Yamaha Stagepas 1K User Manual

STAGEPAS 1K Owner’s Manual 1

Explanation of Graphical Symbols
Explication des symboles

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

L’éclair avec une flèche à l’intérieur d’un triangle équilatéral est destiné à attirer l’attention de l’utilisateur sur la présence d’une
« tension dangereuse » non isolée à l’intérieur de l’appareil, pouvant être suffisamment élevée pour constituer un risque d’électrocution.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the product.

Le point d’exclamation à l’intérieur d’un triangle équilatéral est destiné à attirer l’attention de l’utilisateur sur la présence d’instructions
importantes sur l’emploi ou la maintenance (réparation) de l’appareil dans la documentation fournie.

IMPORTANT SAFETY
INSTRUCTIONS

1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in accordance with

the manufacturer’s instructions.

8 Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that
produce heat.

9 Do not defeat the safety purpose of the polarized or grounding-

type plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.

10 Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point where

they exit from the apparatus.
11 Only use attachments/accessories specified by the manufacturer.
12 Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with

the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to

avoid injury from tip-over.
13 Unplug this apparatus during lightning storms or

when unused for long periods of time.
14 Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way, such

as power-supply cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally, or has

been dropped.

(UL60065_03)

PRÉCAUTIONS CONCER­NANT LA SÉCURITÉ

1 Lire ces instructions.
2 Conserver ces instructions.
3 Tenir compte de tous les avertissements.
4 Suivre toutes les instructions.
5 Ne pas utiliser ce produit à proximité d’eau.
6 Nettoyer uniquement avec un chiffon propre et sec.
7 Ne pas bloquer les orifices de ventilation. Installer l’appareil

conformément aux instructions du fabricant.

8 Ne pas installer l’appareil à proximité d’une source de chaleur

comme un radiateur, une bouche de chaleur, un poêle ou tout autre
appareil (y compris un amplificateur) produisant de la chaleur.

9 Ne pas modifier le système de sécurité de la fiche polarisée ou de

la fiche de terre. Une fiche polarisée dispose de deux broches dont
une est plus large que l’autre. Une fiche de terre dispose de deux
broches et d’une troisième pour le raccordement à la terre. Cette
broche plus large ou cette troisième broche est destinée à assurer
la sécurité de l’utilisateur. Si la fiche équipant l’appareil n’est pas
compatible avec les prises de courant disponibles, faire remplacer
les prises par un électricien.

10 Acheminer les cordons d’alimentation de sorte qu’ils ne soient pas

piétinés ni coincés, en faisant tout spécialement attention aux
fiches, prises de courant et au point de sortie de l’appareil.

11 Utiliser exclusivement les fixations et accessoires spécifiés par le

fabricant.

12 Utiliser exclusivement le chariot, le stand, le

trépied, le support ou la table recommandés par
le fabricant ou vendus avec cet appareil. Si
l’appareil est posé sur un chariot, déplacer le
chariot avec précaution pour éviter tout risque
de chute et de blessure.

13 Débrancher l’appareil en cas d’orage ou lorsqu’il

doit rester hors service pendant une période prolongée.

14 Confier toute réparation à un personnel qualifié. Faire réparer

l’appareil s’il a subi tout dommage, par exemple si la fiche ou le
cordon d’alimentation est endommagé, si du liquide a coulé ou des
objets sont tombés à l’intérieur de l’appareil, si l’appareil a été
exposé à la pluie ou à de l’humidité, si l’appareil ne fonctionne pas
normalement ou est tombé.

(UL60065_03)

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

ATTENTION :

POUR RÉDUIRE LES RISQUES D'ÉLECTROCUTION, NE PAS RETIRER

LE CAPOT (OU LE DOS). NE CONTIENT PAS DE PIÈCES NÉCESSITANT

L'INTERVENTION DE L'UTILISATEUR. POUR TOUTE INTERVENTION,

FAIRE APPEL À DES PROFESSIONNELS QUALIFIÉS.

ATTENTION

RISQUE DE CHOC

ELECTRIQUE-NE PAS OUVRIR

The above warning is located on the rear of the unit. L’avertissement ci-dessus est situé sur l’arrière de l’unité.

WAR NING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.

AVERTISSEMENT

POUR RÉDUIRE LES RISQUES D’INCENDIE OU DE DÉCHARGE
ÉLECTRIQUE, N’EXPOSEZ PAS CET APPAREIL À LA PLUIE OU À
L’HUMIDITÉ.

2 STAGEPAS 1K Owner’s Manual

FCC INFORMATION (U.S.A.)

1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!

