TC70x/TC75x
Touch Computer
Integrator Guide
for Android ™ 8.1 Oreo
MN-003375-03
Copyright
ZEBRA and the stylized Zebra head are trademarks of Zebra Technologies Corporation, registered in many
jurisdictions worldwide. Google, Android, Google Play and other marks are trademarks of Google LLC; Oreo is
a trademark of Mondelez International, Inc. group. All other trademarks are the property of their respective
owners. ©2019 Zebra Technologies Corporation and/or its affiliates. All rights reserved.
COPYRIGHTS & TRADEMARKS: For complete copyright and trademark information, go to www.zebra.com/
copyright.
WARRANTY: For complete warranty information, go to www.zebra.com/warranty
END USER LICENSE AGREEMENT: For complete EULA information, go to www.zebra.com/eula
Terms of Use
• Proprietary Statement
This manual contains proprietary information of Zebra Technologies Corporation and its subs
ebra Technologies”). It is intended solely for the information and use of parties operating and ma
(“Z
e equipment described herein. Such proprietary information may not be used, reproduced, or disclosed to
th
any other parties for any other purpose without the express, written permission of Zebra Technologies.
• Product Improvements
Continuous improvement of products is a policy of Zebra Technologies. All specifications and designs are
subject to change without notice.
• Liability Disclaimer
Zebra Technologies takes steps to ensure that its published Engineering specifications and manuals ar
cor
rect; however, errors do occur. Zebra Technologies reserves the right to correct any such errors and
disclaims liability resulting therefrom.
• Limitation of Liability
In no event shall Zebra Technologies or anyone else involved in the creation, production, or delivery of the
accompanying product (including hardware and software) be liable for any damages whatsoever (including
out limitation, consequential damages including loss of business profits, business interruption, or loss
with
business information)
Zebra Technologies has
the
exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion
apply to you.
not
.
.
idiaries
intaining
e
arising out of the use of, the results of use of, or inability to use such product, even
been advised of the possibility of such damages. Some jurisdictions do not allo
may
,
of
if
w
Revision History
Changes to the original guide are listed below:
Change Date Description
-01 Rev A 10/2018 Initial release.
-02 Rev A 12/2018 Add WWAN information.
-03 Rev A 7/2019 Add note warning against user modification of the device, particularly in the battery
well.
2
Table of Contents
Copyright ......................................................................................................................... 2
Terms of Use ..................................................................................................................2
Revision History ..............................................................................................................2
About This Guide........................................................................................................ 12
Introduction ................................................................................................................... 12
Documentation Set ....................................................................................................... 12
Configurations .............................................................................................................. 13
Software Versions ......................................................................................................... 13
Chapter Descriptions .................................................................................................... 14
Notational Conventions ................................................................................................. 14
Related Documents ...................................................................................................... 14
Service Information ....................................................................................................... 15
Provide Documentation Feedback ................................................................................ 15
Getting Started............................................................................................................ 16
Introduction ................................................................................................................... 16
Setup ............................................................................................................................. 16
Installing the SIM Card .......................................................................................... 16
Installing a microSD Card ...................................................................................... 17
Installing the Hand Strap and Battery .................................................................... 18
Installing the Battery .............................................................................................. 20
Charging the Battery ............................................................................................. 20
Charging Indicators ............................................................................................... 21
Replacing the Battery ............................................................................................ 21
Replacing the SIM Card ................................................................................................ 23
Replacing the microSD Card ........................................................................................ 26
Resetting the Device ..................................................................................................... 27
Performing a Soft Reset ........................................................................................ 27
Performing a Hard Reset ....................................................................................... 28
3
Table of Contents
Accessories................................................................................................................. 29
Introduction ................................................................................................................... 29
Accessories ...................................................................................................................29
2-Slot Charge Only Cradle ............................................................................................ 31
Setup ..................................................................................................................... 32
Charging the Device .............................................................................................. 33
Charging the Spare Battery ................................................................................... 33
Battery Charging ................................................................................................... 34
Main Battery Charging .................................................................................... 34
Spare Battery Charging .................................................................................. 34
Charging Temperature .......................................................................................... 35
2-Slot USB/Ethernet Cradle .......................................................................................... 35
Setup ..................................................................................................................... 36
Charging the Device .............................................................................................. 37
Charging the Spare Battery ................................................................................... 38
Battery Charging ................................................................................................... 38
Main Battery Charging .................................................................................... 38
Spare Battery Charging .................................................................................. 38
Charging Temperature .......................................................................................... 39
USB/Ethernet Communication .............................................................................. 39
Ethernet LED Indicators .................................................................................. 40
Ethernet Settings ............................................................................................ 40
Configuring Ethernet Proxy Settings ............................................................... 40
Configuring Ethernet Static IP Address .......................................................... 41
5-Slot Charge Only Cradle ............................................................................................ 42
Setup ..................................................................................................................... 43
Charging the Device .............................................................................................. 44
Battery Charging ................................................................................................... 45
Main Battery Charging .................................................................................... 45
Charging Temperature .......................................................................................... 45
Installing the Four Slot Battery Charger ................................................................ 46
Removing the 4-Slot Battery Charger ................................................................... 50
5-Slot Ethernet Cradle .................................................................................................. 50
Setup ..................................................................................................................... 52
Daisy-chaining Ethernet Cradles ........................................................................... 52
Ethernet Settings ............................................................................................ 53
Configuring Ethernet Proxy Settings ............................................................... 53
Configuring Ethernet Static IP Address .......................................................... 54
LED Indicators ....................................................................................................... 55
Charging the Device .............................................................................................. 56
Battery Charging ................................................................................................... 57
Main Battery Charging .................................................................................... 57
Spare Battery Charging .................................................................................. 57
4
Table of Contents
Charging Temperature .......................................................................................... 58
Establishing Ethernet Connection ......................................................................... 58
Installing the 4-Slot Battery Charger ..................................................................... 58
Removing the 4-Slot Battery Charger ................................................................... 63
4-Slot Battery Charger .................................................................................................. 63
Setup ..................................................................................................................... 64
Charging Spare Batteries ...................................................................................... 64
Battery Charging ................................................................................................... 65
Spare Battery Charging .................................................................................. 65
Charging Temperature .......................................................................................... 65
Trigger Handle .............................................................................................................. 66
Installing the Attachment Plate to Trigger Handle ................................................. 66
Installing the Trigger Handle Plate ........................................................................ 66
Inserting the Device into the Trigger Handle ......................................................... 68
Removing the Device from the Trigger Handle ..................................................... 70
Hand Strap Replacement .............................................................................................. 71
Settings........................................................................................................................ 75
Introduction ................................................................................................................... 75
WWAN Configuration .................................................................................................... 75
Default SIM Slot Configuration .............................................................................. 75
WLAN Configuration ..................................................................................................... 76
Configuring a Secure Wi-Fi Network ............................................................................. 76
Manually Adding a Wi-Fi Network ......................................................................... 78
Configuring for a Proxy Server .............................................................................. 79
Configuring the Device to Use a Static IP Address ............................................... 80
Wi-Fi Preferences .................................................................................................. 81
Additional Wi-Fi Settings ....................................................................................... 82
Wi-Fi Direct ............................................................................................................ 82
WPS Push Button .................................................................................................. 83
WPS Pin Entry ....................................................................................................... 84
Setting Screen Lock .............................................................................................. 84
Setting Screen Lock Using PIN ............................................................................. 85
Setting Screen Unlock Using Password ................................................................ 86
Setting Screen Unlock Using Pattern .................................................................... 86
Showing Passwords .............................................................................................. 87
Remapping a Button ..................................................................................................... 87
Accounts ....................................................................................................................... 88
Language Usage ........................................................................................................... 88
Changing the Language Setting ............................................................................ 88
Adding Words to the Dictionary ............................................................................. 88
5
Table of Contents
Keyboard Settings ......................................................................................................... 89
PTT Express Configuration ........................................................................................... 89
RxLogger ......................................................................................................................89
RxLogger Configuration ........................................................................................ 89
RxLogger Settings .......................................................................................... 90
ANR Module .......................................................................................................... 90
Kernel Module ................................................................................................. 90
Logcat Module ................................................................................................ 91
LTS Module ..................................................................................................... 92
Qxdm Module .................................................................................................. 92
Ramoops Module ............................................................................................ 93
Resource Module ............................................................................................ 93
Snapshot Module ............................................................................................ 93
TCPDump Module .......................................................................................... 94
Tombstone Module ......................................................................................... 94
Configuration File ............................................................................................ 94
Enabling Logging ................................................................................................... 94
Disabling Logging .................................................................................................. 95
Extracting Log Files ............................................................................................... 95
RxLogger Utility ............................................................................................................. 95
App View ............................................................................................................... 95
Backup ............................................................................................................ 96
Archive Data .......................................................................................................... 96
Overlay View ......................................................................................................... 96
Initiating the Main Chat Head .......................................................................... 97
Removing the Main Chat Head ....................................................................... 97
Viewing Logs ................................................................................................... 97
Removing a Sub Chat Head Icon ................................................................... 98
Backing Up In Overlay View ........................................................................... 98
About Phone ................................................................................................... 98
USB Communication ................................................................................................ 100
Introduction ................................................................................................................. 100
Transferring Files with a Host Computer via USB ...................................................... 100
Transferring Files ................................................................................................ 100
Transferring Photos ............................................................................................. 101
Disconnect from the Host Computer ................................................................... 101
DataWedge ................................................................................................................ 102
Introduction ................................................................................................................. 102
Basic Scanning ........................................................................................................... 102
Barcode Capture with Imager ..................................................................................... 102
6
Table of Contents
Profiles ........................................................................................................................ 103
Profile0 ................................................................................................................ 104
Plug-ins ....................................................................................................................... 104
Input Plug-ins ...................................................................................................... 104
Process Plug-ins ................................................................................................. 104
Output Plug-ins .................................................................................................... 104
Profiles Screen .................................................................................................... 105
Profile Context Menu ........................................................................................... 106
Options Menu ...................................................................................................... 106
Disabling DataWedge .......................................................................................... 106
Creating a New Profile ................................................................................................ 106
Profile Configuration ................................................................................................... 107
Associating Applications ...................................................................................... 108
Data Capture Plus ............................................................................................... 110
Barcode Input ...................................................................................................... 111
Enabled ......................................................................................................... 112
Scanner Selection ....................................................................................................... 112
Auto Switch to Default on Event ................................................................... 112
Configure Scanner Settings .......................................................................... 112
Decoders ....................................................................................................... 113
Decoder Params ................................................................................................. 115
Codabar ........................................................................................................ 115
Reader Params ............................................................................................. 123
