Smart Media Phone
SIP-T58V & SIP-T58A
SIP-T58V
Quick Start Guide (V80.10)
www.yealink.com |
Applies to firmware version 58.80.0.10 or later. |
Packaging Contents
The following items are included in your package. If you find anything missing, contact your system administrator.
|
Handset Cord |
Ethernet Cable |
Stand |
CAM50 |
|
|
(2m CAT5E FTP cable) |
|
|
IP Phone |
Handset Quick Start Guide |
Power Adapter |
Wall Mount Bracket |
|
|
|
Optional |
Optional |
|
Note: The Yealink USB camera CAM50 is an optional accessory for the SIP-T58A IP phone.
We recommend that you use the accessories provided or approved by Yealink. The use of unapproved third-party accessories may result in reduced performance.
Assembling the Phone
1. Insert the camera, as shown below:
Adjust Shutter Switch
PC |
Internet |
DC5V |
|
PC |
Internet |
DC5V |
|
|
|
Adjust Camera Angle
Note: The camera can only be connected to the USB port on the top of the phone. And the IP phone only supports the Yealink original USB camera CAM50.
2. Attach the stand and adjust the angle of touch screen, as shown below:
PUSH
1
3. Attach the optional wall mount bracket, as shown below:
PUSH |
Note: The hookswitch tab has a lip which allows the handset to stay on-hook when the IP phone is mounted vertically. For more information, refer to Yealink Wall Mount Quick Installation Guide for Yealink IP Phones.
4. Connect the handset and optional headset, as shown below:
|
|
|
|
Note: The headset should be purchased separately.
5. Connect the optional USB flash drive, as shown below:
Note: The USB port (on the rear of the phone) can also be used to connect color-screen expansion module EXP50 or USB headset. For more information on how to use EXP50, refer to Yealink EXP50 User Guide. For more information on how to use USB headset, refer to the documentation from the manufacturer.
2
6. Connect the AC power or PoE, as shown below:
Power Adapter
(DC 5V)
A
AC Power Option
|
|
|
B |
|
PoE ( Power over
Ethernet ) Option
IEEE 802.3af compliant
PoE Hub/Switch
Note: The IP phone should be used with Yealink original power adapter (5V/2A) only. The use of the third-party power adapter may cause the damage to the phone.
7. Connect to the network, as shown below:
You have two options for network connection. You can select one of them according to the current office environment.
a) Connect to the wired network:
PC
PC Connection
(Optional)
|
|
Note: If you are connecting a PC to your phone, we recommend that you use the Ethernet cable provided by Yealink.
b)Connect to the wireless network:
1)Swipe down from the top of the screen to enter the control center.
2)Tap Settings->Basic->Wi-Fi.
3)Tap the On radio box in the Wi-Fi field.
The phone will automatically search for available wireless networks in your area.
4)Select an available wireless network from the list of networks.
5)If the network is secure, enter its password in the Password field.
6)Tap Connect to connect to the wireless network.
3
