YAMAHA FZ6-SHGX PARTS CATALOGUE 08
FZ6-SHG (4S86) EUROPE,SOUTH AFRICA
FZ6-SHGX (4S87) AUSTRALIA
A2
1G4S8-300E1
2G4S8-300E1
()
FZ6-SHG/FZ6-SHGX
PARTS CATALOGUE
©2007 by Yamaha Motor Co., Ltd.
1st edition, August 2007
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Co., Ltd.
is expressly prohibited.
A3
FOREWORD
This Parts Catalogue is related to the parts for the model(s) on the cover page. When you are
ordering replacement parts, please refer to this Parts Catalogue and quote both part numbers
and part names correctly.
1. Modifications or additions which have been made after the issue of the Parts Catalogue
will be announced in the Parts News.
It is advisable that you make the necessary corrections to the Parts Catalogue according
to the Parts News.
2. Abbreviations
The following abbreviations are used in this Parts Catalogue.
“UR” Use specified parts number.
“UN” Use as many as needed.
“AP” Alternate Parts
“LM” Locally Made (Parts need to be ordered locally)
“F#” Frame No. (Applicable machine No.)
“O/S” Over Size
3. The number of components for assembly
• Parts, which are to be supplied in an assembly, are listed with a dot (.) in front of the
part name as shown below.
• The numeral appearing to the right of each component part indicates the quantity of
parts for each assembly unit.
PART NO. DESCRIPTION Q’TY REMARKS
2F5–83310–60 FRONT FLASHER LIGHT ASSY 2
115–83311–60 .BULB (6V–18W) 1
6. The asterisk (*) before a reference number indicates modified items after the first edition.
4. Applicable colours of graphics are represented in the “REMARKS” as shown below.
PART NO. DESCRIPTION Q’TY REMARKS
2N4–24110–00–X5 FUEL TANK COMP. 2 MXR
3J1–24240–10 .GRAPHIC, FUEL TANK 1 FOR MXR
5. Note that the illustrations for reference in finding parts numbers are not to be used for
assembling. When assembling, please use the applicable service manual.
A4
7. Applicable Serial No.
Engine Serial No. Frame Serial No.
8. Applicable Colour Code (The (*) mark shows Model colour.)
Abbreviation Colour Name Colour Code
DPBMU(*) DARK PURPLISH BLUE METALLIC U 0996
LGB LOW GLOSS BLACK 0098
MBL2 MAT BLACK 2 0582
SM1(*) SILVER METALLIC 1 0660
SMX(*) BLACK METALLIC X 0903
FOREWORD
A5
MODEL LABEL
(1) A label called “Model Label” is affixed in the location as indicated in (3) below.
When using this parts catalogue, please be sure to cross–reference the “model code –
production code No.” in the catalogue with the “model code – production code No.” indicated on the Model Label affixed onto the product concerned.
(2) “Model Label” Indication
(3) Model Label Affixing Location
(4) Colouring Information
Model Code
4S86
4S87
Colouring
Type Code
A 0903
B 0660
C 0996
A 0903
B 0660
C 0996
Colour
Code
Colour Name
BLACK METALLIC X SMX
SILVER METALLIC 1 SM1
DARK PURPLISH BLUE METALLIC U DPBMU
BLACK METALLIC X SMX
SILVER METALLIC 1 SM1
DARK PURPLISH BLUE METALLIC U DPBMU
Abbrevia-
tion
(5) Model Code – Production Code Number of Model Listed in This Parts Catalogue
Model
Code
4S86
4S87 010 AUSTRALIA
Production
Code No.
010 EUROPE
DENMARK
030
050
060 GREECE
070
FINLAND
NORWAY
SWEDEN
UNITED KINGDOM
IRELAND
SOUTH AFRICA
Country
(destination)
Model
Code
Production
Code No.
