Zebra RS5100 Product Reference Guide

Download

RS5100

Bluetooth Ring Scanner

Product Reference Guide

MN-003561-09EN Rev A

Copyright

ZEBRA and the stylized Zebra head are trademarks of Zebra Technologies Corporation, registered in many jurisdictions worldwide. . All other trademarks are the property of their respective owners. © 2022 Zebra Technologies Corporation and/or its affiliates. All rights reserved.

For further information regarding legal and proprietary statements, please go to:

COPYRIGHTS:zebra.com/copyright WARRANTY:zebra.com/warranty END USER LICENSE AGREEMENT: zebra.com/eula

Terms of Use

• Proprietary Statement

This manual contains proprietary information of Zebra Technologies Corporation and its subsidiaries (“Zebra Technologies”). It is intended solely for the information and use of parties operating and maintaining the equipment described herein. Such proprietary information may not be used, reproduced, or disclosed to any other parties for any other purpose without the express, written permission of Zebra Technologies.

• Product Improvements

Continuous improvement of products is a policy of Zebra Technologies. All specifications and designs are subject to change without notice.

• Liability Disclaimer

Zebra Technologies takes steps to ensure that its published Engineering specifications and manuals are correct; however, errors do occur. Zebra Technologies reserves the right to correct any such errors and disclaims liability resulting therefrom.

• Limitation of Liability

In no event shall Zebra Technologies or anyone else involved in the creation, production, or delivery of the accompanying product (including hardware and software) be liable for any damages whatsoever (including, without limitation, consequential damages including loss of business profits, business interruption, or loss of business information) arising out of the use of, the results of use of, or inability to use such product, even if Zebra Technologies has been advised of the possibility of such damages. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

Revision History

Changes to the original guide are listed below:

Change Date Description

-09 1/22 Add HID CAPS Lock Override parameter Revised Multipoint-to-Point communication description

-08 11/21 Add Hand Mount Glove

-07 02/21 Add note to battery indications

-06 12/20 Replaced Master/Slave references with Central/Peripheral

Change Date Description

-05 08/20 Enhance documentation for support with STB3678

-04 05/20 Add Double-Tigger:USB-C and Double-Trigger:Vibrator

-03 04/20 Add Double-Trigger: Standard and Extended Battery

-02 03/20 Add Auto Un-Pairing

-01 11/19 Initial Release

Table of Contents

Copyright ........................................................................................................................................... 2

Terms of Use .................................................................................................................................... 2

Revision History ................................................................................................................................ 2

About This Guide

Introduction ..................................................................................................................................... 13

Notational Conventions ................................................................................................................... 13

Service Information ......................................................................................................................... 14

Getting Started

Introduction ..................................................................................................................................... 15

Unpacking ....................................................................................................................................... 15

Configuration Features ................................................................................................................... 16

Status Indications ............................................................................................................................ 17

RS5100 Activity Modes ................................................................................................................... 19

Configurations ................................................................................................................................. 19

Single Trigger Assembly - Change Trigger Position ................................................................. 19

Double Trigger Assembly .......................................................................................................... 21

Charge the Battery .................................................................................................................... 21

Install the Battery ...................................................................................................................... 21

Remove the Battery .................................................................................................................. 22

Mounting the RS5100 ............................................................................................................... 22

Bluetooth Connection ...................................................................................................................... 24

Scanning ......................................................................................................................................... 24

RS5100 Scanning with SE4710 ................................................................................................ 24

RS5100 Scanning with SE4770 ................................................................................................ 24

Aiming the RS5100 ................................................................................................................... 24

Resetting the RS5100 ..................................................................................................................... 26

Warm Boot ................................................................................................................................ 26

Cold Boot .................................................................................................................................. 26

Clean Boot ................................................................................................................................ 26

123Scan and Software Tools

Introduction ..................................................................................................................................... 27

123Scan .......................................................................................................................................... 27

Table of Contents

Communication with 123Scan ................................................................................................... 28

123Scan Requirements ............................................................................................................. 28

123Scan Information ................................................................................................................. 28

Scanner SDK, Other Software Tools, and Videos .................................................................... 28

Bluetooth Communications

Introduction ..................................................................................................................................... 30

Scanning Sequence Examples ................................................................................................. 30

Errors While Scanning .............................................................................................................. 30

Bluetooth Communications Parameter Defaults ............................................................................. 30

Bluetooth Status Indications ........................................................................................................... 32

Bluetooth Connection Modes .......................................................................................................... 32

Keyboard Emulation ........................................................................................................................ 32

HID Bluetooth Classic ............................................................................................................... 32

HID Bluetooth Low Energy (Discoverable) ................................................................................ 32

HID Bluetooth Barcodes ............................................................................................................ 33

HID Setup .................................................................................................................................. 33

HID Options ............................................................................................................................... 37

Simple Serial Interface (SSI) ..................................................................................................... 46

SSI Setup .................................................................................................................................. 47

Serial Port Profile ............................................................................................................................ 51

SPP Setup ................................................................................................................................. 51

Special characters ..................................................................................................................... 58

General Bluetooth Options .............................................................................................................. 65

Default Bluetooth Friendly Name .............................................................................................. 65

Discoverable Mode ................................................................................................................... 65

Bluetooth Security ..................................................................................................................... 66

Wi-Fi Friendly Mode .................................................................................................................. 68

Radio Output Power .................................................................................................................. 70

Link Supervision Timeout .......................................................................................................... 71

Reconnecting ............................................................................................................................ 72

Pairing Support ......................................................................................................................... 75

Batch Mode ............................................................................................................................... 78

Unique Identifier (SPP only) ...................................................................................................... 80

Image Capture (SPP only) ........................................................................................................ 81

Accessories

Accessories ..................................................................................................................................... 82

Charging ......................................................................................................................................... 85

Battery Charging ....................................................................................................................... 86

4-Slot RS5100 Charge Only Cradle ................................................................................................ 88

8-Slot Battery Charger .................................................................................................................... 89

20-Slot RS5100 Charge Only Cradle .............................................................................................. 90

40-Slot Battery Charger .................................................................................................................. 92

Lanyard Mount ................................................................................................................................ 93

Back of Hand Mount ....................................................................................................................... 95

Hand Mount Glove ........................................................................................................................ 100

Install Glove: Right Hand User ................................................................................................ 100

Install Glove: Left Hand User .................................................................................................. 101

Table of Contents

Position Glove on Hand .......................................................................................................... 102

Install RS5100 ......................................................................................................................... 104

Correct Installation .................................................................................................................. 105

Incorrect Installation ................................................................................................................ 106

Detach RS5100 ....................................................................................................................... 106

Cleaning the Glove .................................................................................................................. 107

RS5100 Configuration and Update

Introduction ................................................................................................................................... 109

Configuring the RS5100 ................................................................................................................ 109

Introduction ............................................................................................................................. 109

DataWedge ............................................................................................................................. 109

123Scan2 ................................................................................................................................ 110

Real Time Logger ......................................................................................................................... 110

Retrieving the RS5100 Log File .............................................................................................. 110

RS5100 Firmware Update ............................................................................................................ 111

Bluetooth Using 123Scan2 ...................................................................................................... 112

Bluetooth Connected Zebra Device ........................................................................................ 112

Miscellaneous Imager Options

Introduction ................................................................................................................................... 113

Scanning Sequence Examples ..................................................................................................... 114

Errors While Scanning .................................................................................................................. 114

User Preferences/Miscellaneous Options Parameter Defaults ..................................................... 114

User Preferences .......................................................................................................................... 116

Default Parameters ................................................................................................................. 116

Parameter Barcode Scanning ................................................................................................. 117

Beep After Good Decode ........................................................................................................ 118

Beep on Insertion .................................................................................................................... 118

Beeper Volume ....................................................................................................................... 119

Beeper Tone ........................................................................................................................... 120

Beeper Duration ...................................................................................................................... 121

Suppress Power Up Beeps ..................................................................................................... 121

Low Battery Indication ............................................................................................................. 122

Hand-Held Trigger Mode ......................................................................................................... 123

Hand-Held Decode Aiming Pattern ......................................................................................... 124

Picklist Mode ........................................................................................................................... 125

Continuous Barcode Read ...................................................................................................... 126

Unique Barcode Reporting ...................................................................................................... 127

Decode Session Timeout ........................................................................................................ 128

Timeout Between Decodes, Same Symbol ............................................................................. 129

Timeout Between Decodes, Different Symbol ........................................................................ 130

Fuzzy 1D Processing .............................................................................................................. 130

Decode Mirror Images (Data Matrix Only) .............................................................................. 131

Mobile Phone/Display Mode ................................................................................................... 132

PDF Prioritization .................................................................................................................... 133

PDF Prioritization Timeout ...................................................................................................... 134

Decoding Illumination .............................................................................................................. 135

Motion Tolerance .................................................................................................................... 136

Table of Contents

Miscellaneous Scanner Parameters ............................................................................................. 136

Add an Enter Key .................................................................................................................... 136

Transmit Code ID Character ................................................................................................... 136

Prefix/Suffix Values ................................................................................................................. 137

Scan Data Transmission Format ............................................................................................. 138

FN1 Substitution Values .......................................................................................................... 140

Transmit “No Read” Message ................................................................................................. 141

Trigger Buttons Enabled ......................................................................................................... 141

Symbologies

Introduction ................................................................................................................................... 144

Scanning Sequence Examples ..................................................................................................... 144

Errors While Scanning .................................................................................................................. 144

Symbology Parameter Defaults .................................................................................................... 145

Enable/Disable All Code Types .................................................................................................... 151

UPC/EAN ...................................................................................................................................... 152

Enable/Disable UPC-A ............................................................................................................ 152

Enable/Disable UPC-E ............................................................................................................ 152

Enable/Disable UPC-E1 .......................................................................................................... 153

Enable/Disable EAN-8/JAN-8 ................................................................................................. 153

Enable/Disable EAN-13/JAN-13 ............................................................................................. 154

Enable/Disable Bookland EAN ................................................................................................ 154

Decode UPC/EAN/JAN Supplementals .................................................................................. 155

User-Programmable Supplementals ....................................................................................... 158

UPC/EAN/JAN Supplemental Redundancy ............................................................................ 158

UPC/EAN/JAN Supplemental AIM ID Format ......................................................................... 159

UPC Reduced Quiet Zone ...................................................................................................... 160

Transmit UPC-A Check Digit ................................................................................................... 160

Transmit UPC-E Check Digit ................................................................................................... 161

Transmit UPC-E1 Check Digit ................................................................................................. 161

UPC-A Preamble ..................................................................................................................... 162

UPC-E Preamble ..................................................................................................................... 163

UPC-E1 Preamble ................................................................................................................... 164

Convert UPC-E to UPC-A ....................................................................................................... 165

Convert UPC-E1 to UPC-A ..................................................................................................... 165

EAN-8/JAN-8 Extend .............................................................................................................. 166

Bookland ISBN Format ........................................................................................................... 167

UCC Coupon Extended Code ................................................................................................. 168

Coupon Report ........................................................................................................................ 169

ISSN EAN ............................................................................................................................... 170

Code 128 ...................................................................................................................................... 171

Enable/Disable Code 128 ....................................................................................................... 171

Set Lengths for Code 128 ....................................................................................................... 172

Enable/Disable GS1-128 (formerly UCC/EAN-128) ................................................................ 174

Enable/Disable ISBT 128 ........................................................................................................ 174

ISBT Concatenation ................................................................................................................ 175

Check ISBT Table ................................................................................................................... 176

ISBT Concatenation Redundancy ........................................................................................... 176

Code 128 Security Level ......................................................................................................... 177

Code 128 Reduced Quiet Zone .............................................................................................. 178

Table of Contents

Ignore Code 128 <FNC4> ....................................................................................................... 178

Code 128 Exclusive ................................................................................................................ 179

Code 39 ........................................................................................................................................ 180

Enable/Disable Code 39 ......................................................................................................... 180

Enable/Disable Trioptic Code 39 ............................................................................................. 180

Convert Code 39 to Code 32 .................................................................................................. 181

Code 32 Prefix ........................................................................................................................ 182

Set Lengths for Code 39 ......................................................................................................... 183

Code 39 Check Digit Verification ............................................................................................ 184

Transmit Code 39 Check Digit ................................................................................................ 184

Code 39 Full ASCII Conversion .............................................................................................. 185

Code 39 Security Level ........................................................................................................... 186

Code 39 Reduced Quiet Zone ................................................................................................ 187

Code 39 Buffering - Scan & Store ........................................................................................... 187

Code 93 ........................................................................................................................................ 190

