Xerox Plug-Ins for HP Web Jetadmin (WJA) Installation Guide for HP Web Jetadmin 8.1

Xerox Plug-Ins for HP Web Jetadmin (WJA) 8.1

Installation Instructions

This document will help you to install Xerox plug-in packages for HP Web Jetadmin (WJA) 8.1

Installation Instructions

Note: The package will typically be a file with a ‘.fpm’ extension that will be named similar to
wjadev_xerox_devices.fpm. The file will contain the applicable Xerox product-specific plug-ins.

For example, for the WorkCentre 7655/7665 product family this file would contain the following plug-in
package:

• wjadev_xerox_devices.fpm

Installation Steps:

1. Obtain the filename for the zip file containing the plug-in package from the File Download and
End-User License Agreement page accessed from on

specific plug-in selected.

www.support.xerox.com for the product-

.

2. Unzip the file and locate the filename with a ‘.fpm’ extension (e.g., wjadev_xerox_devices.fpm)

3. Download the ‘fpm package’ into a temp directory

4. Start HP Web Jetadmin

Page 1 of 6

5. Select the Product Update in the left menu tree inside the Navigation area.

6. Click Install

7. Browse the fpm package that should be located in your temp directory

8. Click the Upload button

9. The Available Updates list must show the “New Install HP Web Jetadmin Device Package –
Xerox” message. Select it and click the Install button (see example below)

10. You should see a “Success one package installed” message reporting the operations result
(see example on next page)

Page 2 of 6
