RFD8500 USER GUIDE
RFD8500
USER GUIDE
MN002065A06
Revision A
January 2020
ii RFD8500 User Guide
No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means,
without permission in writing from Zebra. This includes electronic or mechanical means, such as photo copying,
recording, or information storage and retrieval systems. The material in this manual is subject to change
without notice.
The software is provided strictly on an “as is” basis. All software, including firmware, furnished to the user is on
a licensed basis. Zebra grants to the user a non-transferable and non-exclusive license to use each software
or firmware program delivered hereunder (licensed program) . Except as n oted below, such licen se may not b e
assigned, sublicensed, or otherwise tran sfe rr e d by th e user without prior written consent of Zebra. No right to
copy a licensed program in whole or in part is granted, except as permitted under copyright law. The user shall
not modify , merge, or incorporate any for m or portion of a licensed program with other pro gram material, create
a derivative work from a licensed program , or us e a li censed program in a network without written permission
from Zebra. The user agrees to maintain Zebra’s copyright notice on the licensed programs delivered
hereunder , and to include the same on any au thorized copies it m akes, in whole or in part. The user agrees not
to decompile, disassemble, decode, or reverse engineer any licensed program delivered to the user or any
portion thereof.
Zebra reserves the right to make changes to any software or product to improve reliability, function, or design.
Zebra does not assume any product liability arising out of, or in connection with, the application or use of any
product, circuit, or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise under any Zebra Technologies
Corporation, intellectual property rights. An implied license only exists for equipment, circuits, and su bsystems
contained in Zebra products.
Warranty
For the complete Zebra hardware product warranty statement, go to:
http://www.zebra.com/warranty
.
Revision History
Changes to the original manual are listed below:
Change Date Description
-01 Rev A 10/2015 Initial Release
-02 Rev A 3/2016 Correct definition for Auto Reconnect Reader on page 3-10.
-03 Rev A 9/2016 Updates for Rev C software.
-04 Rev A 12/2016 Updates for Rev D software.
iii
-05 Rev A 11/2019
-06 Rev A 11/2019
Added cautionary statement to Charging the Battery in the Reader.
Updated copyright statement.
Removed Zebra RFID Mobile Application for Android chapter.
iv RFD8500 User Guide
TABLE OF CONTENTS
Warranty ......................................................................................................................................... ii
Revision History.............................................................................................................................. iii
About This Guide
Introduction..................................................................................................................................... ix
Related Documents ........................................................................................................................ ix
Configurations................................................................................................................................. x
Chapter Descriptions ...................................................................................................................... xi
Notational Conventions................................................................................................................... xii
Service Information......................................................................................................................... xii
Chapter 1: GETTING STARTED
Introduction .................................................................................................................................... 1-1
Unpacking ...................................................................................................................................... 1-1
RFD8500 Features ........................................................................................................................ 1-2
Setting Up the RFD8500 ................................................................................................................ 1-4
Installing the Battery ................................................................................................................ 1-4
Removing the Battery .............................................................................................................. 1-7
Mounting a Mobile Device on the RFD8500 .................................................................................. 1-8
Installing the Lanyard ..................................................................................................................... 1-9
Charging ........................................................................................................................................ 1-10
Charging the Battery in the Reader ......................................................................................... 1-10
Charging the Mobile Device Battery ........................................................................................ 1-11
Charging Temperature ............................................................................................................. 1-11
Battery Management ...................................................................................................................... 1-11
Low Battery Notification ........................................................................................................... 1-11
Battery Optimization ................................................................................................................. 1-11
Downloading Application Software ................................................................................................ 1-12
123RFID Mobile Application for Android .................................................................................. 1-12
Requirements .................................................................................................................... 1-12
Installing the Software ....................................................................................................... 1-12
Zebra RFID Mobile Application for iOS .................................................................................... 1-12
Requirements .................................................................................................................... 1-12
Installing the Software ....................................................................................................... 1-12
vi RFD8500 User Guide
Chapter 2: USING the RFD8500
Introduction .................................................................................................................................... 2-1
Using the Features on the RFD8500 ............................................................................................. 2-1
Using Buttons and the Scan Trigger ........................................................................................ 2-1
LED and Beeper Indicators ...................................................................................................... 2-2
Bluetooth® Wireless Technology Connections .............................................................................. 2-3
Adaptive Frequency Hopping ................................................................................................... 2-4
Security .................................................................................................................................... 2-4
Pairing ............................................................................................................................................ 2-5
Conventional Bluetooth Pairing Method ................................................................................... 2-5
