Ultra-elegant IP Phone
SIP-T40P
Quick Start Guide(V80.10)
www.yealink.com |
Applies to firmware version 54.80.0.10 or later. |
Packaging Contents
The following items are included in your package. If you find anything missing, contact your system administrator.
Handset Cord |
Ethernet Cable |
|
|
|
|
|
Stand |
|
|
|
|
||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IP Phone |
Handset |
Quick Start Guide |
Power Adapter |
Wall Mount Bracket |
|
|
|
Optional |
Optional |
Assembling the Phone
1. Attach the stand, as shown below:
A
40
B
45
Desk Mount Method
Note: You can also mount the phone to a wall. For more information on how to attach the wall mount bracket,refer to Yealink Wall Mount Quick Installation Guide for Yealink IP Phones.
2. Connect the handset and optional headset, as shown below:
Wireless Headset Adapter EHS36
Note: The headset and wireless headset adapter EHS36 should be purchased separately. EHS36 is used for connecting the phone and a compatible wireless headset. For more information on how to use the EHS36, refer to Yealink EHS36 User Guide.
1
3. Connect the network and power, as shown below:
You have two options for network and power connections. Your system administrator will advise you on which one to use.
PC Connection (Optional)
Power Adapter
(DC 5V)
A
AC Power Option
B
PoE ( Power over
Ethernet ) Option
PC Connection
(Optional)
IEEE 802.3af compliant
PoE Hub/Switch
Note: If inline power (PoE) is provided, you don’t need to connect the power adapter. Make sure the hub/switch is PoE-compliant.
Startup
After the IP phone is connected to the network and supplied with |
Welcome |
power, it automatically begins the initialization process. After |
|
startup, the phone is ready for use. You can configure the phone |
Initializing...please wait |
via web user interface or phone user interface. |
|
|
|
2