Scan Params ................................................................................................ 125
UDI Params .................................................................................................. 126
Multibarcode params .................................................................................... 127
Keep enabled on suspend ............................................................................ 127
SimulScan Input ............................................................................................ 127
Voice Input .......................................................................................................... 128
Keystroke Output ................................................................................................. 129
Intent Output ........................................................................................................ 130
Intent Overview ............................................................................................. 131
IP Output ............................................................................................................. 132
Usage ............................................................................................................ 133
Using IP Output with IPWedge ..................................................................... 133
Using IP Output without IPWedge ................................................................ 134
Generating Advanced Data Formatting Rules ............................................................ 136
Configuring ADF Plug-in ...................................................................................... 136
Creating a Rule ............................................................................................. 136
Defining a Rule ............................................................................................. 137
Defining Criteria ............................................................................................ 138
Defining an Action ......................................................................................... 139
Deleting a Rule ............................................................................................. 139
Order Rules List ............................................................................................ 140
7
Table of Contents
Deleting an Action ......................................................................................... 141
ADF Example ...................................................................................................... 141
DataWedge Settings ................................................................................................... 144
Importing a Configuration File ............................................................................. 145
Exporting a Configuration File ............................................................................. 145
Importing a Profile File ........................................................................................ 145
Exporting a Profile ............................................................................................... 146
Restoring DataWedge ......................................................................................... 146
Configuration and Profile File Management ................................................................ 146
Enterprise Folder .......................................................................................... 146
Auto Import .......................................................................................................... 147
Programming Notes .................................................................................................... 147
Overriding Trigger Key in an Application ............................................................. 147
Capture Data and Taking a Photo in the Same Application ................................ 147
Disable DataWedge on Device ........................................................................... 147
DataWedge APIs ................................................................................................. 148
Reporting ............................................................................................................. 148
Soft Scan Trigger ................................................................................................ 148
Parameters ................................................................................................... 148
Function Prototype .............................................................................................. 149
Scanner Input Plugin ........................................................................................... 149
Function Prototype ........................................................................................ 149
Parameters ................................................................................................... 149
Return Values ............................................................................................... 149
Example ........................................................................................................ 150
Comments ..................................................................................................... 150
Enumerate Scanners ........................................................................................... 150
Function Prototype ........................................................................................ 150
Parameters ................................................................................................... 151
Return Values ............................................................................................... 151
Example ........................................................................................................ 152
Comments ..................................................................................................... 152
Set Default Profile ............................................................................................... 153
Default Profile Recap .................................................................................... 153
Usage Scenario ............................................................................................ 153
Function Prototype ........................................................................................ 153
Parameters ................................................................................................... 153
Return Values ............................................................................................... 153
Example ........................................................................................................ 154
Comments ..................................................................................................... 154
Reset Default Profile ........................................................................................... 154
Function Prototype ........................................................................................ 155
Parameters ................................................................................................... 155
Return Values ............................................................................................... 155
8
Table of Contents
Example ........................................................................................................ 155
Comments ..................................................................................................... 155
Switch To Profile ........................................................................................... 155
Profiles Recap ............................................................................................... 156
Usage Scenario ................................................................................................... 156
Function Prototype ........................................................................................ 156
Parameters ................................................................................................... 156
Return Values ............................................................................................... 157
Example ........................................................................................................ 157
Comments ..................................................................................................... 157
Notes ............................................................................................................. 158
Application Deployment........................................................................................... 159
Introduction ................................................................................................................. 159
Security ....................................................................................................................... 159
Secure Certificates ...................................................................................................... 159
Installing a Secure Certificate ..................................................................................... 159
Configuring Credential Storage Settings ............................................................. 160
Development Tools ..................................................................................................... 160
Android Application Development ....................................................................... 160
Development Workstation ............................................................................. 160
Target Device ................................................................................................ 161
EMDK for Android ............................................................................................... 161
StageNow ............................................................................................................ 161
ADB USB Setup .......................................................................................................... 161
Enabling USB Debugging ........................................................................................... 162
Application Installation ................................................................................................ 162
Installing Applications Using the USB Connection .............................................. 162
Installing Applications Using the Android Debug Bridge ..................................... 164
Installing Applications Using a microSD Card ..................................................... 165
Uninstalling an Application .................................................................................. 166
Performing a System Update ...................................................................................... 167
Downloading the System Update Package ......................................................... 167
Using microSD Card ............................................................................................ 167
Using ADB ........................................................................................................... 168
Verify System Update Installation ....................................................................... 169
Performing an Enterprise Reset .......................................................................... 170
Downloading the Enterprise Reset Package ....................................................... 170
Using microSD Card ............................................................................................ 170
Using ADB ........................................................................................................... 170
Performing a Factory Reset ........................................................................................ 171
Downloading the Factory Reset Package ........................................................... 171
9
Table of Contents
Using microSD Card ............................................................................................ 172
Using ADB .................................................................................................................. 172
Storage .......................................................................................................................173
Random Access Memory .................................................................................... 173
Internal Storage ................................................................................................... 174
External Storage .................................................................................................. 175
Formatting a microSD Card or USB Drive as Portable Storage ................... 176
Formatting a microSD Card as Internal Memory .......................................... 178
Enterprise Folder ................................................................................................. 179
App Management ................................................................................................ 179
Viewing App Details ............................................................................................ 180
Managing Downloads ................................................................................................. 180
Technical Specifications.......................................................................................... 182
Introduction ................................................................................................................. 182
TC70x/TC75x .............................................................................................................. 182
SE4750-SR Decode Distances ........................................................................... 185
I/O Connector Pin-Outs ....................................................................................... 185
2-Slot Charge Only Cradle Technical Specifications ........................................... 186
2-Slot USB/Ethernet Cradle Technical Specifications ......................................... 187
5-Slot Charge Only Cradle Technical Specifications ........................................... 187
5-Slot Ethernet Cradle Technical Specifications ................................................. 188
4-Slot Battery Charger Technical Specifications ................................................. 188
Charge Only Vehicle Cradle Technical Specifications ........................................ 189
Trigger Handle Technical Specifications ............................................................. 189
Charging Cable Cup Technical Specifications .................................................... 190
Snap-On USB Cable Technical Specifications .................................................... 190
Snap-On Serial Cable Technical Specifications .................................................. 190
DEX Cable Technical Specifications ................................................................... 191
Maintenance and Troubleshooting ......................................................................... 192
Introduction ................................................................................................................. 192
Maintaining the Device ................................................................................................ 192
Battery Safety Guidelines ........................................................................................... 192
Cleaning Instructions .................................................................................................. 193
Approved Cleanser Active Ingredients ........................................................................ 193
Harmful Ingredients ............................................................................................. 193
Device Cleaning Instructions ............................................................................... 194
Special Cleaning Notes ....................................................................................... 194
Cleaning Materials Required ............................................................................... 194
10
Table of Contents
Cleaning Frequency ............................................................................................ 194
Cleaning the Device ............................................................................................ 194
Housing ......................................................................................................... 194
Display .......................................................................................................... 195
Camera and Exit Window ............................................................................. 195
Cleaning Battery Connectors .............................................................................. 195
Cleaning Cradle Connectors ............................................................................... 195
Troubleshooting ................................................................................................... 196
TC70x/TC75x ...................................................................................................... 196
2-Slot Charge Only Cradle .................................................................................. 198
2-Slot USB/Ethernet Cradle ................................................................................ 199
5-Slot Charge Only Cradle Troubleshooting ....................................................... 200
5-Slot Ethernet Cradle Troubleshooting .............................................................. 201
4-Slot Battery Charger Troubleshooting .............................................................. 201
Index........................................................................................................................... 203
11
About This Guide
Introduction
This guide provides information about using the TC70x and TC75x touch computers and accessories.
NOTE: Screens and windows pictured in this guide are samples and can differ from actual screens.
Documentation Set
The documentation set provides information for specific user needs, and includes:
• TC70x/TC75x Quick Start Guide for Android Version 6.0.1 - describes how to get the device up and
running.
• TC70x/TC75x User Guide for Android Version 8.1 - describes how to use the device.
• TC70x/TC75x Integrator Guide for Android Version 8.1 - describes how to set up the device and
accessories.
12
Configurations
This guide covers the following configurations:
About This Guide
Configuration Radios Display Memory
TC700K WLAN: 802.11
a/b/g/n/d/h/i/r
WPAN:
Bluetooth v4.0
Low Energy
TC75EK WWAN:
HSPA+/LTE/
CDMA
WLAN: 802.11
a/b/g/n/d/h/i/r
WPAN:
Bluetooth v4.0
Low Energy
TC75FK WWAN:
HSPA+/LTE
WLAN: 802.11
a/b/g/n/d/h/i/r
WPAN:
Bluetooth v4.0
Low Energy
4.7” High
Definition (1280
x 720) LCD
4.7” High
Definition (1280
x 720) LCD
4.7” High
Definition (1280
x 720) LCD
2 GB RAM/16
GB Flash
2 GB RAM/16
GB Flash (SLC
High Reliability
Flash)
2 GB RAM/16
GB Flash (SLC
High Reliability
Flash)
Data Capture
Options
2D imager,
camera, or
integrated NFC
2D imager,
camera, or
integrated NFC
2D imager,
camera and
integrated NFC
Operating
System
Android 8.1
Android 8.1
Android 8.1
TC75GK WWAN:
Software Versions
To determine the current software versions:
1. Swipe down from the Status bar to open the Quick Settings bar.
2. Touch > System.
3. Touch About phone.
4. Scroll to view the following information:
•Model
• Android version
•Kernel version
• Build number.
HSPA+/LTE
WLAN: 802.11
a/b/g/n/d/h/i/r
WPAN:
Bluetooth v4.0
Low Energy
4.7” High
Definition (1280
x 720) LCD
2 GB RAM/16
GB Flash (SLC
High Reliability
Flash)
2D imager,
camera and
integrated NFC
Android 8.1
13
To determine the device serial number, touch About phone > Status.
• Serial number
Chapter Descriptions
Topics covered in this guide are as follows:
• Getting Started provides information on getting the device up and running for the first time.
• Accessories describes the available accessories and how to use them with the device.
• USB Communication describes how to connect the device to a host computer using USB.
• DataWedge describes how to use and configure the DataWedge application.
• Settings provides the settings for configuring the device.
• Application Deployment provides information for developing and managing applications.
• Maintenance and Troubleshooting includes instructions on cleaning and storing the device, and provides
troubleshooting solutions for potential problems during device operation.
• Technical Specifications provides the technical specifications for the device.
About This Guide
Notational Conventions
The following conventions are used in this document:
• Bold text is used to highlight the following:
• Dialog box, window and screen names
• Drop-down list and list box names
• Check box and radio button names
• Icons on a screen
• Key names on a keypad
• Button names on a screen.
• Bullets (•) indicate:
• Action items
• Lists of alternatives
• Lists of required steps that are not necessarily sequential.
• Sequential lists (for example, those that describe step-by-step procedures) appear as numbered lists.
Related Documents
• TC70x/TC75x Quick Start Guide for Android Version 6.0.1, p/n MN-002879-xx.
• TC70x Regulatory Guide, p/n MN-002960-xx.
• TC75x Regulatory Guide, p/n MN-002880-xx.
• TC70x/TC75x User Guide for Android Version 8.1, p/n MN-002881-xx.
For the latest version of this guide and all guides, go to: www.zebra.com/support
14
Service Information
If you have a problem with your equipment, contact Customer Support for your region. Contact information is
available at: www.zebra.com/support
When contacting support, please have the following information available:
• Serial number of the unit (found on manufacturing label)
• Model number or product name (found on manufacturing label)
• Software type and version number
• IMEI number.
Customer Support responds to calls by email or telephone within the time limits set forth in support
agreements.
If the problem cannot be solved by Customer Support, you may need to return the equipment for servicing and
will be given specific directions. We are not responsible for any damages incurred during shipment if the
approved shipping container is not used. Shipping the units improperly can possibly void the warranty.
Remove the SIM card and/or microSD card from the device before shipping for service.
If the device was purchased from a business partner, contact that business partner for support.
About This Guide
.
Provide Documentation Feedback
If you have comments, questions, or suggestions about this guide, send an email to
EVM-Techdocs@zebra.com
.
15
Getting Started
Introduction
This chapter provides information for getting the device up and running for the first time.
Setup
Perform this procedure to start using the device for the first time.
• Install a SIM card (TC75x only).
