The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert you to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle
is intended to alert you to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
Note to CATV system installer:
This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building, as
close to the point of cable entry as practical.
1Read these instructions.
2Keep these instructions.
3Heed all warnings.
4Follow all instructions.
5Do not use this apparatus near water.
6Clean only with dry cloth.
7Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11 Only use attachments/accessories specified by the
manufacturer.
12 Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13 Unplug this apparatus during lightning storms or when
unused for long periods of time.
14 Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
FCC INFORMATION (for US customers)
1 IMPORTANT NOTICE: DO NOT MODI FY THIS UNIT!
This product, when installed as indicated in the instructions
contained in this manual, meets FCC requirements. Modifications
not expressly approved by Yamaha may void your authority,
granted by the FCC, to use the product.
2 IMPORTANT:
and/or another product use only high quality shielded cables.
Cable/s supplied with this product MUST be used. Follow all
installation instructions. Failure to follow instructions could void
your FCC authorization to use this product in the USA.
3NOTE:
the requirements listed in FCC Regulations, Part 15 for Class “B”
digital devices. Compliance with these requirements provides a
reasonable level of assurance that your use of this product in a
residential environment will not result in harmful interference with
other electronic devices.
This equipment generates/uses radio frequencies and, if not
installed and used according to the instructions found in the users
manual, may cause interference harmful to the operation of other
electronic devices.
When connecting this product to accessories
This product has been tested and found to comply with
Compliance with FCC regulations does not guarantee that
interference will not occur in all installations. If this product is
found to be the source of interference, which can be determined by
turning the unit “OFF” and “ON”, please try to eliminate the
problem by using one of the following measures:
Relocate either this product or the device that is being affected by
the interference.
Utilize power outlets that are on different branch (circuit breaker or
fuse) circuits or install AC line filter/s.
In the case of radio or TV interference, relocate/reorient the
antenna. If the antenna lead-in is 300 ohm ribbon lead, change the
lead-in to coaxial type cable.
If these corrective measures do not produce satisfactory results,
please contact the local retailer authorized to distribute this type of
product. If you can not locate the appropriate retailer, please
contact Yamaha Electronics Corp., U.S.A. 6660 Orangethorpe
Ave, Buena Park, CA 90620.
The above statements apply ONLY to those products distributed by
Yamaha Corporation of America or its subsidiaries.
Caution-i En
Caution: Read this before operating your unit.
1 To assure the finest performance, please read this manual
carefully. Keep it in a safe place for future reference.
2 Install this sound system in a well ventilated, cool, dry, clean
place – away from direct sunlight, heat sources, vibration,
dust, moisture, and/or cold. Allow ventilation space of at least
30 cm on the top, 20 cm on the left and right, and 20 cm on
the back of this unit.
3 Locate this unit away from other electrical appliances, motors,
or transformers to avoid humming sounds.
4 Do not expose this unit to sudden temperature changes from
cold to hot, and do not locate this unit in an environment with
high humidity (i.e. a room with a humidifier) to prevent
condensation inside this unit, which may cause an electrical
shock, fire, damage to this unit, and/or personal injury.
5 Avoid installing this unit where foreign objects may fall onto
this unit and/or this unit may be exposed to liquid dripping or
splashing. On the top of this unit, do not place:
– Other components, as they may cause damage and/or
discoloration on the surface of this unit.
– Burning objects (i.e. candles), as they may cause fire,
damage to this unit, and/or personal injury.
– Containers with liquid in them, as they may fall and liquid
may cause electrical shock to the user and/or damage to
this unit.
6 Do not cover this unit with a newspaper, tablecloth, curtain,
etc. in order not to obstruct heat radiation. If the temperature
inside this unit rises, it may cause fire, damage to this unit,
and/or personal injury.
7 Do not plug in this unit to a wall outlet until all connections
are complete.
8 Do not operate this unit upside-down. It may overheat,
possibly causing damage.
9 Do not use force on switches, knobs and/or cords.
10 When disconnecting the power cable from the wall outlet,
grasp the plug; do not pull the cable.
11 Do not clean this unit with chemical solvents; this might
damage the finish. Use a clean, dry cloth.
12 Only voltage specified on this unit must be used. Using this
unit with a higher voltage than specified is dangerous and may
cause fire, damage to this unit, and/or personal injury. Yamaha
will not be held responsible for any damage resulting from use
of this unit with a voltage other than specified.
13 To prevent damage by lightning, keep the power cord and
outdoor antennas disconnected from a wall outlet or the unit
during a lightning storm.
14 Do not attempt to modify or fix this unit. Contact qualified
Yamaha service personnel when any service is needed. The
cabinet should never be opened for any reasons.
15 When not planning to use this unit for long periods of time
(i.e. vacation), disconnect the AC power plug from the wall
outlet.
16 Install this unit near the AC outlet and where the AC power
plug can be reached easily.
17 Be sure to read the “Troubleshooting” section on common
operating errors before concluding that this unit is faulty.
18 Before moving this unit, press ASTANDBY/ON to set this
unit in the standby mode, and disconnect the AC power plug
from the wall outlet.
19 VOLTAGE SELECTOR (Asia and General models only)
The VOLTAGE SELECTOR on the rear panel of this unit
must be set for your local main voltage BEFORE plugging
into the AC wall outlet. Voltages are:
.......................... AC 220/230–240 V, 50/60 Hz (Asia model)
20 The batteries shall not be exposed to excessive heat such as
sunshine, fire or like.
21 Excessive sound pressure from earphones and headphones can
cause hearing loss.
22 When replacing the batteries, be sure to use batteries of the
same type. Danger of explosion may happen if batteries are
incorrectly replaced.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN
OR MOISTURE.
As long as this unit is connected to the AC wall outlet,
it is not disconnected from the AC power source even
if you turn off this unit by ASTANDBY/ON. In this
state, this unit is designed to consume a very small
quantity of power.
FOR CANADIAN CUSTOMERS
To prevent electric shock, match wide blade of plug to
wide slot and fully insert.
This Class B digital apparatus complies with Canadian
ICES-003.
POUR LES CONSOMMATEURS CANADIENS
Pour éviter les chocs électriques, introduire la lame la
plus large de la fiche dans la borne correspondante de
la prise et pousser jusqu’au fond.
Cet appareil numérique de la classe B est conforme à
la norme NMB-003 du Canada.
IMPORTANT
Please record the serial number of this unit in the space
below.
MODEL:
Serial No.:
The serial number is located on the rear of the unit.
Retain this Owner’s Manual in a safe place for future
reference.
“iPod” is a trademark of Apple Inc., registered in the U.S. and other
countries.
Yamaha in accordance with a license agreement.
“HDMI,” the “HDMI” logo and “High-Definition Multimedia
Interface” are trademarks, or registered trademarks of HDMI
Licensing LLC.
x.v.Color™
“x.v.Color” is a trademark of Sony Corporation. “SILENT CINEMA”
is a trademark of Yamaha Corporation.
“SILENT CINEMA” is a trademark of Yamaha Corporation.
INTRODUCTION
PREPARATION
OPERATION
BASIC
Supplied accessories
Check that you received all of the following parts.
• Remote control
• Batteries (2) (AAA, R03, UM-4)
• Optimizer microphone
• AM loop antenna
• Indoor FM antenna
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
3 En
English
Front panel
TDG
UPFEH
Part names and functions
THROUGH
HDMI
VOLUME
MEMORY
INFO
CONTROL
STANDBY
A
PHONES
/ON
SILENT
CINEMA
TONE
JMCOKN
A STANDBY/ON
Switches this unit between standby and on (see page 17).
B PHONES jack
For plugging headphones (see page 22).
C INFO
Changes information display screens on the front panel display
(see page 23).
D MEMORY
Registers FM/AM stations as preset stations (see page 29).
E PRESET l / h
Selects an FM/AM preset station (see page 29).
F FM
Sets the FM/AM tuner band to FM (see page 28).
G AM
Sets the FM/AM tuner band to AM (see page 28).
H TUNING l / h
Changes FM/AM tuner frequencies (see page 28).
I SCENE
Switches between linked sets of input sources and sound field
programs (see page 21).
J TONE CONTROL
Adjusts high-frequency/low-frequency output of speakers (see
page 22).
K PROGRAM l / h
Changes sound field programs (see page 24).
L STRAIGHT
Changes a sound field program to straight decoding mode (see
page 27).
PROGRAM
l
l
BD/DVD
PRESET
h
FM
SCENE
TV
STRAIGHT
h
EFFECT
DIRECT
RADIO
CD
INPUT
l
l
h
OPTIMIZER
TUNING
AUX
MIC
VIDEO
VIDEO
AUDIO
PORTABLE
AM
h
IRBLQS
M DIRECT
Changes a sound field program to direct mode (see page 22).
N INPUT l / h
Selects an input source (see page 21).
O OPTIMIZER MIC jack
For connecting the supplied optimizer microphone and adjusting
output characteristics of speakers (see page 18).
P VOLUME control
Controls the volume of this unit (see page 21).
Q VIDEO (VIDEO AUX) jack
For connecting the video output cable of a camcorder or game
console (see page 16).
R AUDIO L/R (VIDEO AUX) jack
For connecting the audio output cable of a camcorder or game
console (see page 16).
S PORTABLE (VIDEO AUX) jack
For connecting the audio output cable of a portable music player
(see page 16).
T Front panel display
Displays information on this unit (see page 6).
U HDMI THROUGH
Lights up during pass-through output of an HDMI signal input
to this unit while this unit is on standby (see page 42).
4 En
Rear panel
abc
ef hgij
kd
(
)
BD/DVD
DOCK
COMPONENT
VIDEO
PR
PB
Y
OPTICAL
(
TV
A
VIDEO
COAXIAL
COAXIAL
)
V
1
OPTICAL
(CD)
AV 2
AV 3
AV 4
a DOCK terminal
For connecting an optional Yamaha iPod universal dock (YDS-
11) or Bluetooth wireless audio receiver (YBA-10) (see
page 16).
b HDMI OUT/HDMI 1-4
For connecting an HDMI-compatible video monitor or external
components for HDMI inputs 1-4 (see page 15).
c ANTENNA jack
For connecting supplied FM and AM antennas (see page 17).
d SPEAKERS terminal
For connecting front right and left, center, surround and
surround back speakers (see page 11).
e AV 1 - 6
For connecting external components for audio/visual inputs 1-6
(see page 15).
f AV O U T
Outputs audio/visual signals from a selected analog input source
to an external component (see page 16).
g AUDIO 1/2
For connecting external components for audio inputs 1-2 (see
page 16).
h MONITOR OUT
Outputs visual signals from this unit to a video monitor, such as
a TV (see page 14).
i AUDIO OUT
Outputs audio signals from a selected analog input source to an
external component (see page 16).
j PRE OUT
For connecting a subwoofer with a built-in amplifier (see
page 11).
k Power Cable
For connecting this cable to an AC wall outlet (see page 17).
OUT
HDMI 1
HDMI
ANTENNA
COMPONENT
UNBAL.
FM
AV 6
AV 5
VIDEO
PR
GND
AM
PB
VIDEO
Y
MONITOR OUT
AV
AUDIO2
AUDIO1
OUT
HDMI 2HDMI 3
FRONT
HDMI 4
Part names and functions
INTRODUCTION
SPEAKERS
SURROUND
BACK/
CENTER
SURROUND
BI-AMP
PREPARATION
AUDIO
OUT
SUBWOOFER
PRE OUT
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
English
5 En
Part names and functions
abcdef
Front panel display
ghig
a HDMI indicator
Lights up during normal communication when HDMI is
selected as an input source.
b CINEMA DSP indicator
Lights up when a sound field program that uses CINEMA DSP
is selected.
c Tuner indicator
Lights up while receiving a radio broadcast signal from an FM/
AM station (see page 28).
d SLEEP indicator
Lights up when the sleep timer is activated (see page 22).
e VOLUME indicator
Displays volume levels.
f MUTE indicator
Flashes when audio is muted.
g Cursor indicators
Light up if corresponding cursors on the remote control are
available for operations.
h Multi information display
Displays menu items and settings for the current operation.
i Speaker indicators
Indicate speaker terminals from which signals are currently
output.
STEREO
TUNED
SLEEP
VOL.
MUTE
SW
C
LR
SLSR
SBLSB SBR
Subwoofer
Front L
Surround L
Surround back L
SW
C
LR
SLSR
SBLSBSBR
Center
Front R
Surround R
Surround back R
Surround back
6 En
a
Remote control
TRANSMIT
POWER
d
SOURCE
SLEEP
HDMI
1234
1234
g
V-AU X
[ A ][ B ]DOCK
TUNER
FM
INFO
MOVIE
BD
DVD
AM
MEMORY
MUSIC
SCENE
TV
h
i
j
k
l
n
r
ENTER
RETURN
TOP
MENU
REC
1234
s
90
INPUT
t
a Remote control signal transmitter
Transmits infrared signals.
b TRANSMIT
Lights up when a signal is output from the remote control.
c CODE SET
Sets remote control codes for external component operations
(see page 44).
d SOURCE POWER
Switches an external component on and off.
e SLEEP
Switches the sleep timer operations (see page 22).
f POWER
Switches this unit on and standby.
MUTE
TV VOL
CODE SET
POWER
AV
AUDIO
1256
PRESET
TUNING
ENHANCER SUR. DECODE
STEREO
DIRECTSTRAIGHT
CD
RADIO
OPTIONSETUP
VOLUME
DISPLAY
MENU
7856
10
TV
POWER
TV CH
MUTE
ENT
e
q
b
c
f
m
o
p
Part names and functions
g Input selection keys
HDMI 1-4
AV 1 - 6
AUDIO 1/2
V-AUX
Selects HDMI inputs 1 through 4.
Selects AV inputs 1 through 6.
Selects AUDIO inputs 1 and 2.
Selects the V-AUX jack on the front
panel of this unit.
[A]/[B]
To control external components using
the rExternal component operation keys separately from
operations of this unit (see page 44).
DOCK
Selects a Yamaha iPod universal dock/
Bluetooth wireless audio receiver
connected to the DOCK jack.
TUNER
Selects the FM/AM tuner.
h Tuner keys
FM
Switches a band between FM and AM.
AM
MEMORY
PRESET k / n
TUNING k / n
Presets radio stations.
Selects a preset station.
Changes tuning frequencies.
i INFO
Changes the information shown on the front panel display (see
page 23).
j Sound selection keys
Selects sound field programs (see page 24).
k SCENE
Switches between linked sets of input sources and sound field
programs (see page 21).
l SETUP
Displays the setup menu (see page 39).
m OPTION
Displays the option menu (see page 33).
n Cursors k / n / l / h/ENTER/RETURN
Cursors k / n / l / h
Select menu items displayed on the
front panel display or on a video
monitor, or change settings.
ENTER
RETURN
Confirms a selected item.
Returns to the previous screen or
ends the menu display.
o VOLUME + /–
Adjust the volume of this unit (see page 21).
p DISPLAY
Changes the operation mode of the iPod connected to the
Yamaha iPod universal dock (see page 30).
q MUTE
Turns the mute function of the sound output on and off (see
page 22).
r External component operation keys
Operate recording, playback etc. of external components (see
page 44).
s Numeric keys
Enter numbers.
t TV control keys
Operate a monitor such as a TV or projector.
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
English
7 En
Quick start guide
When you use this product for the first time, perform setup following the steps below. See the related pages for details on
operations and settings.
Step 1: Prepare items for setup
Prepare speakers, DVD player, cables, and other items
necessary for setup.
For example, prepare the following items for setting up a
5.1-channel sound system.
Front right speaker
Video monitor
Front left speaker
Center speaker
Components
(such as DVD player)
Surround left speaker
Requirementsqty.
SpeakersFront speaker2
Center speaker1
Surround speaker2
Active subwoofer1
Speaker cable5
Subwoofer cable1
Reproduction component such as DVD player1
Video monitor such as TV1
Video cable or HDMI cable2
Audio cable2
y
• Prepare two speakers (for front). The priority of the requirement of other
speakers is as follows:
1 Two surround speakers
2 One center speaker
3 One (or two) surround back speaker(s)
• If your video monitor is a CRT, we recommend that you use magnetically
shielded speakers.
Subwoofer
Surround right speaker
Step 2: Set up your speakers
Place your speakers in the room and connect them to this
unit.
• Placing speakers☞P. 1 0
• Connecting speakers☞P. 1 1
y
• This unit has a YPAO (Yamaha Parametric Room Acoustic Optimizer)
that automatically optimizes this unit based on room acoustic
characteristics (audio characteristics of the speakers, speaker positions,
and room acoustics, etc.).
You can enjoy good balanced sound without special knowledge by using
the YPAO technology (see page 18).
Step 3: Connect your components
Connect your TV, DVD player, or other components.
• Connecting a TV monitor or projector☞P. 1 4
• Connecting other components☞P. 1 5
• Connecting a Yamaha iPod universal dock or
Bluetooth wireless audio receiver☞P. 1 6
• Connecting the FM and AM antennas☞P. 1 7
Step 4: Turn on the power
Connect the power cable and turn on this unit.
