Xpelair 91175AA, 91173AA, 91154AA, 91174AA User Manual
Specifications and Main Features
- Models:
- 91173AA WA210 Wall Air Conditioner
- 91175AA WHP 210 Wall Air Conditioner and Heat Pump
- 91174AA WA 245 Wall Air Conditioner
- 91154AA WHP 245 Wall Air Conditioner and Heat Pump
- Cooling capacity (kW):
- WA 210: 2.1
- WHP 210: 2.45
- WA 245: 2.45
- WHP 245: 2.035
- Heating capacity (kW):
- WHP 210: 2.035
- WHP 245: 2.64
- Power absorbed during cooling (W):
- WA 210: 790
- WHP 210: 790
- WA 245: 1100
- WHP 245: 1080
- Power absorbed during heating (W):
- WHP 210: 720
- WHP 245: 1320
- Energy efficiency ratio (during cooling):
- WA 210: 2.66
- WHP 210: 2.66
- WA 245: 2.23
- WHP 245: 2.23
- Energy efficiency class during cooling:
- WA 210: A
- WHP 210: A
- WA 245: C
- WHP 245: C
- Energy efficiency class during heating:
- WHP 210: C
- WHP 245: F
- Annual energy consumption in cooling mode (kWx500h):
- WA 210: 395
- WHP 210: 395
- WA 245: 550
- WHP 245: 650
- Dehumidification capacity (l/h):
- WA 210: 1.1
Telecom Room Air Conditioner Dimension, General Data and Attributes
(Maximum Range of remote control)
- - WHP 210: 1.2
- -
- WA 245: 1.2
- - Gas for cooling: R410A
- - Supply voltage (V-Hz): 230-50
- - Number of adjustable internal unit air supply speed: 3
- - Maximum Air Supply (Indoor Unit) m³/h
- -
- WA 210: 350
- - WHP 210: 350
- -
- WA 245: 390
- - WHP 245: 390
- -
- Outdoor Unit
- -
- WA 210: 480
- - WHP 210: 480
- -
- WA 245: 550
- - WHP 245: 550
- -
- WA 210: 480
- - WHP 210: 480
- - WA 245 C: 550 WHP 245 C: 550
- -
- Dimensions of indoor unit Lxhxw (mm): 870x400x280
- - Weight of indoor unit: kg
- -
- WA 210: 43
- - WHP 210: 43
- - WA 245: 46
- - WHP 245: 46
- -
- Maximum range of Remote Controller m: 8
- 2)
Frequently Asked Questions
- - Q: Using this air conditioning unit, will that be no more summer heat?
- - A: The units can either cool or heat, they dehumidify and dries the air making it pleasant feeling as well as gives you comfort by having a choice of fan speed.
- -
- Q: Must I be qualified installer of this air conditioner to install it?
- -
- Answer: You are advised to engage the services of a qualified installer and no other so as to comply with the conditions of the warranty.
- -
- Q: What type of air conditioner gas used in this air conditioner?
- -
- Answer: The air conditioner works on r410a cooling gas.
- Q: What can I do to service the AC?
- A: Making it a routine to wash the air filter and checking for blockages in the air inlet and outlet are a part of the regular servicing.
- Q: What can I do if the AC does not turn on?
- A: Initial issues to inspect should be power outages, tripped circuit breakers, and drained batteries in the remote control.
- Q: What is the maximum distance that the remote control can be used?
- A: The remote should not be used from a distance greater than 8 meters.
- Q: Is this model efficient in energy consumption?
- A: Yes, certain models like the A and A +, have an enhanced cooling efficiency making them appropriate for energy conservation.
- Q: What can be done to fix a water leak?
- A: You must turn off the A/C unit and report the issue to the Xpelair Technical Service for resolving water leaks.
