INTRODUCTION > About this User Guide
INTRODUCTION
About this User Guide
• This User Guide is for the following readers:
– the users of the product
– the constructor, builder and dealer that mount the product on the wall
• This User Guide uses the following signal words for the important information:
–
This content indicates “risk of serious injury or death.”
–
This content indicates “risk of injury.”
– NOTICE
Indicates points that you must observe in order to prevent product failure, damage or malfunction and
data loss, as well as to protect the environment.
– NOTE
Indicates notes on instructions, restrictions on functions, and additional information that may be
helpful.
• The illustrations and screens in this User Guide are for instructional purposes only.
• The company names and product names in this User Guide are the trademarks or registered trademarks of
their respective companies.
• Various smartphones and tablet devices are collectively referred to as “mobile devices”. When necessary,
the type of mobile device is specified in the explanations.
• The [Search tag] is a keyword used in searches. This serves as a link from the Quick Start Guide to the User
Guide.
NOTE
The Safety Brochure and the Quick Start Guide are supplied with this product. See the Safety Brochure first.
WARNING
CAUTION
5
INTRODUCTION > Features
Features
This sound bar is a speaker for your TV that allows you to easily enjoy surround sound on the TV.
Play surround sound
n
Related links
“Surround playback”(p.35)
Easily play audio content from a Bluetooth device
n
Related links
“Listening to audio from a Bluetooth® device”(p.40)
6
INTRODUCTION > Features
Additional features
n
Clear Voice
This function automatically distinguishes human voices from background sound and increases the volume of
the voices only. Human voices in TV programs that use a lot of background music and sound effects can be
heard more clearly.
• “Playing back human voices clearly (CLEAR VOICE)”(p.38)
Bass Extension
This function boosts bass levels that are often not strong enough when using a compact speaker, for more
impactful sound.
• “Enjoying enhanced bass sound (BASS EXT)”(p.39)
Audio Return Channel (ARC) and HDMI Control function compatible
An Audio Return Channel (ARC) compatible TV can be connected to the sound bar using a single HDMI cable.
An HDMI control function compatible TV allows for controlling the sound bar's basic functions using the TV’s
remote control.
• “Connecting a TV using an HDMI cable (sold separately)”(p.23)
• “Using a TV’s remote control to control the sound bar (HDMI Control)”(p.44)
Dedicated app: “Sound Bar Remote”
The sound bar can be easily controlled from your mobile device.
Certified as a Yamaha Eco-Product
n
Yamaha Eco-Label is a mark that certifies products of high environmental performance.
With an advanced energy saving design, this product achieves a low power consumption of not more than
1.8 watts when in standby mode.
7
INTRODUCTION > Supplied accessories
Supplied accessories
Make sure you have received all of the following accessories:
• Sound bar (SR-C20A)
• Remote control
* A Lithium battery (CR2025) has already been inserted into the remote control.
• AC adaptor (model number: ANAD-420FIOT-B or ANAD-420FIOT-W)
• Power cord
• Digital optical audio cable
• Spacers (A: ×2, B: ×2 on 1 sheet)
* Use when mounting the sound bar on a wall.
• Mounting template
* Use when mounting the sound bar on a wall.
8
INTRODUCTION > Supplied accessories
• Quick Start Guide
• Safety Brochure
9
a
e
b
c
d
d
c
Off
Glowing
Flashing
PART NAMES AND FUNCTIONS > Part names of the sound bar (front/top)
PART NAMES AND FUNCTIONS
Part names of the sound bar (front/top)
This section describes the part names and functions of the front/top of the sound bar.
a
Indicators
The indicators on the top panel flash or glow to show the operation and setting status. During normal playback, the
setting status is indicated as follows:
TV/OPTICAL / BLUETOOTH / ANALOG: Selected input source
SURROUND: Surround playback (glowing) / Stereo playback (off)
NOTE
This document uses the following illustrations to show that indicators are off, glowing, or flashing.
b
c
d
Controls
Touch the symbols with your fingertip to control the sound bar.
y (Input): Select an input source (p.32).
} / { (Volume +/-): Adjust the volume (p.32).
z (Power): Turn the sound bar on and off.
Speakers
Built-in subwoofers
10
PART NAMES AND FUNCTIONS > Part names of the sound bar (front/top)
e
Remote control sensors
NOTE
• To prevent unintended operation, do not place anything on the controls of the sound bar.
Enabling the Child Lock function prevents accidental operation.