• Install a micro secure digital (SD) card (optional).
• Install hand strap (optional).
• Install the battery.
• Charge the device.
• Power on the device.
Installing the SIM Card
NOTE: TC75x only.
NOTE: The TC75x may contain one mini SIM slot and two nano SIM slots. If using a micro SIM card, a third-party
SIM adapter is required. By default, use a nano SIM card in slot 1.
CAUTION: Follow proper electrostatic discharge (ESD) precautions to avoid damaging the SIM card. Proper ESD
precautions include, but not limited to, working on an ESD mat and ensuring that the user is properly grounded.
16
Getting Started
nano SIM Slot 2
nano SIM Slot 1
(default)
mini SIM
Slot
1. Remove access cover.
Figure 1 TC75x SIM Slot Locations
2. Insert a SIM card into the SIM slot with the cut edge toward the middle of the device and the contacts facing
down.
Figure 2 nano SIM Card Installation
Figure 3 Mini SIM Card Installation
3. Ensure that the SIM card is seated properly.
Installing a microSD Card
The microSD card slot provides secondary non-volatile storage. The slot is located under the battery pack.
Refer to the documentation provided with the card for more information, and follow the manufacturer’s
recommendations for use.
CAUTION: Follow proper electrostatic discharge (ESD) precautions to avoid damaging the microSD card. Proper ESD pre-
cautions include, but are not limited to, working on an ESD mat and ensuring that the operator is properly grounded.
17
Getting Started
1. Remove the hand strap, if installed.
2. Lift the access door.
Figure 4 Lift Access Door
3. Insert the microSD card into the card holder door ensuring that the card slides into the holding tabs on each
side of the door.
Figure 5 Insert microSD Card in Holder
4. Re-install the access door.
Installing the Hand Strap and Battery
NOTE: User modification of the device, particularly in the battery well, such as labels, asset tags, engravings, stickers, etc.,
may compromise the intended performance of the device or accessories. Performance levels such as sealing (Ingress Protection (IP)), impact performance (drop and tumble), functionality, temperature resistance, etc. could be effected. DO NOT
put any labels, asset tags, engravings, stickers, etc. in the battery well.
NOTE: Installation of the hand strap is optional. Skip this section if not installing the hand strap.
1. Remove the hand strap filler from the hand strap slot. Store the hand strap filler in a safe place for future
replacement.
Figure 6 Remove Filler
18
Getting Started
2. Insert the hand strap plate into the hand strap slot.
Figure 7 Insert Hand Strap
3. Insert the battery, bottom first, into the battery compartment in the back of the device.
Figure 8 Insert Bottom of Battery into Battery Compartment
4. Press the battery down into the battery compartment until the battery release latches snap into place.
Figure 9 Press Down on Battery
19
5. Place hand strap clip into hand strap mounting slot and pull down until it snaps into place.
Figure 10 Secure Hand Strap Clip
Installing the Battery
NOTE: User modification of the device, particularly in the battery well, such as labels, asset tags, engravings, stickers, etc.,
may compromise the intended performance of the device or accessories. Performance levels such as sealing (Ingress Protection (IP)), impact performance (drop and tumble), functionality, temperature resistance, etc. could be effected. DO NOT
put any labels, asset tags, engravings, stickers, etc. in the battery well.
1. Insert the battery, bottom first, into the battery compartment in the back of the device.
Getting Started
Figure 11 Insert Bottom of Battery into Battery Compartment
2. Press the battery down into the battery compartment until the battery release latches snap into place.
Figure 12 Press Down on Battery
Charging the Battery
Before using the device for the first time, charge the main battery until the green Charging/Notification light
emitting diode (LED) remains lit. To charge the device, use a cable or a cradle with the appropriate power
supply. For information about the accessories available for the device, see Accessories for more information.
The 4,620 mAh battery fully charges in less than five hours at room temperature.
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). The device or accessory always performs
battery charging in a safe and intelligent manner. At higher temperatures (approximately +37°C (+98°F)) the
device or accessory may, for small periods of time, alternately enable and disable battery charging to keep the
20
battery at acceptable temperatures. The device or accessory indicates when charging is disabled due to
abnormal temperatures via its LED.
To charge the main battery:
1. Connect the charging accessory to the appropriate power source.
2. Insert the device into a cradle or attach to a cable. The device turns on and begins charging. The
Charging/Notification LED blinks amber while charging, then turns solid green when fully charged.
Charging Indicators
Table 1 Charging/Notification LED Charging Indicators
State Indication
Off The device is not charging. The device is not inserted correctly in
Slow Blinking Amber (1 blink every 4
seconds)
Solid Green Charging complete.
Getting Started
the cradle or connected to a power source. Charger/cradle is not
powered.
The device is charging.
Fast Blinking Amber (2 blinks/second) Charging error:
Slow Blinking Red (1 blink every 4
seconds)
Solid Red Charging complete but the battery is at end of useful life.
Fast Blinking Red (2 blinks/second) Charging error but the battery is at end of useful life.
Replacing the Battery
NOTE: User modification of the device, particularly in the battery well, such as labels, asset tags, engravings, stickers, etc.,
may compromise the intended performance of the device or accessories. Performance levels such as sealing (Ingress Protection (IP)), impact performance (drop and tumble), functionality, temperature resistance, etc. could be effected. DO NOT
put any labels, asset tags, engravings, stickers, etc. in the battery well.
CAUTION: Do not add or remove SIM or microSD card during battery replacement.
• Temperature is too low or too high.
• Charging has gone on too long without completion (typically
eight hours).
The device is charging but the battery is at end of useful life.
• Temperature is too low or too high.
• Charging has gone on too long without completion (typically
eight hours).
1. Remove any accessory attached to the device.
2. Press the Power button until the menu appears.
3. Touch Battery Swap.
4. Follow the on-screen instructions.
21
Getting Started
5. Wait for the LED to turn off.
6. If hand strap is attached, slide the hand strap clip up toward the top of the device and then lift.
Figure 13 Remove Hand Strap Clip
7. Press the two battery latches in.
Figure 14 Press Battery Latches
22
8. Lift the battery from the device.
Figure 15 Lift the Battery
Getting Started
CAUTION: Replace the battery within two minutes. After two minutes the device reboots and data may be lost.
9. Insert the replacement battery, bottom first, into the battery compartment in the back of the device.
10.Press the battery down until the battery release latch snaps into place.
11.Replace the hand strap, if required.
12.Press and hold the Power button to turn on the device.
NOTE: After replacing the battery, wait 15 minutes before using Battery Swap again.
Replacing the SIM Card
NOTE: SIM replacement applies to TC75x only.
To replace the SIM card:
1. Press and hold the Power button until the menu appears.
2. Touch Power off.
3. Touch OK.
23
Getting Started
4. If hand strap is attached, slide the hand strap clip up toward the top of the device and then lift.
Figure 16 Remove Hand Strap Clip
5. Press the two battery latches in.
6. Lift the battery from the device.
7. Lift the access door.
Figure 17 Remove Access Door
24
8. Remove card from holder.
Figure 18 Remove Mini SIM Card
Figure 19 Remove Nano SIM Card
Getting Started
9. Insert the replacement card.
Figure 20 Insert Mini SIM Card
Figure 21 Insert Nano SIM Card
25
Getting Started
10.Replace the access door.
Figure 22 Replace Access Door
11.Press the access door down and ensure that it is properly seated.
12.Insert the battery, bottom first, into the battery compartment in the back of the device.
13.Press the battery down until the battery release latch snaps into place.
14.Replace the hand strap, if required.
15.Press and hold the Power button to turn on the device.
Replacing the microSD Card
To replace the microSD card:
1. Press the Power button until the menu appears.
2. Touch Power off.
3. Touch OK.
4. If hand strap is attached, slide the hand strap clip up toward the top of the device and then lift.
Figure 23 Remove Hand Strap Clip
5. Press the two battery latches in.
6. Lift the battery from the device.
26
Getting Started
7. Lift the access door.
Figure 24 Remove Access Door
8. Remove microSD card from holder.
9. Press the access door down and ensure that it is properly seated.
10.Insert the replacement microSD card.
11.Replace the access door.
Figure 25 Replace Access Door
12.Insert the battery, bottom first, into the battery compartment in the back of the device.
13.Press the battery down until the battery release latch snaps into place.
14.Replace the hand strap, if required.
15.Press and hold the Power button to turn on the device.
Resetting the Device
The reset functions include the following:
• Soft reset
• Hard reset
• Enterprise reset
• Factory reset
Performing a Soft Reset
Perform a soft reset if applications stop working.
1. Press and hold the Power button until the menu appears.
2. Touch Restart.
The device reboots.
27
Performing a Hard Reset
CAUTION: Performing a hard reset with a microSD card installed in the device may cause damage or data corruption to the
microSD card. All un-saved data is lost after performing a hard reset.
Perform a hard reset if the device stops responding.
1. Simultaneously press the Power, Scan and Volume Up buttons for at least four seconds.
2. When the screen turns off, release the buttons.
The device reboots.
Getting Started
28
Accessories
Introduction
This chapter provides information for using the accessories for the device.
Accessories
This table lists the accessories available for the device.
Table 2 Accessories
Accessory Part Number Description
Cradles
2-Slot Charge Only
Cradle
CRD-TC7X-SE2CPP-01 Provides device and spare battery charging. Use with
power supply, p/n PWRS-14000-148R.
2-Slot USB/Ethernet
Cradle
5-Slot Charge Only
Cradle
5-Slot Ethernet Cradle CRD-TC7X-SE5EU1–01 Provides device charging and provides Ethernet
Cradle Mount BRKT-SCRD-SMRK-01 Mounts the 5-Slot Charge Only Cradle, 5-Slot Ethernet
Batteries and Chargers
4,620 mAh
PowerPrecision+ battery
4-Slot Spare Battery
Charger
CRD-TC7X-SE2EPP-01 Provides device and spare battery charging and USB
communication with a host computer and Ethernet
communication with a network. Use with power supply,
p/n PWRS-14000-148R.
CRD-TC7X-SE5C1-01 Charges up to five devices. Use with power supply, p/n
PWRS-14000-241R and DC line cord, p/n
50-16002-029R. Can accommodate one 4-Slot Battery
Charger using the Battery Adapter Cup.
communication for up to five devices. Use with power
supply, p/n PWRS-14000-241R and DC line cord, p/n
50-16002-029R. Can accommodate one 4-Slot Battery
Charger using the Battery Adapter Cup.
Cradle, and 4-Slot Battery Charger to a wall or rack.
BTRY-TC7X-46MPP-01
BTRY-TC7X-46MPP-10
SAC-TC7X-4BTYPP-01 Charges up to four battery packs. Use with power
Replacement battery (single pack).
Replacement battery (10–pack).
supply, p/n PWRS-14000-148R.
29
Accessories
Table 2 Accessories (Continued)
Accessory Part Number Description
Battery Charger Adapter
Cup
Vehicle Solutions
Charging Cable Cup CHG-TC7X-CLA1-01 Provides power to the device from a cigarette lighter
CUP-SE-BTYADP1-01 Allows for one 4-Slot Battery Charger to be charged
and docked on the left most slot of the 5-Slot cradles
(maximum one per cradle).
socket.
Charge Only Vehicle
Cradle
Cigarette Light Adapter
Auto Charge Cable
Hard-wire Auto Charge
Cable
RAM Mount RAM-B-166U Provides window mounting option for the Vehicle
RAM Mount Base RAM-B-238U RAM 2.43" x 1.31" Diamond Ball base with 1" ball.