This product, when installed as indicated in the instructions con­tained in this manual, meets FCC requirements. Modifications not
expressly approved by Yamaha may void your authority, granted by
the FCC, to use the product.

2. IMPORTANT: When connecting this product to accessories and/

or another product use only high quality shielded cables. Cable/s
supplied with this product MUST be used. Follow all installation
instructions. Failure to follow instructions could void your FCC
authorization to use this product in the USA.

3. NOTE: This product has been tested and found to comply with the

requirements listed in FCC Regulations, Part 15 for Class “B” digital
devices. Compliance with these requirements provides a reason­able level of assurance that your use of this product in a residential
environment will not result in harmful interference with other elec­tronic devices. This equipment generates/uses radio frequencies
and, if not installed and used according to the instructions found in
the users manual, may cause interference harmful to the operation
of other electronic devices. Compliance with FCC regulations does

* This applies only to products distributed by Yamaha Corporation of America. (class B)

COMPLIANCE INFORMATION STATEMENT

(Supplier’s declaration of conformity procedure)

not guarantee that interference will not occur in all installations. If
this product is found to be the source of interference, which can be
determined by turning the unit “OFF” and “ON”, please try to elimi­nate the problem by using one of the following measures:

Relocate either this product or the device that is being affected by
the interference.

Utilize power outlets that are on different branch (circuit breaker or
fuse) circuits or install AC line filter/s.

In the case of radio or TV interference, relocate/reorient the
antenna. If the antenna lead-in is 300 ohm ribbon lead, change the
lead-in to co-axial type cable.

If these corrective measures do not produce satisfactory results,
please contact the local retailer authorized to distribute this type of
product. If you can not locate the appropriate retailer, please con­tact Yamaha Corporation of America, Electronic Service Division,
6600 Orangethorpe Ave, Buena Park, CA90620

The above statements apply ONLY to those products distributed by
Yamaha Corporation of America or its subsidiaries.

Responsible Party : Yamaha Corporation of America

Address : 6600 Orangethorpe Ave., Buena Park, Calif. 90620

Telephone : [phone]

Type of Equipment : PORTABLE PA SYSTEM

Model Name : STAGEPAS 1K

This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference received including interference
that may cause undesired operation.

* This applies only to products distributed by

Yamaha Corporation of America.

(FCC SDoC)

STAGEPAS 1K Owner’s Manual 3

PRECAUTIONS

PLEASE READ CAREFULLY
BEFORE PROCEEDING

Please keep this manual in a safe place for
future reference.

This device is designed for use at musical or other live
events. Do not use for any purposes other than the one
intended. Those who are unfamiliar with handling or
those who can not handle according to this manual
such as children, should be supervised by responsible
persons to ensure safety.

WARNING

PA_en_11 1/2

• Be sure to connect to an appropriate outlet with a protective
grounding connection. Improper grounding can result in
electrical shock, fire, or damage.

Do not open

• This product contains no user-serviceable parts. Do not
attempt to disassemble the internal parts or modify them in
any way.

Water warning/Fire warning

• Do not expose the product to rain, use it near water or in
damp or wet conditions, or place on it any containers (such as
vases, bottles or glasses) containing liquids which might spill
into any openings.

• Never insert or remove an electric plug with wet hands.

• Do not place any burning items or open flames near the
product, since they may cause a fire.

Always follow the basic precautions listed below to avoid
the possibility of serious injury or even death from
electrical shock, short-circuiting, damages, fire or other
hazards. These precautions include, but are not limited
to, the following:

If you notice any abnormality

• If any of the following problems occur, immediately turn off the
power switch and disconnect the electric plug from the outlet.

- The power cord or plug becomes frayed or damaged.

- Unusual smells or smoke are emitted.

- Some object, or water has been dropped into the product.

- There is a sudden loss of sound during use of the product.

- Cracks or other visible damage appear on the product.
Then have the product inspected or repaired by qualified

Yamaha service personnel.

Power supply/Power cord

• Do not place the power cord near heat sources such as
heaters or radiators, and do not excessively bend or otherwise
damage the cord, place heavy objects on it, or place it in a
position where anyone could walk on, trip over, or roll anything
over it.

• Only use the voltage specified as correct for the product. The
required voltage is printed on the name plate of the product.

• Use only the supplied power cord/plug.
If you intend to use the product in an area other than in the

one you purchased, the included power cord may not be
compatible. Please check with your Yamaha dealer.

• Check the electric plug periodically and remove any dirt or
dust which may have accumulated on it.

• Make sure to fully insert the electric plug to prevent electric
shocks or fire.

