YAMAHA F100CET’07 PARTS CATALOGUE 07

F100CET’07 (60D7)

2007/1/31

NEWS NO. DATE COMMENT

PE0-OM-070008 Jan./10/2007 MOD:CYLINDER BLOCK ASSY REVISION
PE0-OM-070014 Jan./14/2007 COR:FIG.21 PTT ASSY LIST/ILLUSTRATION CORRECTION

1F60D-664E1

()

F100CET

PARTS CATALOGUE

©2006 by Yamaha Motor Co., Ltd.

1st edition, September 2006

All rights reserved.

Any reprinting or unauthorized use

without the written permission of

Yamaha Motor Co., Ltd.

is expressly prohibited.

Printed in Japan.

FOREWORD

This Parts Catalogue is related to the parts for the model(s) on the cover page. When you are
ordering replacement parts, please refer to this Parts Catalogue and quote both part numbers
and part names correctly.

1. Modifications or additions which have been made after the issue of the Parts Catalogue
will be announced in the Parts News.
It is advisable that you make the necessary corrections to the Parts Catalogue according
to the Parts News.

2. Abbreviations
The following abbreviations are used in this Parts Catalogue.

“UR” Use specified parts number.
“UN” Use as many as needed.
“AP” Alternate Parts
“LM” Locally Made (Parts need to be ordered locally)
“F#” Frame No. (Applicable machine No.)
“O/S” Over Size

3. The number of components for assembly

• Parts, which are to be supplied in an assembly, are listed with a dot (.) in front of the
part name as shown below.

• The numeral appearing to the right of each component part indicates the quantity of
parts for each assembly unit.

PART NO. DESCRIPTION Q’TY REMARKS

2F5–83310–60 FRONT FLASHER LIGHT ASSY 2

115–83311–60 .BULB (6V–18W) 1

4. Applicable colours of graphics are represented in the “REMARKS” as shown below.

PART NO. DESCRIPTION Q’TY REMARKS

2N4–24110–00–X5 FUEL TANK COMP. 2 MXR

3J1–24240–10 .GRAPHIC, FUEL TANK 1 FOR MXR

5. Note that the illustrations for reference in finding parts numbers are not to be used for
assembling. When assembling, please use the applicable service manual.

6. The asterisk (*) before a reference number indicates modified items after the first edition.

7. Applicable Serial No.

Engine Serial No.

8. Applicable Engine Starting Serial No.

Model Serial No. Model Serial No.