• Connecting the power cable☞P. 1 7
• Turning this unit on and off☞P. 1 7
Step 5: Select the input source and start
playback
Select the component connected in the step 3 as an input
source and start playback.
• Basic procedure☞P. 2 1
• Selecting sound field programs☞P. 2 4
y
• This unit supports the SCENE function that changes the input source and
sound field program at one time. Four scenes are preset for different
purposes for Blu-ray disc, DVD and CD, and you can select from a scene
from those just by pressing a remote control key. See page 21 for details.
8 En
PREPARATION
Preparing remote control
Installing batteries in the remote
control
1
1Take off the battery compartment cover.
2Insert the two supplied batteries (AAA, R03,
UM-4) according to the polarity markings (+
and –) on the inside of the battery
compartment.
3Snap the battery compartment cover back
into place.
Notes
• Change all batteries if you notice the following conditions:
– the operation range of the remote control narrows
– the transmit indicator does not flash or is dim
• Do not use old batteries together with new ones.
This may shorten the life of the new batteries or cause old batteries
to leak.
• Do not use different types of batteries (such as alkaline and
manganese batteries) together. Specification of batteries may be
different even though they look the same.
• If you find leaking batteries, discard the batteries immediately,
taking care not to touch the leaked material. If the leaked material
comes into contact with your skin or gets into your eyes or mouth,
rinse it away immediately and consult a doctor. Clean the battery
compartment thoroughly before installing new batteries.
• Dispose of the old batteries correctly in accordance with your local
regulations.
• If the remote control is without batteries for more than 2 minutes,
or if exhausted batteries remain in the remote control, the contents
of the memory may be cleared. In such a case, install new batteries
and set the remote control code.
3
2
Using the remote control
The remote control transmits a directional infrared ray. Be
sure to aim the remote control directly at the remote
control sensor on this unit during operation.
Remote control sensor window
within 6 m (20 ft)
30 30
Notes
• Do not spill water or other liquids on the remote control.
• Do not drop the remote control.
• Do not leave or store the remote control in the following conditions:
– places of high humidity, such as near a bath
– places of high temperatures, such as near a heater or stove
– places of extremely low temperatures
– dusty places
y
• You can operate external components with this remote control by setting
the remote control code. See page 44 for details.
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
9 En
English
Connections
Placing speakers
This unit supports up to 7.1-channel surround. We recommended the following speaker layout in order to obtain the
optimum surround effect.
7.1-channel speaker layout
Speaker channels
80˚
SBL
C
30˚
60˚
FL
SW
SL
SL
30 cm (12 in) or more
6.1-channel speaker layout
FL
SW
SL
SL
C
30˚
60˚
80˚
SB
5.1-channel speaker layout
FL
SW
SL
SL
C
30˚
60˚
80˚
SBR
FR
■Front left and right speakers (FL and FR)
The front speakers are used for the front channel sounds
(stereo sound) and effect sounds. Place these speakers at
SW
an equal distance from the ideal listening position. When
using a screen, the appropriate top positions of the
speakers are about 1/4 of the screen from the bottom.
SR
SR
■Center speaker (C)
The center speaker is for the center channel sounds
(dialog, vocals, etc.). Place it halfway between the left and
right speakers. When using a TV, place the speaker just
above or just under the center of the TV with the front
surfaces of the TV and the speaker aligned. When using a
screen, place it just under the center of the screen.
■Surround left and right speakers (SL and SR)
The surround speakers are used for effect and surround
sounds.
FR
SW
Place them at the rear left and rear right facing the
listening position.
To obtain a natural sound flow in the 5.1-channel speaker
layout, place them slightly further back than in the 7.1channel speaker layout.
■Surround back left and right speakers (SBL
SR
and SBR) / Surround back speaker (SB)
The surround back left and right speakers are used for rear
SR
effect sounds. Place them at the rear of the room facing the
listening position at least 30 cm away from each other,
ideally at the same distance as that between the front left
and right speakers.
In the 6.1-channel speaker layout, surround back left and
right channel sound signals are mixed down and output
from the single surround back speaker.
FR
In the 5.1-channel speaker layout, surround back left and
right channel sound signals are output from the surround
SW
left and right speakers.
■Subwoofer (SW)
The subwoofer speaker is used for bass sounds and lowfrequency effect (LFE) sounds included in Dolby Digital
SR
SR
and DTS signals. Use a subwoofer with a built-in
amplifier, such as the Yamaha Active Servo Processing
Subwoofer System. Place it exterior to the front left and
right speakers facing slightly inward to reduce reflections
from a wall.
10 En
Connecting speakers
DMI 3
AUDIO
OUT
Connections
When you connect speakers, connect them to the respective terminals as follows, according to your speaker layout.
■7.1-channel
SpeakersJacks on this unit
b
a
c
gf
a Front speaker LFRONT (L)
b Front speaker RFRONT (R)
SPEAKERS
c Center speakerCENTER
d Surround speaker LSURROUND (L)
e Surround speaker RSURROUND (R)
FRONT
CENTER
SURROUND
SURROUND
BACK/
BI-AMP
f Surround back speaker LSURROUND
BACK/BI-AMP (L)
g Surround back speaker R SURROUND
BACK/BI-AMP (R)
h SubwooferSUB WOOFER
■6.1-channel
SUBWOOFER
ed
h
PRE OUT
a Front speaker LFRONT (L)
b Front speaker RFRONT (R)
c Center speakerCENTER
d Surround speaker LSURROUND (L)
e Surround speaker RSURROUND (R)
f Surround back speakerSURROUND
h SubwooferSUB WOOFER
SpeakersJacks on this unit
BACK/BI-AMP (L)
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
■5.1-channel
SpeakersJacks on this unit
a Front speaker LFRONT (L)
b Front speaker RFRONT (R)
c Center speakerCENTER
d Surround speaker LSURROUND (L)
e Surround speaker RSURROUND (R)
h SubwooferSUB WOOFER
English
11 En
Connections
Connecting the speaker cable
Caution
• A speaker cable is a pair of insulated cables running side by side in general. One of the cables is colored differently
or striped to indicate a polarity. Connect one end of the colored/striped cable to the “+” (red) terminal of this unit
and the other end to that of your speaker, and connect one end of the other cable to the “–” (black) terminal of this
unit and the other end to that of your speaker.
• Before connecting the speakers, be sure to disconnect the power cable.
• Do not let the bare speaker wires touch each other or any metal part of this unit. This could damage this unit and/or
speakers. If the circuit shorts out, “CHECK SP WIRES!” appears on the front panel display when this unit is turned on.
• Use magnetically shielded speakers. If images on the monitor are still distorted even when you use the magnetically
shielded speakers, place the speakers away from the monitor.
• Use speakers with an impedance of 6-ohm or larger. Set speaker impedance in “ADVANCED SETUP” before
connecting the speakers (see page 45).
■Connecting to the FRONT terminals
1Remove approximately 10 mm (0.4 in) of
insulation from the end of each speaker
cable and then twist bare wires of the cable
together so that they will not cause a short
circuits.
10 mm (0.4 in)
2Loosen the knob, insert the twisted bare
wires into the hole, and then tighten the
knob.
2
1
Red: positive (+)
Black: negative (–)
3
■Connecting to the CENTER, SURROUND,
SURROUND BACK/BI-AMP terminals
1Press down the tab and insert the bare end of
the speaker cable into the hole in the
terminal.
Red: positive (+)
Black: negative (–)
2Release the tab to secure the wire.
Using bi-amplification connections
You can connect speakers that support bi-amplification
connections to this unit. Before connecting the speakers,
set this unit to enable bi-amplification connections in
“ADVANCED SETUP” (see page 45), and connect the
speakers to this unit as shown below.
Front speakers
RightLeft
Connecting the banana plug (Except U.K.,
Europe, Asia and Korea models)
Tighten the knob, and then insert the banana plug into
the end of the terminal.
Banana plug
12 En
SURROUND
BACK/
FRONT
BI-AMP
This unit
Caution
Before making bi-amplification connections, remove
any or cables that connect a woofer with a tweeter.
Refer to the instruction manuals of speakers for details.
When not making bi-amplification connections, make
sure that the brackets or cables are connected before
connecting the speaker cables.
Information on jacks and cable plugs
Connections
This unit has the following input and output jacks. Use jacks and cables appropriate for components that you are
connecting.
■Audio jacks
Jack and cablesDescription
AUDIO jacksTo transmit conventional analog
(white)
L
R
AUDIO
(red)
COAXIAL jacksTo transmit coaxial digital audio
(orange)
C
COAXIAL
OPTICAL jacksTo transmit optical digital audio
OPTICAL
O
left and right audio signals. Use
stereo pin cables. Connect red
plugs to red jacks (R) and white
plugs to white jacks (L).
signals. Use pin cables for digital
audio signals.
signals. Use optical fiber cables for
optical digital audio signals.
■Video/audio jacks
Jack and cablesDescription
HDMI jacksTo transmit digital video and
digital audio signals. Use HDMI
HDMI
y
• We recommend that you use a commercially available 19-pin HDMI
cable no longer than 5 meters (16 feet) with the HDMI logo printed on it.
• You can check the potential problem about the HDMI connection (see
page 23).
• You can check error information on HDMI connections (see page 23).
HDMI
cables.
A video signal input to this unit is output from the
output terminals in MONITOR OUT for the same kind
of signal as the input signal.
For example, if a VCR with a composite output signal
and a DVD player with a COMPONENT VIDEO
output signal are connected, connect both VIDEO jack
and COMPONENT VIDEO jack in MONITOR OUT
to the video monitor.
If an HDMI input compatible monitor is connected, this
■Video jacks
Jack and cablesDescription
VIDEO jacksTo transmit conventional
VIDEO
V
(yellow)
composite video signals. Use video
pin cables.
unit automatically converts an analog signal that is
input from a video input terminal to a digital video
signal, and then output it from the HDMI OUT jack.
InputOutput
HDMI
COMPONENT
VIDEO
HDMI
COMPONENT
VIDEO
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
COMPONENT VIDEO
jacks
COMPONENT
VIDEO
P
PR
(red)
PB
(blue)
Y
(green)
R
P
B
Y
To transmit component video
signals that include luminance (Y),
chrominance blue (PB) and
chrominance red (PR) components.
Use component video cables.
P
R
P
B
Y
VIDEO
RepeatConverted
P
VIDEO
R
P
B
Y
English
13 En
Connections
U
FM
GND
AM
(
)
D
OPTICAL
(
TV
)
UNBAL.
FM
GND
AM
Y
P
R
P
B
AV
1
COAXIAL
AV 3
(CD)
COAXIAL
OPTICAL
AV 4
AV 5
OUT
AUDIO1
VIDEO
AV 6
Connecting a TV monitor or projector
Connect a video monitor such as a TV or projector to an output terminal of this unit. You can select one of the following
three types according to the input signal format supported by the video monitor.
Note
• When you connect this unit to the video monitor, make sure that this unit is on standby.
TV, or projector
a
c
b
R
PBYP
BD/DVD
COMPONENT
VIDEO
P
R
P
B
Y
MONITOR OUT
HDMI 2H
VIDEO
NBAL.
HDMI
HDMI
OUT
■To connect an HDMI video monitor
Jacks on componentsJacks on this unit
a HDMI inputHDMI OUT
Outputting sound of a TV from this unit
To output sound of a TV from this unit, make connection
between the AV input 1-6 and an audio output terminal.
If the TV supports an optical digital output, we
recommend that you use the AV input 1. Connecting to the
AV input 1 allows you to switch an input source to the AV
input 1 with just a single key operation using the SCENE
function (see page 21).
V
O
TV, or projector
Digital output
(optical)
■To connect component video monitor
Note
• Only video signals input from this unit via the component input terminal
are output from the component output terminal.
Jacks on componentsJacks on this unit
b Component video outputMONITOR OUT
(COMPONENT VIDEO)
■To connect composite video monitor
Note
• Only video signals input from this unit via the composite video input
terminal are output from the composite video output terminal.
Jacks on componentsJacks on this unit
c Video input (composite)MONITOR OUT (VIDEO)
14 En
Connecting other components
MONITO
U
GND
R
Y
T
V
O
DOC
HDMI
O
O
MONITOR OUT
T
CE
Connections
This unit has input and output terminals for respective input and output sources. You can reproduce sound and movies
from input sources selected with the front panel display or remote control.
Note
• When you connect this unit to the external components, make sure that this unit is on standby.
Audio / video input (AV 1-6)Audio / video output (AV OUT)
HDMI input
(HDMI 1-4)
Audio output
(AUDIO OUT)
COMPONENT
VIDEO
P
R
P
B
Y
OPTICAL
(
TV
A
V
(
)
BD/DVD
AV 6
NBAL.
UT
HDMI 1
AV
AUDIO1
OUT
K
VIDEO
COAXIAL
COAXIAL
)
AV 2
1
OPTICAL
(CD)
AV 3
AV 4
AV 5
COMPONEN
IDE
P
AUDIO2
HDMI 2HDMI 3
VIDE
FRON
HDMI 4
AUDIO
OUT
Audio input (AUDIO 1-2)
■Audio and video player / Set-top box
Output jacks on the connected external component
External
components
External component
with HDMI output
SignalsOutput jacks
Audio/Video HDMI outputHDMI 1 (BD/DVD)HDMI 1
HDMI 2HDMI 2
HDMI 3HDMI 3
HDMI 4HDMI 4
External component
with component video
output
AudioOptical digital outputAV 1 (TV)OPTICAL
VideoComponent videoCOMPONENT VIDEO
AudioCoaxial digital outputAV 2COAXIAL
VideoComponent video outputCOMPONENT VIDEO
External component
with composite video
output
AudioCoaxial digital outputAV 3 (CD)COAXIAL
VideoComposite outputVIDEO
AudioOptical digital outputAV 4OPTICAL
VideoComposite outputVIDEO
AudioAnalog audio outputAV 5AUDIO
VideoComposite outputVIDEO
AudioAnalog audio outputAV 6AUDIO
VideoComposite outputVIDEO
y
• Input sources in parentheses are recommended to connect to the respective jacks. If your Yamaha component has the Remote in/out terminal, you can
switch the input source to that component with a single key operation using the SCENE function (see page 21).
• You can change the name of the input source displayed on the front panel display or the OSD on the video monitor as necessary (see page 43).
Input sources/jacks of this unit
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
English
15 En
Connections
DOCK
UNBAL
GND
V
O
P
R
Y
V
O
HDMI
OUT
COMPO
OGRAM
S
INPUT
O
C
E
CT
D
CD
O
SC
PRES
l
T
G
AM
■Audio player
Output jacks on the connected external component
External componentsOutput jacks
External component with optical digital
output
External component with coaxial digital
output
External component with analog audio
output
Optical digital outputAV 1 (TV)OPTICAL
AV 4OPTICAL
Coaxial digital outputAV 2COAXIAL
AV 3 (CD)COAXIAL
Analog audio outputAV 5AUDIO
AV 6AUDIO
AUDIO 1AUDIO
AUDIO 2AUDIO
y
• We recommend connecting the coaxial digital output terminal of a CD player to the AV3 jack.
Input sources/jacks of this unit
About audio/video output terminals
Among the analog audio and analog video signals input to this unit via input terminals, the audio/video signals of the
selected input sources are output from the AV OUT jack and AUDIO OUT jack. An HDMI input signal,
COMPONENT VIDEO input signal or digital audio input signal cannot be output.
When using the AV OUT jack: connect an external component to the composite or analog audio terminal.
When using the AUDIO OUT jack: connect an external component to the analog audio terminal.
Connecting a Yamaha iPod universal
dock or Bluetooth™ wireless audio
receiver
This unit has the DOCK jack, to which you can connect a
Yamaha iPod universal dock (YDS-11, sold separately) or
a Bluetooth wireless audio receiver (YBA-10, sold
separately). You can play an iPod or a Bluetooth
component with this unit by connecting it to the DOCK
jack.
Use a dedicated cable for connection between the dock/
receiver and this unit.
Use the VIDEO AUX jacks on the front panel to connect a
game console or a video camera to this unit. Be sure to
turn down the volume of this unit and other components
before making connections.
VOLUM
PTIMIZERMI
UNIN
AUX
VIDEO
VIDEO
AUDIO
PORTABLE
PORTABLE
RLAUDIO
Analog audio
output
R
ET
ENE
D/DV
TRAIGHT
EFFE
Video output
DIRECT
VIDEO
V
RADI
l
Analog audio
output
L
Game console/CamcorderMusic player
Note
• When external components are connected both the PORTABLE jack and
AUDIO jack, sound input from the PORTABLE jack is output.
16 En
Connections
COMPO
T
O
O
O
(
D
)
OU
O
COMPO
T
Connecting the FM and AM antennas
An indoor FM antenna and an AM loop antenna are
supplied with this unit. Connect these antennas properly to
the respective jacks.
Indoor FM antenna
DOCK
NEN
VIDE
P
Y
y
• The supplied antennas are normally sensitive enough to obtain good
reception.
• Position the AM loop antenna away from this unit.
• If you cannot get good reception, we recommend that you use an outdoor
antenna. For more details, consult the nearest authorized Yamaha dealer
or service center.