Enable/Disable Code 93 ......................................................................................................... 190

Set Lengths for Code 93 ......................................................................................................... 190

Code 11 ........................................................................................................................................ 192

Code 11 ................................................................................................................................... 192

Set Lengths for Code 11 ......................................................................................................... 192

Code 11 Check Digit Verification ............................................................................................ 194

Transmit Code 11 Check Digits .............................................................................................. 195

Interleaved 2 of 5 (ITF) ................................................................................................................. 196

Enable/Disable Interleaved 2 of 5 ........................................................................................... 196

Set Lengths for Interleaved 2 of 5 ........................................................................................... 197

I 2 of 5 Check Digit Verification ............................................................................................... 199

Transmit I 2 of 5 Check Digit ................................................................................................... 200

Convert I 2 of 5 to EAN-13 ...................................................................................................... 200

I 2 of 5 Security Level .............................................................................................................. 201

I 2 of 5 Reduced Quiet Zone ................................................................................................... 202

Discrete 2 of 5 (DTF) .................................................................................................................... 203

Enable/Disable Discrete 2 of 5 ................................................................................................ 203

Set Lengths for Discrete 2 of 5 ................................................................................................ 204

Codabar (NW - 7) .......................................................................................................................... 206

Enable/Disable Codabar ......................................................................................................... 206

Set Lengths for Codabar ......................................................................................................... 206

CLSI Editing ............................................................................................................................ 208

NOTIS Editing ......................................................................................................................... 208

Codabar Upper or Lower Case Start/Stop Characters Detection ........................................... 209

Codabar Mod 16 Check Digit Verification ............................................................................... 209

MSI ................................................................................................................................................ 210

Enable/Disable MSI ................................................................................................................. 210

Set Lengths for MSI ................................................................................................................ 210

MSI Check Digits ..................................................................................................................... 212

Transmit MSI Check Digit(s) ................................................................................................... 212

MSI Check Digit Algorithm ...................................................................................................... 214

Chinese 2 of 5 ............................................................................................................................... 215

Enable/Disable Chinese 2 of 5 ................................................................................................ 215

Matrix 2 of 5 .................................................................................................................................. 216

Enable/Disable Matrix 2 of 5 ................................................................................................... 216

Set Lengths for Matrix 2 of 5 ................................................................................................... 216

Table of Contents

Matrix 2 of 5 Check Digit ......................................................................................................... 218

Transmit Matrix 2 of 5 Check Digit .......................................................................................... 218

Korean 3 of 5 ................................................................................................................................ 219

Enable/Disable Korean 3 of 5 ................................................................................................. 219

Inverse 1D ..................................................................................................................................... 220

GS1 DataBar ................................................................................................................................. 221

GS1 DataBar-14 ...................................................................................................................... 221

GS1 DataBar Limited .............................................................................................................. 221

GS1 DataBar Expanded .......................................................................................................... 222

Convert GS1 DataBar to UPC/EAN ........................................................................................ 222

GS1 DataBar Limited Security Level ....................................................................................... 223

Composite ..................................................................................................................................... 224

Composite CC-C ..................................................................................................................... 224

Composite CC-A/B .................................................................................................................. 224

Composite TLC-39 .................................................................................................................. 225

UPC Composite Mode ............................................................................................................ 226

Composite Beep Mode ............................................................................................................ 227

GS1-128 Emulation Mode for UCC/EAN Composite Codes ................................................... 227

2D Symbologies ............................................................................................................................ 228

Enable/Disable PDF417 .......................................................................................................... 228

Enable/Disable MicroPDF417 ................................................................................................. 228

Code 128 Emulation ................................................................................................................ 229

Data Matrix .............................................................................................................................. 230

GS1 Data Matrix ...................................................................................................................... 230

Data Matrix Inverse ................................................................................................................. 231

Maxicode ................................................................................................................................. 231

QR Code ................................................................................................................................. 232

GS1 QR ................................................................................................................................... 232

MicroQR .................................................................................................................................. 233

Aztec ....................................................................................................................................... 233

Aztec Inverse .......................................................................................................................... 233

Han Xin ................................................................................................................................... 234

Han Xin Inverse ....................................................................................................................... 234

DotCode .................................................................................................................................. 236

DotCode Inverse ..................................................................................................................... 237

DotCode Mirrored ...

DotCode Prioritize ................................................................................................................... 239

ostal Codes ................................................................................................................................. 240

US Postnet .............................................................................................................................. 240

US Planet ................................................................................................................................ 240

Transmit US Postal Check Digit .............................................................................................. 241

UK Postal ................................................................................................................................ 241

Transmit UK Postal Check Digit .............................................................................................. 242

Japan Postal ........................................................................................................................... 242

Australia Post .......................................................................................................................... 243

Australia Post Format .............................................................................................................. 244

Netherlands KIX Code ........................................................................................................... 245

USPS 4CB/One Code/Intelligent Mail ..................................................................................... 245

UPU FICS Postal .................................................................................................................... 246

Mailmark .................................................................................................................................. 246

Canada Post ........................................................................................................................... 247

................................................................................................................. 238

Table of Contents

Posti LAPA 4-State Code ........................................................................................................ 247

Symbology-Specific Security Levels ............................................................................................. 248

Redundancy Level .................................................................................................................. 248

Security Level .......................................................................................................................... 250

1D Quiet Zone Level ............................................................................................................... 251

Intercharacter Gap Size .......................................................................................................... 252

Report Version .............................................................................................................................. 252

Macro PDF Features ..................................................................................................................... 253

Flush Macro Buffer .................................................................................................................. 253

Abort Macro PDF Entry ........................................................................................................... 253

Digimarc Barcode

Introduction ................................................................................................................................... 254

Digimarc Symbology ..................................................................................................................... 254

Picklist ..................................................................................................................................... 254

Digimarc Digital Watermarks ........................................................................................................ 255

Data Formatting: ADF, MDF, Preferred Symbol

Introduction ................................................................................................................................... 256

Advanced Data Formatting (ADF) ................................................................................................. 256

Multicode Data Formatting (Hand-held Mode Only) ..................................................................... 256

Programming a Scanner ......................................................................................................... 257

Preferred Symbol .......................................................................................................................... 257

OCR Programming

Introduction ................................................................................................................................... 258

OCR Programming Parameters .................................................................................................... 260

Enable/Disable OCR-A ........................................................................................................... 260

OCR-A Variant ........................................................................................................................ 261

Enable/Disable OCR-B ........................................................................................................... 263

OCR-B Variant ........................................................................................................................ 264

Enable/Disable MICR E13B .................................................................................................... 268

Enable/Disable US Currency Serial Number .......................................................................... 269

OCR Orientation ...................................................................................................................... 269

OCR Lines ............................................................................................................................... 271

OCR Minimum Characters ...................................................................................................... 271

OCR Maximum Characters ..................................................................................................... 272

OCR Subset ............................................................................................................................ 272

OCR Quiet Zone ..................................................................................................................... 273

OCR Template ........................................................................................................................ 274

OCR Check Digit Modulus ...................................................................................................... 283

OCR Check Digit Multiplier ..................................................................................................... 284

OCR Check Digit Validation .................................................................................................... 286

Inverse OCR ........................................................................................................................... 291

OCR Redundancy ................................................................................................................... 292

Table of Contents

Maintenance and Troubleshooting

Introduction ................................................................................................................................... 293

Maintenance ................................................................................................................................. 293

Battery Safety Guidelines ............................................................................................................. 293

Long Term Storage ....................................................................................................................... 294

Cleaning Instructions .................................................................................................................... 294

Approved Cleanser Active Ingredients .................................................................................... 294

Harmful Ingredients ................................................................................................................. 294

Cleaning Instructions ............................................................................................................... 294

Special Cleaning Notes ........................................................................................................... 294

Cleaning Materials Required ................................................................................................... 295

Cleaning Frequency ................................................................................................................ 295

Cleaning the RS5100 .............................................................................................................. 295

Cleaning Cradle Connectors ................................................................................................... 296

Cleaning the Finger Strap and Comfort Pad ........................................................................... 296

Comfort Pad Replacement ............................................................................................................ 297

Trigger Assembly Replacement .................................................................................................... 298

Finger Strap Replacement ............................................................................................................ 299

Troubleshooting ............................................................................................................................ 301

RS5100 ................................................................................................................................... 301

Cradles .................................................................................................................................... 302

Specifications

RS5100 Technical Specifications ................................................................................................. 303

Cradle Technical Specifications .................................................................................................... 306

4-Slot Charge Only Cradle Technical Specifications .............................................................. 306

8-Slot Battery Charger Technical Specifications ..................................................................... 306

Decode Distances ......................................................................................................................... 308

Standard Default Parameters

Standard Default Parameters Table ............................................................................................. 309

Programming Reference

Symbol Code Identifiers ................................................................................................................ 318

AIM Code Identifiers ..................................................................................................................... 319

Alphanumeric and Numeric Barcodes

Numeric Barcodes ........................................................................................................................ 324

Cancel ........................................................................................................................................... 325

Sample Barcodes

Code 39 ........................................................................................................................................ 343

UPC/EAN ...................................................................................................................................... 343

UPC-A, 100% .......................................................................................................................... 343

EAN-13, 100% ........................................................................................................................ 344

Code 128 ...................................................................................................................................... 344

Table of Contents

Interleaved 2 of 5 .......................................................................................................................... 344

GS1 DataBar-14 ........................................................................................................................... 344

PDF417 ......................................................................................................................................... 345

Data Matrix .................................................................................................................................... 345

Maxicode ....................................................................................................................................... 345

QR Code ....................................................................................................................................... 346

US Postnet .................................................................................................................................... 346

UK Postal ...................................................................................................................................... 346

Country Codes

Introduction ................................................................................................................................... 347

Country Keyboard Types (Country Codes) ................................................................................... 348

Country Code Pages

Introduction ................................................................................................................................... 363

Country Code Page Defaults ........................................................................................................ 363

Country Code Page Barcodes ...................................................................................................... 367

CKJ Decode Control

Introduction ................................................................................................................................... 376

CJK Control Parameters ............................................................................................................... 377

Unicode Output Control ........................................................................................................... 377

CJK Output Method to Windows Host ..................................................................................... 378

Non-CJK UTF Barcode Output ............................................................................................... 380

Unicode/CJK Decode Setup with Windows Host .......................................................................... 382

Setting Up the Windows Registry Table for Unicode Universal Output .................................. 382

Adding CJK IME on Windows ................................................................................................. 382

Selecting the Simplified Chinese Input Method on the Host ................................................... 383

Selecting the Traditional Chinese Input Method on the Host .................................................. 384

ASCII Character Sets

RSM Attributes

Attributes for Querying Scanner Information ................................................................................. 395

Index

About This Guide

Introduction

The RS5100 Ring Scanner, also referred to as the Bluetooth Ring Scanner, is a wearable barcode scan solution for both 1D and 2D barcode symbologies. The RS5100 is also compatible with a wide range of mobile computers communicating over Bluetooth.

The RS5100 Product Reference Guide provides additional information that is not covered by the Quick Start Guide and is helpful for application developers and customers alike.

This Product Reference Guide provides information on operating the RS5100 for the first time, using the RS5100, resetting and capturing data.

The guide also covers issues such as charging and testing the RS5100 battery, troubleshooting, maintenance, firmware update and configuration of the RS5100. Sample barcodes are provided for configuring and testing the RS5100.

Notational Conventions

The following conventions are used in this document:

• Bold text is used to highlight the following:

• Dialog box, window and screen names

• Drop-down list and list box names

• Check box and radio button names

• Icons on a screen

• Key names on a keypad

• Button names on a screen.

• Bullets (•) indicate:

• Action items

• Lists of alternatives

• Lists of required steps that are not necessarily sequential.

• Sequential lists (e.g., those that describe step-by-step procedures) appear as numbered lists.

Service Information

If you have a problem with your equipment, contact Customer Support for your region. Contact information is available at: zebra.com/support.

When contacting support, please have the following information available:

• Serial number of the unit (found on manufacturing label)

• Model number or product name (found on manufacturing label)

• Software type and version number

The following information should be available when reporting a problem:

• Customer name

• Application used

• Configuration

• RS5100 or Cradle version number

• See Retrieving the RS5100 Log File on page 110 to retrieve and E-mail the RS5100 log to the support

representative

• Occurrence (always, once out of 10 attempts, etc…)

• Suggested steps to reproduce the problem

About This Guide

Customer Support responds to calls by email or telephone within the time limits set forth in support agreements.