Pairing with an Android Device ......................................................................................... 2-5
Pairing with an iOS Device ............................................................................................... 2-6
Pairing with a Windows Mobile Device ............................................................................. 2-6
Using the Locate Device Bar Code ................................................................................... 2-7
Reading Tags ................................................................................................................................ 2-8
Scanning Bar Codes ...................................................................................................................... 2-8
Transferring Data ........................................................................................................................... 2-9
Transferring Data in Batch Mode ............................................................................................. 2-9
Transferring Data via Bluetooth ............................................................................................... 2-9
Transferring Data via USB ....................................................................................................... 2-9
Chapter 3: 123RFID MOBILE APPLICATION for ANDROID
Chapter 4: ZEBRA RFID MOBILE APPLICATION for iOS
Introduction .................................................................................................................................... 4-1
Using the Zebra RFID Mobile Application for iOS ......................................................................... 4-1
Pairing with an iOS Device ............................................................................................... 4-2
Pairing using S/N Bar Code .............................................................................................. 4-2
Home Screen ........................................................................................................................... 4-3
Rapid Read .............................................................................................................................. 4-4
Inventory .................................................................................................................................. 4-5
Inventory Screen Features ............................................................................................... 4-6
Locate Tag ............................................................................................................................... 4-7
Settings .................................................................................................................................... 4-8
Readers List ...................................................................................................................... 4-9
Application ........................................................................................................................ 4-10
Antenna ............................................................................................................................ 4-11
Singulation Control ........................................................................................................... 4-12
Start\Stop Triggers ............................................................................................................ 4-13
Tag Reporting ................................................................................................................... 4-14
Regulatory ........................................................................................................................ 4-15
Battery .............................................................................................................................. 4-16
Power Optimization ........................................................................................................... 4-17
Beeper .............................................................................................................................. 4-18
Save Configuration ........................................................................................................... 4-19
Locate Reader .................................................................................................................. 4-20
Access Control ......................................................................................................................... 4-21
Read/Write ........................................................................................................................ 4-21
Lock .................................................................................................................................. 4-21
Kill ..................................................................................................................................... 4-21
Table of Contents vii
Pre Filters ................................................................................................................................. 4-22
Options .............................................................................................................................. 4-22
About ........................................................................................................................................ 4-23
Chapter 5: ZEBRA RFID MOBILE APPLICATION for Windows
Introduction .................................................................................................................................... 5-1
Using the Zebra RFID Mobile Application for Windows ................................................................. 5-1
Home Screen ........................................................................................................................... 5-2
Rapid Read .............................................................................................................................. 5-3
Inventory .................................................................................................................................. 5-4
Inventory Screen Features ................................................................................................ 5-5
Locate Tag ............................................................................................ ................................... 5-6
Settings .................................................................................................................................... 5-7
Readers List ...................................................................................................................... 5-8
Application ........................................................................................................................ 5-9
Antenna ............................................................................................................................. 5-10
Singulation Control ............................................................................................................ 5-11
Start\Stop Triggers ............................................................................................................ 5-12
Tag Reporting ................................................................................................................... 5-13
Regulatory ......................................................................................................................... 5-14
Battery ............................................................................................................................... 5-15
Power Management .......................................................................................................... 5-16
Beeper .............................................................................................................................. 5-17
Save Configuration ........................................................................................................... 5-18