• Always use the AM loop antenna even when the outdoor antenna is
connected.
Outdoor AM antenna
Connect a 5 to 10 m (16
to 33 ft) vinyl-covered
wire, and extend it
outdoors (use the AM
loop antenna together
with this antenna).
D/DV
T
ANTENNA
UNBAL.
VIDE
Ground (GND terminal)
The GND terminal is not for earth
grounding.
To reduce noises, connect a ground bar or a
vinyl-covered wire with a copper plate at its
tip, and place it in the moist ground.
FM
NEN
VIDE
GND
AM
P
MONITOR OUT
Assembling the AM loop antenna
AM loop
antenna
2
3
VIDE
Connecting the power cable
After all connections are complete, plug the AC power
cable of this unit into an AC wall outlet.
To the AC wall outlet
Power cable
Turning this unit on and off
1Press ASTANDBY/ON on the front panel (or
fPOWER on the remote control) to turn on
this unit.
2Press ASTANDBY/ON (or fPOWER) again
to turn off this unit (standby mode).
y
• The unit needs a few seconds until ready to play back.
• You can also turn on this unit by pressing ISCENE (or kSCENE).
• This unit consumes a small amount of electricity even in the standby
mode. We recommend disconnecting the power cable from the AC wall
outlet.
Caution
Do not unplug this unit while it is turned on. Doing so
may damage this unit or cause the settings of this unit
to be saved incorrectly.
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
Connecting the AM loop antenna
The wires of the AM loop antenna have no polarity. You
can connect either wire to the AM terminal and the other
to the GND terminal.
Press and holdReleaseInsert
English
17 En
Optimizing the speaker setting for your listening room (YPAO)
V
O
A
O
O
UX
This unit has a Yamaha Parametric Acoustic Optimizer (YPAO). With the YPAO, this unit automatically adjusts the
output characteristics of your speakers based on speaker position, speaker performance, and the acoustic characteristics
of the room. We recommend that you first adjust the output characteristics with the YPAO when you use this unit.
Caution
• Be advised that it is normal for loud test tones to be
output during the “Auto Setup” procedure. Do not
allow small children to enter the room during the
procedure.
• To achieve the best results, make sure the room is as
quiet as possible while the “Auto Setup” procedure is
in progress. If there is too much ambient noise, the
results may not be satisfactory.
y
• See page 39 for the “Manual Setup” procedure.
Using Auto Setup
1Check the following points.
Before starting the automatic setup, check the
following.
• All speakers and subwoofer are connected
properly.
• Headphones are disconnected from this unit.
• The video monitor is connected properly.
• This unit and the video monitor are turned on.
• This unit is selected as the video input source of the
video monitor.
• The connected subwoofer is turned on and the
volume level is set to about half way (or slightly
less).
• The crossover frequency controls of the connected
subwoofer are set to the maximum.
CROSSOVER/
VOLUME
HIGH CUT
“MIC ON. View OSD MENU” appears on the front panel
display.
The following menu screen appears on the video monitor.
1 AutoSetup
EQ Type;;;;Natural
. Start
[
[
[]/[]:Up/Down
[ENTER]:Start
y
• You can bring up the above menu screen from the setup menu (see
page 39).
3Place the optimizer microphone at your
normal listening position on a flat level
surface with the omni-directional
microphone heading upward.
Optimizer microphone
y
• It is recommended that you use a tripod or something similar to fix the
optimizer microphone at the same height as your ears would be when
seated in your listening position. You can fix the optimizer microphone to
the tripod with the attaching screw of the tripod.
4To select a sound character for adjustment,
MINMAX
Subwoofer
MINMAX
2Connect the supplied optimizer microphone
to the OPTIMIZER MIC jack on the front
panel.
A
OPTIMIZER
MIC
VIDE
IDE
UDI
Optimizer microphone
PORTABLE
press nCursork to select “EQ Type” and
then press nCursorl / h.
If this unit does not work when you press nCursor,
press lSETUP once and then operate this unit.
This unit has a parametric equalizer that adjusts the
output levels for each frequency range. The equalizer
is adjusted to produce a cohesive sound field based on
automatically measured speaker characteristics.
In “EQ Type,” you can select the following
parametric equalizer characteristics suitable for the
desired sound characteristics.
Natural
This adjusts all speakers to achieve natural sound.
Select this if sounds in the high frequency range seem
too strong when “EQ Type” is set to “Flat.”
18 En
Optimizing the speaker setting for your listening room (YPAO)
Flat
This adjusts each speaker to obtain the same
characteristics. Select this if your speakers have
similar qualities.
Front
This adjusts each speaker to obtain the same
characteristics as the front left and right speakers.
Select this if your front left and right speakers have
significantly better qualities than the other speakers.
5Press nCursorn to select “Start” and then
press nENTER to start the setup procedure.
A countdown starts and a measurement starts in 10
seconds. A loud test tone is output during
measurement.
Notes
• During the automatic setup procedure, do not perform any
operation on this unit.
• Press nCursork to cancel the automatic setup procedure.
Measurement takes about 3 minutes. To obtain precise
results, stay where you will not disturb the
measurement, such as to the side of or behind the
speakers or outside the room.
When measurement is successfully completed,
“YPAO Complete” appears on the front panel display
and the results appear on the monitor.
6Press nENTER to confirm the settings.
The speaker characteristics are adjusted according to
measurement results.
To cancel the operation, press nCursorl / h to
select “Cancel” and press nENTER.
When the following screen appears, remove the
optimizer microphone. “Auto Setup” is now
complete.
1 AutoSetup
AUTOSETUPComplete
DisconnectMicrophone
PRESS[ENTER]
[SETUP]:Exit
The optimizer microphone is sensitive to heat. Store it
in a cool place and away from direct sunlight after
measurement. Do not leave it in a place where it will be
subjected to high temperatures such on an AV
component.
y
• If you do not want to apply the measurement results, select “Cancel.”
• Perform “Auto Setup” again if you change the number or positions of
speakers.
• If you press nENTER before removing the optimizer microphone,
“1 Auto Setup” of “Speaker Setup” in the setup menu (see page 39) is
displayed.
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
1 AutoSetup
RESULT
SP:3/4/0.1
DIST:8.0/8.5ft
LVL:-3.5/+4.5dB
.>SetCancel
[]/[]:Select
p[
[ENTER]:Finish
SP
Displays the number of speakers connected to this unit in
the following order:
Total of Front and Center/Total of Surround and Surround
Back/Subwoofer
DIST
Displays the speaker distance from the listening position
in the following order:
Closest speaker distance/Farthest speaker distance
LVL
Displays the speaker output levels in the following order:
Lowest speaker output level/Highest speaker output level
Notes
• If “ERROR” appears on the video monitor during “Auto Setup,”
measurement is canceled and the type of error is displayed. For details,
see “When an error message is displayed during measurement”
(page 20).
• If problems occur during measurement, “WARNING (XX)” (xx indicates
the number of warning) appears above “RESULT” (see page 20).
INFORMATIONAPPENDIX
ADDITIONAL
English
19 En
Optimizing the speaker setting for your listening room (YPAO)
When an error message is displayed
during measurement
Select “Retry” or “Exit” using nCursorl / h
and then press nENTER.
ERROR
.E-9:USER CANCEL
any function
>RetryExit
[ENTER]:Return
Retry
Performs “Auto Setup” again.
Exit
Terminates the measurement and “Auto Setup.”
y
• See page 51 for details on error messages.
• When “E-5:NOISY” appears, you can continue measurement. To
continue measurement, select “Proceed.” However, we recommend that
you solve the problem first and then perform measurement again.
operate
Don't
[]/[]:Select
p[
When a warning message is displayed
after measurement
If a problem occurs during measurement, “WARNING” is
displayed on the result display screen. Check the error and
solve the problems.
• Optimization will not be performed while a warning message is
displayed. We recommend that you solve the problem and perform “Auto
Setup” again.
1Check if “→” is displayed on the left of
“WARNING” and press nENTER.
Details of the warning message are displayed. If there
are multiple warning messages, you can display the
next message using nCursorh.
2To return to the top result display, press
nENTER again.
20 En
BASIC OPERATION
Playback
Basic procedure
1Turn o n ex t er n al c omponents (TV, DVD
player, etc.) connected to this unit.
2Press NINPUT l / h (or gInput
selection keys) to select an input source.
The name of the selected input source is displayed for
a few seconds.
Input source name
VOL.
AV1
y
• You can change the input source name displayed on the front panel
display or the OSD on the video monitor as necessary (see
page 43).
3Play the external component that you have
selected as the source input, or select a radio
station on the tuner.
Refer to the operating instructions of the external
component for details on playback. For selecting
radio stations or playback of an iPod or Bluetooth
component using this unit, see the following.
• FM/AM radio tuning (see page 28)
• Bluetooth component playback (see page 32)
• iPod playback (see page 30)
4Turn t h e PVOLUME control to adjust the
volume (or press oVOLUME +/–).
Vol um e
VOL.
SW
C
LR
Volume-18.5dB
Note
When you play back a DTS-CD, noise may be output in some
conditions, which may cause a speaker malfunction. Make sure
that the volume is set to low before starting playback. If noise is
output, do the following.
1) When only noise is output
If a DTS bitstream signal is not properly input to this unit,
only noise is output. Connect the playback component to this
unit by digital connection and play back the DTS-CD. If the
condition is not improved, the problem may results from the
playback component. Consult the manufacturer of the
playback component.
2) When noise is output during playback or skip operation
Before playing back the DTS-CD, display the option menu
after selecting the input source and set “Decoder Mode” to
“DTS” (see page 33).
SLSR
Using the SCENE function
This unit has a SCENE function that allows you to change
input sources and sound field programs with one key. Four
scenes are available for different usages, such as playing
movies or music. The following input sources and sound
field programs are provided as the initial factory settings.
Input sourceSound field program
BD/DVDHDMI 1Straight
TVAV 1Straight
CDAV 3Straight
RADIOTUNER7ch Enhancer
y
• When this unit is on standby, you can turn on this unit by pressing the
SCENE key.
Selecting a SCENE
Press ISCENE (or kSCENE).
Registering input source/sound field
program
Select the desired input source/sound field
program, and pressing down ISCENE (or
kSCENE) until “SET Complete” appears on the
front panel display.
While display in the OPTION menu or SETUP menu,
“SCENE Setting Complete” appears on the video monitor
(OSD).
Switching remotely controlled external
components linked to scene selections
You can operate an external component with the remote
control of this unit by setting a remote control code for the
external component for each input source. Setting remote
control codes for desired input sources allows you to
switch between external components linked to scene
selections.
1Register the remote control code of an
external component to the desired input
source (see page 44).
Note
• Remote control codes cannot be registered to TUNER input.
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
English
21 En
Playback
2Press gInput selection keys on the
remote control for the input source whose
remote control code was registered in step 1
for about 3 seconds while pressing down
kSCENE key whose assignment you want
to change.
The external component can now be controlled
remotely just by selecting a scene.
Muting audio output temporarily
(MUTE)
1Press qMUTE on the remote control to mute
the audio output.
The MUTE indicator on the front panel display
flashes while audio output is muted.
2Press qMUTE again to resume audio
output.
Adjusting high/low frequency sound
(tone control)
You can adjust the balance of the high frequency range
(Treble) and low frequency range (Bass) of sounds output
from the front left and right speakers to obtain desired tone.
1Press JTONE CONTROL on the front panel
repeatedly to select “Treble” or “Bass.”
The current setting is displayed on the front panel
display.
Enjoying pure hi-fi sound
Use Direct mode to enjoy the pure high fidelity sound of
the selected source. When Direct mode is activated, this
unit plays back the selected source with the least circuitry.
Press MDIRECT (or jDIRECT) to turn the
Direct mode on or off.
The following features are disabled in Direct mode.
– sound field program, tone control
– display and operation of the option menu and setup
menu
y
• While direct mode is on, the front panel display screen becomes dim.
When setting it back off, the brightness of the screen returns to the
previous setting.
Using the sleep timer
The sleep timer is useful if you want to go to sleep while
this unit is playing or recording a source.
Press eSLEEP repeatedly to set the amount of
time.
Each time you press eSLEEP, the front panel display
changes as shown below.
Sleep 120min.Sleep 90min.
Sleep 60min.Sleep 30min.Sleep Off
When the sleep timer is set, the SLEEP indicator on the
front panel display lights up.
Press eSLEEP on the remote control repeatedly until
“Sleep Off” appears on the front panel display.
Treble
0.0dB
2Adjust the frequency range using
KPROGRAMl / h.
Control range: –10.0 dB to +10.0 dB
The display returns the previous screen soon after you
release the key.
Notes
• The tone control settings are not effective during playback in direct
mode.
• If you set the balance extremely off, sounds may not match those from
other channels well.
Using your headphones
Plug your headphones in the BPHONES jack on
the front panel.
When you select a sound field program while using the
headphones, the mode is automatically set to SILENT
CINEMA mode.
Notes
• When you connect headphones, no signals are output at the speaker
terminals.
• When multi-channel signals are processed, sounds in all channels are
divided to left and right channels.
22 En
Displaying input signal informationChanging information on the front
When HDMI1-4 or AV1-4 is selected as the input source,
you can display audio/video signal information.
y
• Input signal information is displayed on both a video monitor and the
front panel display.
• Information on the input signal is also displayed on the front panel
display. You can select the desired item using nCursork / n.
1Select the desired input source, and press
mOPTION.
The option menu for the selected input source is
displayed (see page 33).
panel display
Information displayed on the front panel display can be
changed by pressing CINFO (or iINFO).
The following information can be displayed according to
the input source.
For example, if you select HDMI1 input and display “DSP
Program,” the following screen appears on the front panel
display.
Input source
Playback
INTRODUCTION
PREPARATION
2Press nCursork / n to select “Signal Info,”
and press nENTER.
Information on input signals is displayed. See
page 34 on messages displayed on the screen.
Notes
• If an HDMI related error occurs, error information is displayed at
the bottom of the screen.
• Information on the input signal is also displayed on the front panel
display. You can select the desired item using nCursork / n.
iPod (Menu browse mode): (in PlayInfo displayed) Artist, Album,
Song, DSP Program, Audio Decoder
(in Play menu displayed) List
Bluetooth:Input, DSP Program, Audio Decoder
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
23 En
English
Enjoy the sound field programs
This unit is also equipped with a Yamaha digital sound field processing (DSP) chip. You can enjoy multi-channel sounds
for almost all input sources using various sound field programs stored on the chip and a variety of surround decoders.
Selecting sound field programs
■Selecting a sound field program on the front panel
Press KPROGRAMl / h repeatedly to select a desired sound field program.
■Selecting a sound field program with the remote control
Perform the following operations depending on the category of the sound field programs.
Sound field programs for movies/TV programs ...............................Press jMOVIE repeatedly.
Sound field programs for music........................................................Press jMUSIC repeatedly.
For example, if you select “Sci-Fi” in “movie/TV program,” the following screen appears on the front panel display.
Sound field program category
Sci-Fi
Program name
Notes
• Sound field programs are stored for each input source. When you change the input source, the sound field program previously selected for that input
source is applied again.
• When you play back the Dolby Digital Plus, Dolby TrueHD, DTS Express, DTS-HD Master Audio, or DTS-HD High Resolution Audio sources, this unit
does not apply any sound field program other than the surround decoder and they are played back in straight decode mode.
• If the sampling frequency of an input source is higher than 96 kHz, this unit does not apply any sound field programs.
Sound field program descriptions
This unit provides sound field programs for multiple categories including music, movies and stereo reproduction. Select
a sound field program based on your listening preference, not merely on the name of the program, etc.
y
• You can check what speakers are currently outputting signals with the speaker indicators on the front panel display (see page 6).
• Each program can adjust sound field elements (sound field parameters). For details, see page 36.
• in the table indicates the sound field program with CINEMA DSP.
For movie/TV program sources
ProgramDescriptions
StandardThis program creates a sound field emphasizing the surrounding feeling without disturbing the original acoustic
positioning of multi-channel audio such as Dolby Digital and DTS. It has been designed with the concept of “an
ideal movie theater,” in which the audience is surrounded by beautiful reverberations from the left, right and rear.
SpectacleThis program represents the spectacular feeling of large-scale movie productions.
It reproduces a broad theater sound field matching the cinemascope and wider-screen movies with an excellent
dynamic range from very small to extremely large sound.
Sci-FiThis program clearly reproduces the finely elaborated sound design of the latest science fiction and special effects-
featuring movies.
You can enjoy a variety of cinematographically created virtual spaces reproduced with clear separation between
dialog, sound effects and background music.
AdventureThis program is ideal for precisely reproducing the sound design of action and adventure movies.
The sound field restrains reverberations but puts emphasis on reproducing a powerful space expanded widely to
the left and right. The reproduced depth is also restrained relatively to ensure the separation between audio
channels and the clarity of the sound.
24 En
Enjoy the sound field programs
ProgramDescriptions
DramaThis sound field features stable reverberations that match a wide range of movie genres from serious dramas to
musicals and comedies. The reverberations are modest but offer an optimum 3D feeling, reproducing effects tones
and background music softly but cubically around clear words and center positioning in a way that does not fatigue
the listener even after long hours of viewing.