If the problem cannot be solved by Customer Support, you may need to return your equipment for servicing and will be given specific directions. We are not responsible for any damages incurred during shipment if the approved shipping container is not used. Shipping the units improperly can possibly void the warranty.

If the device was purchased from a business partner, contact that business partner for support.

Getting Started

Introduction

This chapter describes the features of the RS5100 Ring Scanner and explains how to install and charge the battery, capture data and reset the RS5100.

Unpacking

Carefully remove all protective material from around the equipment and save the shipping container for later storage and shipping.

After opening the shipping box, inspect the contents. You should have received the following:

• RS5100

• Battery

• Regulatory Guide

• Optional Trigger Mount Screw in a separate bag.

Inspect the equipment for damage. If you are missing any equipment or if you find any damaged equipment, contact Support immediately. See Service Information on page 14 for contact information.

Configuration Features

Figure 1 RS5100 Single Trigger Configuration Features

Getting Started

Top Scan Trigger

NFC Icon

Imager Window

Charging Pads for Cradles

Trigger Assembly

System LED

Battery Release Latch

System LED

Restore Key

Side Scan Trigger

Battery

Strap Buckle

Comfort Pad

Finger Strap

Getting Started

Figure 2 RS5100 Double Trigger Configuration Features

Top Scan Trigger

NFC Icon

Imager Window

Charging Pads for Cradles

Trigger Assembly

System LED

Battery Release Latch

System LED

Restore Key

USB Slot

(Not available on all

configurations)

Side Scan Trigger

Battery

USB Slot

(Not available on all

configurations)

Status Indications

The RS5100 has System notification LEDs on the back of the device to display system and decode status and a System LED on the top of the device to display Bluetooth and battery status. The RS5100 is also equipped with a beeper that issues different beep sequences and patterns to indicate status. The System LEDs provide identical indications for ambidextrous usage.

Table 1 defines the System LED and beep sequence indications that occur to indicate status.

Table 1 System LED Indications

LED Type LED Indication Beep Indication Description

Standard Use

System Green Low/Medium/High Device is powered on.

Scanning Indications

System Green single flash High A barcode has been decoded

Finger Straps

Getting Started

Table 1 System LED Indications (Continued)

LED Type LED Indication Beep Indication Description

System Red 4x Low Transmission error.

System Red 5x Low Conversion or format error.

System Red Low/High/Low/High Out of batch memory storage. Unable to

store a new barcode.

Radio Indications

System Red/Green blinking 6x Short High Device in paging state.

System Blue double blink High/low Bluetooth communication is disconnected.

System Blue slow blinking None Attempting to reconnect over Bluetooth.

System None Low/high Bluetooth connection established.

System None Long low/ long high Bluetooth connection attempt failed.

System Blue during beep

sequence

System Blue slow blinking 5x High Attempting to reconnect over Bluetooth

System Blue blinking 3x Short high Bluetooth disconnect indication (disabled by

Battery Indications

System Red 4x Short high Low battery indicator.

System Green/Amber/Red N/A Battery charge level indication (hold trigger

System Red blinking N/A Over temperature or bad battery.

Parameter Programing

Long low/ long high/ Long low/ long high

Bluetooth connection attempt is rejected.

(disabled by default).

default).

for three seconds to activate).

Green is more than 50%

Amber is between 20% and 49%

Red is less than 20%

NOTE: The LED lights up for 3 seconds on the first scan after rebooting the scanner to show battery charge level indication.

System Red Long low/long high

beeps

System Green High/low beeps Keyboard parameter selected. Enter value

System Green High/low/high/low beeps Successful program exit with change in the

Input error, incorrect barcode or Cancel scanned,

wrong entry, incorrect barcode programming

sequence; remain in program mode.

using barcode keypad.

parameter setting.

Table 1 System LED Indications (Continued)

LED Type LED Indication Beep Indication Description

Maintenance Indications

System Green slow blinking Scanner connected to 123Scan2.

System Red fast blinking File being transferred to the scanner (new

System Red slow blinking Firmware installation.

System Green Programing completed successfully

RS5100 Activity Modes

The RS5100 is capable of three modes of activity:

Getting Started

configuration parameters or firmware) via 123Scan2.

(parameters change or firmware updated) via 123Scan2.

• Run Mode – The RS5100 is scanning or transferring data using Bluetooth.

• Low Power Mode – The RS5100 enters Standby mode (Low Power Mode) when it is idle for more than

one second. The RS5100 wakes-up and returns to busy (run) mode upon at least one of the following

events:

• Scan trigger

• Bluetooth activity

• NFC field detected

• Press of the Restore key

• Insert into charging slot

• OFF Mode – The RS5100 is not connected to a power source.

Configurations

The RS5100 can be worn with a Single Trigger Assembly or Double Trigger Assembly.

NOTE: After installing a different type of trigger, reboot the RS5100 to recognize the new trigger.

Single Trigger Assembly - Change Trigger Position

The RS5100 is worn on the index finger, and triggered with the thumb. The Trigger Assembly of the RS5100 is removable to provide left-hand or right-hand use.

To change the position of the trigger:

1. Determine whether the RS5100 is used on the right or left hand and rotate the trigger assembly accordingly, so

that the Scan Trigger is positioned next to the thumb when the RS5100 is placed on the index finger.

Getting Started

2. Push the Trigger Assembly latch in, while lifting the Trigger Assembly away from the RS5100. Find the side

with the arrow on the comfort pad, noting where the yellow latch is.

Figure 3 Push Trigger Assembly Latch In and Lift

Trigger Assembly Latch

Yellow Arrow

3. Lift the Trigger Assembly off of the RS5100.

Figure 4 Lift Trigger Assembly Off RS5100

4. Rotate the Trigger Assembly so the Scan Trigger is positioned next to the thumb when the RS5100 is placed

on the index finger.

5. Align one end of the Trigger Assembly on the RS5100 and push the other end down until it snaps into place.

Figure 5 Align Trigger Assembly and Snap Into Place

NOTE: An optional Trigger Mount screw is included in the packaging and can be used with a Phillips screwdriver

to secure the Trigger Mount when it does not need to be removed or rotated. On the single trigger, the hole for

the Trigger Mount screw is under the comfort pad, while on the double trigger the hole is visible from the outside.

Figure 6 Location of Trigger Mount Screw

Getting Started

Single Trigger

Double Trigger

Double Trigger Assembly

The double trigger assembly comes in the following 3 configurations:

• Standard

• USB-C

• Vibrator

The USB-C port on the assembly allows the RS5100 to be charged via a USB cable and also allows for programming using 123Scan.

Charge the Battery

Before using the RS5100, charge the battery. To charge the RS5100 battery, refer to Accessories.

Install the Battery

1. Align the battery on top of the RS5100 and insert into the battery compartment.

Figure 7 Install the Battery

Battery Release Latch

Battery

2. Slide the battery all the way into the locking slot of the RS5100.

3. Firmly press the battery into the RS5100 until a click is heard ensuring the battery release latch is fully

engaged with the RS5100.

Getting Started

NOTE: Brand new batteries from the factory are shipped in Ship Mode for protection, and need to be plugged

into a charger (cradle or battery toaster) to activate the battery.

Remove the Battery

1. Push the battery release latch down until the latch pops up.

Figure 8 Release Battery

2. Slide the battery out of the battery compartment.

Figure 9 Remove the Battery

Mounting the RS5100

1. Slide the RS5100 onto the index finger with the Scan Trigger next to the thumb.

Figure 10 Slide RS5100 onto Index Finger

Getting Started

Scan Trigger

Single Trigger

2. To tighten the Finger Strap on the Single Trigger, pull the end of the strap through the Strap Buckle. To loosen

the Finger Strap, lift the Strap Buckle away from the Finger Strap while pulling the strap through the Strap Buckle. Release the Strap Buckle to hold the Finger Strap in place.

Figure 11 Adjust Finger Strap

Finger Strap

Strap Buckle

Double Trigger

Scan Trigger

Powering On

To power on the device:

1. Install the battery (if not already installed).

NOTE: Brand new batteries from the factory are shipped in Ship Mode for protection, and need to be plugged

into a charger (cradle or battery toaster) to activate the battery.

2. Press one of the following:

• side scan trigger on the single trigger

• left side scan trigger on the double trigger

• scan trigger on the lanyard

• scan trigger on the back of hand mount.

Bluetooth Connection

The RS5100 sends decoded barcode data to Zebra mobile computers and other devices using Bluetooth. Before using, connect the RS5100 to a device using Bluetooth. See Bluetooth Communications for configuration.

Scanning

The RS5100 uses digital camera technology to take an image of a barcode and software decoding algorithms are executed to extract the barcode data from the image.

RS5100 Scanning with SE4710

To scan a barcode:

1. Launch a scanning application.

2. Press the Scan Trigger and aim the device at a barcode.

3. Adjust the position of the device so that the orange aiming dot appears at the center of the barcode.

Ensure the barcode is within the area formed by the aiming pattern. The aiming dot is used for increased visibility in bright lighting conditions.

The Status LED illuminates red. Upon successful decode, the Status LED changes from red to green and an audible beep sounds.

Getting Started

NOTE: When the device is in Picklist Mode, the imager does not decode the barcode until the crosshair or

aiming dot touches the barcode.

4. Release the Scan Trigger.

The barcode data displays on the screen.

RS5100 Scanning with SE4770

To scan a barcode:

1. Launch a scanning application.

2. Press the Scan Trigger and aim the device at the barcode.

3. Adjust the position of the device so that the red laser cross-hair appears at the center of the barcode.

4. The status LED illuminates red. Upon successful decode, the status LED changes from red to green and an

audible beep sounds.

NOTE: In some configurations proper decoding of a barcode is indicated by the software application running on

the mobile computer.

Aiming the RS5100

The aiming pattern of the RS5100 is a cross hair laser beam with bright center dot (see Figure 12). The virtual rectangle made by the cross hair reflects the field of view of the RS5100. The aiming pattern is used to position the barcode within the field of view.

Getting Started

012345

Figure 12 Cross Hair Laser Beam

Cross hair laser beam

Virtual rectangle made by the cross hair laser beam

Enter the symbol in any orientation within the virtual rectangle made by the cross hair laser beam, making use of its omnidirectional reading capability within the entire field of view.

Figure 13 Barcode Scan Orientation

1D Barcode

Barcodes

Aiming pattern Pattern

2D Barcode

The RS5100 can also read a barcode presented within the aiming pattern but not centered (see the top barcodes on Figure 14). The barcodes marked with X in Figure 14, however, show barcode aiming that may result in no decode.

When using the application on your mobile computer in “Pick List” mode, the Bright Center Dot can be positioned anywhere on the symbol (see Figure 12). The top examples in Figure 14 show acceptable aiming options, while the bottom examples can not be decoded.

Figure 14 Acceptable Aiming Options

The aiming pattern is smaller when the RS5100 is closer to the symbol and larger when it is farther from the barcode. Scan barcodes with smaller bars or elements (mil size) closer to the RS5100 and those with larger bars or elements (mil size) farther from the RS5100.

1. Position the RS5100 between two and eleven inches from the barcode (depending on the barcode density).

NOTE: When a barcode is under transparent plastic or on a mobile computer screen, it is recommended to use

a tilt (pitch) or skew scan angle to minimize reflection.

2. Aim the cross hair laser beam to cover the barcode. The RS5100 takes a digital picture (image) of the barcode

and stores it in memory for decoding.

The Scan LED flashes green and a high beep sounds indicating that the barcode was properly decoded.

Resetting the RS5100

If the RS5100 stops responding to input, reset it. There are three reset functions, warm boot, cold boot and clean boot. Perform a warm boot first. If the RS5100 still does not respond, perform a cold boot. Perform clean boot to restore the RS5100 to its factory default configuration.

Warm Boot

To perform warm boot, press and hold the Restore Key for more than three seconds and then release. The RS5100 resets when the key is released.

Getting Started

NOTE: A warm boot should be performed to reset the RS5100 after scanning the configuration barcodes.

Cold Boot

Cold boot restores the RS5100 operation by performing a power cycle of the device. To perform cold boot, remove and re-insert the battery into the RS5100.

Clean Boot

Clean Boot restores the RS5100 to its factory default configuration.

To perform clean boot:

1. Make sure the battery is inserted and the scanner is turned on.

2. Press and hold the Restore Key until the System LED turns on white.

3. Release the Restore Key and immediately press and hold the Restore Key.

4. Continue to hold the Restore Key until two beeps indicating a Clean Boot are heard and the scanner boot beep

sequence is heard. The RS5100 is now in its factory default configuration.