Country
(destination)
A6
ENGINE
CYLINDER ............................................................................B2
CRANKSHAFT & PISTON ....................................................B3
VALVE ...................................................................................B4
CAMSHAFT & CHAIN ...........................................................B6
WATER PUMP ......................................................................B7
RADIATOR & HOSE .............................................................B8
OIL PUMP .............................................................................B10
OIL CLEANER .......................................................................B11
INTAKE .................................................................................B12
INTAKE 2 ..............................................................................B13
AIR INDUCTION SYSTEM .................................................... B15
EXHAUST .............................................................................C2
CRANKCASE ........................................................................C4
CRANKCASE COVER 1 .......................................................C6
STARTER ..............................................................................C8
CLUTCH ................................................................................C9
TRANSMISSION ...................................................................C11
SHIFT CAM & FORK .............................................................C13
SHIFT SHAFT .......................................................................C14
CHASSIS
FRAME ..................................................................................D2
FENDER ................................................................................D5
SIDE COVER ........................................................................D8
REAR ARM ...........................................................................D9
REAR SUSPENSION ............................................................D10
STEERING ............................................................................D11
FRONT FORK .......................................................................D12
FUEL TANK ...........................................................................D14
SEAT .....................................................................................E2
FRONT WHEEL .................................................................... E3
FRONT BRAKE CALIPER ....................................................E4
REAR WHEEL .......................................................................E5
REAR BRAKE CALIPER .......................................................E7
STEERING HANDLE & CABLE ............................................E8
FRONT MASTER CYLINDER ...............................................E9
STAND & FOOTREST ..........................................................E10
REAR MASTER CYLINDER .................................................E13
COWLING 1 ..........................................................................E14
GENERATOR ........................................................................F2
STARTING MOTOR ..............................................................F3
CONTENTS
FLASHER LIGHT .................................................................. F4
METER ................................................................................. F5
HEADLIGHT ......................................................................... F6
TAILLIGHT ............................................................................ F7
HANDLE SWITCH & LEVER ................................................ F8
ELECTRICAL 1 ..................................................................... F9
ELECTRICAL 2 ..................................................................... F10
INDEX
NUMERICAL INDEX ............................................................. M1
FIG. 1 CYLINDER
REF.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
PART NO. DESCRIPTION
1B3–11101–00
5EB–11133–10
93440–10153
90105–06027
90340–20090
11H–15138–00
95027–08012
90430–08119
95617–08625
90119–10003
91314–06060
94701–00403
5VX–11181–00
1B3–11191–00
5BE–12241–00
CYLINDER HEAD ASSY 1 1
.GUIDE, VALVE 1 16 16
.CIRCLIP 16 16
.BOLT, FLANGE 20 20
.PLUG, STRAIGHT SCREW 3 3
.NOZZLE 1 1 1
BOLT, FLANGE 1 1
GASKET 1 1
BOLT, STUD 8 8
BOLT, WITH WASHER 10 10
BOLT 2 2
PLUG, SPARK (NGK CR9EK) 4 4
GASKET, CYLINDER HEAD 1 1 1
COVER, CYLINDER HEAD 1 1 1
.GUIDE, STOPPER 2 1 1
4S86
4S87
REMARKS
B
2
16
5SL–11193–00
17
5SL–1482K–00
18
5SL–14890–00
19
5SL–14899–00
20
91317–06020
21
90109–066F0
22
4KG–1111G–00
23
99530–10114
GASKET, HEAD COVER 1 1 1
PLATE 4 4
REED VALVE ASSY 2 2
CAP, CASE 2 2
BOLT 4 4
BOLT 6 6
RUBBER, MOUNT 1 6 6
PIN, DOWEL 2 2
FIG. 2 CRANKSHAFT & PISTON
REF.
NO.