• The brightness of the indicators can be adjusted by pressing DIM.
Related links
• “Enabling/disabling the Child Lock function”(p.49)
• “Changing the brightness of the indicators (Dimmer)”(p.43)
11
a b c d e f
PART NAMES AND FUNCTIONS > Part names of the sound bar (rear)
Part names of the sound bar (rear)
This section describes the part names and functions of the rear of the sound bar.
a
UPDATE ONLY jack
Use to update the sound bar’s firmware.
Refer to the instructions supplied with the firmware for details.
b
ANALOG input jack (p.27)
c
OPTICAL input jack (p.27)
d
TV input jack (p.21)
e
HDMI OUT/TV (ARC) jack (p.23)
f
DC IN (20V) jack
Related links
• “Part names of the sound bar (front/top)”(p.10)
• “Part names of the remote control”(p.13)
12
b
c
f
h
a
d
e
i
g
j
PART NAMES AND FUNCTIONS > Part names of the remote control
Part names of the remote control
This section describes the part names and functions of the remote control.
a
z (Power) button
Turn the sound bar on and off (p.31).
b
Input source buttons
Select an audio input source (p.32).
• TV button: Audio from a TV
• OPTICAL button: Audio from a device connected to the OPTICAL input jack
• BLUETOOTH button: Audio from a Bluetooth device
• ANALOG button: Audio from a device connected to the ANALOG input jack
c
CLEAR VOICE button
Enable or disable the Clear Voice function (p.38).
d
BASS EXT button
Enable or disable the Bass Extension function (p.39).
13
Within 6 m
Remote control sensor
PART NAMES AND FUNCTIONS > Part names of the remote control
e
Sound mode buttons
Switch to your preferred sound mode (p.34).
• STANDARD
• MOVIE
• GAME
• STEREO
f
INFO button
Shows information such as the type of audio signal being played and the settings for the sound bar’s functions
(p.45).
g
DIM button
Switch the brightness of the indicators of the sound bar (p.43).
h
SUBWOOFER (+/-) button
Adjust the volume of the subwoofer (p.37).
i
VOLUME (+/-) button
Adjust the volume of the sound bar (p.32).
j
| (Mute) button
Mute the audio output (p.32). Press this button again, or press VOLUME (+/-) to unmute.
NOTE
Use the remote control within the range shown in the following illustration:
Related links
“Part names of the sound bar (front/top)”(p.10)
14
PREPARATION > Preparation
PREPARATION
Preparation
Install the sound bar and connect a TV to it.
1 Install the sound bar.
Installation procedure
“Installing the sound bar”(p.20)
15
OPTICAL
HDMI IN
ARC
OPTICAL
HDMI INOPTICAL
PREPARATION > Preparation
2 Connect a TV to the sound bar.
Depending on the type of TV, connect the TV to the sound bar as follows:
• Connecting the TV using only the supplied digital optical audio cable
Connection procedure
– “Connecting a TV using only the supplied digital optical audio cable”(p.21)
• TV equipped with an HDMI jack labeled as “ARC”
Connection procedure
– “Connecting a TV using an HDMI cable (sold separately)”(p.23)
• TV not equipped with an HDMI jack labeled as “ARC”
Connection procedure
– “Connecting a TV using only the supplied digital optical audio cable”(p.21)
– “Connecting a TV using an HDMI cable (sold separately)”(p.23)
3 Connect an audio device (if required).
Connection procedure
“Connecting an audio device”(p.27)
16
HDMI IN
This sound bar AV devices
PREPARATION > Preparation
4 Prepare the remote control.
“Preparing the remote control”(p.30)
5 Turn on the sound bar.
“Turning on and off the sound bar”(p.31)
NOTE
• Connect AV devices (such as BD/DVD players and set top boxes) to the TV’s HDMI input jacks.
• When playing audio from a TV or AV device via the sound bar, set the input sources as follows:
– Sound bar’s input source: TV
– TV’s input source: AV device playing the content
• ARC (Audio Return Channel) is a function that sends audio signals from the TV’s HDMI output jack.
17
PREPARATION > Precautions for preparation
Precautions for preparation
Before installing the sound bar and connecting other devices, be sure to read the following precautions. Be
sure to always obey the precautions.
Precautions for installation
n
WARNING
• Install in the manner instructed in the manual. Falling or toppling may result in injury or damage.
• Confirm that the finished installation is safe and secure. Also, carry out safety inspections periodically. Failure to observe this
may cause devices to fall and result in injury.