123Scan and Software Tools

Introduction

This chapter briefly describes the Zebra software tools available for customizing scanner operation.

123Scan

123Scan is a software tool that simplifies scanner setup and more.

Intuitive enough for first time users, the 123Scan wizard guides users through a streamlined setup process. Settings are saved in a configuration file that can be printed as a single programming barcode for scanning, emailed to a smart phone for scanning from its screen, or downloaded to the scanner using a USB cable.

Through 123Scan a user can:

• Configure a scanner using a wizard.

• Program the following scanner settings.

• Speaker tone / volume settings.

• Enable / disable symbologies.

• Communication settings.

• Modify data before transmission to a host using:

• Advanced Data Formatting (ADF) - Scan one barcode per trigger pull.

• Multicode Data Formatting (MDF) - Scan many barcodes in one trigger pull (select scanners).

• Preferred Symbol - Single out one barcode on label of many (select scanners).

• Load parameter settings to a scanner via the following.

• Barcode scanning.

• Scan a paper barcode.

• Scan a barcode from a PC screen.

• Scan a barcode from a smart phone screen.

• Download over a USB cable.

• Load settings to one scanner.

• Validate scanner setup.

• Review settings using the Parameter Report.

• Clone settings from an already deployed scanner from the Start screen.

123Scan and Software Tools

• Upgrade scanner firmware.

• Load settings to one scanner.

• View statistics such as:

• Asset tracking information.

• Time and usage information.

• Barcodes scanned by symbology.

• Battery diagnostics (select scanners).

• Generate the following reports.

• Barcode Report - Programming barcode, included parameter settings, and supported scanner models.

• Parameter Report - Parameters programmed within a configuration file.

• Inventory Report - Scanner asset tracking information.

• Statistics Report - All statistics retrieved from the scanner.

NOTE: Data view is not supported.

For more information go to: www.zebra.com/123Scan

Communication with 123Scan

Use a USB cable to connect the scanner to a Windows host computer running 123Scan.

123Scan Requirements

• Host computer running Windows XP, 7, 8, and 10

• Scanner

• USB cable.

123Scan Information

For more information on123Scan, go to: www.zebra.com/123Scan.

For a 1 minute tour of 123Scan, go to: www.zebra.com/ScannerHowToVideos

To see a list of all of our software tools, go to: www.zebra.com/scannersoftware

Scanner SDK, Other Software Tools, and Videos

Tackle all your scanner programming needs with our diversified set of software tools. Whether you need to simply

stage a device, or develop a fully featured application with data capture as well as asset management,

these tools help you every step of the way.

To download any of the following free tools, go to: www.zebra.com/scannersoftware

• 123Scan configuration utility

123Scan and Software Tools

• SDKs

• Scanner SDK for Windows

• Scanner SDK for Android

• Scanner SDK for iOS

• Drivers

• OPOS driver (supported over Bluetooth only)

• USB CDC driver

NOTE: Video and SMS are not supported.

• Mobile Apps

• Scan-To-Connect Utility

• Android

• iOS

• Windows

• Zebra AppGallery

• How-To-Videos

Bluetooth Communications

Introduction

This chapter provides information about the modes of operation and features available for wireless communication between the RS5100 and hosts. The chapter also includes the parameters necessary to configure the RS5100.

The RS5100 ships with the settings shown in the Bluetooth Communication Defaults on page 31 (also see

Standard Default Parameters for all host device and miscellaneous RS5100 defaults). If the default values suit user

requirements, programming is not necessary.

To set feature values, scan a single barcode or a short barcode sequence. The settings are stored in non-volatile memory and are preserved even when the RS5100 is powered down.

To return all features to default values, scan a default barcode in Default Parameters on page 116. Throughout the programming barcode menus, default values are indicated with asterisks (

*Enable Parameter

(1)

Scanning Sequence Examples

In most cases, scan one barcode to set a specific parameter value.

Errors While Scanning

Unless otherwise specified, to correct an error during a scanning sequence, just re-scan the correct parameter.

Bluetooth Communications Parameter Defaults

*).

Feature/option* Indicates default

Option value

Table 2 lists the defaults for Bluetooth radio communication parameters. If you wish to change any option, scan the

appropriate barcode(s)

Bluetooth Communications

NOTE: See Standard Default Parameters for all user preferences, hosts, symbologies, and miscellaneous

default parameters.

In this guide, the parameter numbers listed are the same as the attribure numbers for these parameters.

See Country Codes for Country Keyboard Types (Country Codes).

Table 2 Bluetooth Communication Defaults

Parameter

Number

Default

Bluetooth Communications Host Types SSI Bluetooth Classic

Default BT Friendly Name 1701 Disable 65

Discoverable Mode 610 General 66

Wi-Fi Friendly Mode Disable 68

Wi-Fi Friendly Channel Exclusion Use All Channels 69

Radio Output Power 1324 Class 2 70

Link Supervision Timeout 1698 2 Seconds 71

HID Features for Apple iOS 1114 Disable 37

HID Keyboard Keystroke Delay No Delay (0 msec) 37

HID CAPS Lock Override Disable 39

HID Ignore Unknown Characters Enable 40

Emulate Keypad Disable 40

Fast HID Keyboard 1361 Enable 41

Page

Number

Quick Keypad Emulation 1362 Enable 42

Keyboard FN1 Substitution Disable 42

Function Key Mapping Disable 43

Simulated Caps Lock Disable 43

Convert Case No Case Conversion 44

Beep on Reconnect Attempt 559 Disable 73

Reconnect Attempt Interval 558 30 sec 73

Auto-reconnect 604 Auto-reconnect

Immediately

Beep on Insertion 288 Enable 118

Beep on <BEL> 150 Enable 59

Toggle Pairing 1322 Disable 75

Force Pairing Save 795 Enable 76

Bluetooth Communications

Table 2 Bluetooth Communication Defaults (Continued)

Parameter

Auto Un-Pairing 1708 Disable 76

Batch Mode 544 Normal (Do Not Batch

Unique Identifier Disable 80

PIN Code (Set and Store) 552 12345 66

Variable Pin Code 608 Static

Bluetooth Security Levels 1393 Low 67

Bluetooth Status Indications

When the RS5100 is pairing or re-establishing a connection to a computer, it issues various beep sequences indicating successful or unsuccessful operations. See Status Indications on page 17 for all beep sequences and LED displays including those which occur during pairing operations.

Parameter

Number

Default

Data)

(Default PIN code is

12345)

Page

Number

Bluetooth Connection Modes

The RS5100 can connect to a host computer using the following Bluetooth modes:

• Human Interface Device (HID)

• Simple Serial Interface (SSI)

• Serial Port Profile (SPP).

NOTE: Once the RS5100 is paired to a Zebra host device, the scanning software will disable the ability to read

the configuration barcodes.

Keyboard Emulation

The Bluetooth Human Interface Device (HID) profile enables the RS5100 to emulate a Bluetooth keyboard input device and connect to a host computer. The RS5100 supports two versions of the Bluetooth HID profile.

HID Bluetooth Classic

Enables the RS5100 to communicate using Bluetooth HID profile to a host computer through Bluetooth Classic radio. The RS5100 is capable of operating in Peripheral (discoverable) or Central mode.

HID Bluetooth Low Energy (Discoverable)

Enables the RS5100 to communicate using Bluetooth HID profile to a host computer through Bluetooth Low Energy radio. The RS5100 operates in Peripheral (discoverable) mode when BT HID Low Energy is enabled.

Bluetooth Communications

Low Energy (LE) Bluetooth has a smaller RF footprint (bandwidth) than Classic Bluetooth. The smaller RF footprint of LE Bluetooth significantly improves Wi-Fi co-existence. Due to its smaller RF bandwidth, LE Bluetooth is up to seven times slower than Classic Bluetooth (0.27 Mbps versus 0.7-2.1 Mbps). Data intensive activities such as firmware updates, can take significantly longer.

NOTE: Not all host devices support Bluetooth Low Energy. Verify that your device supports Bluetooth Low

Energy mode before attempting to connect to the RS5100.

HID Bluetooth Barcodes

HID Bluetooth Classic

HID Bluetooth Low Energy

HID Setup

HID Bluetooth Connection to iOS/iPad/iPhone

1. Perform clean boot. See Clean Boot on page 26

2. Scan the appropriate HID Bluetooth Barcode from Table .

3. Perform a Cold Boot by removing and re-installing the battery onto the RS5100. The RS5100 starts to operate

and is discoverable as a keyboard.

4. Select Settings > General > Bluetooth.

5. Turn Bluetooth ON.

6. Select Bluetooth Settings

RS5100 - xxxxxx, where xxxxxx is the serial number.

HID Bluetooth Connection to Android

1. Perform clean boot. See Clean Boot on page 26

2. Scan the appropriate HID Bluetooth Barcode from Table .

3. Perform a Cold Boot by removing and re-installing the battery onto the RS5100. The RS5100 starts to operate

and is discoverable as a keyboard.

4. Select Settings > Wireless & Networks > Bluetooth

5. Turn Bluetooth ON.

6. Select Bluetooth Settings

RS5100 - xxxxxx, where xxxxxx is the serial number.

and choose RS5100 from the list of discovered devices. The RS5100 displays as

Bluetooth Communications

IMPORTANT: Some devices may require scanning a PIN to connect. If so, a PIN displays on the device. To

enter the required PIN, scan the barcode, Variable PIN Code on page 67 then re-attempt connection. When a

beep sounds, indicating the RS5100 is waiting for PIN entry, scan the PIN using the Alphanumeric and Numeric

Barcodes on page 324. Incorrect scanned entries can be deleted by scanning Cancel on page 325.

For more information, see Variable PIN Code on page 67.

HID Bluetooth Connection to Windows 7 or 8

NOTE: For best user experience, it is recommend using Secure Simple Pairing (SSP). Windows 7 SP1 supports

Bluetooth 2.1 and as such, supports SSP. SSP reduces the number of steps to minimal or none when compared to legacy Bluetooth pairing.

If the host computer does not include an integrated Bluetooth module, use a USB Bluetooth dongle. Use off-the-shelf dongle that supports Bluetooth v2.1 for effortless pairing in SSP.

To pair and connect the RS5100:

1. Perform clean boot. See Clean Boot on page 26

2. Scan the HID Bluetooth Classic barcode from page Table .

3. Perform a Cold Boot by removing and re-installing the battery onto the RS5100. The RS5100 starts to operate

and is discoverable as a keyboard.

4. Right click on Bluetooth icon and select Add a Device (Windows 7) or Add a Bluetooth Device (Windows 8).

Figure 15 HID - Adding a Device - Windows

5. From the Add a device screen, select the RS5100 (shown as Bluetooth Keyboard) and click Next.

Bluetooth Communications

Figure 16 HID - Add Device Screen - Windows

Windows 7

Windows 8

The computer connects to the RS5100 and the following screen displays.

Figure 17 HID - Device Successfully Added Screen - Windows

Windows 7

Windows 8

Demonstrating HID Connection

Following a successful connection, data can be scanned into any Windows, iOS or Android application field that accepts keyboard data; for example, in Windows, the Notepad application.

To scan a barcode:

1. Open the Notepad application.

2. Click in the text area.

3. Scan a barcode. The scanned barcode information displays on the Notepad window.

Bluetooth Communications

Figure 18 HID - Scanned Barcode Information On Notepad Window

Bluetooth Communications

HID Options

The RS5100 supports virtual keyboard emulation for the Apple iOS, and keyboard emulation over the Bluetooth HID profile. In this mode the RS5100 can interact with Bluetooth enabled hosts supporting the HID profile as a Bluetooth keyboard. Scanned data is transmitted to the host as keystrokes.

HID Features for Apple iOS

Parameter # 1114

This option works with Apple iOS devices to enable the opening and closing of the iOS virtual keyboard by pressing the Restore key.

NOTE: When this feature is enabled, the RS5100 may be incompatible with non-Apple iOS devices.

*Disable

(0)

Enable

(1)

HID Keyboard Keystroke Delay

This parameter sets the delay, in milliseconds, between emulated keystrokes. Scan a barcode below to increase the delay when the HID host requires a slower transmission of data.

*No Delay (0 msec)

Bluetooth Communications

Long Delay (40 msec)

Medium Delay (20 msec)

Bluetooth Communications

HID CAPS Lock Override

When enabled, the case of the data is preserved regardless of the state of the caps lock key. This setting is always enabled for the “Japanese, Windows (ASCII)” keyboard type and can not be disabled.

