Xerox®Phaser®3320
Printer Symbols
DescriptionSymbol
Warning:
Indicates a hazard that can cause serious injury or death if not avoided.
Hot Warning:
Hot surface on or in the printer. Use caution to avoid personal injury.
Pinch Hazard:
This warning symbol alerts users to areas where there is the possibility
of personal injury.
Laser Warning:
This symbol indicates a laser is being used and alerts the user to refer
to the appropriate safety information.
Caution:
Indicates a mandatory action to taketoavoiddamagetothe property.
Do not touch the part or area of the printer.
Do not touch the part or area of the printer.
Do not expose the drum cartridges to direct sunlight.
Do not burn the item.
Do not burn the toner cartridges.
Do not burn the drum cartridges.
Pinch Hazard:
To avoid personal injury, use caution in this area.
DescriptionSymbol
Hot surface. Wait for the indicated time before handling.
On
Off
Ground/Common/Earth Terminal
Do not use paper attached with staples or any form of binding clip.
Do not use folded, creased, curled, or wrinkled paper.
Do not load or use inkjet paper.
Do not reload paper previously printed on or used.
Do not use postcards.
Do not use envelopes.
Do not copy money.
Add paper or media.
Paper Level Indicator
DescriptionSymbol
Do not load paper in the tray above the MAX line.
Paper Jam
Lock
Unlock
Paper Clip
Cooling
Elapsed Time
Direction Indicator
Load paper/media in the direction indicated.
Push to open.
Flip to open.
Supply Paper
1-Sided Original
2-Sided Original
DescriptionSymbol
Hole-punched Paper
Transparency
Load letterhead face up.
Load letterhead face down.
Load labels face down.
USB
Universal Serial Bus
LAN
Local Area Network
Ethernet Port
Status
WiFi
Weight
Stop Button
Menu Button
OK Button
DescriptionSymbol
Back Button
Power Saver Button
This item can be recycled.
©2016 Xerox Corporation. All rights reserved. Xerox®, Xerox andDesign®, and Phaser®, are trademarks of Xerox Corporation in the United States and / or other
countries. 702P04458 Version 1.0, July 2016