F100C 60D-1000618

9. Applicable Colour Code

Abbreviation Colour Name Colour Code

DBNM2 DARK BLUISH GRAY METALLIC 2 004D

10. Quantity Column Information

Column No. Name Of Q’ty Column Applicable Model

1 60D7 F100CET

TOP COWLING .....................................................................1

CYLINDER & CRANKCASE 1 ..............................................2

CRANKSHAFT & PISTON ....................................................4

CYLINDER & CRANKCASE 2 ..............................................5

VALVE ...................................................................................7

INTAKE .................................................................................10

CARBURETOR 1 ..................................................................11

CARBURETOR 2 ..................................................................13

FUEL .....................................................................................14

GENERATOR ........................................................................16

ELECTRICAL 1 .....................................................................17

ELECTRICAL 2 .....................................................................19

ELECTRICAL 3 .....................................................................21

ELECTRICAL 4 .....................................................................23

STARTING MOTOR ..............................................................24

BOTTOM COWLING .............................................................26

CONTROL .............................................................................28

BRACKET 1 ..........................................................................30

BRACKET 2 ..........................................................................32

OPTIONAL PARTS 1 ............................................................34

POWER TRIM & TILT ASSY 1 .............................................. 35

POWER TRIM & TILT ASSY 2 .............................................. 39

UPPER CASING ...................................................................40

OIL PAN ................................................................................42

LOWER CASING & DRIVE 1 ................................................44

LOWER CASING & DRIVE 2 ................................................47

FUEL TANK ...........................................................................49

STEERING GUIDE ................................................................50

REMOTE CONTROL BOX ....................................................51

REMOTE CONTROL ASSY ..................................................52

METER ..................................................................................55

OPTIONAL PARTS 2 ............................................................56

REPAIR KIT 1 .......................................................................57

REPAIR KIT 2 .......................................................................58

REPAIR KIT 3 .......................................................................59

INDEX

NUMERICAL INDEX .............................................................61

CONTENTS

FIG. 1 TOP COWLING

REF.
NO.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

PART NO. DESCRIPTION

67F–42610–11–4D

67F–42647–00

92990–06100

95380–06600

68V–42652–00

97095–06012

92995–06600

67F–42649–00

67F–42662–00

67F–42613–00–4D

90179–06M24

61N–42628–00

67F–42615–00

67F–42677–10

67F–42678–10

TOP COWLING ASSY 1

.HOLDER, CLAMP BAND 1

.WASHER, SPRING 4

.NUT, HEXAGON 4

.HOOK 2

.BOLT 4

.WASHER 4

.HOLDER, CLAMP BAND 1

.DAMPER 3

.MOLDING, AIR DUCT 1

.NUT 4

.SEAL 1

.SEAL 1

.GRAPHIC, FRONT 1

.GRAPHIC, REAR 1

60D7

REMARKS

16

67F–W0070–10

17

67F–42681–10

18

67F–42682–10

19

67F–42628–00

20

67F–13434–03

.GRAPHIC SET 1

.MARK, COWLING 1

.MARK, COWLING 1

.SEAL 2

LABEL, CAUTION 1

1

FIG. 2 CYLINDER & CRANKCASE 1

REF.
NO.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

PART NO. DESCRIPTION

60C–W009B–05–1S

67F–15100–03–1S

93606–12019

90119–10M88

90119–08M66

90340–14M06

90430–14115

62Y–11119–00

97095–06020

92995–06600

90480–12072

67F–15142–00

6E5–11325–00

98780–04016

67F–41113–20–1S

CYLINDER BLOCK ASSY 1

CRANKCASE ASSY 1

.PIN, DOWEL 10

BOLT, WITH WASHER 10

BOLT, WITH WASHER 10

PLUG, STRAIGHT SCREW 1

GASKET 1

HANGER, ENGINE 2

BOLT 4

WASHER 4

GROMMET 1

GUIDE 1 2

ANODE 3

SCREW, FLAT HEAD 3

OUTER COVER, EXHAUST 1

60D7

REMARKS

Go to P/N:PE0-OM-070008

16

67F–41114–A2

17

90119–06MA4

18

90445–10016

19

90465–11M10

20

6G5–12416–00

21

90501–16M11

22

90480–20M05

23

67F–1246A–01–1S

24

67F–12435–A0

25

90119–06MA2

26

69J–11301–10

27

68V–11325–02

GASKET, EXHAUST OUTER COVER 1

BOLT, WITH WASHER 18

HOSE (L280) 1

CLAMP 2

VALVE, PRESSURE CONTROL 1

SPRING, COMPRESSION 1

GROMMET 1

COVER 1 1

GASKET 1

BOLT, WITH WASHER 3

ANODE COVER ASSY 1

.ANODE 1

2

FIG. 2 CYLINDER & CRANKCASE 1

REF.
NO.

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

PART NO. DESCRIPTION

67F–11328–00

90105–06M07

90430–06M03

97575–08540

67F–1243A–00

90465–11M10

90467–20M15

68V–11351–00

67F–42761–00–94

97095–06025

92995–06600

68F–44533–00

5GH–13440–00

90401–20145

90465–11M10

.GROMMET, ANODE 1

.BOLT, FLANGE 1

.GASKET 1

BOLT, WITH WASHER 1

HOSE 1 1

CLAMP 1

CLIP 1

GASKET, CYLINDER 1

STOPPER 2

BOLT 4

WASHER 4

DAMPER, UPPER MOUNT RUBBER 2

ELEMENT ASSY, OIL CLEANER 1

BOLT, UNION 1

CLAMP 1

60D7

REMARKS

43

67F–13448–00

44

676–11372–00

45

90445–10024

46

90465–11M10

47

90465–10047

48

97095–06012

49

92995–06600

50

90464–10010

51

688–24378–00

52

61A–24316–00

CAP 1

.NIPPE, HOSE 1

HOSE (L360) 1

CLAMP 4

CLAMP 1

BOLT 1

WASHER 1

CLAMP 1

PIPE, JOINT 4 1

PIPE 6 1

3

PARTS NEWS

News No.

