Xerox Phaser 3115 Setup Guide
C
ONTENTS
Step 1: Unpacking ............................................... 1.1
Selecting a Location ...................................... 1.2
Step 2: Understanding Your Printer ........................ 1.3
Front View ................................................... 1.3
Rear View .................................................... 1.3
Understanding the Control Panel .................... 1.4
Step 3: Installing the Toner Cartridge ..................... 1.5
Step 4: Loading Paper .......................................... 1.7
Step 5: Connecting a Printer Cable ......................... 1.9
Step 6: Turning the Printer on ............................. 1.10
Step 7: Printing a Demo Page .............................. 1.10
Step 8:
Step 9: Viewing the User’s Guide ......................... 1.13
Installing Printer software in Windows
System Requirements ................................. 1.11
In Window 2000/XP .................................... 1.11
In Windows 98/Me ...................................... 1.12
In Windows ............................................... 1.13
In Linux .................................................... 1.13
......... 1.11
ii
1.
Step 1 : Unpacking
1
Remove the Printer and all accessories from the packing
carton. Make sure that the printer has been packed with the
following items:
Toner Cartridge Power Cord
USB Cable CD-ROM
English
Setup Guide
Notes:
• If any items are missing or damaged, notify your dealer
immediately.
• Components may differ from one country to another.
• The CD-ROM contains the printer driver, the User’s Guide, and
the Adobe Acrobat Reader program.
2
Carefully remove all of packing tapes from the printer.
Tape
S
ETTING
U
P
Y
OUR
P
RINTER
1
1.
Clearance
Space
•
Selecting a Location
Select a level, stable place with adequate space for air
circulation. Allow extra space for opening covers and tray. The
area should be well-ventilated and away from direct sunlight or
sources of heat, cold, and humidity. See the image below for
clearance space. Do not place the printer close to the edge of
your desk or table!
100 mm
(3.9 in.)
100 mm
(3.9 in.)
482.6 mm(18.8 in.)
552 mm(21.7 in.)
100 mm
(3.9 in.)
954.6 mm(37.5 in.)
Front : 482.6 mm (enough space so that tray can be
removed)
Back : 100 mm (enough space to allow opening of the rear
•
out tray)
Right : 100 mm (enough space for ventilation)
•
Left : 100 mm
•
2
S
ETTING
U
P
Y
OUR
P
RINTER
1.
Step 2 : Understanding Your Printer
Front View
Top output tray
(Face down)
Tray
Paper level indicator
Toner
cartridge
Output Support
Front Cover
Manual Feeder guide
Manual Feeder
English
Control Panel
Power switch
Rear View
Rear output tray
(Face up)
Power receptacle
USB port
S
ETTING
U
P
Y
OUR
P
RINTER
3