Access Control ......................................................................................................................... 5-19
Read/Write ........................................................................................................................ 5-19
Lock .................................................................................................................................. 5-19
Kill ..................................................................................................................................... 5-19
Pre Filters ................................................................................................................................. 5-20
Options .............................................................................................................................. 5-20
Notification Area Updates ................................................................................................. 5-21
About ........................................................................................................................................ 5-22
Chapter 6: ZEBRA SCANNER CONTROL APPLICATION for ANDROID
Introduction .................................................................................................................................... 6-1
Using the Zebra Scanner Control Application for Android ............................................................. 6-2
Home Screen ........................................................................................................................... 6-2
Scanners ........................................................................................................................................ 6-3
Scanners Screen ..................................................................................................................... 6-3
Connecting the Mobile Device and the Scanner ............................................................... 6-4
Active Scanner Screen ..................................................................................................... 6-6
INFO ............................................................................................................................. 6-6
BARCODE ................................................................................................................... 6-7
SETTINGS ................................................................................................................... 6-8
Settings .......................................................................................................................................... 6-9
Configuration (Not Supported) ....................................................................................................... 6-10
About .............................................................................................................................................. 6-11
Chapter 7: ZEBRA SCANNER CONTROL APPLICATION for iOS
Introduction .................................................................................................................................... 7-1
viii RFD8500 User Guide
Using the Zebra Scanner Control Application for iOS Application ................................................. 7-2
Home Screen ........................................................................................................................... 7-2
Scanners ........................................................................................................................................ 7-3
Scanners Screen ..................................................................................................................... 7-3
Connecting the Device and the Scanner .......................................................................... 7-4
Active Scanner Screen ..................................................................................................... 7-5
Info ............................................................................................................................... 7-5
Barcode ........................................................................................................................ 7-6
Settings ........................................................................................................................ 7-6
Settings .......................................................................................................................................... 7-7
Configuration (Not Supported by the RFD8500) ............................................................................ 7-8
About ............................................................................................................................................. 7-9
Chapter 8: 123SCAN
Introduction .................................................................................................................................... 8-1
Communication with 123Scan ....................................................................................................... 8-1
123Scan Requirements ................................................................................................................. 8-2
Scanner SDK, Other Software Tools, and Videos ......................................................................... 8-2
Appendix A: TROUBLESHOOTING, TECHNICAL SPECIFICATIONS and MAINTENANCE
Introduction .................................................................................................................................... A-1
Troubleshooting ............................................................................................................................. A-1
Technical Specifications ................................................................................................................ A-2
Cleaning ......................................................................................................................................... A-2
Approved Cleanser Active Ingredients ..................................................................................... A-2
Harmful Ingredients .................................................................................................................. A-2
Cleaning Instructions ............................................................................................................... A-3
Special Cleaning Notes ............................................................................................................ A-3
Materials Required ........................................................................................................... ........ A-3
Cleaning Charge Connectors ................................................................................................... A-3
Cleaning Frequency ................................................................................................................. A-4
Maintenance .................................................................................................................................. A-4
RFD8500 .................................................................................................................................. A-4
Battery ...................................................................................................................................... A-4
Index
ABOUT THIS GUIDE
Introduction
The RFD8500 reader provides Radio Frequency Identification (RFID), with optional bar code scanning
functionality. The unit can be used stand alone or paired with a Bluetooth® wireless technology enabled host
device (such as a mobile computer and/or smartphone).
This guide provides information on using the R FD 850 0 an d its ac cessories.
NOTES Some screens or windows shown in this guide may differ from the actual screens shown on the device.
This guide refers to screens and features from the Zebra RFID Mobile, and Zebra Scanner Control
applications. Refer to the corresponding feature in the partner application you are using.
Related Documents
•
Zebra Scanner SDK for iOS Developer Guide, p/n MN001834AXX.