Mono MovieThis program is provided for reproducing monaural video sources such as a classic movie in an atmosphere of a
good old movie theater.
The program produces the optimum expansion and reverberation to the original audio to create a comfortable
space with a certain sound depth.
SportsThis program allows the listeners to enjoy stereo sport broadcasts and studio variety programs with enriched live
feeling. In sports broadcasts, the voices of the commentator and sportscaster are positioned clearly at the center
while the atmosphere of the stadium expands in an optimum space to offer the listeners with a feeling of presence
in the stadium.
Action GameThis sound field has been suitable for action games such as car racing and FPS games. It uses the reflection data
that limits the effects range per channel in order to offer a powerful playing environment with a being-there feeling
by enhancing various effects tones while maintaining a clear sense of directions.
Roleplaying GameThis sound field has been suitable for role-playing and adventure games. It combines the sound field effects for
movies and the sound field designs for “Action Game” to represent the depth and 3D feeling of the field during
play, while offering movie-like surround effects in the movie scenes in the game.
For audio music sources
ProgramDescriptions
Hall in MunichThis sound field simulates a concert hall with approximately 2500 seats in Munich, using stylish wood for the
interior finishing as normal standards for European concert halls. Fine, beautiful reverberations spread richly,
creating a calming atmosphere. The listener’s virtual seat is at the center left of the arena.
Hall in ViennaThis is an approximately 1700-seated, middle-sized concert hall with a shoebox shape that is traditional in Vienna.
Pillars and ornate carvings create extremely complex reflections from all around the audience, producing a very
full, rich sound.
ChamberThis program creates a relatively wide space with a high ceiling like an audience hall in a palace. It offers pleasant
reverberations that are suitable for courtly music and chamber music.
Cellar ClubThis program simulates a live house with a low ceiling and homey atmosphere. A realistic, live sound field
features powerful sound as if the listener is in a row in front of a small stage.
The Roxy TheatreThis is the sound field of a rock music live house in Los Angeles, with approximately 460 seats. The listener’s
virtual seat is at the center left of the hall.
The Bottom LineThis is the sound field at stage front in The Bottom Line, that was a famous New York jazz club once. The floor
can seat 300 people to the left and right in a sound field offering real and vibrant sound.
Music VideoThis sound field offers an image of a concert hall for live performance of pop, rock and jazz music. The listener
can indulge oneself in a hot live space thanks to the presence sound field that emphasizes the vividness of vocals
and solo play and the beat of rhythm instruments, and to the surround sound field that reproduces the space of a
big live hall.
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
For stereo reproduction
ProgramDescriptions
2ch StereoUse this program to mix down multi-channel sources to 2 channels.
y
• When multi-channel signals (Dolby Digital and DTS) are input, they are downmixed to 2 channels and output from the front left and right speakers.
25 En
English
Enjoy the sound field programs
For Multi-channel stereo reproduction
ProgramDescriptions
7ch StereoUse this program to output sound from all speakers. When you play back multi-channel sources, this unit
downmixes the source to 2 channels, and then outputs the sound from all speakers. This program creates a larger
sound field and is ideal for background music at parties, etc.
The Compressed Music Enhancer
ProgramDescriptions
Straight EnhancerUse this program to enhance the sound nearest to the original depth and width of the 2-channel or multi-channel
compression artifacts.
7ch EnhancerUse this program to play back compression artifacts in 7-channel stereo.
Surround decode mode
Select this program to playback sources with selected decoders. You can playback 2-channel sources on multi-channels.
DecoderDescriptions
Pro LogicDolby Pro Logic decoder suitable for all kinds of sources.
PLIIx Movie /
PLII Movie
PLIIx Music /
PLII Music
PLIIx Game /
PLII Game
Neo:6 CinemaDTS decoder suitable for movies.
Neo:6 MusicDTS decoder suitable for music.
Dolby Pro Logic IIx (or Dolby Pro Logic II) decoder suitable for movies. If your listening environment is as
follows, you cannot select the Dolby Pro Logic IIx decoder.
• When the surround back speakers are not connected
• When headphones are connected
Dolby Pro Logic IIx (or Dolby Pro Logic II) decoder suitable for music. If your listening environment is as
follows, you cannot select the Dolby Pro Logic IIx decoder.
• When the surround back speakers are not connected
• When headphones are connected
Dolby Pro Logic IIx (or Dolby Pro Logic II) decoder suitable for games. If your listening environment is as
follows, you cannot select the Dolby Pro Logic IIx decoder.
• When the surround back speakers are not connected
• When headphones are connected
y
• An input source is played back in straight decode mode (see page 27) when multi-channel audio signal is input.
In straight decoding mode, sounds are reproduced without
sound field effect. 2-channel stereo sources are output
from only the front left and right speakers. Multi-channel
input sources are decoded straight into the appropriate
channels and multi-channel sounds are reproduced
without a sound field effect.
1To enable straight decoding mode, press
LSTRAIGHT (or jSTRAIGHT).
“Straight” appears on the front panel display.
2To cancel straight decoding mode, press
LSTRAIGHT (or jSTRAIGHT) again.
A sound field program name appears on the front
panel display, and sound is reproduced with that
sound field effect.
Enjoying sound field programs without
surround speakers (Virtual CINEMA
DSP)
Virtual CINEMA DSP allows you to enjoy DSP sound
field surround effects even without any surround speakers
by using virtual surround speakers. You can even enjoy
Virtual CINEMA DSP using a minimal two-speaker
system that does not include a center speaker.
When “Sur. L/R SP” in the setup menu is set to “None”
(see page 40), this unit operates in Virtual CINEMA DSP
mode.
Enjoy sound field programs with
headphones (SILENT CINEMA™)
SILENT CINEMA allows you to enjoy multi-channel
sources with your headphones. SILENT CINEMA mode
is automatically selected when you connect the headphone
plug to the PHONES jack.
Note
• SILENT CINEMA mode is not available in the following conditions.
– 2ch Stereo of the sound field program is selected.
– direct mode or straight decoding mode is selected.
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
Note
• Virtual CINEMA DSP mode is not available in the following conditions
even if you set “Sur. L/R SP” to “None” (see page 40).
– headphone plug is connected to the PHONES jack.
– 7ch Stereo of the field sound program is selected.
– direct mode or straight decoding mode is used.
INFORMATIONAPPENDIX
ADDITIONAL
English
27 En
FM/AM tuning
The FM/AM tuner of this unit provides the following two
modes for tuning.
You can tune in to a desired FM/AM station by searching
or specifying its frequency.
■Preset tuning mode (Preset tuning)
You can preset the frequencies of FM/AM stations by
registering them to specific numbers, and later just select
those numbers to tune in.
Note
• Adjust the FM/AM antennas connected to this unit for the best reception.
Tuning in to the desired FM/AM station
(Frequency tuning)
1Press NINPUTl / h (or gTUNER)
repeatedly and switch the input source to
“TUNER.”
2Press FFM (hFM) or GAM (hAM) to select
a band.
“FM” or “AM” appears on the front panel display
according to the band that you have selected.
3Press HTUNING l / h (or hTUNING k /
n) to specify the frequency.To adjust the frequency to a higher range, press h (or
k). To adjust it to the lower range, press l (or n).
The TUNED indicator on the front panel display
lights up when the tuner is tuned in to a station. The
STEREO indicator also lights up if the program being
broadcasted is in stereo.
STEREO
TUNED
FM92.5MHz
The frequency changes in the following manner according
to how you press HTUNINGl / h (or hTUNINGk
/ n).
When you press the key more than 1 second
The tuner searches the frequency of a station that is
detectable around the current frequency. This is effective
when the tuner can receive strong signals without any
interference. Once the search starts, release the key.
When you keep holding the key, the search continues even
when a station is detected. This is useful when you want to
tune in to a specific station.
When you press and release the key
The tuner increases or decreases the frequency in steps.
Use this method when the tuner cannot receive strong
signals and stations are skipped during the search. You can
listen to better quality sound even when the tuner cannot
receive a strong signal.
y
• You can switch between stereo and monaural for FM broadcast in the
option menu (see page 34).
4To tune in by direct frequency tuning, enter
the frequency of the desired station using
the numeric keys on the remote control.
Enter only integers. For example, if you want to set
the frequency to 88.9 MHz, enter “889” using
sNumeric keys.
Note
• “Wrong Station!” appears on the front panel display when you
enter a frequency that is out of receivable range. Make sure that the
entered frequency is correct.
Registering FM/AM stations and
tuning in (Preset tuning)
You can register up to 40 FM/AM stations (Preset) using
“Automatic station preset” or “Manual station preset.”
Registering stations by automatic station
preset
The tuner automatically detects FM stations with strong
signals and registers up to 40 stations. AM stations cannot
be automatically registered. Use manual station preset.
1Press NINPUTl / h repeatedly (or press
gTUNER) to switch the input source to
“TUNER.”
2Press mOPTION on the remote control.
The option menu screen for setting options of tuner
input appears on the front panel display.
y
• For details on the option menu, see page 33.
• The option menu is displayed on monitor components.
3Select “Auto Preset,” and press nENTER.
Auto Preset
Automatic station preset starts about 5 seconds later
from the lowest frequency upwards.
y
• You can select the preset number at which the preset starts by
pressing hPRESETk / n or nCursork / n while the front
panel display is in the state as shown in the below figure.
• To cancel registration, press nRETURN on the remote control.
Status
01:FM87.5MHz
Preset numberFrequency
28 En
FM/AM tuning
During the automatic station preset, the upper area of
the screen changes as follows: READY → SEARCH
→ MEMORY each time a station is registered.
When registration is complete, “FINISH” appears
and the option menu screen automatically reappears.
When you press mOPTION on the remote control,
the screen returns to the original state.
Registering stations by manual station
preset
You can manually register AM stations or FM stations
with weak signals.
1Tune in to a station referring to “Tuning in to
the desired FM/AM station (Frequency
tuning)” (see page 28).
2Press DMEMORY (or hMEMORY).
“Manual Preset” appears on the front panel display,
followed soon by the preset number to which the
station will be registered.
y
• By pressing down DMEMORY (or hMEMORY) for more
than 2 seconds, you can skip step 3 and register the preset number
to be one higher than the last preset number.
3Press EPRESETl / h (or hPRESETk / n)
on the remote control to select the preset
number to which the station will be
registered.
When you select a preset number to which no station
is registered, “Empty” appears on the display. When
you select a registered preset number, a registered
frequency is displayed on the right of the preset
number.
New registered frequency
Calling a preset station (Preset tuning)
You can call preset stations registered by automatic station
preset or manual station preset.
Press EPRESETl / h (or hPRESETk / n) to
select a preset number.
y
• Preset numbers to which no stations are registered will be skipped.
• When “No Presets” or “No Presets in Memory” is displayed it means that
no stations are registered. See page 28 and register stations.
• You can directly select a preset number by pressing a sNumeric
keys while calling a preset station. “Empty” appears on the display if
you enter a preset number to which no station is registered. “Wrong
Num.” appears if you enter an invalid number.
Clearing the preset station
1Press NINPUTl / h repeatedly (or press
gTUNER) to switch the input source to
“TUNER.”
2Press mOPTION on the remote control.
The option menu screen for setting options of tuner
input appears on the front panel display.
3Display “Clear Preset” using the nCursork
/ n and press nENTER.
The following screen appears on the display.
01:FM92.5MHz
Preset number of the registered station you want to clear.
y
• You can cancel the operation and return to the option menu screen
by pressing nRETURN on the remote control.
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
01:Empty
Preset
number
Flashing
y
• You can select a preset number using the sNumeric keys.
4Press DMEMORY (or hMEMORY) again to
register.
When registration is complete, the screen returns to
the original state.
To end the operation, press mOPTION.
y
• To cancel registration, press nRETURN on the remote control
or leave the tuner without any operations for about 30 seconds.
Empty (or frequency that is currently
registered to the preset number)
4Select the preset number of the registered
station you want to clear using the nCursork / n and press nENTER.
The preset station registered to the selected preset
number is cleared. To clear the registration of
multiple preset numbers, repeat the above steps.
To end the operation, press mOPTION.
English
29 En
Using iPod™
Once you have stationed your iPod in a Yamaha iPod universal dock (such as the YDS-11, sold separately) connected to
the DOCK terminal on the rear panel of this unit (see page 16), you can enjoy playback of your iPod using the supplied
remote control or the menu displayed on the video monitor. You can also use the Compressed Music Enhancer mode of
this unit to improve the sound quality of the compression artifacts (such as MP3 format) stored on your iPod (see
page 24).
Notes
• iPod touch, iPod (Click and Wheel including iPod classic), iPod nano, and iPod mini are supported.
• Some features may not be compatible depending on the model or the software version of your iPod.
• Some features may not be available depending on the model of Yamaha iPod universal dock. The following sections describe the procedure when using
the YDS-11.
y
• Once the connection between your iPod and this unit is complete, “iPod connected” appears on the front panel display.
• For a complete list of status messages that appear on the front panel display and on the video monitor, see the “iPod” section on page 50.
Controlling iPod™
You can control your iPod when you set it in the iPod
universal dock and switch the input source to DOCK. The
operations of your iPod can be done with the aid of the
video display (menu browse mode) or without it (simple
remote mode).
When you connect your iPod to this unit, you can perform
the following operations with the remote control.
KeyFunction
ENTERSubsequent menu
kMenu up
n
r
pDISPLAY
Controlling iPod in simple remote mode
nMenu down
lPrevious menu
hSubsequent menu
wSearch backward (Press and hold)
fSearch forward (Press and hold)
aSkip forward
bSkip backward
sStop
e
p
Pause (Menu browse mode)
Play/Pause (Simple remote mode)
Play (Menu browse mode)
Play/Pause (Simple remote mode)
Switch between Menu browse mode and
Simple remote mode
Controlling iPod in menu browse mode
You can perform advanced iPod operations using the
remote control while looking at the menu displayed on the
video monitor. You can browse the song files or video files
stored on your iPod and displayed on the monitor, and
change the settings of your iPod to suit your personal
preferences. You cannot directly control your iPod in this
mode.
y
• “_”(underscore) is displayed for characters that this unit cannot display.
1Change the input source to “iPod (DOCK)”
using NINPUTl / h (or gDOCK).
2Press pDISPLAY on the remote control.
The following screen appears on the video monitor.
iPodTop
Music>
Videos>
3Press nCursork / n to select “Music,”
“Videos” or “Settings” and press nCursorh.
• Select “Music” to browse music files.
• Select “Videos” to browse video files.
Note
• “Videos” will not be displayed when your iPod or Yamaha iPod
universal dock do not support the browser function for browsing
video files.
You can perform basic iPod operations (play, stop, skip,
etc.) using the supplied remote control without displaying
the menu on the video monitor. You can also directly
control your iPod in this mode.
30 En
Using iPod™
g
4Press nCursork / n / l / h to select a
menu item and then nENTER to start
playback.
Menu items of “Music”
Playlists, Artists, Albums, Songs, Genres, Composers
• Playlists > Songs
• Artists > Albums > Songs
• Albums > Songs
• Songs
• Genres > Artists > Albums > Songs
• Composers > Albums > Songs
Menu items of “Videos”
Menu items vary depending on the files stored on
your iPod.
a Track number/total tracks
b Artist name
c Album title
d Song title
e Progress bar
f Elapsed time
g Shuffle and repeat icons
h (playback), (pausing), (search forward) and
(search backward)
i Remaining time
y
• You can change information screens on the front panel display using
CINFO (or iINFO) (see page 23). Items displayed on the front panel
display vary depending on mode that is currently selected.
h
i
Shuffle/repeat playback
You can use a special playback function such as shuffle
playback and repeat playback by setting the option menu.
1Press pDISPLAY to switch to menu browse
mode while “DOCK” is selected as the input
source.
The option menu can be displayed only in menu
browse mode. Press pDISPLAY to switch to menu
browse mode before starting shuffle or repeat
playback.
2Press mOPTION.
The option menu is displayed.
3Press nCursork / n to select the desired
playback function, Shuffle or Repeat, then
press nENTER.
The following playback styles are available
depending on the playback function selected.
Shuffle: Plays back songs or albums in random
order (Choices: Off, Songs, Albums).
• Select “Off” if you do not want to play back in
random order.
• Select “Songs” to play back songs in random order.
• Select “Albums” to play back albums in random
order.
Repeat: Plays back songs or albums repeatedly
(Choices: Off, One, All).
• Select “Off” if you do not want to play back
repeatedly.
• Select “One” to repeat each song.
• Select “All” to repeat all songs.
4Select the desired style using nCursor l /
h.
The style is selected. Playback starts with the
function selected in step 3.
To return to the previous screen, press nRETURN.
To return to the previous playback function, redo the
above steps.
y
• When the shuffle function is on, “” appears on the video monitor.
• When “Repeat” is set to “One” or “All,” “ ” or “ ” appears on the
video monitor.
