Zanussi ZE 2002 iS User Manual

Specifications and Main Features

  • Width- 600 mm (23.6 inches)
  • Overall Depth But Not Including The Hose- 600 mm (23.6 inches)
  • Height- 850 mm (33.5 inches)
  • Weight- 80 kg (178.5 lbs)
  • The Maximum Capacity A Dry Cloth Can Have (excluding wool and synthetic fabrics)- 10 lbs (4.5 kg)
  • Spinning Revolution Maximum Setting- 1000 rpm
  • Total Energy Used- 2500 W
  • Heater’s Maximum Rating- 2300 W
  • Washing Motor Rating- 250 W
  • Spinning Motor Rating- 350 W/700 W
  • Normal Level Of Water Load- 2.9 Gals (13 Liters)
  • High Level Of Water Load- 4.4 gallons (20 liters)
  • Highest Water Pressure- 759 KN/m² - 110 P.S.I
  • Lowest Water Pressure (conditioned cold)- 48 kN/m² - 7 p.s.i.
  • Minimum Water Pressure Conditions: 27 kN/m² - 4 p.s.i (hot water)
  • Supply Voltage Conditions: 220 - 240 V
  • Supply Frequency Conditions: 50 Hz

Considering these conditions, using the washing machine or a dryer can be both effective and efficient

Frequently Asked Questions

Q: What Is The Large amount Of weight a Single Load In A Washing Machine Can Handle?

A: Clothes capacity with synthetic fabric and wool not included is 4.5 kg or 10 lbs.

Q: At What Set Speeds Can This Device Operate The Spin Cycle?

A: The spin cycle can be operated either on the set speeds of 1000 rpm or 500 rpm.

Q: What Is The Optimal Water Pressure Suitable For A Washing Machine?

A: Water pressure from the cold water supply should not be lower than 7 psi, while the hot water pressure should not be lower than 4 psi.

Q: Is it possible to modify the washing cycle?

A: Yes, the cleaning step of a program can be altered with the help of the “Heavily soiled,” “1/2 load”, “Spin” and “Temperature” to fit your washing needs.

Q: I want to take good care of the machine. How can I do this?

A: Generally it is advised to clean the detergent dispenser more regularly and also perform a full washing cycle without clothes with 25g of “Calgon” occasionally.

Q: How am I supposed to assort the laundry before putting it in a washing machine?

A: The closest to reaching the highest potential of cleaning should be sorted by the type of fabric and color fastness.

Q: In case the "Alarm" light starts to blink what measures should be taken?

A: Always switch off the appliance if the "Alarm" light is blinking constantly when switched on or when it is in use and look for reasons such as loose loading door, dirty drain filter or low water pressure. If it still persists please visit the nearest Zanussi Service Centre.

User Manual

Zanussi ZE 2002 iS User Manual
Loading...
+ 16 hidden pages
