Echo Distance Measurement Radio User’s Guide

ISSUE 2.00

Echo Distance Measurement Radio

User’s Guide

MULTISPECTRAL SOLUTIONS, INC.

1 of 10

Echo Distance Measurement Radio User’s Guide

ISSUE 2.00

NOTE: The Echo Distance Measurement Radio (DMR) unit has been tested to comply
with FCC Part 15, Subpart C for wideband pulse emitter devices. Changes or
modifications to the radiating elements of Echo DMR not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.

NOTE: The Echo DMR is certified under the FCC Part 15.250 rule which restricts
certain applications and use. Operation on board an aircraft or a satellite is prohibited.
The Echo DMR may not be employed for the operation of toys. The use of Echo DMR
on a fixed outdoor infrastructure is prohibited. A fixed infrastructure includes antennas
mounted on outdoor structures, e.g., antennas mounted on the outside of a building or
on a telephone pole.

NOTE: The Echo DMR is approved as a modular transmitter under FCC Part 15.212.
Therefore any equipment that installs the module must include an external label stating
that unit “Contains FCC ID: QCJECHO108”.

NOTE: The Echo DMR unit has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:

—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.

MULTISPECTRAL SOLUTIONS, INC.

2 of 10

Echo Distance Measurement Radio User’s Guide

ISSUE 2.00

CONTENTS

1 INTRODUCTION ......................................................................................6

2 HARDWARE CONNECTIONS..................................................................7

2.1 ANTENNA JACK............................................................................8

2.2 POWER CONNECTOR..................................................................8

2.3 RS232 CONNECTOR....................................................................9

2.4 USB CONNECTOR........................................................................9

2.5 BAUD RATE......................ERROR! BOOKMARK NOT DEFINED.

3 RS232 INTERFACE................................................................................10

3.1 CONFIGURATION.......................................................................10

3.2 SERIAL PORT COMMUNICATION PROTOCOL...............ERROR!

BOOKMARK NOT DEFINED.

3.2.1 GENERAL NOTES.ERROR! BOOKMARK NOT DEFINED.

MULTISPECTRAL SOLUTIONS, INC. PROPRIETARY AND CONFIDENTIAL

3 of 10