Cause

CATALOGUE NO.

Time of YPEC Revision

PE0-OM-070008

Revision Notice Correction Sales Unit Change

Model

Subject

PARTS CATALOGUE CORRECTIONS

Text, Illustration --> Jan./31/2007 PDF Replace --> Jan./31/2007

Others

F100CET '07 (60D7)

1F60D-664E1

(YPEC = Yamaha Parts Electrical Catalogue = Website parts catalogue）

1.LIST CORRECTION

FIG.2 CYLINDER & CRANKCASE 1

Fig.No­Ref.No.

60C-W009B-04-1S

2-1 1

2-15

2-15-1 1

2-16
2-18

2-44 1
2-45
2-46
2-47 1
2-48 1
2-49
2-50 1
2-51

67F-41113-10-1S

­67F-41114-A1
90445-10M40

-

-

-

-

-

-

-

-

NEW P/No.

60C-W009B-05-1S
67F-41113-20-1S
676-11372-00

67F-41114-A2
90445-10016

90445-10024
90465-11M10
90465-10047
97095-06012
92995-06600
90464-10010
688-24378-00
61A-24316-00

CYLINDER BLOCK ASSY
OUTER COVER,EXHAUST
. NIPPLE,HOSE
GASKET,EXHAUST

OUTER COVER
HOSE (L280)
HOSE (L360)
CLAMP
CLAMP
BOLT
WASHER
CLAMP
PIPE,JOINT 4
PIPE 6

PART NAME OLD P/No.

Date:January 10, 2007

Signature: K . Otsuka

*1

1

1

A

1
4

1

1
1

*Part number revision
*Added Parts

*Part number revision

*Added Parts

REMARKSQ'TY

FIG.11 ELECTRICAL 1

11-30

*Applicable Engine Serial No.

MODEL NAME

F100CET

Parts
Manager
Check

-

Service
Manager
Check

67F-82361-00

MODEL CODE

60D7

Parts
Manager
File

CLAMP,CORD

Applicable

Engine Serial No.

60D:1000632-

YAMAHA MOTOR CO.,LTD
2500 Shingai Iwata Shizuoka 438-8501.Japan
Technical Publication Dept.

1

*1: Interchangeability

Old Parts Old Parts

A

New Parts New Parts
Old Parts Old Parts

B

New Parts New Parts
Old Parts Old Parts

C

New Parts New Parts

These parts are interchangeable with a set

*Added Parts

PARTS NEWS

News No.

Cause

CATALOGUE NO.

Time of YPEC Revision

PE0-OM-070008

Revision Notice Correction Sales Unit Change

Model

Subject

PARTS CATALOGUE CORRECTIONS

Text, Illustration --> Jan./31/2007 PDF Replace --> Jan./31/2007

F100CET '07 (60D7)

1F60D-664E1

(YPEC = Yamaha Parts Electrical Catalogue = Website parts catalogue）

2. ILLUSTRATION CORRECTION

FIG.2 CYLINDER & CRANKCASE 1

(OLD) (NEW)

Date:January 10, 2007

Signature: K . Otsuka

Others

FIG.11 ELECTRICAL 1

(OLD) (NEW)

Thank you very much for your cooperation.

Parts
Manager
Check

Service
Manager
Check

Parts
Manager
File

YAMAHA MOTOR CO.,LTD
2500 Shingai Iwata Shizuoka 438-8501.Japan
Technical Publication Dept.

FIG. 3 CRANKSHAFT & PISTON

REF.
NO.