1
2
3
4
PART NO. DESCRIPTION
5SL–11411–00
5VX–11650–00
5VX–11654–00
5VX–11656–00
CRANKSHAFT 1 1
CONNECTING ROD ASSY 4 4
.BOLT, CONNECTING ROD 2 2
PLANE BEARING, CONNECTING ROD 8 8 UR BLUE
4S86
4S87
REMARKS
5VX–11656–10
5VX–11656–20
5VX–11656–30
5
5EB–11416–A0
5EB–11416–00
5EB–11416–10
5EB–11416–20
5EB–11416–30
6
5SL–11631–00
7
5SL–11603–00
8
93450–17129
9
5EB–11633–00
PLANE BEARING, CONNECTING ROD 8 8 UR BLACK
PLANE BEARING, CONNECTING ROD 8 8 UR BROWN
PLANE BEARING, CONNECTING ROD 8 8 UR GREEN
PLANE BEARING, CRANKSHAFT 1 10 10 UR WHITE
PLANE BEARING, CRANKSHAFT 1 10 10 UR BLUE
PLANE BEARING, CRANKSHAFT 1 10 10 UR BLACK
PLANE BEARING, CRANKSHAFT 1 10 10 UR BROWN
PLANE BEARING, CRANKSHAFT 1 10 10 UR GREEN
PISTON (STD) 4 4
PISTON RING SET (STD) 4 4
CIRCLIP 8 8
PIN, PISTON 4 4
B
3
FIG. 3 VALVE
REF.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
PART NO. DESCRIPTION
5SL–12111–10
5SL–12121–10
5SL–12116–00
5EB–12126–00
5EB–12113–00
5EB–12114–00
5EB–12124–01
5EB–12117–00
5EB–12127–00
1HX–12118–00
4TV–12119–00
1HX–12168–00
VALVE, INTAKE 8 8
VALVE, EXHAUST 8 8
SEAT, VALVE SPRING 8 8
SEAT, VALVE SPRING 2 8 8
SPRING, VALVE INNER 8 8
SPRING, VALVE OUTER 8 8
SPRING, VALVE OUTER 8 8
RETAINER, VALVE SPRING 8 8
RETAINER, VALVE SPRING 8 8
COTTER, VALVE 32 32
SEAL, VALVE STEM 16 16
PAD, ADJUSTING 2 (1.20) 16 16 UR
4S86
4S87
REMARKS
B
4
1HX–12168–20
1HX–12168–40
1HX–12168–60
1HX–12168–80
1HX–12168–A0
1HX–12168–F0
1HX–12168–H1
1HX–12168–K1
1HX–12168–M1
1HX–12168–R1
1HX–12168–U1
1HX–12168–W1
1HX–12168–Y1
1HX–12169–11
1HX–12169–31
PAD, ADJUSTING 2 (1.25) 16 16 UR
PAD, ADJUSTING 2 (1.30) 16 16 UR
PAD, ADJUSTING 2 (1.35) 16 16 UR
PAD, ADJUSTING 2 (1.40) 16 16 UR
PAD, ADJUSTING 2 (1.45) 16 16 UR
PAD, ADJUSTING 2 (1.50) 16 16 UR
PAD, ADJUSTING 2 (1.55) 16 16 UR
PAD, ADJUSTING 2 (1.60) 16 16 UR
PAD, ADJUSTING 2 (1.65) 16 16 UR
PAD, ADJUSTING 2 (1.70) 16 16 UR
PAD, ADJUSTING 2 (1.75) 16 16 UR
PAD, ADJUSTING 2 (1.80) 16 16 UR
PAD, ADJUSTING 2 (1.85) 16 16 UR
PAD, ADJUSTING 2 (1.90) 16 16 UR
PAD, ADJUSTING 2 (1.95) 16 16 UR
FIG. 3 VALVE
REF.
NO.