•
Zebra Scanner SDK for Android Developer Guide, p/n MN002223AXX.
•
RFD8500 RFID Developer Guide, p/n MN002222AXX.
•
RFD8500 Quick Start Guide, p/n MN002225AXX.
•
RFD8500 Regulatory Guide, p/n MN002062AXX.
•
CRDUNIV-RFD8500-1R Three Slot Universal Charge Only Cradle Regulatory Guide, p/n MN002224AXX.
•
MC40 User Guide, p/n MN000111AXX.
•
TC55 User Guide, p/n MN000015AXX.
•
TC70 User Guide, p/n MN-002890-XX.
•
123RFID Mobile Application User Guide, p/n MN-003765-xx.
x RFD8500 User Guide
Configurations
Table ii-1
RFD8500-1000100-US BT sled, US (no imager)
RFD8500-1000100-EU BT sled, EU (no imager)
RFD8500-1000100-JP BT sled, Japan, high power (no imager)
RFD8500-1000110-JP BT sled, Japan, low power (no imager)
RFD8500-1000100-IN BT sled, India (no imager)
RFD8500-1000100-IL BT sled, Israel (no imager)
Table ii-2
RFD8500-5000100-US BT sled, US (with imager)
RFD8500-5000100-EU BT sled, EU (with imager)
RFD8500-5000100-JP BT sled, Japan, high power (with imager)
RFD8500-5000110-JP BT sled, Japan, low power (with imager)
RFD8500 without Imager
Configuration Description
RFD8500 with Imager
Configuration Description
RFD8500-5000100-IN BT sled, India (with imager)
RFD8500-5000100-IL BT sled, Israel (with imager)
Table ii-3
Mount support - RFD8500 adapter mount for MC40 terminal ADP-MC40-100
Mount support - RFD8500 adapter mount for TC55 terminal ADP-TC55-100
Quad lock battery door mount and shim for iPod touch KT-IPODTCH-100
Quad lock battery door mount for smartphones KT-QUADOOR-100
Table ii-4
AC line cord; 7.5 ft; grounded, three wire 23844-00-00R
AC line cord, 36 in.; grounded, three wire 50-16000-678R
Charging cable CBL-TC55-CHG1-01
Host Adapters
Item Part Number
Accessories
Item Part Number
Cradle power supply PWRS-14000-148C
About This Guide xi
Table ii-4
Three Slot Universal Charge Only Cradle CRDUNIV-RFD8500-1R
Dual battery charger SAC-TC55-2BTYC1
Lithium-ion battery 4410 mAh BTRY-TC55-44MA1-01
Lanyard SG-8500-HSTRPH-01
Micro USB cable 25-MCXUSB-01R
- Power supply: 100-240 VAC, 5 V, 1.2 A
- Power supply: 100-240 VAC, 5V, 1.2 A with plugs. Includes four international
plugs for US, UK, EU & AU
- 1-slot and 4-slot charging cradles, power supplies, and line cords (DC & AC)
Accessories (Continued)
Chapter Descriptions
This guide includes the following topics:
•
Chapter 1, GETTING ST AR TED provides an overview of RFD8500 physical features, device illustrations
and the how to get the Zebra Scanner Control and Zebra RFID Mobile applications.
Item Part Number
PWRS-124306-01R
•
Chapter 2, USING the RFD8500 describes the basic operations of RFD8500 including device behavior,
Bluetooth pairing and RFID/bar code scanning features.
•
Chapter 3, 123RFID MOBILE APPLICA TION for ANDROID provides information about the 123RFID
Mobile application for Android.
•
Chapter 4, ZEBRA RFID MOBILE APPLICA TION for iOS details the features of the Zebra RFID Mobile
application for iOS devices.
•
Chapter 5, ZEBRA RFID MOBILE APPLICATION for Windows provides information to setup a
development environment for the Windows 10 Universal Windows Platform (UWP) to work with the
RFD8500 over Bluetooth.