Charge and Communication Cables
Charging Cable Cup CHG-TC7X-CBL1-01 Provides power to the device. Use with power supply,
Snap-On USB Cable CBL-TC7X-CBL1-01 Provides power to the device and USB communication
Snap-On Serial Cable CBL-TC7X-SERL1-01 Provides power and serial communication with a host
Snap-On DEX Cable CBL-TC7X-DEX1-01 Provides electronic data exchange with devices such
Audio Accessories
Premium Headset RCH51 Premium Rugged headset.
CRD-TC7X-CVCD1-01 Charges and securely holds the device. Requires
power cable CHG-AUTO-CLA1-01 or
CHG-AUTOHWIRE1-01, sold separately.
CHG-AUTO-CLA1-01 Provides power to the Vehicle Cradle from a cigarette
lighter socket.
CHG-AUTO-HWIRE1-01 Provides power to the Vehicle Cradle from the
vehicle's power panel.
Cradle. RAM Twist Lock Suction Cup with Double
Socket Arm and Diamond Base Adapter. Overall
Length: 6.75”.
p/n PWRS-14000-249R, sold separately.
with a host computer. Use with power supply, p/n
PWRS-14000-249R, sold separately.
computer. Use with power supply, p/n
PWRS-14000-249R, sold separately.
as vending machines.
3.5 mm Audio Adapter ADP-TC7X-AUD35-01 Snaps onto the device and provides audio to a wired
headset with 3.5 mm plug.
3.5 mm Headset HDST-35MM-PTVP-01 Use for PTT and VoIP calls.
3.5 mm Quick
Disconnect
Adapter Cable
Scanning
Trigger Handle TRG-TC7X-SNP1-01 Adds gun-style handle with a scanner trigger for
Carrying Solutions
Soft Holster SG-TC7X-HLSTR1-01 TC7X soft holster.
ADP-35M-QDCBL1-01 Provides connection to the 3.5 mm Headset.
comfortable and productive scanning.
30
Accessories
Spare battery Charging LED
Power LED
Table 2 Accessories (Continued)
Accessory Part Number Description
Rigid Holster SG-TC7X-RHLSTR1-01 TC7X rigid holster.
Hand Strap SG-TC7X-HSTRP1-03 Replacement hand strap with hand strap mounting clip
(3–pack).
Stylus and Coiled Tether SG-TC7X-STYLUS-03 TC7X stylus with coiled tether (3-pack).
Power Supplies
Power Supply PWRS-14000-249R Provides power to the device using the Snap-On USB
Cable, Snap-on Serial Cable or Charging Cable Cup.
Requires AC line cord.
Power Supply PWRS-14000-148R Provides power to the 2–Slot cradles and 4-Slot Spare
Battery Charger. Requires AC line cord.
Power Supply PWRS-14000-241R Provides power to the 5-Slot Charge Only cradle and
the 5-Slot Ethernet Cradle. Requires DC Line Cord, p/n
50–16002–029R and country specific three wire
grounded AC line cord sold separately.
DC Line Cord 50-16002-029R Provides power from the power supply to the 5-Slot
Charge Only Cradle and 5-Slot Ethernet Cradle.
2-Slot Charge Only Cradle
The 2-Slot Charge Only Cradle:
• Provides 5 VDC power for operating the device.
• Charges the device’s battery.
• Charges a spare battery.
Figure 26 2–Slot Charge Only Cradle
31
Setup
Accessories
Figure 27 2–Slot Charge Only Cradle
32
Charging the Device
1. Insert the device into the slot to begin charging.
Figure 28 Battery Charging
Accessories
2. Ensure the device is seated properly.
Charging the Spare Battery
1. Insert the battery into the right slot to begin charging.
33
Figure 29 Spare Battery Charging
2. Ensure the battery is seated properly.
Accessories
Battery Charging
Main Battery Charging
The device’s Charging/Notification LED indicates the status of the battery charging in the device.
The 4,620 mAh battery fully charges in less than five hours at room temperature.
Spare Battery Charging
The Spare battery Charging LED on the cup indicates the status of the spare battery charging.
The 4,620 mAh battery fully charges in less than five hours at room temperature.
Table 3 Spare Battery Charging LED Indicators
Slow Blinking Amber Spare battery is charging.
Solid Green Charging complete.
Fast Blinking Amber Error in charging; check placement of spare battery.
Slow Blinking Red Spare battery is charging and battery is at the end of
LED Indication
useful life.
Solid Red Charging complete and battery is at the end of useful
life.
Fast Blinking Red Error in charging; check placement of spare battery and
battery is at the end of useful life.
Off No spare battery in slot; spare battery not placed
correctly; cradle is not powered.
34
Charging Temperature
Spare Battery Charging LED
Power LED
Charge batteries in temperatures from 0 °C to 40 °C (32 °F to 104 °F). The device or cradle always performs
battery charging in a safe and intelligent manner. At higher temperatures (e.g. approximately +37 °C (+98 °F))
the device or cradle may for small periods of time alternately enable and disable battery charging to keep the
battery at acceptable temperatures. The device and cradle indicates when charging is disabled due to
abnormal temperatures via its LED.
2-Slot USB/Ethernet Cradle
The 2-Slot USB/Ethernet Cradle:
• Provides 5.0 VDC power for operating the device.
• Charges the device’s battery.
• Charges a spare battery.
• Connects the device to an Ethernet network.
• Provides communication to a host computer using a USB cable.
NOTE: Remove all attachments on the device, except the hand strap, before place onto the cradle.
Accessories
Figure 30 2-Slot USB/Ethernet Cradle
35
Setup
Accessories
Figure 31 2–Slot USB/Ethernet Cradle
36
Charging the Device
1. Place the bottom of the device into the base.
Figure 32 Battery Charging
Accessories
2. Rotate the top of the device until the connector on the back of the device mates with the connector on the
cradle.
3. Ensure the device is connected properly. The charging Charging/Notification LED on the device begins
blinking amber indicating that the device is charging.
37
Charging the Spare Battery
1. Insert the battery into the right slot to begin charging.
Figure 33 Spare Battery Charging
Accessories
2. Ensure the battery is seated properly.
Battery Charging
Main Battery Charging
The device’s Charging/Notification LED indicates the status of the battery charging in the device.
The 4,620 mAh battery fully charges in less than five hours at room temperature.
Spare Battery Charging
The Spare battery Charging LED on the cup indicates the status of the spare battery charging.
The 4,620 mAh battery fully charges in less than five hours at room temperature.
Table 4 Spare Battery Charging LED Indicators
Slow Blinking Amber Spare battery is charging.
Solid Green Charging complete.
Fast Blinking Amber Error in charging; check placement of spare battery.
Slow Blinking Red Spare battery is charging and battery is at the end of
LED Indication
useful life.
38
Table 4 Spare Battery Charging LED Indicators (Continued)
LED Indication
Solid Red Charging complete and battery is at the end of useful
Fast Blinking Red Error in charging; check placement of spare battery and
Off No spare battery in slot; spare battery not placed
Charging Temperature
Charge batteries in temperatures from 0 °C to 40 °C (32 °F to 104 °F). The device or cradle always performs
battery charging in a safe and intelligent manner. At higher temperatures (e.g. approximately +37 °C (+98 °F))
the device or cradle may for small periods of time alternately enable and disable battery charging to keep the
battery at acceptable temperatures. The device and cradle indicates when charging is disabled due to
abnormal temperatures via its LED.
USB/Ethernet Communication
Accessories
life.
battery is at the end of useful life.
correctly; cradle is not powered.
The 2–Slot USB/Ethernet Cradle provides both Ethernet communication with a network and USB
communication with a host computer. Prior to using the cradle for Ethernet or USB communication. Ensure that
the switch on the USB/Ethernet module is set properly.
Turn the cradle over to view the module.
Figure 34 2–Slot USB/Ethernet Cradle Module Switch
For Ethernet communication, slide the switch to the position.
For USB communication, slide the switch to the position.
Place the switch in the center position to disable communications.
39
Accessories
1
2
Ethernet LED Indicators
There are two LEDs on the USB/Ethernet Module RJ-45 connector. The green LED lights to indicate that the
transfer rate is 100 Mbps. When the LED is not lit the transfer rate is 10 Mbps. The yellow LED blinks to
indicate activity, or stays lit to indicate that a link is established. When it is not lit it indicates that there is no link.
Figure 35 LED Indicators
Table 5 USB/Ethernet Module LED Data Rate Indicators
Data Rate (1) Amber LED (2) Green LED
100 Mbps On/Blink On
10 Mbps On/Blink Off
Ethernet Settings
The following settings can be configured when using Ethernet communication:
• Proxy Settings
• Static IP.
Configuring Ethernet Proxy Settings
The device includes Ethernet cradle drivers. After inserting the device, configure the Ethernet connection:
1. Swipe down with two fingers from the status bar to open the quick access panel and then touch .
2. Touch Network & Internet.
3. Touch Ethernet.
4. Place the device into the Ethernet cradle slot.
5. Slide the switch to the ON position.
6. Touch and hold Eth0 until the menu appears.
7. Touch Modify Proxy.
40
Accessories
8. Touch the Proxy drop-down list and select Manual.
Figure 36 Ethernet Proxy Settings
9. In the Proxy hostname field, enter the proxy server address.
10.In the Proxy port field, enter the proxy server port number.
NOTE: When entering proxy addresses in the Bypass proxy for field, do not use spaces or carriage returns between ad-
dresses.
11.In the Bypass proxy for text box, enter addresses for web sites that do not require to go through the proxy
server. Use the separator “|” between addresses.
12.Touch MODIFY.
13.Touch .
Configuring Ethernet Static IP Address
The device includes Ethernet cradle drivers. After inserting the device, configure the Ethernet connection:
1. Swipe down with two fingers from the status bar to open the quick access panel and then touch .
2. Touch Network & Internet.
3. Touch Ethernet.
4. Place the device into the Ethernet cradle slot.
5. Slide the switch to the ON position.
6. Touch Eth0.
7. Touch Disconnect.
8. Touch Eth0.
41
Accessories
9. Touch and hold the IP settings drop-down list and select Static.
Figure 37 Static IP Settings
10.In the IP address field, enter the proxy server address.
11.If required, in the Gateway field, enter a gateway address for the device.
12.If required, in the Netmask field, enter the network mask address
13.If required, in the DNS address fields, enter a Domain Name System (DNS) addresses.
14.Touch CONNECT.
15.Touch .
5-Slot Charge Only Cradle
The 5-Slot Charge Only Cradle:
• Provides 5 VDC power for operating the device.
• Simultaneously charges up to five devices and up to four devices and on 4-Slot Battery Charger using the
Battery Charger Adapter. See the TC70x/TC75x Integrator Guide for information on installing the 4-Slot
Battery Charger onto the cradle.
42
Accessories
Power LED
• Consists of a cradle base and cups that can be configured for various charging requirements.
Figure 38 5-Slot Charge Only Cradle
Setup
Figure 39 5-Slot Charge Only Cradle
43
Charging the Device
1. Insert the device into a slot to begin charging.
Figure 40 Battery Charging
Accessories
Figure 41 5-Slot Charge Only Cradle with Four Slot Battery Charger
44
Accessories
2. Ensure the device is seated properly.
Battery Charging
Main Battery Charging
The device’s Charging/Notification LED indicates the status of the battery charging in the device.
The 4,620 mAh battery fully charges in less than five hours at room temperature.