1

2

3

4

PART NO. DESCRIPTION

67F–11411–00

93102–48008

93101–48001

67F–11416–00

CRANKSHAFT 1

OIL SEAL 1

OIL SEAL 1

PLANE BEARING, CRANKSHAFT 1 4 UR GREEN

60D7

REMARKS

67F–11416–10

67F–11416–20

5

67F–11417–00

67F–11417–10

67F–11417–20

67F–11417–30

6

67F–11418–00

67F–11418–10

67F–11418–20

7

60C–W1164–01

60C–W1164–10

8

67F–11654–00

9

60C–11603–00

60C–11604–00

10

6D8–11656–00

6D8–11656–10

6D8–11656–20

PLANE BEARING, CRANKSHAFT 1 4 UR BLUE

PLANE BEARING, CRANKSHAFT 1 4 UR RED

PLANE BEARING, CRANKSHAFT 2 5 UR YELLOW

PLANE BEARING, CRANKSHAFT 2 5 UR GREEN

PLANE BEARING, CRANKSHAFT 2 5 UR BLUE

PLANE BEARING, CRANKSHAFT 2 5 UR RED

PLANE BEARING, CRANKSHAFT 3 1 UR GREEN

PLANE BEARING, CRANKSHAFT 3 1 UR BLUE

PLANE BEARING, CRANKSHAFT 3 1 UR RED

PISTON/CON-ROD ASSY STD 4

PISTON/CON-ROD ASSY(0.25MM OS) 4 AP

.BOLT, CONNECTING ROD 2

PISTON RING SET (STD) 4

PISTON RING SET (0.25MM O/S) 4 AP

PLANE BEARING, CONNECTING ROD 8 UR YELLOW

PLANE BEARING, CONNECTING ROD 8 UR GREEN

PLANE BEARING, CONNECTING ROD 8 UR BLUE

6D8–11656–30

PLANE BEARING, CONNECTING ROD 8 UR RED

4

FIG. 4 CYLINDER & CRANKCASE 2

REF.
NO.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

PART NO. DESCRIPTION

67F–W009A–23–1S

67F–11110–13–94

67F–11133–10

90344–51019

90119–07235

91809–08006

90119–07234

67F–11301–10

68V–11325–02

67F–11328–00

90105–06M07

90430–06M03

97075–08025

92995–08600

97095–08014

CYLINDER HEAD ASSY 1

CYLINDER HEAD ASSY 1

.GUIDE, VALVE 1 16

.PLUG, TAPER SCREW 4

.BOLT/WASHER-CAM CAPS 4

.SLEEVE GUIDE-DOWEL 4

.BOLT, WITH WASHER 16

ANODE COVER ASSY 2

.ANODE 1

.GROMMET, ANODE 1

.BOLT, FLANGE 1

.GASKET 1

BOLT 4

WASHER 4

BOLT 4

60D7

REMARKS

16

90430–08143

17

67F–11181–03

18

90387–10M08

19

90105–10M89

20

90119–08M91

21

68V–11191–00–1S

22

67F–11168–00

23

98507–04008

24

92907–04600

25

90480–12072

26

6D8–11356–01

27

97095–06030

GASKET 4

GASKET, CYLINDER HEAD 1 1

COLLAR 2

BOLT, FLANGE 10

BOLT, WITH WASHER 5

COVER, CYLINDER HEAD 1 1

.COVER, BREATHER 1

.SCREW, PAN HEAD 8

.WASHER 8

GROMMET 2

SEAL, CYLINDER 2 1

BOLT 14

5

FIG. 4 CYLINDER & CRANKCASE 2

REF.
NO.

28

29

30

31

32

33

34

35

36

37

38

PART NO. DESCRIPTION

92995–06600

67F–11192–01

90159–06M29

67F–12411–01

67F–12412–00

68V–12413–00–1S

97095–06025

92995–06600

6G8–15363–00

93210–24M79

94702–00391

WASHER 14

COVER, CYLINDER HEAD 2 1

SCREW, WITH WASHER 5

THERMOSTAT 1

.SEAL, THERMOSTAT 1

COVER, THERMOSTAT 1

BOLT 2

WASHER 2

PLUG, OIL 1

O-RING 1

PLUG, SPARK (NGK LFR5A-11) 4

60D7

REMARKS

6

FIG. 5 VALVE

REF.
NO.