*Do Not Override Caps Lock Key

(Disable)

Override Caps Lock Key

(Enable)

Bluetooth Communications

HID Ignore Unknown Characters

This option applies only to the HID Keyboard Emulation device and IBM device. Unknown characters are characters the host does not recognize. When Send Barcodes With Unknown Characters is selected, all barcode data is sent except for unknown characters, and no error beeps sound. When Do Not Send Barcodes With Unknown Characters is selected, barcode data is sent up to the first unknown character, then the RS5100 issues an error beep.

*Send Barcodes With Unknown Characters

(Enable)

Do Not Send Barcodes With Unknown Characters

(Disable)

Emulate Keypad

When enabled, all characters are sent as ASCII sequences over the numeric keypad. For example, ASCII A is sent as "ALT make" 0 6 5 "ALT Break."

*Enable Numeric Keypad Emulation

Disable Numeric Keypad Emulation

Bluetooth Communications

Fast HID Keyboard

Parameter # 1361

This option transmits Bluetooth HID keyboard data at a faster rate.

Fast HID Disable

*Fast HID Enable

Bluetooth Communications

Quick Keypad Emulation

Parameter # 1362

NOTE: This option applies only to a HID Keyboard Emulation Device which has Emulate Keypad enabled (see

Emulate Keypad on page 40).

This parameter enables a quicker method of keypad emulation where ASCII sequences are only sent for ASCII characters not found on the keyboard.

Quick Keypad Emulation Disable

*Quick Keypad Emulation Enable

HID Keyboard FN1 Substitution

When enabled, this parameter allows replacement of any FN1 character in an EAN128 barcode with a Key Category and value chosen by the user. See FN1 Substitution Values on page 140 to set the Key Category and Key Value.

*Disable Keyboard FN1 Substitution

Enable Keyboard FN1 Substitution

Bluetooth Communications

HID Function Key Mapping

ASCII values under 32 are normally sent as control-key sequences. When this parameter is enabled, the keys in bold are sent in place of the standard key mapping (see ASCII Character Sets).

Table entries that do not have a bold entry remain the same whether or not this parameter is enabled.

*Disable Function Key Mapping

Enable Function Key Mapping

Simulated Caps Lock

When enabled, the RS5100 inverts upper and lower case characters on the RS5100 barcode as if the Caps Lock state is enabled on the keyboard. This inversion is done regardless of the current state of the keyboard Caps Lock state.

*Disable Simulated Caps Lock

Enable Simulated Caps Lock

Bluetooth Communications

Convert Case

When enabled, the RS5100 converts all barcode data to the selected case.

*No Case Conversion

Convert All to Upper Case

Convert All to LowerCase

Bluetooth Communications

Country Keyboard Type Change

While in HID mode, the RS5100 supports several keyboard layouts.

To change the North American Standard Keyboards layout to a different country code layout, scan the required barcode corresponding to the country keyboard type. See Country Codes for country keyboard types.

Bluetooth Communications

Simple Serial Interface (SSI)

Select this host type when connecting to a Zebra mobile device or PC/tablet/phone running a Zebra scanner SDK app.

SSI Bluetooth Classic (Non-discoverable)

This enables the scanner(s) to establish a connection with a Zebra mobile computer over a Bluetooth Classic radio. The scanner is NOT discoverable (Central mode).

To establish a connection (initial setup only), scan the SSI BT Classic (Non-discoverable) barcode, and then scan a pairing barcode with the host device's MAC address.

NOTE: Additional steps may be necessary depending on host's Bluetooth stack.

SSI Bluetooth Classic (Discoverable)

This enables communication with Scanner SDK for Android generated apps, and allows the host to establish a connection with the scanner over Bluetooth Classic radio. The scanner is discoverable (Peripheral mode).

To establish a connection (initial setup only), scan the SSI Bluetooth Classic (Discoverable) barcode. From the host, discover Bluetooth devices and select the scanner from the discovered device list.

SSI Bluetooth Low Energy

This enables communication with Scanner SDK for iOS generated apps, and allows the host to establish a connection with the scanner over Bluetooth Low Energy radio. The scanner is discoverable (Peripheral mode).

To establish a connection (initial setup only), scan the SSI Bluetooth Low Energy barcode. From the host application, select the scanner from the discovered device list.

Bluetooth Communications

SSI Bluetooth Classic (Non-discoverable)

SSI Bluetooth Classic (Discoverable)

SSI Bluetooth Low Energy

SSI Setup

SSI Bluetooth Connection using NFC

The RS5100 is NFC enabled and supports Bluetooth Tap-to-Pair.

To connect with a WT6000:

1. Check that NFC is enabled on the WT6000.

2. Align the NFC icon of the RS5100 with the NFC icon on the WT6000.

The Status LED blinks blue, indicating that the RS5100 is attempting to establish connection with the WT6000. When connection is established, the Status LED turns off and the RS5100 emits a single string of low/high beeps.

Figure 19 Touch NFC Antennas

NFC Logo

Bluetooth Communications

NOTE: Not all Zebra device support NFC readers and the Tap-to-Pair feature.

SSI Bluetooth Connection using Scan2Pair

To pair the RS5100 with the WT6000 using SSI:

1. On the WT6000, touch > . The Bluetooth Pairing Utility opens.

Figure 20 Bluetooth Pairing Utility

2. Using the RS5100, scan the barcode on the screen.

The Status LED blinks blue indicating that the RS5100 is attempting to establish connection with the WT6000. When connection is established, the Status LED turns off and the RS5100 emits a single string of low/high beeps.

3. On the WT6000, touch the triangle button to return to the main screen.

SSI Bluetooth Connection using STB3678 cradle

For information on STB3678 cradle configuration and usage refer to the DS36x8 user guide.

Bluetooth Communications

To pair the RS5100 with a STB3678 cradle:

1. Connect the STB3678 cradle to the host computer.

2. Using the RS5100, scan the pairing barcode on the STB3678 cradle.

The Status LED blinks blue indicating that the RS5100 is attempting to establish a connection with the

STB3678. When the connection is established, the Status LED turns off and the RS5100 emits a single string

of low/high beeps.

NOTE: Before pairing the RS5100 with a different device, perform clean boot. See Clean Boot on page 26.

Point-to-Point Communication

In Point-to-Point communication mode, the cradle allows one digital scanner to connect to it at a time. In this mode, the digital scanner is paired to the cradle by scanning the PAIR barcode. Communication can be locked, unlocked (default), or in a lock override state. In locked mode, locking intervals must be set by scanning a connection maintenance interval barcode.

Pairing Modes

When operating with the cradle, two modes of pairing are supported:

Locked Pairing Mode - When a cradle is paired (connected) to the digital scanner, any attempt to connect a different digital scanner by scanning the PAIR barcode on the cradle is rejected. The currently connected digital scanner(s) maintain connection. In this mode, you must set a Connection Maintenance Interval.

Unlocked Pairing Mode - Unlocking works in Point-to-Point mode only. Pair (connect) a new digital scanner to a cradle at any time by either scanning the PAIR barcode on the cradle. This unpairs the previous digital scanner from the cradle.

Lock Override

Lock Override overrides a locked digital scanner base pairing and connects a new digital scanner.

Bluetooth Communications

Host Trigger Event Mode

Parameter #790

RS5100 is compatible with the STB3678 cradle and apps that utilize Zebra Scanner SDK, as well as Zebra host terminals apps that use EMDK. However, appropriate host trigger event mode has to be selected when partnering with those devices. RS5100 selects appropriate mode automatically, based on the pairing barcode, but it can be also manually set in case an appropriate pairing barcode is not used.

Use Host Trigger Event disabled mode for pairing with STB3678 cradle or Zebra Scanner SDK apps and utilities running on Windows, Android, or Apple iOS.

*Host Trigger Event Mode Enabled

Host Trigger Event Mode Disabled

Serial Port Profile

Select this host type when connecting to a PC/tablet/phone using a Bluetooth serial connection.

SPP BT Classic (Non-discoverable)

This enables the scanner to establish an SPP connection with the host over Bluetooth Classic radio. The scanner is not discoverable (Central mode).

To establish a connection (initial setup only), scan the SPP BT Classic (Non-discoverable) barcode, and then scan a pairing barcode with the MAC address of the host device.

SPP BT Classic (Discoverable)

This enables the host to establish an SPP connection with the scanner over Bluetooth Classic radio. The scanner is discoverable (Peripheral mode).

To establish a connection (initial setup only), scan the SPP BT Classic (Discoverable) barcode. From the host, discover Bluetooth devices and select the scanner from the discovered device list.

Bluetooth Communications

SPP Bluetooth Classic (Non-discoverable)

SPP Bluetooth Classic (Discoverable)

NOTE: Since the SPP connection does not support automatic acknowledgment when the data is received by the

computer application, a BELL indication is used. The BELL indication allows the computer application to send single binary character 0x07 to the RS5100 (as defined in ASCII table). Upon receiving the BELL character, the RS5100 beeps. To configure the beep, see Bell

Indication Control on page 59.

SPP Setup

SPP Bluetooth Connection to Windows 7 or 8 as Central

1. Perform clean boot. See Clean Boot on page 26.

2. Scan the SPP Bluetooth Classic (Non-Discoverable) barcode.

3. Perform a Cold Boot by removing and re-installing the battery onto the RS5100. The RS5100 starts to operate

and is discoverable as a Bluetooth serial device.

4. Right click on the Bluetooth icon and select Open Setting to add a COM port

Bluetooth Communications

Figure 21 .SPP - Open Setting Screen - Windows

5. Select the COM Ports tab and click Add.

Figure 22

6. Select the Incoming radio button and click OK.

SPP - Bluetooth Settings - Com Ports Tab

Bluetooth Communications

Figure 23 SPP - Bluetooth Settings - Add Com Port Screen

7. Click the Hardware tab.

8. Click the Properties button.

9. Click the Advanced tab to retrieve the Bluetooth radio BD address in the Address field.

10. Click OK.

Figure 24 SPP - Bluetooth Settings - Bluetooth Radio BD Address

11. Run the PC Tool application.

Bluetooth Communications

Figure 25 SPP - PC Tool application

12. Click the Show Bluetooth Address barcode button.

13. Manually enter the BD address to the PC Tool application and click the Generate button.

Figure 26 SPP - PC Tool Application - Barcode Generator

14. Click Close.

15. Open the incoming COM port assigned (for example, COM7) in the application. After the COM port is opened

the computer connects to the RS5100 and a beep will sound. For demonstration, refer to General Bluetooth

Options on page 65.

NOTE: If the COM port is not opened prior to the connection, the RS5100 will fail to connect.

Bluetooth Communications

16. To start the connection process aim the RS5100 at about 7" (18 cm) away from the computer screen and scan

the barcode of the BD address of the computer (or the other target device).

The RS5100 Scan LEDs start flashing green indicating that the RS5100 is attempting to establish connection with the computer. The following notifications display upon successful connection.

Figure 27 SPP - Device Successfully Added Screen

Windows 7

NOTE: In case you do not hear the connected beep on the RS5100, press the RS5100 Restore key to connect.

Windows 8

SPP Bluetooth Connection to Windows 7 or 8 as Peripheral

1. Perform clean boot. See Clean Boot on page 26.

2. Scan the SPP Bluetooth Classic (discoverable) barcode.

3. Perform a Cold Boot by removing and re-installing the battery onto the RS5100. The RS5100 starts to operate

and is discoverable as a Bluetooth serial device.

4. Right click the Bluetooth icon and select Add a Device (Windows 7) or Add a Bluetooth Device (Windows 8).

Bluetooth Communications

Figure 28 SPP connection with RS5100 as a Peripheral - Open Settings

5. Select the RS5100 (see Bluetooth Camera icon below) and click Next

Figure 29 SPP connection with RS5100 as a Peripheral - Add Device Screen

Windows 7

6. The computer attempts to connect to the RS5100

Figure 30

SPP connection with RS5100 as a Peripheral - Device Successfully Added Screen

Windows 7

Windows 8

Bluetooth Communications



7. Open the incoming COM port assigned (for example, COM7) in the application. After the COM port is opened

the computer connects to the RS5100 and a beep will sound. For demonstration, refer to General Bluetooth

Options on page 65.

NOTE: Make sure the same COM port is closed in other applications.

How to Demonstrate SPP Connection with a Computer

Once SPP connection is established, an application is required to demonstrate the RS5100.

To scan a barcode:

1. If the RS5100 is still connected to the PC Tool application, close the COM port on the PC Tool application.

2. Run a hyper terminal application such as the Tera Term application. (ayera.com/teraterm/download.cfm).

Figure 31 Tera Term Application Screen

3. Select the virtual COM port set for the RS5100 connection.

4. Scan barcodes. Successful decoding of a barcode is indicated by one green flash of the Scan LEDs and a

high beep sound. In case of Bluetooth disconnection, the RS5100 emits one high beep followed by four low beeps.