Charging Temperature
Charge batteries in temperatures from 0 °C to 40 °C (32 °F to 104 °F). The device always performs battery
charging in a safe and intelligent manner. At higher temperatures (e.g. approximately +37 °C (+98 °F)) the
device may for small periods of time alternately enable and disable battery charging to keep the battery at
acceptable temperatures. The device indicates when charging is disabled due to abnormal temperatures via its
LED.
45
Accessories
Installing the Four Slot Battery Charger
NOTE: The Battery Charger must be installed in the first slot only.
1. Remove power from the cradle.
Figure 42 Remove Power from Cradle
2. Using a Phillips screwdriver, remove the screw securing the cup to the cradle base.
Figure 43 Remove Screw
46
3. Slide the cup to the front of the cradle.
Figure 44 Remove Cup
Accessories
4. Carefully lift the cup up to expose the cup power cable.
5. Disconnect the cup power cable.
Figure 45 Disconnect Cup Power Cable
NOTE: Place power cable into adapter to avoid pinching cable.
47
Accessories
6. Connect the Battery Adapter power cable to the connector on the cradle.
Figure 46 Connect Adapter Power Cable
7. Place adapter onto cradle base and slide toward rear of cradle.
Figure 47 Install Adapter
48
Accessories
8. Using a Phillips screwdriver, secure adapter to cradle base with screw.
Figure 48 Secure adapter to Cradle
9. Align mounting holes on the bottom of the Four Slot Battery Charger with the stubs on the Battery Adapter.
Figure 49 Install Four Slot Battery Charger
10.Slide the Four Slot battery Charger down toward the front of the cradle.
49
Accessories
11.Connect the output power plug into the power port on the Four Slot Battery Charger.
Figure 50 Connect Output Power Plug
Removing the 4-Slot Battery Charger
1. Disconnect the output power plug from the 4-Slot Battery Charger.
2. At the back of the cup, press down on the release latch.
Figure 51 Press Release Latch
3. Slide the 4-Slot Battery Charger toward the front of the cradle.
4. Lift the 4-Slot off the cradle cup.
5-Slot Ethernet Cradle
CAUTION: Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page 192.
50
Accessories
100/10 LED
1000 LED
The 5-Slot Ethernet Cradle:
• Provides 5.0 VDC power for operating the device.
• Connects the device (up to five) to an Ethernet network.
• Simultaneously charges up to five devices or up to four devices and one 4-Slot Battery Charger using the
Battery Charger Adapter.
Figure 52 5-Slot Ethernet Cradle
51
Setup
Accessories
Connect the 5-Slot Ethernet cradle to a power source.
Figure 53 5-Slot Ethernet Cradle Setup
Daisy-chaining Ethernet Cradles
Daisy-chain up to ten 5-Slot Ethernet cradles to connect several cradles to an Ethernet network. Use either a
straight or crossover cable. Daisy-chaining should not be attempted when the main Ethernet connection to the
first cradle is 10 Mbps as throughput issues will almost certainly result.
To daisy-chain 5-Slot Ethernet cradles:
1. Connect power to each 5-Slot Ethernet cradle.
2. Connect an Ethernet cable to the one of the ports on the back of the first cradle and to the Ethernet switch.
52
Accessories
To Switch To Power Supply
To Power SupplyTo Next
Cradle
3. Connect the other end of the Ethernet cable to one of the ports of the back of the second 5-Slot Ethernet
cradle.
Figure 54 Daisy-chaining 5-Slot Ethernet Cradles
4. Connect additional cradles as described in step 2 and 3.
Ethernet Settings
The following settings can be configured when using Ethernet communication:
• Proxy Settings
• Static IP.
Configuring Ethernet Proxy Settings
The device includes Ethernet cradle drivers. After inserting the device, configure the Ethernet connection:
1. Swipe down with two fingers from the status bar to open the quick access panel and then touch .
2. Touch Network & Internet.
3. Touch Ethernet.
4. Place the device into the Ethernet cradle slot.
5. Slide the switch to the ON position.
6. Touch and hold Eth0 until the menu appears.
7. Touch Modify Proxy.
53
Accessories
8. Touch the Proxy drop-down list and select Manual.
Figure 55 Ethernet Proxy Settings
9. In the Proxy hostname field, enter the proxy server address.
10.In the Proxy port field, enter the proxy server port number.
NOTE: When entering proxy addresses in the Bypass proxy for field, do not use spaces or carriage returns between ad-
dresses.
11.In the Bypass proxy for text box, enter addresses for web sites that do not require to go through the proxy
server. Use the separator “|” between addresses.
12.Touch MODIFY.
13.Touch .
Configuring Ethernet Static IP Address
The device includes Ethernet cradle drivers. After inserting the device, configure the Ethernet connection:
1. Swipe down with two fingers from the status bar to open the quick access panel and then touch .
2. Touch Network & Internet.
3. Touch Ethernet.
4. Place the device into the Ethernet cradle slot.
5. Slide the switch to the ON position.
6. Touch Eth0.
7. Touch Disconnect.
8. Touch Eth0.
54
Accessories
9. Touch and hold the IP settings drop-down list and select Static.
Figure 56 Static IP Settings
10.In the IP address field, enter the proxy server address.
11.If required, in the Gateway field, enter a gateway address for the device.
12.If required, in the Netmask field, enter the network mask address
13.If required, in the DNS address fields, enter a Domain Name System (DNS) addresses.
14.Touch CONNECT.
15.Touch .
LED Indicators
There are two green LEDs on the side of the cradle. These green LEDs light and blink to indicate the data
transfer rate.
Table 6 LED Data Rate Indicators
1 Gbps On/Blink Off
100 Mbps Off On/Blink
10 Mbps Off On/Blink
Data Rate 1000 LED 100/10 LED
55
Charging the Device
1. Insert the device into a slot to begin charging.
Figure 57 Battery Charging
Accessories
56
Accessories
2. Ensure the device is seated properly.
Figure 58 5-Slot Ethernet Cradle with 4-Slot Battery Charger
Battery Charging
Main Battery Charging
The device’s Charging/Notification LED indicates the status of the battery charging in the device.
The 4,620 mAh battery fully charges in less than sixfive hours at room temperature.
Spare Battery Charging
The Spare battery Charging LED on the cup indicates the status of the spare battery charging.
The 4,620 mAh battery fully charges in less than five hours at room temperature.
Table 7 Spare Battery Charging LED Indicators
Slow Blinking Amber Spare battery is charging.
Solid Green Charging complete.
Fast Blinking Amber Error in charging; check placement of spare battery.
Slow Blinking Red Spare battery is charging and battery is at the end of
LED Indication
useful life.
57
Table 7 Spare Battery Charging LED Indicators (Continued)
LED Indication
Solid Red Charging complete and battery is at the end of useful
Fast Blinking Red Error in charging; check placement of spare battery
Off No spare battery in slot; spare battery not placed
Charging Temperature
Charge batteries in temperatures from 0 °C to 40 °C (32 °F to 104 °F). The device or cradle always performs
battery charging in a safe and intelligent manner. At higher temperatures (e.g. approximately +37 °C (+98 °F))
the device or cradle may for small periods of time alternately enable and disable battery charging to keep the
battery at acceptable temperatures. The device and cradle indicates when charging is disabled due to
abnormal temperatures via its LED.
Establishing Ethernet Connection
Accessories
life.
and battery is at the end of useful life.
correctly; cradle is not powered.
1. Swipe down with two fingers from the status bar to open the quick access panel and then touch .
2. Touch Network & Internet.
3. Touch Ethernet.
4. Insert the device into a slot.
5. Slide the Ethernet switch to the ON position.
The icon appears in the Status bar.
6. Touch Eth0 to view Ethernet connection details.
Installing the 4-Slot Battery Charger
NOTE: The Battery Charger must be installed in the first slot only.
58
1. Remove power from the cradle.
Figure 59 Remove Power from Cradle
Accessories
2. Using a Phillips screwdriver, remove the screw securing the cup to the cradle base.
Figure 60 Remove Screw
59
3. Slide the cup to the front of the cradle.
Figure 61 Remove Cup
Accessories
4. Carefully lift the cup up to expose the cup power cable.
5. Disconnect the cup power cable and USB cable.
Figure 62 Disconnect Cup Cables
NOTE: Place power cable into adapter to avoid pinching cable.
60
Accessories
6. Connect the Battery Adapter power cable to the connector on the cradle.
Figure 63 Connect Adapter Power Cable
7. Place adapter onto cradle base and slide toward rear of cradle.
Figure 64 Install Adapter
61
Accessories
8. Using a Phillips screwdriver, secure adapter to cradle base with screw.
Figure 65 Secure adapter to Cradle
9. Align mounting holes on the bottom of the 4-Slot Battery Charger with the stubs on the Battery Adapter.
Figure 66 Install 4-Slot Battery Charger
62
Accessories
10.Slide the 4-Slot battery Charger down toward the front of the cradle.
11.Connect the output power plug into the power port on the 4-Slot Battery Charger.
Figure 67 Connect Adapter Power Cable
Removing the 4-Slot Battery Charger
1. Disconnect the output power plug from the 4-Slot Battery Charger.
2. At the back of the cup, press down on the release latch.
Figure 68 Press Release Latch
3. Slide the 4-Slot Battery Charger toward the front of the cradle.
4. Lift the 4-Slot off the cradle cup.
4-Slot Battery Charger
This section describes how to use the 4-Slot Battery Charger to charge up to four device batteries.
63
Setup
Battery
Battery Charge LED
Battery Slot
Accessories
Figure 69 Four Slot Battery Charger Power Setup
Charging Spare Batteries
1. Connect the charger to a power source.
2. Insert the battery into a battery charging well and gently press down on the battery to ensure proper
contact.
Figure 70 Four Slot Battery Charger
64
Battery Charging
Spare Battery Charging
Each Battery Charging LED indicates the status of the battery charging in each slot. The table below describes
the Battery Charging LED status.
The 4,620 mAh battery fully charges in less than five hours at room temperature.
Table 8 Battery LED Charging Indicators
LED Indication
Slow Blinking Amber Spare battery is charging.
Solid Green Charging complete.
Fast Blinking Amber Error in charging; check placement of spare battery.
Slow Blinking Red Spare battery is charging and battery is at the end of useful life.
Solid Red Charging complete and battery is at the end of useful life.
Fast Blinking Red Error in charging; check placement of spare battery and battery is at the
Accessories
end of useful life.
Off No spare battery in slot; spare battery not placed correctly; cradle is not
Charging Temperature
Charge batteries in temperatures from 0 °C to 40 °C (32 °F to 104 °F). The battery charger always performs
battery charging in a safe and intelligent manner. At higher temperatures (e.g. approximately +37 °C (+98 °F))
the battery charger may for small periods of time alternately enable and disable battery charging to keep the
battery at acceptable temperatures. The battery charger indicates when charging is disabled due to abnormal
temperatures via its LED.
powered.
65
Trigger Handle
Trigger
Attachment Plate with
Tether
Latch
Release Button
The Trigger Handle adds a gun-style handle with a scanning trigger to the device. It increases comfort when
using the device in scan-intensive applications for extended periods of time.
Figure 71 Trigger Handle
Accessories
Installing the Attachment Plate to Trigger Handle
To install the attachment plate to the Trigger Handle:
1. Insert the loop end of the tether into the slot on the bottom of the handle.
2. Feed the attachment plate through the loop.
Figure 72 Install Attachment Plate to Handle
3. Pull the attachment plate until the loop tightens on the tether.
Installing the Trigger Handle Plate
1. Press and hold the Power button until the menu appears.
2. Touch Power off.
66
Accessories
3. Touch OK.
4. Press in the two battery latches.
5. Lift the battery from the device.
6. Remove the hand strap filler plate from the hand strap slot. Store the hand strap filler plate in a safe place
for future replacement.