• Do not expose the product to rain, use it near water or in damp or wet conditions, or place on the product any containers (such
as vases, bottles or glasses) containing liquids which might spill into any openings or places where water may drop. A liquid
such as water getting into the product may cause a fire, electric shocks, or malfunctions.
• Do not place any burning items or open flames near the product, since they may cause a fire.
• Do not use this product near medical devices or inside medical facilities. Radio waves from this product may affect electromedical devices.
CAUTION
• Do not place the product in an unstable position where it might accidentally drop or fall over and cause injuries.
• When installing this product, do not obstruct heat dissipation. Failure to observe this may trap heat inside the product, causing
a fire or malfunctions.
• Do not install the product in places where it may come into contact with corrosive gases or salt air, or places that have
excessive smoke or steam. Doing so may result in malfunction.
• Avoid being near the product during a disaster, such as an earthquake. Since the product may turn over or fall and cause injury,
quickly move away from the product and go to a safe place.
NOTICE
• Do not press hard on the speaker units or fabric-covered portion of this product.
• Do not place any objects susceptible to magnetism (such as a hard disk drive or magnetic card) near the product. The magnetic
effect of the sound bar may cause damage to the object or its recorded data.
• Do not use this product in a location that becomes extremely hot, such as in direct sunlight or near a heater, or that becomes
extremely cold, or that is subject to excessive dust or vibration. Failure to observe this may cause this product’s panel to
become deformed, the internal components to malfunction, or for operation to become unstable.
• If using a wireless function, avoid installing this product near metal walls or desks, microwave ovens, or other wireless network
devices. Obstructions could shorten the transmission distance.
18
PREPARATION > Precautions for preparation
Precautions for connections
n
WARNING
• Use this product with the power supply voltage printed on it. Failure to connect to an appropriate AC outlet may cause a fire,
electric shocks, or malfunctions.
• Be sure to use the supplied power cord and AC adaptor. Do not use the supplied power cord and AC adaptor for other devices.
Failure to observe this may cause a fire, electric shocks, or malfunctions.
• Never insert or remove an electric plug with wet hands. Do not handle this product with wet hands. Failure to observe this may
cause electric shocks or malfunctions.
• Do not touch the power plug or cord if there is a chance of lightning. Failure to observe this may cause electric shocks.
• When setting up the product, make sure that the AC outlet you are using is easily accessible. If some trouble or malfunction
occurs, immediately turn off the power switch and disconnect the plug from the AC outlet. Even when the power switch is
turned off, as long as the power cord is not unplugged from the wall AC outlet, the product will not be disconnected from the
power source.
• If not using the product for long periods of time, be sure to pull the power plug from the AC outlet. Failure to observe this may
cause a fire or malfunctions.
• Check the electric plug periodically and remove any dirt or dust which may have accumulated on it. Failure to observe this may
cause a fire or electric shocks.
CAUTION
• Do not use an AC outlet where the power plug fits loosely when inserted. Failure to observe this may cause a fire, electric
shocks, or burns.
• When disconnecting the power plug, always hold the plug itself and not the cord. Pulling by the cord can damage it and cause
electric shocks or a fire.
• Insert the power plug firmly all the way into the AC outlet. Using the product when it is not plugged in sufficiently can cause
dust to accumulate on the plug, causing a fire or burns.
NOTICE
• If connecting external devices, be sure to thoroughly read the User Guide for each device and connect them in accordance with
the instructions. Failure to properly handle a device in accordance with the instructions could cause malfunctions.
• Do not connect this product to industrial devices. This product has been designed to connect to consumer-use devices.
Connection to an industrial-use device could cause this product to malfunction.
19
Controls
PREPARATION > Installing the sound bar
Installing the sound bar
• Before installing the sound bar, be sure to read the following precautions.
– “Precautions for preparation”(p.18)
Install the sound bar as shown in the following illustration.
NOTE
• The sound bar can also be mounted on a wall.
• The frequency characteristics of the sound can be changed according to whether the sound bar is placed on a TV stand or mounted
on a wall.
Related links
• “Mounting the sound bar on a wall (for qualified service personnel)”(p.94)
• “Changing frequency characteristics according to how the sound bar is installed”(p.54)
20
OPTICAL
OO OO
Sound bar (rear)
TV jack
Audio output (Digital optical
audio)
TV
Remove the cap.1. 2. Check the orientation
of the plug.