•
Chapter 6, ZEBRA SCANNER CONTROL APPLICA TION for ANDROID details the features of the Zebra
Scanner Control application for Android devices.
•
Chapter 7, ZEBRA SCANNER CONTROL APPLICATION for iOS details the features of the Zebra
Scanner Control application for iOS devices.
•
Chapter 8, 123SCAN includes an overview of the 123Scan utility.
•
Appendix A, TROUBLESHOOTING, TECHNICAL SPECIFICATIONS and MAINTENANCE includes
RFD8500 specifications, and information about troubleshooting and maintaining the reader.
xii RFD8500 User Guide
Notational Conventions
This document uses the following conventions:
•
Italics are used to highlight chapters, screen names, fields, and sections in this and related documents.
•
bullets (•) indicate:
• Action items
• Lists of alternatives
• Lists of required steps that are not necessarily seq ue nt ial
•
Sequential lists (e.g., those that describe step-by-step procedures) appear as numbered lists.
NOTE This symbol indicates something of special interest or importance to the reader. Failure to read the note
will not result in physical harm to the reader, equipment or data.
CAUTION This symbol indicates that if this information is ignored, the possibility of data or material damage may
occur.
WARNING! This symbol indicates that if this information is ignored the possibility that serious personal
Service Information
If you have a problem using the equipment, contact your facility's technical or systems support. If there is a
problem with the equipment, they will contact the Zebra Technologies Global Customer Support Center at:
http://www.zebra.com/support.
When contacting Zebra support, please have the following information available:
•
Product name
•
Version number
•
Serial number.
Zebra responds to calls by e-mail, telephone or fax within the time limits set forth in support agreements.
If your problem cannot be solved by Zebra support, you may need to return your equipment for servicing and
will be given specific directions. Zebra is not responsible for any damages incurred during shipment if the
approved shipping container is not used. Shipping the un its improperly can possibly void the warranty.
If you purchased your business product from a Zebra business partner, contact that business partner for
support.
injury may occur.
Chapter 1 GETTING STARTED
Introduction
This chapter provides the features of the RFD8 50 0 and explains how to set it up for the first time.
Unpacking
Carefully remove all protective material from the RFD8500 and save the shipping container for later storage
and shipping. Verify the following items are in the box:
•
RFD8500
•
4410 mAh Lithium-ion battery
•
Micro USB cable
•
Lanyard
•
Quick Start Guide
•
Regulatory Guide.
Inspect the equipment for damage. If any equipment is missing or damaged, contact the Zeb ra Support Center
immediately. See Service Information on page xii for contact information.
1 - 2 RFD8500 User Guide
5
3
6
7
8
9
11
2
1
4
12
10
14
13
15
RFD8500 Features
Figure 1-1
Features - Left and Right Side Views
Figure 1-2
Features - Front and Back Views
GETTING STARTED 1 - 3
See Trigger and Button Operations on page 2-1 for more information about using the features.
Table 1-1
Number Item Description
Feature Descriptions
1 Mode Button - Press to toggle between RFID and bar
code modes (applicable to readers with a
scanner). This button controls whether
pressing the scan trigger button enables
RFID or bar code function.
-Press
The default mode is RFID.
2 Mode Indicator Indicates the current mode of the reader.
•
LED on (green) - Bar code mode
•
LED off - RFID mode.
3 Beeper Sounds beeps that reflect the state of the
RFD8500.
4 Bluetooth Button Turns Bluetooth on and off, and enables
discover mode.
5 Bluetooth Indicator Indicates the Bluetooth status.
Mode
and
Bluetooth
simultaneously for three seconds to
perform a soft reset.
buttons
6 USB Port/Cover USB port.
7 Power Button Turns the RFD8500 on and off.
8 Power Indicator Reflects the power state of the RFD8500. See
LED and Beeper Indicators on page 2-2
indicator descriptions.