Figure 73 Remove Hand Strap Plate
7. Insert the attachment plate into the hand strap slot.
Figure 74 Insert Trigger Handle Plate
8. Insert the battery, bottom first, into the battery compartment in the back of the device.
9. Rotate the top of the battery into the battery compartment.
10.Press the battery down into the battery compartment until the battery release latches snap into place.
67
Accessories
Inserting the Device into the Trigger Handle
1. Align the back of the Trigger handle with the Trigger Mounting Plate.
Figure 75 Connect Device to Trigger Handle
2. Press the two release latches.
68
Accessories
3. Rotate the device down and press down until it snaps into place.
Figure 76 Rotate Device onto Trigger Handle
69
Accessories
Removing the Device from the Trigger Handle
1. Press both Trigger Handle release latches.
Figure 77 Press Release Latches
2. Rotate the device up and remove from the Trigger handle.
70
Accessories
3. Rotate the device down and press down until it snaps into place.
Figure 78 Rotate Device onto Trigger Handle
Hand Strap Replacement
CAUTION: Close all running applications prior to replacing the hand strap.
1. Press and hold the Power button until the menu appears.
2. Touch Power Off.
3. Touch OK.
4. Remove the hand strap clip from the hand strap mounting slot.
Figure 79 Remove Hand Strap Clip
71
5. Press the two battery latches in.
Figure 80 Press Battery Latches
Accessories
6. Lift the battery from the device.
Figure 81 Lift the Battery
7. Remove the battery.
72
Accessories
8. Remove the hand strap plate from the hand strap slot.
9. Insert the replacement hand strap plate into the hand strap slot.
Figure 82 Insert Hand Strap
10.Insert the battery, bottom first, into the battery compartment.
Figure 83 Insert Bottom of Battery into Battery Compartment
11.Rotate the top of the battery into the battery compartment.
12.Press the battery down into the battery compartment until the battery release latches snap into place.
Figure 84 Press Down on Battery
73
Accessories
13.Place hand strap clip into hand strap mounting slot and pull down until it snaps into place.
Figure 85 Secure Hand Strap Clip
74
Settings
nano SIM 2
nano SIM 1
(default)
mini SIM
Introduction
This chapter describes settings available for configuring the device.
WWAN Configuration
There are some WWAN configuration options that can be configured by the system administrator.
• Default SIM slot
• Network type
• Band preference.
Default SIM Slot Configuration
The device contains three SIM slots that can be used for installing up to three SIM cards. A system
administrator can set the default SIM slot for the device.
Figure 86 TC75x SIM Slot
To set the default SIM slot:
1. Swipe down from the Status bar to open the Quick Access panel and then touch .
2. Touch System > About phone > SW components.
3. Touch WWAN five times. The message Turn ON SIM Slot UI appears.
4. Touch three times.
75
5. Touch Network & Internet > Mobile network > Advanced > SIM socket selection.
Figure 87 SIM Selection Dialog Box
6. Select the SIM slot to set as default.
WLAN Configuration
This section provides information on configuring Wi-Fi settings.
Settings
Configuring a Secure Wi-Fi Network
To set up a Wi-Fi network:
1. Swipe down from the Status bar to open the Quick Access panel, and then touch .
2. Touch Network & Internet > Wi-Fi.
3. Slide the switch to the ON position.
4. The device searches for WLANs in the area and lists them on the screen.
5. Scroll through the list and select the desired WLAN network.
76
Settings
6. Touch the desired network. If the network security is Open, the device automatically connects to the
network. For all other network security a dialog box appears.
Figure 88 WLAN WEP Network Security Dialog Box
Figure 89 WLAN 802.11 EAP Network Security Dialog Box
7. If the network security is WEP or WPA/WPS2 PSK, enter the required password and then touch Connect.
77
8. If the network security is 802.1x EAP:
• Touch the EAP method drop-down list and select PEAP, TLS, TTLS, or LEAP.
• Touch the Phase 2 authentication drop-down list and select an authentication method.
• If required, touch CA certificate and select a Certification Authority (CA) certificate. Note: Certificates
are installed using the Security settings.
• If required, touch User certificate and select a user certificate. Note: User certificates are installed
using the Location & security settings.
• If required, in the Identity text box, enter the username credentials.
• If desired, in the Anonymous identity text box, enter an anonymous identity username.
• If required, in the Password text box, enter the password for then given identity.
NOTE: By default, the network Proxy is set to None and the IP settings is set to DHCP. See Configuring for a Proxy Server
for setting connection to a proxy server and see Configuring the Device to Use a Static IP Address for setting the device to
use a static IP address.
9. Touch Connect.
10.Touch .
Manually Adding a Wi-Fi Network
Settings
Manually add a Wi-Fi network if the network does not broadcast its name (SSID) or add a Wi-Fi network when
out of range.
1. Swipe down from the Status bar to open the Quick Access panel, and then touch .
2. Touch Network & Internet > Wi-Fi.
3. Slide the Wi-Fi switch to the On position.
4. Scroll to the bottom of the list and select Add network.
5. In the Network name text box, enter the name of the Wi-Fi network.
6. In the Security drop-down list, set the type of security to:
• None
•WEP
• WPA/WPA2 PSK
• 802.1x EAP.
7. If the network security is None, touch Save.
8. If the network security is WEP or WPA/WPA2 PSK, enter the required password, and then touch Save.
78
Settings
9. If the network security is 802.1x EAP:
• Touch the EAP method drop-down list and select PEAP, TLS, TTLS, or LEAP.
• Touch the Phase 2 authentication drop-down list and select an authentication method.
• If required, touch CA certificate and select a Certification Authority (CA) certificate. Note: Certificates
are installed using the Security settings.
• If required, touch User certificate and select a user certificate. Note: User certificates are installed
using the Security settings.
• If required, in the Identity text box, enter the username credentials.
• If desired, in the Anonymous identity text box, enter an anonymous identity username.
• If required, in the Password text box, enter the password for the given identity.
NOTE: By default, the network Proxy is set to None and the IP settings is set to DHCP. See Configuring for a Proxy Server
for setting connection to a proxy server and see Configuring the Device to Use a Static IP Address for setting the device to
use a static IP address.
10.Touch Save. To connect to the saved network, touch and hold on the saved network and select Connect to
network.
11.Touch .
Configuring for a Proxy Server
A proxy server is a server that acts as an intermediary for requests from clients seeking resources from other
servers. A client connects to the proxy server and requests some service, such as a file, connection, web
page, or other resource, available from a different server. The proxy server evaluates the request according to
its filtering rules. For example, it may filter traffic by IP address or protocol. If the request is validated by the
filter, the proxy provides the resource by connecting to the relevant server and requesting the service on behalf
of the client.
It is important for enterprise customers to be able to set up secure computing environments within their
companies, making proxy configuration essential. Proxy configuration acts as a security barrier ensuring that
the proxy server monitors all traffic between the Internet and the intranet. This is normally an integral part of
security enforcement in corporate firewalls within intranets.
To configure the device for a proxy server:
1. Swipe down from the Status bar to open the Quick Access panel, and then touch .
2. Touch Network & Internet > Wi-Fi.
3. Slide the Wi-Fi switch to the On position.
4. In the network dialog box, select and touch a network.
5. Touch Advanced options.
79
6. Touch Proxy and select Manual.
Figure 90 Proxy Settings
Settings
7. In the Proxy hostname text box, enter the address of the proxy server.
8. In the Proxy port text box, enter the port number for the proxy server.
9. In the Bypass proxy for text box, enter addresses for web sites that are not required to go through the
proxy server. Use a comma “,” between addresses. Do not use spaces or carriage returns between
addresses.
10.Touch Connect.
11.Touch .
Configuring the Device to Use a Static IP Address
By default, the device is configured to use Dynamic Host Configuration Protocol (DHCP) to assign an Internet
protocol (IP) address when connecting to a wireless network.
To configure the device to connect to a network using a static IP address:
1. Swipe down from the Status bar to open the Quick Access panel, and then touch .
2. Touch Network & Internet > Wi-Fi.
3. Slide the Wi-Fi switch to the On position.
4. In the network dialog box, select and touch a network.
5. Touch Advanced options.
80
6. Touch IP settings and select Static.
Figure 91 Static IP Settings
Settings
7. In the IP address text box, enter an IP address for the device.
8. If required, in the Gateway text box, enter a gateway address for the device.
9. If required, in the Network prefix length text box, enter the prefix length.
10.If required, in the DNS 1 text box, enter a Domain Name System (DNS) address.
11.If required, in the DNS 2 text box, enter a DNS address.
12.Touch Connect.
13.Touch .
Wi-Fi Preferences
Use the Wi-Fi preferences to configure advanced Wi-Fi settings. From the Wi-Fi screen scroll down to the
bottom of the screen and touch Wi-Fi preferences.
• Open network notification - When enabled, notifies the user when an open network is available.
• Advanced - Touch to expand options.
• Additional settings - See Additional Settings.
• Install Certificates – Touch to install certificates.
• Network rating provider - Disabled (AOSP devices). To help determine what constitutes a good Wi-Fi
network, Android supports external Network rating providers that provide information about the quality of
81
open Wi-Fi networks. Select one of the providers listed or None. If none are available or selected, the
Connect to open networks feature is disabled.
• Wi-Fi Direct - Displays a list of devices available for a direct Wi-Fi connection.
• WPS Push Button - Touch to connect to a network using Wi-Fi Protected Setup (WPS) push button
method.
• WPS Pin Entry - Touch to connect to a network using Wi-Fi Protected Setup (WPS) pin entry method.
• MAC address - Displays the Media Access Control (MAC) address of the device when connecting to
Wi-Fi networks.
• IP address - Displays the IP address of the device when connecting to Wi-Fi networks.
Additional Wi-Fi Settings
NOTE: Additional Wi-Fi settings are for the device, not for a specific wireless network.
Use the Additional Settings to configure additional Wi-Fi settings. To view the additional Wi-Fi settings, scroll
to the bottom of the Wi-Fi screen and touch Wi-Fi Preferences > Advanced > Additional settings.
•Regulatory
• Country Selection - Displays the acquired country code if 802.11d is enabled, else it displays the
currently selected country code.
• Region code - Displays the current region code.
• Band and Channel Selection
• Wi-Fi frequency band - Set the frequency band to: Auto (default), 5 GHz only or 2.4 GHz only.
• Available channels (2.4 GHz) - Touch to display the Available channels menu. Select specific
channels and touch OK.
• Available channels (5 GHz) - Touch to display the Available channels menu. Select specific channels
and touch OK.
• Logging
• Advanced Logging – Touch to enable advanced logging or change the log directory.
• Wireless logs - Use to capture Wi-Fi log files.
• Fusion Logger - Touch to open the Fusion Logger application. This application maintains a history
of high level WLAN events which helps to understand the status of connectivity.
• Fusion Status - Touch to display live status of WLAN state. Also provides information about the
device and connected profile.
• About
• Version - Displays the current Fusion information.
Settings
Wi-Fi Direct
Wi-Fi Direct devices can connect to each other without having to go through an access point. Wi-Fi Direct
devices establish their own ad-hoc network when required, letting you see which devices are available and
choose which one you want to connect to.
1. Swipe down from the status bar and then touch .
82
Settings
2. Touch Wi-Fi > Wi-Fi preferences > Advanced > Wi-Fi Direct. The device begins searching for another
Wi-Fi Direct device.