1

2

3

4

5

6

7

8

9

10

PART NO. DESCRIPTION

68V–12111–00

68V–12121–00

67F–12116–00

67F–12114–00

67F–12117–00

67F–12118–00

K0A–A3721–00

K0A–A3722–00

67F–12153–00

67F–12168–00

VALVE, INTAKE 8

VALVE, EXHAUST 8

SEAT, VALVE SPRING 16

SPRING, VALVE OUTER 16

RETAINER, VALVE SPRING 16

COTTER, VALVE 32

SEAL, VALVE STEM 8

SEAL, VALVE STEM 2 8

LIFTER, VALVE 16

PAD, ADJUSTING (2.000) 16 UR

60D7

REMARKS

67F–12168–10

67F–12168–20

67F–12168–30

67F–12168–40

67F–12168–50

67F–12168–60

67F–12168–70

67F–12168–80

67F–12168–A0

67F–12168–B0

67F–12168–C0

67F–12168–D0

67F–12168–E0

67F–12168–F0

67F–12168–G0

67F–12168–H0

67F–12168–J0

PAD, ADJUSTING (2.025) 16 UR

PAD, ADJUSTING (2.050) 16 UR

PAD, ADJUSTING (2.075) 16 UR

PAD, ADJUSTING (2.100) 16 UR

PAD, ADJUSTING (2.125) 16 UR

PAD, ADJUSTING (2.150) 16 UR

PAD, ADJUSTING (2.175) 16 UR

PAD, ADJUSTING (2.200) 16 UR

PAD, ADJUSTING (2.225) 16 UR

PAD, ADJUSTING (2.250) 16 UR

PAD, ADJUSTING (2.275) 16 UR

PAD, ADJUSTING (2.300) 16 UR

PAD, ADJUSTING (2.325) 16 UR

PAD, ADJUSTING (2.350) 16 UR

PAD, ADJUSTING (2.375) 16 UR

PAD, ADJUSTING (2.400) 16 UR

PAD, ADJUSTING (2.425) 16 UR

7

FIG. 5 VALVE

REF.
NO.

10

PART NO. DESCRIPTION

67F–12168–K0

PAD, ADJUSTING (2.450) 16 UR

60D7

REMARKS

67F–12168–L0

67F–12168–M0

67F–12168–N0

67F–12168–P0

67F–12168–R0

67F–12168–S0

67F–12168–T0

67F–12168–U0

67F–12168–V0

67F–12168–W0

67F–12168–X0

67F–12168–Y0

67F–12169–00

67F–12169–10

67F–12169–20

67F–12169–30

67F–12169–40

PAD, ADJUSTING (2.475) 16 UR

PAD, ADJUSTING (2.500) 16 UR

PAD, ADJUSTING (2.525) 16 UR

PAD, ADJUSTING (2.550) 16 UR

PAD, ADJUSTING (2.575) 16 UR

PAD, ADJUSTING (2.600) 16 UR

PAD, ADJUSTING (2.625) 16 UR

PAD, ADJUSTING (2.650) 16 UR

PAD, ADJUSTING (2.675) 16 UR

PAD, ADJUSTING (2.700) 16 UR

PAD, ADJUSTING (2.725) 16 UR

PAD, ADJUSTING (2.750) 16 UR

PAD, ADJUSTING (2.775) 16 UR

PAD, ADJUSTING (2.800) 16 UR

PAD, ADJUSTING (2.825) 16 UR

PAD, ADJUSTING (2.850) 16 UR

PAD, ADJUSTING (2.875) 16 UR

67F–12169–50

67F–12169–60

67F–12169–70

67F–12169–80

67F–12169–A0

67F–12169–B0

67F–12169–C0

67F–12169–D0

67F–12169–E0

PAD, ADJUSTING (2.900) 16 UR

PAD, ADJUSTING (2.925) 16 UR

PAD, ADJUSTING (2.950) 16 UR

PAD, ADJUSTING (2.975) 16 UR

PAD, ADJUSTING (3.000) 16 UR

PAD, ADJUSTING (3.025) 16 UR

PAD, ADJUSTING (3.050) 16 UR

PAD, ADJUSTING (3.075) 16 UR

PAD, ADJUSTING (3.100) 16 UR

8

FIG. 5 VALVE

REF.
NO.

