SPECIFICATIONS
DOCUMENT #W61
YSI MultiLab Line
Benchtop Instruments for the Lab
The YSI MultiLab line of instruments provide easy to use and easyto-calibrate menu-driven operation ideal for any laboratory. These
one, two, or three channel benchtop meters for the measurement
of pH, ORP, conductivity and/or optical-based dissolved oxygen
(BOD) are ideal for highly accurate lab testing.
The instruments feature a large, easy to read display, Intelligent
Digital Sensors (IDS) for plug-and-play connectivity, and a 3-year
instrument warranty.
Model 4010-1 - One Channel
• Single channel input for pH, ORP, Optical-Based
DO/BOD, or conductivity
Parameters:
Temperature
Conductivity
Resistivity
Salinity
TDS (Total Dissolved
Solids)
pH/mV
Oxidation Reduction
Potential (ORP)
Partial Pressure
Dissolved Oxygen (%
and mg/L* (BOD)
*Optical Based
• Data storage - 500 data sets in manual mode;
5,000 data sets in automatic logging mode
• Large, easy to read backlit graphic display
• GLP Compliant (sensors store serial # and calibration data)
• USB connectivity to manage data
• 3-year warranty
Models 4010-2 and 4010-3
- Two and ree Channel
• Two or Three channel input for pH, ORP,
Optical-Based DO/BOD, or conductivity
• Data storage - 500 data sets in manual mode;
10,000 data sets in automatic logging mode
• Large, easy to read color display
• GLP Compliant (sensors store serial # and calibration data)
• Antibacterial keypad
• USB connectivity to manage data
• 3-year warranty
Intelligent Digital Sensors (IDS)
The IDS sensors automatically store their unique serial number and calibration data. The sensors
maintain their calibration data when moved from instrument to instrument and transmit this information
to the new instrument so you don’t have to recalibrate. In addition, they also digitally process the
measurement signal.
• Plug-and-play connectivity in any combination with all MultiLab instruments
• Sensors store their own unique ID with serial number and calibration status
• Automatic sensor recognition with digital signal processing and data transfer
• Includes self-stirring Optical-Based DO/BOD, pH, ORP, and conductivity sensors
CMC
The CMC function displays continual monitoring of the sensor’s measuring range. The range is represented with a bar and calibration points are shown as vertical lines at the cal point. A moving cursor
shows the current measured value and indicates if the measurement is within the calibrated range.
Quality Sensor Control (QSC)
The QSC is a system to monitor the condition of the pH electrodes. An initial calibration is performed
and, afterwards, the sensor status is monitored and graphically displayed.
The YSI IDS ProOBOD selfstirring optical BOD probe,
powered by the instrument,
has a built-in sensor guard to
protect the sensing tip from
damage while placing it into
the BOD bottles.
Superior Benchtop Measurement
The MultiLab line provides high
accuracy measurements for the lab.
Measure conductivity, pH, ORP, or
DO for BOD calculations confidently
and quickly with the full range of IDS
sensors. Also capable of using non-
IDS pH or ORP sensors with a simple
adapter for sensors with DIN or BNC
connectors.