1All
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
English
31 En
Using Bluetooth™ components
You can connect a Yamaha Bluetooth wireless audio receiver (such as YBA-10, sold separately) to the DOCK terminal of
this unit and enjoy the music contents stored in your Bluetooth component (such as a portable music player) without
wiring between this unit and the Bluetooth component. You need to perform “Pairing” the connected Bluetooth wireless
audio receiver and your Bluetooth component in advance.
Note
• This unit supports A2DP (Advanced Audio Distribution Profile) of the Bluetooth profile.
Pairing the Bluetooth™ wireless audio
receiver and your Bluetooth
component
“Pairing” refers to the operation of registering a Bluetooth
component for Bluetooth communications. Pairing must
be performed when using a Bluetooth component with the
Bluetooth wireless audio receiver connected to this unit
for the first time or if the pairing data has been deleted.
y
• You only need the pairing operation for the first time that you use the
Bluetooth component with the Bluetooth wireless audio receiver.
• Pairing requires operations on this unit and on the other component with
which Bluetooth communications are to be established. If necessary,
refer to the other component’s operating instructions.
■Pairing the Bluetooth™ wireless audio
receiver and your Bluetooth™ component
To ensure security, a time limit of 8 minutes is set for
the pairing operation. You are recommended to read
and fully understand all the instructions before starting.
1Change the input source to “DOCK” using
NINPUTl / h (or gDOCK).
2Turn on the Bluetooth component you want
to pair with and set it to pairing mode.
For details on operation of the Bluetooth component,
refer to its operating instructions.
3Press mOPTION.
The option menu for DOCK input appears on the
video monitor.
DOCKOPTION
.VolumeTrim
Connect
Pairing
[
[
[]/[]:Up/Down
[ENTER]:Select
4Press nCursorn to select “Pairing” and
press nENTER.
“Searching” appears on the front panel display and
the pairing operation starts.
y
• To cancel pairing, press nRETURN.
• You can also start pairing operation by pressing and holding
DMEMORY on the front panel.
5Make sure the Bluetooth component
recognizes the Bluetooth wireless audio
receiver.
If the Bluetooth have recognized the Bluetooth
wireless audio receiver, “YBA-10 YAMAHA,” for
instance, is displayed in the Bluetooth device list.
6Select the Bluetooth wireless audio receiver
from the Bluetooth device list, and enter a
path key “0000” into the Bluetooth
component.
When pairing is complete, “Completed” appears on
the front panel display.
y
• The Yamaha Bluetooth wireless audio receiver can be paired with up to
eight Bluetooth components. When pairing is conducted successfully
with a ninth component and the pairing data is registered, the pairing data
for the least recently used other component is cleared.
Playback of the Bluetooth™
component
1Change the input source to “DOCK” using
NINPUTl / h (or gDOCK).
2Press mOPTION.
3Press nCursorn repeatedly to select
“Connect” and press nENTER.
After you execute “Connect,” communication with
the Bluetooth component is established. When the
connected Bluetooth wireless audio receiver
recognizes the Bluetooth component, “BT
Connected” appears on the front panel display.
y
• When you press nENTER on the remote control, the connected
Bluetooth wireless audio receiver searches and connects to the last
connected Bluetooth component. If the Bluetooth wireless audio
receiver cannot find the Bluetooth component, “Not found”
appears on the front panel display.
• To disconnect the Bluetooth wireless audio receiver from the
Bluetooth component, display the option menu again, select
“Disconnect,” and press nENTER.
4Start playback of the Bluetooth component.
32 En
ADVANCED OPERATION
Setting the option menu for each input source (OPTION menu)
This unit has an OPTION menu of frequently used menu items for input sources compatible with this unit. The procedure
for setting the OPTION menu items is described below.
1Select an input source using NINPUTl / h
(gInput selection keys).
2Press mOPTION on the remote control.
The OPTION menu appears. The displayed OPTION
menu items differ depending on the input source. For
details, see the following section.
HDMI1OPTION
.VolumeTrim
DecoderMode
ExtendedSurround
SignalInfo
[
[
[]/[]:Up/Down
[ENTER]:Select
3Select the desired menu item using
nCursork / n, and press nENTER.
Parameters of the selected menu item are displayed.
4Change the setting of the selected menu item
(or enable a function) using nCursor k / n /
l / h and nENTER.
Details of the selected menu item are displayed.
Parameters you can set differ depending on the menu
items.
5To close the OPTION menu, press
mOPTION.
You can also use nRETURN to return to the
previous screen or close the OPTION menu.
y
• When nCursor or other keys do not work after completing the
menu, select the input source again using gInput selection keys.
OPTION menu items
The following menu items are provided for each input
source.
Input
Source
HDMI1-4Volume
Trim
AV1-4Volume
Trim
AV5-6Volume
Trim
AUDIO1-2 Volume
Trim
V-AUXVolume
Trim
TUNERVolume
Trim
iPod
(DOCK)
Bluetooth
(DOCK)
Vo l u m e
Trim
Vo l u m e
Trim
Details of the menu items are as follows:
y
• The default settings are marked with “*.”
■Volume Trim
Input source:All
Adjustable range: -6.0 dB to 0.0 dB* to +6.0 dB
(in 0.5 dB steps)
Reduces any change in volume when switching input
sources by correcting volume differences between input
sources.
You can set this parameter for each input source.
Menu item
Decoder
Mode
Decoder
Mode
FM ModeAuto
ShuffleRepeat
Connect/
Disconnect
Extended
Surround
Extended
Surround
Preset
Pairing
Signal Info
Signal Info
Clear
Preset
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
33 En
English
Setting the option menu for each input source (OPTION menu)
■Decoder Mode
Input source: HDMI1-4, AV1-4
Choices: Auto*/DTS
Selects DTS digital audio signals for reproduction.
Selects whether to reproduce multi-channel input signals
in 6.1- or 7.1-channel when surround back speakers are
used.
AutoAutomatically selects the most suitable
decoder according to whether a flag for
reproducing surround back channel is present,
and reproduces the signals in 6.1- or 7.1channel.
PLIIx
Movie
Always reproduces signals in 6.1- or 7.1channel using the PLIIxMovie decoder
whether or not surround back channel signals
are contained. You can select this parameter
when one or two speakers are connected.
PLIIx
Music
Always reproduces signals in 6.1- or 7.1channel using the PLIIxMusic decoder whether
or not surround back channel signals are
contained. You can select this parameter when
one or two speakers are connected.
EX/ESAutomatically selects the most suitable
decoder for input signals whether or not the
flag for reproducing surround back channel is
present, and always reproduces signals in 6.1channel.
OffAlways reproduces signals in 5.1-channel
whether or not the flag for reproducing
surround back channel is present.
■ Signal Info
Input source: HDMI1-4, AV1-4
Displays information on audio and video signals on the
video monitor and front panel display. You can change
information to be displayed on the front panel display
using nCursork / n.
Signal Info parameters
■ Audio information
Information Description
Format
Channel
Sampling
Bitrate
Notes
• “No Signal” is displayed when no signals are input and “---” is displayed
when signals that this unit cannot recognize are input.
• The bit rate may vary during playback.
■ Video information
Information Description
In
Out
Message
Format of digital audio signals.
The number of input signal channels (front/
surround/LFE).
For example, if input signal channels are 3
front channels, 2 surrounds and LFE, “3/2/
0.1” is displayed.
If a channel that cannot be expressed as the
above, a total number of channels such as
“5.1ch” may be displayed.
The sampling frequency per second in
analog-to-digital conversion.
The bit rate of input signal per second.
Format and resolution of video input signal.
Format and resolution of video output signal.
Error messages about HDMI signals and
HDMI components. See the following for
details of the error messages.
34 En
HDMI error message
(appears only when an error has occurred)
HDCP Error
Device Over
Out of Res.
FM Mode
■
Input source: TUNER
Choices:Stereo*/Mono
HDCP authentication failed.
The number of HDMI components connected is
over the limit.
The connected monitor is not compatible with
the video input signal.
Sets FM broadcasting receiving mode.
Stereo Receives in stereo mode.
MonoReceives in monaural mode. You can get better
reception in MONO mode.
■Auto Preset
Input source: TUNER
Automatically detects radio stations in the FM frequency
band and registers them as preset stations (see page 28).
Switches communication with a Bluetooth component on
and off (see page 32).
Pairing
■
Input source: Bluetooth (DOCK)
Performs pairing of this unit and a Bluetooth component
(see page 32).
Setting the option menu for each input source (OPTION menu)
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
35 En
INFORMATIONAPPENDIX
ADDITIONAL
English
Editing surround decoders/sound field programs
Selecting a decoder used with a sound
field program
When using sound field programs for movies or TV
programs (except for Mono Movie), you can select a
surround decoder to be used with the sound field program
after setting the parameters from the following decoders.
To set the parameters for sound field programs, see the
following section.
Decoders that can be used with a sound field
program
• PLIIx Movie (PLII Movie)
• Neo:6 Cinema
Setting sound field parameters
Although the field sound programs would satisfy you as
they are with the default parameters, you can arrange
sound effect or decoders suitable for acoustical conditions
of sources or rooms by setting the parameters (sound field
elements).
y
• You can protect the sound field against the changes of parameters the
sound filed parameters when “Memory Guard” of the setup menu is set
to “On” (see page 43). To change the parameters, set it to “Off.”
that you want to change, and press nCursorl / h to change the parameter.
An asterisk (*) appears on the left of the sound field
parameter name displayed on the monitor when you
change the parameter from its default setting. For
details on functions and adjustable ranges of the
sound field parameters, see “Sound field parameters”
on this page.
y
• Repeat steps 4 and 5 to change other sound field program
parameters.
6To end the edit, press nRETURN.
To initialize the parameters of the selected sound field
program, nCursor n repeatedly to select “Initialize”
and then press, nCursor h. When the confirmation
screen appears on the monitor, press nCursor h to
confirm the initialization or nCursor l to cancel it.
Sound field parameters
y
• The default settings are marked with “*.”
CINEMA DSP parameters
DSP Level
Adjustable range: -6 dB to 0 dB* to +3 dB
Fine adjusts an effect level (level of the sound field effect
to be added). You can adjust the level of the sound field
effect while checking sound levels. Adjust “DSP Level” as
follows.
• The effect sound is too soft.
• There are no differences between effects of the sound
field programs.
→Increase the effect level.
• The sound is dull.
• The sound field effect is added too much.
→Reduce the effect level.
4Press nCursork / n to move “→” to the
sound field program and press nCursorl / h to select the sound field program.
36 En
Editing surround decoders/sound field programs
Parameters only usable in certain sound
field programs
■2ch Stereo only
Direct
Choices: Auto*/Off
Automatically bypasses the DSP circuit and tone control
circuit when an analog sound source is selected as the
input source. You can enjoy a higher quality sound.
Auto Outputs sound by bypassing the DSP circuit and
tone control circuit when the “Bass” and “Treble”
tone controls are both set to 0 dB.
Off Do not bypass the DSP circuit and tone control
circuit.
■7ch Stereo only
CT Level/SL Level/SR Level/
SB Level
Adjustable range: 0 to 100%
Adjusts the volume of the center (CT), surround L (SL)
surround R (SR) and surround back (SB) channels in the
7ch Stereo program. The available parameters differ
depending on the setting of the speakers.
■Straight Enhancer/7ch Enhancer only
Effect Level
Choices: High*/Low
Adjusts the Compressed Music Enhancer effect level.
When the high-frequency signals of the source is
emphasized too much, set the effect level to “Low.” To
reduce the effect, set this parameter to “Low.” To increase
the effect, set it to “High.”
Decoder parameters
You can customize decoder effects by setting the
following parameters. For kinds of decoders, see page 26.
■When PLIIx Music/PLII Music is selected
Panorama
Choices: Off*/On
Adjusts the soundscape of the front sound field. Sends
stereo signals to the surround speakers as well as the front
speakers for a wraparound effect.
Dimension
Adjustable range: -3 to STD* to +3
Adjusts the difference in level between the front sound
field and the surround sound field. You can adjust the
difference in level created by the software being played
back to obtain the preferred sound balance. The surround
sound gets stronger as you make the value more negative
and the front sound gets stronger as you make the value
more positive.
Center Width
Adjustable range: 0 to 3* to 7
You can spread the center sound toward left and right
according to your preference. Set this parameter to 0 for
outputting the center sound from the center speaker only,
or to 7 for outputting it from the front left/right speaker.
■When Neo:6 Music is selected
C.Image
Adjustable range: 0.0 to 0.3 to 1.0
Adjusts the front left and right channel output relative to
the center channel to make the center channel more or less
dominant as necessary.
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
37 En
English
Operating various settings for this unit (Setup menu)
You can call the setup menu using the remote control and change the settings of various menus.
You can change the following settings in the setup menu. For details, read “Basic operation of the setup menu” first, and
see the respective pages.
Menu/SubmenuFunctionPage
Speaker SetupSets items for speakers.39
1 Auto Setup (YPAO)Automatically adjusts output characteristics of speakers.39
2 Manual SetupManually adjusts output characteristics of speakers.39
A)ConfigSets speaker configurations, such as connection status of speaker and a size of the
connected speaker (sound reproduction capacity), suitable for the listening
environment.
B)LevelSeparately adjusts volume of each speaker.41
C)DistanceAdjusts timing at which each speaker outputs sound based on distances between
speakers and the listening position.
D)EqualizerSelects an equalizer that adjusts speaker output characteristics.41
E)Test ToneGenerates test tones.41
Sound SetupSets various items for sound outputs.41
1 Dynamic RangeAdjusts dynamic ranges of speakers and headphones.41
2 LipsyncAdjusts delay in output timing between video signals and audio signals.41
HDMI AutoSets on or off of automatic adjustments for delay between output timing between
video signals input from the HDMI jack and audio signals.
Auto DelayFine adjusts a delay time of HDMI Auto.42
Manual DelayManually fine adjusts the delay of audio and visual output.42
Function SetupSet various items for HDMI and display.42
1 HDMISets various items for input sources.42
Standby ThroughSelects on or off of output of HDMI signals input from the HDMI IN jack to the
HDMI OUT jack when this unit is on standby.
Audio OutputSelects this unit or a component connected to this unit via the HDMI OUT jack of
this unit for reproducing sound signals input from the HDMI IN jack.
ResolutionSets resolution of the HDMI output that is converted from analogy visual input
signals.
AspectSet an aspect ratio of images reproduced by HDMI signals converted from analog
video input signals.
2 DisplaySet items for a monitor or the front panel display.42
DimmerSets brightness of the front panel display. 42
FL ScrollSelects the way to display characters on the front panel display.42
OSD ShiftAdjusts top and bottom positions of the screen displayed on the video monitor.43
3 VolumeSets items for volumes.43
Adaptive DRCAdjust the dynamic range (difference between the maximum volume and the
minimum volume) in conjunction with the volume level.
Max VolumeSets the maximum volume level so that the volume will not be accidentally
increased.
Init. VolumeSets the volume at the time this unit is turned on.43
4 Input RenameChanges input source names to be displayed on a video monitor or the front panel
display.
DSP ParameterSets parameters for the sound field programs.43
Memory GuardProtects some settings against accidental alteration.43
39
41
41
42
42
42
42
43
43
43
38 En
Operating various settings for this unit (Setup menu)
Basic operation of the setup menu
The setup menu screen appears on both video display
(OSD) and front panel display.
change the setting of the item using
nCursorl / h.
Some items in the Manual Setup menu of Speaker
Setup take up a full screen. To display other items in
the Manual Setup menu, press nCursork / n.
[
[
“A)Config” display (example)
A)Config
Center SP
None >Small Large
y
• You can change other items by repeating step 4.
5To finish the setting, press lSETUP.
y
• When nCursor or other keys do not work after completing the menu,
select the input source again using gInput selection keys.
Speaker Setup
You can set various items for speakers. Two kinds of
adjustments are available. One is “Auto Setup (YPAO)”
for automatic adjustment and another is “Manual Setup”
for manual adjustment.
y
• The default settings are marked with “*.”
1 Auto Setup
Automatically adjusts output characteristics of speakers to
obtain optimum balance for the output sound based on
positions and performances of the speakers and acoustic
characteristics or the room, which are automatically
measured. For details on operations, see page 18.
2 Manual Setup
Adjusts output characteristics of speakers based on
manually set parameters.
After Auto Setup (YPAO) is performed, you can check
automatically adjusted parameters in the Manual Setup
menu. Fine adjust the parameters for your preference if
necessary.
A)Config
■
Sets speaker configurations, such as connection status of
speaker and a size of the connected speaker (sound
reproduction capacity), suitable for the listening
environment.
y
• The speaker configuration includes items for defining a speaker size:
Large or Small. Large and Small refer to speakers with woofer diameters
16 cm or larger and smaller than 16 cm, respectively.
LFE/Bass Out
Choices: SWFR/Front/Both*
Selects speaker(s) for outputting low-frequency
components of the LFE (low-frequency effect sound)
channel or other channels. The output status is as follows.
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
English
39 En
Operating various settings for this unit (Setup menu)
LFE channel signals
ParameterSubwoofer
BothOutputNot outputNot output
SWFROutputNot outputNot output
FrontNot outputOutputNot output
Front
speakers
Other
speakers
Low-frequency components of other channel signals
ParameterSubwoofer
Both[1][2][3]
SWFR[4][3][3]
FrontNot output[1][3]
[1] Outputs low-frequency components of the front left and right
channels and the channel of speaker, the size of which is set to
“Small.”
