YELLOW JACKET
RecoverXLT™ Refrigerant Recovery Machine
Features
• Fast recovery of Class II, III, IV and V refrigerants
including R-410A.
Refrigerant Recovery the Smart Way
Leading HVAC/R professionals understand that it pays to work
smart. That is, the quickest way is not always the best way. Case
in point – refrigerant recovery. If you slug the compressor with
liquid, not only
will.
The YELLOW JACKET
Machine helps you work smart. The built-in constant pressure
regulator (CPR) valve regulates the refrigerant input to protect the
compressor. There’s no need to worry about slugging because the
RecoverXLT controls that for you. How confident are we?
Confident enough to offer you the leading warranty in the industry
on the compressor – three years.
Working smart means carefully considering the claims of
manufacturers. Can you really safely remove refrigerant quicker?
Not without putting your equipment at risk. And when your
compressor fails in the middle of a service call, how much time
and money are you really saving?
Set yourself up to work smart. Surround yourself with the hardest
working, highest performing tools available. YELLOW JACKET
RecoverXLT and other YELLOW JACKET service tools for the
HVAC/R service professional.
can
it cause premature compressor failure – it
®
RecoverXLT™ Refrigerant Recovery
• Patented single valve control for easy changeover from
liquid to vapor to purge.
• Lightweight case designed for easy carrying.
• Automatic shut-off at 15” of vacuum and automatic
restart if pressure rises.
• CPR valve to regulate refrigerant input and protect the
life of the compressor…...and your investment.
• Auto purge clears residual refrigerant for quick change
from one refrigerant to another. Auto purge clears
residual refrigerant for quick change from one
refrigerant to another.
• 3 year warranty on compressor.
• Designed and manufactured in the U.S.A.
UPC# Description
95760 RecoverXLT Refrigerant Recovery Machine
(115V/60Hz)
95762 RecoverXLT Refrigerant Recovery Machine
with Tank Overfill Switch (TOS)
95763 RecoverXLT Refrigerant Recovery Machine
with CE Approval (230V/50Hz)
Page 2
YELLOW JACKET® RecoverXLT…Refrigerant Recovery the Smart Way
Specifications - RecoverXLT
Capabilities Vapor, liquid, push/pull
Compressor 1/2 hp, oil-less
Weight 32.6 lbs. (14.78 kg)
Size 19.3 x 12.4 x 12.5” (490 x 315 x 317 mm)
Refrigerants 12, 22, 134a, 407C, 410A, 500, 502, HP,
MP, Blends
Electrical 115/60 Hz or 230/50 Hz
Overfill shut-off Standard on 95762
Warranty 3 years compressor; 1 year parts and labor
Lightweight case designed for easy carrying.
Recovery Ratings per UL* ARI - 740-98
Vacuum Level: 15 inHg
R-12 0.37 12.81 1.98 10.2 348.6 54
R-22 0.37 12.81 1.98 10.2 348.6 54
R-500 0.37 12.81 1.98 10.2 348.6 54
R-502 0.66 12.9 2.65 18 351 72
R-134a 0.37 12.81 1.98 10.2 348.6 54
R-410A 0.42 11.6 1.68 11.4 315.6 45.6
*UL and ARI tests are only one way to evaluate recovery speed,
and rates are a “level field” comparison method. In other testing
conditions, units can exhibit much higher rates.
YELLOW JACKET Products Division
Ritchie Engineering Co., Inc.
10950 Hampshire Avenue South
Bloomington, MN 55438-2623
Phone: 800-769-8370 or (952)943-1333
E-mail: [email protected]
Web site: www.yellowjacket.com
Lbs./min
Vapor Push/Pull Liquid Vapor Push/Pull Liquid
Kg./hr.
Printed in U.S.A. 07/08 LT
Patented single valve control for easy
changeover from liquid to vapor to purge.
