848C8C93A1 (506)
CHAIN SAW
G5200
NOTE :
1.Use KOMATSU ZENOAH genuine parts specified in the parts list for repair and/or replacement.
2.KOMATSU ZENOAH does not warrant the machines, those which have been damaged by the use of any parts other than those specified by the company.
3.When placing orders of parts for repair and/or replacement, check if the model name and the serial number are suitable to those specified in the parts list, then use parts number described in the parts list.
4.The contents described in the parts list may change due to improvement.
5.The parts for the machine shall be supplied within ten (10) years after the machine is discontinued. [It is possible that some specific parts may be subject to change of their delivery term and list price within the limit of ten (10) years after the machine is discontinued. And it is also possible that some parts may be available even after the limit of ten (10) years.]
APPLICABLE SERIAL NUMBERS : 303107 and up |
June 2005 |
G5200
Fig.1 POWER UNIT
G5200
Fig.1 POWER UNIT
Key# |
PART NUMBER |
DESCRIPTION |
Q'TY |
NOTE |
|
Key# |
PART NUMBER |
DESCRIPTION |
Q'TY |
NOTE |
/UNIT |
|
/UNIT |
||||||||
1 |
2880-12111 |
Cylinder |
1 |
ø45 |
|
|
|
|
|
|
2 |
2880-14111 |
Inlet Pipe |
1 |
|
|
|
|
|
|
|
3 |
2880-14120 |
Spring |
1 |
|
|
|
|
|
|
|
5 |
2880-14150 |
Inner Guide |
1 |
|
|
|
|
|
|
|
6 |
2670-14311 |
Bracket |
1 |
|
|
|
|
|
|
|
7 |
2670-14320 |
Screw M5x14 |
2 |
|
|
|
|
|
|
|
8 |
2880-14350 |
Spacer |
1 |
|
|
|
|
|
|
|
9 |
2880-14361 |
Gasket |
1 |
|
|
|
|
|
|
|
10 |
2670-14211 |
Gasket, Cylinder |
1 |
|
|
|
|
|
|
|
11 |
4820-13180 |
Bolt, Cylinder M5x20 |
4 |
|
|
|
|
|
|
|
12 |
2810-15220 |
Bolt, Muffler M5x83 |
2 |
|
|
|
|
|
|
|
13 |
2850-15230 |
Nut, Muffler M5 |
2 |
|
|
|
|
|
|
|
14 |
2810-15113 |
Muffler |
1 |
|
|
|
|
|
|
|
15 |
2670-14130 |
Screw M5x10 |
2 |
|
|
|
|
|
|
|
16 |
3356-15210 |
Gasket, Muffler |
1 |
|
|
|
|
|
|
|
17 |
2810-15310 |
Cover |
1 |
|
|
|
|
|
|
|
18 |
848C802101 |
Crankcase assy |
1 |
|
|
|
|
|
|
|
19 |
3356-21130 |
• Spring Pin |
3 |
|
|
|
|
|
|
|
20 |
T4012-21240 |
• Bearing 15x35x11 |
2 |
|
|
|
|
|
|
|
21 |
04065-03515 |
• Snap Ring ø35 |
1 |
|
|
|
|
|
|
|
22 |
2670-21210 |
• Oil Seal 15x35x4.5 |
1 |
|
|
|
|
|
|
|
23 |
2670-21220 |
• Oil Seal 15x28X4.5 |
1 |
|
|
|
|
|
|
|
24 |
2850-21230 |
• Stud |
2 |
|
|
|
|
|
|
|
25 |
2670-21250 |
• Elbow |
1 |
|
|
|
|
|
|
|
26 |
2810-22511 |
• Stopper |
1 |
|
|
|
|
|
|
|
27 |
2810-22521 |
• Stopper |
1 |
|
|
|
|
|
|
|
28 |
848C8021D2 |
Gasket, Case |
1 |
|
|
|
|
|
|
|
29 |
2670-21320 |
Screw M5x25 |
5 |
|
|
|
|
|
|
|
30 |
2810-22210 |
Pipe 3x7x105 |
1 |
|
|
|
|
|
|
|
31 |
3310-82230 |
Clip |
1 |
|
|
|
|
|
|
|
32 |
2810-22411 |
Mat |