• When setting up the product, make sure that the AC outlet you
are using is easily accessible. If some trouble or malfunction
occurs, immediately turn off the power switch and disconnect
the plug from the outlet. Even when the power switch is turned
off, as long as the power cord is not unplugged from the wall
AC outlet, the product will not be disconnected from the
power source.

• Remove the electric plug from the outlet when the product is
not to be used for extended periods of time.

• Do not touch the product or the electric plug during an
electrical storm.

Hearing loss

• Before turning the power of all devices on or off, make sure
that all volume levels are set to the minimum. Failing to do so
may result in hearing loss, electric shock, or device damage.

• When turning on the AC power in your audio system, always
turn on the product LAST, to avoid hearing loss and speaker
damage. When turning the power off, the product should be
turned off FIRST for the same reason.

Wireless unit

• Do not use this product near medical devices or inside
medical facilities. Radio waves from this product may affect
electro-medical devices.

• Do not use this product within 15 cm (6 in) of persons with a
heart pacemaker implant or a defibrillator implant. Radio
waves from this product may affect electro-medical devices,
such as a heart pacemaker implant or defibrillator implant.

CAUTION

Always follow the basic precautions listed below to avoid
the possibility of physical injury to you or others. These
precautions include, but are not limited to, the following:

Power supply/Power cord

• When removing the electric plug from the product or an outlet,
always hold the plug itself and not the cord. Pulling by the
cord can damage it.

Location and connection

• Do not place the product in an unstable position or a location
with excessive vibration, where it might accidentally fall over
and cause injury.

• Keep the device out of reach of children. This product is not
suitable for use in locations where children are likely to be
present.

• Do not block the vents. This product has ventilation holes at
the rear to prevent the internal temperature from becoming too
high. In particular, do not place the product on its side or
upside down. Inadequate ventilation can result in overheating,
possibly causing damage to the product(s), or even fire.

4 STAGEPAS 1K Owner’s Manual

PA_en_11 2/2

• To ensure proper heat dissipation of the product, when
installing it:

- Do not cover it with any cloth.

- Make sure the top surface faces up; do not install on its

sides or upside down.

- Do not use the product in a confined, poorly-ventilated

location.
Inadequate ventilation can result in overheating, possibly
causing damage to the product(s), or even fire. Make sure that
there is adequate space around the product: at least 30 cm
above, 30 cm at the sides and 30 cm behind.

• Do not carry or transport the device unless it is disassembled.
Otherwise, you might be injured if the speaker or spacers
strike your head or body.

• Do not place the product in a location where it may come into
contact with corrosive gases or salt air. Doing so may result in
malfunction.

• Before moving the product, remove all connected cables.

• When transporting or moving the product, always use two or
more people. Attempting to lift the product by yourself may
damage your back, result in other injury, or cause damage to
the product itself.

• Do not press the rear panel of the product against the wall.
Doing so may cause the plug to come in contact with the wall
and detach from the power cord, resulting in short circuiting,
malfunction, or even fire.

Maintenance

• Remove the power plug from the AC outlet when cleaning the
product.

NOTICE

To avoid the possibility of malfunction/ damage to the
product, damage to data, or damage to other property,
follow the notices below.

Handling and maintenance

• Do not use the product in the vicinity of a TV, radio, or other
electric products. Otherwise, the product, TV, or radio may
generate noise.

• Do not expose the product to excessive dust or vibration, or
extreme cold or heat, in order to prevent the possibility of
panel disfiguration, unstable operation, or damage to the
internal components.

• Do not install in locations where temperature changes are
severe. Otherwise, condensation may form on the inside or
the surface of the product, causing it to break.

• If there is reason to believe that condensation might have
occurred, leave the product for several hours without turning
on the power until the condensation has completely dried out,
in order to prevent possible damage.

• Do not place vinyl, plastic or rubber objects on the product,
since this might cause alteration or discoloration of the panel.

• When cleaning the product, use a dry and soft cloth. Do not
use paint thinners, solvents, cleaning fluids, or chemical­impregnated wiping cloths, since this might cause alteration
or discoloration.

Handling caution

• Do not insert your fingers or hands in any gaps or openings on
the product (vents).

• Do not rest your weight on the product or place heavy objects
on it.

• Do not operate the product if the sound is distorting.
Prolonged use in this condition could cause overheating and
result in fire.

The Bluetooth
owned by Bluetooth SIG, Inc. and any use of such marks by
Yamaha Corporation is under license.

The model number, serial number, power requirements, etc.,
may be found on or near the name plate, which is at the rear of
the unit. You should note this serial number in the space pro­vided below and retain this manual as a permanent record of
your purchase to aid identification in the event of theft.