9 Battery Cover Release Buttons Depress buttons to remove the battery cover.
10 Imager Window (units with imager only) Scan/read window.
11 Scan Trigger Press to scan bar codes or read tags.
12 RFID Antenna Houses RFID antenna.
13 Charging Contacts Connects to a charging accessory.
14 Bar code/RFID Indicator Lights to reflect the status of decoding bar
codes/reading RFID tags.
15 Lanyard Slot Used to install the lanyard.
for
1 - 4 RFD8500 User Guide
Setting Up the RFD8500
To start using the RFD8500 for the first time:
•
Install the battery.
•
Charge the RFD8500.
•
Power on the RFD8500.
•
Pair the RFD8500 over Bluetooth with a mobile device.
•
Install the appropriate applications: Zebra RFID Mobile, Zebra Scanner Control, or the partner
application (Android or iOS).
•
Set the region and power level (using the Zebra RFID Mobile application, Zebra Scanner Control
application, or the partner application).
Installing the Battery
To install the battery:
1. Depress both battery cover release buttons.
2. Slide back, and remove battery cover.
Figure 1-3
Removing the Battery Cover
GETTING STARTED 1 - 5
1
2
3. Align the three tabs on the bottom of the battery (Figure 1-5) with the three slots in the battery
compartment.
Figure 1-4
4. Press the battery down and rotate until it locks into place.
Figure 1-5
Inserting the Battery
Inserting the Battery
1 - 6 RFD8500 User Guide
5.
Replace the battery cover by placing the cover over the battery and sliding it forward until it clicks in place.
Figure 1-6
6. Press the Power button to turn on the RFD8500.
Replacing the Battery Cover
Removing the Battery
To remove the battery:
1. If powered on, press the Power button to power off the RFD8500.
GETTING STARTED 1 - 7
2. Remove the battery cover as shown in Figure 1-3 on page 1-4
3. With two fingers, press the battery down.
Figure 1-7
4. Rotate the battery out of the compartment.
Removing the Battery
.
Figure 1-8
5. Replace the battery cover as shown in Figure 1-6 on page 1-6
6. Press the Power button to power on the device.
Removing the Battery
.
1 - 8 RFD8500 User Guide
1
2
1
2
Android Device (TC55 Pictured)
iOS Device (iPod touch Pictured)
Mounting a Mobile Device on the RFD8500
To mount a mobile device:
1. Remove the battery cover as shown in Figure 1-3 on page 1-4
2. Remove the plastic tip from the RFD8500 battery cover.
Figure 1-9
Removing Plastic Tip
.
3. Mount the mobile device into
its case.
(Cases vary depending on
the mobile device.)
4. Attach the mobile computer
case to the RFD8500 battery
cover.
5. Slide the battery cover onto
the RFD8500 until it locks in
place.
Figure 1-10
6. The battery cover latches
secure the mobile computer
to the RFD8500.
Mounting the Device
Installing the Lanyard
To install the optional lanyard:
1. Insert the loop on the lanyard into the slot at the bot tom of th e RF D8 50 0 han dle .
2. Thread the upper portion of the lanyard into the loop.
3. Pull the clip through the loop over the tether point and tighten into place.
GETTING STARTED 1 - 9
Figure 1-11
Installing the Lanyard
1 - 10 RFD8500 User Guide
Charging
Charging the Battery in the Reader
CAUTION Ensure that you follow the guidelines for battery safety described in Battery Management on page
1-1 1. The Micro USB port on the RFD8500 is not intended for charging. The Micro USB port is for data
transfer and firmware upgrading only. For daily charging, use the cable cup or charging cradles.
Before using the RFD8500 for the first time, charge the battery until the LED Power/Charging Indicator turns
solid green (see LED and Beeper Indicators on page 2-2 for charge status indications).