10

PART NO. DESCRIPTION

67F–12169–F0

PAD, ADJUSTING (3.125) 16 UR

60D7

REMARKS

67F–12169–G0

67F–12169–H0

67F–12169–J0

67F–12169–K0

67F–12169–L0

67F–12169–M0

67F–12169–N0

11

67F–12171–00

12

67F–12181–00

13

93605–10108

14

67F–11537–00

15

90119–10M06

16

93102–38M59

17

67F–46241–00

18

67F–11590–00

19

90506–16M39

20

90445–15M03

PAD, ADJUSTING (3.150) 16 UR

PAD, ADJUSTING (3.175) 16 UR

PAD, ADJUSTING (3.200) 16 UR

PAD, ADJUSTING (3.225) 16 UR

PAD, ADJUSTING (3.250) 16 UR

PAD, ADJUSTING (3.275) 16 UR

PAD, ADJUSTING (3.300) 16 UR

CAMSHAFT 1 1

CAMSHAFT 2 1

PIN, DOWEL 2

GEAR, DRIVEN 2

BOLT, WITH WASHER 2

OIL SEAL 2

BELT 1

TENSIONER ASSY 1

SPRING, TENSION 1

HOSE (L23) 1

21

67F–11595–00

22

90119–10M72

23

6D8–11536–00

24

90170–40003

25

90280–04008

PLATE,VALVE 1

BOLT, WITH WASHER 1

GEAR, DRIVE 1

NUT 1

KEY, WOODRUFF 1

9

FIG. 6 INTAKE

REF.
NO.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

PART NO. DESCRIPTION

67F–14243–00

67F–14216–00

67F–14239–00

67F–14271–00

93210–40M10

67F–13641–00–94

97095–06010

90430–06014

97075–08035

92995–08600

91690–50014

67F–13645–00

67F–15373–00

90465–11M10

90467–20M15

PLATE 4

BOLT 8

SEAL 4

INSULATOR 4

O-RING 8

MANIFOLD 1 1

BOLT 4

GASKET 4

BOLT 5

WASHER 5

PIN, SPRING 2

GASKET, MANIFOLD 1 1

PIPE, BREATHER 1

CLAMP 1

CLIP 1

60D7

REMARKS

16

90465–12M03

17

97095–06012

18

92995–06600

19

67F–14440–00

20

90119–06M82

21

93210–41MJ2

22

90119–08M59

CLAMP 2

BOLT 2

WASHER 2

SILENCER ASSY, INTAKE 1

BOLT, WITH WASHER 8

O-RING 4

BOLT, WITH WASHER 3

10

FIG. 7 CARBURETOR 1

REF.
NO.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

PART NO. DESCRIPTION

60C–14901–00

60C–14902–00

60C–14904–00

67F–14923–00

697–14555–00

67F–14146–00

67F–14147–00

97803–04010

676–14966–00

97980–04114

67F–14948–04

67F–14947–00

67F–14943–83

67F–14567–00

67F–14555–00

CARBURETOR ASSY 1 2 #1,3

CARBURETOR ASSY 2 1 #2

CARBURETOR ASSY 4 1 #4

.SCREW, PILOT 4

.SPRING 4

.PLATE 4

.O-RING 4

.SCREW, PAN HEAD 12

.CAP 4

.SCREW, WITH WASHER 16

.JET (#42) 4

.JET, NEEDLE 4

.JET, MAIN (#128) 4

.SCREW 3 #1,2,3

.SPRING 3 #1,2,3

60D7

REMARKS

16

67F–14556–00

17

63V–14523–00

18

90501–10326

19

67F–14998–00

20

67F–14397–00

21

6H2–14578–00

22

67F–14980–00

23

67F–14980–10

24

67F–14984–00

25

6H3–14992–00

26

93210–04230

27

6H4–14985–01

.SPRING 3 #1,2,3

.SCREW, STOP 1 #4

.SPRING, COMPRESSION 1 #4

.BUSH 1 #4

.O-RING 4

.COLLAR 1 #4

.BODY, FLOAT CHAMBER 2 #1,3

.BODY, FLOAT CHAMBER 2 #2,4

.GASKET, FLOAT CHAMBER 4

.SCREW, DRAIN 4

.O-RING 4

.FLOAT 4

11

FIG. 7 CARBURETOR 1

REF.
NO.

