YEALINK DD10 Users Manual

DECT Dongle Kit
DD10K
www.yealink.com
Quick Start Guide(V1.0)
For DD phone firmware 68.81.0.66 or later.
Introduction
DECT dongle kit DD10K helps you turn the SIP-T41S/T42S IP phone to the DECT desk phone (hereinafter referred to as DD phone). After that, you can use the IP phone as a handset for a base station.
Packaging Contents
The following items are included in your package. If you find anything missing, contact your system administrator.
Quick Start GuideDD10K
Assembling the DD10K
Assembling the DD10K, as shown below:
To assemble the DD10K:
1. Insert the DD10K into the USB port on the back of the phone.
2
Getting Started
DD Phone Mode
Before using a IP phone as a DECT desk phone, you should enable the DD phone mode first.
To enable the DD phone mode when the IP phone is powered off:
1. Assemble the DD10K.
2. Power on the IP phone.
The DD phone mode is enabled automatically after the IP phone is started up.
To enable the DD phone mode when the IP phone is powered on:
1. Assemble the DD10K.
The LCD screen prompts “DECT dongle is inserted, reboot and switch to DD Phone mode?”
2. Press the OK soft key.
The DD phone mode is enabled automatically after the IP phone is restarted.
Registration
You can register up to 8 DD phones (for W60B) or 5 DD phones (for W52P) to one base station. Each DD phone can be registered to only one base station.
Before registering the DD phone, make sure the base station is in registration mode (long press the registration LED flashes).
To register the DD phone when the phone screen prompts “Unregistered!”, do one of the following:
A. Press the Reg soft key to register quickly. B1.Do one of the following:
– Press the OK soft key, and then select Register
Handset.
–Press
Register Handset.
and then select Settings->Registration->
on the base station till
3