Figure 1-12
The Three Slot Charge Only cradle can be used to charge any combination of devices includin g the RFD8500,
TC55, and a dual battery charger.
Figure 1-13
Charging Accessories
Charging Devices
Charging the Mobile Device Battery
Follow the instructions in the mobile device User Guide for charging the battery in the mobile device.
Charging Temperature
Charge batteries in temperatures from 0° C to 40° C (32° F to 104° F). The RFD8500 indicates when charging
is disabled due to abnormal temperatures via its power LED.
NOTE For safety reasons, ensure that the battery cover is properly installed.
When the battery is properly installed, the reader powers on and the power LED turns solid green.
Battery Management
Prior to checking the battery charge level, remove the RFD8500 from any AC power source (cradle or cable).
To check the charge status of the main battery, the RFD85 00 should be connected to the mobile com puter over
Bluetooth. When connected, run the appropriate Zebra RFID Mobile application and select Settings > Battery
Status.
GETTING STARTED 1 - 11
Battery status indicates that the battery is discharging and the battery level indicates the battery charge (as a
percentage of fully charged). If using the partner application. Refer to the partner application documentation.
Low Battery Notification
When the reader has 20% battery remaining, the power LED becomes solid amber. No beeps sound.
When the battery State of Charge (SOC) is equal or less than 10%, the power LED is solid red an d short beep
sounds repeat ONLY when the device is NOT connected to a charger AND when the unit is active (not in low
power mode, or off mode).
When the reader has 5% battery remaining, the reader sounds high, medium, low beeps before automatically
powering off.
Battery Optimization
The RFD8500 supports intelligent performance and battery optimizations for your application needs. An API is
available to enable this setting. Refer to the RFD8500 RFID Developer Guide (p/n MN002222AXX) for more
information.
Also see iOS Power Optimization on page 4-17.
1 - 12 RFD8500 User Guide
Downloading Application Software
123RFID Mobile Application for Android
Requirements
•
The recommended Android version on the mobile computer is Kit Kat version 4.4.x.
•
Recommended Zebra Enterprise mobile computers: MC40, TC55, and TC70.
Installing the Software
Install the 123RFID Mobile application for Android (or partner application) on the mobile computer from the
Zebra website. The procedure to install the software in an Android device depends on the Android version.
To install the software:
1. Connect the An dr oid device to yo ur comp uter. It should be connected as MTP Device and should show as
a drive on your computer.
2. Go to Device Settings > Security and check Unknown Sources to allow installation of applications from
unknown sources.
3. Copy the .apk file to the mobile device.
4. Go to Settings > Security and select Unknown sources.
5. Use File Manager to locate the .apk file in the folder to which you copied it in Step 5., and select it.
6. In the pop-up window, select the Android App installer.
7. The installation begins.
8. Before using the application, pair the Android device using the Android BT Settings (see Pairing on page
2-5). Paring is initiated by the Android device.
Zebra RFID Mobile Application for iOS
Requirements
•
iOS version is 8.0 or later is recommended.
•
Recommended devices: iPod touch 5, iPhone 5, and iPhone 6.
Installing the Software
To install the software download the Zebra RFID Mobile application from Apple App Store.
Before using the application, pair the iOS device using iOS BT Settings (see Pairing on page 2-5). Paring is
initiated by the iOS device.
Chapter 2 USING the RFD8500
Introduction
This chapter includes information about LED and beeper indicators, Bluetooth Wireless Technology, and
scanning.
Using the Features on the RFD8500
Using Buttons and the Scan Trigger
Table 2-1 shows the function s of the RF D8 50 0 butt on s an d sca n trigg er.
Table 2-1
Start/Stop RFID Tag Read X n/a
Start/Stop Bar Code Scan X n/a
Turn RFD8500 ON/OFF X Hold the
RFID Reader/ Bar Code
Scanner Toggle
Enable Bluetooth X Hold the
Trigger and Button Operations
Option
Scan
Trigger
Mode
Button
X Press the
Power
Button
BT
Button
seconds to turn the RFD8500 OFF.