Figure 92 Wi-Fi Direct Screen
3. Under Peer devices, touch the other device name.
4. On the other device, select Accept.
5. Connected appears on the device. On both devices, in their respective Wi-Fi Direct screens, the other
device name appears in the list.
WPS Push Button
Wi-Fi Protected Setup (WPS) is a feature allowing devices to easily connect to Wi-Fi access points without
typing a long password.
To use a wireless router WPS button:
1. On the device, swipe down from the status bar and then touch .
2. Touch Wi-Fi > Wi-Fi preferences > Advanced > WPS Push Button. A dialog box displays.
Figure 93 WPS Setup Dialog Box
83
3. On the wireless router, locate the WPS button. The device connects to the wireless router.
WPS Pin Entry
Wi-Fi Protected Setup (WPS) is a feature allowing devices to easily connect to Wi-Fi access points without
typing a long password.
To use a PIN to connect to a wireless router:
1. Log in to the router.
2. Go to the Add WPS Client screen. Refer to the wireless router user documentation specific information.
3. On the device, swipe down from the status bar, and then touch .
4. Touch Wi-Fi > Wi-Fi preferences > Advanced > WPS Pin Entry. A dialog box displays with an Pin
number.
Figure 94 Pin Entry Dialog Box
Settings
5. On the router, enter the Pin number. The device connects to the wireless router.
Setting Screen Lock
Use the Device security settings to set preferences for locking the screen.
1. Swipe down from the Status bar to open the Quick Access panel, and then touch .
2. Touch Security & location.
NOTE: Options vary depending upon the policy of some apps, such as email.
• Screen lock - Touch to configure the device to require a slide, pattern, PIN, or password to unlock the
screen.
• None - Disable screen unlock security.
• Swipe - Slide the lock icon to unlock the screen.
• Pattern - Draw a pattern to unlock screen. See Setting Screen Unlock Using Pattern for more
information.
• PIN - Enter a numeric PIN to unlock screen. See Setting Screen Lock Using PIN for more information.
• Password - Enter a password to unlock screen. See Setting Screen Unlock Using Password for more
information.
Lock the screen to protect access to data on the device. Some email accounts require locking the screen. The
Locking feature functions differently in Single-user versus Multiple-user mode.
84
When locked, a slide, pattern, PIN or password is required to unlock the device. Press the Power button to lock
the screen. The device also locks after a pre-defined time-out.
Press and release the Power button to wake the device. The Lock screen displays.
Slide the screen up to unlock. If the Pattern screen unlock feature is enabled, the Pattern screen appears
instead of the Lock screen.
If the PIN or Password screen unlock feature is enabled, enter the PIN or password after unlocking the screen.
Setting Screen Lock Using PIN
1. Swipe down from the Status bar to open the Quick Access panel, and then touch .
2. Touch Security & location.
3. Touch Screen lock.
4. Touch PIN.
5. To require a PIN upon device start up select Yes, or select No not to require a PIN.
Settings
Figure 95 PIN Screen
6. Touch in the text field.
7. Enter a PIN (4 numbers), and then touch Next.
8. Re-enter PIN and then touch Next.
9. Select the type of notifications that appear when the screen is locked and then touch Done.
10.Touch . The next time the device goes into suspend mode a PIN is required upon waking.
85
Settings
Setting Screen Unlock Using Password
1. Swipe down from the Status bar to open the Quick Access panel, and then touch .
2. Touch Security & location.
3. Touch Screen lock.
4. Touch Password.
5. To require a password upon device start up select Yes, or select No not to require a password.
6. Touch in the text field.
7. Enter a password (between 4 and 16 characters), and then touch Next.
Figure 96 Password Screen
8. Re-enter the password and then touch Next.
9. Select the type of notifications that appear when the screen is locked and then touch Done.
10.Touch . The next time the device goes into suspend mode a password is required upon waking.
Setting Screen Unlock Using Pattern
1. Swipe down from the Status bar to open the Quick Access panel, and then touch .
2. Touch Security & location.
3. Touch Screen lock.
4. Touch Pattern.
86
Settings
5. To require a pattern upon device start up select Yes, or select No not to require a pattern.
Figure 97 Choose Your Pattern Screen
6. Draw a pattern connecting at least four dots.
7. Touch Continue.
8. Re-draw the pattern.
9. Touch Confirm.
10.Select the type of notifications that appear when the screen is locked, and then touch Done.
11.Touch . The next time the device goes into suspend mode a pattern is required upon waking.
Showing Passwords
To set the device to briefly show password characters as the user types:
1. Swipe down from the Status bar to open the Quick Access panel and then touch .
2. Touch Security & location.
3. Slide the Show passwords switch to the ON position.
Remapping a Button
Buttons on the device can be programmed to perform different functions or as shortcuts to installed apps.
NOTE: It is not recommended to remap the scan button.
1. Swipe down from the Status bar to open the Quick Access panel and then touch .
2. Touch Key Programmer. A list of programmable buttons displays.
87
3. Select the button to remap.
4. Touch the BUTTON REMAPPING tab or the SHORTCUT tab that lists the available functions and
5. Touch a function or application shortcut to map to the button.
NOTE: If you select an application shortcut, the application icon appears next to the button on the Key Programmer screen.
6. Touch .
7. If remapping the Back, Home, Search, or Menu button, perform a Soft Reset. See the device User Guide
Accounts
Use the Accounts settings to add, remove, and manage accounts. Use these settings to control how
applications send, receive, and sync data on their own schedules, and whether applications can synchronize
user data automatically.
Settings
applications.
for Android 8.1 Oreo.
Applications may also have their own settings to control how they synchronize data; see the documentation for
those applications for details.
Language Usage
Use the Language & input settings to change the device’s language, including words added to the dictionary.
Changing the Language Setting
1. Swipe down from the Status bar to open the Quick Access panel and then touch .
2. Touch System > Languages & input.
3. Touch Languages. A list of available languages displays.
4. If the desired language is not listed, touch Add a language and select a language from the list.
5. Touch and hold to the right of the desired language, then drag it to the top of the list.
6. The operating system text changes to the selected language.
Adding Words to the Dictionary
1. Swipe down from the Status bar to open the Quick Access panel and then touch .
2. Touch System > Languages & input > Advanced > Personal dictionary.
3. If prompted, select the language where this word or phase is stored.
4. Touch + to add a new word or phrase to the dictionary.
5. Enter the word or phrase.
6. In the Shortcut text box, enter a shortcut for the word or phrase.
88
7. Touch .
Keyboard Settings
Use the Languages & input settings to configure the on-screen keyboards. The device contains the following
keyboard settings:
• Android Keyboard - AOSP devices only
• Enterprise Keyboard
• Gboard - GMS devices only.
PTT Express Configuration
Refer to the PTT Express User Guide at www.zebra.com/support for information on configuring the PTT
Express Client application.
RxLogger
RxLogger is a comprehensive diagnostic tool that provides application and system metrics, allows for the
creation of custom plug-ins, and diagnoses device and application issues. RxLogger logs the following
information: CPU load, memory load, memory snapshots, battery consumption, power states, wireless logging,
cellular logging, TCP dumps, Bluetooth logging, GPS logging, logcat, FTP push/pull, ANR dumps, etc. All
generated logs and files are saved onto flash storage on the device (internal or external).
Settings
Figure 98 RxLogger
RxLogger Configuration
RxLogger is built with an extensible plug-in architecture and comes packaged with a number of plug-ins
already built-in. The included plug-ins are described below.
89
Settings
To open the configuration screen, from the RxLogger home screen touch Settings.
Figure 99 RxLogger Configuration Screen
RxLogger Settings
The RxLogger Settings module provides additional RxLogger settings.
• Enable notifications - Select to allow RxLogger notifications in the Status bar and Notification panel.
• Enable debug logs - Select to enable debug logs.
ANR Module
Application Not Responsive (ANR) indicates that a running application’s UI thread is not responding for a
specified time period. RxLogger is able to detect this condition and trigger a copy of the call stack trace of the
unresponsive application into the log directory. The event is also indicated in the high level CSV log.
• Enable Module - Enables logging for this module.
• Log path - Specifies the default log path to store the ANR log files.
• Collect Historic ANRs - Collects ANR trace files from the system.
Kernel Module
The Kernel Module captures kmsg from the system.
• Enable Module - Enables logging for this kernel module.
• Log path - Specifies the high level log path for storage of all kernel logs. This setting applies globally to all
kernel buffers.
• Kernel Log filename - Specifies the base log filename for this kernel buffer. The current file count is
appended to this name.
• Max Kernel log file size - Specifies the maximum size, in megabytes, of an individual log file.
• Kernel Log interval - Sets the interval, in seconds, on which to flush the log buffer to the file.
90
Settings
• Kernel Log file count - Specifies the number of log files to keep and rotate through. Each log file is subject
to the max log size option.
• Enable System Timestamp in Kernel Log - Enables system timestamps in kernel logs.
• System Timestamp Interval - Sets the interval, in seconds, between system timestamps.
• Enable Logcat Integration override - Enables logcat integration overrides.
Logcat Module
Logcat is an essential debugging tool on Android devices. RxLogger provides the ability to record data from all
four of the available logcat buffers. The Logcat plug-in can collect data from multiple logcat buffers provided by
the system, which are the main, event, radio, and system buffers. Each of the settings are available for each
buffer independently unless otherwise noted.
• Enable Module - Enables logging for this module.
• Log path - Specifies the high level log path for storage of all logcat logs. This setting applies globally to all
logcat buffers.
• Enable main logcat - Enables logging for this logcat buffer.
• Main Log interval (sec) - Sets the interval, in seconds, on which to flush the log buffer to the file.
• Main Log filename - Specifies the base log filename for this logcat buffer. The current file count is
appended to this name.
• Main Log file count - Specifies the number of log files to keep and rotate through. Each log file is
subject to the max log size option.
• Main log file size (MB) - Specifies the maximum size, in megabytes, of an individual log file.
• Main log filter - Custom logcat filter to run on the main buffer.
• Enable event logcat - Enables event logging for this logcat buffer.
• Event log interval (sec) - Sets the interval, in seconds, on which to flush the log buffer to the file.
• Event log filename - Specifies the base log filename for this logcat buffer. The current file count is
appended to this name.
• Event log file count - Specifies the number of log files to keep and rotate through. Each log file is
subject to the max log size option.
• Event log file size (MB) - Specifies the maximum size, in kilobytes, of an individual log file.
• Event log filter - Custom logcat filter to run on the event buffer.
• Enable radio logcat - Enables logging for this logcat buffer.
• Radio log interval (sec) - Sets the interval, in seconds, on which to flush the log buffer to the file.
• Radio log filename - Specifies the base log filename for this logcat buffer. The current file count is
appended to this name.
• Radio log file count - Specifies the number of log files to keep and rotate through
subject to the max log size option.
• Radio log file size (MB) - Specifies the maximum size, in kilobytes, of an individual log file.
• Radio log filter -Custom logcat filter to run on the radio buffer.
. Each log file is
91
Settings
• Enable system logcat - Enables logging for this logcat buffer.
• System log interval (sec) - Sets the interval, in seconds, on which to flush the log buffer to the file.
• System log filename - Specifies the base log filename for this logcat buffer. The current file count is
appended to this name.
• System log file count - Specifies the number of log files to keep and rotate through. Each log file is
subject to the max log size option.
• System log file size (MB) - Specifies the maximum size, in kilobytes, of an individual log file.
• System log filter - Custom logcat filter to run on the system buffer.
• Enable crash logcat- Enables logging for this crash logcat buffer.