1 |
|
|
|
|
|
|
|
33 |
2880-41110 |
Piston ø45 |
1 |
|
|
|
|
|
|
|
34 |
2880-41210 |
Piston Ring ø45 |
2 |
|
|
|
|
|
|
|
35 |
2880-41310 |
Piston Pin 7.4x11x37.5 |
1 |
|
|
|
|
|
|
|
36 |
3350-41320 |
Snap Ring |
2 |
|
|
|
|
|
|
|
37 |
1400-41410 |
Needle Bearing 11x15x12.3 |
1 |
|
|
|
|
|
|
|
38 |
2670-41510 |
Washer |
2 |
|
|
|
|
|
|
|
39 |
848C8A4202 |
Crankshaft Comp. |
1 |
|
|
|
|
|
|
|
40 |
1000-43240 |
Key |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
G5200
Fig.2 IGNITION, STARTING
G5200
Fig.2 IGNITION, STARTING
Key# |
PART NUMBER |
DESCRIPTION |
Q'TY |
NOTE |
|
Key# |
PART NUMBER |
DESCRIPTION |
Q'TY |
NOTE |
/UNIT |
|
/UNIT |
||||||||
1 |
2670-71101 |
Rotor assy |
1 |
|
|
|
|
|
|
|
2 |
1850-75220 |
• Ratchet |
2 |
|
|
|
|
|
|
|
3 |
2670-71130 |
• Spring |
2 |
|
|
|
|
|
|
|
4 |
0308-00040 |
• Ring |
2 |
|
|
|
|
|
|
|
5 |
3350-43231 |
Nut M8 |
1 |
|
|
|
|
|
|
|
6 |
0290-20820 |
Washer M8 |
1 |
|
|
|
|
|
|
|
7 |
2880-71300 |
Coil Assy |
1 |
|
|
|
|
|
|
|
8 |
2810-71204 |
• Coil Comp. |
1 |
|
|
|
|
|
|
|
9 |
2810-71220 |
• • Cord |
1 |
|
|
|
|
|
|
|
10 |
2670-71230 |
• • Grommet |
1 |
|
|
|
|
|
|
|
11 |
2810-72110 |
• Plug cap |
1 |
|
|
|
|
|
|
|
12 |
1400-72121 |
• Spring |
1 |
|
|
|
|
|
|
|
13 |
2670-71320 |
• Tube |
1 |
|
|
|
|
|
|
|
14 |
2810-71250 |
• Grommet |
1 |
|
|
|
|
|
|
|
15 |
2670-14220 |
Screw M5x20 |
2 |
|
|
|
|
|
|
|
18 |
2670-71510 |
Cord |
1 |
|
|
|
|
|
|
|
19 |
2880-71600 |
Switch assy |
1 |
|
|
|
|
|
|
|
20 |
2810-71610 |
• Switch |
1 |
|
|
|
|
|
|
|
21 |
2670-71621 |
• Switch Cover |
1 |
|
|
|
|
|
|
|
22 |
2880-71630 |
• Plate |
1 |
|
|
|
|
|
|
|
23 |
2670-14130 |
Screw M5x10 |
1 |
|
|
|
|
|
|
|
24 |
3699-90512 |
Spark plug (NGK BPM8Y) |
1 |
|
|
|
|
|
|
|
25 |
2810-21270 |
Plate |
1 |
|
|
|
|
|
|
|
26 |
0260-30410 |
Screw M4x10 |
2 |
|
|
|
|
|
|
|
27 |
2881-75000 |
Starter assy |
1 |
|
|
|
|
|
|
|
28 |
2810-75110 |
• Recoil case comp. |
1 |
|
|
|
|
|
|
|
29 |
2810-75120 |
• Guide |
1 |
|
|
|
|
|
|
|
30 |
2810-75150 |
• Boss |
1 |
|
|
|
|
|
|
|
31 |
2670-75212 |
• Reel |
1 |
|
|
|
|
|
|
|
32 |
3317-75300 |
• Spring comp. |
1 |
|
|
|
|
|
|
|
33 |
2670-75411 |
• Rope |
1 |
|
|
|
|
|
|
|
34 |
T2041-75420 |
• Knob |
1 |
|
|
|
|
|
|
|
35 |
T2041-75431 |
• Collar |
2 |
|
|
|
|
|
|
|
37 |
2881-75440 |
• Spring B |
1 |
|
|
|
|
|
|
|
38 |
1400-86280 |
• Washer |
1 |
|
|
|
|
|
|
|
39 |
2670-14220 |
• Screw |
1 |
|
|
|
|
|
|
|
40 |
2880-75600 |
Fan cover comp. |
1 |
|
|
|
|
|
|
|
42 |
2880-75620 |
• Sheet |
1 |
|
|
|
|
|
|
|
43 |
2670-14320 |
Screw |
4 |
|
|
|
|
|
|
|
44 |
848C8C90C1 |
Label, Recoil |
1 |
|
|
|
|
|
|
|
45 |
2881-98611 |
Snow protector |
1 |
OP |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
G5200
Fig.3 HANDLE