Press the
the RFD8500 ON.
trigger control between RFID tag
reading and bar code scanning.
Note
readers with an imager.
second to turn on Bluetooth discovery.
See
information.
: This function is only available on
Pairing on page 2-5
Comments
Power
button for three
Power
button again to turn
Mode
button to toggle scan
Bluetooth
button for one
for more
2 - 2 RFD8500 User Guide
Table 2-1
Disconnect Bluetooth X When connected with a mobile device,
Turn Off Bluetooth X Hold the button fo r five seconds to turn
Soft Reset the RFD8500 X X Hold the
Reset Device to Factory
Defaults
Trigger and Button Operations (Continued)
Option
Scan
Trigger
Mode
Button
Power
Button
BT
Button
hold the button for one second to
disconnect from the current device and
return it to discovery mode to connect
with another device.
off Bluetooth.
simultaneously for three seconds, then
release to initiate the reset process.
X X Hold the
buttons simultaneously for five
seconds, then release to initiate the
factory reset process.
Comments
Mode
Power
and
and
Bluetooth
Bluetooth
buttons
LED and Beeper Indicators
The LED and beeper indicators provide an indication of the operating statuses of th e RFD8500. (See RFD8500
Features on page 1-2 for the location of indicators.)
Table 2-2
Power State Indicator (Power Button)
Low battery (20%) Solid amber No beep
Lower battery (10%) Solid red Short beeps - repeated
Suspend Solid red, then turns off High/medium/low
Charging Blinking amber Short beep when charger is
Charged Solid green One beep
Charging error Fast blink red Three beeps
Power on
Mode Indicator (Mode Button)
RFID mode Off Short high button
Status Indicators
Condition LED Beeper
connected
•
Green if battery charge > 20%
•
Amber
if battery charge between
10% - 20%
•
Red if battery charge < 10%
Low/medium/high beeps
confirmation beep
Bar code mode Solid green Short high button
confirmation beep
USING the RFD8500 2 - 3
Table 2-2
Decode/RFID Read Indicator
Good decode Solid green Short low beep
Transmit error Solid
Good RFID read Solid green (for each read) Short medium beep
RFID error
Other error message Solid red No beep
BT Indicator (BT Button)
BT off Off No beep
BT on/not connected
BT discoverable Medium flash No beep
BT on/pairing in process Fast flash No beep
BT application connected Solid blue
Status Indicators (Continued)
Condition LED Beeper
amber
for 2 seconds Four beeps for RFID/four
beeps for scanner read
Amber
Slow flash
No beep
No beep
Short low/high beeps
BT out of range Slow flash
Bluetooth
Bluetooth-equipped devices can communicate without wires, using frequency-hopping spread spectrum
(FHSS) radio frequency (RF) to transmit and receive data in the 2.4 GHz Industry Scientific and Medical (ISM)
band (802.15.1). Bluetooth wirele ss tec hn o log y is spec ifica lly de sig ne d fo r sho r t-r an g e (10 me te rs/32.8 feet)
communication and low power consumption.
Devices with Bluetooth capabilities can exchange information (e.g., files, appointments, and tasks) with other
Bluetooth enabled devices such as printers, access points, and other mobile devices.
The RFD8500 can be paired with the following Android and Apple devices.
•
•
®
Wireless Technology Connections
Android Devices
• Zebra MC40
• Zebra TC55
• Zebra TC70.
Apple Devices
• iPhone 5/6
• iPod touch 5.
Short high/low beeps
2 - 4 RFD8500 User Guide
Adaptive Frequency Hopping
Adaptive Frequency Hopping (AFH) is a method of avoi ding fixed frequency interfer ence, and can be used with
Bluetooth voice. All devices in the piconet (Bluetooth network) must be AFH-capable in order for AFH to work.