®

word mark and logos are registered trademarks

Information

About functions/data bundled with the product

• XLR-type connectors are wired as follows (IEC60268 standard):
pin 1: ground, pin 2: hot (+), and pin 3: cold (-).

About this manual

• The illustrations as shown in this manual are for instructional
purposes only.

• IOS is a trademark or registered trademark of Cisco in the U.S.
and other countries and is used under license.

• The company names and product names in this manual are
the trademarks or registered trademarks of their respective
companies.

About disposal

•

This product contains recyclable components.
When disposing of this product, please contact the
appropriate local authorities.

Yamaha cannot be held responsible for damage caused by
improper use or modifications to the product, or data that is
lost or destroyed.

Model No.

Serial No.

(rear_en_01)

STAGEPAS 1K Owner’s Manual 5

Table of Contents

PRECAUTIONS....................................... 4

NOTICE ...................................................5

Information ............................................. 5

Introduction ............................................7

Features ................................................7

Package contents..................................7

Optional items .......................................7

About STAGEPAS Editor ......................7

Controls and Functions......................... 8

Top panel ..............................................8

Rear panel...........................................10

Quick Start Guide.................................12

Attaching the line array speaker and

spacers................................................12

Connecting microphones, musical
instruments, or audio devices to

the mixer..............................................12

Getting sound out of the speaker ........12

Playing Bluetooth® Audio ...................15

Registering (pairing) a Bluetooth®

device ................................................. 15

Connecting a Bluetooth

Playing audio files stored in a
Bluetooth

Disconnecting the Bluetooth® device

®

device............................... 15

®

device......... 15

.. 15

Controlling the unit from

STAGEPAS Editor ................................16

Connecting STAGEPAS Editor........... 16

Disconnecting STAGEPAS Editor ...... 16

Initializing the STAGEPAS 1K .............17

Storing the Unit ....................................17

Troubleshooting...................................18

General Specifications ........................51

Input Characteristics........................... 52

Output Characteristics........................ 52

Dimensions......................................... 53

Combining Two STAGEPAS 1K Units 14

Playing sound in stereo .......................14

Expanding the number of

STAGEPAS 1K input channels ...........14

Block Diagram ......................................54

6 STAGEPAS 1K Owner’s Manual

Introduction

Introduction

Thank you for purchasing the Yamaha STAGEPAS 1K
portable PA System! The STAGEPAS 1K is an all-in-one
portable PA system that is designed for use at musical or
other live events. This owner’s manual is intended for
sound crew at live performances or other events.
It explains the steps required to set up the STAGEPAS 1K
throughout installation and connection of the PA system.
It also explains how to operate the STAGEPAS 1K for
sound amplification. To get the most out of your
STAGEPAS 1K and enjoy its sophisticated range of
features, we recommend that you read this manual
thoroughly and keep it in a safe place for future reference.

Features

• Easy setup involves connecting a line array speaker
to the subwoofer.

• Line array speaker can consistently cover a broad
area.

• 12-inch subwoofer produces a powerful low range.

• Built-in mixer features controls that facilitate complex
processes, including “1-knob EQ” that enables you to
handle multiple audio processes with only one knob.

• Efficient, dedicated cover that accommodates the line
array speaker, spacers, and subwoofer.

• Application software that enables you to control the
unit intuitively and in great detail.

Optional items

• DL-SP1K dolly dedicated for STAGEPAS 1K

About STAGEPAS Editor

STAGEPAS Editor is application software that enables you
to remotely control the STAGEPAS 1K via Bluetooth from
your mobile device, such as a smartphone or tablet.
STAGEPAS Editor lets you adjust the parameters and
monitor the meters and indicators on the STAGEPAS 1K.
It also features music player functions, such as a “Cued
Mode” function that engages the unit in stand-by mode
until the song starts. This function is very useful when you
are busy singing and playing.

For information on how to download STAGEPAS Editor,
please refer to the following Yamaha Pro Audio website:

http://www.yamahaproaudio.com/

Package contents

• Subwoofer x 1 • Dedicated cover x 1

• Line array speaker x 1 • Spacers x 2

• Power cord x 1

• Owner’s Manual (this book)

STAGEPAS 1K Owner’s Manual 7

Controls and Functions

3

1
2

4

5

6

7

8 9

0 AB

E

C

F

G

D

Handle

Line array speaker

socket

Mixer section

Mixer section

Controls and Functions

Top panel

1 [PROTECT] LED

Lights red when the protection circuit is activated.
The protection circuit will be activated in the
following cases, and the speaker output will be
muted.