[2] Outputs low-frequency components of the front left and right
channels.
[3] Outputs low frequency components when the sizes of speakers
are set to “Large.”
[4] Outputs low-frequency components of the channel of speaker,
the size of which is set to “Small.”
Front
speakers
Other
speakers
Front SP
Choices: Small/Large*
Sets the sizes of front left and right speakers.
SmallSelect this when small speakers are
connected. Low-frequency components of the
front left and right channels are output from a
subwoofer.
LargeSelect this when large speakers are
connected.
Note
• When “LFE/Bass Out” is set to “Front,” you can only select “Large.” If
“LFE/Bass Out” is changed to “Front,” “Front SP” automatically
switches to “Large” even when it is set to “Small.”
Center SP
Choices: None/Small*/Large
Sets the size of center speaker.
NoneSelect this when no center speaker is
connected. Center channel signals are spread
to front left and right speakers.
SmallSelect this when a small center speaker is
connected. Low-frequency components of
center channel are output from a subwoofer.
If a subwoofer is not connected they are
output from front speakers.
LargeSelect this when a large center speaker is
connected.
Sur. L/R SP
Choices: None/Small*/Large
Sets sizes of left and right surround speakers.
NoneSelect this when no surround speakers are
connected. Surround channel signals are
spread to front left and right speakers. “Sur.B
L/R SP” automatically switches to “None”
when this is selected.
SmallSelect this when small surround speakers are
connected. Low-frequency components of
surround channels are output from a
subwoofer. If a subwoofer is not connected
they are output from front speakers.
LargeSelect this when large surround speakers are
connected.
y
• When “None” is selected, the sound field programs automatically enter
the Virtual CINEMA DSP mode.
Sur.B L/R SP
Choices: None/SMLx1/SMLx2*/LRGx1/LRGx2
Sets sizes of left and right surround back speakers.
NoneSelect this when no surround back speaker
are connected. Surround back channel signals
are output from the surround L/R speakers
and subwoofer. If the subwoofer is disabled,
they are output from the surround L/R
speakers and front speakers.
SMLx1Select this when one small surround back
speaker is connected.
SMLx2Select this when two small surround back
speakers are connected.
LRGx1Select this when one large surround back
speaker is connected.
LRGx2Select this when two large surround back
speakers are connected.
y
• When “None” is selected, “PLIIx Movie” or “PLIIx Music” cannot be
selected.
Crossover Freq.
Choices: 40Hz/60Hz/80Hz*/90Hz/100Hz/110Hz/120Hz/
160Hz/200Hz
Sets the lower limit of the low frequency component
output from a speaker with a size set to “Small (SMLx1/
SMLx2).” Sound with a frequency below that limit is
output from a subwoofer or front speakers.
If your subwoofer has a volume control or a crossover
frequency control, set the volume to half or the crossover
frequency at the maximum.
Subwoofer Phase
Choices: Normal*/Reverse
Sets the phase of your subwoofer if bass sounds are
lacking or unclear.
NormalSelect this not to change the phase of your
subwoofer.
Reverse Select this to reverse the phase of your
subwoofer.
40 En
Operating various settings for this unit (Setup menu)
■B)Level
Adjustable range: -10.0dB to +10.0dB (0.5 dB step)
Defaults: “FR.L/FR.R/SWFR” 0dB*
“CNTR/SUR.L/SUR.R/SBL/SBR” -1.0dB
Separately adjusts volume of each speaker so that the
sounds form speakers are at the same volume at the
listening position. Items to be displayed vary depending
on the number of speakers connected.
y
• When only one surround back speaker is connected, “SB” appears
instead of “SBL” and “SBR.”
• You can adjust the volume listening to test tones when you set “Test
Tone” to “On” (see page 41).
• If your subwoofer has a volume control or a crossover frequency control,
set the volume to half or the crossover frequency at the maximum.
■C)Distance
Adjusts timing at which each speaker outputs sound so
that sounds from speakers reach the listening position at
the same time. Set unit (Unit) first and set the distance of
each speaker.
Unit
Choices: meters (m)/feet (ft)*
meters (m) Displays the speaker distance in meters.
feet (ft)Displays the speaker distance in feet.
Front L
/ Front R / Center / Sur. L /
Sur. R / Sur.B L / Sur.B R / SWFR
Adjustable range: 0.30m to 24.00m (1.0ft to 80.0ft)
Defaults: 3.00m (10.0ft) “Front L/Front R/
SWFR”
2.60m (8.5ft) “Center”
2.40m (8.0ft) “Sur. L/Sur. R/
Sur.B L/Sur.B R”
y
• Different items are displayed depending on settings of “A)Config” (see
page 39).
• When only one surround back speaker is connected, “Sur.B” appears
instead of “Sur.B L” and “Sur.B R.”
■D)Equalizer
Adjusts sound quality and tone using a parametric graphic
equalizer.
EQ Type Select
Choices: Auto PEQ/GEQ*/Off
Select an equalizer type.
Auto PEQ Uses a parametric equalizer selected in
“Auto Setup.” Characteristics of the
currently used parametric equalizer (see
page 18) are displayed below “Auto PEQ.”
GEQUses a graphic equalizer. Press nENTER
to adjust the characteristics of the graphic
equalizer.
OffNot use a graphic equalizer.
GEQ
Choices: 63Hz/160Hz/400Hz/1kHz/2.5kHz/
Adjustable range: -6.0dB to 0dB* to +6.0dB (0.5 dB step)
6.3kHz/16kHz
Adjusts sound quality of each speaker using a graphic
equalizer. The graphic equalizer of this unit can adjust
signal levels in 7 frequency ranges.
To adjust the signal level in each range, select the desired
speaker with nCursorl / h while “→” is displayed
next to “Channel,” then select the desired frequency band
with nCursork / n, and adjust the signal level with nCursorl / h.
E)Test Tone
■
Choices: Off*/On
Switches between on and off of an oscillator that generates
test tones. To turn on the oscillator, select “On” using
nCursorl / h. When “On” is selected, you can adjust
the settings of “2 Manual Setup” while listening to a test
tone.
OffNot generate test tones.
OnGenerates test tones.
Sound Setup
You can set various items for sound outputs.
1 Dynamic Range
■
Choices: Min/Auto/STD/Max*
Selects the dynamic range adjustment method for
reproducing bitstream signals.
Min/Auto (Min) Sets the dynamic range suitable for
low volume or a quiet environment, such as
at night, for bitstream signals except for
Dolby TrueHD signals.
(Auto) Adjusts the dynamic range for Dolby
TrueHD signals based on input signal
information.
STDSets the standard dynamic range
recommended for regular home use.
MaxOutputs sound without adjusting the
dynamic range of the input signals.
2 Lipsync
■
Adjusts delay between video output and audio output.
HDMI Auto
Choices: Off*/On
Automatically adjusts output timing of audio and video
signals when a monitor that supports an automatic lipsync function is connected to this unit.
OffSelect this when the connected monitor does
not support the automatic lip-sync function or
you do not use the automatic lip-sync function.
Set the correction time in “Manual Delay.”
OnSelect this when the connected monitor
supports the automatic lip-sync function. Fine
adjust the correction time in “Auto Delay.”
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
English
41 En
Operating various settings for this unit (Setup menu)
Auto Delay
Adjustable range: 0 to 240ms (1 ms step)
Fine adjust the correction time when “HDMI Auto” is set
to “On.” The actual correction time is displayed under in
“Auto Delay” field and an offset time set by the user in
“Offset” field.
Manual Delay
Adjustable range: 0* to 240ms (1 ms step)
Manually fine adjusts the correction time. Select this when
the connected monitor does not support the automatic lipsync function or you set “HDMI Auto” to “Off.”
Function Setup
You can set various items for HDMI and display.
1 HDMI
You can set items for HDMI.
Standby Through
■
Choices: On/Off*
Selects on or off of output of HDMI signals input from the
HDMI IN jack to the HDMI OUT jack when this unit is on
standby. When this parameter is set to “On” signals input
from the HDMI 1-4 jacks can be output to a monitor
component.
OnOutputs the HDMI signals to the HDMI OUT
jack.
OffNot output the HDMI signals to the HDMI
OUT jack.
y
• To enables pass-through output, any one of the input sources connected
to the HDMI1-4 must be selected before switching to standby.
• When Standby Through turns on, the HDMI THROUGH indicator on the
front panel display lights up. While the indicator lights up, this unit
consumes up to 3W of power even on standby.
■Audio Output
Choices: Amp*/TV/Amp+TV
Selects this unit or a component connected to this unit via
the HDMI OUT jack of this unit for reproducing sound
signals input from the HDMI IN jack.
AmpOutputs HDMI sound signals form the
speakers connected to this unit.
TVOutputs HDMI sound signals from the
speakers of a TV connected to this unit.
Sound output from the speakers connected to
this unit is muted.
Amp+TVOutputs HDMI sound signals from the
speakers connected to this unit and the
speakers of a TV connected to this unit.
Note
• Signal formats of audio and visual signals output from this unit to the
monitor vary depending on specifications of the monitor.
■ Resolution
Choices: Through*/480p/720p/1080i/1080p
Upscales the resolution of HDMI output that is converted
from analog video input signals and output from the
HDMI OUT jack.
Notes
• Resolution of the HDMI output converted from 720p or 1080i analog
video signals cannot be upscaled.
• When a video monitor is connected to this unit via the HDMI jack, this
unit automatically detects a resolution that the monitor supports. An
asterisk (*) appears on the left of the detected resolution.
• If this unit cannot detect the resolution that the monitor supports, set
“MON.CHK” in the advanced setup menu to “SKIP” (see page 45) and
try it again.
■ Aspect
Choices: Thrgh*/16:9/Smart
Set a horizontal to vertical ratio (aspect ratio) of images
reproduced by HDMI signals output from the HDMI OUT
jack when the HDMI signals are converted from analog
video input signals by a video conversion function.
ThrghOutputs the video signals without changing
the aspect ratio.
16:9Outputs the video signals that displays 4:3
images on a 16:9 monitor with black bands
on the right and left sides of the monitor
screen.
SmartOutputs the video signals that displays 4:3
images on a 16:9 monitor by stretching right
and left of images to fit in the monitor screen.
Notes
• You cannot change the aspect ratio of the screen when “Resolution” is set
to “Thrgh.”
• The setting is not effective for inputs with the aspect ratio other than 4:3.
• You cannot obtain an effect of the aspect ratio when visual signals are
input from the HDMI IN jack or 720p, 1080i or 1080p signals are input.
2 Display
You can set items for a monitor or the front panel display.
Dimmer
■
Adjustable range: -4 to 0*
Sets brightness of the front panel display. As the value is
lowered, the brightness of the front panel display is
darkened.
Note
• The brightness of display does not become bright in direct mode even if
the value is increased.
■ FL Scroll
Choices: Continue*/Once
Selects the way to scroll the screen when a total number of
characters exceed a display area of the front panel display.
ContinueRepeatedly displays all characters by
scrolling.
OnceDisplays all characters by scrolling once,
halts scrolling, and then displays first 14
characters.
42 En
Operating various settings for this unit (Setup menu)
■OSD Shift
Adjustable range: -5 to 0* to +5
Adjusts top and bottom positions of the screen displayed
on the video monitor. To move up the screen, set this value
larger. To move down the screen, set it smaller.
3 Volume
You can set items for volumes.
Adaptive DRC
■
Choices: Auto/Off*
Adjust the dynamic range in conjunction with the volume
level. This feature is useful when you are listening at
lower volumes or at night. When this function is enabled,
the dynamic range is adjusted as follows.
If the VOLUME setting is low:
the dynamic range is narrow
If the VOLUME setting is high:
the dynamic range is wide
Auto
Auto
OffOff
Output level
AutoAdjusts the dynamic range automatically.
OffNot adjust the dynamic range automatically.
y
• The Adaptive DRC setting is effective for headphones.
■Max Volume
Adjustable range: -30.0dB to +15.0dB/+16.5dB* (5.0 dB
step)
Sets the maximum volume level so that the volume will
not be accidentally increased. For example, you can adjust
the volume between –80.0 dB and –5.0 dB when you set
this parameter to “–5.0dB.” The volume increases to the
maximum level when this parameter is set to +16.5 dB
(default).
■Init. Volume
Choices: Off*/Mute/-80.0dB to +16.5dB (0.5 dB step)
Sets the volume at the time this unit is turned on. When
this parameter is set to “Off,” the volume is set to a level
that last time this unit is set to standby.
Output level
Input levelInput level
VOLUME: highVOLUME: low
4 Input Rename
Changes input source names to be displayed on the front
panel display.
You can select an input source that you want to change the
name to be displayed using nCursor.
Selecting a name to be displayed from templates
Select an input source that you want to change the name,
and select a name from the following templates using
Cursor.
– Blu-ray– Satellite
– DVD– VCR
– SetTopBox– Tape
– Game– MD
– TV– PC
– DVR– iPod
– CD– HD DVD
– CD-R– “blank”
Entering an original name
Select an input source that you want to name, and press
nENTER. You can enter up to 9 characters by selecting
one character at a time with the following keys according
to the following operation.
nCursorl / hFor selecting characters that you
want to change
nCursork / nFor selecting characters to be
entered
nENTERFor entering the selected characters
The following characters are available for input.
A to Z, 0 to 9, a to z, symbols (#, *, –, +, etc.) and space
DSP Parameter
You can set parameters for the sound field programs. For
details, see page 36.
Memory Guard
Choices: Off*/On
Protects settings of setup menu against accidental
alteration.
OffNot protect settings.
OnProtects the settings of the setup menu
(except for the Memory Guard setting).
Note
• When this parameter is switched to “On,” “G” appears while the setup
menu is displayed on the video monitor.
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
Note
• When you set “Max Volume” and “Init. Volume,” the setting of “Max
Volume” becomes effective. For example, when you set “Max Volume”
to “–30.0dB” and “Init. Volume” to “0.0dB,” the volume is
automatically set to “–30.0dB” at the next time this unit is turned on.
English
43 En
Controlling other components with the remote control
You can control external components for a selected input source with the remote control. The keys available for
controlling external components are as follows:
dSOURCE POWER
Turns on and off an external component.
nCursor, ENTER, RETURN
Operates the menus of external components.
pDISPLAY
Switches between the screens of external components.
rExternal component operation keys
Function as a recording or playback key of an external
component, or a menu display key.
sNumeric keys
Function as numeric keys of an external component.
tTV control keys
INPUTSwitches visual inputs of TV
MUTEMute audio of TV
TV VOL +/– Controls the volume of TV
TV CH +/– Switches channels of TV
POWERTurns on and off TV
y
• You can use tTV control keys only for controls of TV regardless
of selected input sources.
• You need to set the remote control code first to control external
components.
• The remote control keys for controlling external components are
available only when the external components have corresponding control
keys.
The following remote control codes are assigned to input
sources as factory default settings. For a complete list of
available remote control codes, refer to “List of remote
control codes” at the end of this manual.
■Default remote control code settings
Input sourceCategory Manufacturer
[HDMI1]Blu-ray Disc Yamaha2018
[HDMI2]———
[HDMI3]———
[HDMI4]———
[AV1] ———
[AV2] ———
[AV3]CDYamaha5013
[AV4] ———
[AV5] ———
[AV6] ———
[AUDIO1]———
[AUDIO2]———
[V-AUX]———
[TUNER]TunerYamaha5007
Default
code
Input sourceCategory Manufacturer
[DOCK]DOCKYamaha5011
[A]/[B]———
“—” indicates no assignment
y
• An external component that is controlled by the remote control can be
automatically selected according to selection of the scenes (see page 21).
Setting remote control codes
You can control other components by setting the
appropriate remote control codes. For a complete list of
available remote control codes, refer to “List of remote
control codes” at the end of this manual.
1Press cCODE SET on the remote control
using a pointed object such as the tip of a
ballpoint pen.
bTRANSMIT on the remote control blinks twice.
2Press gInput selection keys.
3Enter a remote control code using
sNumeric keys.
Once the remote control code is registered,
bTRANSMIT on the remote control blinks twice.
If it fails, bTRANSMIT blinks six times. Repeat
from step 1.
Resetting all remote control codes
You can clear all the remote control codes previously set,
and reset all of them to the initial factory settings.
1Press cCODE SET on the remote control
using a pointed object such as a tip of a
ballpoint pen.
bTRANSMIT on the remote control blinks twice.
2Press lSETUP on the remote control.
3Enter “9981” using sNumeric keys.
Once the initialization is complete, bTRANSMIT
on the remote control blinks twice. If it fails,
bTRANSMIT blinks six times. Repeat from
step 1.
Default
code
44 En
Advanced setup
In the advanced setup, you can set basic operations of this
unit, such as on and off of a bi-amp connection, or
initialize user settings. Perform the following steps to
change settings.
1Set this unit to the standby mode.
2Press ASTANDBY/ON while pressing and
holding LSTRAIGHT on the front panel.
The advanced setup menu appears on the front panel
display.
