo the given IP address is 192.168.1.102. See Figure 8.
IP Address may vary. Please verify this value on IP addr on the
hyperterminal.
Notes:
Note:
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 14 of 19
Figure 8. Website Browsing
You can use Telnet client from a PC to browse the eZ80 WLAN Zdots SBC and access its
shell prompt through the wireless connection.
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 15 of 19
Configuring the Router
The following steps below in configuring the router is set with SSID equal to
‘NETGEAR’ and the generated keys:
These steps are based on LINKSYS WRT54G Router.
1. Disable the wireless connection on your laptop/PC.
2. If you are using Proxy server for your LAN settings, you can disable it by browsing to
Start Settings Control Panel Internet Options Connections
LAN Settings. Uncheck the proxy server on Proxy Server section then select
Automatically detect settings on Automatic configuration section. Then click OK on
LAN Settings and Internet Properties.
3. Connect the cable on the Ethernet port of your laptop/PC to the router (AP) using one
of its port (not the internet port).
4. Power ON your router.
5. Type 192.168.1.1 in the address bar of Internet Explorer (IE).
6. Enter ‘admin’ in the Password field. Do not enter any User name. You can now see the
Linksys page as displayed in Figure 9.
7. Select Wireless Basic Wireless Settings. Change the Wireless Network Name
(SSID): field to ‘NETGEAR’. See Figure 9.
Note:
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 16 of 19
Figure 9. Basic Wireless Settings
8. Click Save Settings. Then click Continue if settings are successful.
9. Select Wireless Wireless Security. Ensure that WEP is selected on the Security
Mode: field as displayed in Figure 10 (Change the Security Mode to WEP through the
drop down button).
Click Generate if Key 1 and other Keys do not have a value.
Note:
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 17 of 19
Figure 10. Wireless Security
10. Click Save Settings. Then click Continue if settings are successful.
11. You can now try to connect using the specified SSID and Key 1.
12. You can now run your project. See: “How to Execute WLAN Demo Application”
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 18 of 19
Downloading the ZTP Software
Follow the steps below to download the ZTP software from Zilog website
www.zilog.com
:
1. Visit the link http://support.zilog.com/support/product/products.asp
.
2. Login with registered username and password. After a successful login you can now
register your product. Click on Register New Products, and enter the Registration
Key Number found on the Registration Card that is included on the kit. Then click on
the Register button.
3. Locate and find eZ80F91WF01ZCOG and click on the corresponding Updates
Available link.
4. Click on Zilog TCP/IP Stack (ZTP) ZDS - Object Code to download ZTP X.Y.Z
object package; that is,
ZTP_X.Y.Z_Lib_ZDS.exe file.
5. After a successful download, locate
ZTP_X.Y.Z_Lib_ZDS.exe. Double click
ZTP_X.Y.Z_Lib_ZDS.exe and follow the on-screen instructions to complete the
installation. By default
ZTP_X.Y.Z_Lib_ZDS is installed in the following location:
C:\Program Files\ZiLOG\.
References
The documents associated with Wireless Zdots® SBC, ZTP, and RZK available on
www.zilog.com
are listed below:
• eZ80AcclaimPlus!
™
Wireless Zdots® Single Board Computer Product Specification
(PS0280)
• Wireless Zdots
®
Single Board Computer Development Kit User Manual (UM0224)
• Zilog TCP/IP Software Suite Programmer's Guide (RM0041)
• Zilog Full-Feature TCP/IP Software Suite Product Brief (PB0154)
• Zilog TCP/IP Software Suite Quick Start Guide (QS0049)
• Zilog TCP/IP Stack API Reference Manual (RM0040)
• Zilog Real-Time Kernel Product Brief (PB0155)
• Zilog Real-Time Kernel Quick Start Guide (QS0048)
• Zilog Real-Time Kernel Reference Manual (RM0006)
Wireless Zdots® Single Board Computer Development Kit
QS007504-0410 Page 19 of 19
DO NOT USE IN LIFE SUPPORT
LIFE SUPPORT POLICY
ZILOG'S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS
PRIOR WRITTEN APPROVAL OF THE PRESIDENT AND GENERAL COUNSEL OF
ZILOG CORPORATION.
As used herein
Life support devices or systems are devices which (a) are intended for surgical implant
into the body, or (b) support or sustain life and whose failure to perform when properly
used in accordance with instructions for use provided in the labeling can be reasonably
expected to result in a significant injury to the user. A critical component is any component in a life support device or system whose failure to perform can be reasonably
expected to cause the failure of the life support device or system or to affect its safety or
effectiveness.
Document Disclaimer
©2010 by Zilog, Inc. All rights reserved. Information in this publication concerning the
devices, applications, or technology described is intended to suggest possible uses and
may be superseded. ZILOG, INC. DOES NOT ASSUME LIABILITY FOR OR PROVIDE A REPRESENTATION OF ACCURACY OF THE INFORMATION, DEVICES,
OR TECHNOLOGY DESCRIBED IN THIS DOCUMENT. ZILOG ALSO DOES NOT
ASSUME LIABILITY FOR INTELLECTUAL PROPERTY INFRINGEMENT
RELATED IN ANY MANNER TO USE OF INFORMATION, DEVICES, OR TECHNOLOGY DESCRIBED HEREIN OR OTHERWISE. The information contained within
this document has been verified according to the general principles of electrical and
mechanical engineering.
eZ80, eZ80Acclaim!, eZ80AcclaimPlus!, and Zdots are trademarks or registered trademarks of Zilog, Inc. All other product or service names are the property of their respective
owners.
Warning:
Loading...
