_English_
TOASTER OVEN
Z-1441-R
Instruction manual
Read these instructions for use carefully before you use the appliance for the first time and save them for future
reference.
DESCRIPTION
The toaster oven is a versatile, economical deluxe oven toaster.
The toaster oven features a heat select switch, allowing you greater control for optimum cooking performance.
A versatile timer is included to give flexibility with your cooking. Enjoy cooking with your oven.
SAFETY PRECAUTIONS
Keep small children away from the machine. Never let the power cord hang down over the worktop edge-a
child could grab it and pull the machine down;
Do not use if there is any damage to the machine, power cord or plug. It should be repaired by a service
agent or similar qualified person in order to avoid a hazard;
Never put the machine in water or let the power cord or plug get wet;
The temperature of accessible surfaces may be high when the appliance is operating;
Use protective gloves to remove the food tray;
This machine is for domestic use only;
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children being supervised not to play with the appliance;
Appliances are not intended to be operated by means of an external timer or separate remote-control
system;
Operate the appliance on a flat , clean surface - away from material that may be affected by heat;
Do not operate near other heating appliances;
Do not allow food to contact the heating tube, to prevent burning;
Do not allow cold objects to touch the glass when it is hot, to prevent breakage;
Unplug the oven from the wall outlet, when not in use and before cleaning.
BEFORE PLUGGING IN
Make sure your electricity supply is the same as the one shown on the back of your machine.
This machine is manufactured to meet European Safety Requirements.
BEFORE USING FOR THE FIRST TIME
Pre-heat the oven for 3 to 5 minutes to cook perfectly.
Sometimes during the first use, some smoke and burning smell may be noted. This is normal and will stop once
operating temperature is achieved.
_English_
PARTS DESCRIPTION
1. Cooking mode selector knob
2. Timer control knob
3. Power light
4. Glass door
5. Door handle
6. Crumb tray
7. Heating element
8. Tray
9. Wire rack
HOW TO COOK
1. Pre-heat the oven for 3 to 5 minutes to cook perfectly;
2. Place food in the oven, on a metal tray. Oily foods must be wrapped in aluminum foil (oil spilled onto the
tray will burn, causing smoke and damage to the tray). Non-oily food can be placed directly on the tray;
3. With the cooking mode selector knob (1) set the desired operating mode. You can choose between the
following modes:
Both elements are OFF
Upper element is ON
Lower element is ON
Both elements are ON
4. Adjust the timer (2), have in mind the following:
Your timer acts as on / off switch of the device (if not turning the timer device will not work). Turn the
timer clockwise to set the approximate cooking time up to 30 minutes. When cooking time is complete, a
signal will sound and the unit will turn off automatically.
Different foods may cost different time, some of foods need longer than 30 minutes, you may cook it twice,
and it is a matter of personal choice. If this is the case just turn the timer again and the unit will work
again;
In order to cook foods more evenly, you may move or turn the food over during cooking;
When oven is in operation, and you want to remove the food before the timer has completed - turn timer
knob to the “0” position before taking the food out;
5. After use, turn off the heater, turn the timer to "0" and disconnect the power. Allow the unit to cool before
touching it with his hand. Always use gloves.
MAINTENANCE AND CLEANING
Tray, wire rack &crumb tray
To open crumb tray slightly raise the unit, push the lever
back and then carefully pull down. Closing in reverse
order.
Empty and clean the crumb tray often;
Crumb tray is cleaned only after the unit is completely cool;
Wash the tray and the metal grille in soapy water immediately after use to prevent the grease accumulation.
After washing, dry with a dry cloth.
_English_
To clean body
Use a clean, soft cloth soaked in warm soapy water.
Dry with a soft dry cloth;
Body must be cleaned until after its complete cooling.
To clean inside
If the inside of the unit remained splashes of oil that cannot be cleaned, use a clean soft cloth dampened
with water and soap.
Then wipe gently with a soft dry cloth;
Carefully clean and heating pipes;
The unit must be cleaned only after its complete cooling.