ADVANCEDSETUP
3Press KPROGRAMl / h repeatedly to
select the parameter you want to change.
The default setting are marked with “*.”
y
• Set values are placed in XXX of the following parameters on an
actual display screen.
SP IMP. -XXX
Choices: 6 MIN/8 MIN*
Selects output impedance of this unit according to
connected speakers.
REMOTE ID -XXX
Choices: ID1*/ID2
Sets a remote control ID. When using multiple
Yamaha AV receivers, you can operate them with a
single remote control by setting the receiver IDs to
the same setting.
BI AMP - XXX
Choices: ON/OFF*
Switches on and off of bi-amp connection of main
speakers. For bi-amp connection, see page 12.
MON.CHK - XXXX
Choices: YES*/SKIP
Adds upscaling limitation on output signals to a video
monitor connected to this unit via the HDMI OUT
jack.
INIT-XXXXXXXXX
Choices: DSP PARAM/VIDEO/ALL/CANCEL
Initializes various settings stored in this unit. You can
select an initialization method from the following.
4Press LSTRAIGHT a few times to select the
value you want to change.
The value selected here becomes effective when this
unit is turned on the next time. You can change
multiple settings by repeating steps 3 and 4.
5Press ASTANDBY/ON, turns off this
system, and press ASTANDBY/ON again.
The value set in step 3 becomes effective, and this
unit turns on. When you select initialization in step 3,
the initialization is performed.
Setting a remote control ID
Two IDs are provided for the remote control of this unit. If
another Yamaha amplifier is in the same room, setting a
different remote control ID to this unit prevents unwanted
operation of the other amplifier.
ID1 is set for both remote control and amplifier by default.
When you change the remote control ID, display
“Advance Setup” (see the previous section) and change the
ID for the amplifier too.
1Press cCODE SET on the remote control
using a pointed object such as the tip of a
ballpoint pen.
bTRANSMIT blinks twice.
2Press lSETUP on the remote control.
3Enter the desired remote control ID code.
To switch to ID1:
Enter “5019” using sNumeric keys.
To switch to ID2:
Enter “5020” using sNumeric keys.
Once the remote control code is registered,
bTRANSMIT blinks twice.
If it fails, bTRANSMIT blinks six times. Repeat
from step 1.
y
• Initializing the remote control code (see page 44) returns it to ID1.
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
INFORMATIONAPPENDIX
ADDITIONAL
DSP PARAM: All parameters of sound field
programs
VIDEO:Video conversion settings (resolution/
aspect) in the setup menu and the OSD
display position
ALL:Reset this unit to initial factory
settings
CANCEL:Cancellation of initialization
English
45 En
APPENDIX
Troubleshooting
Refer to the table below when this unit does not function properly. If the problem you are experiencing is not listed below
or if the instruction below does not help, turn off this unit, disconnect the power cable, and contact the nearest authorized
Yamaha dealer or service center.
General
ProblemCauseRemedy
This unit fails to turn
on or enters the
standby mode soon
after the power is
turned on.
This unit cannot be
turned off.
No sound.“Audio Output” in “1 HDMI” of Function
The power cable is not connected or the
plug is not completely inserted.
The speaker impedance setting is
incorrect.
(When this unit is turned back on and
“CHECK SP WIRES!” is displayed.) The
protection circuitry has been activated
because this unit was turned on while a
speaker cable was shorted.
The internal microcomputer is frozen due
to an external electric shock (such as
lightning or excessive static electricity) or
by a drop in power supply voltage.
Setup is set to “TV.”
A proper audio decoder is not selected.Display the OPTION menu and set “Decoder Mode”
Incorrect input or output cable
connections.
No appropriate input source has been
selected.
Speaker connections are not secure. Secure the connections. 11
The volume is turned down or muted. Turn up the volume. —
Signals this unit cannot reproduce are
being input from a source component,
such as a CD-ROM.
The HDMI components connected to this
unit do not support the HDCP copy
protection standards.
Connect the power cable properly to an AC wall
outlet.
Set the speaker impedance to match your speakers.45
Make sure that all speaker cables between this unit
and speakers are connected properly.
Disconnect the power cable from the AC wall outlet,
wait about 30 seconds and then plug it in again.
Select a choice for “Audio Output” (Function
Setup→1HDMI→Audio Output) other than “TV.”
to “Auto.”
Connect the cables properly. If the problem persists,
the cables may be defective.
Select an appropriate input source with NINPUTl
/ h or the gInput selection keys on the
remote control.
Display Signal info of the option menu and check the
input signal format.
If “No Signal” is displayed, check if the playback
component is properly connected to this unit (or a
proper input source is selected).
If “___” is displayed, the input signal in that format
cannot be reproduced by this unit.
Connect HDMI components that support the HDCP
copy protection standards.
See
page
—
11
—
42
33
14-16
21
—
55
46 En
Troubleshooting
ProblemCauseRemedy
No picture.An appropriate video input is not selected
on the monitor.
The composite output terminals are used
to output a component video signal, or the
COMPONENT VIDEO jacks are used to
output a composite video signal.
This unit outputs the video signals are not
supported on the video monitor connected
to the HDMI OUT jack.
Non-standard video signals are input.Connect the monitor to this unit via the
The sound suddenly
goes off.
Sound is heard from
the speaker on one
side only.
Only the center
speaker outputs
substantial sound.
No sound is output
from a specific
speaker.
No sound is heard
from the surround
speakers.
The protection circuitry has been activated
because of a short circuit, etc.
The sleep timer has turned off this unit.Turn on this unit, and play the source again.—
The playback component or speakers are
not connected properly.
The speaker level settings are incorrect. Adjust “B)Level” settings.41
When a monaural source sound field
program is applied, sound of all channels
are output from the center speaker for
some surround decoders.
Output from that speaker is disabled. Check the Speaker indicators on the front panel
The volume of that speaker is set to
minimum in Speaker Setup in the Setup
menu.
This unit or speaker is malfunction.Check the Speaker indicators on the front panel
This unit is in the “STRAIGHT” mode
and a monaural source is being played
back.
Sound may not be output from certain
channels depending on input sources or
sound field programs.
Select an appropriate video input on the monitor.—
If your monitor does not support the HDMI
connection, connect it to the COMPONENT OUT
jacks or the composite output terminals and select an
appropriate video input on the monitor.
Displays the advanced setup menu and select
“VIDEO” in “INIT” to reset the video parameters.
Displays the advanced setup menu and set
“MON.CHK” to “YES.”
COMPONENT OUT jacks or the composite output
terminals.
Check that the speaker impedance setting is correct.45
Check that the speaker wires are not touching each
other and then turn this unit back on.
Connect the cables properly. If the problem persists,
the cables may be defective.
Try another sound field program.24
display. If the corresponding indicator is turned off,
try the following.
1) Change the input source to another one.
2) With the selected sound field program, sound is not
output from that speaker. Select another sound field
program.
3) “None” may have been selected for that speaker on
this unit. Display Speaker Setup in the Setup menu
and enables output of that speaker.
Display Speaker Setup in the Setup menu and adjust
the volume (Manual Setup→B)Level).
display. If the corresponding indicator lights up,
connect another speaker and check if sound is output.
If sound is not output, this unit may be malfunction.
Press LSTRAIGHT or the jSTRAIGHT on the
remote control to turn off the “STRAIGHT” mode.
Try another sound field program.24
See
page
14
45
45
14
—
11
6, 21, 24,
40
41
6, 10
27
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
APPENDIX
English
47 En
Troubleshooting
ProblemCauseRemedy
No sound is heard
from the subwoofer.
No sound is heard
from the surround
back speakers.
The audio input
sources cannot be
played in the desired
digital audio signal
format.
Noise/hum noise is
heard.
“Memory Guard!” is
displayed and the
setting cannot be
changed.
This unit does not
operate properly.
“CHECK SP WIRES!”
appears on the front
panel display.
There is noise
interference from
digital or radio
frequency equipment.
“LFE/Bass Out” of “A)Config” in
“Speaker Setup” of the setup menu
(Speaker Setup→Manual
Setup→A)Config) is set to “Front” when
a Dolby Digital, DTS or AAC signal is
being played.
“LFE/Bass Out” of “A)Config” in
“Speaker Setup” of the setup menu
(Speaker Setup→Manual
Setup→A)Config) is set to “SWFR” or
“Front” when a 2-channel source is being
played.
The source does not contain low
frequency signals.
“Extended Surround” in the OPTION
menu is set to “Off,” or an input signal
does not contain a surround back flag with
“Extended Surround” set to “Auto.”
The connected component is not set to
output the desired digital audio signals.
Incorrect cable connection.Connect the audio cables properly. If the problem
A DTS-CD is being played back.1) When only noise is output
“Memory Guard” in “Set Menu” is set to
“On.”
The internal microcomputer is frozen due
to an external electric shock (such as
lightning or excessive static electricity) or
by a drop in power supply voltage.
Speaker cables are short-circuited.Make sure all speaker cables are connected correctly.12
This unit is too close to other digital or
radio frequency equipment.
Set “LFE/Bass Out” to “SWFR” or “Both.”39
Set “LFE/Bass Out” to “Both.”39
Set “Extended Surround” other than “Off” or “Auto.”40
Set the playback component properly referring to its
operating instructions.
persists, the cables may be defective.
If a DTS bitstream signal is not properly input to this
unit, only noise is output. Connect the playback
component to this unit by digital connection and play
back the DTS-CD. If the condition is not improved,
the problem may results from the playback
component. Consult the manufacturer of the playback
component.
2) When noise is output during playback or skip
operation
Before playing back the DTS-CD, display the option
menu after selecting the input source and set
“Decoder Mode” to “DTS.”
Set “Memory Guard” to “Off.”43
Disconnect the power cable from the AC wall outlet,
wait about 30 seconds and then plug it in again.
Move this unit further away from such equipment.—
See
page
—
—
16, 34
—
48 En
Troubleshooting
ProblemCauseRemedy
The picture is
disturbed.
This unit suddenly
enters the standby
mode.
The video software is copy-protected.
The internal temperature becomes too
high and the overheat protection circuitry
has been activated.
Wait about 1 hour for this unit to cool down and then
turn it back on.
HDMI
ProblemCauseRemedy
No picture or sound.The number of the connected HDMI
components is over the limit.
The connected HDMI component does not
support high-bandwidth digital copyright
protection (HDCP).
Disconnect some of the HDMI components.—
Connect an HDMI component that supports HDCP.15
Tuner (FM/AM)
ProblemCauseRemedy
FM stereo reception is
noisy.
There is distortion, and
clear reception cannot
FM
be obtained even with a
good FM antenna.
The desired station
cannot be tuned into
with the automatic
tuning method.
The desired station
cannot be tuned into
with the automatic
tuning method.
There are continuous
crackling and hissing
AM
noises.
There are buzzing and
whining noises.
You are too far from the station
transmitter or the input from the
antenna is weak.
There is multi-path interference.Adjust the antenna height or orientation, or
You are in an area far from a station or
an input from the antenna is weak.
The signal is weak or the antenna
connections are loose.
Supplied AM loop antenna is not
connected.
The noises may be caused by lightning,
fluorescent lamps, motors, thermostats
and other electrical equipment.
A TV set is being used nearby.Move this unit away from the TV set.—
Check the antenna connections.17
Replace the outdoor antenna with a more
sensitive multi-element antenna.
Switch to monaural mode.34
place it in a different location.
Replace an outdoor antenna with more
sensitive multi element antenna.
Tune in manually or by direct frequency
tuning.
Adjust the AM loop antenna orientation.17
Use the manual tuning method.28
Connect the AM loop antenna correctly even
if you use an outdoor antenna.
It is difficult to completely eliminate noise,
but it can be reduced by installing and
properly grounding an outdoor AM antenna.
See
page
—
See
page
See
page
—
—
—
28
17
17
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
APPENDIX
49 En
English
Troubleshooting
Remote control
ProblemCauseRemedy
The remote control
does not work or
function properly.
Wrong distance or angle.The remote control will function within a maximum
range of 6 m (20 ft) and no more than 30 degrees
offaxis from the front panel.
Direct sunlight or lighting (from an
inverter type of fluorescent lamp, strobe
light, etc.) is striking the remote control
sensor of this unit.
The batteries are weak.Replace all batteries.9
The remote control ID of the remote
control and this unit do not match.
The remote control code is not correctly
set.
Even if the remote control code is
correctly set, there are some models that
do not respond to the remote control.
Adjust the lighting angle or reposition this unit.—
Match the remote control ID of this unit and the
remote control.
Set the remote control code correctly using “List of
remote control codes” at the end of this manual.
Try setting another code of the same manufacturer
using “List of remote control codes” at the end of this
manual.
If this unit does not work when you press nCursor,
do the following.
When the key does not work during DVD disc menu
operation: press the gInput selection keys on
the remote control again.
When the key does not work during OPTION menu/
SETUP menu operation: press the key applicable for
the current menu operation again.
See
page
9
45
44
44
—
iPod™
Note
• In case of a transmission error without a status message appearing on the front panel display and the OSD, check the connection of your iPod (see
page 16).
ProblemCauseRemedy
Loading...This unit is in the middle of recognizing
the connection with your iPod.
This unit is in the middle of acquiring
song lists from your iPod.
Connect errorThere is a problem with the signal path
from your iPod to this unit.
Unknown iPodThe iPod being used is not supported by
this unit.
iPod ConnectedYour iPod is properly placed in the
Yamaha iPod universal dock.
Turn off this unit and reconnect the Yamaha iPod
universal dock to the DOCK terminal of this unit.
Remove your iPod in the Yamaha iPod universal dock
and then place it back in the dock.
This unit supports iPod Touch, iPod (Click Wheel),
iPod nano and iPod mini.
50 En
See
page
16
16
—
Troubleshooting
ProblemCauseRemedy
DisconnectedYour iPod is removed from the Yamaha
iPod universal dock.
Unable to playThis unit cannot play back the songs
currently stored on your iPod.
Place your iPod in the Yamaha iPod universal dock.16
Check that the songs currently stored on your iPod
are playable.
Store some other playable music files on your iPod.—
Bluetooth™
ProblemCauseRemedy
Searching...The Bluetooth wireless audio receiver and
the Bluetooth component are in the
middle of the pairing.
The Bluetooth wireless audio receiver and
the Bluetooth component are in the
middle of establishing the connection.
CompletedThe pairing is completed.
CanceledThe pairing is canceled.
BT ConnectedThe connection between the Yamaha
Bluetooth wireless audio receiver and the
Bluetooth component is established.
BT DisconnectedThe Bluetooth component is disconnected
from the Yamaha Bluetooth wireless
audio receiver.
See
page
—
See
page
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
Auto Setup (YPAO)
Notes
• If the “ERROR” or “WARNING” screen appears, resolve the problem and then run “Auto Setup” again.
• Warning message “W-2” or “W-3” indicates that the adjusted settings may not be optimal.
• Depending on the speakers, warning message “W-1” may appears even if the speaker connections are correct.
• If error message “E-10” occurs repeatedly, contact a qualified Yamaha service center.
Before Auto Setup
Error messageCauseRemedy
Connect MIC!Optimizer microphone is not connected.Connect the supplied optimizer microphone to the
OPTIMIZER MIC jack on the front panel.
Unplug HP!Headphones are connected.Unplug the headphones.—
Memory Guard!The parameters of this unit are protected.Set “Memory Guard” to “Off.”43
During Auto Setup
Error messageCauseRemedy
E-1:NO FRONT SPFront L/R channel signals are not
detected.
E-2:NO SUR. SPOnly a signal from one of the surround
channels are detected.
Check the front L/R speaker connections.11
Check the surround L/R speaker connections.11
APPENDIX
See
page
18
See
page
English
51 En
Troubleshooting
Error messageCauseRemedy
E-4:SBR->SBLOnly right surround back channel signal
is detected.
E-5:NOISYMeasurement cannot be performed
accurately due to loud ambient noise.
E-6:CHECK SUR.Surround back speakers are connected,
though surround L/R speakers are not.
E-7:NO MICThe optimizer microphone was
unplugged during the “Auto Setup”
procedure.
E-8:NO SIGNALThe optimizer microphone does not
detect test tones.
E-9:USER CANCEL“Auto Setup” was cancelled due to an
inappropriate user operation.
E-10:INTERNAL ERROR An internal error occurred.Run “Auto Setup” again.18
If you connect only one surround back speaker,
connect it to the L-side (SINGLE) terminal.
Try running “Auto Setup” in a quiet environment.—
Turn off noisy electric equipment like air
conditioners or move them away from the optimizer
microphone.
When using surround back speakers, you need to
connect surround L/R speakers.
Do not touch the optimizer microphone during “Auto
Setup.”
Check whether the microphone is properly placed.18
Check whether the speakers are properly placed and
connected.
The optimizer microphone or OPTIMIZER MIC
jack may be defective. Contact the nearest Yamaha
dealer or service center.
Run “Auto Setup” again.18
See
page
11
—
11
18
11
18
After Auto Setup
Error messageCauseRemedy
W-1:OUT OF PHASESpeaker polarity is not correct. This
message may appear depending on the
speakers even when the speakers are
connected correctly.