Bluetooth Communications

Figure 32 Tera Term Entry Screen

Special characters

SPP mode supports special characters that trigger actions when sent from the computer.

Table 3 Special Characters

Character ASCII Action

BELL 0x07 If Bell Indication is enabled,

performs the configured Bell Indication.

Serial 0x73 Sends the serial number of the

RS5100.

Image Capture Mode 0x69 Activates Image Capture mode.

Custom notification 1 0x79 Performs custom notification

sequence 1.

Custom notification 2 0x63 Performs custom notification

sequence 2.

Scanner enable 0x65 Enables scanner.

Scanner disable 0x64 Disables scanner.

Bluetooth Communications

Beep on BELL Character

Parameter # 150

When this parameter is enabled, the RS5100 issues a beep when a <BEL> character is received over the SPP connection to the host device.

NOTE: This parameter only applies to SPP (Serial Port Profile).

*Beep on <BEL> Enable

Beep on <BEL> Disable

Bell Indication Control

The BELL Indication Control parameter configures the beep tone sequence of the bell indication when a BELL character is received. This feature is valid only in SPP mode for PC connection.

GP_1_HI_SHORT

GP_2_HI_SHORT

GP_3_HI_SHORT

Bluetooth Communications

GP_4_HI_SHORT

GP_5_HI_SHORT

GP_2_LO_SHORT

GP_1_LO_SHORT

GP_3_LO_SHORT

GP_4_LO_SHORT

GP_1_HI_LONG

Bluetooth Communications

GP_5_LO_SHORT

GP_3_HI_LONG

GP_5_HI_LONG

GP_2_HI_LONG

GP_4_HI_LONG

GP_1_LO_LONG

GP_2_LO_LONG

Bluetooth Communications

GP_3_LO_LONG

GP_4_LO_LONG

GP_FAST_WARBLE

GP_5_LO_LONG

GP_SLOW_WARBLE

GP_HI_LO

GP_HI_LO_HI

Bluetooth Communications

GP_LO_HI

GP_HI_HI_LO_LO

APP_CLICK

GP_LO_HI_LO

APP_ERROR_BEEP

LOW_CLICK

Bluetooth Communications

General Bluetooth Options

Default Bluetooth Friendly Name

Parameter # 1701

Select default Bluetooth Friendly Name.

• Select RS5100 for pairing with Host device, in SSI mode, that supports RS5100. The Friendly Name

becomes RS5100 <serial number>.

• Select RS5100 and RS6000 for pairing with old Host device, in SSI mode, that does not support RS5100.

The Friendly Name becomes RS5100 <serial number> (RS6000 compatible)

NOTE: When you change this parameter, the RS5100 needs to be rebooted.

NOTE: If RS5100 is already paired to a Host device in 'RS5100' mode that doesn't have RS5100 support, then

after you change the parameter to 'RS5100 and RS6000' mode, you need to reboot the Host device and pair

again before it can function properly.

Bluetooth Communications

*RS5100

(0)

Discoverable Mode

Parameter # 610

Select a discoverable mode based on the device initiating discovery:

• Select General Discoverable Mode when initiating connection from a PC.

• Select Limited Discoverable Mode when initiating connection from a PC or mobile device, and the

RS5100 does not appear in General Discoverable Mode. Note that it can take longer to discover the

device in this mode.

RS5100 and RS6000

(1)

Bluetooth Communications

The RS5100 remains in Limited Discoverable Mode for 30 seconds, and the blue LED flashes while in this

mode. It is then non-discoverable. To re-activate Limited Discoverable Mode, press the trigger.

*General Discoverable Mode

(0)

Limited Discoverable Mode

(1)

Bluetooth Security

The RS5100 supports Bluetooth authentication. Authentication can be requested by either the remote device or the RS5100.

NOTE: A remote device can still request authentication.

PIN Code

Parameter # 552

NOTE: The default PIN code is 12345.

To set and store a PIN code (e.g., password) on the RS5100 to connect to the host:

1. Scan the Set & Store PIN Code barcode below.

2. Scan five alphanumeric programming barcodes using the alphanumeric barcodes beginning on page 324.

3. Scan End of Message on page 332.

If the RS5100 communicates with a remote device with security enabled, synchronize the PIN codes on the RS5100 and remote device. To achieve this, connect the RS5100 to the host when setting the PIN codes. If the RS5100 is not connected to a host, the PIN code change only takes affect on the RS5100. If is required between the RS5100 and host, and the PIN codes do not match, pairing fails.

NOTE: An extended 16 character PIN code is available for additional security with Open Bluetooth

(SPP and HID).

Bluetooth Communications

Set and Store PIN Code

Variable PIN Code

Parameter # 608

When connecting to a host device with authentication enabled, scan Static PIN Code below to avoid entering the PIN code manually. The PIN stored in memory is used. Scan the Variable PIN Code below to manually enter a PIN code with each connection.

The default PIN code is the user-programmed PIN set and stored above. Typically, however, HID connections require entering a Variable PIN Code. If, when attempting connection, the application presents a text box that includes a PIN, scan the Variable PIN Code barcode, then re-attempt connection. When you hear a beep indicating the RS5100 is waiting for an alphanumeric entry, enter the provided variable PIN using the Alphanumeric

and Numeric Barcodes on page 324, then scan End of Message on page 332 if the code is less than 16

characters. The RS5100 discards the variable PIN code after connection.

*Static PIN Code

(0)

Variable PIN Code

(1)

Bluetooth Security Levels

Parameter # 1393

• Low Bluetooth Security - The low security setting is designed for ease of connection with most devices.

This setting may be unacceptable to some devices. If connection fails, try re-connecting after increasing

security setting on the RS5100.

If connecting to Bluetooth 2.1 device and above, Just Works method for secure and simple pairing is used

NOTE: Data is encrypted using the Low Bluetooth security setting if connected to a Bluetooth 2.1 and above

device.

• Medium Bluetooth Security - The medium security setting may require a passkey for the initial

connection to pair RS5100 and device.

If connecting to Bluetooth 2.1 device and above,

used.

Passkey Entry

method for secure and simple pairing is

Bluetooth Communications

• High Bluetooth Security - The high security setting enables

2.1 and above. Not all devices are able to support this mode.

Man in the Middle

protection for Bluetooth

• Legacy Bluetooth Security (Bluetooth 2.0 and below) - The legacy security setting enables

authentication and encryption for legacy pairing.

*Low Bluetooth Security

Medium Bluetooth Security

High Bluetooth Security

Wi-Fi Friendly Mode

Scanners configured for Wi-Fi friendly mode behave as follows:

• The RS5100 remains in sniff mode, and exits sniff mode only during firmware update.

• If any Wi-Fi channel is excluded from the hopping sequence, AFH turns off.

• RS5100 avoid the selected Wi-Fi channels after establishing connection.

Notes

• If using this feature, configure all RS5100 in the area for Wi-Fi friendly mode.

• By default, no Wi-Fi channels are excluded.

• Since Bluetooth requires a minimum of 20 channels when Wi-Fi channels 1, 6, and 11 are excluded,

a smaller number of channels are cut from the hopping sequence.

• Updating Wi-Fi friendly settings before Bluetooth connection is recommended.

Legacy Bluetooth Security

Bluetooth Communications

Scan a barcode below to enable or disable Wi-Fi Friendly Mode, then see Wi-Fi Friendly Channel Exclusion to select any channels to exclude.

*Disable Wi-Fi Friendly Mode

Enable Wi-Fi Friendly Mode

Wi-Fi Friendly Channel Exclusion

Select the channels to exclude:

• Exclude Wi-Fi channel 1: Bluetooth channels 0-21 are excluded from hopping sequence

(2402-2423 MHz).

• Exclude Wi-Fi channel 6: Bluetooth channels 25-46 are excluded from hopping sequence

(2427 - 2448 MHz).

• Exclude Wi-Fi channel 11: Bluetooth channels 50-71 are excluded from hopping sequence

(2452 - 2473 MHz).

• Exclude Wi-Fi channel 1, 6 and 11: Bluetooth channels 2-19 (2404-2421 MHz),

26-45 (2428 - 2447 MHz) and 51-69 (2453 - 2471 MHz) are excluded from hopping sequence.

• Exclude Wi-Fi channels 1 and 6: Bluetooth channels 0-21 (2402-2423 MHz) and 25-46

(2427 - 2448 MHz) are excluded from hopping sequence.

• Exclude Wi-Fi channels 1 and 11: Bluetooth channels 0-21 (2402-2423 MHz) and 50-71

(2452 - 2473 MHz) are excluded from hopping sequence.

• Exclude Wi-Fi channel 6 and 11: Bluetooth channels 25-46 (2427 - 2448 MHz) and 50-71

(2452 - 2473 MHz) are excluded from hopping sequence.

*Use All Channels (Standard AFH)

Exclude Wi-Fi Channel 1

Bluetooth Communications

Exclude Wi-Fi Channel 6

Exclude Wi-Fi Channels 1, 6, and 11

Exclude Wi-Fi Channel 11

Exclude Wi-Fi Channels 1 and 11

Exclude Wi-Fi Channels 6 and 11

Radio Output Power

Parameter # 1324

RS5100 uses a configurable radio which can be configured to operate in:

• Low power mode as a Class 2 device

• High power mode as Class 1 device.

Exclude Wi-Fi Channels 1 and 6

Bluetooth Communications

Increase the radio output power to increase range. Scan a barcode to select the desired power mode.

*Class 2 (Low Power)

Class 1 (High Power)

Link Supervision Timeout

Parameter # 1698

Link supervision timeout controls how quickly the RS5100 senses that the Bluetooth radio lost connection to the remote device. A lower value helps prevent data loss at the edge of the operating range while a larger value helps prevent disconnects due to the remote device not responding in time. If you are experiencing occasional disconnects and the RS5100 is able to reconnect, increase the link supervision timeout value.

NOTE: The RS5100 only controls Link Supervision Timeout in Central mode.

0.5 Seconds

*2 Seconds

5 Seconds

Bluetooth Communications

10 Seconds

20 Seconds

Reconnecting

When in SPP Central, SSI Bluetooth Classic, and Bluetooth HID, the RS5100 automatically tries to reconnect to a remote device when a disconnection occurs that is due to the radio losing communication. This can happen if the RS5100 goes out of range with the remote device, or if the remote device powers down. The RS5100 initiates auto-reconnect based the Auto-Reconnect setting. The duration of the auto-reconnect attempt is specified by the Reconnect Attempt Interval setting. During reconnection, the Status LED blinks blue.

If the auto-reconnect process fails due to:

• Page Time-Outs - The RS5100 sounds a page timeout beep (long low/long high) and enters low power

mode.

• Connection Attempt Rejected - The RS5100 sounds a connection reject beep sequence (see Status

Indications on page 17) and enters low power mode.

NOTE: If a barcode is scanned while the auto-reconnect sequence is in process, a transmission error beep

sequence sounds and the data is not transmitted to the host. After a connection is reestablished, normal

scanning operation returns.

Switching between Bluetooth host types by scanning a host type barcode causes the radio to be reset. Scanning

is disabled during this time. It takes several seconds for the RS5100 to re-initialize the radio at which time

scanning is enabled.

Restore Lost Bluetooth Connection

If the auto-reconnect process fails and times out, the Bluetooth connection is re-established as follows:

1. Ensure that the RS5100 is within a range of 10 meters (30 feet) from the mobile computer.

2. Ensure that the mobile computer is on and “awake” (not in Suspend mode).

3. Briefly press the Restore Key on the RS5100 to initiate the reconnect process.

4. The Status LED starts flashing blue indicating that the RS5100 is attempting to establish connection with a

mobile computer. The Status LED turns off and the RS5100 emits one string of low/high beeps indicating that the RS5100 is connected and ready for scanning.

Bluetooth Communications

Reconnect Attempt Beep Feedback

Parameter # 559

When the RS5100 disconnects as it goes out of range, it immediately attempts to reconnect. While the RS5100 attempts to reconnect, the Status LED continues to blink blue. If the auto-reconnect process fails, the RS5100 emits a page timeout beep (long low/long high) and the Status LED stops blinking. The process can be restarted by pulling the trigger or pressing the restore key.

The Beep on Reconnect Attempt feature is disabled by default. When enabled, the RS5100 emits five short high beeps every five seconds while the re-connection attempt is in progress. Scan a barcode below to enable or disable Beep on Reconnect Attempt.