• Crash log interval (sec) - Sets the interval, in seconds, on which to flush the log buffer to the file.
• Crash log filename - Specifies the base log filename for this logcat buffer. The current file count is
appended to this name.
• Crash log file count - Specifies the number of log files to keep and rotate through. Each log file is
subject to the max log size option.
• Crash log file size (MB) - Specifies the maximum size, in megabytes, of an individual log file.
• Crash log filter - Custom logcat filter to run on the crash buffer.
• Enable combined logcat - Enables logging for this logcat buffer.
• Enable main buffer - Enable or disable the addition of the main buffer into the combined logcat file.
• Enable event buffer - Enable or disable the addition of the event buffer into the combined logcat file.
• Enable radio buffer - Enable or disable the addition of the radio buffer into the combined logcat file.
• Enable system buffer - Enable or disable the addition of the system buffer into the combined logcat file.
• Enable crash buffer - Enable or disable the addition of the crash buffer into the combined logcat file.
• Combine log interval (sec) - Sets the interval, in seconds, on which to flush the log buffer to the file.
• Combined log filename - Specifies the base log filename for this logcat buffer. The current file count is
appended to this name.
• Combined log file count - Specifies the number of log files to keep and rotate through. Each log file is
subject to the max log size option.
• Combined log file size (MB) - Specifies the maximum size, in megabytes, of an individual log file.
• Combined log filter - Custom logcat filter to run on the combined buffer.
LTS Module
The LTS (Long Term Storage) Module captures data over a long duration of time without losing any data.
Whenever a file is done being written, LTS saves it as a GZ file in an organized path for later use.
• Enable Module - Enables logging for this module.
• Storage Directory - Specifies the high level log path for storage of all logcat logs. This setting applies
globally to all logcat buffers.
Qxdm Module
The Ramoops Module captures Qualcomm Modem Logs from the device.
• Enable Module - Enables logging for this module.
•Log path - Specifies the storage path for Qxdm files.
• Qxdm Log Size - Specifies the maximum size, in kilobytes, of an individual log file.
• Qxdm test sets to keep - Specifies the number of test sets to keep. One test set is a start and stop.
92
Settings
• Choose Log Filter - Select which filter Qxdm uses to process logs.
• Path for User Defined Filter - Specifies the path to a user-defined configuration file.
Ramoops Module
The Ramoops Module captures the last kmsg from the device.
• Enable Module - Enables logging for this module.
• Log path - Specifies the high level log path for storage of all ramoops logs. This setting applies globally to
all Ramoops buffers.
• Base filename - Specifies the base log filename for this kernal buffer. The current file count is appended to
this name.
• Ramoops file count - Specifies the number of log files to keep and rotate through. Each log file is subject
to the log size option.
Resource Module
The Resource Module captures device information and system statistics at specified intervals. The data is
used to determine the health of the device over a period of time.
• Enable Module - Enables logging for this module.
• Log Path - Specifies the high level log path for storage of all resource logs. This setting applies globally to
all resource buffers.
• Resource Log interval - Sets the interval, in seconds, on which to flush the log buffer to the file.
• Resource Log file size - Specifies the maximum size, in megabytes, of an individual log file.
• Resource Log file count - Specifies the number of log files to keep and rotate through. Each log file is
subject to the max log size option.
• Power - Enables or disables the collection of Battery statistics.
• System Resource- Enables or disables the collection of System Resource information.
• Network - Enables or disables the collection of Network status.
• Bluetooth - Enables or disables the collection of Bluetooth information.
• Light - Enables or disables the collection of ambient light level.
• Heater - Not supported.
Snapshot Module
The Snapshot Module collects detailed device statistics at an interval to see detailed device information.
• Enable Module - Enables logging for this module.
• Log Path - Specifies the base path to use to store the snapshot files
• Log filename - Specifies the base filename for all the snapshot files. The current file count is appended to
this name.
• Log Interval (sec) - Specifies the interval, in seconds, on which to invoke a detailed snapshot.
• Snapshot file count - The maximum number of Snapshot files to keep at any one time.
• Top - Enables or disables the running of the
• CPU Info - Enables detailed per process CPU logging in the snapshot.
• Memory Info - Enables logging of detailed per process memory usage in the snapshot.
• Battery Info - Enables logging of detailed power information including battery life, on time, charging, and
wake locks.
top command for data collection.
93
Settings
• Wake Locks - Enables or disables the collection of the sys/fs wake_lock information.
• Time in State - Enables or disables the collection of the sys/fs cpufreq for each core.
• Processes - Enables dumping the complete process list in the snapshot.
• Threads - Enables dumping all processes and their threads in the snapshot.
• Properties - Enables dumping of all system properties on the device. This includes build/version
information as well as state information.
• Interfaces - Enables or disables the running of the
• IP Routing Table - Enables or disables the collection of the net route for data collection.
• Connectivity - Enables or disables the running of the
netcfg command for data collection.
dumpsysconnectivity command for data collection.
• Wifi - Enables or disables the running of the
• File systems - Enables dumping of the available volumes on the file system and the free storage space for
each.
• Usage stats - Enables dumping of detailed usage information for each package on the device. This
includes the number of starts and duration of each run.
dumpsyswifi command for data collection.
TCPDump Module
The TCPDump Module captures TCP data that happens over the device’s networks.
• Enable Module - Enables logging for this module.
• Log path - Specifies the location to store the TCPDump output log files.
• Base filename - Specifies the base filename to use when storing the TCPDump files. The index number of
the current log file is appended to the filename.
• Tcpdump file size (MB) - Specifies the maximum file size, in megabytes, for each log file created.
• Tcpdump file count - Specifies the number of log files to cycle through when storing the network traces.
Tombstone Module
The Tombstone Module collects tombstone (Linux Native Crashes) logs from the device.
• Enable Module - Enables logging for this module.
• Log path - Specifies the location to store the Tombstone output log files.
• Collect Historic tombstones - Collects new and existing tombstone files.
Configuration File
RxLogger configuration can be set using an XML file. The config.xml configuration file is located on the
microSD card in the
connection. Edit the configuration file and then replace the XML file on the device. There is no need to stop and
restart the RxLogger service since the file change is automatically detected.
Enabling Logging
To enable logging:
1. Swipe the screen up and select .
2. Touch Start.
3. Touch .
RxLogger\config folder. Copy the file from the device to a host computer using a USB
94
Disabling Logging
To disable logging:
1. Swipe the screen up and select .
2. Touch Stop.
3. Touch .
Extracting Log Files
1. Connect the device to a host computer using an USB connection.
Settings
2. Using a file explorer, navigate to the
3. Copy the file from the device to the host computer.
4. Disconnect the device from the host computer.
RxLogger Utility
RxLogger Utility is a data monitoring application for viewing logs in the device while RxLogger is running. Logs
and RxLogger Utility features are accessed in the App View or the Overlay View.
App View
In App View, the user views logs in the RxLogger Utility.
Figure 100 App View
RxLogger folder.
95
Backup
RxLogger Utility allows the user to make a zip file of the RxLogger folder in the device, which by default
contains all the RxLogger logs stored in the device.
To save the backup data, touch BACKUP > Yes.
Figure 101 Backup Message
Archive Data
View all the RxLogger logs stored in the default RxLogger directory. Logs viewed in the Archive window are not
live.
Settings
Figure 102 Archive
To view the log files, touch ARCHIVE DATA and then touch a log file.
Overlay View
Use Overlay View to display RxLogger information while using other apps or on the home screen. Overlay
View is accessed using the Main Chat Head.
96
Settings
Initiating the Main Chat Head
To initiate the Main Chat Head:
1. Open RxLogger.
2. Touch > Toggle Chat Head. The Main Chat Head icon appears on the screen.
3. Touch and drag the Main Chat head icon to move it around the screen.
Removing the Main Chat Head
To remove the Main Chat Head icon:
1. Touch and drag the icon. A circle with an X appears.
2. Move the icon over the circle and then release.
Viewing Logs
To view logs:
1. Touch the Main Chat Head icon. The Overlay View screen appears.
Figure 103 Overlay View Screen
2. Touch a log to open it. The user can open many logs with each displaying a new sub Chat Head.
3. If necessary, scroll left or right to view additional Sub Chat Head icons.
97
Settings
4. Touch a Sub Chat Head to display the log contents.
Figure 104 Log File
Removing a Sub Chat Head Icon
To remove a sub chat Head icon, press and hold the icon until it disappears.
Backing Up In Overlay View
RxLogger Utility allows the user to make a zip file of the RxLogger folder in the device, which by default
contains all the RxLogger logs stored in the device.
The Backup icon is always available in Overlay View.
1. Touch . The Backup dialog box appears.
2. Touch Yes to create the back up.
About Phone
Use About phone settings to view information about the device. Swipe down from the Status bar to open the
Quick Access panel and then touch > System > About phone.
• Status - Touch to display the following:
• Battery status - Indicates if the battery is charging (on AC power) or discharging (on battery power).
• Battery level - Indicates the battery charge level.
• SIM Status - Touch to display SIM status (WWAN only).
• Network - Indicates the current network carrier.
• Signal strength - Indicates the radio signal strength.
• Mobile network type - Indicates the mobile network type.
• Operator info - Indicates operator information.
98
Settings
• Service state - Indicates the state of service.
• Roaming - Indicates if the device is roaming outside the network.
• Mobile network state - Indicates the mobile network state.
• IMS Registration State - Indicates the IP Multimedia Subsystem status.
• My phone number - Displays the phone number associated with the device.
• IMEI - Displays the IMEI number for the device.
• IMEI SV - Displays the IMEI SV number for the device.
• ICCID - Displays the ICCID number for the device.
• IMEI Information - Displays the IMEI information for the device (WWAN only).
• IMEI - Displays the IMEI number for the device.
• IMEI SV - Displays the IMEI SV number for the device.
• IP address - Displays the IP address of the device.
• Wi-Fi MAC address - Displays the Wi-Fi radio MAC address.
• Ethernet MAC address - Displays the Ethernet driver MAC address.
• Bluetooth address - Displays the Bluetooth radio Bluetooth address.
• Serial number - Displays the serial number of the device.
• MSM serial number - Displays the serial number of the MSM.
• Up time - Displays the time that the device has been running since being turned on.
• Battery Information - Displays information about the battery.
• SW components - Lists filenames and versions for various software on the device.
• Legal information - Opens a screen to view legal information about the software included on the device.
• Model - Displays the devices model number.
• Android version - Displays the operating system version.
• Android security patch level - Displays the security patch level date.
• Baseband version - Displays WAN radio firmware version (WWAN only).
• Kernel version - Displays the kernel version.
• Build Fingerprint - Defines Device Manufacturer, Model, Android version and Build version together in one
location.
• Build number
- Displays the software build number.
99
USB Communication
Introduction
This chapter provides information for transferring files between the device and a host computer.
Transferring Files with a Host Computer via USB
Connect the device to a host computer using a USB cable or a USB cradle to transfer files between the
device and the host computer.
When connecting the device to a host computer, follow the host computer’s instructions for connecting
and disconnecting USB devices, to avoid damaging or corrupting files.
Transferring Files
NOTE: Use Transfer files to copy files between the device (internal memory or microSD card) and the host com-
puter.
1. Connect a USB cable to the device or place the device into a USB cradle.
2. Pull down the Notification panel and touch USB charging this device.
By default, Charge this device is selected.
Figure 105 Use USB to Dialog Box
3. Touch Transfer files.
4. On the host computer, open a file explorer application.
5. Locate the device as a portable device.