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

PART NO. DESCRIPTION

676–14186–00

67F–14159–00

6H4–14548–00

98580–04008

60C–14590–02

93210–04228

67F–14378–00

67F–14380–01

67F–14178–00

67F–14592–00

67F–14398–00

67F–14565–00

67F–14398–10

67F–14398–20

67F–14369–00

.PIN, FLOAT 4

.CLIP 4

.PIN, FLOAT ARM 4

.SCREW, PAN HEAD 4

.NEEDLE VALVE ASSY 4

.O-RING 4

.BODY, STARTER 2 #1,3

.PRIME STARTER ASSY 2 #1,3

.PLATE, STARTER LEVER 2 #1,3

.SCREW 6 #1,3

.O-RING 2 #1,3

.SCREW 2 #1,3

.O-RING 2 #1,3

.O-RING 2 #1,3

.DIAPHRAGM ASSY 2 1 #4

60D7

REMARKS

43

67F–14325–00

44

67F–14371–01

45

67F–14398–30

.SCREW, PAN HEAD 2 #4

.ELEMENT, FILTER 4

.O-RING 2 #1,3

12

FIG. 8 CARBURETOR 2

REF.
NO.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

PART NO. DESCRIPTION

67F–1412A–00

67F–13183–00

67F–14349–00

67F–14349–10

67F–14349–20

67F–14349–30

67F–14349–40

67F–14349–50

67F–14349–60

67F–14585–00

67F–14189–00

67F–14349–70

90465–11M59

68F–24356–00

60C–14294–00

WIRE HARNESS ASSY 1

VALVE, CHECK 1

PIPE 1

PIPE 2

PIPE 2

PIPE 2

PIPE 1

PIPE 1

PIPE 2

ROD, CHOKE 1

CONNECTOR 4

PIPE 1

CLAMP 1

CLIP, PIPE 1 13

HOSE 2

60D7

REMARKS

16

60C–14298–00

17

688–24378–00

18

90445–10M16

19

90445–10MG6

20

90445–10MG7

21

90445–16M07

22

90464–10M57

23

90465–08M83

24

97095–06012

25

92995–06600

PIPE 1

PIPE, JOINT 4 3

HOSE (L120) 2

HOSE (L180) 1

HOSE (L350) 1

HOSE (L80) 4

CLAMP 1

CLAMP 2

BOLT 2

WASHER 2

13

FIG. 9 FUEL

REF.
NO.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

PART NO. DESCRIPTION

689–85547–00

6R3–24377–00

90465–11M10

90445–13M27

60C–24560–00

68V–24521–01

61N–24563–00

93210–32738

68V–24469–01

90465–11M10

68V–24566–00

95380–08600

97095–06016

92995–06600

90445–13M11

DAMPER 1

PIPE, JOINT 3 1

CLAMP 1

HOSE (L950) 1

FILTER ASSY 1

.CUP, FILTER 1

.ELEMENT, FILTER 1

.O-RING 1

.FLOAT, WATER LEVEL 1

CLAMP 2

BRACKET, FILTER 1

NUT 1

BOLT 1

WASHER 1

HOSE (L300) 1

60D7

REMARKS

16

68V–24410–00

17

68V–24412–00

18

68V–24454–00

19

68V–13131–00

20

68V–24423–00

21

68V–24411–00

22

68V–24374–00

23

68V–24413–00

24

68V–24414–00

25

68V–24444–00

26

68V–24149–00

27

90465–11M10

FUEL PUMP ASSY 1

.BODY 1 1

.SPRING 1

.PLUNGER 1

.SPRING, DIAPHRAGM 1

.DIAPHRAGM 1

.PIN 1

.BODY 2 1

.BODY 3 1

.SCREW 3

.NUT 3

CLAMP 2

14

FIG. 9 FUEL

REF.
NO.

28

29

30

31

32

33

34

35

36

37

PART NO. DESCRIPTION

93210–30682

90119–06M83

67F–24575–00

68V–24495–00

91609–25014

90201–08M12

67F–24491–00

90119–07235

91809–08006

67F–28100–01

O-RING 1

BOLT, WITH WASHER 2

LEVER, FUEL CHANGE 1

SHAFT 1

PIN, SPRING 2

WASHER, PLATE 2

BRACKET, FUEL PUMP 1

BOLT/WASHER-CAM CAPS 2

SLEEVE GUIDE-DOWEL 2

TOOL KIT 1

60D7

REMARKS

15