*Disable Beep on Reconnect Attempt

(0)

Enable Beep on Reconnect Attempt

(1)

Reconnect Attempt Interval

Parameter # 558

When a RS5100 disconnects as it goes out of range, it immediately attempts to reconnect for the default time interval of 30 seconds. This time interval can be changed to one of the options below.

To set the Reconnect Attempt Interval, scan one of the barcodes below.

*Attempt to Reconnect for 30 Seconds

(6)

Attempt to Reconnect for 1 Minute

(12)

Bluetooth Communications

Attempt to Reconnect for 5 Minutes

(60)

Attempt to Reconnect for 30 Minutes

(360)

Attempt to Reconnect for 1 Hour

(720)

Attempt to Reconnect Indefinitely

(0)

Auto-reconnect

Parameter # 604

In Bluetooth Keyboard Emulation (HID) mode, SPP Central, and SSI Bluetooth Classic, select a re-connect option for when the RS5100 loses its connection with a remote device:

• Auto-reconnect on Barcode Data: The RS5100 auto-reconnects when you scan a barcode. With this

option, a delay can occur when transmitting the first characters. The RS5100 sounds a decode beep upon

barcode scan, followed by a connection, a page timeout, a rejection beep, or a transmission error beep.

Select this option to optimize battery life on the RS5100 and mobile device. Note that auto-reconnect does

not occur on rejection commands.

• Auto-reconnect Immediately: When the RS5100 loses connection, it attempts to reconnect. If a page

timeout occurs, the RS5100 attempts reconnect by pulling the trigger or pressing the restore key. Select

this option if the RS5100 battery life is not an issue and you do not want a delay to occur when the first

barcode is transmitted. Note that auto-reconnect does not occur on rejection commands.

Bluetooth Communications

• Disable Auto-reconnect: When the RS5100 loses connection, you must re-establish it manually.

Auto-reconnect on Barcode Data

(1)

*Auto-reconnect Immediately

(2)

Disable Auto-reconnect

(0)

Pairing Support

Toggle Pairing

Parameter # 1322

If the RS5100 is configured for Toggle Pairing, scanning a pairing barcode a second time will unpair the scanner.

*Toggle Pairing Disable

Toggle Pairing Enable

Bluetooth Communications

Force Pairing Save

The Force Pairing Save parameter enables/disables saving the remote Bluetooth address after each Bluetooth connection attempt.

When this parameter is disabled, the Bluetooth address is saved only after a successful Bluetooth connection. If the Bluetooth connection fails, the Bluetooth address is not saved.

NOTE: This parameter is effective when the RS5100 connects as Central.

Disable

*Enable

Auto Un-Pairing

Parameter # 1708

The auto un-pair parameter configures the RS5100 to un-pair from the host computer on specific events.

• Disable (default) - the RS5100 will not auto un-pair on any events.

• On cradle insertion - the RS5100 will un-pair when inserted charging cradle

• On reset - the RS5100 will un-pair if a warm or cold reset occurs

• On cradle or reset - the RS5100 will un-pair on cradle insertion or reset event.

*Disable

Un-pair on Cradle Insertion

Bluetooth Communications

On Reset

On Cradle or Reset

Pairing Barcode Format

When pairing the RS5100 to certain host devices in SSI Bluetooth Classic, SPP Bluetooth Central or Bluetooth HID, it is necessary to create a pairing barcode. The RS5100 scans the pairing barcode and initiates the connection to the host computer. To create a pairing barcode label, the Bluetooth address of the remote device must be known (refer to the mobile computer user guide).

Pairing barcodes are Code 128 or Data Matrix symbologies formatted as follows:

<Fnc 3>Bxxxxxxxxxxxx

where:

• B (or LNKB) is the prefix

• xxxxxxxxxxxx represents the 12-character Bluetooth address.

Pairing Barcode Example

If the mobile computer Bluetooth address is 11:22:33:44:55:66, then the pairing barcode is:

Paring Barcode Content:

‘B’ + Bluetooth Address

Figure 33 Creating a Pairing Bluetooth Barcode

B112233445566

Unpairing

Unpair the RS5100 from the host computer to make the host computer available for pairing with another RS5100. Scan the barcode below to disconnect the RS5100 from its host computer.

Unpairing

Bluetooth Communications

Batch Mode

Parameter # 544

IMPORTANT: Batch mode only applies for HID and SPP Central Mode.

The RS5100 supports five versions of batch mode. When the RS5100 is configured for any of the batch modes, it attempts to store barcode data (not parameter barcodes) until transmission is initialized, or the maximum number of barcodes are stored. When a barcode is saved successfully, a good decode beep sounds and the LED flashes green. If the RS5100 is unable to store a new barcode, a low/high/low/high out of memory beep sounds. (See page

17 for all beeper and LED definitions.)

In all modes, calculate the amount of data (number of barcodes) the RS5100 can store as follows:

Number of storable barcodes = 9,000 bytes of memory / (number of characters in the barcode + 3).

NOTE: If the batch mode selection is changed while there is batched data, the new batch mode takes

effect only after all the previously batched data is sent

Modes of Operation

• Normal (default) - Do not batch data. The RS5100 attempts to transmit every scanned barcode.

• Out of Range Batch Mode - The RS5100 starts storing barcode data when it loses its connection to a

remote device (for example, when a user holding the RS5100 walks out of range). Data transmission is

triggered by re-establishing the connection with the remote device (for example, when a user holding the

RS5100 walks back into range).

• Standard Batch Mode - The RS5100 starts storing barcode data after Enter Batch Mode is scanned.

Data transmission is triggered by scanning Send Batch Data.

NOTE: Transmission is halted if the connection to the remote device is lost.

In all modes, transmissions are halted if the RS5100 is moved out of range. The RS5100 resumes when it is back in range. If a barcode is scanned while batch data is transmitted it is appended to the end of the batched data; parameter barcodes are not stored.

*Normal

(00h)

Out of Range Batch Mode

(01h)

Standard Batch Mode

(02h)

Bluetooth Communications

Enter Batch Mode

Send Batch Data

Bluetooth Communications

Unique Identifier (SPP only)

When using Batch Mode, enable Unique Identifier to add the device serial number to each payload data sent in Batch Mode.

*Disable

Enable

Bluetooth Communications

Image Capture (SPP only)

Image Capture mode allows the RS5100 to capture an image and send the binary data over the SPP connection. The connected device uses the binary data, starting from the JPG signature (hex value image file in JPG format.

To use Image Capture mode:

1. Change the RS5100 to SPP mode. See Serial Port Profile on page 51.

2. Pair and connect the RS5100 to a device.

3. Enable Image Capture mode by sending the character i to the RS5100. See Special characters on page 58.

The cross hair laser beam illuminates, indicating that the RS5100 is ready to capture an image.

4. Press the Scan trigger.

After capturing an image the RS5100 performs the following in order:

FF D8 FF)

• Sends the data to the connected device

• Exits Image Capture mode

Returns to the previous barcode scanning mode.

, to create the

Accessories

Table 4 Accessories

Accessory Part Number Description

Cradles

4-Slot RS5100 Charge Only Cradle

20-Slot RS5100 Charge Only Cradle

WT6000 / RS5100 5 Slot Charge Only Sharecradle

TC5x / RS5100 5 Slot Charge Only Sharecradle

Batteries and Chargers

Replacement Standard Battery

CRD-RS51-4SCHG-01 Charges up to four devices with batteries. Requires

Power Supply PWR-BGA12V50W0WW, DC Line Cord CBL-DC-388A1-01 and Country Specific 3 wire AC Line Cord.

CRD-RS51-20SCHG-01 Charges up to twenty devices with batteries.

Requires Power Supply PWR-BGA12V50W0WW, DC Line Cord CBL-DC-388A1-01 and Country Specific 3 wire AC Line Cord.

CRD-4WT6-4RS51-01 WT6000 / RS5100 5 Slot Charge Only Sharecradle,

Allows Charging of 4 WT6000 Terminals, 4 WT6000 Spare Batteries and 4 RS5100 Ring Scanners.

CRD-4TC5-4RS51-01 TC5x / RS5100 5 Slot Charge Only Sharecradle,

Allows Charging of 4 TC5x Terminals and 4 RS5100 Ring Scanners.

BTRY-RS51-4MA-01 Replacement standard battery for RS5100 (single

pack).

BTRY-RS51-4MA-10 Replacement standard battery for RS5100 (ten

pack).

BTRY-RS51-4MA-CN Replacement standard battery for RS5100, China

only.

Replacement Standard Battery

Replacement Extended Battery

BTRY-RS51-4MA-02 Replacement standard battery for RS5100, India

and South Korea only.

BTRY-RS51-7MA-01 Replacement extended battery for RS5100 (single

pack).

Table 4 Accessories (Continued)

Accessory Part Number Description

Accessories

Replacement Extended Battery

8-Slot Battery Charger SAC-RS51-8SCHG-01 Charges up to eight spare batteries. Requires

40-Slot Battery Charger SAC-RS51-40SCHG-01 Charges up to forty spare batteries. Requires Power

Triggers and Soft Goods

Replacement Trigger Assembly

Replacement Finger Strap SG-RS51-STRPNY-10 RS5100 replacement Spare nylon finger straps for

Replacement Comfort Pad SG-RS51-CMPD-05 RS5100 replacement comfort pads, to be used with

BTRY-RS51-7MA-10 Replacement extended battery for RS5100 (ten

pack).

BTRY-RS51-7MA-02 Replacement extended battery for RS5100, India

and South Korea only.

Power Supply PWR-BGA12V50W0WW, DC Line Cord CBL-DC-388A1-01 and Country Specific 3 wire AC Line Cord.

Supply PWR-BGA12V50W0WW, DC Line Cord CBL-DC-388A1-01 and Country Specific 3 wire AC Line Cord.

SG-RS51-TRGSS-01 RS5100 replacement Single Sided Trigger. Includes

comfort pad and nylon strap.

single sided trigger (10-pack).

single sided trigger (5-pack).

Replacement Trigger Assembly - Double Trigger: Standard Charge Contacts

Replacement Trigger Assembly - Double Trigger: Standard Charge Contacts and Vibrator option

Replacement Trigger Assembly - Double Trigger: USB-C Charge Port

Back of Hand Adapter SG-RS51-BHMT-01 Back of Hand Mount, includes hand strap.

Replacement Hand Strap SG-RS51-BHSTP-01 Replacement strap for RS5100 back of hand mount.

SG-RS51-TRGDS-01 RS5100 replacement Double Sided Trigger.

Replacement straps for double trigger (SG-RS51-STRPDT-10).

SG-RS51-TRGDV-01 RS5100 replacement Double Sided Trigger with

vibrator.

Replacement straps for double trigger (SG-RS51-STRPDT-10).

SG-RS51-TRGDU-01 RS5100 replacement Double Sided Trigger with

USB-C.

USB-C port on assembly allows the RS5100 to be charged via a USB cable and also allows for programming using 123Scan.

Replacement straps for double trigger (SG-RS51-STRPDT-10).

Allows the RS5100 to be worn on the back of hand and provides a remote finger trigger.

One size fits all; ambidextrous.

Hand Mount - Left/Large

SG-RS51-HNMTLL-01 Hand Mount for RS5100, Left Hand Large, Includes

Frame, Trigger and Hand Wrap.

Table 4 Accessories (Continued)

Accessory Part Number Description

Accessories

Hand Mount - Left/Medium

Hand Mount - Left/Small

Hand Mount - Right/Large

Hand Mount Right/Medium

Hand Mount - Right/Small

Replacement Hand Wrap Left/Large

Replacement Hand Wrap Left/Medium

Replacement Hand Wrap Left/Small

Replacement Hand Wrap Right/Large

Replacement Hand Wrap Right/Medium

SG-RS51-HNMTLM-01

Hand Mount for RS5100, Left Hand Medium, Includes Frame, Trigger and Hand Wrap.

SG-RS51-HNMTLS-01 Hand Mount for RS5100, Left Hand Small, Includes

Frame, Trigger and Hand Wrap.

SG-RS51-HNMTRL-01 Hand Mount for RS5100, Right Hand Large,

Includes Frame, Trigger and Hand Wrap.

SG-RS51-HNMTRM-01 Hand Mount for RS5100, Right Hand Medium,

Includes Frame, Trigger and Hand Wrap.

SG-RS51-HNMTRS-01 Hand Mount for RS5100, Right Hand Small,

Includes Frame, Trigger and Hand Wrap.