12
PART NO. DESCRIPTION
1HX–12169–50
PAD, ADJUSTING 2 (2.00) 16 16 UR
4S86
4S87
REMARKS
1HX–12169–70
1HX–12169–90
1HX–12169–E0
1HX–12169–G0
1HX–12169–J0
1HX–12169–L0
1HX–12169–N0
1HX–12169–T0
13
5EB–12153–20
5EB–12153–30
5EB–12153–09
PAD, ADJUSTING 2 (2.05) 16 16 UR
PAD, ADJUSTING 2 (2.10) 16 16 UR
PAD, ADJUSTING 2 (2.15) 16 16 UR
PAD, ADJUSTING 2 (2.20) 16 16 UR
PAD, ADJUSTING 2 (2.25) 16 16 UR
PAD, ADJUSTING 2 (2.30) 16 16 UR
PAD, ADJUSTING 2 (2.35) 16 16 UR
PAD, ADJUSTING 2 (2.40) 16 16 UR
LIFTER, VALVE 16 16 UR BLUE
LIFTER, VALVE 16 16 UR RED
LIFTER, VALVE (O/S) 16 16 AP GREEN
B
5
FIG. 4 CAMSHAFT & CHAIN
REF.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
PART NO. DESCRIPTION
5VX–12170–00
5VX–12180–00
5VX–12176–00
90105–07004
94591–49120
5SL–12210–10
5EL–12228–00
5SL–12214–00
4FM–12213–00
91314–06025
5EB–12251–00
5EB–12252–10
93607–44002
CAMSHAFT ASSY 1 1 1
CAMSHAFT ASSY 2 1 1
SPROCKET, CAM CHAIN 2 2
BOLT, FLANGE 4 4
CHAIN 1 1
TENSIONER ASSY, CAM CHAIN 1 1
.BOLT 1 1
.GASKET 1 1
GASKET, TENSIONER CASE 1 1
BOLT 2 2
DAMPER, CHAIN 1 1 1
DAMPER, CHAIN 2 1 1
PIN, DOWEL 1 1
4S86
4S87
REMARKS
B
6
FIG. 5 WATER PUMP
REF.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
PART NO. DESCRIPTION
5EB–12421–00
93306–00106
93101–12173
11H–12438–10
5EB–12450–00
5SL–12422–00
5EB–12439–00
95024–06020
90430–06014
99009–12400
93210–33133
90110–06086
4NK–12579–00
5VX–12581–00
5EB–12577–01
HOUSING, WATER PUMP 1 1
BEARING 1 1
OIL SEAL 1 1
SEAL, MECHANICAL 1 1
IMPELLER SHAFT ASSY 1 1
COVER, HOUSING 1 1
O-RING 1 1
BOLT, FLANGE 2 2
GASKET 1 1
CIRCLIP 1 1
O-RING 1 1
BOLT, HEXAGON SOCKET HEAD 2 2
HOSE 4 1 1
JOINT, HOSE 1 1 1
HOSE 2 1 1
4S86
4S87
REMARKS
B
7
16
90450–35001
17
5SL–12588–01
18
90450–22017
19
5GV–1246E–00
20
90450–38040
21
5GV–1246A–00
22
90450–32001
23
93210–46001
24
5EB–12469–00
25
90105–06053
HOSE CLAMP ASSY 2 2
HOSE 5 1 1
HOSE CLAMP ASSY 1 1
COVER 2 1 1
HOSE CLAMP ASSY 1 1
COVER 1 1 1
HOSE CLAMP ASSY 1 1
O-RING 1 1
JOINT 1 1 1
BOLT, FLANGE 2 2
FIG. 6 RADIATOR & HOSE
REF.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
PART NO. DESCRIPTION
5SL–12410–00
5VX–12413–00
90105–06557
4S8–12578–00
90450–35001
5GV–1246E–00
4S8–12461–00
4S8–12405–00
97307–06012
92907–06100
92907–06600
1AA–12535–00
4S8–12579–00
90450–32003
90480–15363
THERMOSTAT ASSY 1 1
COVER, THERMOSTAT 1 1
BOLT, FLANGE 2 2
HOSE 3 1 1
HOSE CLAMP ASSY 2 2
COVER 2 1 1
RADIATOR ASSY 1 1
BLOWER ASSY 1 1
BOLT 3 3
WASHER, SPRING 3 3
WASHER, PLATE 3 3
PLATE 3 3
HOSE 4 1 1
HOSE CLAMP ASSY 1 1
GROMMET 3 3
4S86
4S87
REMARKS
B
8
16
90387–0614M
17
5VX–1240J–00
18
90111–06031
19
4S8–12467–00
20
90387–066H4
21
1B3–12462–00
22
5FC–12437–00
23
97004–05012
24
92904–05600
25
90119–06038
26
95824–06030
27
4S8–1244E–00
COLLAR 1 1
RADIATOR COVER ASSY1 2 2
BOLT,HEX. SOCKET BUTTON 4 4
COVER, RADIATOR 1 1
COLLAR 1 1
CAP, RADIATOR 1 1
STOPPER 1 1
BOLT 1 1
WASHER 1 1
BOLT, WITH WASHER 1 1
BOLT, FLANGE 1 1
BRACKET 1 1 1
FIG. 6 RADIATOR & HOSE
REF.