PREPARATION > Connecting a TV
Connecting a TV
Connecting a TV using only the supplied digital optical audio cable
• Before connecting an external subwoofer, be sure to read the following precautions.
– “Precautions for preparation”(p.18)
Connect a TV using the supplied digital optical audio cable.
1 Connect a TV to the sound bar.
21
To an AC wall outlet
Power cord (supplied)
Sound bar (rear)
AC adaptor (supplied)
PREPARATION > Connecting a TV
2 Connect the sound bar to power.
NOTE
Connect an AV device (such as a set top box) to the TV.
22
HDMI IN
ARC
HDMI
HDMIHDMI
HDMI OUT/TV (ARC) jack
Sound bar (rear)
TV
HDMI input
PREPARATION > Connecting a TV
Connecting a TV using an HDMI cable (sold separately)
• Before connecting an external subwoofer, be sure to read the following precautions.
– “Precautions for preparation”(p.18)
If a TV is connected via an HDMI cable, the sound bar can be controlled by the HDMI Control function using
the TV’s remote control.
Audio Return Channel (ARC)-compatible TV
n
Connect an Audio Return Channel (ARC) compatible TV using an ARC-compatible HDMI cable (sold
separately).
1 Connect a TV to the sound bar.
Connect an HDMI cable to the Audio Return Channel compatible jack (labeled as “ARC”) on the
TV.
23
To an AC wall outlet
Power cord (supplied)
Sound bar (rear)
AC adaptor (supplied)
PREPARATION > Connecting a TV
2 Connect the sound bar to power.
TV that does not support Audio Return Channel (ARC)
n
Connect the TV using an HDMI cable (sold separately) and supplied digital optical audio cable.
24
OPTICAL
HDMI IN
OO OO
HDMI
HDMI
HDMI
HDMI OUT/TV (ARC) jack
Sound bar (rear)
TV jack
Audio output (Digital optical
audio)
HDMI input
TV
Remove the cap.
1. 2.
Check the orientation
of the plug.
PREPARATION > Connecting a TV
1 Connect a TV to the sound bar.
25
To an AC wall outlet
Power cord (supplied)
Sound bar (rear)
AC adaptor (supplied)
PREPARATION > Connecting a TV
2 Connect the sound bar to power.
NOTE
• To activate the Audio Return Channel (ARC), enable the HDMI Control function of the sound bar. (The function is enabled by
default.)
• Use a 19-pin HDMI cable with the HDMI logo printed on it.
• Use a cable that is as short as possible to prevent any degradation in signal quality.
• Connect an AV device (such as a set top box) to the TV.
Related links
“Enabling/disabling the HDMI Control function”(p.47)
26
OUTPUT
OO OO
Sound bar (rear)
Audio device
OPTICAL jack
Audio output (Digital
optical audio)
Remove the cap.1. 2. Check the orientation
of the plug.
PREPARATION > Connecting an audio device
Connecting an audio device
• Before connecting an audio device, be sure to read the following precautions.
– “Precautions for preparation”(p.18)
Devices equipped with audio output jacks can be connected directly to the sound bar.
A device with a digital optical audio output jack
n
Connect an audio device using a digital optical audio cable.
1 Connect an audio device to the sound bar.
27
To an AC wall outlet
Power cord (supplied)
Sound bar (rear)
AC adaptor (supplied)
OUTPUT
Sound bar (rear)
Audio device
ANALOG jack Audio output
PREPARATION > Connecting an audio device
2 Connect the sound bar to power.
NOTE
When connecting a device equipped with video output, connect the video output jack directly to the video input jack on the TV.
A device with an analog audio output jack
n
Connect an audio device using a 3.5 mm stereo mini plug cable (sold separately).
1 Connect an audio device to the sound bar.
28
To an AC wall outlet
Power cord (supplied)
Sound bar (rear)
AC adaptor (supplied)
PREPARATION > Connecting an audio device
2 Connect the sound bar to power.
CAUTION
• If the volume can be adjusted on a device connected to the ANALOG input jack of the sound bar, adjust the volume of the device
so that the volume is about the same for both the TV and the device.
NOTE
When connecting a device equipped with video output, connect the video output jack directly to the video input jack on the TV.
29
Battery insulating strip
PREPARATION > Preparing the remote control
Preparing the remote control
Remove the battery insulating strip before attempting to use the remote control.
Related links
“How to replace the remote control battery”(p.76)
30
Loading...
