TC56
MN-002956-03
Touch Computer
Quick Start Guide
2 TC56 Touch Computer
No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means, without permission in
writing. This includes electronic or mechanical means, such as photocopying, recording, or information storage and retrieval
systems. The material in this manual is subject to change without notice.
The software is provided strictly on an “as is” basis. All software, including firmware, furnished to the user is on a licensed basis. We
grant to the user a non-transferable and non-exclusive license to use each software or firmware program delivered hereunder
(licensed program). Except as noted below, such license may not be assigned, sublicensed, or otherwise transferred by the user
without prior written consent. No right to copy a licensed program in whole or in part is granted, except as permitted under copyright
law. The user shall not modify, merge, or incorporate any form or portion of a licensed program with other program material, create
a derivative work from a licensed program, or use a licensed program in a network without written permission. The user agrees to
maintain copyright notice on the licensed programs delivered hereunder, and to include the same on any authorized copies it
makes, in whole or in part. The user agrees not to decompile, disassemble, decode, or reverse engineer any licensed program
delivered to the user or any portion thereof.
We reserve the right to make changes to any software or product to improve reliability, function, or design.
We do not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or
application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise under any of our intellectual property rights. An
implied license only exists for equipment, circuits, and subsystems contained in our products.
Warranty
For the complete Zebra hardware product warranty statement, go to: www.zebra.com/warranty.
Service Information
If you have a problem using the equipment, contact your facility’s Technical or Systems Support. If there is a problem with the
equipment, they will contact the Zebra Support at: http:www.zebra.com/support.
For the latest version of this guide go to: www.zebra.com/support.
Quick Start Guide 3
Features
NOTE ActiveEdge Touch Zone is available on builds BSP 19-01.4 and above.
Data Capture LED
PTT Button
Scan Button
ActiveEdge Touch
Receiver
Zone
Microphone
Proximity Sensor
Microphone
Light Sensor
Charging/Notification LED
ActiveEdge Touch Zone
Touch Screen
Speaker
Interface Connector
Battery
Battery Release Latch
NFC Antenna
Programmable
Button
Headphone
Jack
Exit Window
Power Button
Volume Up/Down Button
Camera
Camera Flash
Scan Button
Battery Release Latch
Installing a microSD Card
The microSD card slot provides secondary non-volatile storage. The slot is located under the battery pack. Refer to the
documentation provided with the card for more information, and follow the manufacturer’s recommendations for use.
CAUTION Follow proper electrostatic discharge (ESD) precautions to avoid damaging the microSD card. Proper ESD precautions
include, but are not limited to, working on an ESD mat and ensuring that the operator is properly grounded.
4 TC56 Touch Computer
1. Lift the access door.
2. Slide the microSD card holder door to the Open position.
3. Lift the microSD card holder door.
4. Insert the microSD card into the card holder door ensuring that the card slides into the holding tabs on each side of the door.
5. Close the microSD card holder door.
Quick Start Guide 5
6. Slide the microSD card holder door to the Lock position.
CAUTION Access door must be replaced and securely seated to ensure proper device sealing.
7. Re-install the access door.
Installing the SIM Card
NOTE Only use nano SIM cards.
CAUTION For proper electrostatic discharge (ESD) precautions to avoid damaging the SIM card. Proper ESD precautions include, but
not limited to, working on an ESD mat and ensuring that the user is properly grounded.
1. Remove access cover.
2. Slide the SIM card holder door to the unlock position.