NO.
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
PART NO. DESCRIPTION
95824–06012
4S8–12589–00
90467–200A0
90450–22017
5VX–1243A–00
90467–11090
90467–11090
5VX–1244G–00
90467–11090
90450–32001
4P5–21871–00
26H–21828–00
90445–081F2
3P6–21875–00
90445–08025
BOLT, FLANGE 1 1
HOSE 6 1 1
CLIP 2 2
HOSE CLAMP ASSY 1 1
HOSE 1 1 1
CLIP 2 2
CLIP 1 1
HOSE, 4 1 1
CLIP 2 2
HOSE CLAMP ASSY 1 1
TANK, RECOVERY 1 1
ELBOW 2 2
HOSE (L200) 1 1
CAP 1 1
HOSE 1 1
4S86
4S87
REMARKS
B
9
43
90467–08075
44
4P5–2172W–00
45
4P5–21873–00
46
95024–10020
47
90464–07012
48
90467–08075
49
90464–12238
50
90105–060A6
CLIP 2 2
COVER 1 1
BRACKET, RECOVERY TANK 1 1
BOLT, FLANGE 1 1
CLAMP 1 1
CLIP 1 1
CLAMP 1 1
BOLT, FLANGE 2 2
FIG. 7 OIL PUMP
REF.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
PART NO. DESCRIPTION
5MT–13300–00
91808–17032
90109–06031
5SL–13410–00
5EB–13415–00
94580–25080
5EB–13898–00
90110–06161
2C0–13416–00
93210–14003
90110–06161
5EB–13161–00
5EB–1316E–00
93210–09165
93210–06667
OIL PUMP ASSY 1 1
PIN, DOWEL 2 2
BOLT 3 3
STRAINER HOUSING ASSY 1 1
.SEAL, OIL STRAINER 1 1
CHAIN 1 1
HOLDER 1 1
BOLT, HEXAGON SOCKET HEAD 2 2
PIPE, OIL 1 1 1
O-RING 2 2
BOLT, HEXAGON SOCKET HEAD 2 2
PIPE, DELIVERY 1 1 1
PIPE, DELIVERY 5 1 1
O-RING 2 2
O-RING 1 1
4S86
4S87
REMARKS
B
10
FIG. 8 OIL CLEANER
REF.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
PART NO. DESCRIPTION
5EB–13470–00
5EB–12822–00
5EB–13475–00
5JW–13473–00
5GH–13440–20
90401–20145
3KS–13490–00
93210–15566
4S8–13417–00
90340–14132
214–11198–01
5VX–13414–01
91312–06025
90110–06169
90465–10030
OIL COOLER ASSY 1 1
.BOLT, UNION 1 1
.GASKET 1 1
.O-RING 1 1
ELEMENT ASSY, OIL CLEANER 1 1
BOLT, UNION 1 1
RELIEF VALVE ASSY 1 1
O-RING 1 1
COVER, STRAINER 1 1
.PLUG, STRAIGHT SCREW 1 1
.GASKET 1 1
GASKET, STRAINER COVER 1 1
BOLT 12 12
BOLT, HEXAGON SOCKET HEAD 1 1
CLAMP 1 1
4S86
4S87
REMARKS
B
11
FIG. 9 INTAKE
REF.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
PART NO. DESCRIPTION
5SL–13586–01
5SL–13596–01
91317–06020
90450–63003
5VX–14411–00
5VX–14421–00
5VX–14452–00