SG-RS51-HNWPLL-01

SG-RS51-HNWPLM-01

SG-RS51-HNWPLS-01

Spare Hand Wrap for RS5100, Left Hand Large.

Spare Hand Wrap for RS5100, Left Hand Medium.

Spare Hand Wrap for RS5100, Left Hand Small.

SG-RS51-HNWPRL-01 Spare Hand Wrap for RS5100, Right Hand Large.

SG-RS51-HNWPRM-01

Spare Hand Wrap for RS5100, Right Hand Medium.

Replacement Hand Wrap Right/Small

Lanyard Trigger Assembly SG-RS51-LNYD-01 Allows the RS5100 to be worn around the neck or

Retractor with Magnetic Recoil for Lanyard Trigger Assembly

SG-RS51-HNWPRS-01 Spare Hand Wrap for RS5100, Right Hand Small.

hip.

Requires separate purchase of the retractor with magnetic recoil (SG-RS51-RLYD1-01) for neck or hip mounting.

SG-RS51-RLYD1-01 Allows RS5100 units with Lanyard Trigger Assembly

(SG-RS51-LNYD-01) to be worn around the neck or hip.

For use with RS51B0-LBLNWR, RS51B0-TBLNWR or SG-RS51-LNYD-01.

Charging

Use one of the accessories in the following table to charge the RS5100 and/or spare battery.

Table 5 Charging and Communication

Description Part Number

Accessories

Battery

(In Device)

Charging Communication

Battery Only

microUSB to

USB

Ethernet

4-Slot RS5100 Charge Only Cradle

20-Slot RS5100 Charge Only Cradle

8-Slot Battery Charger SAC-RS51-8SCHG-01 No Yes No No

40-Slot Battery Charger SAC-RS51-40SCHG-01 No Yes No No

CRD-RS51-4SCHG-01 Yes No No No

CRD-RS51-20SCHG-01 Yes No No No

Charging the RS5100

To Charge the RS5100:

1. Insert the RS5100 into the RS5100 charging slot with the scan window facing the charge contacts.

Figure 34 Insert RS5100 Single Trigger and Double Trigger into Cradle

2. Ensure that the RS5100 is properly seated in the charging slot.

NOTE: It is suggested to charge the RS5100 before doing a firmware update over Bluetooth.

Charging the Spare Battery

1. Insert a spare battery into the spare battery slot.

Figure 35 Insert Battery into Cradle

Accessories

2. Ensure the battery is seated properly. The Spare Battery Charging LED blinks indicating charging.

Battery Charging

The RS5100 Charging LED indicates the charging status of the battery in the RS5100 and the Spare Battery Charging LED indicates the charging status of the spare battery. See Table 6 on page 86.

NOTE: Brand new batteries from the factory are shipped in Ship Mode for protection, and need to be plugged into a charger

(cradle or battery toaster) to activate the battery.

Table 6 Charging LED Indicators

State Indication

Off The battery is not charging. The RS5100 or battery is not inserted correctly in the cradle or

connected to a power source. Cradle is not powered.

Solid Amber Battery is charging.

Solid Green Battery charging is complete.

Fast Blinking Red (2 blinks/second)

Charging error, e.g.:

- Battery temperature is too low or too high for charging.

- The battery has reached the charge cycle time-out period. Battery charging has gone on too long without completing a full charge cycle (typically eight hours).

Solid Red Unhealthy battery is charging or fully charged.

Charge batteries in temperatures from 5°C to 40°C (41°F to 105°F). The standard battery charges from 0% to 90% in less than two and a half hours at room temperature. The extended battery charges from 0% to 90% in less than three and a half hours at room temperature. When the charging temperature is from 5°C to 10°C (41°F to 50°F), the standard battery charges in less than five hours. When the charging temperature is between 5°C and 10°C (41°F to 50°F), the extended battery charges in less than six hours.

Accessories

The device and cradle monitor the battery temperature. Battery charging is only performed when the battery is within safe charging temperature limits. At higher temperatures (e.g. approximately +35 °C (+95 °F)) the device or charging cradle may for small periods of time alternately enable and disable battery charging to keep the battery at acceptable temperatures. This process may require additional time to complete a full charge cycle. The RS5100 or cradle indicate when charging is disabled due to abnormal temperatures via the Status LED.

Accessories

4-Slot RS5100 Charge Only Cradle

NOTE: Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page 293.

The 4-Slot RS5100 Charge Only Cradle:

• provides power for operating the RS5100.

• charges up to four batteries in the RS5100.

Figure 36 4-Slot RS5100 Charge Only Cradle

Figure 37 4-Slot RS5100 Charge Only Cradle Setup

RS5100 Charging Slots (4)

Power LED

8-Slot Battery Charger

NOTE: Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page 293.

The 8-Slot Battery Charger charges up to eight spare batteries.

Figure 38 8-Slot Battery Charger

Accessories

Battery Charging LED (8)

Figure 39 8-Slot Battery Charger Setup

Battery Charging Slot (8)

Power LED

Accessories

20-Slot RS5100 Charge Only Cradle

NOTE: Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page 293.

The 20-Slot RS5100 Charge Only Cradle:

• provides power for operating the RS5100.

• charges up to twenty batteries in the RS5100.

Figure 40 20-Slot RS5100 Charge Only Cradle

RS5100 Charging Slots (20)

Power LED

Accessories

Figure 41 20-Slot RS5100 Charge Only Cradle Setup

40-Slot Battery Charger

NOTE: Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page 293.

The 40-Slot Battery Charger charges up to forty spare batteries.

Figure 42 40-Slot Battery Charger

Accessories

Battery Charging LED (40)

Battery Charging Slot (40)

Power LED

Figure 43 40-Slot Battery Charger Setup

Accessories

Lanyard Mount

The lanyard mount is comprised of the lanyard trigger assembly, retractor, and lanyard. The lanyard trigger assembly allows the RS5100 to be worn around the neck or hip. It requires separate purchase of the retractor with magnetic recoil for neck or hip mounting.

Figure 44 Lanyard Mount

Lanyard

Retractor

Lanyard Trigger Assembly

To attach the lanyard trigger assembly and retractor to the RS5100:

1. Align the contacts on the RS5100 assembly with the contacts on the back of the lanyard trigger assembly and

slide the lanyard trigger assembly into the notch on the RS5100 assembly.

Accessories

Figure 45 Attach Lanyard Trigger Assembly

2. Push down on the lanyard trigger assembly to snap into place.

3. If using the retractor (optional), slide the hook on the bottom of the retractor into the top/front slot on the

lanyard trigger assembly and push the lanyard through the clasp on the top of the retractor.

Figure 46 Attach Lanyard With Retractor

Clasp

Hook

4. If you are not using the retractor, insert the lanyard through the top/front slot on the lanyard trigger assembly.

Accessories

Figure 47 Attach Lanyard Without Retractor

To remove the lanyard trigger assembly, slide the release latch and detach the lanyard trigger assembly from the RS5100 assembly.

Figure 48 Detach Lanyard Trigger

Release Latch

Back of Hand Mount

The Back of Hand Mount (which includes a hand strap), allows the RS5100 to be worn on the back of your hand and provides a remote finger trigger. It is one size to fit all and is ambidextrous.

To attach the back of hand mount, perform the following three steps:

1. Install the strap to the back of hand assembly (there is a difference for a right hand user and a left hand user)

2. Position the back of hand mount on the hand

3. Install the RS5100 onto the back of hand mount.

To install the strap to the back of hand assembly for a right hand user:

1. Hold the Y shape strap in one hand and the back of hand assembly in the other hand.

2. Slide one end of the strap with the snap through the top left slot on the back of hand assembly and snap into

place.

Accessories

Figure 49 Right Hand User: Snap Strap Into Place

3. Slide the other end of the strap with the snap through the bottom left slot on the back of hand assembly and

snap into place.

4. Slide the remaining long end of the strap with the velcro through the right center slot of the back of hand

assembly and velcro in place.

Figure 50 Right Hand User: Velcro Strap Into Place

To install the strap to the back of hand assembly for a left hand user:

1. Hold the Y shape strap in one hand and the back of hand assembly in the other hand.

2. Slide one end of the strap with the snap through the top right slot on the back of hand assembly and snap into

place.

Accessories

Figure 51 Left Hand User: Snap Strap Into Place

3. Slide the other end of the strap with the snap through the bottom right slot on the back of hand assembly and

snap into place.

4. Slide the remaining long end of the strap with the velcro through the left center slot of the back of hand

assembly and velcro in place.

Figure 52 Left Hand User: Velcro Strap Into Place

To position the back of hand mount on the hand:

1. Slide your hand through the strap, with your thumb through the smaller opening between the two snaps and

your remaining four fingers through the larger opening.

Figure 53 Slide Hand Through Strap

2. Adjust the velcro to a comfortable position.

Figure 54 Adjust Velcro

Accessories

3. Pull the finger trigger to place it over your index finger and slide the finger trigger down the index finger.

4. Rotate the finger trigger so that the trigger button is easy access to your thumb.

Figure 55 Position Finger Trigger

Accessories

To install the RS5100 onto the back of hand mount:

1. Align the contacts on the RS5100 assembly with the contacts on the back of hand mount and engage the slot

(located at the top of the RS5100 on the backside) on the RS5100 with the opening at the top of the back of hand mount.

Figure 56 Align and Engage RS5100

2. Push down on the RS5100 to snap into place.

Figure 57 Push Down To Snap In Place

To detach the RS5100 from the back of hand mount, press the release buttons on both sides of the back of hand mount using your thumb and middle finger, and lift the RS5100 off the back of hand mount using your index finger.

Figure 58 Detach RS5100 From Back of Hand Mount

Hand Mount Glove

The Hand Mount Glove allows the RS5100 to be worn on the back of your hand and provides a remote finger trigger. It comes in multiple sizes to fit all and is available for right-handed and left-handed users. You can distinguish the size by the color of the stitching on the glove.

Accessories

• Small = white

• Medium = black

• Large = blue

To attach the hand mount glove to the hand mount assembly, perform the following steps:

1. Install the glove to the back of hand assembly, if not already installed (note the position for right hand user or

left hand user).

2. Position the hand mount glove on the hand.

3. Install the RS5100 onto the back of hand mount, if not already installed.

Install Glove: Right Hand User

To install the glove to the back of hand assembly for a right hand user:

1. Insert the trigger cable and button through the trigger slot.

Figure 59 Insert Trigger Cable and Button

100

Zebra RS5100 Product Reference Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Copyright

Terms of Use

Revision History

About This Guide

Introduction

Notational Conventions

Service Information

Getting Started

Introduction

Unpacking

Configuration Features

Status Indications

RS5100 Activity Modes

Configurations

Single Trigger Assembly - Change Trigger Position

Double Trigger Assembly

Charge the Battery

Install the Battery

Remove the Battery

Mounting the RS5100

Bluetooth Connection

Scanning

RS5100 Scanning with SE4710

RS5100 Scanning with SE4770

Aiming the RS5100

Resetting the RS5100

Warm Boot

Cold Boot

Clean Boot

123Scan and Software Tools

Introduction

123Scan

Communication with 123Scan

123Scan Requirements

123Scan Information

Scanner SDK, Other Software Tools, and Videos

Bluetooth Communications

Introduction

Scanning Sequence Examples

Errors While Scanning

Bluetooth Communications Parameter Defaults

Bluetooth Status Indications

Bluetooth Connection Modes

Keyboard Emulation

HID Bluetooth Classic

HID Bluetooth Low Energy (Discoverable)

HID Bluetooth Barcodes

HID Setup

HID Bluetooth Connection to iOS/iPad/iPhone

HID Bluetooth Connection to Android

HID Bluetooth Connection to Windows 7 or 8

Demonstrating HID Connection

HID Options

HID Features for Apple iOS

HID Keyboard Keystroke Delay

Emulate Keypad

Fast HID Keyboard

HID Keyboard FN1 Substitution

Simulated Caps Lock

Convert Case

Simple Serial Interface (SSI)

SSI Bluetooth Classic (Non-discoverable)

SSI Bluetooth Classic (Discoverable)

SSI Bluetooth Low Energy

SSI Setup

SSI Bluetooth Connection using NFC

SSI Bluetooth Connection using Scan2Pair

SSI Bluetooth Connection using STB3678 cradle

Serial Port Profile

SPP BT Classic (Non-discoverable)

SPP BT Classic (Discoverable)

SPP Setup

SPP Bluetooth Connection to Windows 7 or 8 as Peripheral

How to Demonstrate SPP Connection with a Computer

Special characters

Beep on BELL Character