• Amplifier overheat is detected

• A current surge is detected

• The power to the unit is turned on: The protection

circuit will be activated for a few seconds to avoid
noise. After the unit is properly turned on, the LED
will turn off.

If the protection circuit is activated, wait until the
temperature of the amplifier section decreases.
Alternatively, turn the power to the unit off and then
back on. Then the protection circuit will be
deactivated. If the protection circuit is not
deactivated, please contact your Yamaha dealer.

2 [POWER] LED

Lights green when the [I/O] (Power) switch (P) is
turned on.

3 [REVERB] controls (channels 1-3)

Determine the amount of reverb for each channel
when the [REVERB] switch (

4 [EQ] controls

From the center (FLAT) position, turn these controls
counterclockwise to cut the low range. Turn them
clockwise to boost both low and high ranges.

5 [CLIP] LEDs (channels 1-3)

Light red if signals are clipping due to excessive
input levels. If these LEDs light up, lower the level of
the corresponding input channels, or set the
corresponding [MIC/LINE] switches to LINE.

6 [LEVEL] controls

Use these controls to adjust the volume for each
channel. To reduce noise, set LEVEL controls on
unused channels to minimum.

7 [MIC/LINE] switches

For low-level signals (including microphones), set
the switches to the MIC (N) position. For high-level
signals (including electronic musical instruments
and audio devices), set the switches to the LINE (O)
position.

D) is turned on.

8 STAGEPAS 1K Owner’s Manual

Controls and Functions

8 [Hi-Z] switches (channel 2-3)

This switch is used when connecting a device
directly to the mixer without a DI (direct box)—for
example, instruments with passive pickups, such as
an acoustic-electric guitar or electric bass without a
battery. This function is effective only for the phone
jack input.

9 [BLUETOOTH PAIRING] switch/LED

This switch turns the Bluetooth audio connection on
or off. It is also used to pair (register) a Bluetooth
device (page 15).
The LED indicates the following status:

LED Status

Off Bluetooth standby mode

Lit steadily Bluetooth connected

Flashing slowly Searching for a Bluetooth device

Flashing rapidly Waiting for Bluetooth pairing

NOTE

The STAGEPAS 1K enables you to pair (register) up to
eight Bluetooth devices. Once the ninth Bluetooth device
has been paired successfully, the pairing information for the
Bluetooth device that was connected earliest will be
deleted.

0 [BLUETOOTH/CONTROL MODE] switch/LED

This switch determines whether or not you can
control the unit from STAGEPAS Editor.
The LED indicates the following status:

LED Status

Off Control disabled

Lit steadily Connected to STAGEPAS Editor

Flashing slowly

Waiting for connection to STAGEPAS
Editor

A [MONO/ST MODE] switch/LED

Enables you to select whether the audio output from
the speaker is monaural (MONO) or stereo
(STEREO). Pressing this switch repeatedly will toggle
between MONO and STEREO. If STEREO is
selected, the L-channel signal of the stereo input will
be output from this unit, while the R-channel signal
will be output via the [LINK] output jack to the other
STAGEPAS 1K.
The LED will light orange if STEREO is selected.

C [MONITOR] control

Determines the signal level output from the
[MONITOR] output jack (M). The [MASTER LEVEL]
control does not affect this signal.

D [REVERB] switch/ LED

When this switch is on, the LED lights up, indicating
that you can apply reverb (reverberation/echo).

E [REVERB TYPE/TIME] control

Determines reverb type and length. Turning the
control clockwise lengthens the time of the selected
reverb type.

HALL: Simulated reverb of a large space, such as a
concert hall.

PLATE: Simulated steel plate reverb, producing a
harder-edged and brighter sound.

ROOM: Simulated acoustic ambience of a small
room.

ECHO: Echo effect suitable for vocals.

F [MODE] control

Use this control to adjust the overall sound pressure
and frequency balance. The center position (MUSIC)
is a basic setting. If you turn the control
counterclockwise (SPEECH), it will cut unneeded
low-range frequencies, and create an optimum
setting for speech, or singing and playing an
acoustic musical instrument. If you turn the control
clockwise (CLUB), it will create an optimum setting
for playback of sound sources, since the high and
low ranges are boosted.

G [MASTER LEVEL] control

Determines the volume level of the signal output
from the speaker and the level of the signal routed to
the [LINK] output jack simultaneously. This allows
you to adjust the overall volume without changing
the relative volume balance among the various
channels. The [LIMIT] LED lights when the limiter is
applied.

B [LINE] input jack

Supports stereo-mini plugs. Connect an audio
device here. A signal from the Bluetooth device is
always mixed to the ST IN channel.

STAGEPAS 1K Owner’s Manual 9