W-2:OVER 24m (80ft) The distance between the speaker and the
listening position is over 24 m (80 ft).
W-3:LEVEL ERRORThe difference of volume level among
speakers is excessive.
Check the polarities (+, –) of the displayed speaker.
If they are correct, the speakers work properly even
when this message is displayed.
Bring the speaker within 24 m (80 ft.) area around
the listening position.
Recheck the speaker positions and make sure all
speakers are placed in a similar environment.
Check the polarities (+, –) of the speakers.11
We recommended that you use speakers with the
same or similar specifications.
Adjust the output volume of the subwoofer.—
See
page
11
—
—
—
52 En
Glossary
■Audio and video synchronization (lip sync)
Lip sync, an abbreviation for lip synchronization, is a technical term
that involves both a problem and a capability of maintaining audio and
video signals synchronized during post-production and transmission.
Whereas the audio and video latency requires complex end-user
adjustments, HDMI version 1.3 incorporates an automatic audio and
video syncing capability that allows devices to perform this
synchronization automatically and accurately without user interaction.
■Bi-amplification connection
A bi-amplification connection uses two amplifiers for a speaker.
One amplifier is connected to the woofer section of a loudspeaker
while the other is connected to the combined mid and tweeter section.
With this arrangement each amplifier operates over a restricted
frequency range. This restricted range presents each amplifier with a
much simpler job and each amplifier is less likely to influence the
sound in some way.
■Component video signal
With the component video signal system, the video signal is separated
into the Y signal for the luminance and the PB and PR signals for the
chrominance. Color can be reproduced more faithfully with this
system because each of these signals is independent. The component
signal is also called the “color difference signal” because the
luminance signal is subtracted from the color signal. A monitor with
component input jacks is required in order to output component
signals.
■Composite video signal
With the composite video signal system, the video signal is composed
of three basic elements of a video picture: color, brightness and
synchronization data. A composite video jack on a video component
transmits these three elements combined.
■Deep Color
Deep Color refers to the use of various color depths in displays, up
from the 24-bit depths in previous versions of the HDMI specification.
This extra bit depth allows HDTVs and other displays go from
millions of colors to billions of colors and eliminate on-screen color
banding for smooth tonal transitions and subtle gradations between
colors. The increased contrast ratio can represent many times more
shades of gray between black and white. Also Deep Color increases
the number of available colors within the boundaries defined by the
RGB or YCbCr color space.
■Dolby Digital
Dolby Digital is a digital surround sound system that gives you
completely independent multi-channel audio. With 3 front channels
(front L/R and center), and 2 surround stereo channels, Dolby Digital
provides 5 full-range audio channels. With an additional channel
especially for bass effects, called LFE (Low Frequency Effect), the
system has a total of 5.1-channels (LFE is counted as 0.1 channel). By
using 2-channel stereo for the surround speakers, more accurate
moving sound effects and surround sound environment are possible
than with Dolby Surround. The wide dynamic range from maximum
to minimum volume reproduced by the 5 full-range channels and the
precise sound orientation generated using digital sound processing
provide listeners with unprecedented excitement and realism.
With this unit, any sound environment from monaural up to a 5.1channel configuration can be freely selected for your enjoyment.
■Dolby Digital Surround EX
Dolby Digital EX creates 6 full-bandwidth output channels from 5.1channel sources.
For the best results, Dolby Digital EX should be used with movie
sound tracks recorded with Dolby Digital Surround EX. With this
additional channel, you can experience more dynamic and realistic
moving sound especially with scenes with “fly-over” and “flyaround” effects.
■Dolby Digital Plus
Dolby Digital Plus is an advanced audio technology developed for
high-definition programming and media including HD broadcasts,
and Blu-ray Disc. Selected as an optional audio standard for Blu-ray
Disc, this technology delivers multichannel sound with discrete
channel output. Supporting bitrates up to 6.0 Mbps, Dolby Digital
Plus can carry up to 7.1 discreet audio channels simultaneously.
Supported by HDMI version 1.3 and designed for the optical disc
players and AV receivers/amplifiers of the future, Dolby Digital Plus
also remains fully compatible with the existing multichannel audio
systems that incorporate Dolby Digital.
■Dolby Pro Logic II
Dolby Pro Logic II is an improved technique used to decode vast
numbers of existing Dolby Surround sources. This new technology
enables a discrete 5-channel playback with 2 front left and right
channels, 1 center channel, and 2 surround left and right channels
instead of only 1 surround channel for conventional Pro Logic
technology. There are three modes available: “Music mode” for music
sources, “Movie mode” for movie sources and “Game mode” for
game sources.
■Dolby Pro Logic IIx
Dolby Pro Logic IIx is a new technology enabling discrete
multichannel playback from 2-channel or multi-channel sources.
There are three modes available: “Music mode” for music sources,
“Movie mode” for movie sources (for 2-channel sources only) and
“Game mode” for game sources.
■Dolby Surround
Dolby Surround is widely used with nearly all video tapes and laser
discs, and in many TV and cable broadcasts as well. Dolby Surround
uses a 4-channel analog recording system to reproduce realistic and
dynamic sound effects: 2 front left and right channels (stereo), a
center channel for dialog (monaural), and a surround channel for
special sound effects (monaural). The surround channel reproduces
sound within a narrow frequency range. The Dolby Pro Logic decoder
built into this unit employs a digital signal processing system that
automatically stabilizes the volume on each channel to enhance
moving sound effects and directionality.
■Dolby TrueHD
Dolby TrueHD is an advanced lossless audio technology developed
for high-definition disc-based media including Blu-ray Disc. Selected
as an optional audio standard for Blu-ray Disc, this technology
delivers sound that is bit-for-bit identical to the studio master, offering
a high-definition home theater experience.
Supporting bitrates up to 18.0 Mbps, Dolby TrueHD can carry up to 8
discrete channels of 24-bit/96 kHz audio simultaneously.
Dolby TrueHD also remains fully compatible with the existing
multichannel audio systems and retains the metadata capability of
Dolby Digital, allowing dialog normalization and dynamic range
control.
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
APPENDIX
English
53 En
Glossary
■DSD
Direct Stream Digital (DSD) technology stores audio signals on
digital storage media, such as Super Audio CDs. Using DSD, signals
are stored as single bit values at a high-frequency sampling rate of
2.8224 MHz, while noise shaping and oversampling are used to
reduce distortion, a common occurrence with very high quantization
of audio signals. Due to the high sampling rate, better audio quality
can be achieved than that offered by the PCM format used for normal
audio CDs. The frequency is equal to or higher than 100 kHz and the
dynamic range is 120 dB. This unit can transmit or receive DSD
signals via the HDMI jack.
■DTS 96/24
DTS 96/24 offers an unprecedented level of audio quality for multichannel sound on DVD video, and is fully backward-compatible with
all DTS decoders. “96” refers to a 96 kHz sampling rate compared to
the typical 48 kHz sampling rate. “24” refers to 24-bit word length.
DTS 96/24 offers sound quality transparent to the original 96/24
master, and 96/24 5.1-channel sound with full-quality full-motion
video for music programs and motion picture soundtracks on DVD
video.
■DTS Digital Surround
DTS digital surround was developed to replace the analog soundtracks
of movies with a 5.1-channel digital sound track, and is now rapidly
gaining popularity in movie theaters around the world. DTS, Inc. has
developed a home theater system so that you can enjoy the depth of
sound and natural spatial representation of DTS digital surround in
your home. This system produces practically distortion-free 6-channel
sound (technically, front left and right, center, surround left and right,
and LFE 0.1 (subwoofer) channels for a total of 5.1 channels). This
unit incorporates a DTS-ES decoder that enables 6.1-channel
reproduction by adding the surround back channel to the existing 5.1channel format.
■DTS Express
This is an audio format for next-generation optical discs such as Bluray discs. It uses optimized low bit rate signals for network streaming.
In the case of a Blu-ray disc, this format is used with secondary audio,
enabling you to enjoy the commentary of the movie producer via the
Internet while playing the main program.
■DTS-HD High Resolution Audio
DTS-HD High Resolution Audio is a high resolution audio
technology developed for high-definition disc-based media including
Blu-ray Disc. Selected as an optional audio standard for Blu-ray Disc,
this technology delivers sound that is virtually indistinguishable from
the original, offering a high-definition home theater experience.
Supporting bitrates up to 6.0 Mbps for Blu-ray Disc, DTS-HD High
Resolution Audio can carry up to 7.1 discrete channels of 24-bit/96
kHz audio simultaneously.
DTS-HD High Resolution Audio also remains fully compatible with
the existing multichannel audio systems that incorporate DTS Digital
Surround.
■DTS-HD Master Audio
DTS-HD Master Audio is an advanced lossless audio technology
developed for high-definition disc-based media including Blu-ray
Disc. Selected as an optional audio standard for Blu-ray Disc, this
technology delivers sound that is bit-for-bit identical to the studio
master, offering a high-definition home theater experience.
Supporting bitrates up to 24.5 Mbps for Blu-ray Disc, DTS-HD
Master Audio can carry up to 7.1 discrete channels of 24-bit/96 kHz
audio simultaneously. Supported by HDMI version 1.3 and designed
for the optical disc players and AV receivers/amplifiers of the future,
DTS-HD Master Audio also remains fully compatible with the
existing multichannel audio systems that incorporate DTS Digital
Surround.
■ HDMI
HDMI (High-Definition Multimedia Interface) is the first industrysupported, uncompressed, all-digital audio/video interface. Providing
an interface between any source (such as a set-top box or AV receiver)
and an audio/video monitor (such as a digital television), HDMI
supports standard, enhanced or high-definition video as well as multichannel digital audio using a single cable. HDMI transmits all ATSC
HDTV standards and supports 8-channel digital audio, with
bandwidth to spare to accommodate future enhancements and
requirements.
When used in combination with HDCP (High-bandwidth Digital
Content Protection), HDMI provides a secure audio/video interface
that meets the security requirements of content providers and system
operators. For further information on HDMI, visit the HDMI website
at “http://www.hdmi.org/.”
■ LFE 0.1 channel
This channel reproduces low-frequency signals. The frequency range
of this channel is from 20 Hz to 120 Hz. This channel is counted as
0.1 because it only enforces a low-frequency range compared to the
full-range reproduced by the other 5/6 channels in Dolby Digital or
DTS 5.1/6.1-channel systems.
■ Neo:6
Neo:6 decodes the conventional 2-channel sources for 6- channel
playback by the specific decoder. It enables playback with the fullrange channels with higher separation just like digital discrete signal
playback. There are two modes available: “Music mode” for music
sources and “Cinema mode” for movie sources.
■ PCM (Linear PCM)
Linear PCM is a signal format under which an analog audio signal is
digitized, recorded and transmitted without using any compression.
This is used as a method of recording CDs and DVD audio. The PCM
system uses a technique for sampling the size of the analog signal per
very small unit of time. Standing for “Pulse Code Modulation,” the
analog signal is encoded as pulses and then modulated for recording.
■ Sampling frequency and number of
quantized bits
When digitizing an analog audio signal, the number of times the
signal is sampled per second is called the sampling frequency, while
the degree of fineness when converting the sound level into a numeric
value is called the number of quantized bits. The range of rates that
can be played back is determined based on the sampling rate, while
the dynamic range representing the sound level difference is
determined by the number of quantized bits. In principle, the higher
the sampling frequency, the wider the range of frequencies that can be
played back, and the higher the number of quantized bits, the more
finely the sound level can be reproduced.
■ “x.v.Color”
A color space standard supported by HDMI version 1.3. It is a more
extensive color space than sRGB, and allows the expression of colors
that could not be expressed before. While remaining compatible with
the color gamut of sRGB standards, “x.v.Color” expands the color
space and can thus produce more vivid, natural images. It is
particularly effective for still pictures and computer graphics.
54 En
Sound field program information
■CINEMA DSP
Since the Dolby Surround and DTS systems were originally designed
for use in movie theaters, their effect is best felt in a theater having
many speakers designed for acoustic effects. Since home conditions,
such as room size, wall material, number of speakers, and so on, can
differ so widely, it is inevitable that there are differences in the sound
heard.
Based on a wealth of actually measured data, Yamaha CINEMA DSP
provides the audiovisual experience of a movie theater in the listening
room of your own home by using the Yamaha original sound field
technology combined with various digital audio systems.
■SILENT CINEMA
Yamaha has developed a natural, realistic sound effect DSP algorithm
for headphones. Parameters for headphones have been set for each
sound field so that accurate representations of all the sound field
programs can be enjoyed on headphones.
■Virtual CINEMA DSP
Yamaha has developed a Virtual CINEMA DSP algorithm that allows
you to enjoy DSP sound field surround effects even without any
surround speakers by using virtual surround speakers. It is even
possible to enjoy Virtual CINEMA DSP using a minimal two-speaker
system that does not include a center speaker.
■Compressed Music Enhancer
The Compressed Music Enhancer feature of this unit enhances your
listening experience by regenerating the missing harmonics in a
compression artifact. As a result, flattened complexity due to the loss
of high-frequency fidelity as well as lack of bass due to the loss of
low-frequency bass is compensated, providing improved performance
of the overall sound system.
Information on HDMI™
■HDMI signal compatibility
Audio signals
Audio signal typesAudio signal formatsCompatible media
2ch Linear PCM2ch, 32-192 kHz, 16/20/24 bitCD, DVD-Video, DVD-Audio, etc.
Multi-ch Linear PCM8ch, 32-192 kHz, 16/20/24 bitDVD-Audio, Blu-ray Disc, HD DVD, etc.
DSD2/5.1ch, 2.8224 MHz, 1 bitSA-CD, etc.
BitstreamDolby Digital, DTSDVD-Video, etc.
Bitstream (High definition audio)Dolby TrueHD, Dolby Digital Plus, DTS-HD
Master Audio, DTS-HD High Resolution Audio,
DTS Express
Blu-ray Disc, HD DVD, etc.
INTRODUCTION
PREPARATION
OPERATION
BASIC
OPERATION
ADVANCED
y
• If the input source component can decode the bitstream audio signals of audio commentaries, you can play back the audio sources with the audio
commentaries mixed down by using the DIGITAL INPUT OPTICAL (or COAXIAL) connections.
• Refer to the supplied instruction manuals of the input source component, and set the component appropriately.
Notes
• When CPPM copy-protected DVD-Audio is played back, video and audio signals may not be output depending on the type of the DVD player.
• This unit is not compatible with HDCP-incompatible HDMI or DVI components.
• To decode audio bitstream signals on this unit, set the input source component appropriately so that the component outputs the bitstream audio signals
directly (does not decode the bitstream signals on the component). Refer to the supplied instruction manuals for details.
• This unit is not compatible with the audio commentary features (for example, the special audio contents downloaded via Internet) of Blu-ray Disc or HD
DVD. This unit does not play back the audio commentaries of the Blu-ray Disc or HD DVD contents.
Video signals
This unit is compatible with the video signals of the following resolutions:
• 480i/60 Hz
• 576i/50 Hz
• 480p/60 Hz
• 576p/50 Hz
• 720p/60 Hz, 50 Hz
• 1080i/60 Hz, 50 Hz
• 1080p/60 Hz, 50 Hz, 24 Hz
55 En
APPENDIX
English
Specifications
AUDIO SECTION
• Minimum RMS Output Power for Front, Center, Surround,
Surround back
[U.S.A. and Canada models]
1 kHz, 0.9% THD, 8 Ω .......................................................... 90 W
[Other models]
1 kHz, 0.9% THD, 6 Ω .......................................................... 90 W
• Dynamic Power (IHF)
[U.S.A. and Canada models]
Front Speakers 8/6/4/2 Ω .................................. 95/110/130/150 W
[Other models]
Front Speakers 6/4/2 Ω .......................................... 100/110/125 W
• Maximum Useful Output Power (JEITA) [China, Korea, General
and Asia models]
1 kHz, 10% THD, 6 Ω ......................................................... 115 W
• Maximum Output Power [U.K., Europe, Russia and Asia models]
1 kHz, 0.7% THD, 4 Ω ........................................................ 105 W
• Dynamic Headroom [U.S.A. and Canada models]
8 Ω.......................................................................................0.23 dB
• IEC Output Power [U.K., Europe, Russia and Asia models]
Front Speakers 1 kHz, 0.9% THD, 8 Ω ................................. 90 W
“ASTANDBY/ON” or
“fPOWER” (example) indicates
the name of the parts on the front
panel or the remote control. Refer
to “Part names and functions” on
page 4.
58 En
List of remote control codes
TV
A.R. Systems 0274
Acme0260
Acura0261, 0273
ADC0259
Admiral0100, 0224, 0257,
The letters in circles and the numbers in squares correspond to those in the Owner's Manual.
Les lettres dans les cercles et les numéros dans les carrés correspondent à ceux du mode d'emploi.
Le lettere cerchiate e i numeri nei quadratini corrispondono a quelli nel Manuale di istruzioni.
Las letras enmarcadas en un círculo y los números enmarcados en un cuadrado se corresponden con aquellos del manual de instrucciones.
Буквы в кружочках и цифры в квадратиках соответствуют таковым в инструкции по эксплуатации.