97707–50025
5VX–14451–00
5VX–14453–00
5VX–14463–00
90445–11795
90467–10041
90338–08174
90450–53002
JOINT, CARBURETOR 1 2 2
JOINT, CARBURETOR 2 2 2
BOLT 8 8
HOSE CLAMP ASSY 4 4
CASE, AIR CLEANER 1 1 1
CASE, AIR CLEANER 2 1 1
SEAL 1 1
SCREW, TAPPING 6 6
ELEMENT, AIR CLEANER 1 1
JOINT, AIR CLEANER 1 2 2
JOINT, AIR CLEANER 2 2 2
HOSE (L30) 1 1
CLIP 1 1
PLUG 1 1
HOSE CLAMP ASSY 4 4
4S86
4S87
REMARKS
B
12
16
5CA–14435–00
17
90480–12314
18
5VX–15373–00
19
90467–15054
20
5CA–85886–00
21
5VX–14409–00
22
5EJ–2414H–00
23
90387–06073
24
90467–14015
25
5VX–14148–01
26
90467–17089
GROMMET 1 1
GROMMET 2 2
PIPE, BREATHER 1 1
CLIP 1 1
SENSOR, AIR TEMPRATURE 1 1
DAMPER 2 2
DAMPER, PLATE 1 1 1
COLLAR 2 2
CLIP 1 1
PIPE 2 2
CLIP 2 2
FIG. 10 INTAKE 2
REF.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
PART NO. DESCRIPTION
5VX–13750–04
5VX–14348–00
90430–09002
5VX–13761–00
5PS–14147–00
5VX–82380–00
98507–05016
92907–05100
92907–05600
2D1–85885–00
8CC–14216–10
5VX–14149–00
5VX–14565–00
98507–05010
98507–06012
THROTTLE BODY ASSY 1 1
.PIPE 1 2 2
.GASKET 4 4
.INJECTOR 4 4
..O-RING 1 1
.SENSOR, PRESSURE 1 1
.SCREW, PAN HEAD 2 2
.WASHER, SPRING 2 2
.WASHER, PLATE 2 2
.THROTTLE SENSOR ASSY 1 1
.SCREW 2 2
.PIPE 1 1
.SCREW 1 1
.SCREW, PAN HEAD 2 2
.SCREW, PAN HEAD 2 2
4S86
4S87
REMARKS
B
13
16
5VX–14396–00
17
3UH–14937–00
18
5VX–14987–00
19
68V–24376–00
20
3XV–14251–00
21
5FL–14348–10
22
68V–13533–00
23
5VX–1410E–00
24
5PW–14251–00
25
4KM–14137–00
26
5JW–14104–00
27
3H1–14147–00
.PIPE 1 1
.CLIP 8 8
.HOSE 1 1
.PIPE, JOINT 1 2 2
.NIPPLE 1 1
.PIPE 1 4 4
.HOSE, VACUUM SENSING 4 2 2
.HOSE 1 1
.NIPPLE 4 4
.CLIP 1 1
.AIR SCREW SET 4 4
..O-RING 1 1
FIG. 10 INTAKE 2
REF.
NO.
28
29
30
31
32
33
34
35
36
PART NO. DESCRIPTION
5VX–14349–00
90467–11090
5VX–1243E–00
5VX–13160–00
5VX–82386–00
5VX–13533–00
5VX–14807–00
5VX–14503–00
90464–23041
.PIPE 2 2
.CLIP 1 1
.HOSE 2 1 1
.DELIVERY PIPE ASSY 1 1 1
.EXTENSION, WIRE HARNESS 1 1
.HOSE, VACUUM SENSING 4 1 1
.HOSE 1 1
.ADJUST SCREW SET 1 1
.CLAMP 2 2
4S86
4S87
REMARKS
B
14
FIG. 11 AIR INDUCTION SYSTEM
REF.
NO.
1
2
3
4
5
6
7
8
9
PART NO. DESCRIPTION
5VX–14840–00
5VX–14881–00
90467–17089
5VX–14882–00
90467–17089
5VX–14883–00
5JW–14723–00
90467–17003
90467–17128
AIR CUT VALVE ASSY 1 1
HOSE, BEND 1 1 1
CLIP 2 2
HOSE, BEND 2 1 1
CLIP 1 1
HOSE, BEND 3 1 1
COVER 1 2 2
CLIP 2 2
CLIP 1 1
4S86
4S87
REMARKS
B
15
FIG. 12 EXHAUST
REF.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
PART NO. DESCRIPTION
4S8–14610–00
2D1–8592A–00
3YF–14613–01
90179–08410
4S8–21445–00
90105–08063
90105–08021
4S8–14740–00
5VY–14714–00
95814–08045
95812–08035
90201–08034
5VX–21446–10
4XV–27424–00
90387–082W9
EXHAUST PIPE ASSY 1 1 1
.SENSOR, OXYGEN 1 1
GASKET, EXHAUST PIPE 4 4
NUT 8 8
STAY, MUFFLER 1 1 1
BOLT, FLANGE 1 1
BOLT, FLANGE 2 2
CATALYST ASSY. 1 1
.GASKET, MUFFLER 1 1
.BOLT, FLANGE 1 1
BOLT, FLANGE 1 1
WASHER, PLATE 1 1
STAY, MUFFLER 2 1 1
DAMPER, MUFFLER 1 1
COLLAR 1 1
4S86
4S87
REMARKS
C
2
16
92014–08045
17
5VX–14710–01
18
5EB–14714–01
19
95814–08045
20
5VX–1467K–00
21
91317–08030
22
90480–10332
23
95812–08014
24
90201–082U5
25
5VX–14708–10
26
90480–12006
27
90387–061N6
BOLT, BUTTON HEAD 1 1
MUFFLER ASSY 1 1 1
.GASKET, MUFFLER 1 1
.BOLT, FLANGE 1 1
.BRACKET, SILENCER 3 1 1
.BOLT 2 2
.GROMMET 4 4
BOLT, FLANGE 2 2
WASHER, PLATE 2 2
PROTECTOR ASSY 1 1
.GROMMET 2 2
.COLLAR 2 2
FIG. 12 EXHAUST
REF.
NO.
28
29
PART NO. DESCRIPTION
98902–06020
4FB–14766–00
SCREW, BIND 2 2
WASHER, PROTECTOR 2 2
4S86
4S87
REMARKS
C
3
FIG. 13 CRANKCASE
REF.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
PART NO. DESCRIPTION
1B3–15100–01
5EB–15155–00
93210–04092
99530–10014
5VX–13418–00
93210–14579
90110–06161
5SL–15189–00
90149–06082
90105–087A0
90105–086A9
90201–087K3
95812–06055
95812–08065
90109–06168
CRANKCASE ASSY 1 1
.NOZZLE 3 4 4
.O-RING 4 4
.PIN, DOWEL 3 3
PIPE, OIL 2 1 1
O-RING 2 2
BOLT, HEXAGON SOCKET HEAD 2 2
PLUG 1 1
SCREW 1 1
BOLT, FLANGE 8 8
BOLT, FLANGE 2 2
WASHER, PLATE 10 10
BOLT, FLANGE 6 6
BOLT, FLANGE 2 2
BOLT 2 2
4S86
4S87
REMARKS
C
4
16
95812–06065
17
95812–06045
18
95812–06100
19
90105–06147
20
5SL–11165–00
21
90149–06082
22
5VX–15413–01
23
5SL–15462–00
24
91314–06025
25
36Y–15189–00
26
93210–16325
27
5EB–15362–00
BOLT, FLANGE 2 2
BOLT, FLANGE 3 3
BOLT, FLANGE 1 1
BOLT, FLANGE 1 1
PLATE, BREATHER 1 1
SCREW 3 3
COVER 1 1
GASKET, CRANKCASE COVER 3 1 1
BOLT 4 4
PLUG 2 2
O-RING 2 2
PLUG, OIL LEVEL 1 1
Loading...
